Search Results (19)

Abnormal operations, such as faults occurring in an electrical power system (EPS), disrupt its balanced operation, posing potential hazards to human lives and the system’s equipment. Effective monitoring, control, protection, and coordination are essential to mitigate these risks. The complexity of these processes is further compounded by the presence of intermittent distributed energy resources (DERs) in active distribution networks (ADNs) with bidirectional power flow, which introduces a fast-changing dynamic aspect to the system. The deployment of phasor measurement units (PMUs) within the EPS as highly responsive equipment can play a pivotal role in addressing these challenges, enhancing the system’s resilience and reliability. However, synchrophasor measurement-based studies and analyses of power system phenomena may be hindered by the absence of PMU blocks in certain simulation tools, such as PSCAD, or by the existing PMU block in Matlab/Simulink R2021b, which exhibit technical limitations. These limitations include providing only the positive sequence component of the measurements and lacking information about individual phases, rendering them unsuitable for certain measurements, including unbalanced and non-symmetrical fault operations. This study proposes a new reliable PMU model in Matlab and tests it under normal and abnormal conditions, applying real-time simulation and controller-hardware-in-the-loop (CHIL) techniques. Full article

Power transformers are vital components of electrical power systems, ensuring reliable and efficient energy transfer between high-voltage transmission and low-voltage distribution networks. However, they are prone to various faults, such as insulation breakdowns, winding deformations, partial discharges, and short circuits, which can disrupt electrical service, incur significant economic losses, and pose safety risks. Traditional fault diagnosis methods, including visual inspection, dissolved gas analysis (DGA), and thermal imaging, face challenges such as subjectivity, intermittent data collection, and reliance on expert interpretation. To address these limitations, this paper proposes a novel distributed approach for multi-fault diagnosis of power transformers based on a self-organizing neural network combined with data augmentation and incremental learning techniques. The proposed framework addresses critical challenges, including data quality issues, computational complexity, and the need for real-time adaptability. Data cleaning and preprocessing techniques improve the reliability of input data, while data augmentation generates synthetic samples to mitigate data imbalance and enhance the recognition of rare fault patterns. A two-stage classification model integrates unsupervised and supervised learning, with k-means clustering applied in the first stage for initial fault categorization, followed by a self-organizing neural network in the second stage for refined fault diagnosis. The self-organizing neural network dynamically suppresses inactive nodes and optimizes its training parameter set, reducing computational complexity without sacrificing accuracy. Additionally, incremental learning enables the model to continuously adapt to new fault scenarios without modifying its architecture, ensuring real-time performance and adaptability across diverse operational conditions. Experimental validation demonstrates the effectiveness of the proposed method in achieving accurate, efficient, and adaptive fault diagnosis for power transformers, outperforming traditional and conventional machine learning approaches. This work provides a robust framework for integrating advanced machine learning techniques into power system monitoring, paving the way for automated, real-time, and reliable transformer fault diagnosis systems. Full article

As renewable energy sources such as wind and photovoltaics continue to enter the grid, their intermittency and instability leads to an increasing demand for peaking and frequency regulation. An efficient dynamic monitoring method is necessary to improve the safety level of intelligent operation and maintenance of power stations. To overcome the insufficient detection accuracy and poor adaptability of traditional methods, a novel fault early warning method with careful consideration of dynamic characteristics and model optimization is proposed. A combined loss function is proposed based on the dynamic time warping and the mean square error from the perspective of both shape similarity and time similarity. A prediction model of steam turbine intermediate-stage extraction temperature based on the gate recurrent unit is then proposed, and the change in prediction residuals is utilized as a fault warning criterion. In order to further improve the diagnostic accuracy, a human evolutionary optimization algorithm with lens opposition-based learning is proposed for model parameter adaptive optimization. Experiments on real-world normal and faulty operational data demonstrate that the proposed method can improve the detection accuracy by an average of 1.31% and 1.03% compared to the long short-term memory network, convolutional neural network, back propagation network, extreme learning machines, gradient boosting decision tree, and LightGBM models. Full article

