Search Results (22)

Very low Earth orbit (VLEO) satellites are confronted with the challenge of orbital decay caused by thin atmospheres, and the volume and power limitations of micro satellites further restrict the application of traditional electric propulsion systems. In response to the above requirements, this study proposes an innovative scheme of radio frequency plasma micro-thrusters based on magnetic nozzle acceleration technology. By optimizing the magnetic nozzle configuration through the system, the plasma confinement efficiency was significantly enhanced. Combined with the mixed working medium (5 sccm Xe + 10 sccm air), the thrust reached 1.7 mN at a power of 130 W. Experiments show that the configuration of the magnetic nozzle directly affects the plasma beam morphology and ionization efficiency, and a multi-magnet layout can form a stable trumpet-shaped plume. The air in the mixed working medium has a linear relationship with the thrust gain (60 μN/sccm), but xenon gas is required as a “seed” to maintain the discharge stability. The optimized magnetic nozzle enables the thruster to achieve both high thrust density (13.1 μN/W) and working medium adaptability at a power level of hundreds of watts. This research provides a low-cost and miniaturized propulsion solution for very low Earth orbit satellites. Its magnetic nozzle-hybrid propellant collaborative mechanism holds significant engineering significance for the development of air-aspirating electric propulsion technology. Full article

Micronewton thrusters have a wide range of applications in the aerospace field, and the accuracy of micronewton thrust measurement is directly affected by environmental vibration. The cantilever beam is the core part of the microthrust measurement system, and its stability directly affects the accuracy of thrust calibration. Aiming at the problems of the cantilever beam oscillating during the change in thrust and being susceptible to the impulse vibration of the ground, the interference suppression scheme of the microthrust measurement system based on the fuzzy PID of particle swarm optimization is investigated. And an interference suppression algorithm of the microthrust system based on the adaptive Kalman displacement expectancy estimation algorithm and the fuzzy PID of particle swarm optimization is designed. An adaptive Kalman displacement expectation estimation algorithm and a particle swarm optimization fuzzy PID microthrust system interference suppression algorithm are designed. The results show that the proposed algorithm can effectively track the thrust signal and suppress the influence of external vibration interference for the mN-level thrust change, control the overshooting amount within 10%, shorten the stabilization time to within 0.2 s, reduce the impulse oscillation to 22% of the original, reduce the steady-state error, and have a strong suppression effect on the oscillation phenomenon of the system, with better control accuracy and stability, and provide a good condition for the thrust calibration. Full article

The critical structural parameters are optimized and studied using the numerical simulation method to improve the resolution and stability of the Micro-Thrust Measurement Platform (MTMP). Under two different ground random vibration environments, the parameters, such as pivot thickness, pendulum rod length, and pivot structure, are focused on analyzing the influence of the system’s resolution and stability. The results show that when the thickness of the pivot is 0.04 mm or 0.2 mm, and the pendulum rod length is 2 m, the effect of ground random vibration on the MTMP is minimized. At 0.1 mHz, it can reach 0.0057 $\mathsf{\mu }$N/$\sqrt{\mathrm{Hz}}$. In the series double-pivot structure, an appropriate increase in the distance between the sheets can further optimize the above conclusions. The results and analysis within this study can provide support for the engineering design of the MTMP. Full article

Laser micro-thrust technology is a type of propulsion that uses a laser beam to ablate a propellant such as a metal or plastic. The ablated material is expelled out the back of the spacecraft, generating thrust. The technology has the advantages of high control precision, high thrust–power ratios, and excellent performances, and it has played an important role in the field of micro-propulsion. In this study, a solid propellant laser micro-thruster was developed and then applied for the attitude control of satellites during on-orbit tests. The micro-thruster had a volume of 0.5 U, a weight of 440 g, and a thrust range of 10 μN–0.6 mN. The propellant, 87% glycidyl azide polymer (GAP) + 10% ammonium perchlorate (AP) + 3% carbon nano-powder, was supplied via a double-layer belt, and the average power was less than 10 W. We present the development of the laser micro-thruster, as well as the results regarding the thruster propulsion performance. The thruster was launched into orbit on 27 February 2022 with the Chuangxin Leishen Satellite developed by Spacety. The on-orbit test of the thruster for satellite attitude control was carried out. The thruster was successfully fired in space and played an obvious role in the attitude control of the satellite. The experimental results show that the thrust is about 315 μN. Full article

