Search Results (998)

Sequential ultrasonic spot welding is an interesting joining method for overlapping thermoplastic composite structures. In the framework of the EU Clean Aviation Multi-functional Fuselage Demonstrator (MFFD) and the lower shell SmarT multifunctional and INteGrated TP fuselage (STUNNING) projects, SAM XL and TU Delft Aerospace Engineering collaboratively developed and demonstrated a robot-based sequential ultrasonic spot welding process for the sub-assembly of structural frames and clips in a fuselage section demonstrator. This full-scale thermoplastic composite fuselage section demonstrator, which was recently awarded the 2025 JEC Innovation award, measures 8.0 m in length and 4.0 m in diameter. Our robot-based sequential ultrasonic spot welding technology played an important role in ensuring the joining of structural clips and frames in the stiffened fuselage skin of the demonstrator, through the use of more than 1600 spot welded joints with an average welding time of approximately 10 s per spot, thereby significantly reducing cycle times as compared to traditional joining methods such as fastening or riveting. This paper provides a comprehensive overview of the technology development process and highlights the results achieved during the sub-assembly of the demonstrator, as well as the challenges encountered. Full article

As a solid-state joining technology, friction stir welding (FSW) exhibits significant advantages for joining aluminium alloys, including low heat input and minimal formation of intermetallic compounds, thereby enhancing joint quality and mitigating deformation. This study investigates the single-sided and double-sided FSW processes of 3 mm thick 7075-T6 aluminium alloy sheets, focusing on characterising the microstructure and mechanical properties of the joints. Experimental results show that at a rotational speed of 1500 rpm and a welding speed of 80 mm/min, the double-sided co-directional FSW joint achieves a tensile strength of 388 MPa and an elongation of 7.09%, significantly outperforming those of the other two welding paths. In the weld nugget zone (WNZ), continuous dynamic recrystallization (CDRX) occurs, generating uniformly refined equiaxed grains (average size: 1.10 μm) and facilitating the transformation of low-angle grain boundaries (LAGBs) to high-angle grain boundaries (HAGBs). Meanwhile, the strong rotated cube texture is remarkably weakened and replaced by random recrystallized brass textures with the lowest kernel average misorientation (KAM) value in the WNZ. In contrast, the thermo-mechanically affected zone (TMAZ) accumulates a high density of LAGBs due to welding-induced plastic deformation. Microhardness testing reveals a typical “W”-shaped distribution: WNZ hardness is relatively high but slightly lower than that of the base metal (BM), and the minimum hardness of the advancing side (AS) of the heat-affected zone (HAZ) is higher than that of the retreating side (RS). This study confirms that double-sided co-directional FSW crucially regulates microstructural evolution and improves the mechanical properties of 7075-T6 aluminium alloy joints, providing a viable process optimisation strategy for high-quality welding of thin-gauge sheets. Full article

Additive manufacturing (AM) is a significant contributor to Industry 4.0. However, one considerable challenge is usually encountered by AM due to the bed size limitations of 3D printers, which prevent them from being adopted. An appropriate post-joining technique should be employed to address this issue properly. This study investigates the influence of key friction stir butt welding (FSBW) factors (FSBWFs), such as tool rotational speed (TRS), tool traverse speed (TTS), and pin profile (PP), on the weldability of 3D-printed PLA–Chromium (PC) composites (3PPCC). A filament containing 10% by weight of chromium reinforced in PLA was used to prepare samples. The material extrusion additive manufacturing process (MEX) was employed to prepare the 3D-printed PCC. A Taguchi-based design of experiments (DOE) (L9 orthogonal array) was employed to systematically assess weld hardness (WH), weld temperature (WT), weld strength (WS), and weld efficiency. As far as the 3D-printed samples were concerned, two distinct infill patterns (linear and tri-hexagonal) were also examined to evaluate their effect on joint performance; however, all other 3D printing factors were kept constant. Experimentally validated findings revealed that weld efficiency varied significantly with PP and infill pattern, with the square PP and tri-hexagonal infill pattern yielding the highest weld efficiency, i.e., 108%, with the corresponding highest WS of 30 MPa. The conical PP resulted in reduced WS. Hardness analysis demonstrated that tri-hexagonal infill patterns exhibited superior hardness retention, i.e., 46.1%, as compared to that of linear infill patterns, i.e., 34%. The highest WTs observed with conical PP were 132 °C and 118 °C for both linear and tri-hexagonal infill patterns, which were far below the melting point of PLA. The lowest WT was evaluated to be 65 °C with a tri-hexagonal infill, which is approximately equal to the glass transition temperature of PLA. Microscopic analysis using a coordinate measuring machine (CMM) indicated that optimal weld zones featured minimal void formation, directly contributing to improved weld performance. In addition, scanning electron microscopy (SEM) and energy-dispersive X-ray spectroscopy (EDX) were also performed on four deliberately selected samples to examine the microstructural features and elemental distribution in the weld zones, providing deeper insight into the correlation between morphology, chemical composition, and weld performance. Full article

