Search Results (19)

This article presents an original, multi-depth soil-temperature monitoring system based on TMP117 digital sensors designed for deployment at several depths. The objective was to evaluate the system’s accuracy and applicability for building-energy performance assessment under contemporary climate conditions. Urban measurements at depths between 1.0 and 2.0 m were compared with ground temperatures derived using PN-EN 16798-5-1:2017-07 with Typical Meteorological Year (TMY) inputs and with observations from the Polish Institute of Meteorology and Water Management (IMWM). Standard inputs underestimated soil temperature on average by 1.1–2.3 °C (TMY) and 2.0–2.8 °C (IMWM), with the bias increasing with depth. For a ground-to-air heat-exchanger (GAHE) assessment, energy benefits estimated from standard inputs were lower in measurements by approximately 30–60% for pre-cooling and 70–86% for pre-heating. Measurements also revealed location-dependent differences between boreholes attributable to underground infrastructure. These findings indicate that non-local or outdated climate datasets can materially overestimate GAHE potential and confirm the need for local, multi-depth ground measurements and periodic updates of standard climate inputs to reflect urbanized conditions and climate change. The presented system constitutes a practical, scalable tool for engineers and designers of HVAC systems relying on ground heat exchange. Full article

In many decarbonization scenarios, heat pumps are seen as a key technology for future heating needs. However, market shares for large-capacity heat pumps are still low despite the potential for significant CO₂ reduction. In particular, boiler replacements face the obstacle of insufficient heat sources due to restrictions imposed by the built environment. In this study, overcoming the restriction of individual heat sources through dual-source integration has been investigated, both by simulation and field monitoring. The results confirm that by downsizing the individual heat sources, limitations relating to noise emissions or drilling space can be overcome. For instance, by combining the ground as a heat source for 50% of the peak load coverage with outdoor air as the base load heat source, the length of the borehole heat exchanger can be reduced by up to 80% compared to when using only the ground as a heat source. Through regeneration of the ground, boreholes can be drilled closer together, and their length can be reduced by more than 50%. Cost-optimal regeneration rates were found to be between 40 and 80%. The related cost savings can make the dual-source system more cost-effective than a single-source system, even without limitations on any individual heat source. Simulation results are verified in a pilot and demonstration (P&D) plant for a boiler replacement in two larger multi-family homes. The first winter measurements confirm the basic simulation results. CO₂ saving potentials are estimated to be around 90%. Ongoing monitoring will further verify results and derive standard configurations and best practices. Full article

Medium-deep borehole heat exchanger (BHE) systems represent an emerging form of ground source heat pump technology. Their heat transfer process is significantly influenced by geothermal gradient and soil stratification, typically simulated using segmented finite line source (SFLS) models. However, this approach involves computationally intensive procedures that hinder practical engineering implementation. Building upon an SFLS model adapted for complex geological conditions, this study proposes a comprehensive simplified algorithm: (1) For soil stratification: A geothermally-weighted thermal conductivity method converts layered heterogeneous media into an equivalent homogeneous medium; (2) For geothermal gradient: A temperature correction method establishes fluid temperatures under geothermal gradient by superimposing correction terms onto uniform-temperature model results (g-function model). Validated through two engineering case studies, this integrated algorithm provides a straightforward technical tool for heat transfer calculations in BHE systems. Full article

Geothermal energy, as a clean, low-carbon, widely distributed, renewable and environmentally friendly energy source, plays an important role in the transition from traditional energy sources dominated by coal and oil to clean energy. Ground source heat pump technology is a key technological tool for developing geothermal energy for widespread use. Coaxial-cased heat exchangers are the core component of the ground source heat pump system, and their heat transfer performance directly affects the heat transfer efficiency and service life of the ground source heat pump system. According to the actual working conditions of coaxial-cased heat exchangers in fractured aquifers, the coupled pressure–temperature model of the heat transfer outside the borehole was created by considering the influence of the Joule–Thompson effect. For heat transfer inside the wellbore, a multi-layer long concentric cylinder wall model was developed to obtain the fluid temperature distribution within the wellbore. Results show that the heat transfer efficiency increases with the increase of thermal conductivity, water production and effective permeability of fractures. The positive and negative values of the Joule–Thompson coefficient reflect the trend of fluid temperature changing with pressure. The larger the absolute value is, the greater the temperature change is. The increase in the initial temperature of the injected water will lead to a decrease in the theoretical heat transfer. With the increase of the water injection rate and horizontal wellbore length, the heat recovery power will also increase significantly, but the optimal value needs to be considered comprehensively. The findings of the study can not only lay a theoretical foundation for the performance evaluation and optimal design of coaxial-cased heat exchangers but also have great significance in promoting the efficient development of geothermal energy. Full article

