Search Results (123)

Circular deep excavations, characterized by their symmetrical geometry, are commonly employed in constructing foundations for large-span suspension bridges and as launching shafts for shield tunneling. However, the mechanical behavior of such excavations under asymmetric surface surcharge remains inadequately understood due to a paucity of relevant investigations. This study addresses this knowledge gap by establishing a three-dimensional finite element model (3D-FEA) based on the anchor deep excavation project of a specific bridge. The model is utilized to investigate the influence of asymmetric surcharge on the forces and deformations within the supporting structure. The results show that both the internal force and displacement cloud diagrams of the support structure exhibit asymmetric characteristics. The distribution of displacement and internal forces has spatial effects, and the maximum values all occur in the areas where asymmetric loads are applied. The maximum values of the displacement, axial force, and shear force of underground continuous walls increase with the increase in the excavation depth. The total displacement curves all show the feature of a “bulging belly”. The maximum displacement is 13.3 mm. The axial force is mainly compression, with a maximum value of −9514 kN/m. The maximum positive and negative values of the shear force are 333 kN/m and −705 kN/m, respectively. The bending moment diagram of different monitoring points shows the characteristics of “bow knot”. The maximum values of the positive bending moment and negative bending moment are 1509.4 kN·m/m and −2394.3 kN·m/m, respectively. The axial force of the ring beam is mainly compression, with a maximum value of −5360 kN, which occurs in ring beams 3, 4, and 5. The displacement cloud diagram of the support structure under symmetrical loads shows symmetrical characteristics. Under different load conditions, the displacement curve of the diaphragm wall shows the characteristics of “bulge belly”. The forms of loads with displacements from largest to smallest at the same position are as follows: asymmetric loads, symmetrical loads, and no loads. These findings provide valuable insights for optimizing the structural design of similar deep excavation projects and contribute to promoting sustainable urban underground development. Full article

During the excavation of the underground cavern at the Baihetan hydropower station, significant time-dependent deformation of the surrounding rock was observed, posing a serious challenge to the long-term stability control of the caverns. In this study, numerical models of the layered excavation for typical monitoring sections in the main and auxiliary powerhouses on both banks of the Baihetan hydropower station were established using a viscoplastic damage model. The time-dependent deformation responses of the surrounding rock during the entire underground cavern excavation process were successfully simulated, and the deformation and failure mechanisms of the surrounding rock during layered excavation were analyzed in combination with field monitoring data. The results demonstrate that the maximum stress trajectories at the right-bank powerhouse under higher stress conditions exceeded those at the left-bank powerhouse by 6 MPa after the powerhouse excavation. A larger stress difference caused stress trajectories to move closer to the rock strength surface, therefore making creep failure more likely to occur in the right bank. Targeted reinforcement in high-disturbance zones of the right-bank powerhouse reduced the damage progression rate at borehole openings from 0.295 per month to 0.0015 per month, effectively suppressing abrupt deformations caused by cumulative damage. These findings provide a basis for optimizing the excavation design of deep underground caverns. Full article

With the rapid advancement of urban underground space development, shield tunnel construction has seen a significant increase. However, at the initial launching stage of shield tunnels in shallow-buried weak strata, engineering risks such as face instability and sudden surface settlement frequently occur. At present, there are relatively few studies on the reinforcement technology of the initial section of shield tunnel in shallow soft ground and the evolution law of ground disturbance. This study takes the launching section of the Guanggang New City depot access tunnel on Guangzhou Metro Line 10 as the engineering background. By applying MIDAS/GTS numerical simulation, settlement monitoring, and theoretical analysis, the reinforcement technology at the tunnel face, the spatiotemporal evolution of ground settlement, and the mechanism of soil disturbance transmission during the launching process in muddy soil layer are revealed. The results show that: (1) the reinforcement scheme combining replacement filling, high-pressure jet grouting piles, and soil overburden counterpressure significantly improves surface settlement control. The primary influence zone is concentrated directly above the shield machine and in the forward excavation area. (2) When the shield machine reaches the junction between the reinforced and unreinforced zones, a large settlement area forms, with the maximum ground settlement reaching −26.94 mm. During excavation in the unreinforced zone, ground deformation mainly occurs beneath the rear reinforced section, with subsidence at the crown and uplift at the invert. (3) The transverse settlement trough exhibits a typical Gaussian distribution and the discrepancy between the measured maximum settlement and the numerical and theoretical values is only 3.33% and 1.76%, respectively. (4) The longitudinal settlement follows a trend of initial increase, subsequent decrease, and gradual stabilization, reaching a maximum when the excavation passes directly beneath the monitoring point. The findings can provide theoretical reference and engineering guidance for similar projects. Full article