The advent of internet of things (IoT) technology has ushered in a new dawn for the digital realm, offering innovative avenues for real-time surveillance and assessment of the operational conditions of intricate mechanical systems. Nowadays, mechanical system monitoring technologies are extensively utilized in various sectors, such as rotating and reciprocating machinery, expansive bridges, and intricate aircraft. Nevertheless, in comparison to standard mechanical frameworks, large amusement facilities, which constitute the primary manned electromechanical installations in amusement parks and scenic locales, showcase a myriad of structural designs and multiple failure patterns. The predominant method for fault diagnosis still relies on offline manual evaluations and intermittent testing of vital elements. This practice heavily depends on the inspectors’ expertise and proficiency for effective detection. Moreover, periodic inspections cannot provide immediate feedback on the safety status of crucial components, they lack preemptive warnings for potential malfunctions, and fail to elevate safety measures during equipment operation. Hence, developing an equipment monitoring system grounded in IoT technology and sensor networks is paramount, especially considering the structural nuances and risk profiles of large amusement facilities. This study aims to develop customized operational status monitoring sensors and an IoT platform for large roller coasters, encompassing the design and fabrication of sensors and IoT platforms and data acquisition and processing. The ultimate objective is to enable timely warnings when monitoring signals deviate from normal ranges or violate relevant standards, thereby facilitating the prompt identification of potential safety hazards and equipment faults. Full article

A novel low-pass filtering self-adaptive (LPFA) denoising method combining complete ensemble empirical mode decomposition with adaptive noise (CEEMDAN) and a wavelet threshold (WT) strategy is proposed to solve the problem of the aero-engine gas-path electrostatic signal noise, which challenges the gas-path component condition monitoring and feature extraction techniques. Firstly, the integration of CEEMDAN addresses modal aliasing and intermittent signal challenges, while the proposed low-pass filtering method autonomously selects valuable signal components. Additionally, the application of the WT in the unselected components enhances the extraction of useful information, presenting a unique and advanced approach to electrostatic signal denoising. Moreover, the proposed method is applied to simulated signals with different input signal-to-noise ratios and experimental fault electrostatic signals of a micro-turbojet engine. The comparison with several traditional approaches in a denoising test for the simulated signals and experimental signals reveals that the proposed method performs better in extracting the effective components of the signal and eliminating noise. Full article

Effective fault detection in chemical processes is of utmost importance to ensure operational safety, minimize environmental impact, and optimize production efficiency. To enhance the monitoring of chemical processes under noisy conditions, an innovative statistical approach has been introduced in this study. The proposed approach, called Multiscale Principal Component Analysis (PCA), combines the dimensionality reduction capabilities of PCA with the noise reduction capabilities of wavelet-based filtering. The integrated approach focuses on extracting features from the multiscale representation, balancing the need to retain important process information while minimizing the impact of noise. For fault detection, the Kantorovich distance (KD)-driven monitoring scheme is employed based on features extracted from Multiscale PCA to efficiently detect anomalies in multivariate data. Moreover, a nonparametric decision threshold is employed through kernel density estimation to enhance the flexibility of the proposed approach. The detection performance of the proposed approach is investigated using data collected from distillation columns and continuously stirred tank reactors (CSTRs) under various noisy conditions. Different types of faults, including bias, intermittent, and drift faults, are considered. The results reveal the superior performance of the proposed multiscale PCA-KD based approach compared to conventional PCA and multiscale PCA-based monitoring methods. Full article

High-definition bathymetry mapping, combined with the measurement of dissolved benthic fluxes and water column biogeochemical properties, allows for a description of new biogeochemical processes around the Panarea Volcanic island. Investigations focused on the CO₂ releases from the bottom sea on the east of the Panarea volcanic complex provided insights into the geological setup of the marine area east and south of the Panarea Island. Between the Panarea Island and the Basiluzzo Islet lies a SW-NE-stretching graben structure where a central depression, the Smoking Land Valley, is bounded by extensional faults. Abundant acidic fluids rich in dissolved inorganic Carbon are released on the edges of the graben, along the extensional faults, either diffusely from the seafloor, from hydrothermal chimneys, or at the center of craters of different sizes. The precipitation of iron dissolved in the acidic fluids forms Fe-oxyhydroxides bottom sea crusts that act as a plug, thus preventing the release of the underlying gases until their mounting pressure generates a bursting release. This process is cyclic and results in intermittent gas release from the bottom, leaving extinct craters and quiescent chimneys. The measurement of dissolved benthic fluxes allowed us to estimate the volcanic DIC venting at 15 Mt of CO₂ over the past 10,000 years. The fluxes are not distributed homogeneously but rather concentrate along fractures and fault planes, which facilitate their rise to the seafloor. The acidic fluids released affect the chemical properties and structure of the water column through the formation of layers with a lower pH under the pycnocline, which can limit volcanic CO₂ release to the atmosphere. Further and continuous monitoring and investigation of the area are needed in order to complete a thorough picture of the variations in fluid releases through time and space. The importance of such monitoring lies in the development of a new method for detecting and quantifying the diffusive dissolved benthic fluxes on a volcanic sea bottom affected by hydrothermal seeps. Full article

