Preparing elastic substrates as a carrier for dual-end supported nickel chromium thin film strain sensors is crucial. Wet etching is a vital microfabrication process widely used in producing microelectronic components for various applications. This article combines lithography and wet etching methods to microprocess the external dimensions and rectangular grooves of 304 stainless steel substrates. The single-factor variable method was used to explore the influence mechanism of FeCl₃, HCl, HNO₃, and temperature on the etching rate, etching factor, and etching surface roughness. The optimal etching parameter combination was summarized: an FeCl₃ concentration of 350 g/L, HCl concentration of 150 mL/L, HNO₃ concentration of 100 mL/L, and temperature of 40 °C. In addition, by comparing the surface morphology, microstructure, and chemical and mechanical properties of a 304 stainless steel substrate before and after etching treatment, it can be seen that the height difference of the substrate surface before and after etching is between 160 μm and −70 μm, which is basically consistent with the initial design of 0.2 mm. The results of an XPS analysis and Raman spectroscopy analysis both indicate that the surface C content increases after etching, and the corrosion resistance of the surface after etching decreases. The nano-hardness after etching increased by 26.4% compared to before, and the ζ value decreased by 7%. The combined XPS and Raman results indicate that the changes in surface mechanical properties of 304 stainless steel substrates after etching are mainly caused by the formation of micro-nanostructures, grain boundary density, and dislocations after wet etching. Compared with the initial rectangular substrate, the strain of the I-shaped substrate after wet etching increased by 3.5–4 times. The results of this study provide the preliminary process parameters for the wet etching of a 304 stainless steel substrate of a strain measuring force sensor and have certain guiding significance for the realization of simple steps and low cost of 304 stainless steel substrate micro-nano-processing. Full article

Liquid metal (LM) is widely used in flexible electronic devices due to its excellent metallic conductivity and ductility. However, the fabrication of LM flexible strain sensors with high sensitivity and linearity is still a huge challenge, since the resistance of LM does not change much with strain. Here, a highly sensitive and linear fully flexible strain sensor with a resistive sensing function is proposed. The sensor comprises an Fe-doped liquid metal (Fe-LM) electrode for enhanced performance. The design and manufacturing of flexible strain sensors are based on the technology of controlling surface wettability by femtosecond laser micro/nano-processing. A supermetalphobic microstructure is constructed on a polydimethylsiloxane (PDMS) substrate to achieve the selection adhesion of Fe-LM on the PDMS substrate. The Fe-LM-based flexible strain sensor has high sensitivity and linearity, a gauge factor (GF) up to 1.18 in the strain range of 0–100%, excellent linearity with an R² of 0.9978, a fast response time of 358 ms, and an excellent durability of more than 2400 load cycles. Additionally, the successful monitoring of human body signals demonstrates the potential of our developed flexible strain sensor in wearable monitoring applications. Full article

Micro/nanoprocessing of materials using lasers is currently an active research topic. In that research, the choice of the laser to be used is critical, but the F₂ laser, which has the shortest wavelength (157 nm) among commercially available lasers, has few research compared to its potential. In this paper, we discovered a new photochemical processing by using an F₂ laser to irradiate an amorphous carbon thin film. The short wavelength and high photon energy of the F₂ laser can photoexcite the surface of the thin film at high density and generate active oxygen atoms O(¹D) by photodecomposition of atmospheric oxygen molecules. As a result, the optical change of the amorphous carbon thin film was induced without thickness reduction, and a micron-sized network-like, reticulated structural change was formed in the thin film surface after one month at the latest. The formed micron-sized reticulated structure was relatively swollen, and a graphitization occurred in the structure, observed by Raman spectroscopy. However, the structure was not observed when the laser irradiated area became smaller. This work has made it possible to form a micron-sized reticulated structure including carbon nanocrystals in an amorphous carbon, which is expected to further expand the applications of carbon materials. Full article

Over the past several years, resonance energy transfer involving noble metallic nanoparticles has received considerable attention. The aim of this review is to cover advances in resonance energy transfer, widely exploited in biological structures and dynamics. Due to the presence of surface plasmons, strong surface plasmon resonance absorption and local electric field enhancement are generated near noble metallic nanoparticles, and the resulting energy transfer shows potential applications in microlasers, quantum information storage devices and micro-/nanoprocessing. In this review, we present the basic principle of the characteristics of noble metallic nanoparticles, as well as the representative progress in resonance energy transfer involving noble metallic nanoparticles, such as fluorescence resonance energy transfer, nanometal surface energy transfer, plasmon-induced resonance energy transfer, metal-enhanced fluorescence, surface-enhanced Raman scattering and cascade energy transfer. We end this review with an outlook on the development and applications of the transfer process. This will offer theoretical guidance for further optical methods in distance distribution analysis and microscopic detection. Full article

