Binder systems based on polyethylene (PE) and wax are widely used in Metal Injection Molding (MIM). However, their application raises environmental concerns related to material waste and the possible alteration of binder properties during repeated processing. This study aims to provide a comprehensive understanding of the behavior and properties of PE–wax systems to establish a reference framework for the evaluation and future development of alternative binder formulations. Model PE–wax blends without metallic powder were characterized using differential scanning calorimetry, tensile testing, and X-ray diffraction. The results showed that polymer and wax type influence the mechanical response of the blends, with the HDPE–octadecane formulation exhibiting a lower Young’s modulus than the HDPE–paraffin wax blend at the same wax content. Thermal analysis revealed distinct transitions associated with the polymer and wax components, together with small variations between successive heating and cooling cycles, indicating thermal-history-dependent behavior. Young’s modulus, Poisson’s ratio, thermal conductivity, and density were also predicted using Digimat software. The predicted Young’s modulus values showed good agreement with the experimental tensile results. The results provide a preliminary framework for screening polyethylene–wax binder formulations. Full article

Micro-structured SAE H13 tool steel inserts for polymer injection molding require accurate replication of sub-millimeter features while retaining adequate densification and heat-treatment response. This study compared two powder-based routes on the same hemispherical insert containing pyramidal features of approximately 0.145 mm base width: hot embossing (HE) of water-atomized SAE H13 powder (supplier d50 = 5.7 µm, irregular morphology) compounded with a commercial M1 binder, and material extrusion (MEX) of a commercial gas-atomized SAE H13 filament processed on a Markforged Metal X. Rheological screening selected a 57:43 vol% powder-to-binder ratio for the in-house HE feedstock, and DSC/TGA measurements defined two-step debinding windows. The best HE conditions were 220 °C, 8 MPa, and 45 min for the in-house mixture, and 210 °C, 8 MPa, and 30 min for the granulated commercial filament; the latter showed a 0.15% linear deviation from the silicone replica diameter among the best-rated samples. Under the tested commercial MEX configuration, the pyramidal features were not resolved because the 0.40 mm deposition line width exceeded the target feature base width, causing the slicer to omit the sub-line-width geometry. The defect populations differed qualitatively: HE specimens showed porosity and local cracking associated with powder morphology and pressureless sintering, whereas MEX specimens showed build-direction-aligned inter-raster voids associated with the toolpath. Microhardness and tensile data are therefore interpreted as process-history-specific results rather than as a direct route ranking, because sintering conditions were not uniform across all specimens. The study defines an experimentally bound process-selection limit for SAE H13 micro-tooling: HE remains preferable for sub-nozzle surface features, whereas MEX remains attractive for macro-scale geometric freedom, if resolution, densification, and post-sintering consolidation are addressed. Full article

The transition to a circular economy requires assessment tools that capture not only the environmental and economic performance of products but also their circular design, functionality, and durability. While Life Cycle Assessment (LCA) and Life Cycle Costing (LCC) are widely used, they alone do not capture modularity, reparability, reuse potential, or product lifespan. This study introduces a novel, integrated framework combining LCA, LCC, and product-level circularity indicators to provide a holistic evaluation of sustainability and circularity. In this study, two types of injection molds for plastic part production are compared: a conventionally manufactured mold and an additively manufactured metal mold produced by Laser Powder Bed Fusion (L-PBF) technology. The comparison integrates Life Cycle Assessment (LCA), Life Cycle Costing (LCC), and a set of micro-circularity indicators, including the Material Circularity Indicator (MCI), Recycling Desirability Index (RDI), circular design guidelines (CDG), Disassembly Effort Index (DEI), longevity indicator (LI), and Circular Economy Indicator Prototype (CEIP). Results show that the AM mold exhibits lower environmental impacts across almost all categories, while its slightly higher initial cost is largely offset by reduced indirect costs over the product lifecycle. Micro-circularity indicators reveal that the AM mold achieves higher material circularity and better circular design performance (MCI, CDG, CEIP) but shows only minor improvements in disassembly and recyclability (DEI, RDI) and lower longevity (LI) compared to the conventional mold, highlighting potential limitations for remanufacturing and end-of-life recovery. The novelty of this study lies in the integrated application of LCA, LCC, and multiple micro-circularity indicators, providing an operational framework for evaluating circular design, reparability, and durability in additive manufacturing and enabling informed, holistic decision-making for truly circular products. Full article

