Search Results (131)

Search Parameters:
Keywords = leakage vortex

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
23 pages, 8363 KB
Article
Impact of Inducer Tip Clearance on Cryopump Performance
by Sunwuji Wang, Xiaomei Guo, Ping Li, Zuchao Zhu, Aminjon Gulakhmadov and Saidabdullo Qurbonalizoda
Water 2026, 18(2), 217; https://doi.org/10.3390/w18020217 - 14 Jan 2026
Viewed by 115
Abstract
Inducers play a critical role in pump operation by providing a preliminary pressure boost to suppress cavitation. The size of the tip clearance directly influences a pump’s operational efficiency. To investigate the impact of tip clearance on a pump’s hydraulic performance and its [...] Read more.
Inducers play a critical role in pump operation by providing a preliminary pressure boost to suppress cavitation. The size of the tip clearance directly influences a pump’s operational efficiency. To investigate the impact of tip clearance on a pump’s hydraulic performance and its behavior under cavitation conditions, this study combines experimental and numerical simulation approaches. Numerical computations of the full flow field, including the inducer and a two-stage impeller, were performed for five liquefied natural gas (LNG) cryogenic inducers with different tip clearances. The accuracy of the numerical simulation results was validated by comparing them with the experimentally obtained hydraulic performance curves. The results yield cavitation performance curves, pressure distributions at incipient cavitation, vapor volume fraction contours, and leakage flow streamlines for various tip clearances. The impact of tip clearance on the overall hydraulic performance and cavitation behavior of the LNG inducer was systematically examined, with particular attention given to the microscopic evolution of the Tip Leakage Vortex (TLV) during the initial stages of cavitation. The experimental results indicate that for every 0.2 mm increase in the inducer tip clearance, the pump head decreases by approximately 1 m, the efficiency drops by about 0.2%, and the tip leakage flow rate increases by approximately 5 m3/h. Furthermore, under cavitation conditions, the cavitation area expands as the tip clearance increases. A critical clearance value, δ, exists within the range of 0.4 mm to 0.6 mm, which governs the development pattern of the TLV. When the clearance is smaller than δ, the TLV forms more rapidly, and cavitation development is significantly more sensitive to increases in tip clearance. Conversely, when the clearance exceeds δ, the formation of the TLV is delayed, and cavitation progression becomes less responsive to further increases in tip clearance. Full article
(This article belongs to the Special Issue Advanced Numerical Approaches for Multiphase and Cavitating Flows)
Show Figures

Figure 1

17 pages, 7927 KB
Article
Gas Leakage and Hazard Area Division in a Converter Fan Room: Based on the Actual Leakage Site
by Zeng Long, Furan Zheng, Qi Wang, Hongqing Zhu, Xianhui Xu, Xiliang Liu and Shunyu Yue
Sustainability 2026, 18(2), 756; https://doi.org/10.3390/su18020756 - 12 Jan 2026
Viewed by 89
Abstract
Converter gas is highly susceptible to leakage during the recovery and utilization process, which threatens personnel security and sustainable industrial development. To address this issue, a numerical model was established based on an actual converter fan room, and the accuracy of the simulation [...] Read more.
Converter gas is highly susceptible to leakage during the recovery and utilization process, which threatens personnel security and sustainable industrial development. To address this issue, a numerical model was established based on an actual converter fan room, and the accuracy of the simulation was verified through comparison with actual measurement data. In this study, the gas leakage flow field, diffusion trajectories, and hazard zone gradations were analyzed. Results showed that the gas contamination was significantly influenced by the leakage direction, leakage location, and structural boundary. The jet dominated the gas dispersion near the leakage source, with similar initial diffusion characteristics across different scenarios. Then, the diffusion velocity decayed rapidly within a distance of 0.6 m. Obstacles can significantly promote vortex formation, restrict the gas dispersion path, and reduce the extent of the hazardous area. In addition, it can be found that the far-field velocity under downward leakage was the highest, presenting the greatest risk of poisoning. At a height of 1.6 m, a lethal zone with a radius of 0.8 m was formed directly beneath the leakage hole. This work can guide the optimization of the monitoring program and emergency planning for converter gas leakage accidents. Full article
Show Figures

