The accurate measurement of the tree diameter is vital for forest inventories, urban tree quality assessments, the management of roadside and railway vegetation, and various other applications. It also plays a crucial role in evaluating tree growth dynamics, which are closely linked to tree health, structural stability, and vulnerability. Although a range of devices and methodologies are currently under investigation, the widespread adoption of laser scanners remains constrained by their high cost. This study therefore aimed to compare high-end laser scanners (Trimble TX8 and GeoSLAM ZEB Horizon) with cost-effective alternatives, represented by the Apple iPhone 14 Pro and the LA03 scanner developed by mapry Co., Ltd. (Tamba, Japan). It further sought to evaluate the feasibility of employing these more affordable devices, even for small-scale forest owners or managers. Given the growing availability of 3D-based forest inventory algorithms, a selection of such processing pipelines was used to assess the practical potential of the scanning devices. The tested low-cost device produced moderate results, achieving a tree detection rate of up to 78% and a relative root mean square error (rRMSE) of 19.7% in diameter at breast height (DBH) estimation. However, performance varied depending on the algorithms applied. In contrast, the high-end mobile laser scanning (MLS) and terrestrial laser scanning (TLS) systems outperformed the low-cost alternative across all metrics, with tree detection rates reaching up to 99% and DBH estimation rRMSEs as low as 5%. Nevertheless, the low-cost device may still be suitable for scanning small sample plots at a reduced cost and could potentially be deployed in larger quantities to support broader forest inventory initiatives. Full article

Point clouds acquired by mobile laser scanners (MLS) are widely used for generating as-built building information models (BIM), particularly in indoor construction environments and existing buildings. While MLS offers fast and efficient scanning through SLAM technology, its accuracy and precision remains lower than that of terrestrial laser scanners (TLS). This study investigates the potential to improve MLS-based as-built BIM accuracy by analyzing and utilizing error distribution patterns inherent in MLS point clouds. Based on the assumption that each MLS device exhibits consistent and unique error distribution patterns, an experiment was conducted using three MLS devices and TLS-derived reference data. The analysis employed iterative closest point (ICP) registration and cloud-to-mesh (C2M) distance measurements on mock-ups with closed shapes. The results revealed that error patterns were stable across scans and could be leveraged as correction factors. In other words, the results indicate that when using MLS for as-built BIM generation, robust fitting methods have limitations in obtaining realistic object dimensions, as they do not account for the unique error patterns present in MLS point clouds. The proposed method provides a simple and repeatable approach for enhancing MLS accuracy, contributing to improved dimensional reliability in MLS-driven BIM applications. Full article

Technological development has strongly impacted all processes related to the design, construction, and management of real estate assets. In fact, the introduction of the BIM approach has required the application of three-dimensional survey technologies, and in particular the use of LiDAR instruments, both in their static (TLS—terrestrial laser scanner) and dynamic (iMMS—indoor mobile mapping system) implementations. Operators and developers of LiDAR technologies, for the implementation of scan-to-BIM procedures, initially placed particular care on the 3D surveying accuracy obtainable from such tools. The incorporation of RGB sensors into these instruments has progressively expanded LiDAR-based applications from essential topographic surveying to geospatial applications, where the emphasis is no longer on the accurate three-dimensional reconstruction of buildings but on the capability to create three-dimensional image-based visualizations, such as virtual tours, which allow the recognition of assets located in every area of the buildings. Although much has been written about obtaining the best possible accuracy for extensive asset surveying of large-scale building complexes using iMMS systems, it is now essential to develop and define suitable procedures for controlling such kinds of surveying, targeted at specific geospatial applications. We especially address the design, field acquisition, quality control, and mass data management techniques that might be used in such complex environments. This work aims to contribute by defining the technical specifications for the implementation of geospatial mapping of vast asset survey activities involving significant building sites utilizing iMMS instrumentation. Three-dimensional models can also facilitate virtual tours, enable local measurements inside rooms, and particularly support the subsequent integration of self-locating image-based technologies that can efficiently perform field updates of surveyed databases. Full article

This article examines the combined use of UAV (Unmanned Aerial Vehicle) photogrammetry and TLS (Terrestrial Laser Scanning) to detect changes in coastal cliffs in the Strunjan Nature Reserve. Coastal cliffs present unique surveying challenges, including limited access, unstable reference points due to erosion, GNSS (Global Navigation Satellite System) signal obstruction, dense vegetation, private property restrictions and weak mobile data. To overcome these limitations, UAV and TLS techniques are used with the help of GNSS and TPS (Total Positioning Station) surveying to establish a network of GCPs (Ground Control Points) for georeferencing. The methodology includes several epochs of data collection between 2019 and 2024, using a DJI Phantom 4 RTK for UAV surveys and a Riegl VZ-400 scanner for TLS. The data processing includes point cloud filtering, mesh comparison and a DoD (DEM of difference) analysis to quantify cliff surface changes. This study addresses the effects of vegetation by focusing on vegetation-free regions of interest distributed across the cliff face. The results aim to demonstrate the effectiveness and limitations of both methods for detecting and monitoring cliff erosion and provide valuable insights for coastal management and risk assessment. Full article