Resistance spot welding (RSW) is one of the dominant joining processes in body-in-white manufacturing within the automotive industry, while the use of aluminum alloys continues to increase. This study investigates the influence of key process parameters on the spot diameter in RSW of the aluminum alloys EN AW-5182 (AL5-STD) and EN AW-6005 (AL6-HDI). Experiments were performed using industry-standard robotic welding equipment in a partially automated welding cell. Welding current, electrode force, sheet thickness (1–3 mm), and adhesive application were systematically varied. The welded joints were evaluated by destructive testing to determine spot diameter. The results show that higher welding currents increase the spot diameter for both alloys, while higher electrode forces decrease it. EN AW-5182 exhibited a high tendency toward expulsion, whereas no expulsions occurred for EN AW-6005 under identical conditions. The application of the structural adhesive BETAMATE™ 1640 consistently increased the spot diameter. Full article

This study investigated the dynamic behavior of AA7075 plates joined by Friction Stir Welding (FSW), focusing on the influence of key process parameters, rotation, and traverse speeds, on the resulting dynamic characteristics. Experimental Modal Analysis (EMA) was performed under free boundary conditions to determine resonance frequencies, mode shapes, and damping ratios, revealing that an increase in traverse speed consistently led to a decrease in natural frequencies across most modes, thereby indicating reduced joint stiffness attributed to insufficient heat input. Furthermore, localized weld defects caused significant damping variations, particularly in low-order modes. To complement the experimental findings and enable simultaneous, multi-output prediction of these coupled dynamic parameters, a Co-Active Neuro-Fuzzy Inference System (CANFIS) model was developed. The CANFIS architecture utilized spindle speed and feed rate as inputs to predict natural frequency and damping ratio for multiple vibration modes as tightly coupled outputs. The trained model demonstrated strong agreement and high predictive accuracy against the EMA experimental data, with convergence analysis confirming its stable learning and excellent generalization capability. The successful integration of EMA and CANFIS establishes a robust hybrid framework for both physical interpretation and intelligent, coupled prediction of the dynamic behavior of FSW-welded AA7075 plates. Full article

Reliable joining of multi-layer aluminum foil current collectors is crucial for enhancing the performance and safety of high-capacity lithium-ion batteries. However, laser welding of such thin-thick aluminum combinations is often hindered by porosity, cracks and unstable weld-pool behavior. In this study, a ring-mode fiber laser combined with sinusoidal oscillation and linearly gradient power modulation was employed to achieve high-quality lap welding between 80 layers of 1060 aluminum foil (1 mm in total thickness) and a 1.5 mm thick aluminum plate. Welding experiments and thermo-mechanical simulations were conducted to investigate the effects of welding speed (15–45 mm/s) and central-power modulation parameters (−2, 0, +2, +4) on weld morphology, defect formation, and mechanical properties. The results indicate that increasing the welding speed can effectively suppress cracks and improve the shear strength from 249.8 N to 403.9 N, but it also leads to an increase in porosity from 5.78% to 12.26% and deterioration of the weld reinforcement. Higher central-power modulation (+2, +4) transformed the weld-pool geometry from an ω shape to U shape, effectively suppressing fusion-line cracks but leading to increased porosity (up to 8.41%) and deteriorated surface morphology. Overall, a low welding speed of 15 mm/s combined with an optimized power modulation strategy achieves effective crack suppression while maintaining controlled porosity, resulting in a welded joint with superior comprehensive performance. This research provides a robust process solution for high-quality laser welding of multi-layer aluminum foil current collectors in power battery manufacturing. Full article