Figure 1

23 pages, 5602 KB
Article
Transient Analysis of Vortex-Induced Pressure Pulsations in a Vertical Axial Pump with Bidirectional Flow Passages Under Stall Conditions
by Fan Meng, Haoxuan Tang, Yanjun Li, Jiaxing Lu, Qixiang Hu and Mingming Ge
Machines 2026, 14(1), 34; https://doi.org/10.3390/machines14010034 - 25 Dec 2025
Viewed by 277
Abstract
Vertical axial-flow pumps with bidirectional passages are widely used in applications requiring flow reversal. However, their unique inlet geometry often leads to asymmetric impeller inflow conditions. This study investigates the internal flow behavior and pressure pulsation characteristics of a vertical bidirectional axial-flow pump [...] Read more.
Vertical axial-flow pumps with bidirectional passages are widely used in applications requiring flow reversal. However, their unique inlet geometry often leads to asymmetric impeller inflow conditions. This study investigates the internal flow behavior and pressure pulsation characteristics of a vertical bidirectional axial-flow pump under design, critical stall, and deep stall conditions using unsteady Reynolds-averaged Navier–Stokes simulations combined with Fast Fourier Transform and wavelet analysis. Results show that the pump reaches peak efficiency at the design point, with critical and deep stall occurring at 0.6 Qdes and 0.5 Qdes, respectively. The head at the deep stall condition shows a further drop of 7.51% compared to the critical stall condition. This progressive performance degradation is attributed to vortex-induced blockage: it initiates with the intensification of the tip leakage vortex and evolves into large-scale separation vortices covering the suction surface under deep stall—a mechanism distinctly influenced by the bidirectional inlet’s stagnant water zone. Inlet asymmetry, reflected by a normalized velocity coefficient (Vn) below 0.6 in the stagnant water zone under design flow, is partially mitigated during stall due to flow confinement. Pressure pulsations at the blade leading edge are dominated by the blade passing frequency (BPF), with amplitudes under critical stall about 3.2 times those at design conditions. At the impeller outlet, critical stall produces a mixed dominant frequency (shaft frequency and BPF), whereas deep stall yields the highest pulsation amplitude (BPF ≈ 4.8 × the design value) resulting from extreme passage blockage. These findings clarify how bidirectional-inlet-induced vortices modulate stall progression and provide theoretical guidance for enhancing the operational stability of such pumps under off-design conditions. Full article
(This article belongs to the Section Turbomachinery)
Show Figures

Figure 1

21 pages, 5211 KB
Article
Interference Effect of Shock Wave on Tip Leakage Vortex in a Transonic Variable Nozzle Turbine
by Xinguo Lei, Qin Luo and Hanzhi Zhang
Int. J. Turbomach. Propuls. Power 2025, 10(4), 49; https://doi.org/10.3390/ijtpp10040049 - 1 Dec 2025
Viewed by 430
Abstract
The tip leakage flow at both sides of the nozzle vane is an important factor for the reduction in turbine aerothermal performance. A strong shock wave is generated at the trailing edge of the nozzle vane under transonic condition, which can interfere with [...] Read more.
The tip leakage flow at both sides of the nozzle vane is an important factor for the reduction in turbine aerothermal performance. A strong shock wave is generated at the trailing edge of the nozzle vane under transonic condition, which can interfere with the tip leakage vortex and further aggravate the complexity of the flow field. The primary purpose of this study is to obtain a deeper understanding of the interference mechanism of shock waves on the leakage vortex. Three-dimensional Reynolds averaged Navier–Stokes calculations were performed to investigate the transonic flow fields in the nozzle vane cascade. The flow structure of the tip leakage flow, interference of the shock wave on the tip leakage vortex, and influence of the expansion ratio on the interference effect were analyzed and discussed. The authors found that the tip leakage vortex expanded and broke owing to the reverse pressure gradient under the interference of the shock wave, resulting in a significant increase in flow losses. As the expansion ratio increased, the expansion position of the tip leakage vortex shifted to the trailing edge, and the size of the tip leakage vortex significantly increased initially but remained unchanged at the vane rear part. Additionally, the schematic diagram of a model for interference between the shock wave and leakage vortex is presented to describe the shape of the shock wave and leakage vortex. The numerical results provide a better understanding of the complex flow field phenomena in variable nozzle turbines. Full article
Show Figures

