Search Results (22)

Embedded fiber Bragg gratings are increasingly applied for in-situ strain measurement in fiber-reinforced plastics, integral to high-end aerospace equipment. Existing research primarily focuses on in-plane strain measurement, limited by the fact that fiber Bragg gratings are mainly sensitive to axial strain. However, out-of-plane strain measurement is equally important for comprehending structural deformation. The birefringence of fiber Bragg gratings shows promise for addressing this problem; yet, the strain transfer relationship between composites and optical fibers, along with the decoupling method for multi-directional strains, remains inadequately explored. This study introduces an innovative method for multi-directional strain measurement in fiber-reinforced plastics using the birefringence of a single-fiber Bragg grating. The strain transfer relationship between composites and embedded optical fibers was derived based on Kollar’s analytical model, leading to the development of a multi-directional strain decoupling methodology. This method was experimentally validated on carbon fiber/polyetherimide laminates under thermo-mechanical loading. Its reliability was confirmed by comparing experimental results and finite element simulations. These findings significantly broaden the application scenarios of fiber Bragg gratings, advancing the in-situ measurement technology crucial for the next generation of high-end aerospace equipment. Full article

The theoretical and practical achievements in the field of the theory of strength and reliability of composite materials are discussed in a review conducted on the scientific research conducted on the effect of delamination on the reliability and quality of composites. The methodological aspects of the stability of the mechanical characteristics of composite materials under the combined action of cyclic and impact loads are examined, as are the manufacturing and processing technologies. The reasons for delamination, such as technological, manufacturing and application, free edge, joints and loads, are revealed. The influence of delamination on the bearing capacity of structural elements made of composite materials is analyzed. The mechanism of delamination growth is outlined, and the criteria and processes are defined, such as the growth of delamination cracks in a multidirectional laminated plate from a straight edge, edge delamination during plate bending, delamination in plates in the field of residual stresses, etc. The importance of taking into account the visco-plastic effect at the top of the edge crack of delamination of composite materials is emphasized. The concept of critical delamination behavior is characterized, and the issues of delamination stability are described. Full article

In order to compare and analyze the seismic response characteristics of a safety-related nuclear structure on a non-rock site in the condition of raft and pile group foundations under unidirectional and multidirectional seismic motion input, a large-scale shaking table test of the soil-nuclear structure system was carried out in this paper. In the test, the soil was uniform silted clay, and the shear wave velocity was 213 m/s. Considering the similarity of the superstructure natural frenquency, the actual nuclear power structure was simplified to a three-story frame shear wall structure model. The annular laminated shear model box was used to take the boundary effect of soil into consideration; the seismic motions = were input in only one horizontal direction or three directions at the same time for the shaking table test, and the results were analyzed. The results of the test show that the acceleration response of the safety-related nuclear plant is affected by the directions of input seismic motion and the forms of the foundation. When the seismic motion is input simultaneously in three directions, the acceleration responses of the horizontal motion and vertical rocking of the safety-related plant are larger than those of the single-direction input. The acceleration response of the horizontal motion and vertical rocking of the safety-related structure with the pile group foundation is smaller than that with the raft foundation. The values of most frequency bands in the horizontal acceleration Fourier amplitude spectrum at the top of the pile-foundation structure are smaller than that at the top of the raft-foundation structure, while the displacement is basically the same as that of the raft-foundation structure. This is related to the relation between the frequency component of input seismic motion and the natural frequency of the structure system. Therefore, it is more reasonable to use three-dimensional seismic input in the seismic response analysis of nuclear power plants. The seismic performance of nuclear power plants can be enhanced by using pile group foundations. Full article

It is well known that the use of continuous reinforcing fibers can largely improve the typical low in-plane mechanical properties of 3D-printed parts. However, there is very limited research on the characterization of the interlaminar fracture toughness of 3D-printed composites. In this study, we investigated the feasibility of determining the mode I interlaminar fracture toughness of 3D-printed cFRP composites with multidirectional interfaces. First, elastic calculations and different FE simulations of Double Cantilever Beam (DCB) specimens (using cohesive elements for the delamination, in addition to an intralaminar ply failure criterion) were carried out to choose the best interface orientations and laminate configurations. The objective was to ensure a smooth and stable propagation of the interlaminar crack, while preventing asymmetrical delamination growth and plane migration, also known as crack jumping. Then, the best three specimen configurations were manufactured and tested experimentally to validate the simulation methodology. The experimental results confirmed that, with the appropriate stacking sequence for the specimen arms, it is possible to characterize the interlaminar fracture toughness in multidirectional 3D-printed composites under mode I. The experimental results also show that both initiation and propagation values of the mode I fracture toughness depend on the interface angles, although a clear tendency could not be established. Full article

