This paper presents a compact monopole wideband antenna based on DGS. The ultimate geometry of the designed antenna is obtained after many design modifications and optimizations. A commercially available Taconic TLY substrate with a dielectric constant (ε_r) = 2.2, loss tangent (tan δ) = 0.0009, and thickness (h) of 1.524 mm is used. The dimension of the substrate is 34 mm × 28 mm. A 50Ω microstrip transmission line of size 12 mm × 3 mm is used to feed the antenna. Simulation results demonstrate a bandwidth from 4.08 to 18.92 GHz, a percentage bandwidth of 129% for S11 < −10 dB, and a peak gain of 7.4 dB. The DGS slots are embedded into the ground plane to enhance the antenna’s bandwidth, impedance matching, gain, and efficiency. For verification, the proposed antenna is fabricated and measured. Good agreement between measured and simulated results is observed. Thus, this antenna is appropriate for various modern wireless communication systems. Full article

This paper proposes a 2-D fully polarized Van Atta array, which consists of four tri-polarized antenna elements. The tri-polarized antenna element comprises a monopole antenna and a low-profile microstrip antenna that widens the beam by folding four electric walls. This configuration enables the Van Atta arrays to receive and transmit arbitrarily polarized incident waves over a wider range. The measurement results indicate that the proposed Van Atta array exhibits a −5 dB radar cross-section (RCS) greater than 95° when TE-polarized waves are incident and greater than 134° when TM-polarized waves are incident, significantly surpassing the 2-D dual-polarized array. Full article

In this paper, a compact and simplified geometry monopole antenna with high gain and wideband is introduced. The presented antenna incorporates a microstrip feedline and a circular patch with two circular rings of stubs, which are inserted into the reference circular patch antenna to enhance the bandwidth and return loss. Roger RT/Duroid 6002 is used as the material for the antenna, and has overall dimensions of W_S × L_S = 12 mm × 9 mm. Three designs of two-port MIMO configurations are derived from the reference unit element antenna. In the first design, the antenna element is placed parallel to the reference antenna, while in the second design, the element is placed orthogonal to the reference element of the antenna. In the third design, the antenna elements are adjusted to be opposite each other. In this study, we analyze the isolation between the MIMO elements with different arrangements of the elements. The MIMO configurations have dimensions of 15 mm × 26 mm for two of the cases and 15 mm × 28.75 mm for the third case. All three MIMO antennas are made using similar materials and have the same specifications as the single element antenna. Other significant MIMO parameters, including the envelope correlation coefficient (ECC), diversity gain (DG), channel capacity loss (CCL), and mean effective gain (MEG), are also researched. Additionally, the paper includes a table summarizing the assessment of this work in comparison to relevant literature. The results of this study indicate that the proposed antenna is well-suited for future millimeter wave applications operating at 28 GHz. Full article

A novel compact-slotted four element multiple input multiple output (MIMO) planar monopole antenna is proposed for 5G mmWave N257/N258 and N262 band applications. The antenna, with dimensions of 12 mm × 11.6 mm × 0.508 mm ($1.036{\lambda }_o \times$$1.001{\lambda }_o\times 0.043{\lambda }_o$ where ${\lambda }_o$ is computed at lowest cutoff frequency), is fabricated on a Rogers RT/duroid 5880 (tm) substrate with a relative permittivity of 2.2 and a dielectric loss tangent of 0.0009. The suggested antenna consists of four U-shaped radiating elements (patches) on top of the dielectric material and a slotted ground on the bottom. The radiating elements are fed by a 50-ohm microstrip line feed. To improve the impedance performance of the MIMO antenna, a rectangular strip of 1.3 mm × 0.2 mm and a couple of rectangular slots are added to each radiating element. The first operating band at 27.1 GHz, ranging from 25.9 GHz to 27.8 GHz, is achieved by using slotted U-shaped radiating elements. The second operating band at 48.7 GHz, ranging from 47.1 GHz to 49.9 GHz, is obtained by etching hexagonal slots on the ground. The antenna design achieves an isolation of >27 dB through the orthogonal positioning of radiating elements and slots on the ground. The designed antenna operates at 27 GHz (N257/N258) and 48.7 GHz (N262) bands, exhibiting stable radiation patterns, a peak gain of >5.95 dBi, radiation efficiency of >90%, an envelope correlation coefficient of <10⁻⁶, a total active reflection coefficient of ≤−10 dB, channel capacity losses of <0.03 bits/s/Hz, and a mean effective gain of ≤−3 dB. The simulated and measured results of the antenna show good agreement, making it well-suited for 5G mmWave communication applications. Full article

