In recent years, the global demand for renewable energy has been steadily increasing, and offshore wind power generation technology has thus developed rapidly, with the optimization of the performance of the pitch control system, as a key technology to ensure the efficient and safe operation of wind turbines, becoming a research hotspot. Offshore wind turbines face complex environmental changes, particularly regarding the load perturbations caused by wind speed, wind direction, waves, and other factors, which have a significant impact on the stability and accuracy of the pitch control system. In order to reduce the impact of load disturbance on pitch accuracy, this paper proposes a pitch control strategy with load disturbance compensation. Firstly, the relationship between hydraulic cylinder displacement and pitch angle is analyzed; then, the mathematical model comparing hydraulic cylinder displacement, servo motor speed, and external load disturbance force is constructed; the hydraulic cylinder position control strategy with load disturbance compensation is proposed; and finally, the effectiveness of the control strategy is verified through simulations and experiments. Full article

Hydraulic linear drive systems with conventional proportional valves result in poor energy efficiency due to resistance control. In systems with multiple actuators connected to one common pressure supply, a load-sensing strategy is often used to reduce these throttling losses. However, like conventional cylinder actuators, common load-sensing systems are also not able to recuperate the energy, which is actually released when a dead load is lowered. In order to overcome these drawbacks, in this paper, new concepts of a digital hydraulic smart actuator and a load-sensitive pressure supply unit are presented, which are qualified to reduce throttling losses and, furthermore, to harvest energy from the load. According to previous research, the basic concepts used in this contribution promise energy savings in the range of 30% for certain applications, which is one of the main motivations for this study. The operating principles are based on a parallel arrangement of multiple hydraulic switching converters, representing so-called digital hydraulic transformers. Furthermore, the storage module of the presented load-sensitive pressure supply unit is able to boost the hydraulic power in the common pressure rail beyond the maximum power of the primary motor. For exemplary operating cycles of the smart actuator and the pressure supply unit, a significant reduction in the energy consumption could be shown by simulation experiments, which offers a new perspective for energy-efficient motion control. Full article

This paper presents a study on the thermal behavior of an electro-hydrostatic servo actuator designed to actuate the ailerons of an airliner. The considered servo actuator was designed using existing commercial off-the-shelf components (electric motor, pump, hydraulic cylinder, valves, hydro-accumulator), and the control part was tuned using numerical simulations performed in SIMCENTER/AMESIM. This study begins with the functional parameters of the components used in the design and uses numerical simulations to test the thermal behavior of the components. A continuous stress spectrum of the servo actuator is considered, with the servo actuator located in a compartment inside the wing. Different external conditions are also considered, such as situations where component wear occurs and component efficiencies deteriorate, thus producing more heat in the system. Based on the energy losses identified, the average efficiency of the studied servo actuator is also evaluated. Full article

This study focuses on a hydraulic cylinder that is directly connected to a fixed-displacement hydraulic pump driven by an electric servo motor. This particular setup is referred to as a one-motor-one-pump motor-controlled hydraulic cylinder (MCC). This paper presents a new approach to address mode switching oscillation (MSO) in MCCs by incorporating system pressure control capabilities. It conducts a detailed investigation into the factors that contribute to MSO in standard MCCs and thoroughly evaluates the effectiveness of the proposed system in mitigating MSO. The simulation results demonstrate the successful suppression of MSO. In conclusion, the proposed MCC with system pressure control capabilities is validated and, furthermore, it shows great potential for practical applications involving small loads and rapid retraction. Full article

The conventional hydraulic system of excavators suffers from significant valve throttling losses and inadequate matching between the hydraulic power source and the load, which substantially impact the system’s overall energy consumption and severely impede the trend toward electrification and energy efficiency in construction machinery. To address this issue, a pump-controlled hydraulic cylinder system has been implemented to replace the original valve-controlled hydraulic system that utilizes a single pump with multiple actuators. The influence of energy conversion efficiency and the speed between the motor and the hydraulic pump under varying load-power conditions has been determined through experimental investigations. Based on these findings, a compound-control strategy is proposed that adjusts the displacement of the hydraulic pump to achieve precise control over the position of the hydraulic cylinder and facilitates both the speed and displacement coordination while ensuring optimal motor speed matching with the load power. This strategy is implemented in the boom pump’s hydraulic cylinder control system. The research findings indicate that this combined-control approach enhances efficiency by approximately 18.9% compared with traditional variable-speed pump-controlled hydraulic cylinder systems. Furthermore, energy consumption is reduced by about 39% compared with the conventional valve-controlled hydraulic system. Full article

