Search Results (21)

In recent decades, glaciers in the southeastern Tibetan Plateau (SETP) have been rapidly melting and showing a large scale of glacier mass loss. Due to the lack of large-scale, high-resolution, and high-precision observations, knowledge on the spatial distribution of the glacier mass balance and the response to climate change is limited in this region. We propose a TanDEM-X bi-static InSAR (Interferometric Synthetic Aperture Radar) algorithm with a non-local mean filter method and difference strategy, to improve the precision of glacier surface elevation change detection. Moreover, we improved the glacier mass balance estimation algorithm with a correction method for multi-source system errors and an uncertainty evaluation method based on error propagation theory to reduce the uncertainty of estimations. We used 13 pairs of TanDEM-X bi-static InSAR images to obtain the glacier mass balance data for the entire SETP. The total area of glaciers monitored was 5821 km² and the total number of glaciers monitored was 2321; the glacier surface elevation change rate was −0.505 ± 0.005 m/yr, and the glacier mass balance estimation was −454.5 ± 13.1 mm w.eq. during 2000–2014. Additionally, we analyzed the spatial distribution of the glacier mass balance within the SETP using the sub-watershed analysis method. The results showed that the mass loss rate had a decreasing trend from the southeast to the northwest. Furthermore, the temperature change and the glacier mass loss rate showed a positive correlation from the southeast to the northwest in this region. This study greatly advances our understanding of the regularities of glacier dynamics in this region, and can provide scientific support for major national goals such as the rational utilization of surrounding water resources and construction of important transportation projects. Full article

An Mw 6.8 earthquake occurred in Luding County, Ganzi Tibetan Autonomous Prefecture, Sichuan Province, on 5 September 2022. This seismic event triggered numerous coseismic geohazards in the seismic zone. In this study, the ascending- and descending-track synthetic aperture radar (SAR) images observed by the Sentinel-1A satellite are utilized to extract the coseismic surface deformation of the Luding earthquake. Subsequently, a faulting model is estimated based on the elastic dislocation theory, under the constraint of the InSAR observation. Additionally, the POT technique was employed to detect coseismic geohazards. High-spatial-resolution optical remote sensing images served to validate the reliability of the detection results. The coseismic interferometric synthetic aperture radar (InSAR) deformation field indicated a maximum deformation of ~190 mm and ~140 mm along the ascending and descending tracks, respectively. The estimated best-fitting faulting model suggests that the optimal seismogenic fault strike and dip angles are 169.3° and 70°, respectively. The fault slip predominantly exhibits left-lateral strike-slip characteristics and is concentrated at depths of 3–12 km. The estimated maximum fault slip was 2.67 m, occurring at a depth of 7 km. The pixel offset tracking (POT) result derived from the pre- and post-earthquake SAR images found a total of 245 medium- to large-scale coseismic geohazards, with a verification rate from optical images exceeding 64%. The distribution of these geohazards is notably dense within the significant fault rupture segment. Geohazards on the fault hanging wall are densely packed, whereas landslides along the Dadu River’s fault footwall are also notably frequent. Full article

In recent years, Interferometric Synthetic Aperture Radar (InSAR) technology has been able to determine the semi-static behavior of bridges. However, most of the research about the use of InSAR in the monitoring of bridges has been applied only in deterministic assessments of their performance. Therefore, in the current manuscript, the Usumacinta Bridge, located in Mexico, was evaluated based on a probabilistic methodology to define structural reliability using images from Sentinel-1. In addition, a controlled experiment was developed using a corner reflector (CR) to evaluate the capabilities of InSAR for determining vertical displacements. In the trial, the CR was designed, oriented, and implemented, finding discrepancies concerning leveling of less than 2 mm. On the other hand, the case of the alternative probabilistic approach integrates the reliability of structures theory and probability density functions (PDFs) of displacements obtained via InSAR technology. In summary, the proposed study focused on the analysis of two years of vertical displacements and monthly velocities; then, implementing the alternative probabilistic approach, the reliability index (β) and probability of risk (P_R) of the bridge were extracted, respectively. Based on the results of the experimental part of the paper, the displacements indicated maximum and minimum values of reliability index of 8.1 and 3.4, respectively. Within this context, the mean and standard deviation obtained were 5.9 and 1.4, respectively. On the other hand, the monthly velocities showed a maximum probability of risk of 2.61%, minimum value of 1.5 × 10⁻⁵%, mean of 0.4%, and standard deviation of 0.8%. Hence, the above-documented results indicate that the Usumacinta Bridge did not suffer any damage during its overloading condition period. Full article