When the satellite is in orbit, the thruster will experience drastic temperature changes (100–1000 K) under solar radiation, which will affect the rarefied gas flow state in the micro-nozzle structure of the cold gas micro-thruster. In this study, the effect of different wall temperatures on the rarefied flow and heat transfer in the micro-nozzle is investigated based on the DSMC method. The micro-nozzle structure in this paper has a micro-channel with a large length-to-diameter ratio of 10 and a micro-scale needle valve displacement (maximum needle valve displacement up to 4 μm). This leads to more pronounced multiscale flow characteristics in the micro-nozzle, which is more influenced by the change in wall temperature. At wall temperatures ranging from 100 K to 1000 K, the spatial distribution of local Kn distribution, slip velocity distribution, temperature, and wall heat flux distribution in the micro-nozzle were calculated. The slip flow region is located in the flow channel and transforms into transition flow as the slip velocity reaches approximately 50 m/s. The spatial distribution of the flow pattern is dominated by the wall temperature at small needle valve opening ratios. The higher the wall temperature, the smaller the temperature drop ratio in the low-temperature region inside the micro-nozzle. The results of the study provide a reference for the design of temperature control of micro-nozzles in cold gas micro-thrusters. Full article

The needle valve, serving as the flow control unit of the thruster system, is a crucial component of the entire thruster. Its performance directly impacts the flow state of the rarefied gas in the micro-nozzle structure of the cold gas micro-thruster, thereby exerting a significant influence on the high precision and stability of the propulsion system as a whole. This study examines the impact of different needle valve structures on the flow and thrust in micro-nozzles using the DSMC method. The analysis includes discussions on the spatial distribution, Kn distribution, slip velocity distribution, and pressure distribution of the micro-nozzle’s flow mechanism. Notably, increased curvature of the needle valve enhances the flow velocity in the throat and expansion section. The magnitude of the curvature directly affects the flow velocity, with larger curvatures resulting in higher velocities. Comparing different spool shapes, the conical spool shape minimizes the velocity gradient in the high-speed region at the junction between the spool area and the outlet pipe, particularly with a wide opening. Increasing the curvature of the spool leads to a higher velocity in the expansion section. Consequently, an arc-shaped spool valve maximizes the nitrogen flow at the nozzle during wide openings, thereby enhancing thrust. These research findings serve as a valuable reference for the structural design of the needle valve in the micro-nozzle of the cold gas micro-thruster. Full article

Visualization methods have always been used to inspect flows that are invisible to the naked eye. Seedless velocimetry has been regarded as an alternative to other intrusive quantitative methods and adapted to fit many applications in the industrial or scientific field. Schlieren image velocimetry (SIV) uses the general working principle of a schlieren system to acquire flow images, while relying on a particle image velocimetry (PIV)-like algorithm to obtain quantitative data related to the studied flow. The test case of this study consists of a turbulent round exhaust jet generated by a micro-thruster that uses ${\mathrm{H}}_2-{\mathrm{O}}_2$ as a propellent. Mapping the local velocities of the flow is achieved by initially performing a lagrangian tracking method which makes use of a direct image correlation algorithm. These results are then compared to the velocity map obtained from a kymograph applied to a series of images. The velocity profiles obtained through SIV will be compared to the velocity profile of the jet provided by the CFD simulation. The schlieren investigation of the jet’s local velocity map is set to determine the thruster’s capabilities, and conclude if the thruster reaches the desired Mach for which it has been designed. Full article

The transmissive mode laser micro-ablation performance of near-infrared (NIR) dye-optimized ammonium dinitramide (ADN)-based liquid propellant was investigated in laser plasma propulsion using a pulse YAG laser with 5 ns pulse width and 1064 nm wavelength. Miniature fiber optic near-infrared spectrometer, differential scanning calorimeter (DSC) and high-speed camera were used to study laser energy deposition, thermal analysis of ADN-based liquid propellants and the flow field evolution process, respectively. Experimental results indicate that two important factors, laser energy deposition efficiency and heat release from energetic liquid propellants, obviously affect the ablation performance. The results showed that the best ablation effect of 0.4 mL ADN solution dissolved in 0.6 mL dye solution (40%-AAD) liquid propellant was obtained with the ADN liquid propellant content increasing in the combustion chamber. Furthermore, adding 2% ammonium perchlorate (AP) solid powder gave rise to variations in the ablation volume and energetic properties of propellants, which enhanced the propellant enthalpy variable and burn rate. Based on the AP optimized laser ablation, the optimal single-pulse impulse (I)~9.8 μN·s, specific impulse (I_sp)~234.9 s, impulse coupling coefficient (C_m)~62.43 dyne/W and energy factor (η)~71.2% were obtained in 200 µm scale combustion chamber. This work would enable further improvements in the small volume and high integration of liquid propellant laser micro-thruster. Full article