A directional valve is a core component of the electro-hydraulic shakers in fatigue testing machines, controlling the cylinder or motor that drives the piston for reciprocating linear or rotary motion. In this article, a high-speed rotating directional valve with a symmetrical flow channel layout is designed to optimize the force on the valve core of the directional valve. A comparative analysis is conducted on the flow capacity of valve ports with different shapes. A steady-state hydrodynamic mathematical model is established for the valve core, the theoretical analysis results of which are verified through a Computational Fluid Dynamics (CFD) simulation of the fluid domain inside the directional valve. A prototype of the rotatory directional valve is designed and manufactured, and an experimental platform is built to measure the hydraulic force acting on the valve core to verify the performance of the valve. The displacement curves at different commutation frequencies are also obtained. The experimental results show that the symmetrical flow channel layout can significantly optimize the hydraulic force during the movement of the valve core. Under a pressure of 1 MPa, the hydraulic cylinder driven by the prototype can achieve a sinusoidal curve output with a maximum frequency of 60 Hz and an amplitude of 2.5 mm. The innovation of this design lies in the creation of a directional valve with a symmetric flow channel layout. The feasibility of the design is verified through modeling, simulation, and experimentation, and it significantly optimizes the hydraulic forces acting on the spool. It provides us with the possibility to further improve the switching frequency of hydraulic valves and has important value in engineering applications. Full article

Among various motor-controlled hydraulic cylinder (MCC) topologies, the two-motor-two-pump (2M2P) MCC distinguishes itself through several notable advantages, including precise cylinder pressure control and eliminating mode switch oscillations. Nevertheless, there are challenges remaining in fully realizing its operations across four quadrants and establishing an effective load-holding function within these operations. This study bridges this gap by implementing a 2M2P MCC prototype on a laboratory knuckle boom crane, enabling operation across all four quadrants. Experimental results indicate that position tracking errors remain within ±2.5 mm across three cases, which is well below 1% of the total cylinder travels in the experiments. Furthermore, smooth intersection of cylinder-bore-side and rod-side pressures is observed during transitions between quadrants. In conclusion, the proposed 2M2P MCC demonstrates seamless operation throughout all quadrants, with the load-holding function smoothly activating and deactivating in all four quadrants. Full article

Adaptive active suspension systems, integral to specialized vehicles, hold significance for their stability and safety. This study introduces a novel adaptive active suspension system featuring four independently controlled wheels employing wheel-hub motors, hydraulic cylinders, pump motor power, controllers, and sensors. A rapid and, within a certain range, leveling and height adjustment control strategy is proposed for this system, utilizing the Kalman filter algorithm. Additionally, the paper examines the front-wheel Ackermann steering model and four-wheel reverse Ackermann transition model to enhance the suspension’s stability. Subsequently, experiments on leveling and height adjustment are conducted, demonstrating the system’s capability to swiftly and accurately rectify the vehicle’s deviation angle within the specified threshold. Following adjustments made by the leveling and height control algorithm, the vehicle body promptly returns to the preset level state and designated height. The leveling control system holds broad applicability in intelligent agriculture, logistics handling, off-road equipment, and other domains, presenting significant practical utility. Full article