Mid-deep geothermal heat pump systems (MD-GHPs) use mid-deep borehole heat exchangers (MDBHEs) to extract heat from the geothermal energy at a depth of 2–3 km, and have been used for space heating in China over the last decade. This paper proposes a comprehensive and multilevel evaluation-index system to analyze and evaluate the energy performance of MD-GHPs. The multilevel evaluation index system consists of a target layer, a criterion layer, and an index layer, where the criterion layer is subdivided into six aspects and the index layer includes 26 specific indices, reflecting the geothermal resources, heat transfer performance of the MDBHEs, energy efficiency of the heat pump systems, building space heating demand, grid dynamic response capability, and energy-saving and economic benefits. Then, based on both expert survey results and case study data, the entropy weight method and the analytic hierarchy process are integrated to determine indicator weight coefficients among the multilevel evaluation indices, comprehensively considering both subjective and objective analyses. Furthermore, a fuzzy comprehensive evaluation model is conducted to integrate these weighted indices into a multi-criteria evaluation of MD-GHP performance. Finally, the proposed method was applied to evaluate the practical performance of four projects, returning scores of 61.56, 58.33, 72.73, and 78.41. These evaluations enable an overall assessment of the energy performance of MD-GHPs, reflecting the technical weaknesses and offering optimization guidance for system design and operation. Full article

Ground-source heat pumps with deep borehole heat exchangers can fully utilize deep geothermal energy, effectively reducing the consumption of non-renewable energy for building air conditioning and achieving energy conservation and emissions reduction goals. However, the middle–deep coaxial borehole heat exchange (MDBHE) development is insufficient, and there is currently a lack of definitive guidelines for system optimal design and operation. This paper firstly establishes an effective and efficient system model and examines nine important parameters related to the design and operation of the MDBHE using a single-factor analysis. Thereafter, we compare and analyze the impact of different parameters through an orthogonal experimentation method. The findings reveal that the three most significant factors are borehole depth, inlet temperature, and mass flow rate, in descending order of importance. In addition, in terms of operation mode, this paper makes a comparative analysis of the operation of the MDBHE in variable flow mode and constant flow mode. The results showed that the average energy consumption of the pump in the variable flow mode decreased by 9.6%, and the surrounding ground temperature recovered at a faster rate. Full article

As an energy-efficient and low-carbon technology, ground-source heat pumps are promising to contribute to carbon neutrality in the building sector. A crucial component of these systems is the ground heat exchanger, which has been extensively studied through sandbox experiments. These experiments play a vital role in understanding heat transfer characteristics and validating simulation results. In order to facilitate the improvement of ground heat exchangers and the development of ground-source heat-pump systems, this article provides a comprehensive summary of existing sandbox experiments. The borehole sandbox experiments are classified into the single borehole experiment, borehole group experiment, seepage experiment, and multi-layer soil experiment. It was observed that the heat transfer efficiency of a single spiral tube is only 80% compared to that of a double spiral tube. Moving on to energy-pile sandbox experiments, they are further divided into mechanical performance, thermal performance, and thermal-mechanical coupled performance tests. It was revealed that the heat transfer distance of a single U-shaped energy pile in the radial direction is three times greater than in the vertical direction. For the mentioned sandbox experiments, the sandbox design, experiment conduction, testing conditions, and result analyses are summarized. To improve the sandbox experiments, there are still some difficulties in building a similarity experiment, testing the temperatures in a small error, controlling the boundary conditions accurately, and testing the thermophysical properties of soil accurately. Furthermore, the perspectives of sandbox experiments of ground heat exchangers are also proposed. The sandbox experiments under complex environment conditions or with novel composite energy geo-structures or ground heat exchangers with new materials and new technologies would be further investigated. By addressing these aspects, this review aims to provide guidelines for the design, construction, operation, and optimization of sandbox experiments for different ground heat exchangers, ultimately promoting the wider adoption of ground-source heat pumps in achieving carbon neutrality. Full article

