Aiming to address the problems of asynchronous acquisition time of multiple sensors in the crop phenotype acquisition system and high cost of the acquisition equipment, this paper developed a low-cost crop phenotype synchronous acquisition system based on the PTP synchronization protocol, realizing the synchronous acquisition of three types of crop data: visible light images, thermal infrared images, and laser point clouds. The paper innovatively proposed the Difference Structural Similarity Index Measure (DSSIM) index, combined with statistical indicators (average point number difference, average coordinate error), distribution characteristic indicators (Charm distance), and Hausdorff distance to characterize the stability of the system. After 72 consecutive hours of synchronization testing on the timing boards, it was verified that the root mean square error of the synchronization time for each timing board reached the ns level. The synchronous trigger acquisition time for crop parameters under time synchronization was controlled at the microsecond level. Using pepper as the crop sample, 133 consecutive acquisitions were conducted. The acquisition success rate for the three phenotypic data types of pepper samples was 100%, with a DSSIM of approximately 0.96. The average point number difference and average coordinate error were both about 3%, while the Charm distance and Hausdorff distance were only 1.14 mm and 5 mm. This system can provide hardware support for multi-parameter acquisition and data registration in the fast mobile crop phenotype platform, laying a reliable data foundation for crop growth monitoring, intelligent yield analysis, and prediction. Full article

This study examined the integraftion of airborne Light Detection and Ranging (LiDAR), Simultaneous Localization and Mapping (SLAM)-based handheld LiDAR, and iPhone LiDAR to inspect forest road networks following forest operations. The goal is to overcome the challenges posed by dense canopy cover and ensure accurate and efficient data collection and mapping. Airborne data were collected using the DJI Matrice 300 RTK UAV equipped with a Zenmuse L2 LiDAR sensor, which achieved a high point density of 285 points/m² at an altitude of 80 m. Ground-level data were collected using the BLK2GO handheld laser scanner (HPLS) with SLAM methods (LiDAR SLAM, Visual SLAM, Inertial Measurement Unit) and the iPhone 13 Pro Max LiDAR. Data processing included generating DEMs, DSMs, and True Digital Orthophotos (TDOMs) via DJI Terra, LiDAR360 V8, and Cyclone REGISTER 360 PLUS, with additional processing and merging using CloudCompare V2 and ArcGIS Pro 3.4.0. The pairwise comparison analysis between ALS data and each alternative method revealed notable differences in elevation, highlighting discrepancies between methods. ALS + iPhone demonstrated the smallest deviation from ALS (MAE = 0.011, RMSE = 0.011, RE = 0.003%) and HPLS the larger deviation from ALS (MAE = 0.507, RMSE = 0.542, RE = 0.123%). The findings highlight the potential of fusing point clouds from diverse platforms to enhance forest road mapping accuracy. However, the selection of technology should consider trade-offs among accuracy, cost, and operational constraints. Mobile LiDAR solutions, particularly the iPhone, offer promising low-cost alternatives for certain applications. Future research should explore real-time fusion workflows and strategies to improve the cost-effectiveness and scalability of multisensor approaches for forest road monitoring. Full article

The accurate measurement of the tree diameter is vital for forest inventories, urban tree quality assessments, the management of roadside and railway vegetation, and various other applications. It also plays a crucial role in evaluating tree growth dynamics, which are closely linked to tree health, structural stability, and vulnerability. Although a range of devices and methodologies are currently under investigation, the widespread adoption of laser scanners remains constrained by their high cost. This study therefore aimed to compare high-end laser scanners (Trimble TX8 and GeoSLAM ZEB Horizon) with cost-effective alternatives, represented by the Apple iPhone 14 Pro and the LA03 scanner developed by mapry Co., Ltd. (Tamba, Japan). It further sought to evaluate the feasibility of employing these more affordable devices, even for small-scale forest owners or managers. Given the growing availability of 3D-based forest inventory algorithms, a selection of such processing pipelines was used to assess the practical potential of the scanning devices. The tested low-cost device produced moderate results, achieving a tree detection rate of up to 78% and a relative root mean square error (rRMSE) of 19.7% in diameter at breast height (DBH) estimation. However, performance varied depending on the algorithms applied. In contrast, the high-end mobile laser scanning (MLS) and terrestrial laser scanning (TLS) systems outperformed the low-cost alternative across all metrics, with tree detection rates reaching up to 99% and DBH estimation rRMSEs as low as 5%. Nevertheless, the low-cost device may still be suitable for scanning small sample plots at a reduced cost and could potentially be deployed in larger quantities to support broader forest inventory initiatives. Full article

