Search Results (41)

Compared to traditional manufacturing methods, additive manufacturing (AM) enables the production of parts with arbitrary structures, effectively addressing the challenges faced when fabricating complex geometries using conventional techniques. The dynamic development of this technology has led to the emergence of increasingly advanced materials. One of the best examples is metal–polymer composites, which allow the manufacturing of fully dense components consisting of stainless steel and titanium alloys, employing the widely available AM technology based on material extrusion (MEX). Metallic materials intended for this type of 3D printing may serve as an alternative to currently prevalent techniques including techniques like selective laser melting (SLM), owing to significantly lower equipment and material costs. Particularly applicable in low-volume production, where total costs and manufacturing time are critical factors, MEX technology of polymer–metallic composites offer relatively fast and economical AM of metal components, proving beneficial during the design of geometrically complex, and low-cost equipment. Due to the significant advancements in AM technology, this review focuses on the latest developments in the additive manufacturing of metallic components using the MEX approach. The discussion encompasses the printing process characteristics, materials tailored to this technology, and post-processing steps (debinding and sintering) necessary for obtaining fully metallic MEX components. Additionally, the article characterizes the printing process parameters and their influence on the functional characteristics of the resulting components. Finally, it presents the drawbacks of the process, identifies gaps in existing research, and outlines challenges in refining the technology. Full article

Additive manufacturing (AM) is one of the most frequently used technologies to produce complex configuration products. Moreover, AM is very well known as a technology which is characterized by a low amount of generated waste and the potential to be called zero-waste technology. As is known, there are seven main groups of technologies described in the ISO/ASTM 52900 standard that allow the use of very different materials from polymers to metals, ceramics, and composites. However, the increased utilization of additively manufactured composites for different applications requires a deeper analysis of production processes and materials’ characteristics. Various AM technologies can be used to produce complex composite structures reinforced with short fibers; however, only material extrusion (MEX)-based technology is used for the production of composites reinforced with continuous fibers (CFs). At this time, five different methods exist to produce CF-reinforced composite structures. This study focuses on co-extrusion with the towpreg method. Because of the complexity and layer-by-layer nature of the process, defects can occur during production, such as poor interlayer adhesion, increased porosity, insufficient impregnation, and others. To eliminate or minimize defects’ influence on mechanical properties and structural integrity of additively manufactured structures, a hypothesis was proposed involving heat treatment. Carbon fiber’s conductive properties can be used to heal the composite structures, by heating them up through the application of electric current. In this research article, an experimental evaluation of conditions for additively manufactured composites with continuous carbon fiber reinforcement for self-healing processes is presented. Mechanical testing was conducted to check the influence of heat treatment on the flexural properties of the composite samples. Full article

This study introduced a systematic framework to develop practical design guidelines specifically for filament-based material extrusion of metals (MEX/M), an additive manufacturing (AM) process defined by ISO/ASTM 52900. MEX/M provides a cost-efficient alternative to conventional manufacturing methods, which is particularly valuable for rapid prototyping. Although AM offers significant design flexibility, the MEX/M process imposes distinct geometric and process constraints requiring targeted optimization. The research formulates and validates design guidelines tailored for the MEX/M using an austenitic steel 316L (1.4404) alloy filament. The feedstock consists of a uniform blend of 316L stainless steel powder and polymeric binder embedded within a thermoplastic matrix, extruded and deposited layer by layer. Benchmark parts were fabricated to examine geometric feasibility, such as minimum printable wall thickness, feature inclination angles, borehole precision, overhang stability, and achievable resolution of horizontal and vertical gaps. After fabrication, the as-built (green-state) components undergo a two-step thermal post-processing treatment involving binder removal (debinding), followed by sintering at elevated temperatures to reach densification. Geometric accuracy was quantitatively assessed through a 3D scan by comparing the manufactured parts to their original CAD models, allowing the identification of deformation patterns and shrinkage rates. Finally, the practical utility of the developed guidelines was demonstrated by successfully manufacturing an impeller designed according to the established geometric constraints. These design guidelines apply specifically to the machine and filament type utilized in this study. Full article