This paper presents a novel methodology for deploying wireless sensor nodes in the Industrial Internet of Things (IIoT) to address the safety and efficiency challenges in underground coal mining. The methodology is intended to support long-term planning on mitigating the risks in occupational health and safety policies. To ensure realistic and accurate deployment, we propose a software tool that generates mine models based on geolocation data or blueprints in image format, allowing precise adaptation to the specific conditions of each mine. Furthermore, the process is based on sensing and communication range values obtained through simulations and on-site experiments. The deployment strategy is articulated in two complementary steps: a deterministic deployment, where nodes are strategically placed according to the structure of the tunnels, followed by a random stage to include additional nodes that ensure optimal coverage and connectivity inside the mine by comparing different methodologies for deploying sensor networks using coverage density as a performance metric. We analyze coverage and connectivity based on the three probability density functions (PDFs) for the random deployment of nodes: uniform, normal, and exponential, evaluating both the degree of coverage (k-coverage) and the degree of connectivity (k-connectivity). The results show that our proposed methodology stands out for its lower density of sensors per square meter, which translates into a reduction of between 20.81% and 23.46% for uniform and exponential PDFs, respectively, concerning the number of sensors compared to the analyzed methodologies. In this way, it is possible to determine which distribution is suitable to cover the elongated area with the smallest number of nodes, considering the coverage and connectivity requirements, to reduce the deployment cost. The uniform PDF minimizes the number of sensors needed by 44.70% in small mines and 46.27% in medium ones compared to the exponential PDF. These findings provide valuable information to optimize node deployment regarding cost and efficiency; a uniform function is a good option depending on prices. The exponential distribution reached the highest values of k-coverage and k-connectivity for small and medium-sized mines; in addition, it has greater robustness and tolerance to faults like signal network intermittence. This methodology not only improves the collection of critical information for the mining operation but also plays a vital role in reducing the risks to the health and safety of workers by providing a more robust and adaptive monitoring system. The approach can be used to plan IIoT systems based on Wireless Sensor Networks (WSN) for underground mining exploitation, offering a more reliable and adaptable strategy for monitoring and managing complex work environments. Full article

Fault detection is crucial in maintaining reliability, safety, and consistent product quality in chemical engineering processes. Accurate fault detection allows for identifying anomalies, signaling deviations from the system’s nominal behavior, ensuring the system operates within desired performance parameters, and minimizing potential losses. This paper presents a novel semi-supervised data-based monitoring technique for fault detection in multivariate processes. To this end, the proposed approach merges the capabilities of Principal Component Analysis (PCA) for dimensionality reduction and feature extraction with the Kolmogorov–Smirnov (KS)-based scheme for fault detection. The KS indicator is computed between the two distributions in a moving window of fixed length, allowing it to capture sensitive details that enhance the detection of faults. Moreover, no labeling is required when using this fault detection approach, making it flexible in practice. The performance of the proposed PCA–KS strategy is assessed for different sensor faults on benchmark processes, specifically the Plug Flow Reactor (PFR) process and the benchmark Tennessee Eastman (TE) process. Different sensor faults, including bias, intermittent, and aging faults, are considered in this study to evaluate the proposed fault detection scheme. The results demonstrate that the proposed approach surpasses traditional PCA-based methods. Specifically, when applied to PFR data, it achieves a high average detection rate of 98.31% and a low false alarm rate of 0.25%. Similarly, when applied to the TE process, it provides a good average detection rate of 97.27% and a false alarm rate of 6.32%. These results underscore the efficacy of the proposed PCA–KS approach in enhancing the fault detection of high-dimensional processes. Full article

