High-performance piezoelectric micromachined ultrasonic transducers (PMUTs) are crucial for portable medical imaging and sensing. The efficiency of advanced PMUTs relies on high-quality piezoelectric thin films and optimized device designs. However, variability in common piezoelectric thin films like Sc_xAl_1−xN (ScAlN) and PbZr_1−xTi_xO₃ (PZT) often leads to inaccurate material parameters—especially those derived from thick ceramics. To enhance simulation accuracy in standard designs affected by these inconsistencies, this work introduces an optimization framework combining first-principles calculations with multiphysics simulations. First, the intrinsic properties of PZT and ScAlN are analyzed through atomistic calculations, confirming that PZT, with its higher electromechanical coupling coefficient, is better suited for actuation. The parameters obtained from these calculations calibrate the finite-element model, addressing issues of missing or inaccurate data in commercial software libraries. Next, an efficient analytical acoustic-field model is developed. Compared to full-wave simulations in COMSOL, this model significantly reduces computational cost while maintaining accuracy, allowing for quicker scanning and optimization of large-array topologies. Additionally, results demonstrate that each individual hexagonal PMUT element outperforms a comparable circular element, achieving a peak SPL of 90.4 dB at 4.9 MHz versus 89.7 dB at 2.8 MHz. This higher acoustic output and operating frequency enable improved spatial resolution and sensitivity. This modeling approach, based on intrinsic material properties, provides a solid theoretical foundation for designing high-precision, low-power ultrasonic devices. Full article

This study developed predictive mathematical models for UV laser penetration depth in FR-4-based rigid–flex printed circuit boards, addressing the critical need for precise material removal in applications like protective plug removal. Utilizing a comprehensive Design of Experiments framework, specifically two-level full factorial designs, the influence of key operational parameters—number of loops, scanning speed, and focal position offset—on material removal was systematically investigated in both laminate and multilayer substrates. Empirical models were established for both substrate types, identifying significant factors and interactions that govern penetration depth with physical justification. Comparative analysis revealed that the multilayer model consistently predicted deeper penetration (6–17 µm) than the laminate model under identical conditions, primarily due to reduced heat-associated phenomena with prepreg, yet the laminate model offered a reasonable approximation for complex stack-ups. Rigorous validation through confirmation experiments, achieving 100% success in electrical integrity tests with compliant plug removal, unequivocally demonstrated the models’ robustness and reliability. This research provided a crucial tool for optimizing UV laser micromachining processes, significantly reducing parameter identification times and minimizing scrap generation, thereby enhancing the efficiency and reliability of advanced rigid–flex PCB manufacturing. Full article

A robust and cost-effective fiber-optic ultrasound sensor based on a slope-symmetric Fabry–Perot interferometer (FPI) is presented, employing dual-channel quadrature-biased heterodyne interrogation with an acousto-optic modulator (AOM). By introducing a 200 MHz frequency shift that yields an effective π/2 phase offset between the direct (unshifted) and frequency-shifted optical paths, the system ensures complementary sensitivity: when one channel operates at zero slope on the FPI transfer function (minimum sensitivity), the other resides at maximum slope, providing inherent immunity to laser wavelength drift and environmental perturbations. Experimental validation demonstrates reliable ultrasound detection across varying operating points. At quadrature extremes, one channel achieves peak amplitudes of ±2 V while the other is quiescent, whereas intermediate points enable simultaneous detection with amplitudes of ±1.5 V (AOM channel) and ±0.05–0.1 V (direct channel), accompanied by corresponding DC levels ranging from ~0.4 V to 1.6 V. The AOM channel utilizes simple envelope detection after 9.5–11.5 MHz bandpass filtering, maintaining low cost, though coherent mixing is suggested for enhanced weak-signal performance. The angle-symmetric FPI design, combined with gold-disk reflector adaptations and potential femtosecond laser micromachining, further reduces fabrication costs without sacrificing finesse or sensitivity. This quadrature-biased approach offers superior stability compared to single-channel systems, making it highly suitable for practical applications in photoacoustic imaging, nondestructive testing, and structural health monitoring. Full article