Fused Filament Fabrication (FFF) is a low-cost additive manufacturing process that produces metallic parts from printing with a metal-polymer filament, followed by a debinding–sintering process. It presents an opportunity for the tooling sector to improve performance by geometrical optimization while keeping costs low. This study investigates the possibility of producing a molding core for plastic injection by FFF technology. This research aimed to characterize 17-4 PH stainless steel and H13 hot work tool steels produced through this process. Their heat treatment behavior was investigated using dilatometry, which led to the obtention of a Continuous Cooling Transformation (CCT) diagram. Results show that for as-sintered materials, martensitic steel with some residual austenite is present in 17-4 PH, and a pearlitic microstructure is observed in H13. Porosity (around 4%) falls within the reported range in the literature and can be removed by hot isostatic pressing. CCT diagrams do not show significant differences with conventional materials. The low hardness of as-sintered H13 (around 175 HV1) is improved (>500 HV1) by suitable heat treatment. Finally, both materials meet the requirements for this specific industrial application, and demonstrators were produced. Full article

Injection molding has been used for many years in the fabrication of thermoplastic parts with different complexities. With metal and ceramic injection molding, it is possible to realize at the end of the related process chain sintered metal and ceramic parts. Parts made from glass are rather seldom realized applying powder technology methods. This work describes the production of devices made from a commercial soda-lime glass applying the process chain of powder injection molding, covering the individual process steps like compounding, shaping, debinding, and sintering. In the first step, a binder consisting of polyethylene glycol (PEG) with different average molecular masses (4000, 8000, and 20,000 g/mol), polyvinyl butyral (PVB), and stearic acid (SA) were used for compounding new feedstocks with a solid load of 55 Vol% and 60 Vol%. As filler, a soda-lime glass with an average particle size of 6.1 µm, an almost symmetrical particle size distribution, a specific surface area of 0.78 m²/g, and a spherical morphology was applied. The measured equilibrium torque during compounding was low, with values between 2.5 and 5.5 Nm depending on the solid load and average molecular mass of the investigated PEG. All feedstock possessed a pseudoplastic flow behavior in the shear rate range between 10 and 3500 1/s. Small disk-shaped parts, as well as large cuboids and plates, were injection molded to a good quality. These green bodies were pre-debinded in water to remove the PEG, subsequently followed by thermal debinding to eliminate the remaining organic moieties. The concluding sintering in the temperature range between 660 and 680 °C delivered glass parts with huge density values close to 100% of the theoretical value, as measured by the Archimedes method. The principal feasibility of glass injection molding with a suitable feedstock system could be demonstrated successfully. Full article

The COVID-19 pandemic critically emphasized the need for rapid, flexible, and decentralized manufacturing solutions to support the urgent demand for essential medical equipment, such as oximeters. Metal wire directed energy deposition—w-DED, also known as w-LMD (wire laser metal deposition)—combines the benefits of high material utilization, increased printing speed, and reduced waste, making it an attractive alternative to traditional powder-based processes, especially under time-sensitive and resource-constrained conditions. This work presents a case study focusing on the design and fabrication of injection molds for oximeter casings using metal-wire-based DED. Martensitic stainless steel AISI-420 wire was employed as feedstock and processed via laser wire additive manufacturing to produce a robust, near-net-shape mold suitable for plastic injection molding. The material was selected due to good corrosion and wear resistance. However, poor ductility and toughness, together with AM-induced anisotropy, were the main challenges to address. Therefore, a multi-step methodology was defined to study the effect of different process parameters, which was validated through printing trials, and the optimum process parameter set was identified. The process enabled the rapid construction of intricate mold geometries, minimizing lead times and allowing for quick design iterations. Microstructural and physical properties such as microhardness of the as-built molds were thoroughly characterized. This case study not only illustrates the technical feasibility of producing functional injection molds via metal w-DED but also outlines its role as a resilient manufacturing pathway, capable of meeting emergent healthcare needs and supporting broader industrial applications in a post-pandemic context. Full article

Powder Injection Molding (PIM) is a versatile manufacturing technology widely used for fabricating components with complex geometries from metals and ceramics, yet its application to high-performance thermoplastics remains underutilized. This study explores the feasibility of manufacturing products from Polyphenylene Sulfide (PPS)—a promising linear aromatic polymer synthesized in powder form—using PIM technology and investigates the development of PE-based feedstocks with PPS and solid fillers. Regarding the matrix formulation, it was found that using pure paraffin as a binder limited the maximum PPS content to 20%. Consequently, a modified binder system consisting of Low-Density Polyethylene (LDPE) and paraffin in a 70:30 wt.% ratio was utilized, which successfully increased the PPS loading in the feedstock to 50% and enabled stable molding. Following matrix optimization, the study examined composites incorporating various fillers, including chalk, talc, and carbon fibers. Systematic rheological analysis confirmed that these composite suspensions possess characteristics necessary for molding products with complex geometries. Key results indicate that optimal sintering conditions were established to achieve the required mechanical properties. Among the tested fillers, carbon fibers were the most effective reinforcement, increasing the elastic modulus by 33% and flexural strength by 20%. Representative examples of samples successfully manufactured via this approach are presented. Full article

