Search Results (21)

This paper presents a novel Earth-System Stratified Grid (ISEA4H-ESSG) model, designed to address the challenges in multi-layer geoscience data management and analysis. In the realm of geosciences, which encompasses the solid earth, atmosphere, hydrosphere, and biosphere, as well as planetary and space sciences, the effective integration of diverse data sources is crucial. Traditional grids have limitations in three-dimensional spatial modeling, cross-layer data fusion, and dynamic multi-scale analysis. The ISEA4H-ESSG model overcomes these drawbacks by integrating the Icosahedral Snyder Equal-Area Aperture 4 Hexagon Discrete Global Grid System (ISEA4H DGGS) with a degenerative subdivision mechanism. It adheres to six core principles, including stratified spherical coverage, geographic consistency, multi-scale dynamic adaptability, global seamless partitioning, encoding uniqueness and efficiency, and multi-source data compatibility. Through the independent subdivision of spherical and radial layers, this model balances resolution differences and resolves polar-grid distortion and cross-layer data heterogeneity issues. The introduction of a four-dimensional spatiotemporal encoding framework enhances the storage and parallel computing capabilities of massive datasets. Case studies on ionosphere three-dimensional modeling and global atmospheric temperature field formatting demonstrate the high precision and adaptability of the ISEA4H-ESSG model. This research provides a unified spatial data infrastructure for geosciences, facilitating in-depth studies on natural hazards, climate change, and planetary evolution, and offering new perspectives for international partnerships and future Earth-related research. Full article

As the peak of solar cycle 25 approaches, increased ionospheric and scintillation activity is being observed, which is negatively impacting the quality of GNSS measurements and presenting challenges in the positioning domain. Ionospheric refraction and diffraction introduce delays and distortions to GNSS carrier phase measurements, leading to positioning errors that exceed the anticipated accuracies. These position errors can be a significant concern for users across the world who depend on precise GNSS positioning, such as in agriculture, offshore marine positioning and autonomous automotive positioning. To understand the direct impact on NovAtel receivers and its positioning engines, a comprehensive analysis was conducted. A closer look was taken at what happened in 2023–2024 by characterizing scintillation using the amplitude scintillation index (S4) values in an equatorial region. Additionally, the scintillation effect on the receivers was characterized through the analysis of C/N0, lock breaks, double differences and other indicators. With a substantial amount of data collected at 20° latitude, where high solar activity occurs due to the proximity to the equator, the positioning performance of Real-Time Kinematic (RTK) and Precise Point Positioning (PPP) was analyzed. Full article

Satellite-borne electromagnetic pulse (EMP) detection technology plays an important role in military reconnaissance, space environment monitoring, and early warning of natural disasters. However, the complex ionosphere greatly distorts the waveform during propagation and poses a challenge to EMP detection. Therefore, it is necessary to conduct theoretical research on EMP propagation in the ionosphere. Conventional second-order pseudo-spectral time-domain (PSTD-2) algorithm has difficulties in keeping the stability and accuracy of waveforms in calculations over hundreds of kilometers of propagation. To overcome the difficulties, a fourth-order PSTD algorithm incorporating the moving window technique (MWPSTD-4) is proposed. In the numerical examples, the performance of MWPSTD-4 is compared with PSTD-4 and PSTD-2 in the long-distance propagation of EMP. The results show that the MWPSTD-4 improves efficiency while guaranteeing accuracy and is suitable for large-scale electromagnetic field simulation. The proposed method provides a basic algorithm to eliminate the numerical dispersion interference for calculating the long-distance propagation of EMP in complex spaces and is helpful for the design and calibration of satellite-borne EMP detectors. Full article