Point clouds acquired by mobile laser scanners (MLS) are widely used for generating as-built building information models (BIM), particularly in indoor construction environments and existing buildings. While MLS offers fast and efficient scanning through SLAM technology, its accuracy and precision remains lower than that of terrestrial laser scanners (TLS). This study investigates the potential to improve MLS-based as-built BIM accuracy by analyzing and utilizing error distribution patterns inherent in MLS point clouds. Based on the assumption that each MLS device exhibits consistent and unique error distribution patterns, an experiment was conducted using three MLS devices and TLS-derived reference data. The analysis employed iterative closest point (ICP) registration and cloud-to-mesh (C2M) distance measurements on mock-ups with closed shapes. The results revealed that error patterns were stable across scans and could be leveraged as correction factors. In other words, the results indicate that when using MLS for as-built BIM generation, robust fitting methods have limitations in obtaining realistic object dimensions, as they do not account for the unique error patterns present in MLS point clouds. The proposed method provides a simple and repeatable approach for enhancing MLS accuracy, contributing to improved dimensional reliability in MLS-driven BIM applications. Full article

Technological development has strongly impacted all processes related to the design, construction, and management of real estate assets. In fact, the introduction of the BIM approach has required the application of three-dimensional survey technologies, and in particular the use of LiDAR instruments, both in their static (TLS—terrestrial laser scanner) and dynamic (iMMS—indoor mobile mapping system) implementations. Operators and developers of LiDAR technologies, for the implementation of scan-to-BIM procedures, initially placed particular care on the 3D surveying accuracy obtainable from such tools. The incorporation of RGB sensors into these instruments has progressively expanded LiDAR-based applications from essential topographic surveying to geospatial applications, where the emphasis is no longer on the accurate three-dimensional reconstruction of buildings but on the capability to create three-dimensional image-based visualizations, such as virtual tours, which allow the recognition of assets located in every area of the buildings. Although much has been written about obtaining the best possible accuracy for extensive asset surveying of large-scale building complexes using iMMS systems, it is now essential to develop and define suitable procedures for controlling such kinds of surveying, targeted at specific geospatial applications. We especially address the design, field acquisition, quality control, and mass data management techniques that might be used in such complex environments. This work aims to contribute by defining the technical specifications for the implementation of geospatial mapping of vast asset survey activities involving significant building sites utilizing iMMS instrumentation. Three-dimensional models can also facilitate virtual tours, enable local measurements inside rooms, and particularly support the subsequent integration of self-locating image-based technologies that can efficiently perform field updates of surveyed databases. Full article

The health of road tunnel linings directly impacts traffic safety and requires regular inspection. Appearance defects on tunnel linings can be measured through images scanned by cameras mounted on a car to avoid disrupting traffic. Existing tunnel lining mobile scanning methods often fail in image stitching due to the lack of corresponding feature points in the lining images, or require complex, time-consuming algorithms to eliminate stitching seams caused by the same issue. This paper proposes a mobile scanning method aided by collimated lasers, which uses lasers as corresponding points to assist with image stitching to address the problems. Additionally, the lasers serve as structured light, enabling the measurement of image projection relationships. An inspection car was developed based on this method for the experiment. To ensure operational flexibility, a single checkerboard was used to calibrate the system, including estimating the poses of lasers and cameras, and a Laplace kernel-based algorithm was developed to guarantee the calibration accuracy. Experiments show that the performance of this algorithm exceeds that of other benchmark algorithms, and the proposed method produces nearly seamless, measurable tunnel lining images, demonstrating its feasibility. Full article

The increasing pace of climate-driven changes in forest ecosystems calls for reliable remote sensing techniques for quantifying above-ground carbon storage. In this article, we compare the methodology and results of traditional field surveys, mobile laser scanning, optical drone imaging and photogrammetry, and both drone-based and light aircraft-based aerial laser scanning to determine forest stand parameters, which are suitable to estimate carbon stock. Measurements were conducted at four designated sampling points established during a large-scale project in deciduous and coniferous tree stands of the Dudles Forest, Hungary. The results of the surveys were first compared spatially and quantitatively, followed by a summary of the advantages and disadvantages of each method. The mobile laser scanner proved to be the most accurate, while optical surveying—enhanced with a new diameter measurement methodology based on detecting stem positions from the photogrammetric point cloud and measuring the diameter directly on the orthorectified images—also delivered promising results. Aerial laser scanning was the least accurate but provided coverage over large areas. Based on the results, we recommend adapting our carbon stock estimation methodology primarily to mobile laser scanning surveys combined with aerial laser scanned data. Full article