The rise in electric vehicles (EVs) with lithium-ion batteries supports net-zero goals, but the increasing demand will inevitably generate more battery waste. Current pack designs often rely on permanent joining techniques, which hinder disassembly and thereby limit serviceability, reuse and recycling. A critical challenge is the removal of the battery lid, typically bonded to the pack frame with sealant adhesives. In the absence of design for disassembly requirements for OEMs, this study investigates a novel debonding strategy focused on the lid-to-frame bonding. A silane-based adhesive commonly used in battery packs is first characterised under tensile, shear and mode I conditions to establish the baseline performance in the range of flexible adhesive properties. Herein, a heat-activated primer is introduced as a debondable interfacial layer between the adhesive and the substrate. Upon activation at 150 °C, the primer significantly reduces adhesion, around 98% of the initial joint strength, enabling room temperature debonding. The primer demonstrates strong compatibility with epoxy and polyurethane adhesives, but its performance with silane-based systems still needs to be improved in terms of the primer’s compatibility with silane-based adhesives. Finally, a small-scale testing apparatus is developed to evaluate primer effectiveness in the disassembly of battery lids. This approach represents a promising step toward more serviceable, recyclable and sustainable battery systems. Full article

Friction stir spot welding (FSSW) is a novel variant of Friction Stir welding (FSW), developed by Mazda Motors and Kawasaki Heavy Industries to join similar and dissimilar materials in a solid state. It is an economic and environmentally friendly alternative to resistance spot welding (RSW). The FSSW technique, however, includes some structural defects imbedded within the weld joint, such as keyhole formation, hook crack, and bond line oxidation challenging the joint strength. The unique properties of nanomaterials in the reinforcement of metal matrices motivated researchers to enhance the FSSW joints’ strength. Previous studies successfully fabricated nano-reinforced FSSW joints. At different volumetric ratios of nano-reinforcement, nanoparticles may agglomerate due to inefficient stirring of the welding tool pin, forming stress concentration sites and brittle phases, affecting tensile and fatigue strength under static and cyclic loading conditions, respectively. This work investigated how the welding tool pin affects stirring efficiency by controlling the distribution of a nano-reinforcing material within the joint stir zone (SZ), and thus the tensile and fatigue strength of the FSSW joints. Sheets of AA6061-T6 of 1.8 mm thickness were used as a base material. In addition, graphene nanoplatelets (GNPs) with lateral sizes of 1–10 µm and thicknesses of 3–9 nm were used as nano-reinforcements. GNP-reinforced FSSW specimens were prepared and successfully fabricated. Optical microscope (OM) and field emission scanning electron microscope (FE-SEM) methods were employed to visualize the GNPs’ incorporation into the SZs of the FSSW joints. Micrographs of as-welded specimens showed lower formations of scattered, clustered GNPs achieved by the threaded pin tool compared to continuous agglomerations observed when the cylindrical pin tool was used. Tensile test results revealed a significant improvement of about 30% exhibited by the threaded pin tool compared to the cylindrical pin tool, while fatigue test showed an improvement of 46–24% for the low- and high-cycle fatigue, respectively. Full article

The reliable joining of dissimilar stainless steel and carbon steel remains a critical challenge in Metal Inert Gas (MIG) welding due to complex thermal–metallurgical interactions and the formation of brittle phases at the weld interface. In this study, a Taguchi-based design of experiments was employed to systematically optimize MIG welding parameters for SUS201/S20C dissimilar joints using a SUS201 filler wire, with particular attention to the welding current, voltage, travel speed, and electrode stick-out. The welding process was performed using an automatic welding robot. Tensile specimens were tested on a universal testing machine. Microstructural analysis was performed using a metallurgical microscope. The microstructure reveals that the development of the carbon side’s large ferrite and the stainless steel side’s δ-ferrite both significantly degrade joint quality. Among all process parameters, electrode stick-out is identified as the most influential parameter governing both tensile and bending performance, highlighting a critical process sensitivity that has received limited attention in prior studies. Optimized parameter combinations are required to maximize tensile and flexural responses. The highest tensile strength is 450.96 MPa. These findings advance the understanding of parameter–microstructure–property relationships in dissimilar MIG welding. Future work applying numerical welding simulations and advanced evaluation techniques is recommended. Full article

