Multilevel inverters (MLIs) have become fundamental in contemporary power electronics, providing enhanced performance compared to conventional two-level inverters regarding their output voltage quality, efficiency, and scalability. This study comprehensively assesses multilevel inverter technologies, including their topologies, control systems, and various applications. The study starts with a comprehensive examination of the core concepts of MLIs, subsequently embarking on a detailed evaluation of both conventional and innovative topologies, such as diode-clamped, flying capacitor, cascaded H-bridge, and modular multilevel converters. The study further examines the control systems used in MLIs, including Pulse Width Modulation (PWM), space vector modulation (SVM), and Model Predictive Control (MPC), emphasizing their benefits and drawbacks. The applications of MLIs in renewable energy systems, electric cars, industrial drives, and grid integration are comprehensively examined. The study closes by examining growing trends, difficulties, and future research paths, emphasizing the ability of MLIs to transform power conversion systems. Full article

In medium-voltage AC applications, multilevel converters are essential due to their ability to achieve high efficiency and significantly reduce total harmonic distortion (THD), ensuring improved performance and power quality. This paper presents a detailed analysis of the efficiency, power loss, and THD characteristics of multiplexed multilevel converters and neutral point clamped converters. Using MATLAB^®Simulink 2024b, the switching and conduction losses of both multiplexed multilevel converters and NPC converters are calculated. The three-level NPC converter offers advantages of a simpler design, reduced component count, and cost effectiveness with the drawback of low voltage quality. Simulation results validate the THD, power losses, and efficiency for the conventional three-phase three-level NPC converter and the three-phase multiplexed multilevel converter, and a detailed comparison is performed. Full article

The problem of balancing capacitor voltages is of utmost importance in multilevel converter topologies involving flying capacitors. In this study, a new minimum angular distance (MAD) algorithm is proposed to control the turning on and off of the switches, ensuring fast convergence of the capacitor voltages balancing problem in multilevel flying-capacitor converters. This algorithm was developed based on a preliminary analytical analysis of the capacitor voltage trajectories using the power-oriented model of the converter. Compared to other approaches, the proposed algorithm involves only simple and well-defined calculations, requires no training, and does not require any prediction of future values that the output current assumes. The proposed algorithm, implemented in the MATLAB/Simulink environment, is proven to give very good performance, verified against an optimal benchmark given by dynamic programming, in terms of capacitor voltages convergence time, efficiency, power loss, and total harmonic distortion. Full article

This paper presents a novel modeling approach for flying capacitor dynamics in boost-type multi-level converters (FCML-boosts) controlled by Phase Shift Pulse Width Modulation (PSPWM). By explicitly taking into account the interaction between the inductor current and the flying capacitor voltage, the model is able to reveal an underlying resonance phenomenon and to predict its frequency at each operating point. Based on such a model, whose derivation is explained in detail, both passive and active damping solutions are proposed, designed, and experimentally verified that significantly reduce the undesirable oscillations. The analytical results and the devised control solutions are tested on a $1\mathrm{k}\mathrm{W}$, four-level, boost DC-DC converter prototype employing $200\mathrm{V}$, $48\mathrm{A}$ rated EPC2034C GaN devices. Full article

With the development of distributed energy technology, the establishment of the energy internet has become a general trend, and relevant research about the core component, energy router, has also become a hotspot. Therefore, the bidirectional isolated DC–DC converter (BIDC) is widely used in AC–DC–AC energy router systems, because it can flexibly support the DC bus voltage ratio and achieve bidirectional power flow. This paper proposes a novel vector reconfiguration on a bidirectional multilevel LCL-T resonant converter in which an NPC (neutral-point clamped) multilevel structure with a flying capacitor is introduced to form a novel active bridge, and a coupling transformer is specially added into the active bridge to achieve multilevel voltage output under hybrid modulation. In addition, an LCL-T two-port vector analysis is adopted to elaborate bidirectional power flow which can generate some reactive power to realize zero-voltage switching (ZVS) on active bridges to improve the efficiency of the converter. Meanwhile, due to the symmetry of the LCL-T structure, the difficulty of the bidirectional operation analysis of the power flow is reduced. Finally, a simulation study is designed with a rated voltage of 200 V on front and rear input sources which has a rated power of 450 W with an operational efficiency of 93.8%. Then, the feasibility of the proposed converter is verified. Full article

