Search Results (108)

The electroosmotic flow (EOF) of non-Newtonian fluids plays a significant role in microfluidic systems. The EOF of Powell–Eyring fluid within a parallel-plate microchannel, under the influence of both electric field and pressure gradient, is investigated. Navier’s boundary condition is adopted. The velocity distribution’s approximate solution is derived via the homotopy perturbation technique (HPM). Optimized initial guesses enable accurate second-order approximations, dramatically lowering computational complexity. The numerical solution is acquired via the modified spectral local linearization method (SLLM), exhibiting both high accuracy and computational efficiency. Visualizations reveal how the pressure gradient/electric field, the electric double layer (EDL) width, and slip length affect velocity. The ratio of pressure gradient to electric field exhibits a nonlinear modulating effect on the velocity. The EDL is a nanoscale charge layer at solid–liquid interfaces. A thinner EDL thickness diminishes the slip flow phenomenon. The shear-thinning characteristics of the Powell–Eyring fluid are particularly pronounced in the central region under high pressure gradients and in the boundary layer region when wall slip is present. These findings establish a theoretical base for the development of microfluidic devices and the improvement of pharmaceutical carrier strategies. Full article

Belle II is a particle physics experiment working at an high luminosity collider within a hard irradiation environment. The Time-Of-Propagation detector, aimed at the charged particle identification, surrounds the Belle II tracking detector on the barrel part. This detector is composed by 16 modules, each module contains a finely fused silica bar, coupled to microchannel plate photomultiplier tube (MCP-PMT) photo-detectors and readout by high-speed electronics. The MCP-PMT lifetime at the nominal collider luminosity is about one year, this is due to the high photon background degrading the quantum efficiency of the photocathode. An alternative to these MCP-PMTs is multi-pixel photon counters (MPPC), known as silicon photomultipliers (SiPM). The SiPMs, in comparison to MCP-PMTs, have a lower cost, higher photon detection efficiency and are unaffected by the presence of a magnetic field, but also have a higher dark count rate that rapidly increases with the integrated neutron flux. The dark count rate can be mitigated by annealing the damaged devices and/or operating them at low temperatures. We tested SiPMs, with different dimensions and pixel sizes from different producers, to study their time resolution (the main constraint that has to satisfy the photon detector) and to understand their behavior and tolerance to radiation. For these studies we irradiated the devices to radiation up to $5\times {10}^{11}1$ MeV neutrons equivalent (neq) per cm² fluences; we also started studying the effect of annealing on dark count rates. We performed several measurements on these devices, on top of the dark count rate, at different conditions in terms of overvoltage and temperatures. These measurements are: IV-curves, amplitude spectra, time resolution. For the last two measurements we illuminated the devices with a picosecond pulsed laser at very low intensities (with a number of detected photons up to about twenty). We present results mainly on two types of SiPMs. A new SiPM prototype developed in collaboration with FBK with the aim of improving radiation hardness, is expected to be delivered in September 2025. Full article

A conventional microchannel plate framing camera is typically utilized for inertial confinement fusion diagnosis. However, as a vacuum electronic device, it has inherent limitations, such as a complex structure and the inability to achieve single-line-of-sight imaging. To address these challenges, a CMOS image sensor that can be seamlessly integrated with an electronic pulse broadening system can provide a viable alternative to the microchannel plate detector. This paper introduces the design of an 8 × 8 pixel-array ultrashort shutter-time single-framing CMOS image sensor, which leverages silicon epitaxial processing and a 0.18 μm standard CMOS process. The focus of this study is on the photodiode and the readout pixel-array circuit. The photodiode, designed using the silicon epitaxial process, achieves a quantum efficiency exceeding 30% in the visible light band at a bias voltage of 1.8 V, with a temporal resolution greater than 200 ps for visible light. The readout pixel-array circuit, which is based on the 0.18 μm standard CMOS process, incorporates 5T structure pixel units, voltage-controlled delayers, clock trees, and row-column decoding and scanning circuits. Simulations of the pixel circuit demonstrate an optimal temporal resolution of 60 ps. Under the shutter condition with the best temporal resolution, the maximum output swing of the pixel circuit is 448 mV, and the output noise is 77.47 μV, resulting in a dynamic range of 75.2 dB for the pixel circuit; the small-signal responsivity is 1.93 × 10⁻⁷ V/e⁻, and the full-well capacity is 2.3 Me⁻. The maximum power consumption of the 8 × 8 pixel-array and its control circuits is 0.35 mW. Considering both the photodiode and the pixel circuit, the proposed CMOS image sensor achieves a temporal resolution better than 209 ps. Full article