Plant phenotyping plays a crucial role in crop science and plant breeding. However, traditional methods often involve time-consuming and manual observations. Therefore, it is essential to develop automated, sensor-driven techniques that can provide objective and rapid information. Various methods rely on camera systems, including RGB, multi-spectral, and hyper-spectral cameras, which offer valuable insights into plant physiology. In recent years, 3D sensing systems such as laser scanners have gained popularity due to their ability to capture structural plant parameters that are difficult to obtain using spectral sensors. Unlike images, point clouds are not structured and require pre-processing steps to extract precise information and handle noise or missing points. One approach is to generate mesh-based surface representations using triangulation. A key challenge in the 3D surface reconstruction of plants is the pre-processing of point clouds, which involves removing non-plant noise from the scene, segmenting point clouds from populations to individual plants, and further dividing individual plants into their respective organs. In this study, we will not focus on the segmentation aspect but rather on the other pre-processing steps, like denoising parameters, which depend on the data type. We present an automated pipeline for converting high-resolution point clouds into surface models of plants. The pipeline incorporates additional pre-processing steps such as outlier removal, denoising, and subsampling to ensure the accuracy and quality of the reconstructed surfaces. Data were collected using three different sensors: a handheld scanner, a terrestrial laser scanner (TLS), and a mobile mapping platform, under varying conditions from controlled laboratory environments to complex field settings. The investigation includes five different plant species, each with distinct characteristics, to demonstrate the potential of the pipeline. In a next step, phenotypic traits such as leaf area, leaf area index (LAI), and leaf angle distribution (LAD) were calculated to further illustrate the pipeline’s potential and effectiveness. The pipeline is based on the Open3D framework and is available open source. Full article

This article examines the potential of low-cost LiDAR technology for 3D modeling and assessment of the degradation of historic buildings, using a section of the Koszalin city walls in Poland as a case study. Traditional terrestrial laser scanning (TLS) offers high accuracy but is expensive. The study assessed whether more accessible LiDAR options, such as those integrated with mobile devices such as the Apple iPad Pro, can serve as viable alternatives. This study was conducted in two phases—first assessing measurement accuracy and then assessing degradation detection—using tools such as the FreeScan Combo scanner and the Z+F 5016 IMAGER TLS. The results show that, while low-cost LiDAR is suitable for small-scale documentation, its accuracy decreases for larger, complex structures compared to TLS. Despite these limitations, this study suggests that low-cost LiDAR can reduce costs and improve access to heritage conservation, although further development of mobile applications is recommended. Full article

Our work aimed to compare the chip pile volumes calculated by laser ground scanning, UAV technology, and laser ground measurement and also to determine the accuracy, speed, and economic efficiency of each method. The large chip pile was measured in seven different ways: band measurement, laser measurement with Vertex, global navigation satellite system, handheld mobile laser scanner, terrestrial laser scanner, drone, and smartphone with a light detection and ranging sensor. All the methods were compared in terms of accuracy, price, user-friendliness, and time required to obtain results. The calculated pile volume, depending on the method, varied from 2588 to 3362 m³. The most accurate results were provided by the terrestrial laser scanning method, which, however, was the most expensive and the most demanding in terms of collecting and evaluating the results. From a time and economic point of view, the most effective methods were UAVs and smartphones with LiDAR. Full article

Global pose refinement is a significant challenge within Simultaneous Localization and Mapping (SLAM) frameworks. For LIDAR-based SLAM systems, pose refinement is integral to correcting drift caused by the successive registration of 3D point clouds collected by the sensor. A divergence between the actual and calculated platform paths characterizes this error. In response to this challenge, we propose a linear, parameter-free model that uses a closed circuit for global trajectory corrections. Our model maps rotations to quaternions and uses Spherical Linear Interpolation (SLERP) for transitions between them. The intervals are established by the constraint set by the Least Squares (LS) method on rotation closure and are proportional to the circuit’s size. Translations are globally adjusted in a distinct linear phase. Additionally, we suggest a coarse-to-fine pairwise registration method, integrating Fast Global Registration and Generalized ICP with multiscale sampling and filtering. The proposed approach is tested on three varied datasets of point clouds, including Mobile Laser Scanners and Terrestrial Laser Scanners. These diverse datasets affirm the model’s effectiveness in 3D pose estimation, with substantial pose differences and efficient pose optimization in larger circuits. Full article