Electrochemical discharge machining (ECDM) with low machining reaction forces is useful for machining hard and brittle materials, which are required in precision equipment. Lathe-type ECD machines have been proposed to machine axisymmetric shapes while reducing cracks caused by thermal expansion, and they are suitable for thin workpiece machining due to the small reaction force. This paper demonstrates the micromachining of non-circular cross-sections using a lathe-type ECD machine equipped with an improved force-controlled tool electrode holder. The tool electrode holder combining a voice coil motor (VCM) with leaf springs arranged in parallel was built. This holder achieves both flexibility in the longitudinal direction of the tool electrode and high rigidity in the lateral direction. The relationship between the VCM current, tool electrode shift within the tool electrode holder, and thrust force was approximated using a polynomial. Consequently, this device allows for the stable, small contact force required in micromachining. An on-machine shape measurement method was also carried out by combining the tool electrode shift with the motion of an XZ stage. As a demonstration for non-circular cross-section machining, a square cross-section was grooved from a cylindrical glass rod. The removal and measurement processes were alternately repeated to achieve precision. During ECDM, the on/off of the DC power supply for ECDM was synchronized with the rotation of the workpiece. The measurement results indicated some dimensional errors, including bulging at the middle of sides and excessive removal at corners. The bulging was mainly caused by drift due to thermal expansion of the stage, as well as tool electrode wear. Since the tool electrode comes into close proximity to with the machined surface, the discharge from the side surface of the tool electrode caused excessive removal at the corners. Full article

Capacitive micromachined ultrasonic transducers (CMUTs) are a promising alternative to conventional piezoelectric transducers, offering superior design flexibility and broadband operational characteristics. However, their clinical and practical deployment is constrained by elevated driving voltages and limited acoustic power output, particularly when producing CMUTs based on polymers. This paper presents an end-to-end, measurement-driven experimental validation strategy for designing passive broadband impedance-matching networks that enhance transmitted acoustic power in immersed CMUT arrays while preserving bandwidth. Matching topologies are synthesized to operate near the theoretical Bode–Fano limit, and robustness to component tolerances is quantified through Monte Carlo yield analysis using realistic off-the-shelf component variations. The matching networks are then implemented and experimentally validated under representative unipolar pulse excitation, with far-field acoustic pressure characterized in both time and frequency domains and compared against numerical predictions. The results show that the optimized impedance matching increases transmit power by a factor of 2.1 at the cost of a 40% fractional-bandwidth reduction. These findings establish a directly applicable, validated framework for broadband impedance matching in polymer CMUT arrays and support its use as a cost-effective approach for ultrasound imaging and therapeutic systems. Full article

Laser-based manufacturing processes—including marking, hardening, cutting, and welding—demand the precise selection of processing parameters, as the resulting surface state is critically dependent on the delivered power density and beam–material interaction time. This study presents a unified predictive framework for estimating the critical surface power density thresholds for melting q_scm and evaporation q_scv as functions of scanning speed v for the following four technologically important metallic materials: titanium, C26000 brass, SS304 stainless steel, and 42CrMo4 alloy steel. The principal novelty of this work is twofold. First, it provides the first directly comparative analysis of these four materials under identical, standardized laser conditions (λ = 1064 nm, d = 40 μm, constant absorptivity A = 0.4), eliminating the confounding effects of variable beam geometries and optical assumptions that hinder cross-study comparisons. Second, it translates fundamental thermophysical principles into a practical engineering tool, such as a validated spreadsheet calculator that outputs material-specific threshold curves in real time, enabling rapid, physics-based parameter estimation without recourse to complex numerical simulations. The computed threshold curves exhibit a consistent non-linear increase with scanning speed for all materials, governed by the inverse relationship between interaction time and required power density. The following clear material hierarchy emerges: C26000 brass exhibits the highest thresholds (e.g., q_scm = 0.94 × 10¹⁰ W/m², q_scv = 10.74 × 10¹⁰ W/m² at v = 100 mm/s) due to its high thermal conductivity, while titanium shows the lowest (q_scm = 0.19 × 10¹⁰ W/m², q_scv = 0.48 × 10¹⁰ W/m² at v = 100 mm/s) as a consequence of strong heat confinement. SS304 and 42CrMo4 occupy intermediate positions, with 42CrMo4 demonstrating notably higher evaporation resistance than SS304 despite similar melting thresholds. The resulting dual-threshold framework delineates three distinct process regimes—sub-melting heating, melting-dominant processing, and evaporation—providing a quantitative basis for parameter selection in applications ranging from surface hardening to micromachining. By bridging the gap between theoretical material science and applied manufacturing, this work offers a robust, first-order reference for process design and establishes a methodological template for future comparative studies of laser–material interactions. Full article