Capture efficiency (CE) is a critical performance parameter for microchannel plates (MCPs), yet its accurate measurement remains challenging. In this study, we propose an innovative method for evaluating the CE of newly fabricated MCPs based on the detection of a photoelectron beam generated by UV light irradiation of a zinc plate. When incident photoelectrons are detected by the MCPs, they produce a series of disordered pulse signals. We demonstrate that the average pulse interval (denoted as Ts) correlates with the number of electrons entering the microchannels, enabling the assessment of CE differences among various MCPs under identical experimental conditions. Additionally, by partially blocking the incident surface to modulate the active area of the MCP, we established a relationship between Ts and active area, providing a means to roughly quantify CE. This method offers a straightforward alternative for assessing MCP performance, with reduced platform requirements and operational complexity. Full article

While extensive research has focused on improving the efficiency and performance of heat exchangers (HXs), identifying the underlying causes of performance degradation remains equally important. Flow and temperature non-uniformities are among the most critical factors affecting performance, often reducing thermo-hydraulic efficiency by approximately 5–10%. These non-uniformities commonly manifest as thermal inconsistencies, airflow maldistribution, and uneven refrigerant distribution. Researchers have observed a notable performance degradation—up to 27%—due to flow maldistribution. Therefore, a clear understanding of their causes and effects is essential for developing effective mitigation strategies to enhance system performance. Despite the notable progress in this area, few studies have systematically classified the dominant non-uniformities associated with specific HX types. This article presents a two-decade review of the causes, impacts, and mitigation approaches related to non-uniformities across different HX configurations. The primary objective is to identify the most critical form of non-uniformity affecting performance in each category. This review specifically examines plate heat exchangers (PHXs), finned and tube heat exchangers (FTHXs), microchannel heat exchangers (MCHXs), and printed circuit heat exchangers (PCHXs). It also discusses mathematical models designed to account for non-uniformities in HXs. This article concludes by identifying key research gaps and outlining future directions to support the development of more reliable and energy-efficient HXs. Full article

Air-cooled proton exchange membrane fuel cells (PEMFCs) offer advantages such as light weight, compact size, and simple structure, and have been widely used in fields such as portable electronics, drones, and new energy electric vehicles. However, due to the influence of air convective cooling efficiency, air-cooled PEMFC can only operate at low power to avoid overheating. To improve the air-cooling efficiency and the maximum output power of PEMFCs, a new enhanced cooling structure has been proposed, which adds secondary micro-channels on the surface of the original bipolar plate flow channels. Thermal simulation analysis was conducted for flow channels with and without an array of micro-channels on the surface. Through orthogonal simulation experiments, the optimal geometric parameters for the secondary micro-channels were determined. The simulation results show that for flow channels with optimized secondary micro-channels, the maximum temperature at the center plane of the MEA is reduced by approximately 10 °C, the thermal resistance of heat transfer in the channel decreases by about 21.2%, and the experimental results on heat transfer in the channel indicate that the maximum heat flux density increases by approximately 22.5%. Finally, performance tests were conducted on air-cooled PEMFC stacks with and without enhanced cooling secondary micro-channels. The test results show that the fuel cell stack with enhanced cooling secondary micro-channels exhibits a temperature reduction of approximately 14 °C at a current density of 0.5 A/cm², a maximum output power increase of about 27%, and improved voltage uniformity across individual cells, demonstrating the effectiveness of the enhanced cooling secondary micro-channel structure. Full article

Microchannel liquid-cooled plates are widely used in high-performance electronic devices, but their heat transfer performance and pressure drop characteristics face complex challenges in the design process. In this paper, a counter-flow rectangular microchannel liquid-cooled plate is designed, and the effects of velocity, aspect ratio, and inlet/outlet forms on its heat transfer and pressure drop performance are investigated through orthogonal tests and numerical simulations. The results indicate that the velocity plays a crucial role in determining the plate’s performance. While increasing the velocity substantially enhances heat transfer efficiency, it also causes a steep rise in pressure drop. The aspect ratio has a lesser effect on the performance than the velocity, and smaller aspect ratios help to achieve a balance between thermal and flow properties. The comprehensive optimization of the inlet and outlet forms and velocity has a significant effect on the temperature uniformity and pressure drop, and the design of the cooling fluid inlet and outlet form of CM (side inlet and middle outlet) can effectively improve the temperature distribution and reduce the pressure drop at high velocity. The design parameters with the best overall performance are the aspect ratio of 2, the velocity of 0.5 m/s, and the CM inlet/outlet form (K2V0.5CM). Comparison with other design parameter sets verified that this parameter set showed significant advantages in cooling effect, temperature uniformity, flow and heat transfer performance. Finally, the correlation equation on Nu is established, and the simulated Nu as well as the calculated Nu are compared. In this thesis, a counter-flow rectangular microchannel cold plate is designed to optimize the flow rate, channel structure and other parameters through orthogonal tests to reduce the temperature gradient and balance the heat transfer and flow resistance to meet the demand for efficient heat dissipation of 350 W CPU. This study provides an important reference for the structural optimization of microchannel liquid-cooled panels and the engineering application of high-efficiency heat dissipation systems. Full article

