Search Results (28)

This paper presents a highly efficient 5G New-Radio (NR) RF power amplifier module (PAM). The n77 PAM consists of a high-voltage differential-topology 2 μm GaAs HBT power amplifier, a CMOS controller, a silicon-on-insulator (SOI) switch, an integrated passive device (IPD) bandpass filter, a low-noise amplifier (LNA), and a bi-directional coupler. This PAM generates a saturation output power of 32.7 dBm including the loss of the SOI switch and output filter. The designed n77 PAM is tested with a commercial envelope tracker IC (ET-IC). The designed PAM with an ET-IC achieves an ACLR of −37 dBc at a 27 dBm output power with a DFT-s-OFDM QPSK 100 MHz NR signal and saves a dc power consumption of 950 mW compared to the APT mode. For the CP-OFDM 256QAM with the most stringent EVM requirements, it achieves an EVM of 1.22% at 23 dBm and saves 640 mW compared to the APT mode. Full article

In this article, a miniature eight-port multiple-input multiple-output (MIMO) antenna array is proposed for fifth-generation (5G) sub-6 GHz handset applications. The individual antenna element comprises a radiator shaped like the Chinese character “王” (phonetically represented as “Wang”) and three split-ring resonators (SRR) on the metal frame. The size of the individual antenna element is only 6.8 × 7 × 1 mm³ (47.6 mm³). The proposed antenna element has a −10 dB impedance bandwidth of 1.7 GHz (from 3.3 GHz to 5 GHz) that can cover 5G New Radio (NR) sub-6 GHz bands N77 (3.3–4.2 GHz), N78 (3.3–3.8 GHz), and N79 (4.4–5 GHz). The evolution design, the current distribution, the effects of single-handed holding, and the analysis of the parameters are deduced to study the approach used to design the featured antenna. The measured total efficiencies are from 40% to 80%, the isolation is better than 12 dB, the calculated envelope correlation coefficient (ECC) is less than 0.12, and the calculated channel capacity (CC) ranges from 35 to 38 bps/Hz. The presented antenna array is a good alternative to 5G mobile handsets with wideband operation, a metal frame, and minimized spacing. Full article

This paper presents a design and performance analysis of a 10-element 5G massive Multiple Input Multiple Output (m-MIMO) antenna array for sub-6 GHz mobile handsets, specifically for Long Term Evolution (LTE) bands 43 (3600–3800 MHz) and 48/49 (3550–3700 MHz) applications. The proposed antenna array consists of ten closely spaced inverted-F antennas with a compact size of 20 × 9 mm${}^2$ of a single element. The proposed antenna array provides high efficiency and low correlation between the antenna elements, which result in increased data rate and enhanced signal quality. The performance of the antenna array is evaluated in terms of the radiation pattern, diversity gain, efficiency, and correlation coefficient. The simulation and measured results show that the proposed antenna array achieves an approximate peak gain of 2.8 dBi and a total efficiency of 65% at the resonance frequency of 37 GHz and a low correlation coefficient of 0.07 between the adjacent antenna elements. Moreover, the single and two-hand modes are also given in order to highlight the potential of such a structure as a smart mobile terminal. The simulated results are discovered to be in excellent agreement with the measured values. We think this structure has a bright future in the next generation of smart mobile phones based on the performance and the measured findings. Full article

This study presents internet of things (IOT) and artificial intelligence technologies that are critical in reducing the harmful effects of this illness and assisting its recovery. It explores COVID-19’s economic impacts before learning about new technologies and potential solutions. The research objective was to propose a solution for self-diagnosis, self-monitoring, and self-management of COVID-19 with personal mobiles and personal data using cloud solutions and mobile applications with the help of an intelligent IoT system, artificial intelligence, machine learning, and 5G technologies. The proposed solution based on self-diagnosis without any security risk for users’ data with low cost of cloud-based data analytics by using handsets only is an innovative approach. Since the COVID-19 outbreak, the global social, economic, religious, and cultural frameworks and schedules have been affected adversely. The fear and panic associated with the new disease, which the world barely knew anything about, amplified the situation. Scientists and epidemiologists have traced the first outbreak of COVID-19 at Wuhan, China. A close examination of the genetic makeup of the virus showed that the virus is zoonotic, meaning that the virus changed hosts from animals to humans. The uncertainty associated with the above features and characteristics of the virus, as well as the high mortality rates witnessed in many parts of the globe, significantly contributed to the widespread global panic that brought the world to a standstill. Different authorities and agencies associated with securing the public have implemented different means and methods to try and mitigate the transmission of the infection as scientists and medical practitioners work on remedies to curb the spread of COVID-19. Owing to different demographics, different parts of the globe have attempted to effectively implement locally available resources to efficiently fight and mitigate the adverse effects of the COVID-19 pandemic. The general framework provided by the World Health Organization (WHO) has been implemented or enhanced in different parts of the globe by locally available resources and expertise to effectively mitigate the impact of COVID-19. There is currently no effective vaccine for COVID-19, but new technology can be available within weeks to reduce the spread of the disease; current approaches such as contact tracing and testing are not secure, and the cost of testing is high for end users. The proposed solution based on self-diagnosis without any security risk for users’ data with low cost of cloud-based data analytics functions by using an intelligent internet of things (IOT) system for collecting sensors data and processing them with artificial intelligence to improve efficiency and reduce the spread of COVID-19. Full article