A propagation of ultrawideband electromagnetic pulses (UWB EMPs) through magnetized plasma has been experimentally studied using a “gigantic” coaxial line, which has been developed at IAP RAS for laboratory modeling of ionospheric effects. This coaxial line is 1.4 m in diameter and 10 m in length and is installed inside the chamber of the large-scale Krot plasma device. The line can be filled with rf inductively coupled plasma, magnetized or not. It allows one to explore the propagation of UWB EMPs in plasma along a long path without refraction and divergence and obtain a physical picture of EMP transformation. Under conditions where the duration of the UWB EMP is comparable to the period of electron plasma oscillations (f_p⁻¹), the period of cyclotron rotation of electrons (f_c⁻¹), or even significantly shorter, a complex of effects of transformation of the waveform and frequency spectrum of the pulse occurs. Without ambient magnetic field, a UWB EMP is distorted due to the effects of the cutoff and frequency dispersion. In dense magnetized plasma, i.e., when f_p >> f_c, the UWB EMP breaks into two wave packets, the high-frequency one (f > f_p) and low-frequency one (f < f_c). In rare magnetized plasma (f_p << f_c), the cyclotron absorption produces a long train of damped oscillations at a frequency close to the cyclotron frequency f_c following the UWB EMP. Full article

We present a position and attitude estimation algorithm of moving platforms based on the tightly coupled sensor fusion of low-cost multi baseline GNSS, inertial, magnetic and barometric observations obtained by low-cost sensors and affordable dual-frequency GNSS receivers. The sensor fusion algorithm is realized by an Extended Kalman Filter and estimates the states including GNSS receiver inter-channel biases, integer ambiguities and non-GNSS receiver biases. Tightly coupled sensor fusion increases the reliability of the position and attitude solution in challenging environments such as urban canyons by utilizing the inertial observations in case of GNSS outage. Moreover, GNSS observations can be efficiently used to mitigate IMU sensor drifts. Standard GNSS cycle slips detection methods, such as the application of triple differences or linear combinations such as Melbourne–Wübbena combination and the phase ionospheric residual extended TurboEdit method. However, these techniques are not well suited for the localization in quickly changing environments such as urban canyons. We present a new method of tightly coupled sensor fusion supported by a prediction based cycle slip detection technique, applied to a GNSS setup using three antennas leading to multiple moving baselines on the platform. Thus, not only the GNSS signal properties but also the dynamics of the moving platform are considered in the cycle slip detection. The developed algorithm is tested in an open-sky validation measurement and two sets of measurement in an urban canyon area. The sensor fusion algorithm processes the data sets using the proposed prediction-based cycle slip method, the loss-of-lock indicator-based, and for comparison, the Melbourne–Wübbena and the TurboEdit cycle slip detection methods are also included. The obtained position and attitude estimation results are compared to the internal solution of raw data source GNSS receivers and to the observations of a high-accuracy GNSS/INS unit including a fiber optic gyro. The validation test confirms the proper cycle slip detection in an ideal environment. The more challenging urban canyon test results show the reliability and the accuracy of the proposed method. In the case of the second urban canyon test, the proposed method improved the integer ambiguity resolution success rate by 19% and these results show the lowest horizontal and vertical coordinate distortion in comparison of the linear combination and the loss-of-lock-based cycle slip methods. Full article

Modern space missions provide a great number of height profiles of ionospheric electron density, measured by the remote sensing technique of radio occultation (RO). The deducing of the profiles from the RO measurements suffers from bias, resulting in negative values of the electron density. We developed a machine learning technique that allows automatic identification of ionospheric layers and avoids the bias problem. An algorithm of convolutional neural networks was applied for the classification of the height profiles. Six classes of the profiles were distinguished on the base of prominent ionospheric layers F2, Es, E, F1 and F3, as well as distorted profiles (Sc). For the models, we selected the ground truth of more than 712 height profiles measured by the COSMIC/Formosat-3 mission above Taiwan from 2011 to 2013. Two different models, a 1D convolutional neural network (CNN) and fully convolutional network (FCN), were applied for classification. It was found that both models demonstrate the best classification performance, with the average accuracy around 0.8 for prediction of the F2 layer-related class and the E layer-related class. The F1 layer is classified by the models with good performance (>0.7). The CNN model can effectively classify the Es layer with an accuracy of 0.75. The FCN model has good classification performance (0.72) for the Sc-related profiles. The lowest performance (<0.4) was found for the F3 layer-related class. It was shown that the more complex FCN model has better classification performance for both large-scale and small-scale variations in the height profiles of the ionospheric electron density. Full article

