Search Results (176)

This research is concerned with design optimization of control systems. Our case study deals with magnetic levitation, in which an essential part is a solenoid. Its dimensions, along with controller parameters, form the optimization variables. We present a novel way of writing the explicit expression of the solenoid’s force acting on a magnetic dipole, as well as its first derivatives. Numerical tests using non-gradient search algorithms show the difference in optimal designs provided by these methods. Since such optimization depends on output signals, a comparison of step response analysis methods is presented. Full article

At present, the redundant structures are one of the most effective methods for solving magnetic levitation bearing coil failure. Coil failure causes residual effective magnetic poles to form different support structures and even asymmetrical structures. For the magnetic bearing with redundant structures, how to construct the electromagnetic force (EMF) that occurs under different support structures to achieve support reconstruction is the key to realizing fault tolerance control. To reveal the support reconstruction mechanism of magnetic bearing with a redundant structure, firstly, this paper takes a single-degree-of-freedom magnetic suspension body as an example to conduct a linearization theory analysis of the offset current, clarifying the concept of the current distribution matrix (CDM) and its function; then, the nonlinear EMF mode of magnetic bearing with an eight-pole is constructed, and it is linearized by using the theory of bias current linearization. Furthermore, the conditions of no coils fail, the 8th coil fails, and the 6–8th coils fail are considered, and, with the maximum principle function of EMF, the corresponding current matrices are obtained. Meanwhile, based on the CDM, the corresponding magnetic flux densities were calculated, proving that EMF reconstruction can be achieved under the three support structures. Finally, with the CDM and position control law, a fault-tolerant control system was constructed, and the simulation of the magnetic bearing with a redundant structure was carried out. The simulation results reveal the mechanism of support reconstruction with three aspects of rotor displacement, the value and direction of currents that occur in each coil. The simulation results show that, in the 8-pole magnetic bearing, this study can achieve support reconstruction in the case of faults in up to two coils. Under the three working conditions of wireless no coil failure, the 8th coil fails and the 6–8th coils fail, the current distribution strategy was adjusted through the CDM. The instantaneous displacement disturbance during the support reconstruction process was less than 0.28 μm, and the EMF after reconstruction was basically consistent with the expected value. Full article

The permanent magnet electrodynamic suspension system (PMEDS) has demonstrated significant advantages in high-speed and ultra-high-speed applications due to its simple structure, low cost, and stable levitation force. However, the weak damping characteristic remains a critical issue limiting its practical implementation. This work investigates a passive damping plate utilizing the end field of onboard magnets, focusing on magnet-damping plate optimization and vehicle dynamics. Firstly, the configuration, operation principles, and electromagnetic parameters of the PMEDS vehicle are elucidated. Secondly, the dependences of magnet-conductive plate specifications on the damping force are examined. An optimization index based on the levitation-to-damping force ratio is proposed to enable collaborative optimization of magnet and conductive plate parameters. Finally, the vehicle dynamic model is developed using Simpack software to investigate payload and speed effects on dynamic responses under random track excitation, validating the effectiveness of the proposed passive damping solution. This study provides technical references for the design, engineering applications, and performance evaluation of passive damping schemes in PMEDS vehicles. Full article

Magnetic levitation enables the confinement and melting of conductive metals using alternating magnetic fields, eliminating the need for a crucible or other contact supports. This makes the technology particularly suitable for applications where container use is impractical, such as preventing contamination between the melt and the crucible, handling high-purity materials, or facilitating in-orbit operations. For a given coil design and load, selecting the appropriate feeding parameters, such as the current and frequency, is crucial to ensure the correct operation of the device. This study investigates the optimal current and frequency values required to levitate an aluminum billet using a proposed longitudinal electromagnetic levitator, which represents an initial prototype of a more complex system for automated material manipulation. The analysis was conducted through 2D and 3D finite element method (FEM) simulations, assessing the equilibrium position and stability with respect to translations and rotations under various operating conditions. The study identifies an operating configuration that ensures vertical stability while minimizing excessive heating, in order to obtain a sufficiently long confinement time before the melting point is reached. A fully coupled 2D thermal simulation was then performed to assess the billet’s heating rate under the selected operating conditions. Finally, an experiment was conducted on a prototype to confirm billet levitation. Full article