Figure 1

33 pages, 8558 KB
Article
Unsteady Impact of Casing Air Injection in Reducing Aerodynamic Losses and Heat Transfer on Various Squealer Tip Geometries
by Nasser Can Kasımbeyoğlu, Levent Ali Kavurmacıoğlu and Cengiz Camci
Aerospace 2025, 12(11), 979; https://doi.org/10.3390/aerospace12110979 - 31 Oct 2025
Viewed by 481
Abstract
This study deals with the effectiveness of casing-injection for a few squealer tip designs in a turbine stage to mitigate tip leakage penalties. Seventy-two Unsteady Reynolds-Averaged Navier–Stokes (URANS) simulations were conducted. Five factors were examined: number of injection holes, axial position, jet inclination, [...] Read more.
This study deals with the effectiveness of casing-injection for a few squealer tip designs in a turbine stage to mitigate tip leakage penalties. Seventy-two Unsteady Reynolds-Averaged Navier–Stokes (URANS) simulations were conducted. Five factors were examined: number of injection holes, axial position, jet inclination, blowing ratio, and hole diameter. The ideal configuration demonstrated the highest aerodynamic loss reduction compared to the baseline flat tip by 2.66%. The optimal injection scheme was integrated with three tip-rim topologies: complete channel squealer, suction-side partial squealer, and pressure-side partial squealer. The channel squealer enhances the advantageous effects of injection; the injected jets produce a counter-rotating vortex pair that disturbs the tip leakage vortex core, while the cavity formed by the squealer rim captures low-momentum fluid, thus thermally protecting the tip surface. The injection combined with channel squealer had the highest stage isentropic efficiency and the lowest total-pressure loss, thereby validating the synergy between active jet momentum augmentation and passive geometric sealing. The best configuration shows a 2.87% total pressure loss decrement and a 4.49% total-to-total efficiency increment compared to the baseline design. The best configuration not only improved stage efficiency but also achieved a 43.9% decrease in the tip heat transfer coefficient. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

23 pages, 6268 KB
Article
Investigation of Sediment Erosion of the Top Cover in the Francis Turbine Guide Vanes at the Genda Power Station
by Xudong Lu, Kang Xu, Tianlin Li, Yu Xiao, Kailiang Hu, Yaogang Xu and Xiaobing Liu
J. Mar. Sci. Eng. 2025, 13(10), 1923; https://doi.org/10.3390/jmse13101923 - 7 Oct 2025
Cited by 1 | Viewed by 611
Abstract
This study utilizes the Standard k-ε turbulence model and ANSYS CFX software to tackle silt erosion in the top cover clearances of guide vane of the Francis turbine at Genda Power Station (Minjiang River Basin section, 103°17′ E and 31°06′ N) [...] Read more.
This study utilizes the Standard k-ε turbulence model and ANSYS CFX software to tackle silt erosion in the top cover clearances of guide vane of the Francis turbine at Genda Power Station (Minjiang River Basin section, 103°17′ E and 31°06′ N) under sediment-laden flow conditions. A numerical simulation of a solid–liquid two-phase flow along the whole flow route was performed under rated operating circumstances to examine the impact of varying guide vane end clearance heights (0.3 mm, 0.5 mm, and 1.0 mm) on internal flow patterns and sediment erosion characteristics. The simulation parameters employed an average sediment concentration of 2.9 kg/m3 and a median particle size of 0.058 mm, indicative of the flood season. The findings demonstrate that augmenting the clearance height intensifies leaky flow and secondary flow, resulting in a 0.49% reduction in efficiency. As the gap expanded from 0.3 mm to 1.0 mm, the leakage flow velocity notably increased to 40 m/s, exacerbating flow separation, enlarging the vortex structures in the vaneless space, and augmenting the sediment velocity gradient and concentration, consequently heightening the risk of erosion. An experimental setup was devised based on the numerical results, and the dynamic resemblance between the constructed test section and the prototype turbine was confirmed for flow velocity, concentration, and Reynolds number. Tests on sediment erosion revealed that the erosion resistance of the anti-sediment erosion material 04Cr13Ni5Mo markedly exceeded that of the base cast steel, especially in high-velocity areas. This study delivers a systematic, quantitative analysis of clearance effects on flow and erosion, along with an experimental wear model specifically for the Gengda Power Station, thereby providing direct theoretical support and engineering guidance for its wear protection strategy and maintenance planning. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