Building Information Modeling (BIM) has recently been widely applied in the Architecture, Engineering, and Construction Industry (AEC). BIM graphical information can provide a more intuitive display of the building and its contents. However, during the Operation and Maintenance (O&M) stage of the building lifecycle, changes may occur in the building’s contents and cause inaccuracies in the BIM model, which could lead to inappropriate decisions. This study aims to address this issue by proposing a novel approach to creating 3D point clouds for updating as-built BIM models. The proposed approach is based on Pedestrian Dead Reckoning (PDR) for an Inertial Measurement Unit (IMU) integrated with a Mobile Laser Scanner (MLS) to create room-based 3D point clouds. Unlike conventional methods previously undertaken where a Terrestrial Laser Scanner (TLS) is used, the proposed approach utilizes low-cost MLS in combination with IMU to replace the TLS for indoor scanning. The approach eliminates the process of selecting scanning points and leveling of the TLS, enabling a more efficient and cost-effective creation of the point clouds. Scanning of three buildings with varying sizes and shapes was conducted. The results indicated that the proposed approach created room-based 3D point clouds with centimeter-level accuracy; it also proved to be more efficient than the TLS in updating the BIM models. Full article

The motivation behind this research is the lack of an underground mining shaft data set in the literature in the form of open access. For this reason, our data set can be used for many research purposes such as shaft inspection, 3D measurements, simultaneous localization and mapping, artificial intelligence, etc. The data collection method incorporates rotated Velodyne VLP-16, Velodyne Ultra Puck VLP-32c, Livox Tele-15, IMU Xsens MTi-30 and Faro Focus 3D. The ground truth data were acquired with a geodetic survey including 15 ground control points and 6 Faro Focus 3D terrestrial laser scanner stations of a total 273,784,932 of 3D measurement points. This data set provides an end-user case study of realistic applications in mobile mapping technology. The goal of this research was to fill the gap in the underground mining data set domain. The result is the first open-access data set for an underground mining shaft (shaft depth −300 m). Full article

The automated inspection and mapping of engineering structures are mainly based on photogrammetry and laser scanning. Mobile robotic platforms like unmanned aerial vehicles (UAVs) and unmanned ground vehicles (UGVs), but also handheld platforms, allow efficient automated mapping. Engineering structures like bridges shadow global navigation satellite system (GNSS), which complicates precise localization. Simultaneous localization and mapping (SLAM) algorithms offer a sufficient solution, since they do not require GNSS. However, testing and comparing SLAM algorithms in GNSS-denied areas is difficult due to missing ground truth data. This work presents an approach to measuring the performance of SLAM in indoor and outdoor GNSS-denied areas using a terrestrial scanner Leica RTC360 and a tachymeter to acquire point cloud and trajectory information. The proposed method is independent of time synchronization between robot and tachymeter and also works on sparse SLAM point clouds. For the evaluation of the proposed method, three LiDAR-based SLAM algorithms called KISS-ICP, SC-LIO-SAM, and MA-LIO are tested using a UGV equipped with two light detection and ranging (LiDAR) sensors and an inertial measurement unit (IMU). KISS-ICP is based solely on a single LiDAR scanner and SC-LIO-SAM also uses an IMU. MA-LIO, which allows multiple (different) LiDAR sensors, is tested on a horizontal and vertical one and an IMU. Time synchronization between the tachymeter and SLAM data during post-processing allows calculating the root mean square (RMS) absolute trajectory error, mean relative trajectory error, and the mean point cloud to reference point cloud distance. It shows that the proposed method is an efficient approach to measure the performance of SLAM in GNSS-denied areas. Additionally, the method shows the superior performance of MA-LIO in four of six test tracks with 5 to 7 cm RMS trajectory error, followed by SC-LIO-SAM and KISS-ICP in last place. SC-LIO-SAM reaches the lowest point cloud to reference point cloud distance in four of six test tracks, with 4 to 12 cm. Full article