This directive proposes an efficiency optimization process in which the flying capacitor multilevel flyback converter (FCMFC) will be designed for the highest efficiency based on component selection, the number of flying capacitor stages, with isolation. The application of interest is a front-end voltage-boosting converter that is part of a solar microinverter. The converter will need high gain and high efficiency over a large range due to the variable input voltage supplied by the output of a solar panel. The electrical specifications are 40 V to 400 V conversion for a 200 W load; however, the input voltage and load power are subject to variability. Full article

The modular multilevel converter (MMC) based on half-bridge modules is a power converter topology suitable for high-power medium-voltage variable-speed drives. However, the voltage of its flying capacitors is negatively affected when low frequencies appear at the AC port. This paper analyzes the influence of using a variable DC port voltage in a machine-side MMC by implementing a closed-loop approach, ensuring a constant voltage fluctuation in the capacitors of the MMC during the whole operating range. The effectiveness of the proposed control scheme is demonstrated through simulation studies and experimental validation tests conducted using a 7.5 kW experimental prototype composed of an induction machine fed by an MMC with 18 half-bridge cells. Full article

Recently, multilevel converters (MLCs) have gained significant attention for stationary applications, including static compensators, industrial drives, and utility-grid interfaces for renewable energy sources. Compared to two-level voltage-source inverters (VSI) MLCs feature high-quality AC voltage with reduced harmonic content despite the lower switching frequency of the semiconductor devices. On the DC side, MLCs can integrate multiple isolated/non-isolated battery modules instead of a single battery pack. This helps to keep the system in service in case of a malfunction of one or more battery modules, as well as active balancing among the modules, a feature not possible with two-level VSI. In general, MLCs can be classified into two types: (i) two-port MLCs, which provide a single interface to connect with the battery pack, and (ii) multiport MLCs, which provide multiple interfaces to allow connection at the module or cell level. The classical topologies of both MLC types (e.g., neutral point clamped, flying capacitor, cascaded bridge) face limitations due to the high switch count. Consequently, many hybrid and reduced-switch topologies are reported in the literature. This paper presents a critical overview of both classical and recently reported MLC topologies and offers a better insight of MLC operation for grid-connected and standalone applications. In addition, the analysis thoroughly assesses various high-level control and modulation strategies while considering active balancing among the battery modules. Other salient features such as balancing speed during offtake/grid-injection mode and fault-ride-through capability are also incorporated. In conclusion, the key findings are summarized for a better understanding of the present and future integration of battery systems in stationary applications. Full article

Standard medium-voltage converters are operated at low switching frequencies using bulky passive components. One concept to change this involves the quasi-two-level operation (Q2O) of multilevel converters that use fast-switching semiconductors to minimize the need for passive components. The flying capacitor converter (FCC) uses SiC semiconductors and operates with Q2O to minimize passive components. In this paper, two different quasi-two-level algorithms are analyzed. A medium-voltage prototype was built and low-voltage and medium-voltage measurements were used to validate the concept. A particular focus is on the overvoltage, the $\mathrm{d}v/\mathrm{d}t$ behavior of the converter, as well as the dynamic behavior. Full article

With the development of space exploration, high-power and high-voltage power systems are essential for future spacecraft applications. Because of the effects of space radiation such as single event burnout (SEB), the rated voltage of power devices in converters for a spacecraft power system is limited to a level much lower than that for traditional ground applications. Thus, multi-level DC/DC converters are good choices for high-voltage applications in spacecraft. In this paper, a fault-tolerant strategy is proposed for a three-level flying capacitor DC/DC converter to increase the reliability with minimal cost. There is no extra hardware needed for the proposed strategy; the fault tolerance of the converter is only achieved by changing the software control strategy. A stage analysis of the proposed strategy is provided in detail for different fault locations and ratios between the input and output voltage. Finally, a simulation model and prototype are built to verify the effectiveness of the proposed strategy. Full article

Multilevel inverters (MLI) consist of a wide range of power converters. They have many designs and have been introduced with different circuit topologies such as neutral point clamped, diode clamped, cascaded H-bridges, and flying capacitors. Some of these MLIs have disadvantages, including design complexity, size, and losses due to the large number of switching devices required when they produce many output voltage levels. They are also bulky in size and may require several DC power sources. This paper presents a review of the various topologies of single-phase T-Type MLIs (T-MLIs). These MLIs are used to convert DC power from renewable energy sources (RES)” into AC with a near-sine waveform and low total harmonic distortion (THD). Simple and complex MLI designs are discussed. The major types of modulation techniques are discussed, including sinusoidal pulse width modulation (SPWM), selective harmonic elimination (SHE), and preprogrammed PWM. Various methods of output voltage control are taken into consideration as well. The aim of this comprehensive survey is to identify T-MLIs for researchers and those interested in the power conversion field, as well as to discuss the many topologies, identifying designs with superior characteristics that can be efficiently implemented with RESs to obtain better AC voltage with enhanced power quality. Full article

