This study presents a methodology for developing and validating digital models of tooth-inlay systems, aiming to trace the complete workflow from clinical procedures to simulation by involving dental professionals—dentists for manual cavity preparation and dental technicians for restoration modelling—while integrating micro-computed tomography (micro-CT) imaging with finite element analysis (FEA). The proposed workflow includes (1) the acquisition of high-resolution 3D micro-CT scans of a non-restored tooth, (2) image segmentation and reconstruction to create anatomically accurate digital twins and mesh generation, (3) the selection of proper resin and the 3D printing of four typodonts, (4) the manual preparation of cavities on the typodonts, (5) the acquisition of high-resolution 3D micro-CT scans of the typodonts, (6) mesh generation, digital inlay and onlay modelling and material property assignment, and (7) nonlinear FEA simulations under representative masticatory loading. The approach enables the visualisation of stress and deformation patterns, with preliminary results indicating stress concentrations at the tooth-restoration interface integrating different cavity alternatives and restorations on the same tooth. Quantitative outputs include von Mises stress, strain energy density, and displacement distribution. This study demonstrates the feasibility of using image-based, tooth-specific digital twins for biomechanical modelling in dentistry. The developed framework lays the groundwork for future investigations into the optimisation of restoration design and material selection in clinical applications. Full article

In this paper, a Wiener filtering algorithm in the wavelet domain is proposed to filter the laser self-mixing interference (SMI) signals, which is used to improve the accuracy of displacement reconstruction. The Wiener filter is theoretically constructed and applied to filter both high-frequency coefficients and low-frequency coefficients in the wavelet domain, which are obtained by two-level discrete wavelet transformation (DWT) decomposition from unfiltered SMI signals. Two-level wavelet decomposition in wavelet threshold filtering is determined without any manual judgment. Subsequently, the inverse DWT is employed to generate the filtered SMI signals. Compared with that, using wavelet threshold denoising, the results of the simulation and experiments demonstrate that the displacement reconstruction from the filtered SMI signals exhibits better accuracy when using Wiener filtering in the wavelet domain with two levels of wavelet decomposition. Also, the fake peaks due to local oscillation caused by wavelet threshold filtering can be eliminated effectively. The proposed method employs two-level wavelet decomposition, ensuring computational efficiency and achieving an 11.3% improvement in displacement reconstruction accuracy compared to wavelet threshold filtering. The maximum error ratio of the micro-displacement reconstruction is reduced to 2.7% using the Wiener filter in the wavelet domain. Full article

Water surface micro-amplitude waves (WSMWs) of identical frequency are elicited as acoustic waves propagating through water. This displacement can be translated into an intermediate frequency (IF) phase shift through transmitting a frequency modulated continuous wave (FMCW) towards the water surface by a millimeter-wave radar, and information transmission across the water–air interface is achieved via the signal reconstruction method. In this paper, a novel mathematical model based on energy conversion from underwater acoustic to vibration (ECUAV) is presented. This method was able to obtain WSMW vibration information directly by measuring the sound source level (SL). An acoustic electromagnetic wave-based information transmission (AEIT) system was integrated within the water tank environment. The measured distribution of SL within the frequency range of 100 Hz to 300 Hz exhibited the same amplitude variation trend as predicted by the ECUAV model. Thus, the WSMW formation process at 135 Hz was simulated, and the phase information was extracted. The initial vibration information was retrieved through a combination of phase unwinding and Butterworth digital filtering. Fourier transform was applied to the vibrational data to accurately reproduce the acoustic frequency of underwater nodes. Finally, the dual-band binary frequency shift keying (BFSK) modulated underwater encoding acoustic signal was effectively recognized and reconstructed by the AEIT system. Full article