The improvement of the energy efficiency of hydraulic systems remains an essential challenge for industry, and the demand for more sustainable solutions is increasing. A main focus in this endeavor is the ability to eliminate or strongly reduce the use of throttle control valves which have been the preferred control element in industrial hydraulic systems for decades. Components have been subject to continuous evolution, and current industrial grade hydraulic pumps and motors are both efficient and reliable. Even though few percentages of energy efficiency can still be achieved, the main achievements in terms of efficiency are associated with novel system designs rather than further development of components. An area subject to increasing attention is the field of variable-speed displacement control, allowing to avoid the main control valve throttle losses. Systems using this technology are, however, mainly developed as standalone drive systems, necessitating maximum force, speed, and power installed in each axis, with limited hydraulic power distribution capability compared to valve-controlled systems. An emerging field addressing this challenge is that of so-called electro-hydraulic variable-speed drive networks, which allow to completely eliminate the use of control valves and enable power sharing both electrically and hydraulically, potentially reducing the necessary installed power in many cases. The idea of such a technology was first proposed in 2022, and so far developments reported in the literature have mainly been of a theoretical nature. This article presents the first ever experimental results for a dual-cylinder electro-hydraulic variable-speed drive network prototype. The prototype was developed for an industrial application, but has initially been implemented in a laboratory testbench. Extensive data acquisition has been conducted while subject to the associated industrial motion cycle, under different load conditions. The data obtained are further used in combination with models to predict the total efficiency of the drive network prototype under higher loads than what could be achieved in the laboratory, suggesting a total efficiency from the electric supply to the cylinder pistons of 68%. Re-configuring the prototype to a known standalone drive system structure implies comparable efficiencies. Finally, the drive network is theoretically compared to a valve drive solution, generally suggesting that the prototype drive network can provide efficiency improvements of at least 40% in comparison. Full article

This paper is concerned with a hydraulic cylinder directly controlled by a variable speed motor-driven fixed-displacement pump. The considered configuration is referred to as a one-motor-one-pump (1M1P) motor-controlled hydraulic cylinder (MCC). A 1M1P MCC with a hydraulically driven passive load-holding function enabled by controlled system pressures is proposed. The proposed load-holding functionality works if there is a standstill command, a loss of power supply, or a hose rupture. Additionally, this paper conducts a comprehensive analysis of the proposed system’s operation and load-holding function across four quadrants. The simulation results demonstrate four-quadrant operation and good load-holding performance under the aforementioned scenarios. In conclusion, the proposed 1M1P MCC can be successfully used on practical applications characterized by overrunning loads and four quadrant operation. Full article

The electro-hydrostatic actuator (EHA) is a new type of high-performance servo actuator that originated in the field of aerospace, and it is gradually becoming a common basic component for various types of large equipment. A miniature EHA, mainly composed of a micro two-dimensional (2D) piston pump and a brushless DC motor, is designed in this article by simplifying the system structure. This paper analyzes the structure and working principle of this EHA and establishes the mathematical models of the brushless DC motor, micro two-dimensional pump, and hydraulic cylinder. Field-oriented control (FOC) is used to drive the brushless DC motor, and the models of the controller are established in Simulink. Furthermore, the models of the mechanical and hydraulic systems of the miniature EHA are established in AMESim. In addition to this, a prototype of this miniature EHA was fabricated in this paper and an experimental platform was built for experiments. In the joint simulation environment, the rise time of the EHA system at 6000 r/min is 0.158 s and the frequency response amplitude attenuation to −3 dB has a bandwidth of 20 Hz. On the other hand, the constructed miniature EHA prototype was dynamically characterized to obtain a rise time of 0.242 s at 6000 r/min and a bandwidth of 13 Hz. In this paper, the feasibility of the design scheme of the miniature EHA system is verified, and its excellent dynamic properties are verified with simulation and experiment. Full article

