Search Results (78)

In optical one-dimensional grating-on-layer planar structures, an optical resonance occurs when the incident light wave becomes phase-matched to a leaky waveguide mode excited in the layer underneath the grating by an appropriate tuning of the grating periodicity. Changing the refractive indices of the grating’s constituents, and/or thickness, changes the resonance frequency. In the case of a two-dimensional grating atop such a smooth layer, a similar and also cavity-mode resonance can occur. This idea has straightforward usage in diverse optical sensor applications. In this study, a novel guided-mode resonance sensor design for detecting glucose and hemoglobin in minute concentrations at a wide range of incidence angles is presented. In this design, materials of the grating, such as a polymer and cesium-lead halide with a perovskite crystal structure, are examined, which will allow flexible, low-cost fabrication by soft-lithography/imprint-lithography methods. The sensitivity, figure of merit, and quality factor are reported for one- and two-dimensional grating structures. The simulations performed are based on rigorous coupled-wave analysis. Optical resonance quality factor of ∼$5·{10}^5$ is achieved at oblique incidence for a structure comprising a one-dimensional grating etched in a poly-vinylidene chloride layer atop a silicon nitride waveguide layer on a substrate. Record values of the above-noted characteristics are achieved with a synergetic interplay of the materials, structural dimensions, incidence angle, polarization, and grating geometry. Full article

Micro-motors are essential for power drive systems, and efficient fault diagnosis is crucial to reduce safety risks and economic losses caused by failures. However, the fault signals from micro-motors typically exhibit weak and unclear characteristics. To address this challenge, this paper proposes a novel fault diagnosis method that integrates jump plus AM-FM mode decomposition (JMD), symmetrized dot pattern (SDP) visualization, and an improved convolutional neural network (ICNN). Firstly, we employed the jump plus AM-FM mode decomposition technique to decompose the mixed fault signals, addressing the problem of mode mixing in traditional decomposition methods. Then, the intrinsic mode functions (IMFs) decomposed by JMD serve as the multi-channel inputs for symmetrized dot pattern, constructing a two-dimensional polar coordinate petal image. This process achieves both signal reconstruction and visual enhancement of fault features simultaneously. Finally, this paper designed an ICNN method with LeakyReLU activation function to address the vanishing gradient problem and enhance classification accuracy and training efficiency for fault diagnosis. Experimental results indicate that the proposed JMD-SDP-ICNN method outperforms traditional methods with a significantly superior fault classification accuracy of up to 99.2381%. It can offer a potential solution for the monitoring of electromechanical structures under complex conditions. Full article

The propagation of interface acoustic waves (IAWs) along rotated YX-LiNbO₃/SU-8/ZX-Si structures is theoretically investigated to identify the Y-rotation angles that support the efficient propagation of low-loss modes guided along the structure’s interface. A three-dimensional finite element analysis was performed to simulate IAW propagation in the layered structure and to optimize design parameters, specifically the thicknesses of the platinum (Pt) interdigital transducers (IDTs) and the SU-8 adhesive layer. The simulations revealed the existence of two types of IAWs travelling at different velocities under specific Y-rotated cuts of the LiNbO₃ half-space. These IAWs are faster than the surface acoustic wave (SAW) and slower than the leaky SAW (LSAW) propagating on the surface of the bare LiNbO₃ half-space. The mechanical displacement fields of both IAWs exhibit a rapid decay to zero within a few wavelengths from the LiNbO₃ surface. The piezoelectric coupling coefficients of the IAWs were found to be as high as approximately 7% and 31%, depending on the Y-rotation angle. The theoretical results were experimentally validated by measuring the velocities of the SAW and LSAW on a bare 90° YX-LiNbO₃ substrate, and the velocities of the IAWs in a 90° YX-LiNbO₃/SU-8/Si structure featuring 330 nm thick Pt IDTs, a 200 µm wavelength, and a 15 µm thick SU-8 layer. The experimental data showed good agreement with the theoretical predictions. These combined theoretical and experimental findings establish design principles for exciting two interface waves with elliptical and quasi-shear polarization, offering enhanced flexibility for fluidic manipulation and the integration of sensing functionalities. Full article

Graphene interfaces in layered dielectrics can support unique electromagnetic modes, but analyzing these modes requires robust computational techniques. This work presents a numerical method for computing TE-polarized eigenmodes in a planar stratified dielectric slab with an infinitesimally thin graphene sheet at its interface. The governing boundary-value problem is reformulated as coupled initial-value problems and solved via a customized shooting method, enabling accurate calculation of complex propagation constants and field profiles despite the discontinuity at the graphene layer. We demonstrate that the graphene significantly alters the modal spectrum, introducing complex leaky and surface waves with attenuation due to graphene’s conductivity. Numerical results illustrate how the layers’ inhomogeneity and the graphene’s surface conductivity influence mode confinement and loss. These findings confirm the robustness of the proposed computational approach and provide insights relevant to the design and analysis of graphene-based waveguiding devices. Full article