The strong nonlinear absorption effect and “cold” processing characteristics of femtosecond lasers make them uniquely advantageous and promising for the micro- and nanoprocessing of hard and brittle materials, such as quartz. Traditional methods for studying the effects of femtosecond laser parameters on the quality of the processed structure mainly use univariate analysis methods, which require large mounts of experiments to predict and achieve the desired experimental results. The method of design of experiments (DOE) provides a way to predict desirable experimental results through smaller experimental scales, shorter experimental periods and lower experimental costs. In this study, a DOE program was designed to investigate the effects of a serious of parameters (laser repetition frequency, pulse energy, scan speed, scan distance, scan mode, scan times and laser focus position) on the depth and roughness (Ra) of the fabricated structure through the liquid-assisted femtosecond laser processing of quartz. A prediction model between the response variables and the main parameters was defined and validated. Finally, several blind holes with a size of 50 × $50{\mathsf{\mu }\mathrm{m}}^2$ and a depth of 200 $\mathsf{\mu }\mathrm{m}$ were fabricated by the prediction model, which demonstrated the good consistency of the prediction model. Full article

As the application requirements of semiconductor lasers continue to increase, severe challenges are brought to the reliability of semiconductor lasers. In order to promote the study of laser failure, this paper proposes an effective failure analysis method for packaged semiconductor lasers with a simple sample preparation and home-made photon emission microscopy (PEM) system. The new simple sample preparation process for failure analysis is presented and the necessary polishing fixture is designed so that sample can be obtained without expensive and complex micro-/nano-processing. Two types of home-made PEM experimental systems were established for observing the failure from the front facet and active region of semiconductor lasers. Experimental results showed that, with the proposed sample preparation flow, the home-made PEM experimental system effectively observed the leakage defects from the front facet and dark spot defects (DSDs) in the active region of semiconductor lasers. The method can help researchers and laser manufactures to perform effective failure analysis of packaged semiconductor lasers. Full article

Graphite is expected to be a common choice for basic microelectromechanical-system (MEMS) material in the future. However, in order to become a basic MEMS material, it is very important for graphite to be adapted to the commonly-used micro-/nanoprocessing technology. Therefore, this paper used a directly lithography and etching process to study micro-, /nanoprocessing on graphite. The results show that the graphite surface is suitable for lithography, and that different shapes and sizes of photoresist patterns can be directly fabricated on the graphite surface. In addition, the micro-meter height of photoresist could still resist plasma etching when process nanometers height of graphite structures. Therefore, graphite with photoresist patterns were directly processed by etching, and nanometer amounts of graphite were etched. Moreover, micro-/nanoscale graphite structure with height ranges from 29.4 nm–30.9 nm were fabricated with about 23° sidewall. Full article

Resonance absorption mechanism-based metasurface absorbers can realize perfect optical absorption. Further, all-dielectric metasurface absorbers have more extensive applicability than metasurface absorbers that contain metal components. However, the absorption peaks of the all-dielectric metasurface absorbers reported to date are very sharp. In this work, we propose a broadband optical absorption all-dielectric metasurface, where a unit cell of this metasurface is composed of two coupled subwavelength semiconductor resonators arrayed in the direction of the wave vector and embedded in a low-index material. The results indicate that the peak absorption for more than 99% is achieved across a 60 nm bandwidth in the short-wavelength infrared region. This absorption bandwidth is three times that of a metasurface based on the conventional design scheme that consists of only a single layer of semiconductor resonators. Additionally, the coupled semiconductor resonator-based all-dielectric metasurface shows robust perfect absorption properties when the geometrical and material parameters—including the diameter, height, permittivity, and loss tangent of the resonator and the vertical and horizontal distances between the two centers of the coupled resonators—are varied over a wide range. With the convenience of use of existing semiconductor technologies in micro/nano-processing of the surface, this proposed broadband absorption all-dielectric metasurface offers a path toward realizing potential applications in numerous optical devices. Full article

The working principle of a rotating micro-actuator based on a piezoelectric stack was theoretically analyzed and experimentally verified. The actuator is compact in structure, and the key component is the shearing piezoelectric stack. The piezoelectric stack is used to drive the micro-rotor via an electromechanical transition, which produces high-speed rotation of the micro-rotor. We first established the dynamic model of the micro-actuator and numerically analyzed the motion of this model. The step displacement output was observed by simulation, and the step increment is quite large. For experimental verification, we fabricated the piezoelectric micro-actuator with a size of 12 mm × 10 mm × 8 mm and mass of 4.12 g and conducted a series of experiments. The results show qualitative agreement with the theoretical results; the maximum output speed of the micro-actuator is 5.86 × 10 ${}^5$ $\mathsf{\mu }$ rad/s, and the motion resolution is 0.64 $\mathsf{\mu }$ rad, which is greater than that of most traditional piezoelectric actuators. The proposed micro-actuator offers superior performance in driving of selected small objects, such as in micro-/nano-processing and cell operation. Full article
