Magnetic targeting of drug carriers is commonly studied at macroscopic scales, while its impact on drug transport across individual cell membranes remains poorly quantified. Here, we present a theoretical and numerical model of magnetically assisted drug transport across the membrane of a single tumor cell exposed to magnetic field gradients. Extracellular transport is described by an advection–diffusion equation that couples passive diffusion with magnetophoretic drift, whereas intracellular transport is governed by diffusion and first-order uptake kinetics. The cell membrane is modeled as a semi-permeable interface with finite permeability, providing explicit coupling between extracellular and intracellular domains. Assuming spherical symmetry, the coupled transport equations are solved using finite-difference schemes, with magnetic forcing represented through an effective drift velocity $v_{\mathrm{m}\mathrm{a}\mathrm{g}}$ and interpreted using the magnetic Peclet number. To enable a controlled comparison between healthy and tumor cells, identical geometric, diffusive, and magnetic parameters are used, while biological differences are introduced solely through membrane permeability and intracellular uptake rates. By separating cumulative membrane delivery from cumulative intracellular uptake, the model resolves ambiguities arising from heterogeneous uptake kinetics. The results show that magnetophoretic drift enhances near-membrane drug accumulation and effective transmembrane flux without modifying intrinsic membrane properties. Magnetic targeting therefore acts as a transport amplifier, magnifying pre-existing biological differences and producing a larger model-predicted delivery advantage in tumor cells. Overall, the framework identifies the magnetic Peclet number as the key parameter governing the transition from diffusion-dominated to drift-enhanced cellular drug transport. Full article

Accurate malaria diagnosis is essential for effective case management and transmission control; however, the sensitivity, operational requirements, and field applicability of current conventional methods are limited. Hemozoin, an optically and magnetically active crystalline biomarker produced by Plasmodium species, offers a reagent-free target for next-generation diagnostics. This scoping review, following PRISMA-ScR and Joanna Briggs Institute guidance, synthesizes recent advances in hemozoin-based detection technologies and maps the current landscape. Twenty-four studies were reviewed, spanning eight major technology classes: magneto-optical platforms, magnetophoretic microdevices, photoacoustic detection, Raman/SERS spectroscopy, optical and hyperspectral imaging, NMR relaxometry, smartphone-based microscopy, and flow cytometry. Magneto-optical systems—including Hz-MOD, Gazelle™, and RMOD—demonstrated the highest operational readiness, with robust specificity but reduced sensitivity at low parasitemia. Photoacoustic Cytophone studies demonstrated promising sensitivity and noninvasive in vivo detection. Raman/SERS platforms achieved sub-100 infected cell/mL analytical sensitivity but remain laboratory-bound. Microfluidic and smartphone-based tools offer emerging, potentially low-cost alternatives. Across modalities, performance varied by parasite stage, with reduced detection of early ring forms. In conclusion, hemozoin-targeted diagnostics represent a rapidly evolving field with multiple viable translational pathways. While magneto-optical devices are closest to field deployment, further clinical validation, improved low-density detection, and standardized comparison across platforms are needed to support future adoption in malaria-endemic settings. Full article

In order to remove high-concentration emulsified oil from wastewater, a chitosan-based magnetic flocculant, denoted as FS@CTS-P(AM-DMC), was employed in this present study. The effects of factors including the magnetic flocculant dose, pH values, and coexisting ions were investigated. A comparative dosing mode with the assistance of polyacrylamide (PAM) was also included. The evolution of floc size was studied using microscopic observation to investigate the properties of flocs under different pH values and dosing modes. Particle image velocimetry (PIV) and extended Deryaguin–Landau–Verwey–Overbeek models were utilized to illustrate the distribution and velocity magnitude of the particle flow fields and to delve into the mechanism of magnetic flocculation. The results showed that FS@CTS-P(AM-DMC) achieved values of 96.4 and 74.5% for both turbidity and COD removal for 3000 mg/L of simulated emulsified oil. In the presence of PAM, the turbidity and COD removal reached 95.7 and 71.6%. In addition, FS@CTS-P(AM-DMC) demonstrated remarkable recycling and reusability performances, maintaining effective removal after eight cycles. The strength and recovery factors of magnetic flocs without PAM reached 69.3 and 76.8%, respectively. However, with the addition of PAM, they decreased to 46.73 and 51.47%, respectively. During the magnetophoretic processes, FS@CTS-P(AM-DMC) and oil droplets continuously collided and aggregated, forming three-dimensional network aggregates. Moreover, the magnetic floc generated a swirling motion, and the residual emulsified oil droplets could be further captured. Emulsified oil droplets were primarily removed through charge neutralization under acidic conditions. Under neutral and alkaline conditions, magnetic interactions played a major role in magnetic flocculation. Full article

