Search Results (29)

Non-contact magnetic sensing technology is widely adopted in transmission line online monitoring scenarios including current measurement and fault location for its non-contact measurement capability, strong environmental robustness and low deployment cost. However, existing magnetic-sensing-based galloping monitoring methods suffer from two critical limitations: no theoretical guidance is provided for sensor placement, and a high false detection rate is observed under current fluctuation conditions. To address these issues, a novel transmission line galloping monitoring method based on spatial magnetic field distribution features is proposed in this paper. A conductor galloping-power frequency magnetic field coupling model is first established to derive the optimal magnetic sensor array arrangement strategy. Subsequently, a galloping detection algorithm fusing multi-node frequency-domain features and phase difference information is proposed to eliminate current fluctuation induced false detection. Simulations conducted based on actual 500 kV transmission line parameters and verification tests carried out on a scaled-down laboratory platform confirm that reliable galloping detection can be realized by the proposed method under both current low-frequency oscillation and random fluctuation scenarios. With advantages of non-contact deployment, high anti-interference performance and detection accuracy, the proposed method has promising application potential in engineering-oriented high-voltage transmission line monitoring. Full article

Addressing the challenges of topological design and the limitations of global optimization for large-scale photovoltaic (PV) plants in complex terrains, this paper proposes a topology optimization method based on mixed-integer linear programming (MILP). The innovation of the proposed method lies in its use of a MILP framework to integrate complex terrain modeling, quantification of construction difficulty, and coordinated configuration of conductor cross-sections into a single equivalent annual cost optimization model. First, equivalent mathematical models tailored to diverse environmental features—including flat, mountainous, and hilly terrains—are developed to enable accurate spatial identification. Second, aimed at minimizing the total equivalent annual cost (EAC), a MILP model is formulated. This model comprehensively incorporates physical construction difficulties and strict electrical constraints, such as active power flow balance, cable current-carrying capacity, and node voltage deviations. A high-performance solver is then utilized to achieve global optimization for radial topologies. Furthermore, the cross-sectional areas of the conductors are dynamically configured to compensate for power quality losses caused by path detours. Case studies demonstrate that the proposed method significantly reduces the EAC and enhances the overall economic benefits of PV plants while ensuring strict electrical safety across various complex environments. Full article

Let ${\mathrm{\Phi }}_N(X,Y)$ be the N-th classical modular polynomial and let $Z_0\left(N\right)=\{(X,Y)\in {\mathbb{C}}^2\mid {\mathrm{\Phi }}_N(X,Y)=0\}$ be the plane model of the modular curve $X_0\left(N\right)$. We present an explicit procedure that, for a prime ℓ, enumerates all non-cuspidal singular points of $Z_0(\ell )$ over $\mathbb{C}$ and outputs the corresponding pairs of distinct points on $X_0(\ell )$ mapping to each node. The method relies on the arithmetic (CM) classification of self-intersections of the map $X_0(\ell )\to Z_0(\ell )$ and on effective computations of proper ideal classes in imaginary quadratic orders. We also provide a complete and self-contained exposition of Kara’s proof of the automorphism-group equality $Aut\left(E\right)=Aut\left(E^{\prime }\right)$ in the self-intersection setting, making explicit where Kolyvagin’s conductor lemma is used essentially. Finally, we discuss termination, correctness, and practical complexity issues, and we report computational evidence for larger primes using a parallel implementation; in particular, for $\ell =389$, we obtained $151,288$ output pairs in $151,017$ seconds on a 56-core machine. Full article

As a part of the power subsystem in spacecraft, batteries face a less severe environment, but they are sensitive to thermal changes under strict thermal requirements. In order to understand the thermal behavior, the best and cost-effective method is to use a structural thermal representative of the design, apply flight-like conditions, and create a simulation model. In order to fulfill this task, a thermal balance test was applied to a newly developed Li-ion battery’s structural thermal model in this study. The thermal control hardware was designed identical to the flight model, and the tests were conducted on eight scenarios simulating the thermal environment in space. A reduced thermal mathematical model was derived using the experimental data inversion. First, the battery parts that indicate similar temperatures were assumed as a unique node, and each part of the structural thermal model was represented by a single node; the heat exchange between each node was modeled by linear conductors. Due to high temperature differences in higher temperature simulations, the model was updated with radiation conductors, which was called hybrid modeling. It was seen that the final mathematical correlation was satisfied with test cases 4 to 8, which cover the operational and non-operational temperature limits of the Li-ion battery. Full article

