The elastic and photoelastic coefficients of Ba₃TaGa₃Si₂O₁₄ (BTGS) crystals were determined by the quantum–mechanical calculation technique. Based on these data, extreme piezo-optic surfaces π′°_km were constructed, which describe the change in the path difference in light beams in the crystal under the influence of mechanical stress. The results for BTGS crystals are compared with the ones for other crystals of the langasite group (La₃Ga₅SiO₁₄, Ca₃Ga₂Ge₄O₁₄, Ca₃TaGa₃Si₂O₁₄ and Ca₃NbGa₃Si₂O₁₄). The global maxima of the π′°_km surfaces for BTGS crystals significantly exceed the ones for the other crystals mentioned above and, accordingly, BTGS crystals can be suitable for use in polarization-optic light modulators and devices based on them. The acousto-optic efficiency of BTGS crystals was evaluated. The correlations between the magnitude of the piezo- and elasto-optic coefficients and the parameters of the unit cell of the studied crystals were determined. Full article

La₃Ga₅SiO₁₄ (langasite, LGS)-based surface acoustic wave (SAW) devices are widely used for industrial health monitoring in harsh high-temperature environments. However, a conventional LGS-based SAW structure has a low quality factor (Q) due to its spurious resonant peaks. A hetero-acoustic layer (HAL)-based structure can effectively enhance the Q factor and the figure of merit (FOM) of SAWs due to its better energy confinement of SAWs. In this work, a HAL-based structure is proposed to achieve a high FOM and high-temperature resistance at the same time. Based on the finite element method (FEM) and coupling-of-model (COM) combined simulation, a systematic numerical investigation was conducted to find the optimal materials and structural parameters considering the viability of an actual fabricating process. After optimizing the layer number, an intermediate-layer material choice and structural parameters, Pt/(0°, 138.5°, 27°) LGS/YX-LGS/SiC HAL structure were chosen. The proposed structure achieves a Q factor and FOM improvement of more than 5 and 2.6 times higher than those of conventional SAW structures, which is important for the development of high temperature SAW sensors. These findings pave a viable method for improving the Q factor and FOM of LGS-based SAW and can provide material and device structural design guidance for fabrication and high-temperature applications in the future. Full article

The ordered Ca₃TaGa₃Si₂O₁₄ and disordered La₃Ga₅SiO₁₄ crystals of the lantangallium silicate family were grown via the Czochralski method. The independent coefficients of thermal expansion of crystals ${\alpha }_c$ and ${\alpha }_a$ were determined using X-ray powder diffraction based on the analysis of X-ray diffraction spectra measured in the temperature range of 25~1000 °C. It is shown that, in the temperature range of 25~800 °C, the thermal expansion coefficients are linear. At temperatures above 800 °C, there is a nonlinear character of the thermal expansion coefficients, associated with a decrease in the Ga content in the crystal lattice. Full article

This study examines the effect of suspensions based on pure glycerol and diamond powder with different concentrations on the characteristics of resonators with a longitudinal electric field. We used two disk resonators made of the quartz and langasite plates with round electrodes on both sides of the plate and resonant frequencies of 4.4 and 4.1 MHz, operating in shear and longitudinal acoustic modes, respectively. Each resonator was mounted on the bottom of a 30 mL liquid container. During the experiments, the container was filled with the suspension under study in such a way that the resonator was completely immersed in the suspension, and the frequency dependences of the real and imaginary parts of the electrical impedance of the resonator were measured. As a result, the shear modulus of the elasticity and shear coefficient of the viscosity of the studied suspensions were determined. The material constants of the suspensions were found by fitting the theoretical frequency dependences of the real and imaginary parts of the electrical impedance of the resonator to the experimentally measured ones, which was calculated using Mason’s equivalent circuit. As a result, the dependencies of the density, shear modulus of elasticity, shear viscosity coefficient, and velocity of the shear acoustic wave on the volume concentration of the diamond particles were constructed. Full article

