Negative Ion Source Neutral beam Injection (NNBI), as a critical auxiliary heating system for magnetic confinement fusion devices, directly affects the plasma heating efficiency of tokamak devices through the reliability of its beam source system. The single-shot experiment constitutes a significant experimental program for NNBI. This study addresses the frequent equipment failures encountered by the NNBI beam source system during a cycle of experiments, employing fault tree analysis (FTA) to conduct a systematic reliability assessment. Utilizing the AutoFTA 3.9 software platform, a fault tree model of the beam source system was established. Minimal cut set analysis was performed to identify the system’s weak points. The research employed AutoFTA 3.9 for both qualitative analysis and quantitative calculations, obtaining the failure probabilities of critical components. Furthermore, the F-V importance measure and mean time between failures (MTBF) were applied to analyze the system. This provides a theoretical basis and practical engineering guidance for enhancing the operational reliability of the NNBI system. The evaluation methodology developed in this study can be extended and applied to the reliability analysis of other high-power particle acceleration systems. Full article

A disruptive Electric Propulsion system is proposed for next-generation Low-Earth-Orbit (LEO) small satellite constellations, utilizing an RF-powered Helicon Plasma Thruster (HPT). This system is built around a Magnetically Enhanced Inductively Coupled Plasma (MEICP) reactor, which enables acceleration of quasi-neutral plasma through a magnetic nozzle. The MEICP reactor features an innovative design with a multi-dipole magnetic confinement system, generated by neodymium iron boron (NdFeB) permanent magnets, combined with an azimuthally asymmetric half-wavelength right (HWRH) antenna and a variable-section ionization chamber. The plasma reactor is followed by a solenoid-free magnetic nozzle (MN), which facilitates the formation of an ambipolar potential drop, enabling the conversion of electron thermal energy into ion beam energy. This study explores the impact of an inhomogeneous magnetic field on the heating mechanism of the HPT and highlights its multi-mode operation within a pulsed power range of 200 to 500 W of RF. The discharge state, characterized by high-energy electron-excited ions and low-energy excited neutral particles in the plasma plume, was analyzed using optical emission spectroscopy (OES). The experimental testing campaign, conducted under pulsed power excitation, reveals that, as RF input power increases, the MEICP reactor transitions from inductive (H-mode) to wave coupling (W-mode) discharge modes. Spectrograms, electron temperature, and plasma density measurements were obtained for the Helicon Plasma Thruster within its operational envelope. Based on OES data, the ideal specific impulse was estimated to exceed 1000 s, highlighting the significant potential of this technology for future LEO/VLEO space missions. Full article

We study the effect of the rotational transform profile on the L–H confinement transitions in the neutral beam-heated plasmas in the TJ-II stellarator. The rotational transform profile in the vacuum is determined by the external coil currents but is modified by the plasma current, $I_p$. We find that L–H confinement transitions systematically occur when the configuration and plasma current are such that a low-order rational is placed in the plasma edge region, with a distribution centered around $\rho =0.8\pm 0.05$. It is suggested that magnetohydrodynamic turbulence plays an important role in triggering the L–H transitions at TJ-II. Full article

Event-driven data acquisition is used to capture information from fast transient phenomena typically requiring a high sampling speed. This is an important requirement in the ITER Neutral Beam Test Facility for the development of one of the heating systems of the ITER nuclear fusion experiment. The Red Pitaya board has been chosen for this project because of its versatility and low cost. Versatility is provided by the hosted Zynq System on Chip (SoC), which allows full configuration of the module architecture and the OpenSource architecture of Red Pitaya. Price is an important factor, because the boards are installed in a hostile environment where devices can be damaged by EMI and radiation. A flexible solution for event-driven data acquisition has been developed in the Zynq SoC and interfaced to the Linux-based embedded ARM processor. It has been successfully adopted in a variety of data acquisition applications in the test facility. Full article

BTR code (originally—“Beam Transmission and Re-ionization”, 1995) is used for Neutral Beam Injection (NBI) design; it is also applied to the injector system of ITER. In 2008, the BTR model was extended to include the beam interaction with plasmas and direct beam losses in tokamak. For many years, BTR has been widely used for various NBI designs for efficient heating and current drive in nuclear fusion devices for plasma scenario control and diagnostics. BTR analysis is especially important for ‘beam-driven’ fusion devices, such as fusion neutron source (FNS) tokamaks, since their operation depends on a high NBI input in non-inductive current drive and fusion yield. BTR calculates detailed power deposition maps and particle losses with an account of ionized beam fractions and background electromagnetic fields; these results are used for the overall NBI performance analysis. BTR code is open for public usage; it is fully interactive and supplied with an intuitive graphical user interface (GUI). The input configuration is flexibly adapted to any specific NBI geometry. High running speed and full control over the running options allow the user to perform multiple parametric runs on the fly. The paper describes the detailed physics of BTR, numerical methods, graphical user interface, and examples of BTR application. The code is still in evolution; basic support is available to all BTR users. Full article