This paper presents a standardized apparatus and method for testing the accuracy of mobile phone apps designed to measure concrete crack widths. The apparatus comprises a standardized crack-width calibration plate (CWCP) and a simulated wall (SW), along with a pose adjusting and fixing device (PAFD) and a spatial distance measuring assemblage (SDMA). The test method employs an innovative two-stage procedure associated with the SDMA to calculate the distances (K_i) from the phone’s four corners to the SW. The phone’s position is adjusted using the PAFD until the four monitored K_i values match the target K_i. An app installed on the phone then measures crack widths on the CWCP. A standard experimental procedure was established to assess the accuracy of a preliminary Android app in measuring concrete crack widths, with results presented and discussed. This apparatus and method, grounded in their underlying physical meaning, can realistically simulate actual engineering conditions precisely and cost-effectively. Full article

This study presents an automated docking block placement system developed for regular and emergency repairs of large ships and naval vessels. Traditional methods involve manually arranging heavy concrete docking blocks using cranes or forklifts, which can take several days and pose significant safety risks because of the heavy materials involved. The proposed system integrates an unmanned crane with a six-degree-of-freedom (6-DOF) robotic platform and a mobile robot-based 3D precision positioning system to automate block relocation. The use of a 3D laser tracker mounted on the mobile robot is the key to the system, which, when combined with environmental sensors such as LiDAR and RTK-GPS, provides millimeter-level positional feedback. To address the lack of clear reference points in conventional docking blocks, a precisely machined aluminum target block was attached to each block. An algorithm employing Density-Based Spatial Clustering of Applications with Noise (DBSCAN), KD-Tree, and Random Sample Consensus (RANSAC) techniques was used to detect and classify the vertex of the target block from the 3D point cloud data. The experimental results demonstrated a positional measurement error within 0.5 mm at an 8 m distance. This novel system reduces the setup time, enhances worker safety, and increases the overall efficiency and capacity of dry dock maintenance operations. Full article

In the N$\nu$DEx collaboration, a high-pressure gas TPC is being developed to search for the neutrinoless double beta decay. The use of electronegative ⁸²SeF₆ gas mandates an ion-TPC. The reconstruction of the z coordinate is to be realized by exploiting the feature of multiple species of charge carriers. As the initial stage of the development, we studied the properties of the ${\mathrm{SF}}_6$ gas, which is non-toxic and has a similar molecular structure to ${\mathrm{SeF}}_6$. In the paper, we present the measurement of drift velocities and mobilities of the majority and minority negative charge carriers found in ${\mathrm{SF}}_6$ at a pressure of 750 Torr, slightly higher than the local atmospheric pressure. The reduced fields range between 3.0 and 5.5 Td. This was performed using a laser beam to ionize the gas inside a small TPC, with a drift length of 3.7 cm. A customized charge-sensitive amplifier was developed to read out the anode signals induced by the slowly drifting ions. The closure test of the reconstruction of the z coordinate using the difference in the velocities of the two carriers was also demonstrated. Full article

This study investigates a laser ranging technology scheme featuring a large divergence angle for both the emitted and received laser beams, focusing on applications where both the measured target and the ranging carrier are high-mobility platforms. A dual-concave beam-reducing lens design is adopted to reshape the original beam divergence angle of 10 mrad from the erbium glass laser into a ranging output beam divergence angle of 26 mrad, while maintaining the Gaussian energy distribution of the original laser beam. A φ500 μm photosensitive surface APD detector is used, and a combination of aspherical and spherical elements is employed in the receiving optical system to achieve a 30 mrad large field-of-view echo reception within the small photosensitive surface. This laser ranging system addresses the challenge of aiming and tracking for laser ranging between relatively high-speed moving objects and reduces the stability precision requirements for the ranging carrier platform. Full article