Circulating tumor cells (CTCs) display antigenic heterogeneity between epithelial and mesenchymal phenotypes. However, most current CTC isolation methods rely on EpCAM (epithelial cell adhesion molecule) antibodies. This study introduces a more efficient CTC isolation technique utilizing both EpCAM and vimentin (mesenchymal cell marker) antibodies, alongside a lateral magnetophoretic microseparator. The effectiveness of this approach was assessed by isolating CTCs from prostate (n = 17) and pancreatic (n = 5) cancer patients using EpCAM alone, vimentin alone, and both antibodies together. Prostate cancer patients showed an average of 13.29, 11.13, and 27.95 CTCs/mL isolated using EpCAM alone, vimentin alone, and both antibodies, respectively. For pancreatic cancer patients, the averages were 1.50, 3.44, and 10.82 CTCs/mL with EpCAM alone, vimentin alone, and both antibodies, respectively. Combining antibodies more than doubled CTC isolation compared to single antibodies. Interestingly, EpCAM antibodies were more effective for localized prostate cancer, while vimentin antibodies excelled in metastatic prostate cancer isolation. Moreover, vimentin antibodies outperformed EpCAM antibodies for all pancreatic cancer patients. These results highlight that using both epithelial and mesenchymal antibodies with the lateral magnetophoretic microseparator significantly enhances CTC isolation efficiency, and that antibody choice may vary depending on cancer type and stage. Full article

The timely detection and diagnosis of diseases and accurate monitoring of specific genetic conditions require rapid and accurate separation, sorting, and direction of target cell types toward a sensor device surface. In that regard, cellular manipulation, separation, and sorting are progressively finding application potential within various bioassay applications such as medical disease diagnosis, pathogen detection, and medical testing. The aim of this paper is to present the design and development of a simple traveling wave ferro-microfluidic device and system rig purposed for the potential manipulation and magnetophoretic separation of cells in water-based ferrofluids. This paper details in full: (1) a method for tailoring cobalt ferrite nanoparticles for specific diameter size ranges (10–20 nm), (2) the development of a ferro-microfluidic device for potentially separating cells and magnetic nanoparticles, (3) the development of a water-based ferrofluid with magnetic nanoparticles and non-magnetic microparticles, and (4) the design and development of a system rig for producing the electric field within the ferro-microfluidic channel device for magnetizing and manipulating nonmagnetic particles in the ferro-microfluidic channel. The results reported in this work demonstrate a proof of concept for magnetophoretic manipulation and separation of magnetic and non-magnetic particles in a simple ferro-microfluidic device. This work is a design and proof-of-concept study. The design reported in this model is an improvement over existing magnetic excitation microfluidic system designs in that heat is efficiently removed from the circuit board to allow a range of input currents and frequencies to manipulate non-magnetic particles. Although this work did not analyze the separation of cells from magnetic particles, the results demonstrate that non-magnetic (surrogates for cellular materials) and magnetic entities can be separated and, in some cases, continuously pushed through the channel based on amperage, size, frequency, and electrode spacing. The results reported in this work establish that the developed ferro-microfluidic device may potentially be used as an effective platform for microparticle and cellular manipulation and sorting. Full article

Identification of circulating tumor cells (CTCs) from a majority of various cell pools has been an appealing topic for diagnostic purposes. This study numerically demonstrates the isolation of CTCs from blood cells by the combination of dielectrophoresis and magnetophoresis in a microfluidic chip. Taking advantage of the label-free property, the separation of red blood cells, platelets, T cells, HT-29, and MDA-231 was conducted in the microchannel. By using the ferromagnet structure with double segments and a relatively shorter distance in between, a strong gradient of the magnetic field, i.e., sufficiently large MAP forces acting on the cells, can be generated, leading to a high separation resolution. In order to generate strong DEP forces, the non-uniform electric field gradient is induced by applying the electric voltage through the microchannel across a pair of asymmetric orifices, i.e., a small orifice and a large orifice on the opposite wall of the channel sides. The distribution of the gradient of the magnetic field near the edge of ferromagnet segments, the gradient of the non-uniform electric field in the vicinity of the asymmetric orifices, and the flow field were investigated. In this numerical simulation, the effects of the ferromagnet structure on the magnetic field, the flow rate, as well as the strength of the electric field on their combined magnetophoretic and dielectrophoretic behaviors and trajectories are systemically studied. The simulation results demonstrate the potential of both property- and size-based cell isolation in the microfluidic device by implementing magnetophoresis and dielectrophoresis. Full article

