Search Results (29)

The increasing demand for higher efficiency and lower emissions in aircraft gas turbines motivates investigation of alternative thermodynamic cycle architectures. This study assesses the performance and nitrogen oxides (NOx) emission behavior of a triple-spool, separate-exhaust turbofan engine equipped with an interstage turbine burner (ITB). A baseline engine representative of the RB211 Trent 892 is first modeled at maximum takeoff, sea-level static conditions and verified against publicly available takeoff reference data. The cycle is then modified by introducing an isobaric secondary combustion process between the high-pressure and intermediate-pressure turbines. The effects of fan pressure ratio, bypass ratio, overall pressure ratio, high-pressure turbine inlet temperature, and ITB exit temperature are examined using two-parameter response surface sweeps. Main combustor NOx is estimated using an RQL-type cycle correlation, while the ITB contribution is represented using an engineering source–sink model accounting for new NOx formation and partial reburning of upstream NOx. The baseline model predicts specific thrust, thrust-specific fuel consumption (TSFC), and NOx emission index (EINOx) within ±8% of reference values. At a selected ITB operating point, specific thrust increases by 1.98%, TSFC increases by 9.84%, thermal efficiency decreases by 2.56%, and the adopted engineering source–sink model predicts a 20.03% reduction in fuel flow-weighted EINOx. The corresponding takeoff-mode NOx-per-thrust indicator decreases by approximately 12.1%. These results indicate that ITB integration introduces a coupled performance–emissions trade-off and should not be evaluated solely as a thrust augmentation method. Full article

The stage separation process, though often completed within one second, plays a critical role in determining the overall success and safety of the launch mission. The process of host stage separation is simulated to study the flow field evolution and the impact on the lower-stage. Overset mesh is utilized together with a novel adaptive mesh refinement sensor for the purpose of adapting to the relative motion. A third-order scheme is adopted in spatial discretization, and the simulation results fit well with the experiment data. The results show that the initial shockwave oscillated back and forth in the cavity of the lower-stage, leading to sustained oscillations in the forces of the lower-stage. Based on the monitor data, the force acting on the lower-stage exhibits five phases. Compared with former research, a longer interstage results in two more obvious oscillation phases. The pressure distribution on the forward dome of the lower-stage is also studied. Full article

Downhole boosting technology breaks the physical limitations of conventional surface boosting by enhancing pressure at the wellbore bottom, with micro-axial compressors serving as its core compression module. However, traditional axial compressors, when miniaturized, suffer from severe end losses and easy instability, failing to adapt to downhole space constraints and the efficient pressurization demands of low-permeability, low-pressure, and small-flow reservoirs. To address this, this study designed a compact micro-axial compressor. CFturbo was used for parametric blade design and optimization, while ANSYS CFX 2025 (with the SST turbulence model) conducted numerical simulations. A “simulation–diagnosis–optimization–validation” closed-loop strategy was adopted to adjust the blade’s leading-edge shape, camber line, and thickness distribution, combined with grid independence verification and inter-stage matching optimization. The results show that at the design speed (60,000 rpm), the compressor achieves a pressure ratio of 1.57 and an isentropic efficiency of 83.6%. It also maintains stable performance at 55,000 rpm (off-design speed), with excellent inter-stage aerodynamic matching and controllable leakage losses. This compressor meets downhole operational needs, providing technical support for developing low-permeability, low-pressure, small-flow reservoirs. Full article