The ultrasonic detectability of buried defects within composite materials is dependent on the anisotropy of the composite material by which the propagation property of acoustic wave in each direction is variably affected. In this study, the characteristics of acoustic waves propagating in different directions for composite materials are explored based on the full matrix capture (FMC) data using an ultrasonic phased array. The elastic constant of multidirectional carbon fiber reinforced plastic (CFRP) laminate is first derived based on the genetic algorithm. The characteristics of transmitted and reflected waves in higher angles are predicted by implementing the Christoffel equation, and the focal law used in post-processing of FMC data can be optimized accordingly. The imaging results of the total focusing method (TFM) using the improved focal law are compared with the results of the conventional TFM. The results suggest that the optimized TFM can effectively characterize the defect by reducing the background noise. Furthermore, since it is impractical to theoretically correct angle-dependent velocity for in situ inspection, a linear extrapolation method based on the experimentally measurable velocity at low angles is proposed to estimate the velocity profile at higher angles. The imaging results using the fast extrapolated velocity profile is then compared with the theoretical, and it has been demonstrated that while the difference between the images using the theoretical focal law and the linearly extrapolated one is barely visible, the later one is overwhelmingly advantageous to be realiszd for engineering practices. Full article

Quasi-static or cyclic loading of an artificial starter crack in unidirectionally fibre-reinforced composite test coupons yields fracture mechanics data—the toughness or strain-energy release rate (labelled G)—for characterising delamination initiation and propagation. Thus far, the reproducibility of these tests is typically between 10 and 20%. However, differences in the size and possibly the shape, but also in the fibre lay-up, between test coupons and components or structures raise additional questions: Is G from a coupon test a suitable parameter for describing the behaviour of delaminations in composite structures? Can planar, two-dimensional, delamination propagation in composite plates or shells be properly predicted from essentially one-dimensional propagation in coupons? How does fibre bridging in unidirectionally reinforced test coupons relate to delamination propagation in multidirectional lay-ups of components and structures? How can multiple, localised delaminations—often created by impact in composite structures—and their interaction under service loads with constant or variable amplitudes be accounted for? Does planar delamination propagation depend on laminate thickness, thickness variation or the overall shape of the structure? How does exposure to different, variable service environments affect delamination initiation and propagation? Is the microscopic and mesoscopic morphology of FRP composite structures sufficiently understood for accurate predictive modelling and simulation of delamination behaviour? This contribution will examine selected issues and discuss the consequences for test development and analysis. The discussion indicates that current coupon testing and analysis are unlikely to provide the data for reliable long-term predictions of delamination behaviour in FRP composite structures. The attempts to make the building block design methodology for composite structures more efficient via combinations of experiments and related modelling look promising, but models require input data with low scatter and, even more importantly, insight into the physics of the microscopic damage processes yielding delamination initiation and propagation. Full article

The stiffness of composite laminates is easily affected by wrinkle defects. In this paper, a new effective analytical model was proposed to predict the three-dimensional equivalent elastic properties of multidirectional composite laminates with wrinkle defects. Firstly, a geometric model was established according to the microscopic characteristics of wrinkle defects. Then, based on the classical laminate theory and homogenization method, the constitutive equation and flexibility matrix of the wrinkle region were established. Finally, the equivalent stiffness parameters of unidirectional and multidirectional laminates were derived, and the effects of different wrinkle parameters and ply-stacking sequences on the stiffness of unidirectional and multidirectional laminates were studied by using the analytical model. The results show that the mechanical properties of the lamina and laminates are affected by the out-of-plane angle and in-plane angle of the wrinkle defects. The accuracy of the analytical model has been verified by the numerical model and other theoretical models, and it has the characteristics of few parameters and a high efficiency. The analytical model can be used to predict the stiffness of composite structures with wrinkle defects simply, effectively, and quantitatively. It can also be used as a tool to provide the mechanical response information of laminates with wrinkle defects. Full article