In the presented paper, we studied bilayer CVD graphene transferred to a langasite substrate and irradiated with a focused electron beam through a layer of polymethyl methacrylate (PMMA). Changes in the Raman spectra and an increase in the electrical resistance of bigraphene after irradiation indicate a local phase transition associated with graphene diamondization. The results are explained in the framework of the theory of a chemically induced phase transition of bilayer graphene to diamane, which can be associated with the release of hydrogen and oxygen atoms from PMMA and langasite due to the “knock-on” effect, respectively, upon irradiation of the structure with an electron beam. Theoretical calculations of the modified structure of bigraphene on langasite and the experimental evaluation of sp³-hybridized carbon fraction indicate the formation of diamane nanoclusters in the bigraphene irradiated regions. This result can be considered as the first realization of local tunable bilayer graphene diamondization. Full article

In the harsh environment of high temperature and high rotation, a single parameter is difficult to satisfy the multi-parameter test requirements of aerospace metallurgy. Therefore, a multi-parameter coplanar integrated surface acoustic wave (SAW) sensor based on Langasite (LGS) is proposed. In this paper, the optimal cut for different measurement parameters is analyzed, and the optimal cut to temperature, pressure and vibration are obtained. The simulation results show that (0°, 138.5°, 25°) LGS has superior second-order temperature sensitivity, the edge of the rectangular sealed cavity is more suitable for pressure sensors, and the optimal cut is (0°, 138.5°, 30°). The stress of the vibration sensor cantilever beam is mainly concentrated on the edge of the fixed end, and the optimal cut is (0°, 138.5°, 35°). Based on the optimal sensitive tangential direction of each sensitive element and the symmetry of the Langasite wafer, the reasonable layout of the coplanar integrated structure with the three parameters of temperature, pressure and vibration is determined. Moreover, according to the optimal orientation selection and reasonable structure layout of each parameter, combined with frequency separation rules, the parameters of interdigital electrode were determined, and the idea of multi-parameter integrated design was simulated and verified. Full article

We proposed a novel Langasite (LGS) bonding method only using high temperature to solve the manufacturing difficulty of the sealed microcavity of pressure sensors. The optimal bonding parameters by comparative experiments were defined as 1350 °C for 3 h. Due to simple experimental conditions, low experimental cost, and be suitable for bonding wafers with various sizes, the method is convenient for popularization and mass-production, thus promoting the development of surface acoustic wave (SAW) devices at high temperatures. Simultaneously, an intact microcavity was observed by scanning electron microscopy, and a tight and void-free bonding interface with a transition layer thickness of 2.2 nm was confirmed via transmission electron microscopy. The results of tensile and leakage experiments indicated that the bonded wafer with the sealed microcavity exhibited a high bonding strength of 4.02 MPa and excellent seal performance. Compared to the original wafer, the piezoelectric constant of the LGS bonded wafer had a reduction of only 4.43%. The above characteristics show that the sealed microcavity prepared by this method satisfies the conditions for fabricating the LGS SAW pressure sensors. Additionally, based on the bonding interface characterizations, the mechanism of LGS bonding has been investigated for the first time. Full article

Langasite crystals (LGS) are known for their exceptional piezoelectric properties at high temperatures up to 1000 °C and more. In this respect, many studies have been conducted in order to achieve surface acoustic wave (SAW) sensors based on LGS crystals dedicated to high-temperature operations. Operating temperatures of more than 1000 °C and 600 °C for wired and wireless sensors, respectively, have been reached. These outstanding performances have been obtained under an air atmosphere since LGS crystals are not stable in high-temperature conditions under a low-oxygen atmosphere due to their oxide nature. However, if the stability of bulk LGS crystals under a high-temperature air atmosphere is well established, the surface deterioration under such conditions has been hardly investigated, as most of the papers dedicated to LGS-based SAW sensors are essentially focused on the development of thin film electrodes that are able to withstand very elevated temperatures to be combined with LGS crystals. Yet, any surface modification of the substrate can dramatically change the performance of SAW sensors. Consequently, the aim of this paper is to study the stability of the LGS surface under a high-temperature air environment. To do so, LGS substrates have been annealed in an air atmosphere at temperatures between 800 and 1200 °C and for durations between one week and one month. The morphology, microstructure, and chemical composition of the LGS surface was examined before and after annealing treatments by numerous and complementary methods, while the surface acoustic properties have been probed by SAW measurements. These investigations reveal that depending on both the temperature and the annealing duration, many defects with a corolla-like shape appear at the surface of LGS crystals in high-temperature prolonged exposure in an air atmosphere. These defects are related to the formation of a new phase, likely an oxiapatite ternary compound, the chemical formula of which is La₁₄Ga_xSi_9−xO_39−x/2. These defects are located on the surface and penetrate into the depth of the sample by no more than 1–2 microns. However, SAW measurements show that the surface acoustic properties are modified by the high-temperature exposure at a larger deepness of at least several tens of microns. These perturbations of the LGS surface acoustic properties could induce, in the case of LGS-based SAW sensors operating in the 434 MHz ISM band, temperature measurement errors around 10 °C. Full article