Quasi-2-level (Q2L) operation of multi-level bridge-legs, especially of flying-capacitor converters (FCC), is an interesting option for realizing single-cell power conversion in applications whose system voltages exceed the ratings of available power semiconductors. To ensure equal voltage sharing among a Q2L-FCC’s switches, the voltages of a Q2L-FCC’s minimized flying capacitors (FCs) must always be balanced. Thus, we propose a concept for load-independent FC voltage balancing: For non-zero load current, we use a model predictive control (MPC) approach to identify the commutation sequence of the individual switches within a Q2L transition that minimizes the FC or cell voltage errors. In case of zero load current, we employ a novel MPC-based approach using cell multiple switching (CMS), i.e., the insertion of additional zero-current commutations within a Q2L transition, to exchange charge between the FCs via the charging currents of the switches’ parasitic capacitances. Experiments with a 5-level FCC half-bridge demonstrator confirm the validity of the derived models and verify the performance of the proposed load-independent balancing concept. Full article

When performing AC/DC-DC/AC power conversions, multilevel converters provide several advantages as compared to classical two-level converters. This paper deals with the dynamic modeling, control, and robustness assessment of multilevel flying-capacitor converters. The dynamic model is derived using the Power-Oriented Graphs modeling technique, which provides the user with block schemes that are directly implementable in the Matlab/Simulink environment by employing standard Simulink libraries. The performed robustness assessment has led to the proposal of a divergence index, which allows for evaluating the voltage balancing capability of the converter using different voltage vector configurations for the extended operation of the converter, namely when the number of output voltage levels is increased for a given number of capacitors. A new variable-step control algorithm is then proposed. The variable-step control algorithm safely enables the converter extended operation, which prevents voltage balancing issues, even under particularly unfavorable conditions, such as a constant desired output voltage or a sudden load change. The simulation results showing the good performances of the proposed variable-step control as compared to a classical minimum distance approach are finally provided and commented in detail. Full article

This research proposes a four-level T-type inverter that is suitable for low-power applications. The presented topology outranks other types of inverters in terms of a smaller number of semiconductor devices, absence of passive components such as clamping diodes and flying capacitors, low switching and conduction losses, and high efficiency. The proposed topology is free from voltage deviation and unbalanced voltage occurrences that are present in other multilevel converters having clamping diodes or flying capacitors. The proposed inverter can extend to N levels using unequal dc-link voltage sources for medium-voltage application. The inverter employs the simple fundamental frequency staircase modulation technique. Moreover, this paper presents a current commutation strategy to prevent the occurrences of short circuit and minimizing the number of required switching devices and switching transitions, resulting in improving the efficiency of the inverter. This paper also analyses the theoretical converter losses showing lower switching and conduction losses when compared to existing four-level inverters. The experimental validation of the proposed inverter shows its operating feasibility and a low output voltage THD. Full article

At present, renewable energies represent 25% of the global power generation capacity. The increase in clean energy facilities is mainly due to the high levels of pollution generated by the burning of fossil fuels to satisfy the growing electricity demand. The global capacity of generating electricity from solar energy has experienced a significant increase, reaching 505 GW in 2018. Today, multilevel inverters are used in PV systems to convert direct current into alternating current. However, the use of multilevel inverters in renewable energies applications presents different challenges; for example, grid-connected systems use a transformer to avoid the presence of leakage currents. The grid-connected systems must meet at least two international standards analyzed in this work: VDE 0126-1-1 and VDE-AR-N 4105, which establish a maximum leakage current of 300 mA and harmonic distortion maximum of 5%. Previously, DC/AC converters have been studied in different industrial applications. The state-of-the-art presented in the work is due to the growing need for a greater use of clean energy and the use of inverters as an interface between these technologies and the grid. Also, the paper presents a comparative analysis of the main multilevel inverter voltage-source topologies used in transformerless PV systems. In each scheme, the advantages and disadvantages are presented, as well as the main challenges. In addition, current trends in grid-connected systems using these schemes are discussed. Finally, a comparative table based on input voltage, switching frequency, output levels, control strategy used, efficiency, and leakage current is shown. Full article