To alleviate the adverse effects of the flow-field structure caused by interstage sealing structures on the aerodynamic characteristics of compressor cascades, a blade-root through-slot structure was designed in this study. The structure links the pressure surface to the suction surface of the blade. Numerical simulation techniques were utilized to investigate the process. In this process, the through-slot structure enhances corner separation across varying jet positions, jet heights, and jet widths. The results indicate that the high-speed fluid ejected by the through-slot configuration can suppress the accumulation of low-energy fluid at the suction root. It can also alleviate blockages in the cascade passage and reduce the range of separation vortices and recirculation zones on the suction side. Consequently, the flow loss due to separation is reduced. As the through-slot jet progresses from the blade leading edge to the trailing edge, its restraining impact on the low-energy fluid cluster gradually diminishes. This leads to a corresponding reduction in its effect on the total pressure loss. With an increase in the slot height, the restraining impact on corner separation and total pressure loss first rises and then falls. As the through-slot height increases, the suppressive effect on corner separation and loss initially intensifies and then weakens. As the through-slot width increases, the suppressive effect on corner separation and total pressure loss increases steadily. Compared to the original compressor cascade, the through-slot configuration attains peak performance at 25% chord length, with a height of 6% height and a width of 10 mm, reducing the total pressure loss coefficient by 19.22%. Furthermore, as the incoming flow incidence angle enlarges, the enhancement impact of the through-slot configuration on cascade performance initially intensifies and then diminishes. The peak enhancement impact occurs at a 0° incidence angle. At this angle, the configuration can reduce flow loss by 16.72% compared to the original, significantly improving the aerodynamic performance of the high-load compressor cascade. Full article

Performance deterioration and unstable operation are common when multistage centrifugal pumps handle gas–liquid mixtures. Here, we investigate a two-stage centrifugal pump over a wide speed range and inlet gas volume fractions (IGVFs) using experiments and CFD. The two-phase flow is simulated with a Eulerian–Eulerian two-fluid approach (liquid as the continuous phase; gas as a dispersed bubbly phase with a representative bubble diameter of 0.3 mm). Turbulence is closed using the SST k–ω model for the liquid phase and the built-in dispersed-phase turbulence treatment in ANSYS CFX. Transient pressure signals are analyzed in the time and frequency domains (FFT) to assess how rotational speed affects void-fraction distribution, overall performance, and the dominant unsteady components within the adopted modeling framework. The results show that IGVF primarily controls gas accumulation in the impeller passages: as IGVF increases, the gas phase evolves from dispersed bubbles to a central core, whereas speed mainly alters the detailed morphology via centrifugal effects. Similarity-law scaling is strongly speed-dependent in this pump: agreement is better at higher speeds and deteriorates at lower speeds where viscous effects become more influential. The dominant unsteady content also changes with speed, shifting from low-speed broadband features associated with gas redistribution to high-speed periodic components linked to blade–vane rotor–stator interaction (RSI). In addition, the downstream stage exhibits more uniform void fraction and more regular periodic signatures, consistent with an inter-stage flow-rectification effect. These observations provide practical guidance for hydraulic design and variable-speed operation of multistage pumps under gas entrainment. Full article

During natural gas field extraction, downhole compressors frequently encounter gas-liquid two-phase flow conditions, yet the internal flow characteristics and performance evolution mechanisms remain insufficiently understood. This paper investigates a small-scale, low-pressure-ratio five-stage axial compressor using a multiphase numerical simulation method based on the Euler-Lagrange framework. The study systematically examines the effects of different inlet pressures (0.1 MPa, 1 MPa, 8 MPa) and liquid mass fraction (0%, 5%, 10%) on its overall and stage-by-stage performance, droplet evolution, and flow field structure. The results indicate that the inlet pressure exerts a decisive influence on the overall efficiency trend of wet compression. The stage efficiency response displays a trend of an initial decrease in the front stages followed by an increase in the rear stages, showing significant variation under different inlet pressures. Flow field analysis reveals that increased inlet pressure intensifies droplet aerodynamic breakup, leading to higher flow losses in the compressor. Simultaneously, under high-pressure conditions, the cumulative cooling effect resulting from droplet heat transfer and evaporation effectively enhances the flow stability in the rear stages. This research elucidates the interstage interaction mechanisms of gas-liquid two-phase flow in low-pressure-ratio multistage compressors and highlights the competing influences of droplet breakup and evaporation effects on performance under different pressure conditions, providing a theoretical basis for the optimal design of downhole wet gas compression technology. Full article