29 pages, 22467 KB
Article
Research on Internal Instability Characteristics of Centrifugal Impeller Based on Dynamic Mode Decomposition
by Xiaoping Fan, Zhuhai Zhong, Hongfen Chen, Yang Chen, Meng Wang and Xiaodong Lu
Fluids 2025, 10(9), 246; https://doi.org/10.3390/fluids10090246 - 19 Sep 2025
Viewed by 622
Abstract
Nitrogen compression requires centrifugal compressors to operate under relatively high ambient pressure. However, the internal instability characteristics of compressors handling high-density working fluids remain unclear. Therefore, this study employs Dynamic Mode Decomposition (DMD) to investigate unsteady flow fluctuations within an isolated centrifugal impeller [...] Read more.
Nitrogen compression requires centrifugal compressors to operate under relatively high ambient pressure. However, the internal instability characteristics of compressors handling high-density working fluids remain unclear. Therefore, this study employs Dynamic Mode Decomposition (DMD) to investigate unsteady flow fluctuations within an isolated centrifugal impeller under both best efficiency and near-stall conditions at high ambient pressure. Results show that as the throttling process progresses, distinct unsteady phenomena emerge within the impeller. Under near-stall conditions, the frequency of the instability is 0.44 times the blade passage frequency (BPF), manifesting as periodic pressure fluctuations throughout the entire blade passage. This instability originates from periodic passage blockages caused by fluctuations in tip leakage flow. Additionally, the pressure fluctuations at the impeller inlet exhibit a noticeable lag compared to those in the latter half of the passage. Through DMD analysis, it is found that after the tip leakage vortex exits the blade, it interacts with the pressure surface of the adjacent blade, affecting the tip loading of the neighboring blade and forming a dynamic cycle. However, this vortex is not the primary flow structure responsible for the instability. These insights into the nature of unsteady disturbances provide valuable implications for future stall warning and instability prediction technologies. Full article
Show Figures

Figure 1

32 pages, 10952 KB
Article
Study on the Gas–Liquid Two-Flow Characteristics Inside a Three-Stage Centrifugal Pump
by Xiang Zhang and Weidong Cao
Energies 2025, 18(17), 4772; https://doi.org/10.3390/en18174772 - 8 Sep 2025
Viewed by 977
Abstract
This paper takes a small three-stage centrifugal pump as the research object. Based on the RNG k-ε turbulence model and the TFM two-phase flow model, the numerical simulation of the internal gas–liquid two-phase flow was carried out, and the influence of the inlet [...] Read more.
This paper takes a small three-stage centrifugal pump as the research object. Based on the RNG k-ε turbulence model and the TFM two-phase flow model, the numerical simulation of the internal gas–liquid two-phase flow was carried out, and the influence of the inlet gas content rate of the small multistage centrifugal pump on its internal flow was analyzed. The research results show that the head and efficiency of the multistage centrifugal pump will decrease with the increase in the inlet gas content rate. As the gas content increases from 0% to 5%, the head of the multistage centrifugal pump decreases by 3% and its efficiency drops by 5%. The trend of the continuous increase in the pressure on the blade surface does not change with the increase in the inlet gas content rate. The bubble area on the surface of the first-stage impeller blade increases with the increase in the gas content rate. When the inlet gas content rate condition reaches 5%, the bubbles cover the middle section of the blade suction surface. The flow vortex structure is mainly composed of blade separation vortices and mouth ring clearance leakage vortices. The vortices inside the impeller are concentrated in the blade outlet and rim area, while the vortices inside the guide vanes are located in the flow channel area of the anti-guide vanes. With the increase in the gas content rate, the amplitude of pressure pulsation in the flow channel inside the pump decreases. Full article
Show Figures