To enhance the accuracy of micro-Newton thrust measurements via a torsion pendulum, addressing microgravity coupling effects caused by platform tilt and pendulum mass eccentricity is crucial. This study focuses on analyzing and minimizing these effects by alleviating reference surface tilt and calibrating the center of mass during thrust measurements. The study introduced analysis techniques and compensation measures. It first examined the impact of reference tilt and center of mass eccentricity on the stiffness and compliance of the torsion pendulum by reconstructing its dynamic model. Simscape Multibody was initially employed for numerical analysis to assess the dynamic coupling effects of the tilted pendulum. The results showed the influence of reference tilt on the stiffness and compliance of the torsion pendulum through simulation. An inverted pendulum was developed to amplify the platform’s tilt angle for microgravity drag-free control. Center of mass calibration can identify the gravity coupling caused by the center of mass position. Based on the displacement signal from the capacitive sensor located at the end of the inverted pendulum, which represents the platform’s tilt angle, the pendulum’s vibration at 0.1 mHz was reduced from 5.7 $\mathsf{\mu }$m/Hz^1/2 to 0.28 $\mathsf{\mu }$m/Hz^1/2 by adjusting the voltage of piezoelectric actuator. Finally, a new two-stage torsion pendulum structure was proposed to decouple the tilt coupling buried in both pitch and roll angle. The study utilized theoretical models, numerical analysis, and experimental testing to validate the analysis methods and compensation measures for microgravity coupling effects in torsion pendulums. This led to a reduction in low-frequency noise caused by ground vibrations and thermal strains, ultimately improving the micro-Newton thrust measurement accuracy of the torsion pendulum through the platform’s drag-free control. Full article

Introduction: Three tiny bones compose the human ossicular chain: malleus, incus and stapes. Also known as auditory ossicles, they are united by joints in the middle ear cavity of the petrous part of the temporal bone. Completely developed two years after birth, the ossicular chain is involved in the physiological process of hearing, by which sound waves from the environment are converted into electrochemical impulses. In the last 500 years, most studies have focused on the morphogenesis, morphological variability and clinical pathology of the ossicular chain, whilst only a few studies have added relevant knowledge to anthropology and forensic science. The auditory ossicles and the enclosing petrous bone are some of the hardest in the human skeleton. This is reflected in a relative resistance to fire and in the possibility of preservation and fossilization in millions of years. Materials and Methods: The literature and four present-day forensic cases were included in studying the postmortem loss of the auditory ossicles in skeletal or decomposing remains. Results indicate that it can be ascribed to their destruction or physical displacement, by either macro-micro-faunal action and/or any other natural or artificial disturbance. Discussion: Physical displacement is closely connected to the depositional environment of the skeletal remains, such as burial, entombment (sarcophagus, coffin, vault…), submersion or exposure to natural elements. Auditory ossicles can be recovered in situ, or very close to their anatomical location, when the skeletal material has been involved in an archaeological excavation. In the case of accessible or disturbed remains, scavengers may remove the tiny ossicles and/or they can slip out of the middle ear cavity following skull movements. Entombment offers effective protection against the displacement of the auditory ossicles, whereas aquatic submersion and aquatic movement almost invariably displace them. Conclusion: the preservation of the human auditory ossicles should be critically considered in the comprehensive context of any forensic investigation on human remains since it can assist the reconstruction of their taphonomic history. Taphonomic histories of remains can add crucial information to forensic investigations (e.g., the Post Mortem Interval, PMI). The aim of this study, limited by scarce relevant literature, is to discuss the potential role of the ossicular chain, detected by postmortem imaging techniques, as a taphonomical indicator in decomposing and/or skeletonized bodies. Full article

As the fields of aviation and aerospace optics continue to evolve, there is an increasing demand for enhanced detection capabilities in equipment. Nonetheless, in applications where both optical and mechanical constraints are stringent, the continuous expansion of optical aperture and focal length is impractical. Given the existing technological landscape, employing super-resolution algorithms to enhance the imaging capability of optical systems is both practical and highly relevant. This study capitalizes on using a 2D scanning galvanometer in optical systems to acquire micro-displacement information. Initially, an imaging model for optical systems equipped with a 2D scanning galvanometer was established, and the displacement vectors for both forward and sweep image motions were defined. On this foundation, we incorporated micro-displacement information that can induce high-frequency aliasing. Subsequently, the motion paths of the galvanometer were planned and modeled. To align image sequences with micro-displacement correlations, the Lucas–Kanade (L-K) optical flow method was employed with multi-layer pyramid iteration. Then, super-resolution reconstruction was performed using kernel regression techniques. Ultimately, we tested the algorithm on an aeronautical optoelectronic pod to evaluate its impact on optical resolution and imaging quality. Compared with the original images, the 16-frame image demonstrated a 39% improvement in optical resolution under laboratory conditions. Moreover, the algorithm exhibited satisfactory performance under both nighttime and daytime conditions, as well as during aerial tests. Full article