Under the influence of space weather, abnormal disturbances in the ionosphere will distort the ionosphere model seriously and affect the global navigation satellite system negatively. This study analyzes the ionospheric activity characteristics and the ionospheric model performance in low latitude during a strong geomagnetic storm from 7 to 9 September 2017. The research goals are to determine the abnormal behavior of the ionosphere during the geomagnetic storm and to refine the ionosphere model in the low latitude. In the experiment, the vertical total electron content (VTEC) peak value at low latitudes caused by this geomagnetic storm was significantly higher than that on the geomagnetic quiet day, and the VTEC peak value increased by approximately 75%. In the main phase of the geomagnetic storm, the degree of VTEC variation with longitude is significantly higher than that of the geomagnetic quiet day. The VTEC variation trend in the northern hemisphere is more severe than that in the southern hemisphere. In the region where VTEC decreases with longitude, the VTEC in the northern hemisphere is higher than that in the southern hemisphere on the same longitude at low latitudes, and this phenomenon is not significantly affected by the geomagnetic disturbance of the recovery phase. During the geomagnetic storm, the daily minimum value of VTEC at different latitudes was basically the same, approximately 5 TECU, indicating that the nighttime VTEC of the ionosphere in low latitudes was weakly affected by latitude and geomagnetic storms. Geomagnetic disturbances during geomagnetic storms will lead to anomalous features of the “Fountain effect” in the ionosphere at low latitudes. In addition, this geomagnetic storm event caused the accuracy of spherical harmonics (SH), polynomial, and ICE models to decrease by 7.12%, 27.87%, and 48.56%, respectively, and caused serious distortion, which is negative VTEC values fitted by the polynomial model. Full article

In high-frequency surface wave radar (HFSWR) systems, clutter is a common phenomenon that causes objects to be submerged. Space-time adaptive processing (STAP), which uses two-dimensional data to increase the degrees of freedom, has recently become a crucial tool for clutter suppression in advanced HFSWR systems. However, in STAP, the pattern is distorted if a clutter component is contained in the main lobe, which leads to errors in estimating the target angle and Doppler frequency. To solve the main-lobe distortion problem, this study developed a clutter-suppression method based on beam reshaping (BR). In this method, clutter components were estimated and maximally suppressed in the side lobe while ensuring that the main lobe remained intact. The results of the proposed algorithm were evaluated by comparison with those of standard STAP and sparse-representation STAP (SR-STAP). Among the tested algorithms, the proposed BR algorithm had the best suppression performance and the most accurate main-lobe peak response, thereby preserving the target angle and Doppler frequency information. The BR algorithm can assist with target detection and tracking despite a background with ionospheric clutter. Full article

The detector is an integral part of the device for receiving and processing radio signals. Signals that have passed through the ionospheric channel acquire an unknown Doppler shift and are subject to dispersion distortions. It is necessary to carry out joint detection and parameter estimation to improve reception quality and detection accuracy. Modern hardware base developing makes it possible to implement a device for joint detection and evaluation of signals based on standard processors (CPU) and graphic processors (GPU). The article discusses the implementation of a signal detector that allows for real-time operation. A comparison of implementations of algorithms for estimating the Doppler frequency shift through multiplication by a complex exponent and the fast Fourier transform (FFT) is performed. A comparison of computational costs and execution speed on the CPU and GPU is considered. Full article

The ionosphere has important influences on trans-ionosphere radio propagation. When signals pass through ionospheric irregularities, their amplitude and phase are often attenuated and distorted. In this work, the statistical features of scintillation observed by the Global Navigation Satellite System (GNSS) and low earth orbit (LEO) satellites are investigated with Constellation Observing System for Meteorology, Ionosphere, and Climate (COSMIC) data in solar cycle 24. The amplitude scintillation propagation channel is fitted by the Nakagami-m, α-μ and κ-μ models. The performance is evaluated in terms of root mean square error (RMSE), kurtosis and information entropy. The results reveal that the α-μ model achieves the best performance in all considered scintillation intensities, while the Nakagami-m model achieves better performance under severe scintillation in the GNSS-LEO propagation channels. Full article