The separation and purification of a sample of interest is essential for subsequent detection and analysis procedures, but there is a lack of effective separation methods with which to purify nano-sized particles from the sample media. In this paper, a microfluidic system based on negative magnetophoresis is presented for the high-resolution separation of nanoparticles. The system includes on-chip magnetic pole arrays and permalloys that symmetrically distribute on both sides of the separation channel and four permanent magnets that provide strong magnetic fields. The microfluidic system can separate 200 nm particles with a high purity from the mixture (1000 nm and 200 nm particles) due to a magnetic field gradient as high as 10,000 T/m being generated inside the separation channel, which can provide a negative magnetophoretic force of up to 10 pN to the 1000 nm particle. The overall recovery rate of the particles reaches 99%, the recovery rate of 200 nm particles is 84.2%, and the purity reaches 98.2%. Compared with the existing negative magnetophoretic separation methods, our system not only exhibits high resolution on particle sizes (800 nm), but also improves the sample processing throughput, which reaches 2.5 μL/min. The microfluidic system is expected to provide a new solution for the high-purity separation of nanoparticles, as well as nanobiological samples. Full article

Magnetic nanoparticles (MNPs) are used for magnetophoresis-based separation processes in various biomedical and engineering applications. Essential requirements are the colloidal stability of the MNPs and the ability to be separated even in low magnetic field gradients. Bare iron oxide nanoparticles (BIONs) with a diameter of 9.2 nm are synthesized via coprecipitation, exhibiting a high saturation magnetization of 70.84 Am² kg⁻¹ and no remanence. In our study, zeta potential, dynamic light scattering (DLS), and sedimentation analysis show that the aggregation behavior of BIONs is influenced by pH and viscosity. Small aggregate clusters are formed with either low or high pH values or increased viscosity. Regarding magnetophoresis-based separation, a higher viscosity leads to lower magnetophoretic velocities, similar to how small aggregates do. Additionally, cooperative magnetophoresis, the joint motion of strongly interacting particles, affects the separation of the BIONs, too. Our study emphasizes the effect of pH and viscosity on the physicochemical characteristics of MNPs, resulting in different aggregation behavior. Particularly, for high viscous working media in downstream processing and medicine, respectively, the viscosity should be taken into account, as it will affect particle migration. Full article

Due to the low frequency of circulating tumor cells (CTC), the standard CellSearch method of enumeration and isolation using a single tube of blood is insufficient to measure treatment effects consistently, or to steer personalized therapy. Using diagnostic leukapheresis this sample size can be increased; however, this also calls for a suitable new method to process larger sample inputs. In order to achieve this, we have optimized the immunomagnetic enrichment process using a flow-through magnetophoretic system. An overview of the major forces involved in magnetophoretic separation is provided and the model used for optimizing the magnetic configuration in flow through immunomagnetic enrichment is presented. The optimal Halbach array element size was calculated and both optimal and non-optimal arrays were built and tested using anti-EpCAM ferrofluid in combination with cell lines of varying EpCAM antigen expression. Experimentally measured distributions of the magnetic moment of the cell lines used for comparison were combined with predicted recoveries and fit to the experimental data. Resulting predictions agree with measured data within measurement uncertainty. The presented method can be used not only to optimize magnetophoretic separation using a variety of flow configurations but could also be adapted to optimize other (static) magnetic separation techniques. Full article

Magneto-plasmonic nanocomposites can possess properties inherent to both individual components (iron oxide and gold nanoparticles) and are reported to demonstrate high potential in targeted drug delivery and therapy. Herein, we report on Fe₃O₄/Au magneto-plasmonic nanocomposites (MPNC) synthesized with the use of amino acid tryptophan via chemical and photochemical reduction of Au ions in the presence of nanosized magnetite. The magnetic field (MF) induced aggregation was accompanied by an increase in the absorption in the near-infrared (NIR) spectral region, which was demonstrated to provide an enhanced photothermal (PT) effect under NIR laser irradiation (at 808 nm). A possibility for therapeutic application of the MPNC was illustrated using cancer cells in vitro. Cultured HeLa cells were treated by MPNC in the presence of MF and without it, following laser irradiation and imaging using confocal laser scanning microscopy. After scanning laser irradiation of the MPNC/MF treated cells, a formation and rise of photothermally-induced microbubbles on the cell surfaces was observed, leading to a damage of the cell membrane and cell destruction. We conclude that the synthesized magneto-plasmonic Fe₃O₄/Au nanosystems exhibit magnetic field-induced reversible aggregation accompanied by an increase in NIR absorption, allowing for an opportunity to magnetophoretically control and locally enhance a NIR light-induced thermal effect, which holds high promise for the application in photothermal therapy. Full article

