Search Results (57)

Urban building energy modeling (UBEM) is crucial for assessing energy consumption patterns at the city-scale and for supporting data driven planning and decarbonization strategies. However, its practical deployment is often hindered by the need to balance detailed physics-based simulations with acceptable computation times when thousands of buildings are involved. This work presents a large-scale real world UBEM case study and proposes a workflow that combines EnergyPlus simulations, high-performance computing (HPC), and open urban datasets to model the energy consumption of the building stock in the Municipality of Bologna, Italy. Geometric data such as building footprints and heights were acquired from the Bologna Open Data portal and complemented by aerial light detection and ranging (LiDAR) measurements to refine elevations and roof geometries. Non-geometrical building characteristics, including wall materials, insulation levels, and window properties, were derived from local building regulations and the European TABULA project, enabling the assignment of archetypes in contexts where granular information about building materials is not available. The pipeline’s modular design allows us to analyze different combinations of retrofitting scenarios, making it possible to identify the groups of buildings that would benefit the most. A key feature of the workflow is the use of Leonardo, the supercomputer hosted and managed by Cineca, which made it possible to simulate the energy consumption of approximately 25,000 buildings in less than 30 min. In contrast to approaches that mainly reduce computation time by simplifying the physical model or aggregating representative buildings, the HPC-based workflow allows the entire building stock to be individually simulated (within the intrinsic simplifications of UBEM) without introducing further compromises in model detail. Overall, this case study demonstrates that the combination of open data and HPC-accelerated UBEM can deliver city-scale energy simulations that are both computationally tractable and sufficiently detailed to inform municipal decision-making and future digital twin applications. Full article

Small and medium Unmanned Aerial Vehicles (UAVs) are commonly equipped with diverse sensors for situational awareness, including cameras, Frequency-Modulated Continuous-Wave (FMCW) radars, Light Detection and Ranging (LiDAR) systems, and ultrasonic sensors. However, optical systems are constrained by adverse weather and darkness, while the limited detection range of compact FMCW radars-typically a few hundred meters-is often insufficient for higher-speed UAVs, particularly those operating Beyond Visual Line of Sight (BVLOS). This paper presents a Collision Avoidance System (CAS) based on a lightweight pulse radar, targeting medium UAV platforms (10–300 kg MTOM) where installing large, nose-mounted radars is impractical. The system is designed for obstacle detection at ranges of 1–3 km, directly addressing the standoff distance limitations of conventional sensors. Beyond its primary sensing function, the pulse architecture offers several operational advantages. Its lower time-averaged power also results in a reduced electromagnetic footprint, mitigating interference and supporting emission-control objectives. Furthermore, pulse radar offers greater robustness against interference in dense electromagnetic environments and lower power consumption, both of which directly enhance UAV operational endurance. Field tests demonstrated a one-to-one correspondence between visually identified objects and radar detections across 1–3 km, with ${\mathrm{P}}_{\mathrm{FA}}$ = 1.5%, confirming adequate standoff for tens of seconds of maneuvering time, with range resolution of 3.75 m and average system power below 80 W. Full article

Three-dimensional (3D) building models are essential for urban planning, spatial analysis, and virtual simulations. However, most reconstruction methods based on Airborne LiDAR Scanning (ALS) rely primarily on rooftop information, often resulting in distorted footprints and the omission of façade semantics such as windows and doors. To address these limitations, this study proposes an automatic 3D building reconstruction method driven by façade geometry. The proposed method introduces three key contributions: (1) a façade-guided footprint generation strategy that eliminates geometric distortions associated with roof projection methods; (2) robust detection and reconstruction of façade openings, enabling reliable identification of windows and doors even under sparse ALS conditions; and (3) an integrated volumetric modeling pipeline that produces watertight models with embedded façade details, ensuring both structural accuracy and semantic completeness. Experimental results show that the proposed method achieves geometric deviations at the decimeter level and feature recognition accuracy exceeding 97%. On average, the reconstruction time of a single building is 91 s, demonstrating reliable reconstruction accuracy and satisfactory computational performance. These findings highlight the potential of the method as a robust and scalable solution for large-scale ALS-based urban modeling, offering substantial improvements in both structural precision and semantic richness compared with conventional roof-based approaches. Full article