Aircraft systems are designed to perform functions that will aid the various missions of the aircraft. Their performance, when subjected to an unfamiliar condition of operation, imposes stress on them. The system components experience degradation due to fault which ultimately results in failure. Maintenance and monitoring mechanisms are put in place to ensure these systems are readily available when required. Thus, the sensing of parameters assists in providing conditions under which healthy and faulty scenarios can be indicated. To obtain parameter values, sensor data is processed, and the results are displayed so that the presence of faults may be known. Some faults are intermittent and incipient in nature. These are not discovered easily and can only be known through a display of unusual system performance by error code indication. Therefore, the assessed faults are transmitted to a maintenance crew by error codes. The results may be fault found (FF), no fault found (NFF), or cannot display (CND). However, the main classification of the faults and their origins may not be known in the system. This continues throughout the life cycle of the system or equipment. This paper reviews the diagnostic methods used for the hydraulically powered flight control actuation system (HPFCAS) of an aircraft and its interaction with other aircraft systems. The complexities of the subsystem’s integration are discussed, and different subsystems are identified. Approaches used for the diagnostics of faults, such as model-based, statistical mapping and classification, the use of algorithms, as well as parity checks are reviewed. These are integrated vehicle health management (IVHM) tools for systems diagnostics. The review shows that when a system is made up of several subsystems on the aircraft with dissimilar functions, the probability of fault existing in the system increases, as the subsystems are interconnected for resource sharing, space, and weight savings. Additionally, this review demonstrates that data-driven approaches for the fault diagnostics of components are good. However, they require large amounts of data for feature extraction. For a system such as the HPFCAS, flight-management data or aircraft maintenance records hold information on performance, health monitoring, diagnostics, and time scales during operation. These are needed for analysis. Here, a knowledge of training algorithms is used to interpret different fault scenarios from the record. Thus, such specific data are not readily available for use in a data-driven approach, since manufacturers, producers, and the end users of the system components or equipment do not readily distribute these verifiable data. This makes it difficult to perform diagnostics using a data-driven approach. In conclusion, this paper exposes the areas of interest, which constitute opportunities and challenges in the diagnostics and health monitoring of flight-control actuation systems on aircraft. Full article

The relationship between clutch thermodynamic characteristics and contact states of friction components is explored numerically and experimentally. The clutch thermodynamic numerical model is developed with consideration of the contact state and oil film between friction pairs. The clutch bench test is conducted to verify the variation of the clutch thermodynamic characteristics from the uniform contact (UCS) to the intermittent contact (ICS). The results show that the oil film decreases gradually with increasing temperature; the lubrication state finally changes from hydrodynamic lubrication to dry friction, where the friction coefficient shows an increasing trend before a decrease. Thus, the friction torque in UCS gradually increases after the applied pressure stabilizes. When the contact state changes to ICS, the contact pressure increases suddenly and the oil film decreases rapidly in the local contact area, bringing about a sharp increase in friction torque; subsequently, the circumferential and radial temperature differences of friction components expand dramatically. However, if the contact zone is already in the dry friction state, friction torque declines directly, resulting in clutch failure. The conclusions can potentially be used for online monitoring and fault diagnosis of the clutch. Full article

Solar power systems have been growing globally to replace fossil fuel-based energy and reduce greenhouse gases (GHG). In addition to panel efficiency deterioration and contamination, the produced power of photovoltaic (PV) systems is intermittent due to the dependency on weather conditions, causing reliability and resiliency issues. Monitoring system parameters can help in predicting faults in time for corrective action to be taken or preventive maintenance to be applied. However, classical monitoring approaches have two main problems: neither local nor centralized monitoring support distributed PV power systems nor provide remote access capability. Therefore, this paper presents an appraisal of a remote monitoring system of PV power generation stations by utilizing the Internet of Things (IoT) and a state-of-the-art tool for virtual supervision. The proposed system allows real-time measurements of all PV system parameters, including surrounding weather conditions, which are then available at the remote control center to check and track the PV power system. The proposed technique is composed of a set of cost-effective devices and algorithms, including a PV power conditioning unit (PCU); a sensor board for measuring the variables that influence PV energy production such as irradiance and temperature, using a communication module based on Wi-Fi for data transmission; and a maximum power point tracking (MPPT) controller for enhancing the efficiency of the PV system. For validating the proposed system, different common scenarios of PV panel conditions including different shading circumstances were considered. The results show that accurate, real-time monitoring with remote access capabilities can provide timely information for predicting and diagnosing the system condition to ensure continued stable power generation and management. Full article

An efficient and all-inclusive health management encompassing condition-based maintenance (CBM) environment plays a pivotal role in enhancing the useful life of mission-critical systems. Leveraging high fidelity digital modelling and simulation, scalable to digital twin (DT) representation, quadruples their performance prediction and health management regime. The work presented in this paper does exactly the same for an electric braking system (EBS) of a more-electric aircraft (MEA) by developing a highly representative digital model of its electro-mechanical actuator (EMA) and integrating it with the digital model of anti-skid braking system (ABS). We have shown how, when supported with more-realistic simulation and the application of a qualitative validation approach, various fault modes (such as open circuit, circuit intermittence, and jamming) are implemented in an EMA digital model, followed by their impact assessment. Substantial performance degradation of an electric braking system is observed along with associated hazards as different fault mode scenarios are introduced into the model. With the subsequent qualitative validation of an EMA digital model, a complete performance as well as reliability profile of an EMA can be built to enable its wider deployment and safe integration with a larger number of aircraft systems to achieve environmentally friendly objectives of the aircraft industry. Most significantly, the qualitative validation provides an efficient method of identifying various fault modes in an EMA through rapid monitoring of associated sensor signals and their comparative analysis. It is envisaged that when applied as an add-on in digital twin environment, it would help enhance its CBM capability and improve the overall health management regime of electric braking systems in more-electric aircraft. Full article