Stable and uniform beams with low divergence are required in particle accelerators; therefore, beyond the accelerated current, measuring the beam current spatial uniformity and stability over time is necessary to assess the beam performance, since these parameters affect the perveance and thus the beam optics. For high-power beams operating with long pulses, it is convenient to directly measure these current parameters with a non-intercepting system due to the heat management requirement. Such a system needs to be capable of operating in a vacuum in the presence of strong electromagnetic fields and overvoltages, due to electrical breakdowns in the accelerator. Finally, the measure of the beam current needs to be efficiently integrated into a pulse file with the other relevant plant parameters to allow the data analyses required for beam optimization. This paper describes the development, design and commissioning of such a non-intercepting system, the so-called beamlet current monitor (BCM), aimed to directly measure the electric current of a particle beam. In particular, the layout of the system was adapted to the SPIDER experiment, the ion source (IS) prototype of the heating neutral beam injectors (HNB) for the ITER fusion reactor. The diagnostic is suitable to provide the electric current of five beamlets from DC up to 10 MHz. Full article

Mathematical modelling of heating and current drive as well as yields and distributions of fusion products in a magnetically confined plasma subject to neutral beam injection requires, in turn, modelling of distributions of fast ions, which is a complex task including calculations of the source of suprathermal particles, i.e., the number of fast ions occurring in unit volume during unit time owing to the injection of fast atoms. The knowledge of the magnetohydrodynamic equilibrium, beam injection geometry and spatial distribution of the magnetic field are the necessary prerequisites. Explicit general analytical formulae for the source of fast ions have been obtained by two different methods. In addition, a method of statistical modelling is presented. Calculations of spatial and angular distributions of the fast ion source for a tokamak and verifications of the obtained results have been performed by a number of methods. Full article

In most present-day tokamaks, the majority of the heating power comes from sources such as neutral-beam injection (NBI) and other types of auxiliary heating which allow for the transfer of energy to the plasma by a small population of externally introduced fast particles. The behavior of the fast ions is important for the overall plasma dynamics, and understanding their influence is vital for the success of any future magnetic confinement devices. In the TUMAN-3M tokamak, it has been noted that the loss of fast particles during NBI can lead to dramatic changes in the rotation velocity profiles, as they are responsible for the negative radial electric field on the periphery. Full article

The reduction of carbon dioxide emissions, introduced by the European Union, opened the possibility of conducting experimental works on a new generation of materials—ecological and environmentally friendly ones. Such materials include those which combine raw natural resources with waste subject to disposal. The objective of the performed investigations was an assessment of the influence of fly ashes on selected parameters of building materials. The paper proposes a method of the enrichment of clay with fly ash, which would lead to the neutralization of heavy metals in the burnt matrix, possible oxidation of organic substances present in the ashes, or the destruction of pathogens, as well as an increase of the resistance of the clay ceramics to low temperatures. Clay samples were prepared with the addition of the fly ash from three sewage treatment plants. The experiments encompassed investigations of physical and chemical properties of the fly ash, as well as bending strength tests of the beam-shaped samples heated at temperatures of 20, 300, 500, and 700 °C. The beam halves, resulting from the destruction of the samples during these tests, served for testing the compressive strength. The collected results allowed a comparison of the properties of the samples. The obtained test results confirm the possibility of manufacturing a product modified with the fly ash from the thermal treatment of sewage sludge. The obtained compressive strength of the samples amounted 0.3–2.6 MPa. Full article

The deflection magnet (DM) is the most important component of the Neutral Beam Injection (NBI) system of Experimental Advanced Superconducting Tokamak (EAST), which can magnetically deflect the un-neutralized charged particles after the neutralized process of the beam is extracted from the ion source, and then form a neutral beam injected into the tokamak. Under the operating conditions of the NBI system, by using the thermocouple monitoring system in the experiment, it can be found that the currently operating DM beam collimator has a quite high temperature rise. It is necessary to redesign the DM beam collimator to improve its heat transfer performance. The parallel arrangement of multiple rows of tubes is proposed as the basic method for the redesign of the beam collimator of DM, the thermal-fluid-structure analysis model of this redesign model is established and its temperature field, pressure field and stress field are analyzed. Taking the surface temperature of the beam collimator, the overall dimension after the total tube combination and the pressure drop of the whole structure of collimator as the optimization objectives, and setting the fluid velocity, the tube’s inner diameter and the number of tube rows as the design variables, the optimized design scheme of the beam collimator structure is obtained. From the results of simulation, the new structure can better meet the operation requirements of DM, and its maximum temperature rise is well controlled, which is expected to meet the long pulse operation requirements of the NBI system. The proposed simulation and design optimization method can provide a certain reference for the design and optimization of other high-heat-flux structures in complex large-scale neutral beam systems in the future. Full article