Metal Injection Molding (MIM) enables complex orthodontic-bracket geometries but can introduce surface and geometric discontinuities that act as initiation sites for crevice and pitting corrosion. The effect of acidic, kombucha-like exposure on corrosion and repassivation was assessed for MIM-316L brackets relative to a commercial comparator, and the coupling between surface quality (roughness and wettability) and localized damage at scanning electron microscopy (SEM)-identified hot-spots was examined. Kombucha was characterized by pH and titratable acidity. Surfaces were characterized by SEM, areal roughness metrics (R_a, S_a, S_z, and A2), and wettability by sessile-drop goniometry. Electrochemical behavior in artificial saliva was measured using open-circuit potential and cyclic potentiodynamic polarization (ASTM F2129/G59), and a qualitative magnetic check was included as a pragmatic quality-assurance screen. Exposure in kombucha reduced breakdown and repassivation potentials and increased passive current density, with the strongest effects co-localizing geometric discontinuities. Commercial brackets exhibited markedly poorer surface quality (notably higher S_z), amplifying acidity-driven susceptibility. These findings indicate that, under acidic challenges, surface/geometry quality dominates corrosion behavior; non-magnetic-phase compliance and simple chairside screening (e.g., magnet test), alongside tighter manufacturing controls on roughness and edge finish, should be incorporated into clinical and industrial quality assurance (QA). Full article

Solid rocket motors (SRMs) play a pivotal role in space exploration owing to their reliability and high thrust-to-weight ratios. SRM propellant health monitoring is in critical demand owing to the complex operational scenarios throughout the entire life cycle of SRMs. To achieve in situ detection of three-dimensional stress, this study introduces a novel flexible three-dimensional stress sensor (FSS). First, a liquid metal pressure-sensing element with a variable cross-section was designed and numerically modeled. The performance of the FSS under different loading conditions was analyzed using finite element modeling. The sensing element prototype was fabricated using mold casting and liquid metal injection methods. The fabricated sensing-element prototype with an area ratio of 1:5 exhibited a sensitivity coefficient of 1.5%/kPa at a pressure of 300 kPa, a maximum hysteresis error of 3.98%, and a stability error of 0.17%. Finally, the FSS was developed by integrating multiple pressure-sensing elements and encapsulating the force-concentrating layers. The fabricated FSS prototype was characterized using simulated propellant experiments. Via comparison with the simulation results, the FSS was found to detect multiaxial stress differences when embedded within a propellant. Full article

Microcellular injection-molded polypropylene/oyster shell nano-powder (PP/OSP) composites show potential as adsorbent materials for reducing toxic metal ion contamination in groundwater. This study investigates the material properties of PP/OSP composites and evaluates their Pb(II) adsorption performance in aqueous media. The effects of key operational parameters, including contact time, pH, and initial Pb(II) concentration, were examined to determine the optimal conditions for heavy metal remediation. The composites were characterized using XRD, SEM, FTIR, and TGA to assess their crystalline structure, surface morphology, functional groups, and thermal stability, respectively. Adsorption isotherm analysis indicated that the Pb(II) uptake behavior followed both the Freundlich and Temkin models. Kinetic studies showed that the adsorption process was best described by the pseudo-first-order model. The maximum adsorption capacity for Pb(II) removal was determined to be 13.89 mg/g. Full article

Metal Injection Molding (MIM) is an established, high-precision manufacturing route for small, geometrically complex metallic components, integrating polymer injection molding with powder metallurgy. State-of-the-art feedstock systems, such as Catamold (polyacetal-based), enable catalytic debinding performed in furnaces operating under ultra-high-purity nitric acid atmospheres (>99.999%). The subsequent thermal stages pre-sintering and sintering are carried out in continuous controlled-atmosphere furnaces or vacuum systems, typically employing inert (N₂) or reducing (H₂) atmospheres to meet the specific thermodynamic requirements of each alloy. However, incomplete decomposition or secondary volatilization of binder residues can lead to progressive hydrocarbon accumulation within the sinering chamber. These contaminants promote undesirable carburizing atmospheres, which, under austenitizing or intercritical conditions, increase carbon diffusion and generate uncontrolled surface carbon gradients. Such effects alter the microstructural evolution, hardness, wear behavior, and mechanical integrity of MIM steels. Conversely, inadequate dew point control may shift the atmosphere toward oxidizing regimes, resulting in surface decarburization and oxide formation effects that are particularly detrimental in stainless steels, tool steels, and martensitic alloys, where surface chemistry is critical for performance. This review synthesizes current knowledge on atmosphere-induced surface deviations in MIM steels, examining the underlying thermodynamic and kinetic mechanisms governing carbon transport, oxidation, and phase evolution. Strategies for atmosphere monitoring, contamination mitigation, and corrective thermal or thermochemical treatments are evaluated. Recommendations are provided to optimize surface substrate interactions and maximize the functional performance and reliability of MIM-processed steel components in demanding engineering applications. Full article