This paper proposes a miniaturized frequency-scanning antenna with high scanning rate. To overcome the OSB (open stopband) of traditional leaky wave antenna, CRLH-TL (Composite Right/Left-Handed-Transmission Line) is adopted. Furthermore, an antenna unit consisting of two symmetrically curved microstrip lines with two short branches is employed, whose second mode exhibits excellent transmission characteristics. The measurements demonstrate that the antenna can achieve scanning from −67.5° to 35.5° in the frequency band range of 5.65–6.5 GHz, with a scanning rate of 7.3. During scanning, the highest gain in the band is 12.3 dBi, the lowest is 10 dBi, and the gain fluctuation is within 2.3 dB, showing good scanning characteristics. Additionally, the length of the proposed antenna is approximately 3.84λ₀ for a central frequency of 5.95 GHz. Full article

With the development of piezoelectric-on-insulator (POI) substrates, X-cut LiNbO₃ thin-film resonators with interdigital transducers are widely investigated due to their adjustable resonant frequency (f_s) and effective electromechanical coupling coefficient ($K_{eff}^2$). This paper presents an in-depth study of simulations and measurements of laterally excited bulk acoustic wave resonators based on an X-cut LiNbO₃/SiO₂/Si substrate and a LiNbO₃ thin film to analyze the effects of electrode angle rotation ($\theta$) on the modes, f_s, and $K_{eff}^2$. The rotated $\theta$ leads to different electric field directions, causing mode changes, where the resonators without cavities are longitudinal leaky SAWs (LLSAWs, $\theta$ = 0$°$) and zero-order shear horizontal SAWs (SH₀-SAWs, $\theta$ = 90$°$) and the resonators with cavities are zero-order-symmetry (S₀) lateral vibrating resonators (LVRs, $\theta$ = 0$°$) and SH₀ plate wave resonators (PAW, $\theta$ = 90$°$). The resonators are fabricated based on a 400 nm X-cut LiNbO₃ thin-film substrate, and the measured results are consistent with those from the simulation. The fabricated LLSAW and SH₀-SAW without cavities show a $K_{eff}^2$ of 1.62% and 26.6% and a Bode-Q_max of 1309 and 228, respectively. Meanwhile, an S₀ LVR and an SH₀-PAW with cavities present a $K_{eff}^2$ of 4.82% and 27.66% and a Bode-Q_max of 3289 and 289, respectively. In addition, the TCF with a different rotated $\theta$ is also measured and analyzed. This paper systematically analyzes resonators on X-cut LiNbO₃ thin-film substrates and provides potential strategies for multi-band and multi-bandwidth filters. Full article

Plasmon waveguide resonances (PWRs) have been widely used to enhance the interaction between light and matter. PWRs have been used for chemical and biological sensing, molecular detection, and boosting other optical phenomena, such as Raman scattering and fluorescence. However, the performances of plasmon-waveguide-based structures have been investigated in the angular interrogation mode, and their potential in different spectral regions has hardly been explored. Moreover, the applications of PWRs have been limited to the weak light–matter coupling regime. In this study, we investigate leaky coupled waveguide plasmon resonances (LCWPRs) and explore their potential to enhance light–matter interaction in different spectral regions. In the weak coupling regime, we demonstrate the potential of LCWPRs for sensing in the near-IR region by detecting heavy water (D₂O) and ethanol in water. The experimental results show spectral sensitivity of 15.2 nm/% and 1.41 nm/% for ethanol and D₂O detection, respectively. Additionally, we show that LCWPRs can be used to achieve vibrational strong coupling (VSC) with organic molecules in the mid-IR region. We numerically show that the coupling between LCWPRs and the C=O stretching vibration of hexanal yields a Rabi splitting of 210 cm⁻¹, putting the system in the VSC regime. We anticipate that LCWPRs will be a promising platform for enhanced spectroscopy, sensing, and strong coupling. Full article