Accurate and reliable extraction of building footprints from LiDAR point clouds is a fundamental task in remote sensing and urban scene reconstruction. Building footprints serve as essential geospatial products that support GIS database updating, land-use monitoring, disaster management, and digital twin development. Traditional image-based methods enable large-scale mapping but suffer from 2D perspective limitations and radiometric distortions, while airborne or vehicle-borne LiDAR systems often face single-viewpoint constraints that lead to incomplete or fragmented footprints. Recently, backpack mobile laser scanning (MLS) has emerged as a flexible platform for capturing dense urban geometry at the pedestrian level. However, the high noise, point sparsity, and structural complexity of MLS data make reliable footprints delineation particularly challenging. To address these issues, this study proposes a Deep Line-Segment Detection–Driven Building Footprints Extraction Framework that integrates multi-layer accumulated occupancy mapping, deep geometric feature learning, and structure-aware regularization. The accumulated occupancy maps aggregate stable wall features from multiple height slices to enhance contour continuity and suppress random noise. A deep line-segment detector is then employed to extract robust geometric cues from noisy projections, achieving accurate edge localization and reduced false responses. Finally, a structural chain-based completion and redundancy filtering strategy repairs fragmented contours and removes spurious lines, ensuring coherent and topologically consistent footprints reconstruction. Extensive experiments conducted on two campus scenes containing 102 buildings demonstrate that the proposed method achieves superior performance with an average Precision of 95.7%, Recall of 92.2%, F1-score of 93.9%, and IoU of 88.6%, outperforming existing baseline approaches by 4.5–7.8% in F1-score. These results highlight the strong potential of backpack LiDAR point clouds, when combined with deep line-segment detection and structural reasoning, to complement traditional remote sensing imagery and provide a reliable pathway for large-scale urban scene reconstruction and geospatial interpretation. Full article

Forest height is a key structural parameter for evaluating ecological functions, biodiversity, and carbon dynamics. While LiDAR and Synthetic Aperture Radar (SAR) provide vertical structure information, their large-scale use is restricted by sparse sampling (LiDAR) and temporal decorrelation (SAR). Optical remote sensing offers complementary spectral information but lacks direct height retrieval. To address these limitations, we developed a multi-modal framework integrating GEDI waveform LiDAR, Sentinel-1 SAR (InSAR and PolSAR), and Sentinel-2 multispectral data, combined with machine learning, to estimate forest canopy height across Jiangsu Province, China. GEDI L2A footprints were used as training labels, and a suite of structural and spectral features was extracted from SAR, GEDI, and Sentinel-2 data as input variables for canopy height estimation. The performance of two ensemble algorithms, Random Forest (RF) and Gradient Tree Boosting (GTB) for canopy height estimation, was evaluated through stratified five-fold cross-validation. RF consistently outperformed GTB, with the integration of SAR, GEDI, and optical features achieving the best accuracy (R² = 0.708, RMSE = 2.564 m). The results demonstrate that InSAR features substantially enhance sensitivity to vertical heterogeneity, improving forest height estimation accuracy. These findings highlight the advantage of incorporating SAR, particularly InSAR with optical data, in enhancing sensitivity to vertical heterogeneity and improving the performance of RF and GTB in estimating forest height. The framework we proposed is scalable to other regions and has the potential to contribute to global sustainable forest monitoring initiatives. Full article