Surface settlement prediction is crucial to assess the safety of subway station construction. To overcome challenges such as missing on-site settlement data and a limited number of monitoring points, this study proposes a composite prediction model that integrates finite element analysis, a time-series interval GA-BP neural network, and variational mode decomposition (VMD) techniques. Using the Dongba-zhongjie Station in Beijing Subway Line 3 as a case study, surface settlement predictions were made for both typical monitoring points and randomly selected feature points throughout the construction period, followed by validation. The experimental results show that the root mean square error (RMSE) of the finite element model is 15.77%, confirming the model’s effectiveness. As excavation progressed through the second underground floor and bottom plate, the settlement at the maximum settlement point began to rebound, and the structure tended to stabilize. At this stage, construction of the comprehensive utility tunnel above the station can proceed concurrently. Full article

This study reveals the damage mechanisms and fracture evolution characteristics of deeply buried granite with prefabricated joints (inclinations of 0°, 30°, 45°, 60°, and 90°) using uniaxial compression tests monitored by Acoustic Emission (AE) technology. Three-dimensional X-CT technology was used to analyze post-damage fracture evolution in specimens with varying joint inclinations. The results show that the stress–strain curve of deeply buried jointed granite under uniaxial compression includes three stages: initial compaction, crack extension, and failure. AE characteristics align with these stages, showing clear stress responses and timing features. In the initial compaction stage, micro-crack closure dominates, with smaller joint inclinations showing stronger closure effects. In the crack extension stage, joint inclination determines the crack propagation mode. In the failure stage, joint inclination significantly affects the spatial distribution of the rupture network by altering stress concentration areas and crack types. The proportion of shear micro-cracks increases with joint inclination, and peak strength rises with increasing joint angle, potentially accelerating micro-crack evolution. These findings provide valuable insights for designing excavation and instability monitoring in deeply buried multi-jointed granite underground projects. Full article

Due to the intersection of three mining rights in a mining area, the stability of the rock mass is mutually affected after mining operations. To study the optimal backfill ratio and the surface stability after backfilling in the adjacent goaf areas of the three mines in this mining area, a mineral deposit model is established using Rhino software. The model spans 2500 m in the east–west direction, 3000 m in the north–south direction, and ranges from an underground elevation of −610 m below. FLAC3D software was then used to analyze the surface stability under two different backfill ratios after the complete excavation of the ore body. Additionally, 52 monitoring points were set up at critical buildings and structures. The results revealed that after the complete excavation of the ore body, large-scale surface subsidence occurred in the mining area, with the main subsidence center located in the Yinzhushan mining area. Under backfill condition 1, six monitoring points experienced settlements exceeding 30.00 mm, with a maximum settlement of 53.98 mm. Under backfill condition 2, three monitoring points exceeded 30.00 mm, with a maximum settlement of 51.93 mm. The level displacement deformation at the monitoring points under both conditions met the stability requirements specified by national standards. By comparing the settlements at the monitoring points, it was determined that backfill condition 2 represents the optimal backfill ratio. This study provides a theoretical basis for practical backfilling operations in the mine. Full article

Underground winter bamboo shoots, prized for their high nutritional value and economic significance, face harvesting challenges owing to inefficient manual methods and the lack of specialized detection technologies. This review systematically evaluates current detection approaches, including manual harvesting, microwave detection, resistivity methods, and biomimetic techniques. While manual methods remain dominant, they suffer from labor shortages, low efficiency, and high damage rates. Microwave-based technologies demonstrate high accuracy and good depths but are hindered by high costs and soil moisture interference. Resistivity methods show feasibility in controlled environments but struggle with field complexity and low resolution. Biomimetic approaches, though innovative, face limitations in odor sensitivity and real-time data processing. Key challenges include heterogeneous soil conditions, performance loss, and a lack of standardized protocols. To address these, an integrated intelligent framework is proposed: (1) three-dimensional modeling via multi-sensor fusion for subsurface mapping; (2) artificial intelligence (AI)-driven harvesting robots with adaptive excavation arms and obstacle avoidance; (3) standardized cultivation systems to optimize soil conditions; (4) convolution neural network–transformer hybrid models for visual-aided radar image analysis; and (5) aeroponic AI systems for controlled growth monitoring. These advancements aim to enhance detection accuracy, reduce labor dependency, and increase yields. Future research should prioritize edge-computing solutions, cost-effective sensor networks, and cross-disciplinary collaborations to bridge technical and practical gaps. The integration of intelligent technologies is poised to transform traditional bamboo forestry into automated, sustainable “smart forest farms”, addressing global supply demands while preserving ecological integrity. Full article