The article provides an overview of the digitisation project conducted by the Parco Archeologico dell’Appia Antica (PAAA) in Rome, focusing on an 11.7 km section of the Appian Way. This effort is part of the “Appia Regina Viarum” project, supporting the UNESCO heritage site candidacy of the Appian Way. Advanced sensor technologies, including the Mobile Mapping System (MMS), 360° Cameras, Terrestrial Laser Scanner (TLS), digital cameras, and drones, are employed to collect extensive data sets. The primary goal is to create highly accurate three-dimensional (3D) models for knowledge enhancement, conservation, and communication purposes. Innovative tools are introduced to manage High Resolution 3D textured models, improving maintenance, management, and design processes over traditional CAD methods. The project aims to develop multi-temporal Digital Twins integrated with historical documentation, such as Piranesi’s imaginary views and architect Canina’s monument reconstructions. These informative models function as nodes within the DT, serving the PAAA’s geographic hub by means of an eXtended Reality (XR) platform: the paper proposes bridging the physical object and virtual models, contributing to supporting the operators in the maintenance planning as well as information dissemination and public awareness, offering an immersive experience beyond conventional reality. Full article

Ground-based forest inventories are reliable methods for forest carbon monitoring, reporting, and verification schemes and the cornerstone of forest ecology research. Recent work using LiDAR-equipped mobile phones to automate parts of the forest inventory process assumes that tree trunks are well-spaced and visually unoccluded, or else require manual intervention or offline processing to identify and measure tree trunks. In this paper, we designed an algorithm that exploits a low-cost smartphone LiDAR sensor to estimate the trunk diameter automatically from a single image in complex and realistic field conditions. We implemented our design and built it into an app on a Huawei P30 Pro smartphone, demonstrating that the algorithm has low enough computational costs to run on this commodity platform in near real-time. We evaluated our app in 3 different forests across 3 seasons and found that in a corpus of 97 sample tree images, our app estimated the trunk diameter with a RMSE of 3.7 cm ($R^2$ = 0.97; 8.0% mean absolute error) compared to manual DBH measurement. It achieved a 100% tree detection rate while reducing the surveyor time by up to a factor of 4.6. Our work contributes to the search for a low-cost, low-expertise alternative to terrestrial laser scanning that is nonetheless robust and efficient enough to compete with manual methods. We highlight the challenges that low-end mobile depth scanners face in occluded conditions and offer a lightweight, fully automatic approach for segmenting depth images and estimating the trunk diameter despite these challenges. Our approach lowers the barriers to in situ forest measurements outside of an urban or plantation context, maintaining a tree detection and accuracy rate comparable to previous mobile phone methods even in complex forest conditions. Full article

Gardens play a key role in the definition of the cultural landscape since they reflect the culture, identity, and history of a people. They also contribute to the ecological balance of the city. Despite the fact that gardens have an historic and social value, they are not protected as much as the rest of the existing heritage, such as architecture and archaeological sites. While methods of built-heritage mapping and monitoring are increasing and constantly improving to reduce built-heritage loss and the severe impact of natural disasters, the documentation and survey techniques for gardens are often antiquated. In addition, inventories are typically made by non-updated/updateable reports, and they are rarely in digital format or in 3D. This paper presents the results of a comprehensive study on the latest technology for laser scanning in gardens. We compared static terrestrial laser scanning and mobile laser scanning point clouds generated by the Focus 3D S120 and the Leica BLK2GO, respectively, to evaluate their quality for documentation, estimate tree attributes, and terrain morphology. The evaluation is based on visual observation, C2C comparisons, and terrain information extraction capabilities, i.e., M3C2 comparisons for topography, DTM generation, and contour lines. Both methods produced useful outcomes for the scope of the research within their limitations. Terrestrial laser scanning is still the method that offers accurate point clouds with a higher point density and less noise. However, the more recent mobile laser scanning is able to survey in less time, significantly reducing the costs for site activities, data post-production, and registration. Both methods have their own restrictions that are amplified by site features, mainly the lack of plans for the geometric alignment of scans and the simultaneous location and mapping (SLAM) process. We offer a critical description of the issues related to the functionality of the two sensors, such as the operative range limit, light dependency, scanning time, point cloud completeness and size, and noise level. Full article

With the development of 3D vision techniques, RGB-D cameras are increasingly used to allow easier and cheaper access to the third dimension. In this paper, we focus on testing the potential of the Kinect Azure RGB-D camera in the 3D reconstruction of indoor scenes. First, a series of investigations of the hardware was performed to evaluate its accuracy and precision. The results show that the measurements made with the Azure could be exploited for close-range survey applications. Second, we performed a methodological workflow for indoor reconstruction based on the Open3D framework, which was applied to two different indoor scenes. Based on the results, we can state that the quality of 3D reconstruction significantly depends on the architecture of the captured scene. This was supported by a comparison of the point cloud from the Kinect Azure with that from a terrestrial laser scanner and another from a mobile laser scanner. The results show that the average differences do not exceed 8 mm, which confirms that the Kinect Azure can be considered a 3D measurement system at least as reliable as a mobile laser scanner. Full article