A comprehensive understanding of the linear/nonlinear dynamic behavior of wireless microresonators is essential for micro-electromechanical systems (MEMS) design optimization. This study investigates the dynamic behaviour of a magnetoelectric (ME) microresonator, using a finite element method (FEM) and machine learning algorithm. First, the linear/nonlinear behaviour of a fabricated thin-film ME microactuator is assessed in both the time domain and frequency spectrum. Next, a data driven system identification (DDSI) procedure and simulated annealing (SA) method are implemented to reconstruct differential equations from measured datasets. The Duffing equation is employed to replicate the dynamic behavior of the ME microactuator. The Duffing coefficients such as mass, stiffness, damping, force amplitude, and excitation frequency are considered as input parameters. Meanwhile, the microactuator displacement is taken as the output parameter, which is measured experimentally via a laser Doppler vibrometer (LDV) device. To determine the optimal range and step size for input parameters, the sensitivity analysis is conducted using Latin hypercube sampling (LHS). The peak index matching (PIM) and correlation coefficient (CC) are considered assessment criteria for the objective function. The data-driven developed models are subsequently employed to reconstruct/predict mode shapes and the vibration amplitude over the time domain. The effect of driving signal nonlinearity and total harmonic distortion (THD) is explored experimentally under resonance and sub-resonance conditions. The vibration measurements reveal that as excitation levels increase, hysteresis variations become more noticeable, which may result in a higher prediction error in the Duffing array model. The verification test indicates that the first bending mode reconstructs reasonably with a prediction accuracy of about 92 percent. This proof-of-concept study demonstrates that the simulated annealing approach is a promising tool for modeling the dynamic behavior of MEMS systems, making it a strong candidate for real-world applications. Full article

Poor tendon–bone interface (TBI) integration is one of the major causes contributing to unsatisfactory healing quality in patients after anterior cruciate ligament (ACL) reconstruction. Type H vessels have been recently found to closely modulate bone formation via regulation of the osteo-angiogenic crosstalk, so the strategies favoring type H vessel formation may be promising therapeutic approaches for improved graft osteointegration. In this study, we reported for the first time the treatment outcome of slit guidance ligand 3 (slit3), a novel proangiogenic factor favoring type H vessel formation, in TBI healing in mice with ACL reconstruction. The mice (n = 87) were divided into three groups for various treatments: hydrogel microparticles (HMP, control group), slit3@HMP, and slit3 neutralizing antibody@HMP (slit3-AB@HMP). Histological analysis, gait performance, radiographic measurement, and biomechanical testing were performed to assess the TBI healing quality. Increased bony ingrowth and reduced fibrous scar tissue was formed at the TBI in the slit3@HMP group when compared to the HMP group. Meanwhile, the slit3-AB@HMP inhibited the osseous ingrowth and increased fibrous scar tissue formation relative to the HMP group. Compared to the HMP group, the slit3@HMP favored type H vessel formation at the TBI while the slit3-AB@HMP impeded it. According to micro-CT assessment, compared to the HMP group, the slit3@HMP significantly increased the peri-tunnel bone mass while the slit3-AB@HMP significantly reduced the peri-tunnel bone mass. The mice in the slit3@HMP group showed the best gait performance in terms of stance time, stride length, paw print area, and stance pressure. Dynamic laxity measurement and tensile testing showed the slit3@HMP group exhibited significantly reduced laxity displacement and improved failure load and stiffness relative to the other two groups. Collectively, the injection of slit3 could be used to enhance tendon–bone integration, which may be ascribed to modulation of angiogenesis–osteogenesis crosstalk coupled by type H vessels. Full article