In forest remote sensing monitoring of complex terrain, spaceborne lidar data has become a key technology for obtaining large-scale forest structure parameters due to its uniquethree-dimensional observation capabilities. However, in complex terrain conditions, there are still many challenges for spaceborne lidar. Particularly in mountainous forest areas with significant topographic relief, overcoming the limitations imposed by complex terrain conditions to achieve high-precision forest stock volume estimation has emerged as one of the most challenging and cutting-edge research areas in vegetation remote sensing. Objective: This study aims to explore the feasibility and methods of forest stock volume estimation using spaceborne lidar data ICESat-2/ATL08 in complex terrain and to compare the effectiveness of three machine learning regression models for this purpose. Method: Based on the ATL08 product from ICESat-2/ATLAS data, a sequential Gaussian conditional simulation was used for spatial interpolation of forest areas in Jingdong Yi Autonomous County, Pu’er City, Yunnan Province. XGBoost, LightGBM, and Random Forest methods were then employed to develop stock volume models, and their estimation capabilities were analyzed and compared. Results: (1) Among the 57 ICESat-2/ATLAS footprint parameters extracted, 13 were retained for interpolation after analysis and screening. (2) Based on sequential Gaussian conditional simulation, three parameters demonstrating lower interpolation accuracy were eliminated, with the remaining ten parameters allocated for inversion model development. (3) In terms of inversion model accuracy, XGBoost outperformed LightGBM and Random Forest, achieving an R² of 0.89 and an rRMSE of 10.5912. The average forest stock volume derived from the inversion was 141.00 m³/hm². Conclusions: Overall, large-area forest stock volume estimation through spaceborne Lidar inversion using ICESat-2/ATLAS photon-counting footprints proved feasible for mountainous environments with complex terrain. The XGBoost method demonstrates strong forest stock volume inversion capabilities. This study provides a case study for investigating forest structure parameters in complex mountainous terrain using spaceborne lidar ICESat-2/ATLAS data. Full article

In this paper, the application is investigated of fast Fourier transform filtering (FFT-FR) to high spatial resolution digital terrain models (HR-DTM) derived from LiDAR sensors, assessing its efficacy in identifying genuine relief elements, including both natural geological features and anthropogenic landforms. The suitability of the derived filtered geomorphic references (FGRs) is evaluated through spatial correlation with ground truths (GTs) extracted from the topographical and geological geodatabases of Santander Bay, Northern Spain. In this study, it is revealed that existing artefacts, derived from vegetation or human infrastructures, pose challenges in the units’ construction, and large physiographic units are better represented using low-pass filters, whereas detailed units are more accurately depicted with high-pass filters. The results indicate a propensity of high-frequency filters to detect anthropogenic elements within the DTM. The quality of GTs used for validation proves more critical than the geodatabase scale. Additionally, in this study, it is demonstrated that the footprint of buildings remains uneliminated, indicating that the model is a poorly refined digital surface model (DSM) rather than a true digital terrain model (DTM). Experiments validate the DTM’s capability to highlight contacts and constructions, with water detection showing high precision (≥60%) and varying precision for buildings. Large units are better captured with low filters, whilst high filters effectively detect anthropogenic elements and more detailed units. This facilitates the design of validation and correction procedures for DEMs derived from LiDAR point clouds, enhancing the potential for more accurate and objective Earth surface representation. Full article

In recent years, the growth of digital data has been unimaginable. This also applies to geospatial data. One of the largest data types is LiDAR point clouds. Their large volumes on disk, both at the acquisition and processing stages, and in the final versions translate into a high demand for disk space and therefore electricity. It is therefore obvious that in order to reduce energy consumption, lower the carbon footprint of the activity and sensitize sustainability in the digitization of the industry, lossless compression of the aforementioned datasets is a good solution. In this article, a new format for point clouds—3DL—is presented, the effectiveness of which is compared with 21 available formats that can contain LiDAR data. A total of 404 processes were carried out to validate the 3DL file format. The validation was based on four LiDAR point clouds stored in LAS files: two files derived from ALS (airborne laser scanning), one in the local coordinate system and the other in PL-2000; and two obtained by TLS (terrestrial laser scanning), also with the same georeferencing (local and national PL-2000). During research, each LAS file was saved 101 different ways in 22 different formats, and the results were then compared in several ways (according to the coordinate system, ALS and TLS data, both types of data within a single coordinate system and the time of processing). The validated solution (3DL) achieved CR (compression rate) results of around 32% for ALS data and around 42% for TLS data, while the best solutions reached 15% for ALS and 34% for TLS. On the other hand, the worst method compressed the file up to 424.92% (ALS_PL2000). This significant reduction in file size contributes to a significant reduction in energy consumption during the storage of LiDAR point clouds, their transmission over the internet and/or during copy/transfer. For all solutions, rankings were developed according to CR and CT (compression time) parameters. Full article