When developing deep subsurface infrastructure in areas with intense geothermal activity, the significant temperature gradient inevitably leads to low-temperature contraction and high-temperature expansion of the rock body, resulting in changes in the rock’s mechanical properties. These thermodynamic effects can easily lead to the destabilization and subsequent collapse of the rock. There exists a pressing necessity to methodically evaluate the surrounding rock stability encountered in deep underground engineering under the action of thermal-solid coupling. This study constructed a multi-physical field coupling nonlinear calculation model based on a high-precision three-dimensional finite difference method, systematically analyzed the interdependent effects between the original rock temperature and excavation-induced disturbance, and then analyzed the dynamic changes in temperature, stress, and displacement fields along with plastic zone of surrounding rock of the deep underground engineering under thermal-solid coupling. The results indicate that the closer to the excavation contour surface, the lower the surrounding rock temperature, while the temperature gradient increased correspondingly. The farther away from the excavation contour face, the closer the temperature was to the original rock temperature. As the original rock temperature climbed from 30 °C to 90 °C, the increment of vault displacement was 2.45 times that of arch bottom displacement, and the influence of temperature change on vault deformation was more significant. The horizontal displacement magnitudes at the different original temperatures followed the following order: sidewall > spandrel > skewback, and at an original rock temperature of 90 °C, the sidewall horizontal displacement reached 15.31 cm. With the elevation of the original rock temperature, the distribution range and concentration degree of the maximum and minimum principal stresses increased obviously, and both were compression-dominated. The types of plastic zones in the surrounding rock were mainly characterized by shear stress-induced yielding and tensile stress-induced damage failure. When the original rock temperature increased to 90 °C, the rock mass extending up to 1.5 m from the excavation contour surface formed a large area of damage zone. The closer the working face was to the monitoring section, the faster the temperature dropped, and the displacement changed in the monitoring section. The findings offer a theoretical basis for engineering practice, and it is of great significance to ensure the safety of the project. Full article

The use of envelope structures is crucial in enhancing the safety and stability of foundation pits. However, excavation activities in the foundation pit can result in deformations affecting the envelope structure. To investigate the impact of the excavation process on the envelope structure and surrounding soil, the Midas GTS NX 2022R1 (64-bit) finite element software was employed to model the excavation process of Nantong East Railway Station. The settlement of the soil around the envelope structure and the horizontal displacement of the underground diaphragm wall (UDW) were compared with field measurements. The analysis demonstrated that the numerical analysis results exhibited a similar trend to the data obtained from field monitoring. This comparison provided valuable insights for selecting an optimal excavation method for the foundation pit and offered guidance for addressing similar challenges in the future. Additionally, a new method using metamaterials as a frame to improve the stability of continuous walls is proposed. The method relies on the excellent mechanical properties of metamaterials, improves the integrity and stability of the underground diaphragm wall, and provides a new way to solve the stability problem of underground diaphragm walls. Full article