Figure 1

14 pages, 2638 KB
Article
The Impact of Pump Cavity Gaps on the Flow Characteristics of Helical Mixed-Flow Pumps
by Wei Han, Yucheng Chen, Tongqing Xue and Pengzheng Lei
Actuators 2025, 14(9), 444; https://doi.org/10.3390/act14090444 - 8 Sep 2025
Viewed by 640
Abstract
The performance of pump-jet propulsion systems is critically important in defense and marine applications. However, their optimization has encountered bottlenecks due to a lack of theoretical understanding of underlying flow mechanisms. This study investigates the influence of the pump cavity gap on the [...] Read more.
The performance of pump-jet propulsion systems is critically important in defense and marine applications. However, their optimization has encountered bottlenecks due to a lack of theoretical understanding of underlying flow mechanisms. This study investigates the influence of the pump cavity gap on the flow characteristics and performance of a helical mixed-flow pump using numerical simulations. The gap size is non-dimensionalized as a gap coefficient—defined as the ratio of pump cavity gap to blade thickness—with the inlet ring gap fixed at 0.2 mm. Results demonstrate that the gap coefficient significantly affects internal flow stability and energy loss. A gap coefficient of 0.15 effectively suppresses leakage and vortex formation, improving efficiency (peak efficiency reaches 75%) and head (1.9 m) under low-flow conditions. This configuration also promotes uniform pressure distribution on the impeller shaft surface and reduces turbulent kinetic energy and axial vorticity. In contrast, a smaller gap coefficient (0.125) exacerbates flow separation at high flow rates, while a larger value (0.2) increases leakage losses and degrades performance. The study elucidates correlations between the pump cavity gap and vortex evolution, pressure gradient, and turbulence distribution, providing theoretical support for the optimized design of helical mixed-flow pumps. Full article
Show Figures

Figure 1

25 pages, 10989 KB
Article
Research on the Relationship Between Pressure Pulsation and Leakage Vortex Intensity in the Blade Tip Clearance Under Various Operational Conditions of Axial Flow Pumps
by Xiaoqi Jia, Zhipeng Gan, Jie Liu, Xiaoqin Li, Zhe Lin and Zuchao Zhu
Fluids 2025, 10(9), 235; https://doi.org/10.3390/fluids10090235 - 3 Sep 2025
Viewed by 665
Abstract
Large underwater vehicles, designed for multiple cruising speeds, are required to operate under diverse conditions such as full speed, surfacing, diving, and hovering. This demands that the axial flow pumps used in these applications have a broad operational range, typically functioning efficiently from [...] Read more.
Large underwater vehicles, designed for multiple cruising speeds, are required to operate under diverse conditions such as full speed, surfacing, diving, and hovering. This demands that the axial flow pumps used in these applications have a broad operational range, typically functioning efficiently from 0.1 times rated flow to 1.5 times rated flow. In the process of adjusting operational conditions, axial flow pumps may experience rotating stall phenomena. Importantly, the presence of tip leakage vortices within the pump markedly influences the internal flow dynamics. To assess the impact of tip leakage vortices on the internal flow field under varied operational states, this study delves into the inherent link between tip leakage vortices and pressure pulsation across three specific scenarios: optimal, critical stall, and deep stall conditions. Analyzing from the perspective of the vorticity transport equation, it is found that the compression–expansion term dictates the core strength of tip leakage vortices, while the viscous dissipation factor determines the frequency of pressure pulsation. With an increase in the core strength of tip leakage vortices, a gradual rise in pressure pulsation is observed; in optimal scenarios, the core of tip leakage vortices progressively shifts toward the interior of the clearance, keeping the pulsation amplitude at each monitoring point within the blade tip clearance at integer multiples of the blade passing frequency. During critical stall and deep stall scenarios, the viscous dissipation effect of tip leakage vortices contributes to the emergence of high-frequency harmonic components within pressure pulsation. Full article
Show Figures