Pulsed plasma thrusters (PPT) have demonstrated enormous potential since the 1960s. One major shortcoming is their low thrust efficiency, typically <30%. Most of these losses are due to joule heating, while some can be attributed to poor efficiency of the power processing units (PPUs). We model PPTs to improve their efficiency, by exploring the use of power electronic topologies to enhance the power conversion efficiency from the DC source to the thruster head. Different control approaches are considered, starting off with the basic approach of a fixed frequency flyback converter. Then, the more advanced critical conduction mode (CrCM) flyback, as well as other optimized solutions using commercial off-the-shelf (COTS) components, are presented. Variations of these flyback converters are studied under different control regimes, such as zero voltage switching (ZVS), valley voltage switching (VVS), and hard switched, to enhance the performance and efficiency of the PPU. We compare the max voltage, charge time, and the overall power conversion efficiency for different operating regimes. Our analytical results show that a more dynamic control regime can result in fewer losses and enhanced performance, offering an improved power conversion efficiency for PPUs used with PPTs. An efficiency of 86% was achieved using the variable frequency approach. This work has narrowed the possible PPU options through analytical analysis and has therefore identified a strategic approach for future investigations. In addition, a new low-power coaxial micro-thruster model using equivalent circuit model elements is developed.This is referred to as the Carlow–Stuttgart model and has been validated against experimental data from vacuum chamber tests in Stuttgart’s Pulsed Plasma Laboratory. This work serves as a valuable precursor towards the implementation of highly optimized PPU designs for efficient PPT thrusters for the next PETRUS (pulsed electrothermal thruster for the University of Stuttgart) missions. Full article

In this article, electro-osmotic thrusters (EOTs), which are full of non-Newtonian power-law fluids with a flow behavior index n of the effective viscosity, are theoretically investigated in a microchannel. Different values of the flow behavior index represent two kinds of non-Newtonian power-law fluids, pseudoplastic fluids (n < 1) and dilatant fluids (n > 1), which have not yet been considered to be used as propellants in micro-thrusters. Analytical solutions of the electric potential and flow velocity are obtained using the Debye–Hückel linearization assumption and the approximate scheme of hyperbolic sine function. Then, thruster performances of power-law fluids, including specific impulse, thrust, thruster efficiency, and thrust-to-power ratio, are explored in detail. Results show that these performance curves strongly depend on the flow behavior index and electrokinetic width. It is noted that the non-Newtonian pseudoplastic fluid is most suitable as a propeller solvent in micro electro-osmotic thrusters owing to its improving or optimizing deficiencies in the performances of the existing Newtonian fluid thrusters. Full article

This paper reports on the effect of structural materials on heat loss-associated propulsion performance degradation of monopropellant thrusters in the micro scale. In order to address the effect of fabrication materials on heat loss, propellant flow characteristics, and propulsion performance, a conjugate heat transfer numerical study has been conducted considering several practical substrate candidates for microthrusters. The results were analyzed with respect to the thermal diffusivity of the materials, which revealed different propulsion performance characteristics and inner nozzle flow characteristics due to varying amounts of heat loss, depending on the microfabrication materials used and propellant enthalpies. Regardless of propellant enthalpies, however, there was a dramatic degradation in the amount of the thrust produced with respect to thermal diffusivity, particularly in the range of low thermal diffusivity. Glass, among the material types compatible with fabrication processes in regard to microthrusters, exhibited a 4% degradation in thrust performance for the 50 mN class microthruster considered, with the least degradation, while copper, with 7% degradation, exhibited the greatest amount of degradation among the materials considered. With varying chamber pressure and Mach number at the nozzle exit depending on structural materials, the results also indicated the necessity of heat loss consideration in a microthruster design process. Full article