This paper addresses the simultaneous feeder routing and conductor sizing problem in unbalanced three-phase distribution systems, formulated as a nonconvex mixed-integer nonlinear program (MINLP) that minimizes the equivalent annualized expansion cost—combining investment and loss costs—under voltage, ampacity, and radiality constraints. The model captures nonconvex voltage–current–power couplings, $\Delta /Y$ load asymmetries, and discrete conductor selections, creating a large combinatorial design space that challenges heuristic methods. An exact MINLP formulation in complex variables is implemented in Julia/JuMP and solved with the Basic Open-source Nonlinear Mixed Integer programming (BONMIN) solver, which integrates branch-and-bound for discrete variables and interior-point methods for nonlinear subproblems. The main contributions are: (i) a rigorous, reproducible formulation that jointly optimizes routing and conductor sizing; (ii) a transparent, replicable implementation; and (iii) a benchmark against minimum spanning tree (MST)-based and metaheuristic approaches, clarifying the trade-off between computational time and global optimality. Tests on 10- and 30-node rural feeders show that, although metaheuristics converge faster, they often yield suboptimal solutions. The proposed MINLP achieves globally optimal, technically feasible results, reducing annualized cost by 14.6% versus MST and 2.1% versus metaheuristics in the 10-node system, and by 17.2% and 2.5%, respectively, in the 30-node system. These results highlight the advantages of exact optimization for rural network planning, providing reproducible and verifiable decisions in investment-intensive scenarios. Full article

This paper presents a heuristic methodology for the optimal expansion of unbalanced three-phase distribution systems in rural areas, simultaneously addressing feeder routing and conductor sizing to minimize the total annualized cost—defined as the sum of investments in conductors and operational energy losses. The planning strategy explores two radial topological models: the Minimum Spanning Tree (MST) and the Steiner Tree (ST). The latter incorporates auxiliary nodes to reduce the total line length. For each topology, an initial conductor sizing is performed based on three-phase power flow calculations using Broyden’s method, capturing the unbalanced nature of the rural networks. These initial solutions are refined via four metaheuristic algorithms—the Chu–Beasley Genetic Algorithm (CBGA), Particle Swarm Optimization (PSO), the Sine–Cosine Algorithm (SCA), and the Grey Wolf Optimizer (GWO)—under a master–slave optimization framework. Numerical experiments on 15-, 25- and 50-node rural test systems show that the ST combined with GWO consistently achieves the lowest total costs—reducing expenditures by up to 70.63% compared to MST configurations—and exhibits superior robustness across all performance metrics, including best-, average-, and worst-case solutions, as well as standard deviation. Beyond its technical contributions, the proposed methodology supports the United Nations Sustainable Development Goals by promoting universal energy access (SDG 7), fostering cost-effective rural infrastructure (SDG 9), and contributing to reductions in urban–rural inequalities in electricity access (SDG 10). All simulations were implemented in MATLAB 2024a, demonstrating the practical viability and scalability of the method for planning rural distribution networks under unbalanced load conditions. Full article

In this paper, we address the problem of intelligent operation of Distribution Static Synchronous Compensators (D-STATCOMs) in power distribution systems to reduce energy losses and CO₂ emissions while improving system operating conditions. In addition, we consider the entire set of constraints inherent in the operation of such networks in an environment with D-STATCOMs. To solve such a problem, we used three master–slave methodologies based on sequential programming methods. In the proposed methodologies, the master stage solves the problem of intelligent D-STATCOM operation using the continuous versions of the Monte Carlo (MC) method, the population-based genetic algorithm (PGA), and the Particle Swarm Optimizer (PSO). The slave stage, for its part, evaluates the solutions proposed by the algorithms to determine their impact on the objective functions and constraints representing the problem. This is accomplished by running an Hourly Power Flow (HPF) based on the method of successive approximations. As test scenarios, we employed the 33- and 69-node radial test systems, considering data on power demand and CO₂ emissions reported for the city of Medellín in Colombia (as documented in the literature). Furthermore, a test system was adapted in this work to the demand characteristics of a feeder located in the city of Talca in Chile. This adaptation involved adjusting the conductors and voltage limits to include a test system with variations in power demand due to seasonal changes throughout the year (spring, winter, autumn, and summer). Demand curves were obtained by analyzing data reported by the local network operator, i.e., Compañía General de Electricidad. To assess the robustness and performance of the proposed optimization approach, each scenario was simulated 100 times. The evaluation metrics included average solution quality, standard deviation, and repeatability. Across all scenarios, the PGA consistently outperformed the other methods tested. Specifically, in the 33-node system, the PGA achieved a 24.646% reduction in energy losses and a 0.9109% reduction in CO₂ emissions compared to the base case. In the 69-node system, reductions reached 26.0823% in energy losses and 0.9784% in CO₂ emissions compared to the base case. Notably, in the case of the Talca feeder—particularly during summer, the most demanding season—the PGA yielded the most significant improvements, reducing energy losses by 33.4902% and CO₂ emissions by 1.2805%. Additionally, an uncertainty analysis was conducted to validate the effectiveness and robustness of the proposed optimization methodology under realistic operating variability. A total of 100 randomized demand profiles for both active and reactive power were evaluated. The results demonstrated the scalability and consistent performance of the proposed strategy, confirming its effectiveness under diverse and practical operating conditions. Full article