This study presents the development and mechanical characterization of a full-scale helmet manufactured from a polyester matrix composite reinforced with woven jute fabric using vacuum infusion. Laminates with two and four reinforcement layers were produced and assembled using four joining configurations: seamless, stitched, bonded, and hybrid (bonded + stitched). Tensile tests were performed according to ASTM D3039, while frontal and lateral compression tests followed ABNT NBR 7471, aiming to evaluate the influence of laminate thickness and joining strategy on mechanical performance. In tension, the seamless configuration reached maximum loads of 0.80 kN (two layers) and 1.60 kN (four layers), while the hybrid configuration achieved 0.79 kN and 1.43 kN, respectively. Stitched and bonded joints showed lower strength. Under compression, increasing the laminate thickness from two to four layers reduced frontal elongation from 15.09 mm to 9.97 mm and lateral elongation from 13.73 mm to 7.24 mm, corresponding to stiffness gains of 50.3% and 87.3%, respectively. Statistical analysis (ANOVA/Tukey, α = 0.05) confirmed significant effects of thickness and joint configuration. Although vacuum infusion is a well-established process, the novelty of this work lies in its application to a full-scale natural-fiber helmet, combined with a systematic evaluation of joining strategies and a direct correlation between standardized tensile behavior and structural compression performance. The four-layer hybrid laminate exhibited the best balance between strength, stiffness, and deformation capacity. Full article

The search for innovative solutions in the field of construction materials used in aircraft manufacturing has led to the development of composite materials, particularly CFRP polymer composites. Composite airframe components, which are required to have high strength, are joined using mechanical fasteners. Considering that the composite consists of a polymer matrix, which is a material susceptible to rheological phenomena occurring rapidly at elevated temperature, there is a high probability of significant changes in the strength and performance properties. Coupled thermal and mechanical loads on composite material joints occur in everyday aircraft operation. Experimental tests were conducted using a quasi-isotropic CFRP on an epoxy resin matrix with aerospace certification. The assessment of changes in the strength parameters of the material itself showed a decrease of approx. 40% in its short-term strength at 80 °C compared to the ambient temperature and a decrease in the load-bearing capacity of single-lap bolted joints of over 25%. Even more rapid changes were observed when assessing the fatigue life of the joints assessed at ambient and elevated temperature. In addition, the actual glass transition temperature of the resin was determined using the DSC technique. Analysis of the damage mechanisms showed that at 80 °C, the main degradation mechanisms of the material are accelerated creep processes of the CFRP and softening of the matrix, increasing its susceptibility to damage in the joint area. Full article

Ensuring friction stir welding (FSW) joint quality typically relies on ultrasonic testing (UT) and radiographic testing (RT), but achieving complete coverage is challenging, and echo-based defect discrimination becomes difficult in dissimilar joints. Laser ultrasonics is a promising non-contact technique that remotely assesses weld quality and provides high spatial resolution at the generation and detection points. This study establishes a laser-ultrasonic method for defect detection in dissimilar Cu–Al FSW joints. Slit-like artificial defects (0.1–2.5 mm deep in 5 mm thick plates) were introduced at the Al-side interface of specimens fabricated with an Al-offset tool. Experiments and numerical simulations were used to evaluate wave modes and irradiation configurations, focusing on intensity-attenuation ratios of specific wave types, including longitudinal and Rayleigh waves. On the non-slit surface, attenuation of reflected longitudinal waves enabled detection of defects ≥0.5 mm deep. On the slit surface, Rayleigh-wave attenuation allowed identification of defects as shallow as 0.1 mm, although slit-side irradiation may be less practical during joining. These results demonstrate that defect identification in dissimilar materials can be achieved by evaluating wave-intensity attenuation rather than relying solely on the presence of reflected echoes, suggesting potential for implementing laser ultrasonics in in-process monitoring of FSW joints. Full article