Extracorporeal membrane oxygenation (ECMO) is a crucial life support therapy for patients with severe cardiac and respiratory failure. However, the complications associated with venoarterial ECMO (VA-ECMO), including thrombus formation, bleeding, and hemolysis, remain significant challenges that impact patient outcomes and healthcare costs. These complications primarily arise from blood–material interactions within the ECMO circuit, necessitating the development of biocompatible materials to optimize hemocompatibility. This review provides an updated overview of the latest advancements in VA-ECMO materials, focusing on cannula, oxygenators, and centrifugal pumps. Various surface modifications, such as heparin coatings, nitric oxide-releasing polymers, phosphorylcholine (PC)-based coatings, and emerging omniphobic surfaces, have been explored to mitigate thrombosis and bleeding risks. Additionally, novel oxygenator membrane technologies, including zwitterionic polymers and endothelial-mimicking coatings, offer promising strategies to enhance biocompatibility and reduce inflammatory responses. In centrifugal pumps, magnetic levitation systems and hybrid polymer-composite impellers have been introduced to minimize shear stress and thrombogenicity. Despite these advancements, no single material has fully addressed all complications, and further research is needed to refine surface engineering strategies. This review highlights the current progress in ECMO biomaterials and discusses future directions in developing more effective and durable solutions to improve patient safety and clinical outcomes. Full article

This paper proposes an A-shape hybrid levitation system combining high-temperature superconducting (HTS) maglev and permanent magnet levitation (PML) technologies to address the lateral instability of the PML system. By tilting the PM arrays and HTS bulks on both sides at a specific angle, the system’s cross-section forms an “A” shape. This configuration offers dual advantages: the A-shape PML significantly mitigates unstable lateral deflection forces while preserving levitation capacity, whereas the A-shape HTS maglev enhances guidance force. Through systematic analysis, the effects of the tilt angle and the magnetization direction of the PM arrays on levitation performance are investigated and optimized. The simulation results demonstrate that, at the lateral movement of 5 mm, for the PML system, a tilt angle of 45° reduces lateral deflection force by 94.4%, and synergistic optimization of the tilt angle of 40° and magnetization direction of 38° achieves an 84.6% reduction. The HTS maglev system enhances guidance force, with a 45.3% improvement at a 60° tilt angle and a 30° magnetization direction. This study presents a promising solution for developing a stable, high-load-capacity hybrid levitation system. Full article

Magnetic levitation (maglev) technology offers significant advantages for rail transport, including frictionless propulsion, reduced noise, and lower maintenance costs. However, its widespread adoption has been limited due to the need for a dedicated infrastructure incompatible with conventional rail networks. The MaDe4Rail project, funded by Europe’s Rail Joint Undertaking (ERJU), explores Maglev-Derived Systems (MDSs) as means to integrate maglev-inspired solutions into existing railway corridors with minimal modifications. This paper focuses on the so-called “hybrid MDS” configuration, which refers to levitating systems that can operate on existing rail infrastructure. Unlike current maglev systems, which require dedicated tracks, the proposed MDS system is designed to operate on conventional rail tracks, allowing for its compatibility with traditional trains and ensuring the interoperability of lines. In order to identify the most viable solution, two different configurations have been analysed. The evaluated scenario could benefit from the introduction of hybrid MDSs based on magnetic levitation, where a group of single vehicles, also called pods, is used in a virtual coupling configuration. The objective of this case study is to increase the capacity of traffic on the existing railway line by significantly reducing travel time, while maintaining a similar energy consumption to that of the current conventional trains operating on this line. Simulation results indicate that the hybrid MDS can optimise railway operations by taking advantage of virtual coupling to improve traffic flow, reducing travel times and energy consumption with the optimisation of the aerodynamic drag. The system achieves a balance between increased speed and energy efficiency, making it a viable alternative for future rail transport. An initial cost–benefit analysis suggests that the hybrid MDS could deliver substantial economic advantages, positioning it as a promising solution for enhancing European railway networks with minimal infrastructure investment. Full article

Aiming at the high-precision torque output and saturation singularity avoidance problems in Lorentz force magnetic bearing (LFMB) swarms for magnetic levitation spacecraft, this study designs a manipulation law based on an adaptive weighted pseudo-inverse law. The system monitors each magnetic bearing’s working state in real time using high-precision position and current sensors. As the key input for the adaptive weighted pseudo-inverse control law, the sensor data’s measurement accuracy directly determines torque distribution effectiveness and attitude control precision. First, considering electromagnetic back-EMF effects, individual LFMB dynamics are modeled via the equivalent magnetic circuit method, with working principles elucidated. Subsequently, saturation coefficients for LFMB swarms are designed. Incorporating spacecraft maneuvering requirements, a genetic optimization algorithm establishes the optimal mounting configuration under task constraints. Considering the LFMB swarm configuration characteristics, this study proposes an adaptive weighted pseudo-inverse maneuvering law tailored to operational constraints. By designing an adaptive weighting matrix, the maneuvering law adjusts each LFMB’s torque output in real time, reducing residual saturation effects on attitude control speed and accuracy. Simulation results demonstrate that the proposed mounting configuration and adaptive weighted pseudo-inverse maneuvering law effectively mitigate saturation singularity’s impact on attitude control accuracy while reducing total energy consumption by 22%, validating the method’s effectiveness and superiority. Full article