This paper presents the design, fabrication, and experimental characterization of a novel terahertz receiver comprising two high-performance receiving antennas and a combiner. The low efficiency of local oscillator (LO) power utilization, caused by conventional beam splitters, presents a major bottleneck for large-array terahertz receivers. By eliminating the conventional beam splitter, the proposed system allows the terahertz signal and LO power to be directly and independently received by two dedicated antennas, thereby significantly enhancing LO power efficiency. The receiver is successfully fabricated using micromachining technology into a compact 2.5-dimensional multilayered structure measuring 9 mm × 16 mm × 7.2 mm. Key performance metrics, including the waveguide port S-parameters, radiation patterns, and gains of the two horn antennas, were measured. The experimental results show close agreement with simulations, validating the system’s accuracy and reliability. Furthermore, the system’s equivalent noise temperature was measured to be 395 K, indicating excellent thermal stability and sensitivity. This study concludes that the proposed terahertz receiver design is both feasible and efficient for high-resolution applications, showing great potential for use in satellite-based space observation systems or base stations requiring advanced terahertz signal processing. Full article

To mitigate acoustic beam drift, which degrades the signal-to-noise ratio (SNR) and limits the measurement range in ultrasonic gas flowmeters (USFMs), we present a miniaturized transit-time USFM that integrates a single piezoelectric micromachined ultrasonic transducer (PMUT) with a non-axisymmetric conical cavity. This design increases acoustic transmission gain and produces anisotropic directivity across orthogonal radiation planes, thereby broadening acoustic coverage along the flow direction and reducing beam steering. With an optimized cavity angle combination of (50°, 70°), the system achieves a 7.4 dB transmission gain and a half-power beamwidth (HPBW) of 29.1°. Experimental validation demonstrates a sound pressure attenuation of only 0.72 dB at 18.74 m/s. Within the 0.06–12 m³/h flow range, the USFM exhibits indication errors of ±2% (<1 m³/h) and ±1.5% (≥1 m³/h), with repeatability below 0.5%. The performance meets the Class 1.5 accuracy standard specified in CJ/T 477-2015, offering an innovative solution for wide-range miniaturized gas flow measurement. Full article

Variable reluctance sensors are widely adopted for robust and contactless detection of motion in harsh and space-constrained environments. This paper presents a MEMS-based variable reluctance induction sensor for the noncontact characterization of rotating ferromagnetic targets, based on a micromachined planar micro-coil coupled with an external permanent magnet. The rotation of a ferromagnetic object modulates the magnetic circuit reluctance, generating a voltage signal across the micro-coil that encodes information on the target rotational speed, proximity, and cross-sectional shape. Sensor operation is investigated through a lumped-element magnetic–electrical circuit model and finite-element magnetostatic simulations, quantifying the effects of target diameter, distance, and angular position on the linked magnetic flux. Experimental validation is performed using rotating drill bits as representative targets and a dedicated high-gain, high-input-impedance front-end circuit to amplify the induced voltage. Measured results at fixed rotation frequency show periodic voltage waveforms whose amplitude and shape vary consistently with target geometry, proximity and speed. Reliable detection is achieved for rotational speeds up to 1500 rpm, for drill bit diameters as small as 5 mm, and at sensor-to-target distances up to 8 mm. These results demonstrate the potential of MEMS variable reluctance induction sensors for compact speed sensing and target shape detection. Full article

Air-shielding radial ultrasonic rolling electrochemical micromachining (AS-RUREMM) is proposed to fabricate high-quality micro-dimple textures on cylindrical SS304 surfaces while suppressing stray corrosion. In AS-RUREMM, an annular air sheath coaxially envelopes the electrolyte jet to confine the wetting footprint, and radial ultrasonic vibration is superimposed on a rolling cathode with micro-protrusions to intensify local mass transport and stabilize the interelectrode environment. A conductivity-centered theoretical framework is established to link air-sheathing-induced gas–liquid distribution, ultrasonic gap modulation, and the resulting current-density localization. Multiphysics simulations in COMSOL 5.3 clarify that moderate air pressure forms a stable confined gas–liquid structure that narrows the effective conductive pathway, whereas excessive air pressure increases intermittency and weakens effective gap conductivity. Experiments on SS304 tubes validate the confinement mechanism: compared with RUREMM, AS-RUREMM produces smaller pit width and depth but a higher depth-to-width ratio, indicating enhanced localization and reduced peripheral over-etching. The simulated cross-sectional profiles agree with measurements, with an overall deviation within 6%. Parameter studies identify an optimal operating window, and the combination of 0.18 MPa air pressure and 12 V pulse voltage provides the highest aspect ratio while maintaining stable machining. SEM/EDX analyses further support the improved process controllability under air shielding through reduced stray corrosion and composition changes consistent with a more regulated electrochemical dissolution environment. Full article