Pressurized chemical looping combustion (PCLC) provides the benefit of simplifying the carbon capture process by generating a flue gas stream with high CO₂ concentration. However, flue gas polishing is required to remove the residual impurities for pipeline transport. The intensified heat exchanger reactor (IHXR) is a promising method for flue gas polishing while maximizing useful heat recovery that incorporates alternating catalytic packed beds with interstage cooling via printed circuit heat exchangers (PCHE). This work offers a design process for an IHXR capable of polishing a flue gas stream from a 100 MWth natural gas-fired PCLC unit while recovering 1.6 MW of useful heat in the form of saturated steam at 180 °C. Simulation work performed in Aspen HYSYS was used to determine the polished flue gas outlet species concentrations as well as the required number and size of the packed bed sections. The PCHEs for interstage cooling were sized via a thermal circuit approach. The final IHXR consists of six packed beds at 0.06 m in length and five PCHEs at 0.265 m in length, combining to a total IHXR length of 1.685 m. The height and width of the IHXR is shared between the packed beds and PCHEs at 0.91 m and 0.45 m, respectively. The resulting IHXR is capable of recovering heat at a rate of approximately 2.3 MW/m³. Full article

In response to grid peak-shaving requirements under renewable energy integration, this study investigates the thermodynamic performance of a 300 MW adiabatic compressed air energy storage (A-CAES) system, with a focus on optimizing electro-thermal efficiency through parametric analysis. A detailed thermodynamic model was developed to systematically evaluate the effects of compression/expansion stage configurations (2–4 stages), pressure ratios (4–6), and inter-stage outlet temperatures (120–190 °C) on system performance. The results demonstrate that variable-pressure operation improves round-trip efficiency by a 1.8% per unit compression ratio increase, while optimized inter-stage cooling (150 °C) reduces exergy destruction by 22.5%. Thermal efficiency monotonically improves with additional expansion stages, whereas electrical efficiency peaks at three stages (70%) before declining due to parasitic losses. Exergy analysis reveals that compressors and turbines account for 65% of total destruction, emphasizing the need for enhanced heat exchanger design. These findings provide actionable insights for balancing efficiency gains with operational constraints in large-scale A-CAES deployment. Full article

This study examines how leading-edge inclination angles affect a two-stage centrifugal compressor’s aerodynamic performance using numerical and experimental methods. Five impellers with varied inclination configurations were designed for both stages. The results show that negative inclination improves the pressure ratio and efficiency under near-choke conditions, with greater enhancements in the low-pressure stage. Positive inclination significantly boosts the pressure ratio and efficiency under near-stall conditions, particularly in the low-pressure stage. Negative inclinations optimize blade loading and choke flow capacity, while effectively reducing incidence angle deviations induced by interstage pipeline distortion and decreasing outlet pressure fluctuation amplitude in the high-pressure stage. Positive inclinations delay flow separation, suppress tip leakage vortices, and extend the stall margin. Full article

Uneven inter-stage pressure drops of the common two-stage brush seal (CBS) lead to a problem that the second stage bristles bear excessive pressure load, and this problem leads to the premature failure of the brush seal. In this paper, a novel two-stage brush seal (NBS) with the backing plate holes of the second stage was proposed, and a three-dimensional numerical model of the NBS was established. Then, the effects of the pressure-equalizing (PE) hole on the inter-stage pressure drop distribution of the NBS were numerically analyzed, and an optimal structure was obtained. Finally, the leakage flow characteristics of this optimal structure were studied. The results showed that the NBS with PE hole increased the passage area of the downstream, and so effectively improved the uneven pressure drops of the CBS, and the pressure drop balance ratio of the NBS was obviously smaller than that of the CBS. For the structural parameters studied in this paper, the pressure drop balance ratio of the NBS was improved by 45.6~67.9% compared to the CBS. Moreover, when PE holes were 0.4 mm in diameter, 5.95 mm in height, and the number of rows was 1, the NBS had the best pressure drop balance and its leakage was only 8.7% higher than that of the CBS. Full article