Pixellated scintillation detectors have the potential to overcome several limitations of conventional microchannel-plate-based detectors employed in time-of-flight mass spectrometry (ToF-MS), such as extending detector lifetime, reducing vacuum requirements, or increasing the ion throughput. We have developed a prototype comprising a fast organic scintillator (Exalite 404) coupled to an array of 16 silicon photomultipliers (SiPMs), with read-out electronics based on the FastIC application-specific integrated circuit (ASIC). Each SiPM signal processed by FastIC is fed into its own time-to-digital converter (TDC). The dead time of a single channel can be as short as ∼20 ns. As a result, our system have the potential to process ion rates above ${10}^9$ cm⁻² s⁻¹. We have evaluated the performance of our prototype using a velocity-map imaging ToF-MS instrument, recording the time-of-flight mass spectra of C₃H₆ and CF₃I samples. We achieved time resolutions of ($3.3\pm 0.1$) and ($2.5\pm 0.2$) ns FWHM for ions of mass-to-charge ratio ($m/z$) values of 196 and 18, respectively. This corresponds to a mass resolution of ∼1000 for $m/z<200$, which we found to be dominated by the spread in ion arrival times. Full article

The microchannel plate (MCP) is susceptible to the adsorption of substantial amounts of gas during its fabrication process. To mitigate this, a uniform electron source is essential for effective electron scrubbing and gas removal. Thermionic emission, a method of electron generation, can be employed to create the electron source. In this study, a flat spiral filament was designed and simulated using the CST Studio Suite electron simulation software to assess the cleaning performance of the electron gun. The impact of variations in electron gun parameters on the uniformity of the electron beam and current density was systematically analysed. The simulation results show that, with filament, grid, focusing sleeve, and anode voltages set to 200 V, 500 V, 250 V, and 300 V, respectively, a uniform electron beam with a diameter exceeding 30 mm can be achieved. In order to obtain the current density (5~50 nA/mm²) required for the MCP, the temperature of the filament should be 1800–2000 K through theoretical calculation. These findings offer valuable insights for designing a more efficient electron gun for MCP scrubbing. Full article

The metal bipolar plate is a critical component of the hydrogen fuel cell stack used in proton exchange membrane fuel cells. Bipolar plates must have high accuracy micro-channels with a high aspect ratio (AR) between the channel depth and the half periodic width to achieve optimal cell performance. Conventional forming methods, such as micro-stamping, hydroforming, and rubber pad forming, cannot achieve these high ARs given that in these processes, material deformation is dominated by stretch deformation. In micro-roll forming the major deformation mode is bending, and this enables production of channels with higher ARs than is currently possible. However, micro-roll forming uses multiple sets of forming roll stands to form the part and this leads to technological challenges related to tool alignment and roll tool precision that must be overcome before widespread application can be achieved. This study presents a new methodology to achieve tight tool tolerances when producing micro-roll tooling by utilizing wire-EDM and micro-turning techniques. This is combined with a new micro-roll former design that enables high-precision tool alignment across multiple roll stations. Proof of concept is provided through micro-roll forming trials performed on ultra-thin titanium sheets that show that the proposed technology can achieve tight dimensional tolerances in the sub-millimeter scale that suits bipolar plate applications. Full article