In this work, a highly miniaturized microstrip antenna array based on two elements is proposed for multiple inputs multiple outputs (MIMO) application systems at sub-6 GHz frequency bands. The antenna is structured from a meander line in conjugate with an interdigital capacitor when excited through the monopole basic antenna. The proposed antenna elements are separated with a Minkowski factor-shaped metamaterial (MTM) column to achieve a separation distance (D) of 0.08λ at 3 GHz when printed on an FR-4 substrate. Later on, the antenna performance in terms of bandwidth and gain is controlled using a photonic process based on optical active switches based on light-dependent resistances (LDR). Therefore, the reconfiguration complexity with such a technique can be eliminated significantly without the need for a biasing circuit. The antenna design was conducted through several parametric studies to arrive at the optimal design that realizes the frequency bandwidth between 3 and 5.5 GHz with a maximum gain of about 4.5 dBi when all LDR terminals are off. For a wireless channel performance study-based massive MIMO environment, the proposed antenna is suitable to be configured in arrays of 64 × 64 elements. From this study, it was found the maximum bit error rate (BER) does not exceed 0.15 with a channel capacity (CC) of 2 Gbps. For validation, the antenna was fabricated based on two elements and tested experimentally. Finally, it was revealed that the measured results agree very well with simulations after comparing the theoretical calculations with the measured data. Full article

This work presents an efficient design and optimization method based on characteristic mode analysis (CMA) to predict the resonance and gain of wideband antennas made from flexible materials. Known as the even mode combination (EMC) method based on CMA, the forward gain is estimated based on the principle of summing the electric field magnitudes of the first even dominant modes of the antenna. To demonstrate its effectiveness, two compact, flexible planar monopole antennas designed on different materials and two different feeding methods are presented and analyzed. The first planar monopole is designed on Kapton polyimide substrate and fed using a coplanar waveguide to operate from 2 to 5.27 GHz (measured). On the other hand, the second antenna is designed on felt textile and fed using a microstrip line to operate from about 2.99 to 5.57 GHz (measured). Their frequencies are selected to ensure their relevance in operating across several important wireless frequency bands, such as 2.45 GHz, 3.6 GHz, 5.5 GHz, and 5.8 GHz. On the other hand, these antennas are also designed to enable competitive bandwidth and compactness relative to the recent literature. Comparison of the optimized gains and other performance parameters of both structures are in agreement with the optimized results from full wave simulations, which process is less resource-efficient and more iterative. Full article

A high-dimension ratio, octagonal-shaped, super-wideband (SWB) monopole antenna was proposed in this paper. The proposed antenna was composed of an octagonal-structured radiating patch with a flower-shaped slot fed by a linearly tapering microstrip line and a rectangular partial ground fabricated on a Rogers 5880 dielectric substrate, with an overall dimension of 14 × 16 × 0.787 mm³. The designed antenna exhibits SWB characteristics over the frequency range of 3.71 to 337.88 GHz at |S11| ≤ −10 dB, VSWR < 2, a bandwidth ratio (BR) of 91.07:1, and a very high BDR of 6057.27. The proposed SWB antenna was designed, simulated, and analyzed using Ansys high-frequency structural simulator (HFSS). The simulated and measured findings have good confirmability, making them ideal for future-generation mobile networks, due to their strong radiation properties, compactness, and extremely wide bandwidth. Full article

For the future application of wireless power transfer on the human body, a wearable directional button antenna, composed of $2\times 3$ artificial magnetic conductor (AMC) cells, is proposed, where the kinetic energy antenna is put on the elbow, which then charges the receiving communication antenna on the upper arm. The radiator of the button antenna is a monopole antenna, which is top-loaded by two cylindrical substrates with different radii to achieve a low profile, and it is fed by the microstrip line made by textiles, including 100% cotton substrate and conductive textile. The AMC cells are put close to the feeding microstrip line in order to realize directional radiation to the other side. Meanwhile, a real human arm model of a Chinese women is built to accurately analyze the corresponding wave propagations. Consequently, two identical antenna prototypes are fabricated, and the corresponding measurements are implemented, where an on-arm approximate measurement method for the radiation pattern is proposed. The measurements agree well with the simulations. Additionally, the influence of the communication antenna on the kinetic energy antenna and the interactions between the antenna and the arm are analyzed. Finally, the transmission efficiency and the SAR values are investigated. Full article