Ultra-compact passive phase shifters are inversely designed by the multi-objective particle swarm optimization algorithm. The wavelength-dependent phase difference between two output beams originates from the different distances of the input light passing through the 4 μm × 3.2 μm rectangular waveguide with random-distributed air-hole arrays. As the wavelength changes from 1535 to 1565 nm, a phase difference tuning range of 6.26 rad and 6.95 rad is obtained for TE and TM modes, respectively. Compared with the array waveguide grating counterpart, the phase shifters exhibit higher transmission with a much smaller footprint. By combining the inverse-designed phase shifter and random-grating emitter together, integrated beam-steering structures are built, which show a large scanning range of ±25.47° and ±27.85° in the lateral direction for TE and TM mode, respectively. This work may pave the way for the development of ultra-compact high-performance optical phased array LiDARs. Full article

Building height is important information in disaster management and damage assessment. It is also a key parameter in studies such as population modeling and urbanization. Relatively few studies have been conducted on extracting building height in rural areas using imagery from China’s Gaofen-7 satellite (GF-7). In this study, we developed a method combining photogrammetry and deep learning to extract building height using GF-7 data in the rural area of Pingquan in northern China. The deep learning model DELaMa was proposed for digital surface model (DSM) editing based on the Large Mask Inpainting (LaMa) architecture. It not only preserves topographic details but also reasonably predicts the topography inside the building mask. The percentile value of the normalized digital surface model (nDSM) in the building footprint was taken as the building height. The extracted building heights in the study area are highly consistent with the reference building heights measured from the ICESat-2 LiDAR point cloud, with an R² of 0.83, an MAE of 1.81 m and an RMSE of 2.13 m for all validation buildings. Overall, the proposed method in this paper helps to promote the use of satellite data in large-scale building height surveys, especially in rural areas. Full article

Gaps are openings within tropical forest canopies created by natural or anthropogenic disturbances. Important aspects of gap dynamics that are not well understood include how gaps close over time and their potential for contagiousness, indicating whether the presence of gaps may or may not induce the creation of new gaps. This is especially important when we consider disturbances from selective logging activities in rainforests, which take away large trees of high commercial value and leave behind a forest full of gaps. The goal of this study was to quantify and understand how gaps open and close over time within tropical rainforests using a time series of airborne LiDAR data, attributing observed processes to gap types and origins. For this purpose, the Jamari National Forest located in the Brazilian Amazon was chosen as the study area because of the unique availability of multi-temporal small-footprint airborne LiDAR data covering the time period of 2011–2017 with five data acquisitions, alongside the geolocation of trees that were felled by selective logging activities. We found an increased likelihood of natural new gaps opening closer to pre-existing gaps associated with felled tree locations (<20 m distance) rather than farther away from them, suggesting that small-scale disturbances caused by logging, even at a low intensity, may cause a legacy effect of increased mortality over six years after logging due to gap contagiousness. Moreover, gaps were closed at similar annual rates by vertical and lateral ingrowth (16.7% yr⁻¹) and about 90% of the original gap area was closed at six years post-disturbance. Therefore, the relative contribution of lateral and vertical growth for gap closure was similar when consolidated over time. We highlight that aboveground biomass or carbon density of logged forests can be overestimated if considering only top of the canopy height metrics due to fast lateral ingrowth of neighboring trees, especially in the first two years of regeneration where 26% of gaps were closed solely by lateral ingrowth, which would not translate to 26% of regeneration of forest biomass. Trees inside gaps grew 2.2 times faster (1.5 m yr⁻¹) than trees at the surrounding non-gap canopy (0.7 m yr⁻¹). Our study brings new insights into the processes of both the opening and closure of forest gaps within tropical forests and the importance of considering gap types and origins in this analysis. Moreover, it demonstrates the capability of airborne LiDAR multi-temporal data in effectively characterizing the impacts of forest degradation and subsequent recovery. Full article