To promote environmental sustainability, this research investigated the potential of utilizing recycled polymethylmethacrylate (PMMA) as raw material in material extrusion (MEX) additive manufacturing (AM). To enhance its mechanical response, carbon black (CB) was employed as the filler in nanocomposite formation. Filament extrusion of the mixture at different concentrations produced printable feedstocks for MEX AM. Rheological analysis (viscosity and material flow rate) showed that the CB introduction to the matrix was beneficial for consistent layer deposition, while differential scanning calorimetry and thermogravimetric analyses verified the thermal stability of the nanocomposites during processing. Mechanical properties were optimized, with increases in modulus (27.8% and 25.8%, respectively, in tensile and bending loadings) and tensile strength at optimal CB loadings. Dynamic mechanical analysis revealed the viscoelastic response of the nanocomposites. Raman and energy dispersive spectroscopy provided element-related insights. Surface morphology and parts structure were observed employing scanning electron microscopy and micro-computed tomography, respectively, revealing a positive impact on the AM parts due to the CB presence in the nanocomposites. The 4 wt.% in CB content nanocomposite was the optimum one. This research pioneers the development of new sustainable nanocomposite filaments and highlights the potential of next-generation MEX-based AM. Full article

Poly(ether ketone ketone) (PEKK), as a representative of high-performance poly(aryl ether ketones), shows outstanding thermomechanical properties, opening up a huge range of different applications in various technical fields. Its appearance as a quasi-amorphous polymer with a certain suppression of the crystallization process facilitates melt processing via additive manufacturing processes like material extrusion (MEX), especially in fused filament fabrication (FFF). The quality of the printing process is proven in this work by tensile testing and surface roughness measurements of suitable specimens. The MEX printing of semicrystalline PEKK faces two major challenges: on the one hand, the very high printing temperature is in contrast to established engineering plastics, and on the other hand, it is difficult to avoid crystallization after printing. The first issue can be addressed by using suitably enhanced MEX printers and the second one by selecting adapted printing parameters. The measured Young’s modulus (3.49 GPa) and tensile strength (104 MPa) values are higher than the related vendors’ data given for filaments (3.0 GPa and 92 MPa, respectively). In addition, the temperature-dependent thermal conductivity is determined, and the values of well-established PEEK (poly(ether ether ketone)) in the temperature range from 20 to 180 °C are mostly slightly higher in comparison to the related PEKK data. Based on the results, PEKK can be a useful substitute for well-established PEEK because of their comparable properties. However, PEKK has a pronouncedly lower FFF printing temperature, combined with a reduced tendency of the device to warp after printing. A larger printed test part with some surface structures shows the improved printability of PEKK in comparison to PEEK. Full article

Additive manufacturing (AM) technologies have witnessed remarkable advancements, offering opportunities to produce complex components across various industries. This paper explores the potential of AM for fabricating bipolar plates (BPPs) in fuel cell or electrolysis cell applications. BPPs play a critical role in the performance and efficiency of such cells, and conventional manufacturing methods often face limitations, particularly concerning the complexity and customization of geometries. The focus here lies in two specific AM methods: the laser powder bed fusion of metals (PBF-LB/M) and material extrusion of metals (MEX/M). PBF-LB/M, tailored for high-performance applications, enables the creation of highly complex geometries, albeit at increased costs. On the other hand, MEX/M excels in rapid prototyping, facilitating the swift production of diverse geometries for real-world testing. This approach can facilitate the evaluation of geometries suitable for mass production via sinter-based manufacturing processes. The geometric deviations of different BPPs were identified by evaluating 3D scans. The PBF-LB/M method is more suitable for small features, while the MEX/M method has lower deviations for geometrically less complex BPPs. Through this investigation, the limits of the capabilities of these AM methods became clear, knowledge that can potentially enhance the design and production of BPPs, revolutionizing the energy conversion and storage landscape and contributing to the design of additive manufacturing technologies. Full article

Purpose: The effectiveness of the customised solutions compared to the conventional ones and the emergence of advanced production technologies, such as Additive Manufacturing (AM) techniques, strengthened the trend towards an enhanced individualization of the clinical treatments. In the present research, the value of topological optimisation (TO) in the manufacturing process of tailor-made orthopaedic appliance (upper-limb orthosis) was analysed. Methodology: From the morphology of a patient’s arm, orthotic models were developed. Nonparametric optimization (Simulia Tosca) was performed, based on the Finite Element Analysis (FEA) program (Abaqus), and contributed to the development of TO orthotic models with diverse levels of volume reduction fraction. The modelling and manufacturing framework for customising orthotic solutions was evaluated with a discussion on the feasibility of lightweight and high-performance products, encompassing production time and cost. Pilot products were produced with a Material Extrusion (MEX) printer. Findings: TO proved to be a practical and valuable approach for the advanced customisation of orthopaedic devices, offering lightweight solutions able to withstand stresses also during patient rehabilitation and remission. From the rapid prototyping perspective, specific strategies must be adopted to prevent the escalation of production costs and time. Originality: The research delves into the overall benefit of implementing an advanced modelling technique within the context of manufacturing highly customised orthoses, analysing how TO activity impacts the rapid prototyping process. Beyond product evaluation, the analysis explores broader implications, including the assessment of feasibility and the development of strategies for integrating the approach into clinical workflows and hospital settings. Full article