This paper introduces a novel miniaturized, four-mode, semi-flexible leaky wave Multiple-Input Multiple-Output (MIMO) antenna specifically designed to advance vehicular communication systems. The proposed antenna addresses key challenges in 5G low- and high-frequency bands, including millimeter-wave communication, by integrating innovative features such as a periodic Spoof Surface Plasmon Polariton Transmission Line (SSPP-TL) and logarithmic-spiral-like semi-circular strip patches parasitically fed via orthogonal ports. These design elements facilitate stable impedance matching and wide impedance bandwidths across operating bands, which is essential for vehicular networks. The hybrid combination of leaky wave and SSPP structures, along with a defected wide-slot ground structure and backside meander lines, enhances radiation characteristics by reducing back and bidirectional radiation. Additionally, a naturalization network incorporating chamfered-edge meander lines minimizes mutual coupling and introduces a fourth radiation mode at 80 GHz. Compact in size (14 × 12 × 0.25 mm³), the antenna achieves high-performance metrics, including S11 < −18.34 dB, dual-polarization, peak directive gains of 11.6 dBi (free space) and 14.6 dBi (on vehicles), isolation > 27 dB, Channel Capacity Loss (CCL) < 3, Envelope Correlation Coefficient (ECC) < 0.001, axial ratio < 2.25, and diversity gain (DG) > 9.85 dB. Extensive testing across various vehicular scenarios confirms the antenna’s robustness for Vehicle-to-Vehicle (V2V), Vehicle-to-Pedestrian (V2P), and Vehicle-to-Infrastructure (V2I) communication. Its exceptional performance ensures seamless connectivity with mobile networks and enhances safety through Specific Absorption Rate (SAR) compliance. This compact, high-performance antenna is a transformative solution for connected and autonomous vehicles, addressing critical challenges in modern automotive communication networks and paving the way for reliable and efficient vehicular communication systems. Full article

We proposed a novel fiber Mach–Zehnder interferometer (FMZI) that can perform an ultrahigh extinction ratio (ER), ultracompact, and ultra-broadband interference characteristics. The FMZI structure is based on an extremely tiny hollow core fiber (HCF) with a small diameter of 10 μm (named HCF₁₀) connected with a beam splitter of a large core of 50 μm HCF (named HCF₅₀). The refractive index (RI) of the air core is lower than that of the HCF cladding; a leaky-guided fiber waveguide (LGFW) occurs in such a short-section HCF₁₀ waveguide to simultaneously have the core and cladding modes. To achieve better fringe visibility of the interference, the section of HCF₅₀ assists in splitting the optical light into core and cladding beams launched into the HCF₁₀ with appropriate intensities. Experimental and simulation results show that the optical characteristics of the proposed LGFW-FMZI are very similar. Based on the results of the study, the length of the HCF₁₀ primarily influences the free spectral range (FSR) of the interference spectra, and the HCF₅₀ splitter significantly controls the optimal extinction ratio (ER) of the interference fringes. By exactly adjusting the lengths of HCF₁₀ and HCF₅₀, the proposed fiber interferometers can perform the capability of an ultrahigh ER over 50 dB with the arbitrary FSR in the transmitted interference spectra over an ultra-broad wavelength range of 1250 nm to 1650 nm. Full article

Piezoelectric c-axis oriented zinc oxide (ZnO) thin films, from 1.8 up to 6.6 µm thick, have been grown by the radio frequency magnetron sputtering technique onto fused silica substrates. A delay line consisting of two interdigital transducers (IDTs) with wavelength λ = 80 µm was photolithographically implemented onto the surface of the ZnO layers. Due to the IDTs’ split-finger configuration and metallization ratio (0.5), the propagation of the fundamental, third, and ninth harmonic Rayleigh waves is excited; also, three leaky surface acoustic waves (SAWs) were detected travelling at a velocity close to that of the longitudinal bulk wave in SiO₂. The acoustic waves’ propagation in ZnO/fused silica was simulated by using the 2D finite-element method (FEM) technique to identify the nature of the experimentally detected waves. It turned out that, in addition to the fundamental and harmonic Rayleigh waves, high-frequency leaky surface waves are also excited by the harmonic wavelengths; such modes are identified as Sezawa waves under the cut-off, hereafter named leaky Sezawa (LS). The velocities of all the modes was found to be in good agreement with the theoretically calculated values. The existence of a low-loss region in the attenuation vs. layer thickness curve for the Sezawa wave below the cut-off was theoretically predicted and experimentally assessed. Full article

In this paper we consider flexural-gravity waves propagating in a layer of water of constant depth limited by a vertical wall simulating a straight coastline. The water surface is covered with an elastic ice sheet of constant thickness. The ice sheet is split by one or two straight cracks parallel to the coastline, simulating the structure of land-fast ice with a refrozen lead. Analytical solutions of hydrodynamic equations describing the interaction of flexural-gravity waves with the ice sheet and cracks have been constructed and studied. In this paper, the amplification of the amplitude of incident waves between the shoreline and cracks was described depending on the incident angle of the wave coming from offshore. The constructed solutions allow the existence of edge waves propagating along the coastline and attenuated offshore. The energy of edge waves is trapped between the coastline and ice cracks. The application of the constructed solutions to describe wave phenomena observed in the land-fast ice of the Arctic shelf of Alaska is discussed. Full article