Forest canopy height is a fundamental parameter of forest structure, and plays a pivotal role in understanding forest biomass allocation, carbon stock, forest productivity, and biodiversity. Spaceborne LiDAR (Light Detection and Ranging) systems, such as GEDI (Global Ecosystem Dynamics Investigation), provide large-scale estimation of ground elevation, canopy height, and other forest parameters. However, these measurements may have uncertainties influenced by topographic factors. This study focuses on the calibration of GEDI L2A and L1B data using an airborne LiDAR point cloud, and the combination of Sentinel-2 multispectral imagery, 1D convolutional neural network (CNN), artificial neural network (ANN), and random forest (RF) for upscaling estimated forest height in the Guangxi Gaofeng Forest Farm. First, various environmental (i.e., slope, solar elevation, etc.) and acquisition parameters (i.e., beam type, Solar elevation, etc.) were used to select and optimize the L2A footprint. Second, pseudo-waveforms were simulated from the airborne LiDAR point cloud and were combined with a 1D CNN model to calibrate the L1B waveform data. Third, the forest height extracted from the calibrated L1B waveforms and selected L2A footprints were compared and assessed, utilizing the CHM derived from the airborne LiDAR point cloud. Finally, the forest height data with higher accuracy were combined with Sentinel-2 multispectral imagery for an upscaling estimation of forest height. The results indicate that through optimization using environmental and acquisition parameters, the ground elevation and forest canopy height extracted from the L2A footprint are generally consistent with airborne LiDAR data (ground elevation: R² = 0.99, RMSE = 4.99 m; canopy height: R² = 0.42, RMSE = 5.16 m). Through optimizing, ground elevation extraction error was reduced by 45.5% (RMSE), and the canopy height extraction error was reduced by 30.3% (RMSE). After training a 1D CNN model to calibrate the forest height, the forest height information extracted using L1B has a high accuracy (R² = 0.84, RMSE = 3.13 m). Compared to the optimized L2A data, the RMSE was reduced by 2.03 m. Combining the more accurate L1B forest height data with Sentinel-2 multispectral imagery and using RF and ANN for the upscaled estimation of the forest height, the RF model has the highest accuracy (R² = 0.64, RMSE = 4.59 m). The results show that the extrapolation and inversion of GEDI, combined with multispectral remote sensing data, serve as effective tools for obtaining forest height distribution on a large scale. Full article

A key feature for urban digital twins (DTs) is an automatically generated detailed 3D representation of the built and unbuilt environment from aerial imagery, footprints, LiDAR, or a fusion of these. Such 3D models have applications in architecture, civil engineering, urban planning, construction, real estate, Geographical Information Systems (GIS), and many other areas. While the visualization of large-scale data in conjunction with the generated 3D models is often a recurring and resource-intensive task, an automated workflow is complex, requiring many steps to achieve a high-quality visualization. Methods for building reconstruction approaches have come a long way, from previously manual approaches to semi-automatic or automatic approaches. This paper aims to complement existing methods of 3D building generation. First, we present a literature review covering different options for procedural context generation and visualization methods, focusing on workflows and data pipelines. Next, we present a semi-automated workflow that extends the building reconstruction pipeline to include procedural context generation using Python and Unreal Engine. Finally, we propose a workflow for integrating various types of large-scale urban analysis data for visualization. We conclude with a series of challenges faced in achieving such pipelines and the limitations of the current approach. However, the steps for a complete, end-to-end solution involve further developing robust systems for building detection, rooftop recognition, and geometry generation and importing and visualizing data in the same 3D environment, highlighting a need for further research and development in this field. Full article