The intricate structure of human hands requires personalized orthotic treatments, especially with the growing aging population’s demand for accessible care. While traditional orthoses are effective, they face challenges of cost, customization time, and accessibility. Additive manufacturing, particularly material extrusion (MEX) techniques, can effectively address challenges in orthotic device production by enabling automated, complex, and cost-effective solutions. This work aims to provide engineers with a comprehensive set of design considerations for developing hand orthoses using MEX technology, focusing on applying design for additive manufacturing principles, to enhance rehabilitation outcomes. This objective is achieved by establishing design requirements for hand orthoses, reviewing design choices and methodologies across conventional and state-of-the-art MEX-based devices, and proposing an innovative approach to orthotic design. Hand orthosis design requirements were gathered through workshops with occupational therapists and categorized into engineer-, medical-, and patient-specific needs. A review of 3D-printed hand orthoses using MEX analyzes various design approaches, providing insights into existing solutions. The study introduces a modular design concept aimed at improving rehabilitation by enhancing customizability and functionality. It highlights the potential of MEX for creating personalized, cost-effective orthoses and offers recommendations for future research, to optimize designs and improve patient outcomes. Full article

In this study, specific additives were incorporated in polyhydroxyalcanoate (PHB) and polylactic acid (PLA) blend to improve its compatibility, and so enhance the cell metabolic activity of scaffolds for tissue engineering. The formulations were manufactured through material extrusion (MEX) additive manufacturing (AM) technology. As additives, petroleum-based poly(ethylene) with glicidyl metacrylate (EGM) and methyl acrylate-co-glycidyl methacrylate (EMAG); poly(styrene-co-maleic anhydride) copolymer (Xibond); and bio-based epoxidized linseed oil (ELO) were used. On one hand, standard geometries manufactured were assessed to evaluate the compatibilizing effect. The additives improved the compatibility of PHB/PLA blend, highlighting the effect of EMAG and ELO in ductile properties. The processability was also enhanced for the decrease in melt temperature as well as the improvement of thermal stability. On the other hand, manufactured scaffolds were evaluated for the purpose of bone regeneration. The mean pore size and porosity exhibited values between 675 and 718 μm and 50 and 53%, respectively. According to the results, the compression stress was higher (11–13 MPa) than the required for trabecular bones (5–10 MPa). The best results in cell metabolic activity were obtained by incorporating ELO and Xibond due to the decrease in water contact angle, showing a stable cell attachment after 7 days of culture as observed in SEM. Full article

Filament-based material extrusion (MEX) represents one of the most commonly used additive manufacturing techniques for polymer materials. In a special variation of this process, highly filled polymer filaments are used to create metal parts via a multi-step process. The challenges associated with creating a dense final part are versatile due to the different and partly contrary requirements of the individual processing steps. Especially for processing in MEX, the compound must show sufficiently low viscosity, which is often achieved by the addition of wax. However, wax addition also leads to a significant reduction in ductility. This can cause filaments to break, which leads to failure of the MEX process. Therefore, the present study investigates the influence of different ethylene–propylene copolymers (EPCs) with varying ethylene contents as a ductility-enhancing component within the feedstock to improve filament processing behavior. The resulting feedstock materials are evaluated regarding their mechanical, thermal and debinding behavior. In addition, the processability in MEX is assessed. This study shows that a rising ethylene content within the EPC leads to a higher ductility and an enhanced filament flexibility while also influencing the crystallization behavior of the feedstock. For the MEX process, an ethylene fraction of 12% within the EPC was found to be the optimum regarding processability for the highly filled filaments in MEX and the additional processing steps to create sintered metal parts. Full article

This study investigated the effect of two critical variables for environmental process sustainability, i.e., extruder temperature and printing rate, on thermomechanical performance and accuracy in overall sample sizes, when printing bio-based materials. In this context, 3D specimens produced from basic polylactide (n-PLA) and wood-filled PLA polymer (f-PLA) were realized using extrusion-based additive manufacturing technology (MEX) by varying the nozzle temperatures (200 °C, 210 °C, and 220 °C) and speed (from 70 mm/s to 130 mm/s). Dynamic mechanical analysis (DMA) was carried out on the produced specimens, providing information on changes in storage modulus at testing temperature of 30 °C (E′₃₀) and glass transition temperature (Tg) for each printing condition. Measurements of sample sizes allowed for printing precision considerations as a function of processing temperature and speed. The results revealed similar trends in E′₃₀ changes in printed specimens at a fixed extruder temperature as a function of printing speed for n-PLA and f-PLA. Infrared spectroscopy was performed on printed samples and unextruded material to attest potential material degradation under various operating conditions. Finally, images of sample surface allowed to verify the homogeneity of the diameter of the extruded material and the layer–layer contact at the interface. Full article