This article addresses the optimal network expansion problem in rural distribution systems using a mixed-integer nonlinear programming (MINLP) model that simultaneously performs route selection and conductor sizing in radial distribution systems. The proposed methodology was validated on 9- and 25-node test systems, comparing the results against approaches based on the minimum spanning tree (MST) formulation and metaheuristic approaches (the sine-cosine and tabu search algorithms). The MINLP model significantly reduced the total costs. For the nine-node system, the total cost decreased from USD 131,819.33 (MST-TSA) to USD 77,129.34 (MINLP), saving USD 54,689.99 (41.48%). Similarly, the costs of energy losses dropped from USD 111,746.73 to USD 63,764.12, a reduction of USD 47,982.61 (42.94%). In the 25-node system, the total costs fell by over 65% from USD 371,516.59 to USD 128,974.72, while the costs of energy losses decreased by USD 210,057.16 (61.06%). Despite requiring a higher initial investment in conductors, the MINLP model led to substantial long-term savings due to reduced operating costs. Unlike previous methods which separate network topology design and conductor sizing, our proposal integrates both aspects, ensuring globally optimal solutions. The results demonstrate its scalability and effectiveness for long-term distribution planning in complex power networks. The experimental implementation was carried out in Julia (v1.10.2) using JuMP (v1.21.1) and BONMIN. Full article

In recent years, the scientific and industrial interest regarding alternative technologies for transmission cables has increased. These conductors should efficiently transmit significant amounts of power between grid nodes, which are expected to be particularly congested due to the projected global increase in electricity production. Superconducting cables are considered a promising solution in this context, offering the potential to transmit large amounts of energy with minimal losses and compact dimensions, thereby potentially benefiting the environment. To evaluate the feasibility of integrating superconducting cables into existing grids, techno-economic approaches should be adopted. Such techniques enable the conceptual design of a specific cable structure, allowing users to explore a wide range of operating parameters to derive optimal designs. This paper reports a comprehensive techno-economic analysis of High Voltage Alternating Current (HVAC) cables realized with High-Temperature Superconducting (HTS) tapes, with the aim to transmit extremely high-power level. The optimal coaxial design is selected using Optimization Tool for Superconducting Cable Research (OSCaR) by implementing a graded approach to the critical current of the HTS tapes used for the different phases. This optimization aims to achieve the most effective balance between the cost of the coated conductors and their electrical properties. The whole set of model equations, the user-defined parameters, and the applied constraints are detailed. The OSCaR tool is then applied to assess the impact on the optimized design of the cable system and the corresponding cost indexes of several crucial parameters, such as the maximum transmitted power, the voltage level, and the line length. Full article

The grounding network is a significant component of substations, and the corrosion of its ground resistance is predominantly detected using the electromagnetic method. However, the application of electromagnetic methods for detecting corrosion within earthing networks has received relatively limited attention in research. Currently, the prevailing method utilizes electromagnetic techniques to identify the breakage points within the given earthing network. In this study, we propose a corrosion detection method for grounding networks based on the low-frequency electromagnetic method, which measures the resistance value between individual nodes of the network. Specifically, an excitation source signal of a predetermined frequency was transmitted to the measurement segment of the grounding network, which facilitated the direct measurement of the strength of the induced magnetic field above the center of the measuring conductor. The recorded electromagnetic data were subsequently uploaded to the host computer for data processing, and the computer interface was constructed based on a LABVIEW design. By leveraging the relationship between the induced electric potential, current strength, excitation source strength, and additional voltage detection devices, the resistance of the conductor under examination could be determined. Furthermore, the proposed method was tested under suitable conditions, and it demonstrated favorable results. Thus, the proposed method can serve as a foundation for developing electromagnetic testing instruments tailored to the investigated grounding network. Full article

Single-component molecular conductors exhibit a strong connection to the Dirac electron system. The formation of Dirac cones in single-component molecular conductors relies on (1) the crossing of HOMO and LUMO bands and (2) the presence of nodes in the HOMO–LUMO couplings. In this study, we investigated the possibility of Dirac cone formation in two single-component molecular conductors derived from nickel complexes with extended tetrathiafulvalenedithiolate ligands, [Ni(tmdt)₂] and [Ni(btdt)₂], using tight-biding models and first-principles density-functional theory (DFT) calculations. The tight-binding model predicts the emergence of Dirac cones in both systems, which is associated with the stretcher bond type molecular arrangement. The DFT calculations also indicate the formation of Dirac cones in both systems. In the case of [Ni(btdt)₂], the DFT calculations, employing a vdW-DF2 functional, reveal the formation of Dirac cones near the Fermi level in the nonmagnetic state after structural optimization. Furthermore, the DFT calculations, by utilizing the range-separated hybrid functional, confirm the antiferromagnetic stability in [Ni(btdt)₂], as observed experimentally. Full article