The neutral beam injector (NBI) generates a high-energy ion beam and neutralizes it, and then relies on drift transmission to inject the formed neutral beam into the fusion plasma to increase the plasma temperature and drive the plasma current. In order to better cooperate with the Experimental Advanced Superconductive Tokamak (EAST), part of the Chinese major national scientific and technological infrastructure, in carrying out long-pulse high-parameter physics experiments of 400 s and above, this paper considers the optimization of the current design and operation of the NBI beam line with a pulse width of 100 s. Based on an upgraded and optimized NBI vacuum chamber and the structure of the beam-line components, the gas-source characteristics under the layout design of the NBI system are analyzed and an NBI vacuum system that meets relevant needs is designed. Using Molflow software to simulate the transport process of gas molecules in the vacuum chamber, the pressure gradient in the vacuum chamber and the heat-load distribution of the low-temperature condensation surface are obtained. The results show that when the NBI system is dynamically balanced, the pressure of each vacuum chamber section is lower than the set value, thus meeting the performance requirements for the NBI vacuum system and providing a basis for subsequent implementation of the NBI vacuum system upgrade using engineering. Full article

For the FNS-ST compact neutron source, the dependence of the neutron yield on the tritium content in the bulk plasma is analyzed for the operation of the heating injectors with different isotope compositions of the neutral beams. Self-consistent simulations of the FNS-ST operating regimes are performed using the SOLPS4.3 and ASTRA codes for different densities of the bulk plasma and diffusion coefficients. The FC-FNS code is used to calculate the required fluxes of the fuel components into the plasma provided by different injection systems: the pellet injectors and the neutral beams. In simulations, the plasma density is varied in the range n_e = (7–10) × 10¹⁹ m⁻³, and the ratio of the diffusivity to the heat conductivity in the range D/χ_e = 0.2–0.6. For the scenarios with the D + T or D beams, in the window of the operating parameters, the maximum possible fractions of tritium in the bulk plasma are calculated, and the corresponding neutron yields are obtained. For the regimes with the maximum neutron yield (4.5–5.5) × 10¹⁷ s⁻¹, the accumulation of tritium at the site (up to 550 g) is calculated for different heating beams. Full article

The overview discusses development of the unique fusion plasma diagnostics—Heavy Ion Beam Probing (HIBP) in application to toroidal magnetic plasma devices. The basis of the HIBP measurements of the plasma electric potential and processing of experimental data are considered. Diagnostic systems for probing plasma in tokamaks TM-4, TJ-1, TUMAN-3M and T-10, stellarators WEGA, TJ-II and Uragan-2M are presented. Promising results of the HIBP projects for various existing modern machines, such as TCV, TCABR, MAST, COMPASS, GLOBUS-M2, T-15 MD and W7-X and the international fusion tokamak reactor ITER are given. Results from two machines with similar size and plasma parameters, but with different types of the magnetic con-figuration: axisymmetric tokamak T-10 and helically symmetric stellarator TJ-II are compared. The results of studies of stationary potential profiles and oscillations in the form of quasimonochromatic and broadband fluctuations, turbulent particle flux, fluctuations of density and poloidal magnetic field are presented. The properties of symmetric structures—zonal flows and geodesic acoustic modes of plasma oscillations as well as Alfvén Eigenmodes excited by fast particles from neutral beam injection heating are described. General trends in the behavior of electric potential and turbulence in magnetized fusion plasmas are revealed. Full article

Cryosorption pumps create a vacuum by adsorbing gas at low temperature through porous solid adsorbents. The transmission probability of gas molecules and heat loads of cryosorption pumps are important factors affecting its performance. Herein, Molflow software based on the Monte Carlo principle is used to analyze the effects of the structural design of cryosorption pumps on transmission probability. The influence of structural design on radiation heat transfer is analyzed by ANSYS Steady-State Thermal software. This provides a reference for the design of a cryosorption pump to validate the prototype of a neutral beam injector for the China Engineering Fusion Experimental Reactor (CFETR). Full article

The large (size: 1 m × 2 m) radio frequency (RF) driven negative ion sources for the neutral beam heating (NBI) systems of the future fusion experiment ITER will be operated at a low filling pressure of 0.3 Pa, in hydrogen or in deuterium. The plasma will be generated by inductively coupling an RF power of up to 800 kW into the source volume. Under consideration for future neutral beam heating systems, like the one for the demonstration reactor DEMO, is an even lower filling pressure of 0.2 Pa. Together with the effect of neutral gas depletion, such low operational pressures can result in a neutral gas density below the limit required for sustaining the plasma. Systematic investigations on the low-pressure operational limit of the half-ITER-size negative ion source of the ELISE (Extraction from a Large Ion Source Experiment) test facility were performed, demonstrating that operation is possible below 0.2 Pa. A strong correlation of the lower pressure limit on the magnetic filter field topology is found. Depending on the field topology, operation close to the low-pressure limit is accompanied by strong plasma oscillations in the kHz range. Full article