Metal additive manufacturing technologies such as powder bed fusion (PBF) and direct energy deposition (DED) are experiencing fast development, due to the growing awareness of industries. However, high energy consumption, slow production processes, and high costs of both machines and feedstocks hamper their competitiveness, compared to conventional manufacturing techniques. Metal material extrusion (metal-MEX) can represent a cost- and energy-effective alternative for metal additive manufacturing. This article aims to assess the potential of such technology by addressing uncertainties related to product design and process stability through a preliminary geometric benchmarking study. The geometric tolerances and minimum achievable sizes of some simple geometries produced in 316L stainless steel were evaluated using geometric benchmark test artifacts (GBTAs). Process maps were also proposed to forecast the feasibility of achieving acceptable values of the investigated tolerances, based on the nominal dimensions of the features. Full article

This research investigates the feasibility of manufacturing stamping devices using Material Extrusion (MEX) Additive Manufacturing (AM) technology, traditionally fabricated from metal, to reduce production costs and time. This study examines polymer-based devices subjected to Finite Element Analysis (FEA) to evaluate their performance in stamping metal sheets of varying thicknesses. The findings reveal that ABS polymer devices, while demonstrating potential, operate near the material’s limit under compression forces, particularly for sheet thicknesses up to 1 mm. Specifically, differences of 0.7 mm were observed at the connection radii of 0.25 mm sheets and 1.4 mm for 0.5 mm sheets, with angular deviations of 1.5 degrees for 0.25 mm sheets and 4 degrees for 0.5 mm sheets. Additionally, devices made of Nylon were deemed suitable for reduced-thickness sheets (0.25 mm), performing better than those made of ABS. These results suggest that while ABS devices exhibit significant deviations (up to 45 degrees for 1 mm sheets), the method shows promise for small batch production and prototyping. Further optimisation through material enhancements and mechanical improvements is recommended to minimise deformations and enhance precision. Full article

Material Extrusion (MEX) currently stands as the most widespread Additive Manufacturing (AM) process, but part quality deficiencies remain a barrier to its generalized industrial adoption. Quality control in MEX is a complex task as extrusion performance impacts the consistency of mechanical properties and the surface finish, dimensional accuracy, and geometric precision of manufactured parts. Recognizing the need for early-stage process monitoring, this study explores the potential of integrating Laser Triangulation Sensors (LTS) into MEX/P manufacturing equipment for layer-wise 3D inspections. Using a double-bridge architecture, an LTS-based sub-micrometric inspection system operates independently from the manufacturing process, enabling comprehensive digitization and autonomous reconstruction of the target layer’s topography. Surface texture is then computed using standardized indicators and a new approach that provides insight into layer quality uniformity. A case study evaluating two alternative extruder head designs demonstrates the efficacy of this integrated approach for layer quality characterization. Implementing a generalized layer-wise procedure based on this integration can significantly mitigate quality issues in MEX manufacturing and optimize process parameter configurations for enhanced performance. Full article

The additive manufacturing of components using material extrusion (MEX) enables the integration of several materials into one component, including functional structures such as electrically conductive structures. This study investigated the influence of the selected additive MEX process on the resistivity of MEX structures. Specimens were produced from filaments and granules of an electrically conductive PLA and filled with carbon nanotubes and carbon black. Specimens were produced with a full-factorial variation of the input variables: extrusion temperature, deposition speed, and production process. The resistivity of the specimens was determined by four-wire measurement. Analysis of the obtained data showed that only the extrusion temperature had a significant influence on the resistivity of the MEX specimens. Furthermore, the impact of the nozzle diameter was evaluated by comparing the results of this study with those of a previous study, with an otherwise equal experimental setup. The nozzle diameter had a significant influence on resistivity and a larger nozzle diameter reduced the mean variance by an order of magnitude. The resistivity was lower for most process parameter sets. As the manufacturing process had no significant influence on the resistivity of MEX structures, it can be selected based on other criteria, e.g., the cost of feedstock. Full article