At present, the hydraulic systems of electric forklifts and traditional internal combustion forklifts are mostly valve-controlled speed-regulation systems, which have large throttling losses and potential energy waste. To further improve the energy-saving ability of electric forklifts, the forklift’s common working conditions are analyzed in this paper. A throttling loss energy-regeneration system based on pressure difference pump control is designed, and the system’s working principle is described. Aiming to deal with the problem that the pump−valve compound speed regulation with constant pressure difference could not realize high controllability and energy saving at the same time, a control strategy for variable pressure difference pump−valve compound speed regulation based on pressure balance control is proposed. The handle signal is positively related to the target speed of the oil cylinder. In the low-speed stage, the closed-loop control of the actual output torque of the motor/generator keeps the pressure difference across the proportional throttle valve unchanged, and the speed adjustment is realized by changing the opening of the proportional throttle valve. In the high-speed stage, the valve opening area is kept unchanged and the target pressure difference is changed to achieve the target speed. Finally, the feasibility of the control strategy is verified through an AMESim simulation, and the minimum pressure difference switching point is determined through experiments. The experiments show that the system’s energy-saving efficiency can reach 21.5% under a 1 t load. With the increase in the load, the system’s energy-saving efficiency can be further improved. Full article

In this paper, a new solution for an electro-hydraulic servo drive is proposed, which consists of two electro-hydraulic servo drives: one with a hydraulic cylinder and one with a hydraulic rotary motor. In the proposed drive, the linear actuator is attached to a horizontal base and the hydraulic motor is mounted on the actuator piston rod. Thus, the output signal of the drive is the lifting and lowering of the element suspended on the rope. The paper describes the structure, kinematics, dynamics, and control of a novel electro-hydraulic servo drive. A servo valve and a proportional valve are used to control the flow of the hydraulic cylinder and the hydraulic motor. Special attention is paid to the construction of two actuators in one drive unit. The controller is based on the PLC controller. The measuring system uses laser displacement sensors and an encoder. The results of laboratory investigations are discussed in the paper. The proposed drive contains all of the characteristics of a mechatronic device. The main contribution of this study is the proposal of the controller architecture and the algorithm to control the speed and position when lifting or lowering loads. Full article

This paper presents the design and experimental validation of a novel human–machine redundant braking system (HMRBS) for aftermarket low-speed electric vehicles (LSEVs) to realise the backup redundancy ability and improve active safety. First, the HMRBS is designed by connecting the electro-hydraulic braking (EHB) unit oil pipelines in parallel with the manual braking (MB) unit through two three-way shuttle valves. Then, the mathematical model of the EHB subsystem is built, and a master cylinder pressure controller with adaptive fuzzy proportion integration differentiation (PID) and a servo motor speed controller with double-closed-loop proportion integration (PI) are proposed to improve the system response performance. Following this, the co-simulation model of the proposed closed-loop system is established based on AMESim and MATLAB/Simulink to validate the feasibility of the proposed control strategy. Finally, the effectiveness of the HMRBS is also validated by test rig and vehicle experiments. The results imply that the modified LSEV with the HMRBS meets the requirements of vehicle active braking ability and manual braking redundancy. Furthermore, the proposed controller can significantly enhance pressure control accuracy compared to the classical PID controller. The deceleration fluctuation and braking distance in the active braking mode are smaller than those in the manual braking mode, indicating that the proposed system makes the braking effect more stable and safer. Full article

In order to solve the problems of nonlinearity, uncertainty and coupling of multi-hydraulic cylinder group platform of a digging-anchor-support robot, as well as the lack of synchronization control accuracy of hydraulic synchronous motors, an improved Automatic Disturbance Rejection Controller-Improved Particle Swarm Optimization (ADRC-IPSO) position synchronization control method is proposed. The mathematical model of a multi-hydraulic cylinder group platform of a digging-anchor-support robot is established, the compression factor is used to replace the inertia weight, and the traditional Particle Swarm Optimization (PSO) algorithm is improved by using the genetic algorithm theory to improve the optimization range and convergence rate of the algorithm, and the parameters of the Active Disturbance Rejection Controller (ADRC) were adjusted online. The simulation results verify the effectiveness of the improved ADRC-IPSO control method. The experimental results show that, compared with the traditional ADRC, ADRC-PSO and PID controller, the improved ADRC-IPSO has better position tracking performance and shorter adjusting time, and its step signal synchronization error is controlled within 5.0 mm, and the adjusting time is less than 2.55 s, indicating that the designed controller has better synchronization control effect. Full article