In this research, we assess the feasibility of employing hybrid friction stir channeling (HFSC) to produce composite panels that combined an 8 mm thick AA6082-T6 aluminum alloy and 5 mm thick glass-fiber-reinforced Noryl GFN2. HFSC is an innovative solid-state technology that combines both friction stir joining and channeling characteristics, which enable the generation of integral internal channels while joining different components. A parametric study was outlined to explore the effects of the travel speed, probe length, and tool plunging on the resulting composite panels. The resulting composite panels were subsequently subjected to a comprehensive analysis encompassing exterior ceiling quality, internal channel, and joining interface morphology. Depending on the processing parameters, the geometry of the channels was found to be quasi-rectangular or quasi-trapezoidal, with significant variability on cross-sectional area, resulting in hydraulic diameters ranging from 1.2 to 2.9 mm. The joining interface was characterized by a concavity of aluminum that was extruded downwards into the polymeric molten pool, which was clinched after polymeric re-solidification. The experimental results prove the ability to join metals and polymers while creating an integral channel in a single process step using HFSC. Despite the positive effect of irregular shaped channels on heat exchange, the numerical models evidenced a detrimental effect of 14.3 and 16.3% on ultimate tensile and flexural loads, respectively. This way, this fabrication technology evidenced promising characteristics that are suitable for manufacturing thermal management systems such as conformal cooling for plastic injection molding or battery trays for EVs. Full article

The paper presents the results of research aimed at verifying the possibility of creating renovation layers using HVOF (High Velocity Oxygen Fuel) technology. HVOF ceramic coatings represent a promising way to increase the efficiency, reliability, and sustainability of manufacturing processes. Molds for high-pressure injection of aluminum alloys were analyzed. The degradation mechanism of the functional surfaces of the molds was determined. The paper analyzes two types of HVOF coatings—Cr₂O₃-TiO₂ and Al₂O₃-TiO₂. For both coatings, a Ni-Al interlayer was used for mechanical stability, durability, and reliable functionality in demanding operating conditions. The interlayer is used in thermal spraying as a so-called bond coat—a layer that mediates adhesion between the metal substrate and the ceramic coating. EDX maps of chemical elements from the coating surface and cross-sections were determined. The tribological properties of the coatings were evaluated by a ball-on-disk test at 20 °C and 250 °C. SEM analysis of the surface after the tribological test was performed. The resistance of the coatings was evaluated by COF and friction resistance. Full article

Additive manufacturing (AM) has emerged as a promising technology for producing low-cost, customized tooling, particularly for prototyping and small-series injection molding. However, the inherent surface roughness and anisotropic properties of 3D-printed parts pose significant challenges for their direct use as functional mold inserts. This study investigates the effectiveness of various post-processing techniques on 3D-printed plastic inserts made from polyamide 12 (PA12) and glass bead-filled PA12 (PA12GB). The primary objective was to evaluate the impact of these surface treatments on the functional properties and service life of the mold inserts. A comprehensive analysis was conducted, including a detailed characterization of roughness using a confocal microscope, cross-sectional analysis to determine layer thickness, and tribological tests employing the ball-on-disc method to assess wear resistance. The study employed a modular injection mold and tested a range of surface finishing processes, including PostProcess Suspended Rotational Force (SRF) technology, metal decomposition coatings from HVM Plasma, and various methods from DyeMansion (Powershot S and Powerfuse). Results show a significant reduction in surface roughness across all methods. Notably, the vapor-based Powefuse treatment from DyeMansion achieved a surface roughness (R_a) of 1.2797 μm, which is below the typical R_a value of 1.6 μm for conventional metal molds, thereby making it suitable for high-quality molding applications. The tribological analysis provided critical insights into the durability and wear resistance of the treated surfaces, supporting their potential for extended use. This research validates the potential of specific post-processing methods to transform AM parts into functional tooling, enabling cost-effective and rapid prototyping in the plastics industry. Full article

For L-PBF (Laser Powder Bed Fusion) metal additive manufacturing (AM) the choice of available materials is still limited. 1.2709 maraging steel powders are widely used for injection molds and high-quality engineering parts. The quality of the parts produced by L-PBF are significantly affected by the process parameters. The aim of this research was to find optimal process parameters for producing 1.2709 tool steel at a layer thickness of 20 µm and to reveal the possible parameter settings yielding comparable build quality as the “EOS surface” parameter set at a layer thickness of 20 µm. Findings showed that too low or too high input energies produce improper parts. A large range of parameters produce good quality parts, of which the optimum parameters can be chosen. Full article