Ice accumulation on infrastructure poses severe safety risks and economic losses, necessitating effective detection and monitoring solutions. This study introduces a novel approach employing surface acoustic wave (SAW) sensors, known for their small size, wireless operation, energy self-sufficiency, and retrofit capability. Utilizing a SAW dual-mode delay line device on a 64°-rotated Y-cut lithium niobate substrate, we demonstrate a solution for combined ice detection and temperature measurement. In addition to the shear-horizontal polarized leaky SAW, our findings reveal an electrically excitable Rayleigh-type wave in the X+90° direction on the same cut. Experimental results in a temperature chamber confirm capability for reliable differentiation between liquid water and ice loading and simultaneous temperature measurements. This research presents a promising advancement in addressing safety concerns and economic losses associated with ice accretion. Full article

In this paper, both fundamental SSP modes on a roofed metallic grating and its effective excitation of the bounded SSP mode by an injected electron beam on the structure are numerically examined and investigated in the THz regime. Apart from the bounded SSP mode on the metallic grating with open space, the introduced roofed metallic grating can generate a closed waveguide mode that occupies the dispersion region outside the light line. The closed waveguide mode shifts gradually to a higher frequency band with a decreased gap size, while the bounded SSP mode line becomes lower. The effective excitation of the bounded SSP mode on this roofed metallic grating is also implemented and studied by using a particle-in-cell simulation studio. The output SSP power spectrums with various gap sizes by the same electron beam on this roofed metallic grating are obtained and analyzed. The simulation results reveal that the generated SSP spectra show a slight red shift with a decreased gap size. This work on the excitation of the SSP mode using an electron beam can benefit the development of high-power compact THz radiation sources by utilizing the strong near-field confinement of SSPs on metallic gratings. Full article

Topological nature in different areas of physics and electronics has often been characterized and controlled through topological invariants depending on the global properties of the material. The validity of bulk–edge correspondence and symmetry-related topological invariants has been extended to non-Hermitian systems. Correspondingly, the value of geometric phases, such as the Pancharatnam–Berry or Zak phases, under the adiabatic quantum deformation process in the presence of non-Hermitian conditions, are now of significant interest. Here, we explicitly calculate the Zak phases of one-dimensional topological nanobeams that sustain guided-mode resonances, which lead to energy leakage to a continuum state. The retrieved Zak phases show as zero for trivial and as π for nontrivial photonic crystals, respectively, which ensures bulk–edge correspondence is still valid for certain non-Hermitian conditions. Full article

Subwavelength resonant lattices offer a wide range of fascinating spectral phenomena under broadside illumination. The resonance mechanism relies on the generation of lateral Bloch modes that are phase matched to evanescent diffraction orders. The spectral properties and the total number of resonance states are governed by the structure of leaky modes and the mode count. This study investigates the effect of interface modifications on the band dynamics and bound-state transitions in guided-mode resonant lattices. We provide photonic lattices comprising rectangular Si₃N₄ rods with a liquid film with an adjustable boundary. The band structures and band flips are examined through numerical simulations using the rigorous coupled-wave analysis (RCWA) method and analyzing the zero-order spectral reflectance as a function of the incident angle. The band structures and band flips are examined through numerical simulations, and the influences of the refractive index and the thickness of the oil layer on the band dynamics are investigated. The results reveal distinct resonance linewidths corresponding to different refractive indices of the oil layer. Furthermore, the effect of the oil thickness on the band dynamics is explored, demonstrating precise control over the number of propagating modes within the lattice structure. Theoretical simulations and experimental results are presented for a subwavelength silicon-nitride lattice combined with a liquid film featuring an adjustable boundary. The presence of a relatively thick liquid waveguiding region enables the emergence of additional modes, including the first four transverse-electric (TE) leaky modes, which produce observable resonance signatures. Through experimental manipulation of the basic lattice’s duty cycle, the four bands undergo quantifiable band transitions and closures. The experimental results obtained within the 1400–1600 nm spectral range exhibit reasonable agreement with the numerical analysis. These findings underscore the significant role played by the interface in shaping the band dynamics of the lattice structure, providing valuable insights into the design and optimization of photonic lattices with adjustable interfaces. Full article