Premature seal failure induced by the unevenness of interstage pressure distribution in multi-stage brush seals significantly compromises the sealing efficiency of Air-Turbo Rocket (ATR) engines operating under high-pressure (megapascal-level) differential conditions. Conventional pressure equalization designs for such seals often result in significant leakage rate increases. This study addresses the pressure imbalance phenomenon in four-tooth three-stage brush composite seals through a novel fractal–geometric porous-media model, rigorously validated against experimental data. Systematic investigations were conducted to elucidate the effects of structural parameters and operational conditions on both sealing performance and pressure distribution characteristics. Key findings reveal that, under the prototype structure parameter, the first-, second-, and third-stage brush bundles account for 18.3%, 30.0%, and 43.3% of the total pressure drop, respectively, with grate teeth contributing 8.4%, demonstrating an inherent pressure imbalance. Axial brush spacing exhibits a minimal impact on the pressure distribution, while the gradient thickness settings of the brush bundles show limited influence. Radial clearance optimization and gradient backplate height adjustment effectively regulate pressure distribution, albeit with associated leakage rate increases. Structural modifications based on these principles achieved only a 5.8% leakage increment while reducing the maximum bundle pressure drop by 23%, demonstrating effective pressure balancing. A simplified analysis of entropy reveals that the fundamental mechanism governing the pressure imbalance stems from non-uniform entropy generation caused by aerodynamic damping dissipation across sequential brush stages. These findings establish a dampened dissipation-based theoretical framework for designing high-performance multistage brush seals in aerospace applications, providing critical insights for achieving an optimal balance between leakage control and pressure equalization in extreme-pressure environments. Full article

The process pump as turbine (PPAT) serves as a crucial component for recovering high-pressure energy from mediums used in chemical and refining processes. Ensuring the long-term safe and stable operation of PPAT in high-temperature and high-pressure environments is essential, with pressure pulsation being one of its most significant external characteristic indicators. This study investigates the evolution of vortex structure distribution and the generation and propagation mechanisms of pressure pulsation in a two-stage PPAT operating in turbine mode. Results indicate that the uniformity of the pressure coefficient (Cp) gradient distribution is poorer in the first stage runner compared to the second stage, with a larger distribution area of high-strength vortices. In the draft tube, vortex strength increases with rising flow rates, and the flow around the circular cylinder on one side gradually develops to both sides. In the two-stage diffusers, the primary source of pressure pulsation is the dynamic and static interference effect between the two impellers and the corresponding diffuser tongue. The interstage interference with a frequency of n*15fn is most pronounced in the inflow runner, gradually weakening along the flow direction, and ultimately disappearing in the draft tube. In addition, more low-frequency signals with a frequency of 0.5fn are captured in the draft tube under large flow conditions, which is mainly generated by the vortex band in the draft tube. The low-frequency pulsation energy is high and the attenuation is slow, which has a great destructive effect on the energy recovery system of the PPAT. Full article