Performing high-temperature measurements on the rotating parts of aero-engine systems requires wireless passive sensors. Surface acoustic wave (SAW) sensors can measure high temperatures wirelessly, making them ideal for extreme situations where wired sensors are not applicable. This study reports a new SAW temperature sensor based on a langasite (LGS) substrate that can perform measurements in environments with temperatures as high as 1300 °C. The Pt electrode and LGS substrate were protected by an AlN passivation layer deposited via a pulsed laser, thereby improving the crystallization quality of the Pt film, with the function and stability of the SAW device guaranteed at 1100 °C. The linear relationship between the resonant frequency and temperature is verified by various high-temperature radio-frequency (RF) tests. Changes in sample microstructure before and after high-temperature exposure are analyzed using scanning electron microscopy (SEM) and X-ray diffraction (XRD). The analysis confirms that the proposed AlN/Pt/Cr thin-film electrode has great application potential in high-temperature SAW sensors. Full article

The dispersion relation of elastic Bloch waves in 1-3 piezoelectric phononic structures (PPnSs) with Langasite (La₃Ga₅SiO₁₄) inclusions in a polymeric matrix is reported. Langasite presents promising material properties, for instance good temperature behaviour, high piezoelectric coupling, low acoustic loss and high quality factor. Furthermore, Langasite belongs to the point group 32 and has a trigonal structure. Thus, the 2-D bulk wave propagation in periodic systems with Langasite inclusions cannot be decoupled into XY and Z modes. The improved plane wave expansion (IPWE) is used to obtain the dispersion diagram of the bulk Bloch waves in 1-3 PPnSs considering the classical elasticity theory and D₃ symmetry. Full band gaps are obtained for a broad range of frequency. The piezoelectricity enhances significantly the band gap widths and opens up a narrow band gap in lower frequencies for a filling fraction of 0.5. This study should be useful for surface acoustic wave (SAW) filter and 1-3 piezocomposite transducer design using PPnSs with Langasite. Full article

Platinum (Pt) gratings on langasite (LGS) substrates are a widely used structures in high temperature surface acoustic wave (SAW) devices. Multiple modes can be excited in Pt$/$LGS SAW devices owing to the heavy weight of the Pt electrode and leaky waves in the LGS substrate. In this work, we report on a detailed mode analysis of Pt$/$LGS SAW devices, where three commonly used LGS cuts are considered. A three-dimensional (3D) finite element method (FEM) numerical model was developed, and the simulation and experiment results were compared. The experiment and simulation results showed that there are two modes excited in the Pt$/$LGS SAW devices with Euler angle (0$°$, 138.5$°$, 27$°$) and (0$°$, 138.5$°$, 117$°$), which are Rayleigh-type SAW and SH-type leaky wave, respectively. Only the Rayleigh-type mode was observed in the Pt$/$LGS SAW devices with Euler angle (0$°$, 138.5$°$, 72$°$). It was found that the acoustic velocities are dependent on the wavelength, which is attributed to the change of wave penetration depth in interdigital transducers (IDTs) and the velocity dispersion can be modulated by the thickness of the Pt electrode. We also demonstrated that addition of an Al₂O₃ passivation layer has no effect on the wave modes, but can increase the resonant frequencies. This paper provides a better understanding of the acoustic modes of Pt$/$LGS SAW devices, as well as useful guidance for device design. It is believed that the Rayleigh-type SAW and SH-type leaky waves are potentially useful for dual-mode sensing applications in harsh environments, to achieve multi-parameter monitoring or temperature-compensation on a single chip. Full article