This study aims to investigate the performance of a Maglev Vortex Rotor Organic Rankine Cycle (ORC) system for low-temperature waste heat recovery. The primary objective is to evaluate the net power generation and efficiency of the system under actual operating conditions. This study designed and constructed a novel magnetic levitation ORC system, which directly measures the net power generation under actual operating conditions. The system uses R245fa as the working fluid and was tested over a 20-day period. Linear regression analysis was employed to model the net power generation as a function of system operating time. The experimental results indicate that the net power generation of the ORC system increased from −186.9 to 70,290 kW·h over the 20-day period. The slope value obtained from linear regression analysis is 0.5962, with R-squared and adjusted R-squared values both at 0.9999, indicating a strong linear relationship. The net power generation can be approximated by a linear function, starting with a negative initial value and increasing stably with the increase in system operating time. The efficiency of waste heat power generation reached 10.03%. The Maglev Vortex Rotor ORC system demonstrates a significant improvement in net power generation and efficiency compared to traditional ORC systems. The system’s performance is highly stable and reliable, making it a promising technology for low-temperature waste heat recovery. Full article

The installation distance between the speed sensor of the traditional rolling or sliding bearing permanent magnet synchronous motor and the rotor was very close, and the rotor of the magnetic levitation motor supported by Active Magnetic Bearings (AMBs) was in suspension. When the motor was running at high speed, the radial trajectory of the rotor changed all the time. The same frequency vibration caused by the unbalanced mass of the rotor made it easy to cause mechanical collision between the sensor and the rotor, resulting in direct damage of the sensor. Therefore, the sensorless speed estimation method was needed for the rotor control system of the magnetic levitation motor (MLM) to achieve high performance closed-loop control of speed and position. More importantly, in order to control or compensate the unbalanced force of the electromagnetic bearing rotor system, the rotor rotation speed signal should be obtained as accurately as possible. Therefore, the principle of adaptive sliding mode observer (SMO) was analyzed in detail by taking the rotor system of MLM as an example. Then, the sliding mode surface was designed, the speed estimation algorithm based on adaptive SMO was derived, and the stability analysis was completed. Finally, in order to verify the anti-disturbance performance of the system and the static and dynamic tracking performance of the motor, the dynamic performance was verified by increasing and decreasing the speed and load. The results showed that the speed estimation method based on adaptive SMO could achieve accurate speed estimation and had good static and dynamic performance. Full article

Background and Objectives: Pediatric ECMO is a valid support mechanism for refractory cardiac and/or respiratory failure. Magnetic levitation technology applied to the centrifugal pump has reduced the hemolysis caused by this procedure, which can be particularly dangerous, especially in neonates and small children. ECMOLife, a new magnetic levitation centrifugal pump, has been introduced for these patients. Materials and Methods: Four patients were supported with the ECMOLife System in a newborn setting, with veno-venous application in two cases and veno-arterial in the other two. All parameters related to pump functioning, anticoagulation, hemolysis, and inflammation were recorded for the duration of the support. Results: All patients survived the procedure, in three cases achieving recovery, while one veno-arterial ECMO was switched to VAD, and then the patient underwent heart transplantation. All recorded parameters were compatible with clinical conditions. In particular, free haemoglobin was close to 0 g/L in all recorded samples. The possibility of monitoring pump functioning parameters, venous and arterial O2 saturation, and venous and arterial pressures creates an opportunity to check the adequacy of mechanical support for the clinical condition of the patient. Conclusions: This is the first reported experiment in a newborn setting with ECMOLife mechanical support. At present, ECMOLife represents the only system with a newborn and pediatric pump, allowing for the continuous monitoring of perfusion and hemodynamic parameters, with a large number of facilities for transportation available. Full article