The East Kunlun fault zone (EKFZ), located northeast of the Qinghai–Tibet Plateau, has experienced several strong earthquakes of magnitude seven or above since 1900. It is one of the most active fault systems and is characterized by left-lateral strike-slip. However, the Xidatan–Dongdatan segment (XDS) of the East Kunlun fault zone (EKFZ) has had no earthquakes for many years, and the Kunlun Mountains M_S 8.1 earthquake has a stress loading effect on this segment, so it is widely regarded as a high-risk earthquake gap. To this end, we collected the Sentinel-1 data of the XDS of the EKFZ from July 2014 to July 2019 and obtained the high-precision interseismic deformation field by the Interferometric Synthetic Aperture Radar (InSAR) technique to obtain the slip rate and locking depth of the XDS of the EKFZ, and the seismic potential of the segment was analyzed. The results are as follows: (1) The LOS deformation field of the XDS of the EKFZ was obtained using Sentinel-1 data of ascending and descending orbits, which indicated that the XDS of the EKFZ is dominated by horizontal motion. Combined with the interference results, it is shown that the strike-slip rate dominates the deformation information of the XDS of the EKFZ. The deep strike-slip rate of the fault is about 6 mm/yr, the deep dip-slip rate is about 2 mm/yr, and the slip-deficit rate on the fault surface is about 6 mm/yr; (2) Combined with the spiral dislocation theory model, the slip rate of the XDS to Xiugou Basin of the EKFZ has a gradually increasing trend, with an average slip rate of 9.6 ± 2.3 mm/yr and a locking depth of 29 ± 5 m; (3) The stress accumulation is about 483 ± 92 years in the XDS of the EKFZ, indicating that the cumulative elastic strain energy of the XDS can produce an M_W 7.29 ± 0.1 earthquake in the future. Full article

Today, synthetic aperture radar (SAR) satellites provide large amounts of SAR data at unprecedented temporal resolutions, which promotes hazard dynamic monitoring and disaster mitigation with interferometric SAR (InSAR) technology. This study focuses on big InSAR data dynamical processing in areas of serious decorrelation and large gradient deformation. A new stepwise temporal phase optimization method is proposed to alleviate the decorrelation, customized for deformation parameter dynamical estimation. Subsequently, the sequential estimation theory is introduced to the intermittent small baseline subset (ISBAS) approach to dynamically obtain deformation time series with dense coherent targets. Then, we analyze the reason for the unstable accuracy of deformation parameters using sequential distributed scatterers-ISBAS technology, and construct five indices to describe the quality of deformation parameters pixel-by-pixel. Finally, real data of the post-failure Baige landslide at the Jinsha River in China is used to demonstrate the validity of the proposed approach. Full article

Forest height and vertical structure profile functions can be estimated using polarimetric interferometric synthetic aperture radar (PolInSAR) data based on the random volume over ground (RVoG) model and polarization coherence tomography (PCT) theory, respectively. For each resolution cell, considering different forest vertical scattering structure functions to solve the corresponding forest height, the accuracy of PolInSAR forest height inversion will be improved. In this study, a forest vertical structure profile function and forest height inversion algorithm based on PCT technology was developed by using dual-baseline PolInSAR data. Then the deviation of forest height was corrected according to the inverted forest vertical structure. Finally, the LiDAR and PolInSAR data were employed to verify the proposed method. The experimental results show that the accuracy of the proposed method (tropical forest: RMSE = 5.96 m, boreal forest: RMSE = 3.11 m) is 25.5% and 30.43% higher than that of the dual-baseline RVoG model algorithm (tropical forest: RMSE = 8 m, boreal forest: RMSE = 4.47 m). Full article

With the development of spaceborne processing technologies, the demand for on-board processing has risen sharply. Against this background, spaceborne Interferometric Synthetic Aperture Radar (InSAR) processing has become an important research area. In many cases, high processing capacity is required during on-board InSAR processing, yet Field-Programmable Gate Array (FPGA) resources on the satellites are limited. To improve the performance of spaceborne remote sensing processing, this paper designs a high-performing FPGA system for the coarse registration and interferogram generation process of InSAR. Moreover, to address this dual-constraint problem of resource and processing capacity, the paper proposes an FPGA design method based on the gradient descent theory, which can identify the optimum trade-off scheme between two such constraints. Finally, the proposed system design and method are implemented in FPGA. Experiments showed that the FPGA system outperformed the NVIDIA (Santa Clara, CA, USA) GTX Titan Black Graphics Processing Unit (GPU), and the optimum trade-off scheme only increases the entire time by 1.1% but reduces the FPGA BRAM usage by 8.7%. The experimental results proved the effectiveness and validity of the proposed system and method. Full article