In this paper, an embedded system is used as a host for the intercom and as a chatbot server for this system. The chatbot server controls door locks, cameras, buzzers, and related devices through web services on the WoT (Web of Things) to provide residents and visitors with better functionality and integrational services. This system can greatly improve the security and convenience of the system compared with the traditional intercom system. The resident uses the instant messaging software of the smartphone to replace the handset function, and there is no need to install and learn new apps, reducing the cost of the handset and the wiring indoors and outdoors. Whether or not the residents are at home, they can check whether there are visitors and check the status of their doors through their smartphones. Conversely, any visitor can also contact the resident through this intercom, while there is no way to confirm whether the resident is at home or not, which enhances the security of the house. This system provides flexibility in wireless installation and use and sufficient mobility for residents. The system architecture strikes a good balance between user convenience and home security and between performance and cost, effectively improving home security and reducing costs. Full article

This article reported a compact ultra-thin tightly arranged 4 × 4 multiple-input multiple-output (MIMO) antenna pair (AP) functioning in the fifth-generation (5G) n78 band (3.4–3.6 GHz) for the ultra-thin 5G mobile handset. Two APs were printed on the center of two sideboards. A T-shaped open-ended slot was utilized in the grounding plane to improve the port impedance matching and attenuate the reciprocal magnetic coupling. A minimized total volume of 145 × 75 × 5 mm³ was obtained, and the area of each radiating unit was only 8.5 × 4.2 mm² (0.1λ₀ × 0.05λ₀, λ₀ is the free-space wavelength at the frequency of 3.5 GHz). By placing two radiating elements in an exceeding closed (1 mm or 0.01167λ₀) distance, the designed AP precisely resonated at 3.5 GHz, and an acceptable measured isolation performance superior to 17 dB was attained. A prototype of this presented APs system was printed and tested, and remarkable consistency was observed between the simulated and measured curves. Numerous indicators were computed to assess its MIMO performance, such as Envelope Correlation Efficiency (ECC), Diversity Gain (DG), Total Active Reflection Coefficient (TARC), and Multiplexing Efficiency (ME). Full article

Visually impaired people face many challenges that limit their ability to perform daily tasks and interact with the surrounding world. Navigating around places is one of the biggest challenges that face visually impaired people, especially those with complete loss of vision. As the Internet of Things (IoT) concept starts to play a major role in smart cities applications, visually impaired people can be one of the benefitted clients. In this paper, we propose a smart IoT-based mobile sensors unit that can be attached to an off-the-shelf cane, hereafter a smart cane, to facilitate independent movement for visually impaired people. The proposed mobile sensors unit consists of a six-axis accelerometer/gyro, ultrasonic sensors, GPS sensor, cameras, a digital motion processor and a single credit-card-sized single-board microcomputer. The unit is used to collect information about the cane user and the surrounding obstacles while on the move. An embedded machine learning algorithm is developed and stored in the microcomputer memory to identify the detected obstacles and alarm the user about their nature. In addition, in case of emergencies such as a cane fall, the unit alerts the cane user and their guardian. Moreover, a mobile application is developed to be used by the guardian to track the cane user via Google Maps using a mobile handset to ensure safety. To validate the system, a prototype was developed and tested. Full article