The majority of electromagnetic force calculation models employed in maglev vehicle system dynamics focus exclusively on vertical and lateral movement while neglecting the nonlinear magnetization properties of ferromagnetic materials. This oversight leads to discrepancies between the dynamics simulations and actual conditions. To enhance the accuracy of dynamics simulations and evaluate the performance of maglev vehicle systems under various operational conditions, it is imperative to identify an electromagnetic force calculation model that combines accuracy and applicability. To address this objective, this paper examines a U-shaped electromagnet in medium–low-speed maglev vehicles as a case study. It constructs a spatial electromagnetic force calculation surrogate model using a Shallow Neural Network. The surrogate model is capable of accurately calculating electromagnetic forces considering relative position deviations in the lateral, vertical, rolling, pitching, and shaking directions. Moreover, it can be integrated into vehicle system dynamics simulations. The accuracy of the electromagnetic force calculation surrogate model is confirmed by extensive comparisons with finite element simulation results across various conditions, achieving an impressive concordance rate of up to 95%. An illustrative application of the electromagnetic force calculation surrogate model in maglev vehicle system dynamics simulation is provided to showcase its practical utility. Full article

One of the most important contributions of modern control theory from the 1960s was the separation of the dynamics of state-space controller design from the dynamics of state reconstruction. However, because modern control theory predates the mass spread of digital controllers and was predominantly focused on analog solutions that avoided modeling dead-time elements, it cannot effectively cover all aspects that emerged with the development of programmable devices and embedded systems. The same historical limitations also characterized the development of proportional-integral-derivative (PID) controllers, which began several decades earlier. Although they were used to control time-delayed systems, these solutions, which are most commonly used in practice today, can also be referred to as simplified disturbance observers that allow the avoidance of the the direct use of dead-time models. Using the example of controlling systems with a double integrator plus dead-time model, this article shows a novel controller design that significantly improves control performance compared to conventional PID controllers. The new control structure is a combination of a generalized state-space controller, interpreted as a higher-order derivative controller, and a predictive disturbance observer that uses the inversion of double integrator dynamics and dead-time models. It enables the elimination of the windup effect that is typical for PID control and extends the separation of the dynamics of setpoint tracking from the dynamics of state and disturbance reconstruction to time-delayed processes as well. The novelty of the presented solution offers several orders of magnitude lower amplification of measurement noise compared to traditional PID control. On the other hand, it offers high robustness and a stable transient response despite the unstable internal feedback of processes like the magnetic levitation system. The improvements achieved are so high that they call into question the classical solutions with PID controllers, at least for DIPDT models. In addition to the comparison with PID control, the relationship with traditional state space controllers, which today form the basis of active disturbance rejection control (ADRC), is also discussed and examined for processes including dead time. Full article

Featured with optimal power consumption, active magnetic bearings (AMBs) have been extensively integrated into turbomachinery applications. For turbomachinery components, including the rotor and impeller, their connection is generally based on bolted joints, which would easily induce excessive interface contact. As a result, the pre-tightening torque can induce modal vibrations in the rotor upon levitation. Although a notch filter can be adopted to suppress the vibrations, it should be noted that the current reported notch filters are based on fixed center frequency, making it challenging to enable high effectiveness over a broad range of rotor speeds, particularly in cases where the gyroscopic effect is significant. Herein, a modal vibration suppression based on a varying-frequency notch filter is proposed, considering gyroscopic effect and interface contact. First, the rotor–AMB system was developed, taking into consideration the bolted-joint interface contact. This modeled the effect of the interface contact as a time-varying force in the positive feedback. Secondly, the relationship between vibration frequency and rotational speed was obtained, based on simulations. Lastly, a test rig was configured to validate the performance of the frequency-varying notch filter. The experimental data confirm that the filter is capable of attenuating the modal vibrations resulting from interface contact across all operational speeds. Full article

The working accuracy of space optical payloads and sensitive components carried on space aircraft greatly depends on the pointing accuracy and stability of the platform. Based on Disturbance Free Payload (DFP) technology, non-contact maglev technology is proposed in this paper, achieving dynamic and static isolation of the platform module and payload module, so that the vibration and interference of the platform module with movable and flexible components will not be transmitted to the payload module, thereby achieving the effect of vibration isolation. High-precision active control of the payload module is adopted at the same time; the platform module follows the master–slave collaborative control strategy of the payload module, meeting the requirements of high-performance payloads. A primary and backup redundant controller is designed, using a one-to-four architecture. The control board achieves high-speed and high-precision driving current control, voltage output, and outputs current feedback signal sampling. Based on uniform magnetic field design, high-precision force control performance is ensured by adjusting current accuracy. Interdisciplinary joint simulation of electric, magnetic, and structural aspects was conducted on the magnetic levitation isolation system. By conducting physical testing and calibration and designing a testing and calibration system, it has been proven that the system meets the design requirements, achieving high-precision current control technology of 0.15 mA and driving force control technology of 0.5 mN. Full article