Figure 1

19 pages, 7347 KB
Article
Experimental Study of Fluidization and Defluidization Processes in Sand Bed Induced by a Leaking Pipe
by Huaqing Wang, Zhaolin Zheng, Tingchao Yu, Yiyi Ma and Yiping Zhang
Appl. Sci. 2025, 15(17), 9618; https://doi.org/10.3390/app15179618 - 1 Sep 2025
Cited by 1 | Viewed by 1088
Abstract
Underground pressurized pipe leakage can induce sand fluidization, leading to ground collapses in urban areas. Additionally, the defluidization process is one of the main causes of sinkholes. In this study, a physical model test was conducted to examine sand bed fluidization and defluidization [...] Read more.
Underground pressurized pipe leakage can induce sand fluidization, leading to ground collapses in urban areas. Additionally, the defluidization process is one of the main causes of sinkholes. In this study, a physical model test was conducted to examine sand bed fluidization and defluidization through a slot, which allowed precise control of the water flow rate in increments of 10 mL/s. The sand layer movement during the experiments was recorded, and the pressure field was accurately measured. The fluidization and defluidization processes were classified into five stages: fluidization static bed, internal fluidization, surface fluidization, internal defluidization, and defluidization static bed. Subsequently, the static bed stage included slow fluidization and fast fluidization, with the former driven by seepage and the latter involving densification and upward movement of sand particles above the orifice. Fluidization initiated at 240 mL/s when the sand particles near the orifice were compressed to approximately minimum porosity 0.37. The head losses comprised orifice head loss, seepage head loss, and vortex head loss, each exhibiting different variation patterns with the water flow rate. Hysteresis was observed in the cavity height curve, attributed to the arching effect. The findings of this study contribute to a more comprehensive understanding of effective strategies for preventing ground collapse. Full article
(This article belongs to the Special Issue Sediment Transport and Infrastructure Scour)
Show Figures

Figure 1

12 pages, 3318 KB
Article
Influence of the Inducer on the Performance of a Miniature High-Speed Centrifugal Pump
by Yifu Hou, Xiaonian Zeng and Yuchuan Wang
Micromachines 2025, 16(8), 952; https://doi.org/10.3390/mi16080952 - 19 Aug 2025
Viewed by 1037
Abstract
The inclusion of an inducer is an effective approach to improve the cavitation performance of centrifugal pumps, significantly influencing both the internal flow characteristics and the external performance of the pumps. This study examines a miniature high-speed centrifugal pump (MHCP) using numerical simulations [...] Read more.
The inclusion of an inducer is an effective approach to improve the cavitation performance of centrifugal pumps, significantly influencing both the internal flow characteristics and the external performance of the pumps. This study examines a miniature high-speed centrifugal pump (MHCP) using numerical simulations based on the k-ε turbulence model, comparing the cases with an inducer and without one. Experimental tests on the pump’s external performance are conducted and flow visualization images are presented to validate the findings. The effects of the inducer on the tip leakage backflow, cavitation performance, and external pump performance are analyzed. The results show that the inducer provides pre-pressurization of the fluid, leading to a higher circumferential velocity at the impeller inlet and a reduced inlet flow angle. This allows for a reduction in the impeller blade inlet angle, resulting in smoother flow streamlines inside the impeller. Moreover, the inducer helps to suppress local low-pressure regions caused by the vortex and cavities generated by the interaction between the tip clearance backflow and the main flow, thereby mitigating cavitation in the non-blade zone. Within the investigated operating range, the pump with an inducer exhibits a significantly improved external hydraulic performance, including an increased head and efficiency, a reduced required net positive suction head (NPSHr), and a broader stable operating range. Full article
Show Figures