This article presents the design of a uni-planar MIMO antenna system for sub-6 GHz 5G-enabled smartphones. The MIMO antenna designed comprises four loop-shaped radiators placed at each corner of the mobile phone board, which follows the principle of pattern diversity. The single-antenna element resonates at 3.5 GHz, its impedance bandwidth is noted to be 1.28 GHz (3–4.28 GHz) for S${}_{11}\le$ −6 dB, and it is equal to 720 MHz (3.18–3.9 GHz) for S${}_{11}\le$ −10 dB. For a single-antenna element, a peak gain of 3.64 dBi is observed with an antenna efficiency of >90%. The isolation of >10 dB between antenna elements is achieved for the MIMO configuration. Furthermore, the MIMO antenna designed provides enough radiation coverage to support different sides of the mobile phone board, which is an important feature for future 5G-enabled handsets. In addition, the impacts of human hands and heads on MIMO antenna performance are investigated, and acceptable performance in the data and conversation modes is observed. Full article

With the rapid growth in the penetration rate of mobile devices and the surge in demand for mobile data services, small cells and mobile backhaul networks have become the critical focus of next-generation mobile network development. Backhaul requirements within current wireless networks are almost asymmetrical, with most traffic flowing from the core to the handset, but 5G networks will require more symmetrical backhaul capability. The deployment of small cells and the placement of transceivers for cellular phones are crucial in trading off the symmetric backhaul capability and cost-effectiveness. The deployment of small cells is related to the placement of transceivers for cellular phones. Chang, Kloks, and Lee transformed the placement problem into the maximum-clique transversal problem on graphs. From the theoretical point of view, our paper considers the parameterized complexity of variations of the maximum-clique transversal problem for split graphs, doubly chordal graphs, planar graphs, and graphs of bounded treewidth. Full article

The electromagnetic field (EMF) in electric vehicles (EVs) affects not only drivers, but also passengers (using EVs daily) and electronic devices inside. This article summarizes the measurement methods applicable in studies of complex EMF in EVs focused on the evaluation of characteristics of such exposure to EVs users and drivers, together with the results of investigations into the static magnetic field (SMF), the extremely low-frequency magnetic field (ELF) and radiofrequency (RF) EMF related to the use of the EVs in urban transportation. The investigated EMF components comply separately with limits provided by international labor law and guidelines regarding the evaluation of human short-term exposure; however other issues need attention—electromagnetic immunity of electronic devices and long-term human exposure. The strongest EMF was found in the vicinity of direct current (DC) charging installations—SMF up to 0.2 mT and ELF magnetic field up to 100 µT—and inside the EVs—up to 30 µT close to its internal electrical equipment. Exposure to RF EMF inside the EVs (up to a few V/m) was found and recognized to be emitted from outdoor radiocommunications systems, together with emissions from sources used inside vehicles, such as passenger mobile communication handsets and antennas of Wi-Fi routers. Full article

Faced with the biggest virus outbreak in a century, world governments at the start of 2020 took unprecedented measures to protect their healthcare systems from being overwhelmed in the light of the COVID-19 pandemic. International travel was halted and lockdowns were imposed. Many nations adopted measures to stop the transmission of the virus, such as imposing the wearing of face masks, social distancing, and limits on social gatherings. Technology was quickly developed for mobile phones, allowing governments to track people’s movements concerning locations of the virus (both people and places). These are called contact tracing applications. Contact tracing applications raise serious privacy and security concerns. Within Europe, two systems evolved: a centralised system, which calculates risk on a central server, and a decentralised system, which calculates risk on the users’ handset. This study examined both systems from a threat perspective to design a framework that enables privacy and security for contact tracing applications. Such a framework is helpful for App developers. The study found that even though both systems comply with the General Data Protection Regulation (GDPR), Europe’s privacy legislation, the centralised system suffers from severe risks against the threats identified. Experiments, research, and reviews tested the decentralised system in various settings but found that it performs better but still suffers from inherent shortcomings. User tracking and re-identification are possible, especially when users report themselves as infected. Based on these data, the study identified and validated a framework that enables privacy and security. The study also found that the current implementations using the decentralised Google/Apple API do not comply with the framework. Full article