In this paper, a miniaturized textile microstrip antenna is proposed for wireless body area networks (WBAN). The ultra-wideband (UWB) antenna used a denim substrate to reduce the surface wave losses. The monopole antenna consists of a modified circular radiation patch and an asymmetric defected ground structure, which expands impedance bandwidth (BW) and improves the radiation patterns of the antenna with a small size of 20 × 30 × 1.4 mm³. An impedance BW of 110% (2.85–9.81 GHz) frequency boundaries was observed. Based on the measured results, a peak gain of 3.28 dBi was analyzed at 6 GHz. The SAR values were calculated to observe the radiation effects, and the SAR values obtained from the simulation at 4/6/8 GHz frequencies followed the FCC guideline. Compared to typical wearable miniaturized antennas, the antenna size is reduced by 62.5%. The proposed antenna has good performance and can be integrated on a peaked cap as a wearable antenna for indoor positioning systems. Full article

This manuscript examines the design principle and real-world validation of a new miniaturized high-performance flower-shaped radiator (FSR). The antenna prototype consists of an ultracompact square metallic patch of 0.116λ₀ × 0.116λ₀ (λ₀ is the free space wavelength at 3.67 GHz), a rectangular microstrip feed network, and a partial metal ground plane. A novel, effective, and efficient approach based on open circuit loaded stubs is employed to achieve the antenna’s optimal performance features. Rectangular, triangular, and circular disc stubs were added to the simple structure of the square radiator, and hence, the FSR configuration was formed. The proposed antenna was imprinted on a low-cost F4B laminate with low profile thickness of 0.018λ₀, relative permittivity ε_r = 2.55, and dielectric loss tangent δ = 0.0018. The designed radiator has an overall small size of 0.256λ₀ × 0.354λ₀. The parameter study of multiple variables and their influence on the performance results has been extensively studied. Moreover, the impact of different substrate materials, impedance bandwidths, resonance tuning, and impedance matching has also been analyzed. The proposed antenna model has been designed, simulated, and fabricated. The designed antenna exhibits a wide bandwidth of 5.33 GHz ranging from 3.67 to 9.0 GHz at 10 dB return loss, which resulted in an 83.6% fractional impedance bandwidth; a maximum gain of 7.3 dBi at 8.625 GHz; optimal radiation efficiency of 89% at 4.5 GHz; strong intensity current flow across the radiator; and stable monopole-like far-field radiation patterns. Finally, a comparison between the scientific results and newly published research has been provided. The antenna’s high-performance simulated and measured results are in a good agreement; hence, they make the proposed antenna an excellent choice for modern smartphones’ connectivity with the sub-6 GHz frequency spectrum of modern fifth-generation (5G) mobile communication application. Full article

In this paper, a frequency reconfigurable multiband multiple-input-multiple-output (MIMO) antenna is developed for 5G communication systems. The presented MIMO antenna element consists of a 50 Ω microstrip line, a rectangular monopole divided into two patches, and a partial ground plane. A split-ring resonator (SRR) is introduced into the upper patch to cover multiple 5G application bands, and an RF PIN diode is embedded between the upper and lower patches to enable the frequency diversity feature. In order to design a MIMO antenna with improved inter-element isolation, four antenna elements are orthogonally located with ground planes connected to each other. The antenna design covers the n41/n46/n48/n79 5G application bands. The prototype MIMO antenna is developed on the FR-4 substrate, and the measured results match with the simulated outcomes. The overall footprint of the prototype antenna is 70 × 70 × 1.6 mm³. Full article