To meet the application requirements of neutron detectors, a novel large-area microchannel plate photomultiplier tube with a gate function (G-MCP-PMT) was developed in this study. A kind of regular hexagonal mesh electrode as the gated electrode was designed to achieve excellent gating functions for target pulse signals. The photoelectron transmittances for different mesh electrode sizes and voltages were studied via numerical simulations. To increase the effective detection area of the photocathode, an electrostatic-focusing electrode was designed in the G-MCP-PMT. By optimizing the structure of the focusing electrode, an effective photocathode detection surface diameter of 80 mm was achieved based on commercially available MCPs with a diameter of 56 mm. By adjusting the channel diameter configurations of the dual MCPs, the output pulse peak and time response of the large-area G-MCP-PMT can be flexibly adjusted. The experimental results indicate that when the large-area G-MCP-PMT is operated at −2700 V, the gate establishment time is approximately 50 ns. The extinction ratio of the large-area G-MCP-PMT is higher than 3000:1, and the maximum linear output current is greater than 300 mA at 250 ns FWHM, meeting application needs in various fields such as white neutron detection and laser radar. Full article

This study proposes a platinum catalytic plate burner with a clover-shaped microchannel design to reduce the maximum temperature difference (ΔT_max) and improve long-term hydrogen production (HP) performance in an autothermal methanol steam reforming (ATMSR) microreactor. The burner integrates with a plate reformer within a cylindrical adiabatic container. By optimizing catalyst arrangement and incorporating a parallel clover-type microchannel design, thermal gradients inside the burner are minimized, enabling better operation conditions for the plate reformer. Three Pt catalyst gradients (50/50, 40/60, and 30/70) reduce ΔT_max from 48.2 °C and 38.3 °C to 25.8 °C. Additionally, the startup time to 250 °C is reduced from 35, 25, and 14 min, respectively. The integration of the plate burner and reformer with the 30/70 catalyst type shows a higher methanol conversion rate (98%), better hydrogen yield, and lower CO selectivity compared to the 50/50 type. Long-term testing for 30 h shows a low catalyst degradation rate, making it suitable for sustained operation. Full article

A new pulse-dilated photomultiplier tube (PD-PMT) with sub-20 ps temporal resolution and associated drivers have been developed for use detection and signal amplification in the inertial confinement fusion (ICF) community. The PD-PMT is coupled to a transmission line output in order to provide a continuous time history of the input signal. Electron pulse dilation provides high-speed detection capabilities by converting incoming signals into a free-electron cloud and manipulating the electron signal with electric and magnetic fields. This velocity dispersion is translated into temporal separation after the electrons transit into a drift space. The free electrons are then detected by using conventional time-resolved methods and the effective temporal resolution is improved about 12 times. In order to accurately obtain the actual device input signal, we experimentally investigated the relationship between microchannel plate (MCP) gain and electron energy during the first collision. We report the measurements with the PD-PMT, and the error source of the amplitude of the compressed signal is analyzed, which provides a reference for subsequent accurate construction. Full article

Timing and/or position-sensitive MCP detectors, which detect secondary electrons (SEs) emitted from a conversion foil during ion passage, are widely utilized in nuclear physics and nuclear astrophysics experiments. This review covers high-performance timing and/or position-sensitive MCP detectors that use SE emission for mass measurements of exotic nuclei at nuclear physics facilities, along with their applications in new measurement schemes. The design, principles, performance, and applications of these detectors with different arrangements of electromagnetic fields are summarized. To achieve high precision and accuracy in mass measurements of exotic nuclei using time-of-flight (TOF) and/or position (imaging) measurement methods, such as high-resolution beam-line magnetic-rigidity time-of-flight (B$\rho$-TOF) and in-ring isochronous mass spectrometry (IMS), foil-MCP detectors with high position and timing resolution have been introduced and simulated. Beyond TOF mass measurements, these new detector systems are also described for use in heavy ion beam trajectory monitoring and momentum measurements for both beam-line and in-ring applications. Additionally, the use of position-sensitive timing foil-MCP detectors for Penning trap mass spectrometers and multi-reflection time-of-flight (MR-TOF) mass spectrometers is proposed and discussed to improve efficiency and enhance precision. Full article

Angle-resolved photoelectron spectrometers with microchannel plate detectors and fast digitizer electronics are versatile and powerful devices for providing non-invasive single-shot photon diagnostics at a MHz repetition rate X-ray free-electron lasers. In this contribution, we demonstrate and characterize the performance of our two operational photoelectron spectrometers for the application of hard X-rays and soft X-rays as well as new automation tools and online data analysis that enable continuous support for machine operators and instrument scientists. Customized software has been developed for the real-time monitoring of photon beam polarization and spectral distribution both in single-color and two-color operation. Hard X-ray operation imposes specific design challenges due to poor photoionization cross-sections and very high photoelectron velocities. Furthermore, recent advancements in machine learning enable resolution enhancement by training the photoelectron spectrometer together with an invasive high-resolution spectrometer, which generates a response function model. Full article