This work develops a novel dynamic load modulation Power Amplifier (PA) circuity that can provide an optimum compromise between linearity and efficiency while covering multiple cellular frequency bands. Exploiting monolithic microwave integrated circuits (MMIC) technology, a fully integrated 1W Doherty PA architecture is proposed based on 0.1 μm AlGaAs/InGaAs Depletion-Mode (D-Mode) technology provided by the WIN Semiconductors foundry. The proposed wideband DPA incorporates the harmonic tuning Class-J mode of operation, which aims to engineer the voltage waveform via second harmonic capacitive load termination. Moreover, the applied post-matching technique not only reduces the impedance transformation ratio of the conventional DPA, but also restores its proper load modulation. The simulation results indicate that the monolithic drive load modulation PA at 4 V operation voltage delivers 44% PAE at the maximum output power of 30 dBm at the 1 dB compression point, and 34% power-added efficiency (PAE) at 6 dB power back-off (PBO). A power gain flatness of around 14 ± 0.5 dB was achieved over the frequency band of 23 GHz to 27 GHz. The compact MMIC load modulation technique developed for the 5G mobile handset occupies the die area of 3.2 mm². Full article

In this paper, a new sensor is developed to estimate the dielectric constant of Cyclo Olefin Polymer (COP) film utilizable for 5G mobile phones’ multi-layered back-cover. It is featured by the electrical characterization of the thin layer of the COP film at 28 GHz as the material under test (MUT) directly contacting the planar probe (which is an array of resonating patches) and a new meta-surface as metal patterned on the COP film inserted between the planar probe and the 5G multi-layered back-cover for enhanced physical interpretation of the data by way of impedance matching. In this approach to delving into the material, a thin and small meta-surface film with an area of 25.65 × 21.06 mm² and a thickness of 55 μm is examined for applications to 5G mobile 28 GHz-frequency communication on the basis of the below −10 dB-impedance matching for the 1-by-4 array sensor. Along with this, the real and commercial handset back-cover is brought to the test. The proposed method presents the advantages of geometrical adequacy to the realistic 5G handset antenna configuration, the idea of impedance-matching via meta-materials, and the suitability of characterizing the film-type structure as compared to the open-ended coaxial waveguide, waveguide-to-waveguide and TX horn-to-RX horn free-space test methods. Full article

Public works’ relationship with the landscape should be among the factors addressed in heritage studies. Their association with place defines their purpose while contributing to the construction of the cultural landscape. Unawareness of the existence of public works is their most powerful enemy. Inventorying and cataloguing are therefore imperative in any study of these assets. The research described here drew from information technologies to develop cost-free mobile apps in an innovative approach to dissemination with the aim to enhance public awareness of and esteem for such elements. The applications described, which are all author-developed and designed to promote Spain’s heritage public works, address the heritage value of rural public works (VAPROP_Rutas), geolocation of the built heritage (GEOPACK), heritage public works on the River Duero (PHDuero), major works of engineering (GOING) and geolocation of Eduardo Torroja’s public works (underway). All these applications build on the geo-positioning features of mobile handsets and are characterised by simple and intuitive interfaces for ready accessibility by the public at large. Users may participate in the experience by entering useful information, new content and suggestions. These apps deploy the latest technologies to enhance the understanding and appreciation of civil works by explaining their territorial, social and cultural significance. Full article

The increasing popularity of using wireless devices to handle routine tasks has increased the demand for incorporating multiple-input-multiple-output (MIMO) technology to utilize limited bandwidth efficiently. The presence of comparatively large space at the base station (BS) makes it straightforward to exploit the MIMO technology’s useful properties. From a mobile handset point of view, and limited space at the mobile handset, complex procedures are required to increase the number of active antenna elements. In this paper, to address such type of issues, a four-element MIMO dual band, dual diversity, dipole antenna has been proposed for 5G-enabled handsets. The proposed antenna design relies on space diversity as well as pattern diversity to provide an acceptable MIMO performance. The proposed dipole antenna simultaneously operates at 3.6 and 4.7 sub-6 GHz bands. The usefulness of the proposed $4\times 4$ MIMO dipole antenna has been verified by comparing the simulated and measured results using a fabricated version of the proposed antenna. A specific absorption rate (SAR) analysis has been carried out using CST Voxel (a heterogeneous biological human head) model, which shows maximum SAR value for 10 g of head tissue is well below the permitted value of 2.0 W/kg. The total efficiency of each antenna element in this structure is −2.88, −3.12, −1.92 and −2.45 dB at 3.6 GHz, while at 4.7 GHz are −1.61, −2.19, −1.72 and −1.18 dB respectively. The isolation, envelope correlation coefficient (ECC) between the adjacent ports and the loss in capacity is below the standard margin, making the structure appropriate for MIMO applications. The effect of handgrip and the housing box on the total antenna efficiency is analyzed, and only 5% variation is observed, which results from careful placement of antenna elements. Full article