In this paper, a high-isolation multiple-input/multiple-output (MIMO) microstrip monopole antenna array is investigated. To reduce the mutual coupling between antenna elements, a novel composite parasitic element constituted by a T-shaped ground branch and an isolated branch was designed and analyzed. The proposed composite parasitic element is capable of generating a unique three-dimensional weak electric field, which can effectively suppress the mutual coupling between the antenna elements. To give an intuitive illustration about the design principle and decoupling strategy of the proposed antenna, the antenna design procedure was ingeniously divided into four steps, and three types of decoupling structures during the antenna evolution were meticulously analyzed at both the theoretical and the physical level. To validate the proposed decoupling concept, the antenna prototype was fabricated, measured, and evaluated. The reflection coefficient, transmission coefficient, radiation pattern, and antenna gain were studied, and remarkable consistency between the measured and simulated results was observed. The simulations showed that the antenna has a peak gain of 3.5 dBi, a low envelope correlation coefficient (ECC < 0.001), and a high radiation efficiency (radiation efficiency > 0.9). Parameters of the proposed MIMO antenna including electrical dimension, highest isolation level, and 20 dB isolation bandwidth were evaluated. Compared with the previous similar designs, the proposed antenna exhibits attractive features including compressed dimension (0.55λ₀ × 0.46λ₀), extremely high isolation level (approximately 43 dB), fabulous 20 dB isolation bandwidth (3.11–3.78 GHz, 19.4%), a high diversity gain (DG > 9.99 dB), an appropriate mean effective gain (−3.5 dB < MEG < −3 dB), and low design complexity. Full article

A quad-element multiple-input-multiple-output (MIMO) antenna with ultra-wideband (UWB) performance is presented in this paper. The MIMO antenna consists of four orthogonally arranged microstrip line-fed hexagonal monopole radiators and a modified ground plane. In addition, E-shaped and G-shaped stubs are added to the radiator to achieve additional resonances at 1.5 GHz and 2.45 GHz. The reliability of the antenna in the automotive environment is investigated, with housing effects taken into account. The housing effects show that the antenna performs consistently even in the presence of a large metal object. The proposed MIMO antenna has potential for various automotive applications, including vehicle-to-vehicle (V2V), vehicle-to-infrastructure (V2I), vehicle-to-everything (V2X), intelligent transport system (ITS), automatic vehicle identifier, and RFID-based electronic toll collection. Full article

This work proposes a compact 3-bit frequency-reconfigurable monopole antenna covering a broad reconfigurable range by inserting a switchable three-line section (STLS). The design starts with a conventional quarter-wavelength monopole line antenna, which is then replaced by a novel structure, the STLS. The STLS is composed of three parallel-connected lines with different lengths. Accordingly, three RF p–i–n diodes are introduced in the STLS to achieve binary reconfiguration. After all parameters of the antenna have been optimized, it will eventually output 2^N = 8 (N is the number of switches) independent working states with different equivalent lengths and a reconfigurable working frequency. The number of states in a binary reconfigurable antenna is optimally large in relation to the number of switches used, which means that it can be extremely convenient for digital control of switching all the states and capable of decreasing the number of RF p–i–n diodes we used, thereby minimizing the manufacturing cost and loss of diodes. A prototype antenna is fabricated and tested, and the measurement results agree well with the simulation results, validating the good features, such as a large reconfigurable switchable frequency range from 0.95 GHz to 2.45 GHz with considerable working bandwidth varying from 40 MHz to 540 MHz for each state, simple structure, and a compact size of 70 × 40 mm², which can be appropriately used for a multi-radio wireless system and handheld devices. All the states have a similar monopole radiation pattern with a good maximum efficiency and an acceptable peak gain according to its compact size. Full article

Direction finding (DF) systems are used to determine the direction-of-arrival (DoA) of electromagnetic waves, thus allowing for the tracking of RF sources. In this paper, we present an alternative formulation of antenna arrays for modeling DF systems. To improve the accuracy of the data provided by the DF systems, the effects of mutual coupling in the array, polarization of the received waves, and impedance mismatches in the RF front-end receiver are all taken into account in the steering vectors of the DoA algorithms. A closed-form expression, which uses scattering parameter data and active-element patterns, is derived to compute the receiver output voltages. Special attention is given to the analysis of wave polarization relative to the DF system orientation. Applying the formulation introduced here, a complete characterization of the received waves is accomplished without the need for system calibration techniques. The validation of the proposed model is carried out by measurements of a 2.2 GHz DF system running a MUSIC algorithm. Tests are performed with a linear array of printed monopoles and with a planar microstrip antenna array having polarization diversity. The experimental results show DoA estimation errors below 6° and correct classification of the polarization of incoming waves, confirming the good performance of the developed formulation. Full article