Aiming at the shortcomings of non-optimal fuel consumption and low accuracy of Geosynchronous orbit (GEO) satellites in the east/west station keeping (EWSK) at the current stage, a micro-thrust EWSK algorithm for GEO satellites based on a single-synovial surface is proposed. This algorithm has the characteristics of low fuel consumption and high control precision. However, when this algorithm performs GEO station switching under the condition of limited velocity increment, the mean longitude capture path may not be optimal, the capture time of the mean longitude is too long, and the engineering applicability is not good. In view of the above problems, a micro-thrust EWSK for GEO satellites based on dual synovial surfaces is proposed. Through the advance planning of the mean longitude, the control lag caused by the limited velocity increment is eliminated, the optimal path-planning problem of the mean longitude is solved, and the capture time of the mean longitude is greatly shortened. The two EWSK algorithms proposed in this paper have the advantages of small calculation amount, optimal fuel consumption, high precision and strong stability, which have good engineering application value. Full article

In this study, we first considered the influence of micro-nozzle wall roughness structure on molecular collision and reflection behavior and established a modified CLL model. The DSMC method was used to simulate and analyze the flow of the micro-nozzle in the cold gas micro-propulsion system, and the deviation of simulation results before and after the improvement of CLL model were compared. Then, the rarefied flow characteristics under a small needle valve opening (less than 1%) were focused on the research, and the particle position, molecular number density, and spatial distribution of internal energy in the micro-nozzle were calculated. The spatial distributions of the flow mechanism in the micro-nozzle under different needle valve openings were compared and analyzed. It was found that when the needle valve opening is lower than 1%, the slip flow and transition flow regions move significantly upstream of the nozzle, the free molecular flow distribution region expands significantly, and the relationship between thrust force and needle valve opening is obviously different from that of medium and large needle valve openings. The effect of nitrogen temperature on the rarefied flow and thrust force is also discussed in this research. The numerical results showed that as gas temperature increases, the molecular internal energy, momentum, and molecular number density near the nozzle exit are enhanced. The thrust at small needle valve openings was significantly affected by the temperature of the working mass. The results of this study will provide key data for the design and development of cold gas micro-thrusters. Full article

In the field of laser ablation micro-propulsion, the property of double-layer tape has significant impact on the propulsion performance. In this paper, low temperature plasma was used to treat the surface of polyethylene terephthalate (PET) to improve its adhesion with energetic polymer. The PET surface pre- and post-plasma treatment was characterized by X-ray photoelectron spectroscopy (XPS) and atomic force microscopy (AFM), and the enhancement mechanism of the interface adhesion was discussed. In addition, the ablation performance of the double-layer tape after the plasma treatment was studied. The results showed that the plasma etching effect increased the root mean square roughness of the PET surface from 1.74 nm to 19.10 nm. In addition, after the plasma treatment, the number of C–OH/COOH bonds and O=C–O bonds increased, which also greatly improved the adhesion between the PET and energetic polymers. In the optimization of the ablation performance, the optimal laser pulse width was about 200 μs. The optimal values of the specific impulse (I_sp), impulse coupling coefficient (C_m), and ablation efficiency (η) were 390.65 s, 250.82 μN/W, and 48.01%, respectively. The optimization of the adhesion of the double-layer tape and the ablation performance lay the foundation for the engineering application of laser ablation micro-thrusters. Full article

Submicron particles transported by a Laval-type micronozzle are widely used in micro- and nano-electromechanical systems for the aerodynamic scheme of particle acceleration and focusing. In this paper, the Euler–Lagrangian method is utilized to numerically study non-spherical submicron particle diffusion in a converging–diverging micronozzle flow field. The influence of particle density and shape factor on the focusing process is discussed. The numerical simulation shows how submicron particle transporting with varying shape factors and particle density results in different particle velocities, trajectories and focusing in a micronozzle flow field. The particle with a larger shape factor or larger density exhibits a stronger aerodynamic focusing effect in a supersonic flow field through the nozzle. In the intersection process, as the particle size increases, the position of the particle trajectory intersection moves towards the throat at first and then it moves towards the nozzle outlet. Moreover, the influence of the thermophoretic force of the submicron particle on the aerodynamic focusing can be ignored. The results will be beneficial in technological applications, such as micro-thrusters, microfabrication and micro cold spray. Full article