Underground space development has significantly increased the depth, scale, and complexity of foundation pit engineering. However, monitoring systems lack mechanical analysis models and fail to predict and control construction risks. Additionally, the foundation pit model could not be updated based on on-site observed data, leading to inaccurate predictions. This study proposes a DT modeling framework for foundation pits, which is used to simulate, predict, and control the risks associated with the entire excavation process. Consequently, based on the DT modeling framework, a DT foundation pit model (DTFPM) was established using modeling and updating algorithms. This study summarizes and identifies the key modeling parameters of foundation pits. A parametric modeling algorithm based on ABAQUS (v2020) was developed to drive the excavation pit modeling process within seconds. Furthermore, an inverse analysis optimization algorithm based on genetic algorithms (GA) and real-time observed deformation was employed to update the elastic modulus of the soil. The algorithm supports parallel computing and can converge within 10 generations. The prediction error of the model after inverse analysis can be reduced to within 10%. Finally, the authors applied DTFPM to establish an intelligent monitoring system. The focus is on real-time and predictive warnings based on the monitoring deformation of the current construction step and the updated model. This study analyzes a Beijing project case to verify the effectiveness of the system, demonstrating the practical application of the proposed method. The results showed that the DTFPM could accurately simulate the deformation behavior of the foundation pit. The system could provide more timely and accurate safety warnings. The proposed method can potentially contribute to the intelligent construction of foundation pits in the future, both theoretically and practically. Full article

Acid mine drainage (AMD), which is primarily caused by the exposure of sulfidic minerals to oxygen and water during mining operations, remains a significant contributor to environmental pollution. Numerous technologies have been developed to prevent/control and treat AMD, including the isolation of waste from the atmosphere and treatment systems for AMD-impacted water. Many field studies on mine site reclamation have involved an individual AMD source and/or technology, with a limited number of studies looking at reclamation programs integrating multiple approaches to manage AMD stemming from both surface and underground sources. The former Franklin mine site in Nova Scotia, Canada, was impacted by the deposition of waste rock across the site and the discharge of mine water from underground workings, with the adjacent Sullivan’s Pond serving as the main environmental receptor. Site reclamation was completed in 2010 and involved the following: (1) excavation of the dispersed waste rock (117,000 m²) and backfilling with clean soil; (2) consolidation of the excavated waste rock into a covered, compact waste rock pile (WRP) (25,000 m²); and (3) construction of a passive treatment system for the discharging underground mine water. An extensive field sampling program was conducted between 2011 and 2018 to monitor a range of meteorological, cover material, waste rock, groundwater, and surface water quality parameters. The results confirm that the multi-layer, geomembrane-lined WRP cover system is an extremely effective barrier to air and water influx, thereby minimizing the rate of AMD generation and seepage into groundwater and eliminating all contaminated surface water runoff. A small AMD groundwater plume emanates from the base of the WRP, with 50% captured by the underground mine workings over the long term and 50% slowly migrating towards Sullivan’s Pond. Excavation of the former waste disposal area eliminated the AMD source from the previously dispersed waste, with only clean surface water runoff and a diminishing legacy groundwater plume remaining. Finally, the passive treatment system, which contains a series of treatment technologies such as a limestone leach bed and settling pond, successfully treats all mine water loading (~50 kg/day) discharging from the underground workings and surface runoff. Its additional treatment capacity (up to ~150 kg/day) ensures it will be able to manage any potential drop in treatment efficiency and/or increased AMD loading from long-term WRP seepage. This comprehensive study of mine site reclamation and AMD management at an abandoned mining site can be of great reference value for environmental management and policymakers in the mining sector. Full article

Recently, there has been a growing interest in underground construction safety, during activities such as subway construction, underground mining, and tunnel excavation. While Internet of Things (IoT) sensors help to monitor these conditions, large-scale deployment is limited by high power needs and complex tunnel layouts, making real-time response a critical challenge. A delay-sensitive multi-sensor multi-base-station routing scheduling method is proposed for the IoT in underground mining. First, a mixed network topology of wireless and wired networks is formed based on the irregular distribution characteristics of multiple tunnels in the mine construction environment. Based on this topology, a multi-sensor and multi-base-station real-time routing scheduling problem is proposed, proving that the problem is NP-hard. Secondly, the corresponding solving algorithms are designed based on the greedy strategy and the heuristic strategy. Finally, an experimental platform is built, and the performance of the proposed algorithm is compared and analyzed. Full article