Friction stir welding (FSW) was employed to achieve a reliable joining of 2 mm thick dissimilar metals, 6061 aluminum alloy and AZ31B magnesium alloy. This study revealed the evolution of interfacial interlocking features and their impact on the mechanical properties of the joints under different welding speeds (25–35 mm/min). The results indicate that the Al/Mg FSW joint interface exhibits a strip-like interlaced structure, the morphological characteristics of which are closely related to the welding speed. For quantitative analysis, the ratio of interlocking length to plate thickness (embedding ratio) was used as a quantitative indicator of the structural interlocking feature. As the welding speed increased from 25 mm/min to 35 mm/min, the embedding ratio decreased from 13.2 to 7.9, and the average thickness of the intermetallic compound (IMC) layer decreased from 2.71 μm to 2.19 μm. Transmission Electron Microscopy (TEM) results confirmed that the Al/Mg FSW joint interface consists of a bilayer of IMCs, specifically Al₃Mg₂ and Al₁₂Mg₁₇, with thicknesses of 220 nm and 470 nm, respectively. Tensile testing of joints with different embedding ratios demonstrated that the tensile strength of the welded joint exhibits a positive correlation with the embedding ratio, reaching a maximum of 178 MPa. Full article

The dissimilar joining of solid-solution-strengthened superalloys and precipitation-strengthened superalloys enables complementary performance synergy, holding significant application potential in the aerospace industry. This study investigated the transient liquid phase bonding of Hastelloy X and IN738 using a BNi-2 interlayer, focusing on the effects of bonding temperature and time on interfacial microstructure evolution and mechanical properties. The results demonstrated that achieving complete isothermal solidification is paramount for joint properties, a process governed by the synergistic control of bonding temperature and time. At lower temperatures (e.g., 1050 °C), the joint centerline contained an athermal solidification zone (ASZ) rich in hard and brittle Cr-rich (∼15.9 GPa) and Ni-rich borides, which served as the failure initiation site. As the ASZ was progressively eliminated with increasing temperature, a fully isothermal solidified zone (ISZ, ∼52 μm wide) consisting of γ-Ni formed at 1100 °C. Concurrently, Cr-Mo borides (∼9.8 GPa) precipitated within the diffusion-affected zone (DAZ) on the Hastelloy X side, becoming the new potential sites for crack initiation. Prolonging the holding time at 1100 °C not only ensured complete isothermal solidification but also promoted Mo diffusion, which improved the plasticity of the Cr-Mo borides and their interfacial bonding with the γ-Ni matrix (∼5.9 GPa). This synergistic optimization resulted in a significant increase in joint shear strength, achieving a maximum value of 587 MPa under the optimal condition of 1100 °C/40 min. Full article

This study investigates the microstructure and mechanical properties of a dissimilar joint formed by rotary friction welding, which joins TC4 titanium alloy to 304 stainless steel using an Inconel 718 interlayer. The welding parameters were as follows: a friction time of 9 s, a friction pressure of 160 MPa, an upset time of 2 s, a forging pressure of 250 MPa, and a rotational speed of 1400 rpm. Microstructural analysis revealed the formation of intermetallic compounds (IMCs), including Fe₂Ti, Ni₃Ti, NiCrFe, FeNi₃, Ti₂Ni, and FeNi, at the TC4/Inconel 718 interface, while Ni₃Ti and FeNi₃ IMCs were identified at the Inconel 718/304SS interface. The tensile tests demonstrated that the joint with the Inconel 718 interlayer (TC4/Inconel 718/304SS) achieved an ultimate tensile strength (UTS) of 717.73 MPa and an elongation of 13.05%. In contrast, the direct joint without the interlayer (TC4/304SS) exhibited a lower UTS of 631.58 MPa and a reduced elongation of 7.39%. Therefore, the introduction of the Inconel 718 interlayer significantly improved joint quality, increasing tensile strength by 13.64% and elongation by 76.59%. More importantly, the interlayer effectively inhibited the formation of brittle Ti-Fe intermetallic compounds, which are typically detrimental to joint performance. Full article