These days, with the significant increase in the use of renewable energy sources as additional energy sources connected to the distribution network, many challenges and difficulties arise in ensuring sustainability and reliability. The generation, transmission and distribution, in the current state of the electricity system, are facing quite dynamic changes. They are the result of the liberalization of the energy market, the increased use of renewable energy sources such as photovoltaic systems, wind turbines and the charging stations for hybrid and electric vehicles. The most important factors are related to the balancing of the energy system, the analysis of voltage stability, overcoming the consequences of the increase in short-circuit currents, increasing the transmission capacities of the system forming and distribution networks, as well as the accurate forecasting of the development of loads and consumption over the coming years. This article presents an analysis of the voltage stability in a smart microgrid for two different scenarios. The studied cases describe a linear low-voltage p-type microgrid with loads connected to it at different nodes. Data on the type and cross-section of the conductors of the studied power line are presented. Simulation studies were carried out to determine the limits of grid voltage stability when connecting photovoltaic plants with a set power. The simulation results are commented on and an analysis of the optimal operating mode of the system is realized. The model studies were implemented in the NEPLAN program environment. The research carried out allows an evaluation of the permissible limits for network stability when connecting photovoltaic plants. Through this evaluation, it can be determined how many and at which node the loads should be connected without causing an imbalance in the network. This is useful from the point of view of ensuring the sustainability and reliability of electrical energy in a microgrid. Full article

Voltage sensing technology is crucial in realizing distributed voltage sensing at critical nodes of the power grid and providing key state variables to provide information support for control decisions. Among the existing voltage measurement methods, voltage transformers have problems such as high insulation performance requirements and limited installation locations. However, non-contact voltage sensors designed based on the electric field coupling principle have sensor accuracy problems due to the instability of the coupling capacitance. Based on the above problems, this paper first proposes a floating ground measurement system based on an equipotential and differential structure. It also proposes a dual capacitance equivalent model for AC voltage measurement on transmission lines. Based on this method, a calibration method for the amplitude and phase of the sensor is built. Under the voltage test at 50 Hz operating frequency in the voltage range (100–300 V), the maximum relative error of the voltage amplitude is 0.89%, and the maximum relative error of the voltage phase is 0.68°. The maximum relative error of voltage amplitude under a 50 Hz operating frequency voltage test in the voltage range (600 V–10 kV) is 4.48%. In the final scenario adaptation analysis, the method’s specific height amplitude accuracy error was experimentally verified to be 0.88%, with a maximum difference of 0.52% for multi-type conductor testing. Full article

This paper proposes and validates using experimental data a dynamic model to determine the current–temperature relationship of insulated and jacketed cables in air. The model includes the conductor core, the inner insulation layer, the outer insulating and protective jacket and the air surrounding the cable. To increase its accuracy, the model takes into account the different materials of the cable (conductor, polymeric insulation and jacket) and also considers the temperature dependence of the physical properties, such as electrical resistivity, heat capacity and thermal conductivity. The model discretizes the cable in the radial direction and applies the finite difference method (FDM) to determine the evolution over time of the temperatures of all nodal elements from the temperatures of the two contiguous nodes on the left and right sides. This formulation results in a tri-diagonal matrix, which is solved using the tri-diagonal matrix algorithm (TDMA). Experimental temperature rise tests at different current levels are carried out to validate the proposed model. This model can be used to simulate the temperature rise of the cable when the applied current and ambient temperature are known, even under short-circuit conditions or under changing applied currents or ambient temperatures. Full article

This paper presents a new methodology to simultaneously solve the optimal conductor selection and optimal phase-balancing problems in unbalanced three-phase distribution systems. Both problems were represented by means of a mathematical model known as the Mixed-Integer Nonlinear Programming (MINLP) model, and the objective function was the minimization of the total annual operating costs. The latter included the costs associated with energy losses, investment in conductors per network segment, and phase reconfiguration at each node in the system. To solve the problem addressed in this study, a master–slave methodology was implemented. The master stage employs a discrete version of the Salp Swarm Algorithm (SSA) to determine the set of conductors to be installed in each line, as well as the set of connections per phase at each of the nodes that compose the system. Afterward, the slave stage uses the three-phase version of the backward/forward sweep power flow method to determine the value of the fitness function of each individual provided by the master stage. Compared to those of the Hurricane-based Optimization Algorithm (HOA) and the Sine Cosine Algorithm (SCA), the numerical results obtained by the proposed solution methodology in the IEEE 8- and 25-node test systems demonstrate its applicability and effectiveness. All the numerical validations were performed in MATLAB. Full article