The purpose of the present work was to determine the thermal performance of borehole heat exchangers, considering the influences of their geometric configurations and the thermophysical properties of the soil, grout and pipe wall material. A three-dimensional model was developed for the heat and mass transfer in soil (a porous medium) and grout, together with one-dimensional conductive heat transfer through the pipe walls and one-dimensional convective heat transfer of the heat transfer fluid circulating in the pipes. An algorithm was developed to solve the mathematical equations of the model. The COMSOL Multiphysics software was used to implement the algorithm and perform the numerical simulations. An apparatus was designed, installed and tested to implement the thermal response test (TRT) method. Two wells of depth 50 m were drilled in the Almaty region in Kazakhstan. Gravel and till/loam were mainly found, which are in accordance with the stratigraphic map of the local geological data. In each well, two borehole heat exchangers were installed, which were an integral part of the ground source heat pump. The TRT measurements were conducted using one borehole heat exchanger in one well and the data were obtained. The present TRT data were found to be in good agreement with those available in literature. The numerical results of the model agreed well with the present TRT data, with the root-mean-square-deviation within 0.184 °C. The TRT data, together with the predictions of the line-source analytical model, were utilized to determine the soil thermal conductivity (${\lambda }_g$ = 2.35 W/m K) and the thermal resistance of the borehole heat exchanger from the heat transfer fluid to the soil ($R_b$ = 0.20 m K/W). The model was then used to predict the efficiencies of the borehole heat exchangers with various geometric configurations and dimensions. The simulation results show that the spiral borehole heat exchanger extracts the highest amount of heat, followed by the multi-tube, double U-type parallel, double U-type cross and single U-type. It is also found that the spiral configuration can save 34.6% drilling depth compared with the conventional single U-type one, suggesting that the spiral configuration is the best one in terms of the depth and the maximum heat extracted. The simulation results showed that (i) more heat was extracted with a higher thermal conductivity of grout material, in the range of 0.5–3.3 W/m K; (ii) the extracted heat remained unchanged for a thermal conductivity of pipe material higher than 2.0 W/m K (experiments in the range of 0.24–0.42 W/m K); (iii) the extracted heat remained unchanged for a volumetric flow rate of water higher than 1.0 m³/h (experimental flow rate 0.6 m³/h); and (iv) the heat extracted by the borehole heat exchanger increased with an increase in the thermal conductivity of the soil (experiments in the range of 0.4–6.0 W/m K). The numerical tool developed, the TRT data and simulation results obtained from the present work are of great value for design and optimization of borehole heat exchangers as well as studying other important factors such as the heat transfer performance during charging/discharging, freezing factor and thermal interference. Full article

Shallow geothermal energy is a clean and effective form of energy that can overcome the problems associated with the depletion of carbon-based energy carbon emissions. Due to the special hydrogeological conditions in karst regions, the heat transfer between heat exchange boreholes and the ground formation is a complicated, multi-physical process. The abundant groundwater flow plays an important role in the heat transfer process, and even presents an opportunity to mitigate the heat imbalance during the long term operation of ground-coupled heat pumps (GCHP). In this study, both laboratorial experiments and numerical simulations were performed to analyze the mechanism that shows how fracture water impacts on heat capacity and the thermal imbalance of the energy storage rock mass. The results showed that the overall temperature fluctuation of the rock mass was reduced by the fracture water, and the temperature curve with time became gentler, which means in practice that the heat imbalance in the rock mass could be delayed. However, the temperature contour map showed that the impact of the fracture water flow was constrained in the nearby areas and decreased obviously with distance. The temperature field was also dragged along the direction of the fracture water flow. During the shutdown period, the fracture water significantly enhanced the thermal recovery ability of the rock mass. The results will assist in further understanding the mechanism of heat transfer and energy balance in a rock mass with fracture water flow. It is proposed that the U pipes should be located at zones with abundant fracture water if the construction condition permits. U pipes that are near the fractures should share more of the load or a denser layout could be possible as their heat transfer capacity is improved by the water flow. Full article

The study of heat transfer in ground heat exchangers (GHEs) considering the fluid advection inside the pipes; the heat transfer between the fluid and the ground through the grout material; and the thermal interaction between GHEs is a challenging task. The present paper presents a new semi-analytical method that takes into account the aforementioned effects to consider both the short- to long-term effects of GHEs. The heat transfer between the fluid and grout was studied by a transient multipole expansion considering time-dependent fluid temperatures and an advection model for the pipes obtained from an energy balance on the heat carrier fluid. Thermal interactions were analyzed using an equivalent borehole method while penalizing the transient multipole expansion to include thermal interaction effects. Validation of the short-term predictions was performed by comparing the proposed model to experimental data found in the literature and to an FEA model. The proposed model was then compared with a FEA model in long-term simulations of a geothermal field comprised of 24 GHEs for multi-annual simulation. The method resulted in substantial reduction in computational time while preserving good accuracy when compared with the FEA model. Full article