Interferometric Synthetic Aperture Radar (InSAR) technology has emerged as a vital tool for monitoring surface deformation due to its high accuracy and spatial resolution. With the rapid economic development of Nanchang, extensive infrastructure development and construction activities have significantly altered the urban landscape. Underground excavation and groundwater extraction in the region are potential contributors to surface deformation. This study utilized Sentinel-1 satellite data, acquired between September 2018 and May 2023, and applied the Permanent Scatterer Interferometric Synthetic Aperture Radar (PS-InSAR) technique to monitor surface deformation in Nanchang’s urban area. The findings revealed that surface deformation rates in the study area range from −10 mm/a to 6 mm/a, with the majority of regions remaining relatively stable. Approximately 99.9% of the monitored points exhibited deformation rates within −5 mm/a to 5 mm/a. However, four significant subsidence zones were identified along the Gan River and its downstream regions, with a maximum subsidence rate reaching 9.7 mm/a. Historical satellite imagery comparisons indicated that certain subsidence areas are potentially associated with construction activities. Further analysis integrating subsidence data, monthly precipitation, and groundwater depth revealed a negative correlation between surface deformation in Region A and rainfall, with subsidence trends aligning with groundwater level fluctuations. However, such a correlation was not evident in the other three regions. Additionally, water level data from the Xingzi Station of Poyang Lake showed that only Region A’s subsidence trend closely corresponds with water level variations. We conducted a detailed analysis of the spatial distribution of soil types in Nanchang and found that the soil types in areas of surface deformation are primarily Semi-hydromorphic Soils and Anthropogenic Soils. These soils exhibit high compressibility, making them prone to compaction and significantly influencing surface deformation. This study concludes that localized surface deformation in Nanchang is primarily driven by urban construction activities and the compaction of artificial fill soils, while precipitation also has an impact in certain areas. Full article

Currently, subway and underground engineering projects are vital for alleviating urban congestion and enhancing citizens’ quality of life. Among these, excavation engineering for foundation pits involves the most accidents in geotechnical engineering. Although there are various construction methods, most face issues such as a large footprint, high investments, resource waste, and low mechanization. Addressing these, this paper focuses on a subway foundation pit project in Guangzhou using mechanical shaft sinking technology. Using intelligent cloud monitoring, we analyzed the stress–strain patterns of the cutting edge and segments. The results showed significant improvements in construction efficiency, cost reduction, safety, and resource conservation. Based on this work, this paper makes the following conclusions: (1) The mechanical shaft sinking method offers advantages such as small footprint, high mechanization, minimal environmental impact, and cost-effectiveness. The achievements include a 22.22% reduction in construction time, a 20.27% decrease in investment, and lower worker risk. (2) Monitoring confirmed that all cutting edge and segment values remained safe, demonstrating the method’s feasibility and rationality. (3) Analyzing shaft monitoring data and field uncertainties, this study proposes recommendations for future work, including precise segment lowering control and introducing high-precision total stations and GPS technology to mitigate tunneling and assembly inaccuracies. The research validates the mechanical shaft sinking scheme’s scientific and logical nature, ensuring safety and contributing to technological advancements. It offers practical insights, implementable suggestions, and significant economic benefits, reducing project investment by RMB 41,235,600. This sets a benchmark for subway excavation projects in South China and beyond, providing reliable reference values. Furthermore, the findings provide valuable insights and guidance for industry peers, enhancing overall efficiency and sustainable development in subway construction. Full article

Taking the foundation pit of the Suzhou Chunshenhu Road Expressway Reconstruction Project as an example, the excavation process of the foundation pit was numerically simulated using a three-dimensional finite element method. The measured data and simulated data of the lateral deformation of the enclosure structure, surface settlement deformation of the ground outside the pit, and settlement deformation of the building were compared to analyze the impact of foundation pit construction on adjacent buildings. The influence of foundation pit floor and diaphragm wall thickness on wall displacement, building settlement, and foundation pit uplift was also discussed. The results showed the following: (1) Adding a foundation pit floor has a significant effect on reducing the lateral displacement of the diaphragm wall, settlement of the building, and uplift of the foundation pit. Increasing the thickness of the foundation pit floor has a limited effect on reducing the displacement, while increasing the thickness of the diaphragm wall has a small effect. (2) The displacement curve of the underground diaphragm wall increases with depth. It reaches a maximum at the excavation surface and then decreases gradually. (3) The surface settlement increases first and then decreases with distance from the foundation pit, showing a concave shape. As the depth of excavation increases, the settlement value increases. (4) Through analysis of the monitoring data of vertical displacement of buildings, it can be seen that during foundation pit excavation, buildings undergo five stages: initial slow descent, steep descent, mid-term slow descent, late steep descent, and stable deformation. The buildings are dominated by settlement deformation. Full article