Accurately estimating building heights is crucial for various applications, including urban planning, climate studies, population estimation, and environmental assessment. However, this remains a challenging task, particularly for large areas. Satellite-based Light Detection and Ranging (LiDAR) has shown promise, but it often faces difficulties in distinguishing building photons from other ground objects. To address this challenge, we propose a novel method that incorporates building footprints, relative positions of building and ground photons, and a self-adaptive buffer for building photon selection. We employ the Ice, Cloud, and Land Elevation Satellite 2 (ICESat-2) photon-counting LiDAR, specifically the ICESat-2/ATL03 data, along with building footprints obtained from the New York City (NYC) Open Data platform. The proposed approach was applied to estimate the heights of 17,399 buildings in NYC, and the results showed strong consistency with the reference building heights. The root mean square error (RMSE) was 8.1 m, and for 71% of the buildings, the mean absolute error (MAE) was less than 3 m. Furthermore, we conducted an extensive evaluation of the proposed approach and thoroughly investigated the influence of terrain, region, building height, building density, and parameter selection. We also verified the effectiveness of our approach in an experimental area in Beijing and compared it with other existing methods. By leveraging ICESat-2 LiDAR data, building footprints, and advanced selection techniques, the proposed approach demonstrates the potential to accurately estimate building heights over broad areas. Full article

Light detection and ranging (LiDAR) is a widely used technology for the acquisition of three-dimensional (3D) information about a wide variety of physical objects and environments. However, before conducting a campaign, a test is typically conducted to assess the potential of the utilized algorithm for information retrieval. It might not be a real campaign but rather a simulation to save time and costs. Here, a multi-platform LiDAR simulation model considering the location, direction, and wavelength of each emitted laser pulse was developed based on the large-scale remote sensing (RS) data and image simulation framework (LESS) model, which is a 3D radiative transfer model for simulating passive optical remote sensing signals using the ray tracing algorithm. The LESS LiDAR simulator took footprint size, returned energy, multiple scattering, and multispectrum LiDAR into account. The waveform and point similarity were assessed with the LiDAR module of the discrete anisotropic radiative transfer (DART) model. Abstract and realistic scenes were designed to assess the simulated LiDAR waveforms and point clouds. A waveform comparison in the abstract scene with the DART LiDAR module showed that the relative error was lower than 1%. In the realistic scene, airborne and terrestrial laser scanning were simulated by LESS and DART LiDAR modules. Their coefficients of determination ranged from $0.9108$ to $0.9984$. Their mean was $0.9698$. The number of discrete returns fitted well and the coefficient of determination was $0.9986$. A terrestrial point cloud comparison in the realistic scene showed that the coefficient of determination between the two sets of data could reach $0.9849$. The performance of the LESS LiDAR simulator was also compared with the DART LiDAR module and HELIOS++. The results showed that the LESS LiDAR simulator is over three times faster than the DART LiDAR module and HELIOS++ when simulating terrestrial point clouds in a realistic scene. The proposed LiDAR simulator offers two modes for simulating point clouds: single-ray and multi-ray modes. The findings demonstrate that utilizing a single-ray simulation approach can significantly reduce the simulation time, by over 28 times, without substantially affecting the overall point number or ground pointswhen compared to employing multiple rays for simulations. This new LESS model integrating a LiDAR simulator has great potential in terms of simultaneously simulating LiDAR data and optical images based on the same 3D scene and parameters. As a proof of concept, the normalized difference vegetation index (NDVI) results from multispectral images and the vertical profiles from multispectral LiDAR waveforms were simulated and analyzed. The results showed that the proposed LESS LiDAR simulator can fulfill its design goals. Full article