Just as the double-pipe heat exchanger is being utilized in an increasing number of applications, its research content is also deepening. For this paper, based on the air-conditioning cold and heat source project of a building in Handan, Hebei Province, a 300-meter medium-shallow well double-pipe heat exchanger was used for heating and cooling, and a corresponding heat transfer model was established. The changes of parameters such as the inlet and outlet temperature, heat exchange (with and without a temperature gradient), and borehole wall temperature distribution between a single borehole, double boreholes, and four boreholes over one year in medium-shallow wells were simulated and analyzed. By comparing the obtained experimental data and the simulation data, the accuracy of the heat transfer model was verified. This provides a theoretical basis for the further advancement of the project and lays the foundation for an in-depth study of multi-borehole double-pipe heat exchangers. Full article

In this numerical study, 4 types of hybrid nanofluid, including Ag-MgO/water, TiO₂-Cu/water, Al₂O₃-CuO/water, and Fe₃O₄-multi-wall carbon nanotube/water, have been considered potential working fluid in a single U-tube borehole heat exchanger. The selected hybrid nanofluid is then analyzed by changing the volume fraction and the Reynolds number. Based on the numerical results, Ag-MgO/water hybrid nanofluid is chosen as the most favorable heat carrier fluid, among others, considering its superior effectiveness, minor pressure drop, and appropriate thermal resistance compared to the pure water. Moreover, it was indicated that all cases of Ag-MgO/water hybrid nanofluid at various volume fractions (from 0.05 to 0.20) and Reynolds numbers (from 3200 to 6200) could achieve better effectiveness and lower thermal resistances, but higher pressure drops compared to the corresponding cases of pure water. Nevertheless, all the evaluated hybrid nanofluids present lower coefficient of performance (COP)-improvement than unity which means that applying them as working fluid is not economically viable because of having higher pressure drop than the heat transfer enhancement. Full article

To investigate the impacts of using nano-enhanced phase change materials on the thermal performance of a borehole heat exchanger in the summer season, a three-dimensional numerical model of a borehole heat exchanger is created in the present work. Seven nanoparticles including Cu, CuO, Al₂O₃, TiO₂, SiO₂, multi-wall carbon nanotube, and graphene are added to the Paraffin. Considering the highest melting rate and lowest outlet temperature, the selected nano-enhanced phase change material is evaluated in terms of volume fraction (0.05, 0.10, 0.15, 0.20) and then the shape (sphere, brick, cylinder, platelet, blade) of its nanoparticles. Based on the results, the Paraffin containing Cu and SiO₂ nanoparticles are found to be the best and worst ones in thermal performance improvement, respectively. Moreover, it is indicated that the increase in the volume fraction of Cu nanoparticles could enhance markedly the melting rate, being 0.20 the most favorable value which increased up to 55% the thermal conductivity of the nano-enhanced phase change material compared to the pure phase change material. Furthermore, the blade shape is by far the most appropriate shape of the Cu nanoparticles by considering about 85% melting of the nano-enhanced phase change material. Full article

A conventional ground-coupled heat pump (GCHP) can be used to supplement heat rejection or extraction, creating a hybrid system that is cost-effective for certainly unbalanced climes. This research explores the possibility for a hybrid GCHP to use excess heat from a combined heat power (CHP) unit of natural gas in a heating-dominated environment for smart cities. A design for a multi-family residential building is considered, with a CHP sized to meet the average electrical load of the building. The constant electric output of the CHP is used directly, stored for later use in a battery, or sold back to the grid. Part of the thermal output provides the building with hot water, and the rest is channeled into the GCHP borehole array to support the building’s large heating needs. Consumption and weather data are used to predict hourly loads over a year for a specific multi-family residence. Simulations of the energies exchanged between system components are performed, and a cost model is minimized over CHP size, battery storage capacity, number of boreholes, and depth of the borehole. Results indicate a greater cost advantage for the design in a severely heated (Canada) climate than in a moderately imbalanced (Ohio) climate. Full article

In this study, a mobile measuring device was developed and a thermal response test that applied a standing column well-type heat exchanger was conducted to obtain design parameters from field measurements. The main purpose of this study was to investigate the effects of thermal conductivity and geothermal resistance on site, including the flow and effects of natural convection of groundwater in boreholes. We compared, analyzed, and investigated the effective thermal conductivity of a borehole heat exchanger system and the effective thermal conductivity that was not applied when bleeding single-well standing column wells (SCWs), which is called an open-type standing column well geothermal heat exchanger system. We also investigated the heat transfer characteristics during the bleeding of two-well type SCWs, where water is injected from one clearing hole to the returning hole depending on the bleeding rate. Artificial recharging was used to inject the change of thermal conductivity from the bleeding rate of a geothermal heat exchanger into another SCW type. From the comparison results of the thermal conductivity of the multi-well and single-well underground heat exchangers, four times higher efficiency than the single-well was obtained. The reason for this is considered to be energy utilization utilizing groundwater energy. Full article