Due to different designs of receiver correlators and front ends, receiver-related pseudorange biases, called signal distortion biases (SDBs), exist. Ignoring SDBs that can reach up to 0.66 cycles and 10 ns in Melbourne-Wübbena (MW) and ionosphere-free (IF) combinations can negatively affect phase bias estimation. In this contribution, we investigate the SDBs and evaluate the impacts on wide-lane (WL) and narrow-lane (NL) phase bias estimations, and further propose an approach to eliminating these SDBs to improve phase bias estimation. Based on a large data set of 302 multi-global navigation satellite system (GNSS) experiment (MGEX) stations, including 5 receiver brands, we analyze the characteristics of these SDBs The SDB characteristics of different receiver types for different GNSS systems differ from each other. Compared to the global positioning system (GPS) and BeiDou navigation satellite system (BDS), SDBs of Galileo are not significant; those of BDS-3 are significantly superior to BDS-2; Septentrio (SEPT) receivers show the most excellent consistency among all receiver types. Then, we apply the corresponding corrections to phase bias estimation for GPS, Galileo and BDS. The experimental results reveal that the calibration can greatly improve the performance of phase bias estimation. For WL phase biases estimation, the consistencies of WL phase biases among different networks for GPS, Galileo, BDS-2 and BDS-3 improve by 89%, 77%, 76% and 78%, respectively. There are scarcely any improvements of the fixing rates for Galileo due to its significantly small SDBs, while for GPS, BDS-2 and BDS-3, the WL ambiguity fixing rates can improve greatly by 13%, 27% and 14% after SDB calibrations with improvements of WL ambiguity fixing rates, the corresponding NL ambiguity fixing rates can further increase greatly, which can reach approximately 16%, 27% and 22%, respectively. Additionally, after the calibration, both WL and NL phase bias series become more stable. The standard deviations (STDs) of WL phase bias series for GPS and BDS can improve by more than 46%, while those of NL phase bias series can yield improvements of more than 13%. Ultimately, the calibration can make more WL and NL ambiguity residuals concentrated in ranges within ±0.02 cycles. All these results demonstrate that SDBs for phase bias estimation cannot be ignored and must be considered when inhomogeneous receivers are used. Full article

Pulsars’ signals reaching the atmosphere can be considered being stable under certain assumptions. In such a case the ionosphere remains the main factor distorting signal from the extraterrestrial sources, particularly if we observe them at long radio waves. In this article we present the results of the analysis of relative peak flux changes for two selected pulsars: PSR J0332+5434 (B0329+54) and PSR J1509+5531 (B1508+55), observed with the long radio wave sensor (The PL612 Low Frequency Array (LOFAR) station in Bałdy), together with the analysis of Rate of TEC (ROT) parameter changes measured with the Global Navigation Satellite Systems (GNSS) sensor (IGS LAMA station (IGS: International GSSN Service)). The main objective of the work is to find if the rapid plasma density (observed with the Rate of Total Electron Content (TEC)) has a counterpart in the pulsar observation characteristics. This focuses the attention on ionosphere influence during pulsar investigations at low radio frequencies. Additionally, what was the aim of this work, our results give reasons for using pulsar signals from LOFAR together with GNSS data as multi instrumental ionosphere state probes. Our results show a clear anti-correlation between the ROT and the pulsar profile’s peak flux trends. Full article