The wellbeing of pipelines is influenced by a range of factors, such as internal and external pressures, as well as deterioration over time due to issues like erosion and corrosion. It is thus essential to establish a reliable monitoring system that can precisely examine pipeline behavior over time in order to prevent potential damages. To this end, pipelines are inspected based on internal and external approaches. Radar, as a non-contact sensing system, can be a suitable choice for external pipeline inspection. Radar is capable of the transmission and receiving of thousands of signals in a second, which reconstructs the displacement signal and is used for a vibration analysis. Synthetic aperture radar (SAR) imaging adds cross-range resolution to radar signals. However, a data acquisition rate of longer than several seconds makes it unsuitable for sub-second vibration monitoring. This study aims to address this limitation by presenting a method for high-resolution vibration monitoring using ground-based SAR (GBSAR) signals. To this end, a signal processing method by modifying the radar’s signal model is presented, which allows for estimating scattering targets’ vibration parameters and angle of arrival with high resolution. The proposed method is validated with numerical simulation and a real case study comprising water pipelines. Moreover, various analyses are presented for the in-depth evaluation of the method’s performance in different situations. The results indicate that the proposed method can be effective in detecting pipeline vibration frequencies with micro-scale amplitudes while providing high spatial resolution for generating accurate vibration maps of pipelines. Also, the comparison with the radar observations shows a high degree of agreement between the frequency responses with the maximum error of 0.25 Hz in some rare instances. Full article

A new signal processing method named orthogonal signal phase multiplication (OSPM) is proposed, which is used to improve the precision of vibration measurement in a phase-modulating self-mixing interferometer (SMI). The modulated signal is acquired by an electro-optic modulator, which is placed in the external cavity. Higher measurement precision is realized by performing the phase multiplication algorithm on the orthogonal signals extracted from the harmonic components of the signal spectrum. Theoretically, the displacement reconstruction precision of OSPM is higher than that of conventional modulation methods, and it can be continuously improved by increasing the multiplication times. The feasibility and performance of the proposed method are verified by simulated signals and confirmed by experiments; the absolute error is less than 11 nm, and relative error is less than 0.75%, within the amplitude range from 661 nm to 2013 nm. This method does not involve additional optical elements, and its effectiveness meet the requirements for real-time high-precision measurements. Full article

The low oil recovery rate observed in current oil fields is largely attributed to the presence of remaining oil trapped in the pores of porous media during waterflooding. To improve the recovery rate, it is imperative to gain an understanding of the oil–water flow characteristics and displacement mechanisms during waterflooding, as well as to elucidate the underlying mobilization mechanisms of residual oil at the pore scale. In this paper, we explore these issues in depth by numerically investigating the influence of factors such as water injection velocities, oil–water viscosity ratios, and wettability conditions on pore-scale oil–water flow characteristics and oil recovery rate. To this end, we employ a direct numerical simulation (DNS) method in conjunction with the volume of fluid (VOF) method to study the microscopic displacement mechanisms of waterflooding in a reconstructed two-dimensional digital rock core based on micro-CT technology. In addition, the particle tracing method is adopted to identify the flow path and dominant areas during waterflooding in order to mobilize the residual oil within the pores. The findings indicate that the oil–water flow characteristics in porous media are determined by the interplay between capillary and viscous forces. Furthermore, the oil recovery rate is 10.6% and 24.7% lower under strong water-wet and oil-wet conditions than that (32.36%) under intermediate wettability conditions, and the final oil recovery rate is higher under water-wet conditions than under oil-wet conditions. The seepage path and the dominant areas are directly linked to the capillarity formed during waterflooding. The findings of this study are significant in terms of enhancing the recovery rate of residual oil and provide a novel perspective for understanding the waterflooding process. Full article