The sizes of most prokaryotic cells are several microns. It is very difficult to separate cells with similar sizes. A sorter with a contraction–expansion microchannel and applied magnetic field is designed to sort microparticles with diameters of 3, 4 and 5 microns. To evaluate the sorting efficiency of the designed sorter, numerical simulations for calculating the distributions of microparticles with similar sizes were carried out for various magnetic fields, inlet velocities, sheath flow ratios and structural parameters. The numerical results indicate that micro-particles with diameters of 3, 4 and 5 microns can be sorted efficiently in such a sorter within appropriate parameters. Furthermore, it is shown that a bigger particle size and more powerful magnetic field can result in a greater lateral migration of microparticles. The sorting efficiency of microparticles promotes a lower inlet velocity and greater sheath flow ratios. A smaller contraction–expansion ratio can induce a greater space between particle-bands. Finally, the micro particle image velocity (micro-PIV) experiments were conducted to obtain the bandwidths and spaces between particle-bands. The comparisons between the numerical and experimental results show a good agreement and make the validity of the numerical results certain. Full article

In this work, the harvesting of Nannochloropsis oculata microalgae through the use of nanosized Fe₃O₄ immobilized in polyvinyl alcohol (PVA)/sodium alginate (SA) as a flocculant (Fe₃O₄/PS) is investigated. Using the Fe₃O₄/PS immobilized beads could reduce the amount of soluble ferrous ions (Fe²⁺) released from naked Fe₃O₄ in acid treatment, leading to easy recovery. The characterization was performed under different dosages and pH values of Fe₃O₄/PS. The results show that the Fe₃O₄/PS, when applied to the algae culture (500 mg dry cell weight/L), achieves a 96% harvesting efficiency under conditions of a pH of 4 with 200 mT magnetic field intensity. Fe₃O₄/PS can be directly reused without adjusting the pH value. The recycled Fe₃O₄/PS shows stability in terms of its surface properties, maintaining more than 80% harvesting efficiency after five recycles. Magnetophoretic harvesting, using immobilized magnetic iron oxide as a particle-based flocculant, is a potential method to reduce challenges related to the cost-effective microalgae-harvesting method. Full article

Ferrofluid is a colloidal liquid in which magnetic nanoparticles such as Fe₃O₄ are dispersed in a nonconductive solution, and the average diameter of the nanoparticles is 10 nm. When a magnetic field is applied, the ferrofluid generates magnetization, which changes the physical properties of the fluid itself. In this study, characteristics of the thermomagnetic convection of ferrofluid (Fe₃O₄) by the permanent magnet in the enclosure channel were studied. To effectively mix the ferrofluid (Fe₃O₄) and disturb the boundary layer, the heat dissipation of the heat source depending on the strength of the magnetic field and the shape of the enclosure channel was numerically studied. In particular, four different enclosure channels were considered: Square, separated square, circle, and separated circle. The hot temperature was set at the center of the enclosure channel. The ferrofluid was affected by the permanent magnet in the center of the channel. The magnetic field strength in the region close to the permanent magnet was enhanced. The magnetophoretic (MAP) force increased with increasing magnetic field strength. The MAP force generated a vortex in the enclosure channel, disturbing the thermal boundary. The vortex occurs differently, depending on the shape of the enclosure channel and affects the thermomagnetic convection. The temperature and velocity fields for thermomagnetic convection were described and the convective heat flux was calculated and compared. Results show that when the magnetic field strength was 4000 kA/m and the shape of the enclosure channel was a circle, the maximum convective heat flux of 4.86 × 10⁵ W/m² was obtained. Full article

Droplet microfluidics is a promising tool for single-cell analysis since single cell can be comparted inside a tiny volume. However, droplet encapsulation of single cells still remains a challenging issue due to the low ratio of droplets containing single cells. Here, we introduce a simple and robust single cell sorting platform based on a magnetophoretic method using monodisperse magnetic nanoparticles (MNPs) and droplet microfluidics with >94% purity. There is an approximately equal amount of MNPs in the same-sized droplet, which has the same magnetic force under the magnetic field. However, the droplets containing single cells have a reduced number of MNPs, as much as the volume of the cell inside the droplet, resulting in a low magnetic force. Based on this simple principle, this platform enables the separation of single cell-encapsulated droplets from the droplets with no cells. Additionally, this device uses only a permanent magnet without any complex additional apparatus; hence, this new platform can be integrated into a single cell analysis system considering its effectiveness and convenience. Full article