The ionospheric error can significantly affect the synthetic aperture radar (SAR) signals, particularly in the case of L band and lower frequency SAR systems. The ionospheric distortions are mixed with terrain and ground deformation signals, lowering the precision of the interferometric measurements. Moreover, it is often difficult to detect the small-scale ionospheric structure due to its rapid changes and may have more influence on ionospheric phase compensation for InSAR measurements. In this paper, we present a Faraday rotation (FR) inversion method and corresponding procedure to compensate the ionospheric error for SAR interferograms and to detect the variations of small-scale ionospheric disturbances. This method retrieves the absolute total electron content (TEC) based on the FR estimation and corrects the ionospheric error for synthetic aperture radar interferometry (InSAR) measurements by transforming the differential TEC into the ionospheric phase. In two selected study cases, located in high latitude and equatorial regions where ionospheric disturbances occur frequently, we test the method using the Phased Array L-band Synthetic Aperture Radar (PALSAR) full-polarimetric SAR images. Our results show that the proposed procedure can effectively compensate the ionospheric phase. In order to validate the results, we present the results of ionospheric phase compensation based on the split-spectrum method as a comparison to the proposed method. To analyze the ability of our proposed method in detecting small-scale ionospheric disturbances, TEC derived from FR estimation are also compared with those derived from the global ionosphere maps (GIM). Our research provides a robust choice for the correction of ionospheric error in SAR interferograms. It also provides a powerful tool to measure small-scale ionospheric structure. Full article

Interferometric synthetic aperture radar (InSAR) products may be significantly distorted by microwave signals traveling through the ionosphere, especially with long wavelengths. The split-spectrum method (SSM) is used to separate the ionospheric and the nondispersive phase terms with lower and higher spectral sub-band interferogram images. However, the ionospheric path delay phase is very delicate to the synthetic aperture radar (SAR) parameters including orbit vectors, slant range, and target height. In this paper, we get the impact of SAR parameter errors on the ionospheric phase by two steps. The first step is getting the derivates of geolocation with reference to SAR parameters based on the range-Doppler (RD) imaging model and the second step is calculating the derivates of the ionospheric phase delay with respect to geometric positioning. Through the numerical simulation, we demonstrate that the deviation of ionospheric phase has a linear relationship with SAR parameter errors. The experimental results show that the estimation of SAR parameters should be accurate enough since the parameter errors significantly affect the performance of ionospheric correction. The root mean square error (RMSE) between the corrected differential interferometric SAR (DInSAR) phase with SAR parameter errors and the corrected DInSAR phase without parameter errors varies from centimeter to decimeter level with the L-band data acquired by the Advanced Land Observing Satellite (ALOS) Phased Array type L-band SAR (PALSAR) over Antofagasta, Chile. Furthermore, the effectiveness of SSM can be improved when SAR parameters are accurately estimated. Full article

This work presents an overview of the multiple aperture synthetic aperture radar interferometric (MAI) technique, which is primarily used to measure the along-track components of the Earth’s surface deformation, by investigating its capabilities and potential applications. Such a method is widely used to monitor the time evolution of ground surface changes in areas with large deformations (e.g., due to glaciers movements or seismic episodes), permitting one to discriminate the three-dimensional (up–down, east–west, north–south) components of the Earth’s surface displacements. The MAI technique relies on the spectral diversity (SD) method, which consists of splitting the azimuth (range) Synthetic Aperture RADAR (SAR) signal spectrum into separate sub-bands to get an estimate of the surface displacement along the azimuth (sensor line-of-sight (LOS)) direction. Moreover, the SD techniques are also used to correct the atmospheric phase screen (APS) artefacts (e.g., the ionospheric and water vapor phase distortion effects) that corrupt surface displacement time-series obtained by currently available multi-temporal InSAR (MT-InSAR) tools. More recently, the SD methods have also been exploited for the fine co-registration of SAR data acquired with the Terrain Observation with Progressive Scans (TOPS) mode. This work is primarily devoted to illustrating the underlying rationale and effectiveness of the MAI and SD techniques as well as their applications. In addition, we present an innovative method to combine complementary information of the ground deformation collected from multi-orbit/multi-track satellite observations. In particular, the presented technique complements the recently developed Minimum Acceleration combination (MinA) method with MAI-driven azimuthal ground deformation measurements to obtain the time-series of the 3-D components of the deformation in areas affected by large deformation episodes. Experimental results encompass several case studies. The validity and relevance of the presented approaches are clearly demonstrated in the context of geospatial analyses. Full article