To effectively address the issue of premature failure caused by the unbalanced distribution of pressure drops between the stages of a traditional two-stage finger seal, this study proposes a method to improve the pressure drop balance by increasing the protection height of the second stage back plate. We established a new numerical calculation model for a two-stage finger seal, based on the porous media model. After verifying the precision of the model, we conducted a numerical analysis to examine the impact of the protection height of the second stage back plate on the flow and heat transfer characteristics of the two-stage finger seal. We then conducted a differentiated structural design for each stage of the two-stage finger seal. The research results are as follows: the pressure drop at the second stage of the traditional two-stage finger seal exceeds that of the first stage; when the protection height of the second stage back plate of the traditional two-stage finger seal is increased from 1.5 mm to 1.57 mm, forming a two-stage pressure equalizing finger seal structure, the pressure drop between the two stages is balanced, but the leakage is greater than that of the traditional two-stage finger seal; a grate seal structure was arranged between the first and second stages of the two-stage pressure equalizing finger seal to form a two-stage pressure equalizing finger seal with grate teeth, which exhibits significantly lower leakage compared to the two-stage pressure equalizing finger seal. However, the proportion of pressure drop at the first and second stages of the two-stage pressure equalizing finger seal is 36.8% and 42.1%, respectively, while the grate tooth stage accounts for 21.1%, resulting in an imbalanced pressure drop once again. Increasing the protection height of the second stage back plate in the two-stage pressure equalizing finger seal with grate teeth to 1.6 mm results in a 37.5% pressure drop at the first and second stages, and a 25% pressure drop at the grate tooth stage. The two-stage finger seal balances the pressure drop and matches the leakage of the traditional two-stage finger seal. The maximum temperatures of the first and second stages of the finger seal are 0.7% lower and 2.6% higher compared to the traditional two-stage finger seal. This suggests that a differential multi-stage finger seal is the optimal structure. Full article

Background/Objectives: Hybrid palliation (HP) procedures for hypoplastic left heart syndrome (HLHS) are increasing. Our objective was to compare mortality and morbidity following HP and NP (Norwood palliation) procedures. Methods: Systematic review and meta-analysis of HLHS patients of peer-reviewed literature between 2000 and 2023. Mortality and/or heart transplantation in HP versus NP in the neonatal period, interstage period, and at 1, 3 and 5 years of age, and morbidity including completion of Stage II and Stage III palliation, unexpected interventions, pulmonary artery pressures, right ventricle function, neurodevelopmental outcomes and length of hospital stay were evaluated. Results: Twenty-one (meta-analysis: 16; qualitative synthesis: 5) studies evaluating 1182 HLHS patients included. HP patients had higher interstage mortality (RR = 1.61; 95% CI: 1.10–2.33; p = 0.01) and 1-year mortality (RR = 1.22; 95% CI: 1.03–1.43; p = 0.02) compared to NP patients without differences in 3- and 5-years mortality. HP procedure in high-risk HLHS patients had lower mortality (RR = 0.48; 95% CI: 0.27–0.87; p = 0.01) only in the neonatal period. HP patients underwent fewer Stage II (RR = 0.90; 95% CI: 0.81–1.00; p = 0.05) and Stage III palliation (RR = 0.78; 95% CI: 0.69–0.90; p < 0.01), had more unplanned interventions (RR = 3.38; 95% CI: 2.04–5.59; p < 0.01), and longer hospital stay after Stage I palliation (weighted mean difference = 12.88; 95% CI: 1.15–24.62; p = 0.03) compared to NP patients. Conclusions: Our study reveals that HP, compared to NP for HLHS, is associated with increased morbidity risk without an improved survival rate. Full article

In order to analyze the inner flow in a multi-stage double-suction centrifugal pump, which is regarded as a common way of knowing the current characteristics of the pump and as the basis of optimization for better performance, a numerical simulation considering the velocity field distribution characteristics and pressure fluctuation propagation law using the detached eddy simulation method was conducted. Additionally, the principle of entropy generation was put to use to quantify and compare the energy loss of different components. The results reveal that the existence of unstable flow structures in the first-stage impeller and a large number of vortical structures in the back-channel result in reduced operational efficiency of the pump. Furthermore, the pressure fluctuation intensity reaches its maximum with 0.15 at the blade trailing edge, which propagates to the tongue region of the forward flow channel and the double-volute under the low rates condition. Additionally, the main frequency of the monitoring points in the inter-stage flow channel and volute is basically located at a frequency of 198.667 Hz, which is twice the blade frequency. Consequently, the wall entropy production accounting for nearly 25% cannot be ignored and that the loss mainly occurs in the double-volute and the inter-stage flow channel due to the occurrence of irregular flow in the above components with more than 50%. The outcomes of this research present a valuable point of reference for the optimization of structural design in multistage turbomachines with various applications. Full article