The grid integration of large scale photovoltaic (PV) power plants represents many challenging tasks for system stability, reliability and power quality due to the intermittent nature of solar radiation and the site accessibility issues where most PV power plants are located over a wide area. In order to enable real-time monitoring and control of large scale PV power plants, reliable two-way communications with low latency are required which provide accurate information for the electrical and environmental parameters as well as enabling the system operator to evaluate the overall performance and identify any abnormal conditions and faults. This work aims to design a communication network architecture for the remote monitoring of large-scale PV power plants based on the IEC 61850 Standard. The proposed architecture consists of three layers: the PV power system layer, the communication network layer, and the application layer. The PV power system layer consists of solar arrays, inverters, feeders, buses, a substation, and a control center. Monitoring parameters are classified into different categories including electrical measurements, status information, and meteorological data. This work considers the future plan of PV power plants in Saudi Arabia. In order to evaluate the performance of the communication network for local and remote monitoring, the OPNET Modeler is used for network modeling and simulation, and critical parameters such as network topology, link capacity, and latency are investigated and discussed. This work contributes to the design of reliable monitoring and communication of large-scale PV power plants. Full article

Traditionally, the choices to balance the grid and meet its peaking power needs are by installing more spinning reserves or perform load shedding when it becomes too much. This problem becomes worse as more intermittent renewable energy resources are installed, forming a substantial amount of total capacity. Advancements in Energy Storage System (ESS) provides the utility new ways to balance the grid and to meet its peak demand by storing un-used off peak energy for peak usage. Large sized ESS—mega watt (MW) level—are installed by different utilities at their substations to provide the high speed grid stabilization to balance the grid to avoid installing more capacity or triggering any current load shedding schemes. However, such large sized ESS systems and their required inverters are costly to install, require much space and their efficacy could also be limited due to network fault current limits and impedances. In this paper, we propose a novel approach and trial for 3000+ homes in Singapore of achieving a large capacity of demand management by developing a smart distribution board (DB) in each home with the high speed metering sensors (>6 kHz sampling rate) and non-intrusive load monitoring (NILM) algorithm, that can assist home users to perform the load/appliance profile identification with daily usage patterns and allow targeted load interruption using the smart sockets/plugs provided. By allowing load shedding at device or appliance level, while knowing their usage profile and preferences, this can allow such an approach to become part of a new voluntary interruptible load management system (ILMS) that requires little user intervention, while minimizing disruption to them, allowing ease of mass participation and thus achieving the intended MW demand management capacities for the grid. This allows for a more cost effective way to better balance the grid without the need for generation capacity growth, large ESS investment while improving the way to perform load shedding without disruptions to entire districts. Simply, home users can now know and participate with the grid in interruptible load (IL) schemes to target specific home appliance, such as water heaters or air conditioning, allowing interruptions during certain times of the day, instead of the entire house, albeit with the right incentives. This allows utilities to achieve MW capacity load shedding with millions of appliances with their preferences, and most importantly, with minimal disruptions to their consumers quality of life. In our paper, we will also consider coupling a small sized Home Energy Storage System (HESS) to amplify the demand management capacity. The proposed approach does not require any infrastructure or wiring changes and is highly scalable. Simulation results demonstrate the effectiveness of the NILM algorithm and achieving high capacity grid demand management. This approach of taking user preferences for appliance level load shedding was developed from the results of a survey of 500 households that indicates >95% participation if they were able to control their choices, possibly allowing this design to be the most successful demand management program than any large ESS solution for the utility. The proposed system has the ability to operate in centralized as part of a larger Energy Management System (EMS) Supervisory Control And Data Acquisition (SCADA) that decide what to dispatch as well as in autonomous modes making it simpler to manage than any MW level large ESS setup. With the availability of high-speed sampling at the DB level, it can rely on EMS SCADA dispatch or when disconnected, rely on the decaying of the grid frequency measured at the metering point in the Smart DB. Our simulation results demonstrate the effectiveness of our proposed approach for fast grid balancing. Full article