Micromachines, MEMS and actuators suffer from much more significant relative friction and wear issues than their equivalent macroscopic devices. Active magnetic bearings can be a good option to mitigate friction issues; however, their construction at microscale is still an open research topic. In this work, we have developed a micrometric-size active magnetic bearing with a simple configuration and one vertical degree of freedom. This active magnetic microbearing is composed of a coreless coil with 1 mm outer diameter, 0.3 mm inner diameter and 0.5 mm length that holds a 0.3 mm outer diameter, 0.5 mm length NdFeB N52 micromagnet. Stable magnetic levitation is achieved by regulating the coil current based on precise position measurements of the magnet obtained using the smallest commercially available Hall-effect microsensor. The microprobe integrates between the coil and magnet, reducing the total size of the device. A maximum axial load capacity of 1.16 mN/A has been demonstrated. This micromagnetic bearing is one of the smallest active magnetic bearings developed to date, demonstrating the viability of this kind of system at the micrometric scale. Full article

The technology development for the mass ceramic gas flow sensor (CGFS) adopted for harsh operating conditions is presented. The main characteristic of this technology is its simplicity and affordability for mass fast prototyping of CGFS with a limited set of technological equipment. Special attention is paid to the discussion of the technological and operational materials’ compatibility, flexibility, and speed of their processing to adapt the best mass flow sensor design option. The CGFS, designed and manufactured in just a few days, was tested in conditions close to the real ones and demonstrated the ability to measure gas flow in the range from 0.21 m/s to 1.25 m/s, with a constant power consumption of 152 mW@346 °C. Full article

We report a dispersion-controlled Yb-doped fiber chirped pulse amplification (CPA) system incorporating a tunable chirped fiber Bragg grating (CFBG) stretcher and a single-grating transmission compressor for dynamic compensation of power-dependent nonlinear effect. During the pulse amplification, the CFBG introduces adjustable third-order dispersion (TOD). By tuning the initial TOD provided by CFBG from −0.1965 ps³ at 2.37 W to −0.1791 ps³ at 9.65 W, residual TOD is efficiently compensated with the power-dependent nonlinear effect. As a result, by optimizing the dispersion balance at each output power, nearly constant femtosecond pulses with a duration of 250 fs are obtained over the entire power range, confirming effective control of nonlinear and dispersive effects in the amplification. The high-quality 1030 nm pulses enable efficient second-harmonic generation (SHG) in a type-I BBO crystal, producing 3.56 W femtosecond output at around 515 nm with a pulse duration of 190 fs, close to the Fourier transform limit. These results demonstrate a robust approach to generating high-power and temporal coherent ultrafast pulses suitable for precision micromachining and two-photon polymerization. Full article

This work presents, to the best of our knowledge, the first experimental report of an erbium/ytterbium double-clad ring fiber laser based on nonlinear polarization rotation (NPR) operating in a self-starting Q-switched high-order harmonic mode locking noise-like pulse (QHML-NLP) regime. The NPR mechanism relies on an arrangement composed of a beam splitter cube, a half-wave retarder, and a quarter-wave retarder. Through specific adjustments of the wave retarders and pump power, the laser cavity engages the QHML-NLP regime, where mode-locked burst-like pulses containing a significant number of NLPs are modulated by a giant Q-switched envelope. The laser system emits at the 132nd-order harmonic mode locking (HML) frequency, representing the highest order achieved to date in the framework of QHML-NLP. Additional features include a broadband optical spectrum with dual-wavelength emission at 1568.4 nm and 1605.9 nm, and maximum energies of 2.37 µJ for the Q-switched envelope and 200 nJ for the mode-locked burst-like pulse. These detailed experimental results reveal remarkable aspects in the NLP dynamics, contributing to a deeper understanding of their physical mechanisms and highlighting their potential as novel laser sources for micromachining and nonlinear optics. Full article