With the gradual application of 3D reconstruction technology in underwater scenes, the design of vision-based reconstruction models has become an important research direction for human ocean exploration and development. The underwater laser triangulation method is the most commonly used approach, yet it misses details during the reconstruction of sparse point clouds, which do not meet the requirements of practical applications. On the other hand, existing underwater photometric stereo methods can accurately reconstruct local details of target objects, but they require relative stillness to be maintained between the camera and the target, which is practically difficult to achieve in underwater imaging environments. In this paper, we propose an underwater target reconstruction algorithm that combines laser triangulation and multispectral photometric stereo (MPS) to address the aforementioned practical problems in underwater 3D reconstruction.This algorithm can obtain more comprehensive 3D surface data of underwater objects through mobile measurement. At the same time, we propose to optimize the laser place calibration and laser line separation processes, further improving the reconstruction performance of underwater laser triangulation and multispectral photometric stereo. The experimental results show that our method achieves higher-precision and higher-density 3D reconstruction than current state-of-the-art methods. Full article

Forests are invaluable natural resources that provide essential ecosystem services, and their carbon storage capacity is critical for climate mitigation efforts. Quantifying this capacity would require accurate estimation of forest structural attributes for deriving their aboveground biomass (AGB). Traditional field measurements, while precise, are labor-intensive and often spatially limited. Handheld Mobile Laser Scanning (HMLS) offers a rapid alternative for building forest inventories; however, its effectiveness and accuracy in diverse subtropical forests with complex canopy structure remain under-investigated. In this study, we employed both HMLS and traditional surveys within structurally complex subtropical forest plots, including old-growth forests (Fung Shui Woods) and secondary forests. These forests are characterized by dense understories with abundant shrubs and lianas, as well as high stem density, which pose challenges in Light Detection and Ranging (LiDAR) point cloud data processing. We assessed tree detection rates and extracted tree attributes, including diameter at breast height (DBH) and canopy height. Additionally, we compared tree-level and plot-level AGB estimates using allometric equations. Our findings indicate that HMLS successfully detected over 90% of trees in both forest types and precisely measured DBH (R² > 0.96), although tree height detection exhibited relatively higher uncertainty (R² > 0.35). The AGB estimates derived from HMLS were comparable to those obtained from traditional field measurements. By producing highly accurate estimates of tree attributes, HMLS demonstrates its potential as an effective and non-destructive method for rapid forest inventory and AGB estimation in subtropical forests, making it a competitive option for aiding carbon storage estimations in complex forest environments. Full article

The removal of rust from large equipment such as trains and ship hulls poses a significant challenge. Traditional methods, such as chemical cleaning, flame rust removal, and laser rust removal, suffer from drawbacks such as high energy consumption, operational complexity, and poor mobility. Sandblasting and high-pressure water jet rust removal face issues such as high consumable costs and environmental pollution. Existing robotic grinding systems often rely on precise measurement of the workpiece surface geometry to perform deburring and polishing tasks; however, they lack the sufficient adaptability and robustness required for rust removal operations. To address these limitations, this study proposes a floating grinding actuator scheme based on compound force-position fuzzy control. By implementing simplified path-point planning, continuous grinding and rust removal can be achieved without requiring the pre-measurement of workpiece geometry data. This solution integrates force and laser displacement sensors to provide real-time compensation for path deviations and ensures adaptability to complex surfaces. A fuzzy derivative-leading PID algorithm was employed to control the grinding force, enabling adaptive force regulation and enhancing the control precision. Rust removal test results demonstrate that under varying advancing speeds, fuzzy derivative-leading PID control can significantly reduce fluctuations in both the grinding force and average error compared to traditional PID control. At a speed of 40 mm/s, excellent control performance was maintained, achieving a rust removal rate of 99.73%. This solution provides an efficient, environmentally friendly, and high-precision automated approach to rust removal using large-scale equipment. Full article

Human tracking is a fundamental technology for mobile robots that work with humans. Various devices are used to observe humans, such as cameras, RGB-D sensors, millimeter-wave radars, and laser range finders (LRF). Typical LRF measurements observe only the surroundings on a particular horizontal plane. Human recognition using an LRF has a low computational load and is suitable for mobile robots. However, it is vulnerable to variations in human height, potentially leading to detection failures for individuals taller or shorter than the standard height. This work aims to develop a method that is robust to height differences among humans using a 3D LiDAR. We observed the environment using a 3D LiDAR and projected the point cloud onto a single horizontal plane to apply a human-tracking method for 2D LRFs. We investigated the optimal height range of the point clouds for projection and found that using 30% of the point clouds from the top of the measured person provided the most stable tracking. The results of the path-following experiments revealed that the proposed method reduced the proportion of outlier points compared to projecting all the points (from 3.63% to 1.75%). As a result, the proposed method was effective in achieving robust human following. Full article