Due to the abrasive nature of the material, the conventional machining of CFRP composites is typically characterised by high mechanical forces and poor tool life, which can have a detrimental effect on workpiece surface quality, mechanical properties, dimensional accuracy, and, ultimately, functional performance. The present paper details an experimental investigation to assess the feasibility of wire electrical discharge machining (WEDM) as an alternative for cutting multidirectional CFRP composite laminates using high-performance wire electrodes. A full factorial experimental array comprising a total of 8 tests was employed to evaluate the effect of varying ignition current (3 and 5 A), pulse-off time (8 and 10 µs), and wire type (Topas Plus D and Compeed) on material removal rate (MRR), kerf width, workpiece surface roughness, and surface damage. The Compeed wire achieved a lower MRR of up to ~40% compared with the Topas wire when operating at comparable cutting parameters, despite having a higher electrical conductivity. Statistical investigation involving analysis of variance (ANOVA) showed that the pulse-off time was the only significant factor impacting the material removal rate, with a percentage contribution ratio of 67.76%. In terms of cut accuracy and surface quality, machining with the Compeed wire resulted in marginally wider kerfs (~8%) and a higher workpiece surface roughness (~11%) compared to the Topas wire, with maximum recorded values of 374.38 µm and 27.53 µm Sa, respectively. Micrographs from scanning electron microscopy revealed the presence of considerable fibre fragments, voids, and adhered re-solidified matrix material on the machined surfaces, which was likely due to the thermal nature of the WEDM process. The research demonstrated the viability of WEDM for cutting relatively thick (9 mm) multidirectional CFRP laminates without the need for employing conductive assistive electrodes. The advanced coated wire electrodes used in combination with higher ignition current and lower pulse-off time levels resulted in an increased MRR of up to ~15 mm³/min. Full article

In this paper, a failure theory for the multidirectional fiber-reinforced composite laminate with a circular hole is developed. In this theory, the finite fracture mechanics method is combined with the improved Puck’s failure theory including the in situ strength effect. It can predict the notched strength by only basic material properties of unidirectional laminas, geometries and stacking sequence of the laminate. In advance mechanical properties of the laminate are unnecessary. The notched laminates with different material types and stacking sequences are taken as examples to verify this failure theory, and predicted results are in good agreement with experiments. Based on the developed failure theory, importance measurement of uncertain material properties to the notched strength is analysed. Results show that notched strength increases with increasing longitudinal tensile strength and in-plane shear modulus for the laminate with an arbitrary hole diameter. However, it decreases with increasing transverse modulus. Full article

Carbon-fiber-reinforced polymers (CFRPs) are the standard lightweight composite material for structural applications in aviation. The addition of metallic fibers to CFRPs to form metal/carbon-fiber hybrid composites (MCFRPs) has been shown to improve the elastic and plastic properties and to enable a non-destructive method for structural health monitoring over the material’s service life. In this paper, the results from the fatigue experiments on these hybrid composites at −55, 25 and 120 °C are discussed. Multidirectional CFRP and MCFRP laminates, fabricated using the autoclave method, were tested and compared under different fatigue loading conditions, while being simultaneously monitored for temperature and electrical resistance. Magnetic phase measurements were additionally carried out for the chosen metastable austenitic steel fibers in the MCFRPs. The results show that the improved ductility of the hybrid composite due to the presence of the steel fibers leads to better performance under fatigue loads and a less-brittle failure behavior. Based on the chemical composition of the metastable austenitic steel fibers, a temperature and plastic deformation-dependent phase transformation was observed, which could potentially lead to a method for non-destructive structural health monitoring of the hybrid composite over its service life. Full article

Damage evolution inside compression-loaded laminates is a crucial aspect when designing crash structures. In this study, ex situ CT scanning is used to identify damage evolution in multidirectional composite laminates. Multiple CT scans throughout the stress–strain envelope are used to quantify the internal damage and failure propagation of a [45, −45, 90]_s carbon fiber laminate. Initially, observed damage occurs in form of delamination between the −45° and 90° layers. Afterward, shear failure propagates from the central layers throughout the entire laminate. Shear failure in the middle two layers expands after continued loading up to double shear failure. The same distinct failure sequence is observed in multiple specimens, and the small deviation supports consistency. Furthermore, the stress–strain envelope of the successive load cycles matches closely with reference measurements. Full article