We present a possible method to reduce the anisotropy of the thermal stress generated on langasite-type La₃Ta_0.5Ga_5.5O₁₄ (LTG) piezoelectric crystals arising from the mismatch of the thermal expansion coefficients and Young’s moduli of the crystals and metals at high temperatures. To formulate this method, the thermal stresses of order-type langasite crystals, in which each cation site is occupied by one element only, were calculated and compared to each other. Our results suggest that the largest cation site affects the thermal stress. We attempted to replace La³⁺ in LTG by a larger ion and considered Sr²⁺. Single crystals of strontium-substituted LTG (Sr-LTG) were grown using the Czochralski method. The thermal stress along the crystallographic c-axis decreased but that perpendicular to the c-axis increased by strontium substitution into the LTG crystal. The anisotropic thermal stress was reduced effectively. The Sr-LTG single crystal is a superior candidate material for pressure sensors usable at high temperatures. Full article

Recently, the iron containing langasite-type crystal Ba₃NbFe₃Si₂O₁₄ has attracted great attention as a new magnetically induced multiferroic. In this work, magnetic, structural and electronic properties of the multiferroic Ba₃NbFe₃Si₂O₁₄ were investigated by several methods, including synchrotron X-ray diffraction, Raman spectroscopy and synchrotron Mössbauer source technique at high quasi-hydrostatic pressures (up to 70 GPa), created in diamond anvil cells. At room temperature, two structural transitions at pressures of about 3.0 and 17.5 GPa were detected. Mössbauer studies at high pressures revealed a radical change in the magnetic properties during structural transitions. At pressures above 18 GPa, the crystal transforms into two magnetic fractions, and in one of them the Néel temperature (T_N) increases by about four times compared with the T_N value in the initial phase (from 27 to 115 K). At pressures above 50 GPa, a spin crossover occurs when the fraction of iron Fe³⁺ ions in oxygen octahedra transits from the high-spin (HS, S = 5/2) to the low-spin (LS, S = 1/2) state. This leads to a new change in the magnetic properties. The magnetic ordering temperature of the LS sublattice was found to be of about 22(1) K, and magnetic correlations between HS and LS sublattices were studied. Full article

Research has shown that SAW (surface acoustic wave) devices with an LGS/Pt (langasite La₃Ga₅SiO₁₄/platinum) structure are useful in high-temperature sensor applications. Extreme high temperature brings great acoustic attenuation because of the thermal radiation loss, which requires that the sensing device offer a sufficiently high quality factor (Q) and a low loss. Therefore, it is necessary to improve the performance of the quality factor as much as possible so as to better meet the application of high-temperature sensors. Based on these reasons, the main work of this paper was to extract accurate simulation parameters to optimize the Pt/LGS device and obtain Q-value device parameters. Optimization of SAW devices with LGS/Pt structure for sensing extreme high temperature was addressed by employing a typical coupling of modes (COM) model in this work. Using the short pulse method, the reflection coefficient of Pt electrodes on LGS substrate was extracted accurately by characterizing the prepared SAW device with strategic design. Other relevant parameters for COM simulation were determined by finite element analysis. To determine the optimal design parameters, the COM simulation was conducted on the SAW sensing device with a one-port resonator pattern for sensing extreme temperature, which allows for a larger Q-value and low insertion loss. Experimental results validate the theoretical simulation. In addition, the corresponding high-temperature characteristics of the prepared sensing device were investigated. Full article

We propose a novel langasite crystal microbalance (LCM) sensor with a graphene-based sensing medium to detect and discriminate volatile organic compounds (VOCs) at room temperature. A thin film of graphene oxide embedded with Pt nanostructures (GO-Pt nanocomposite) was deposited on the electrode surface of the LCM, a thickness-shear acoustic wave resonator. Ethyl acetate, acetic acid, and ethanol were chosen as typical VOCs for this study. Sensitivity and selectivity of coated LCM were investigated for different concentrations of the VOCs by analysing the resonant properties of the sensor. When exposed to VOCs, a negative shift in series resonance frequency was observed due to the mass loading of VOC molecules. Simultaneously, changes in equivalent resistance and parallel resonance frequency of the sensor were also observed due to the interaction of VOCs with charge carriers on the GO-Pt nanocomposite film surface. This dual measurement of both series and parallel resonance frequencies allowed for detection and discrimination of VOCs. Moreover, the high thermal stability of langasite makes the proposed sensor suitable even for harsh environmental conditions. Full article