The understanding of multiphase flow phenomena occurring in porous media at the pore scale is fundamental in a significant number of fields, from life science to geo and environmental engineering. However, because of the optical opacity and the geometrical complexity of natural porous media, detailed visual characterization is not possible or is limited and requires powerful and expensive imaging techniques. As a consequence, the understanding of micro-scale behavior is based on the interpretation of macro-scale parameters and indirect measurements. Microfluidic devices are transparent and synthetic tools that reproduce the porous network on a 2D plane, enabling the direct visualization of the fluid dynamics. Moreover, microfluidic patterns (also called micromodels) can be specifically designed according to research interests by tuning their geometrical features and surface properties. In this work we design, fabricate and test two different micromodels for the visualization and analysis of the gas-brine fluid flow, occurring during gas injection and withdrawal in underground storage systems. In particular, we compare two different designs: a regular grid and a real rock-like pattern reconstructed from a thin section of a sample of Hostun rock. We characterize the two media in terms of porosity, tortuosity and pore size distribution using the A* algorithm and CFD simulation. We fabricate PDMS-glass devices via soft lithography, and we perform preliminary air-water displacement tests at different capillary numbers to observe the impact of the design on the fluid dynamics. This preliminary work serves as a validation of design and fabrication procedures and opens the way to further investigations. Full article

Due to the unclear seepage mechanism for shale oil, it is hard to establish a reasonable mathematical model to describe the flowing law. In this study, a real shale pore structure was reconstructed with CT scanning and a numerical model of fluid flowing in the real shale pore is developed with COMSOL, based on the boundary slip at the micro-nano pore scale to study the causes of nonlinear seepage. A two-fluid model is employed to establish a simple mathematical model to describe the relationship between the flow rate and the pressure gradient using the effective slip length to account for the influence of pore structure and true slip, and the established model is verified with experimental data coming from Jiyang shale oil. The results indicated that the pore structure greatly affected the shape of the seepage curve. With the increase in displacement pressure, the percentage of fluid involved in the flow increased until it became stable, showing a changing trend from nonlinearity to linearity. The established model can fit the experimental data well and reasonably characterize the nonlinear seepage of shale oil. Full article

An improved method combining multiple reflections with the phase-modulation technique (MR-PM) is proposed to construct a self-mixing interferometer with high accuracy. The phase modulation is performed by using an electro-optic modulator that is placed in the external cavity. To broaden the harmonic components spectrum of the self-mixing signal, the multiple-reflection technique is employed. By extracting orthogonal signals from the spectrum, phase demodulation is implemented to realize displacement reconstruction. The principle and signal processing approach are described in detail. A series of simulations and experiments indicate that the measurement accuracy of the system can be effectively improved with the increase in reflection times. The vibration with an amplitude of 44 nm has been proved to be measurable with a reconstruction error less than 3 nm. Due to the advantages of high accuracy and broad measurement range, the proposed method will play a significant role in the field of non-contact nanometer vibration measurement. Full article

We propose an imaging method based on optical fiber bundle combined with micro-scanning technique for improving image quality without complex image reconstruction algorithms. In the proposed method, a piezoelectric-ceramic-chip is used as the micro-displacement driver of the optical fiber bundle, which has the advantages of small volume, fast response speed and high precision. The corresponding displacement of the optical fiber bundle can be generated by precise voltage controlling. An optical fiber bundle with core/cladding diameter 4/80 μm and hexagonal arrangement is used to scan the 1951 USAF target. The scanning step is 1 μm, which is equivalent to the diffraction limit resolution of the optical system. The corresponding information is recorded at high speed through photo-detectors and a high-resolution image is obtained by image stitching processing. The minimum distinguishable stripe width of the proposed imaging technique with piezoelectric-ceramic-chip driven micro-scanning is approximately 2.1 μm, which is 1 time higher than that of direct imaging with a CCD camera whose pixel size is close to the fiber core size. The experimental results indicate that the optical fiber bundle combined with piezoelectric-ceramic-chip driven micro-scanning is a high-speed and high-precision technique for high-resolution imaging. Full article