This study investigated the mechanism of delamination damage in the double cantilever beam (DCB) standard test by the use of the strain energy release rate. The curve of the strain energy release rate was verified by the Rise Angle (RA) method. For this purpose, 24-layer carbon fiber/epoxy multidirectional laminates with interface orientations of 0°, 30°, 45°, and 60° were fabricated according to the standard ASTM D5528(13). In the course of this test, acoustic emission (AE) was used for real-time monitoring, and combined with micro visualization, the damage mechanism of composite multidirectional laminates was studied at multiple scales. Combining the AE detection results with micro visualization, it is found that the AE parameters and the damage to multidirectional laminates could realize a one-to-one correspondence. Through the study of the variation of the RA value, load, and strain energy release rate with the crack length, it is proved that the AE parameters can effectively characterize the initiation of delamination damage. Full article

A model that predicts the stiffness degradation in multidirectional reinforced laminates due to off-axis matrix cracks is proposed and evaluated using data from fatigue experiments. Off-axis cracks are detected in images from the fatigue tests with automated crack detection to compute the crack density of the off-axis cracks which is used as the damage parameter for the degradation model. The purpose of this study is to test the effect of off-axis cracks on laminate stiffness for different laminate configurations. The hypothesis is that off-axis cracks have the same effect on the stiffness of a ply regardless of the acting stress components as long as the transverse stress is positive. This hypothesis proves to be wrong. The model is able to predict the stiffness degradation well for laminates with a ply orientation similar to the one used for calibration but deviates for plies with different in-plane shear stress. This behavior can be explained by the theory that off-axis cracks develop by two different micro damage modes depending on the level of in-plane shear stress. It is found that besides influencing the initiation and growth of off-axis cracks, the stiffness degradation is also mode dependent. Full article

This paper proposes a multi-scale analysis technique based on the micromechanics of failure (MMF) to predict and investigate the damage progression and ultimate strength at failure of laminated composites. A lamina’s representative volume element (RVE) is developed to predict and calculate constituent stresses. Damages that occurred in the constituents are calculated using separate failure criteria for both fiber and matrix. Subsequently, the volume-based damage homogenization technique is utilized to prevent the localization of damage throughout the total matrix zone. The proposed multiscale analysis procedure is then used to investigate the notched and unnotched behavior of three multi-directional composite layups, [30, 60, 90, −60, 30]_2S, [0, 45, 90, −45]_2S, and [60, 0, −60]_3S, subjected to static tension and compression loading. The specimen is fabricated from unidirectionally reinforced composite (IM7/977-3). The prediction of ultimate strength at failure and equivalent stiffness are then benchmarked against the experimental test data. The comparative analysis with various failure models is also carried out to validate the proposed model. MMF demonstrated the capability to correctly predict the ultimate strength at failure for a range of multidirectional composites laminates under tensile and compressive load. The numerically predicted findings revealed a good agreement with the experimental test data. Out of the three investigated composite layups, the simulated results for the quasi-isotropic [0, 45, 90, −45]_2S layup agreed extremely well with the experimental results with all the percentage errors within 10% of the measured failure loads. Full article

The application of fiber-reinforced plastic (FRP) composites as structural elements of air vehicles provides weight saving, which results in a reduction in fuel consumption, fuel cost, and air pollution, and a higher speed. The goal of this research was to elaborate a new optimization method for a totally FRP composite construction for helicopter floors. During the optimization, 46 different layer combinations of 4 different FRP layers (woven glass fibers with phenolic resin; woven glass fibers with epoxy resin; woven carbon fibers with epoxy resin; hybrid composite) and FRP honeycomb core structural elements were investigated. The face sheets were composed of a different number of layers with cross-ply, angle-ply, and multidirectional fiber orientations. During the optimization, nine design constraints were considered: deflection; face sheet stress (bending load, end loading); stiffness; buckling; core shear stress; skin wrinkling; intracell buckling; and shear crimping. The single-objective weight optimization was solved by applying the Interior Point Algorithm of the Matlab software, the Generalized Reduced Gradient (GRG) Nonlinear Algorithm of the Excel Solver software, and the Laminator software. The Digimat-HC software solved the numerical models for the optimum sandwich plates of helicopter floors. The main contribution is developing a new method for optimizing a totally FRP composite sandwich structure—due to its material constituents and construction—that is more advantageous than traditional helicopter floors. A case study validated this fact. Full article