Figure 1

18 pages, 3836 KB
Article
Investigation of Blade Root Clearance Flow Effects on Pressure Fluctuations in an Axial Flow Pump
by Fan Meng, Yanjun Li, Mingzhe Li and Chao Ning
Machines 2025, 13(8), 733; https://doi.org/10.3390/machines13080733 - 18 Aug 2025
Cited by 3 | Viewed by 698
Abstract
This study investigates the leakage vortex influence on pressure pulsation characteristics within a vertical axial flow pump. Three impeller configurations with blade root clearance (δ) of 2.7–8.0 mm were designed to analyze geometric effects on internal flow dynamics. Unsteady RANS simulations [...] Read more.
This study investigates the leakage vortex influence on pressure pulsation characteristics within a vertical axial flow pump. Three impeller configurations with blade root clearance (δ) of 2.7–8.0 mm were designed to analyze geometric effects on internal flow dynamics. Unsteady RANS simulations predicted flow structures under multiple operating conditions (0.8–1.2Qdes). Fast Fourier Transform (FFT) extracted frequency–domain and time–frequency characteristics of pressure pulsations in critical flow regions. Key results reveal: (1) δ enlargement expands low-pressure zones within blade channels due to enhanced leakage vortices; (2) leading-edge pulsation shows 8.2–11.7% reduction in peak-to-peak amplitude and fundamental frequency magnitude with increasing δ; (3) trailing-edge response exhibits non-monotonic behavior, with maximum amplitude at δ = 5.0 mm (42.2% increase at design flow). These findings demonstrate that blade root clearance optimization requires condition-dependent thresholds to balance leakage management and pulsation control. Full article
Show Figures

Figure 1

19 pages, 5246 KB
Article
Effects of Partial Admission Ratio on the Performance and Flow Characteristics of a Supercritical Carbon Dioxide Axial-Flow Turbine
by Zhuo Hu, Hongsheng Jiang, Weilin Zhuge, Yuping Qian and Yangjun Zhang
Energies 2025, 18(16), 4259; https://doi.org/10.3390/en18164259 - 11 Aug 2025
Viewed by 766
Abstract
The supercritical carbon dioxide (S-CO2) Brayton cycle has become one of the most promising power generation systems in recent years. Owing to the high density of S-CO2, the turbine operates with a lower flow coefficient and a reduced blade [...] Read more.
The supercritical carbon dioxide (S-CO2) Brayton cycle has become one of the most promising power generation systems in recent years. Owing to the high density of S-CO2, the turbine operates with a lower flow coefficient and a reduced blade height compared to conventional gas turbines, leading to relatively higher tip leakage and secondary flow losses. A properly designed partial admission scheme can increase blade height and improve turbine efficiency. In this study, the effects of partial admission ratio on the performance and flow characteristics of a partial admission S-CO2 turbine were investigated using numerical methods. The results indicate that the decline in turbine efficiency accelerates when the partial admission rate falls below 0.3. Furthermore, the maximum blade torque begins to decrease once the partial admission ratio drops below 0.1. Stronger tip passage vortices and a large-scale leakage vortex were identified in the passage located at the sector interface. Blade loading analysis revealed a reduction in pressure on the pressure surface of blades just entering the active sector, and a significant increase in suction surface pressure for blades about to exit the active sector. These pressure variations result in reduced blade torque near the boundaries of the active sector. Full article
Show Figures

Figure 1

16 pages, 10446 KB
Article
Transient Vortex Dynamics in Tip Clearance Flow of a Novel Dishwasher Pump
by Chao Ning, Yalin Li, Haichao Sun, Yue Wang and Fan Meng
Machines 2025, 13(8), 681; https://doi.org/10.3390/machines13080681 - 2 Aug 2025
Viewed by 637
Abstract
Blade tip leakage vortex (TLV) is a critical phenomenon in hydraulic machinery, which can significantly affect the internal flow characteristics and deteriorate the hydraulic performance. In this paper, the blade tip leakage flow and TLV characteristics in a novel dishwasher pump were investigated. [...] Read more.
Blade tip leakage vortex (TLV) is a critical phenomenon in hydraulic machinery, which can significantly affect the internal flow characteristics and deteriorate the hydraulic performance. In this paper, the blade tip leakage flow and TLV characteristics in a novel dishwasher pump were investigated. The correlation between the vorticity distribution in various directions and the leakage vortices was established within a rotating coordinate system. The results show that the TLV in a composite impeller can be categorized into initial and secondary leakage vortices. The initial leakage vortex originates from the evolution of two corner vortices that initially form at different locations within the blade tip clearance. This vortex induces pressure fluctuations at the impeller inlet; its shedding is identified as the primary contributor to localized energy loss within the flow passage. These findings provide insights into TLVs in complex pump geometries and provide solutions for future pump optimization strategies. Full article
Show Figures

Figure 1