The hybrid interferometric synthetic aperture radar system is a combination of an along-track configuration and cross-track configuration. Based on linear ocean wave theory, an ocean wave inversion algorithm for a hybrid interferometric synthetic aperture radar system is proposed in this work. Using the interferometric synthetic aperture radar images acquired by the TerraSAR-X and TanDEM-X satellites and the interferometric synthetic aperture radar images acquired by an airborne interferometric radar altimeter with a certain degree of squint, the profile of ocean waves and the corresponding orbital velocities were retrieved by combining the new inversion algorithm with the cross-spectra. Meanwhile, key parameters of ocean waves, such as the significant wave height, significant wave orbital velocity, propagation direction, and wavelength of the dominant waves, were also extracted from the ocean wave spectra retrieved in this study. In order to evaluate the reliability of the new inversion algorithm, the retrieved significant wave heights were compared with those provided by the European Centre for Medium-Range Weather Forecasts and measured by a Global Navigation Satellite System buoy. The results showed that for the ocean waves retrieved from the spaceborne hybrid interferometric synthetic aperture radar images, the differences between the retrieved significant wave heights of the four subareas selected in this paper and those provided by European Centre for Medium-Range Weather Forecasts were approximately 0.01, –0.17, –0.55, and –0.37 m, respectively, and for the ocean waves retrieved from the airborne interferometric radar altimeter images, the differences between the retrieved significant wave heights corresponding to the M920 and M3120 images used in this paper and those measured by the Global Navigation Satellite System buoy were approximately –0.05 and –0.09, respectively. Therefore, the method proposed in this work could retrieve the ocean wave spectra well when the velocity bunching had a small influence; however, as the nonlinear influence of the velocity bunching increased, the difference between the significant wave heights retrieved using this method and provided by the European Centre for Medium-Range Weather Forecasts also increased. Full article

The lack and uneven distribution of Ground Control Points (GCPs) will lead to the deterioration of Digital Elevation Model (DEM) block adjustment results in the bistatic Interferometric Synthetic Aperture Radar (InSAR) system. Given this issue, we first explain the relationship between the stability of adjustment parameters and the GCP distribution pattern theoretically using matrix perturbation theory. Second, we put forward the Constraint Slices (CSs) concept and first introduce CSs into the adjustment optimization model as constraint conditions rather than actual values as GCPs. Finally, we propose a novel DEM block adjustment method for spaceborne InSAR using CSs based on an optimization model with nonlinear constraints. The simulated experiment shows the instability of the conventional method and validates the proposed method under different parallel baseline errors. Four groups of real experiments were carried out according to the size of the uncontrolled area using twelve Co-registered Single-look Slant–range Complex (CoSSC) datasets for Henan Province, China. The adjustment results verified by the ICESat-2 ATL08 data demonstrate that the performance of the proposed method is better than the conventional method in the uncontrolled area; the corresponding improvements in adjustment accuracies compared with the conventional method are 0.13 m, 1.02 m, 2.12 m, and 8.18 m, respectively. At the same time, the proposed method can enhance the height consistency in overlapping areas, which is vital for seamless DEM production. Full article

Interferometric synthetic aperture radar (InSAR) enables us to obtain precipitable water vapor (PWV) maps with high spatial resolution through the phase difference caused by refraction in the atmosphere. Although previous studies have evaluated the error level of InSARPWV observations, they validated it only with C-band InSARPWV observations. Since ionospheric disturbance seriously contaminates the InSAR phase in the case of the lower-frequency SAR system, it is necessary for a PWV error level evaluation correcting the ionospheric effect appropriately if we use lower-frequency SAR systems, such as the Advanced Land Observing Satellite-2 (ALOS-2). In this paper, we evaluated the error level of the L-band InSARPWV observation obtained from ALOS-2 data covering four areas in Japan. We compared the InSAR observations with global navigation satellite system (GNSS) atmospheric observations and estimated the L-band InSARPWV error value by utilizing the error propagation theory. As a result, the L-band InSARPWV absolute error reached 2.83 mm, which was comparable to traditional PWV observations. Moreover, we investigated the impacts of the seasonality, the interferometric coherence, and the height dependence on the PWV observation accuracy in InSAR. Full article

Traditional security check technology is mainly based on metal detection by manual inspection. This method is simple and convenient, can detect a few different kinds of contrabands, and also takes into account the safety of inspectors. Because of its strong penetration characteristics, millimeter waves make up for the deficiency of existing security check technologies. Therefore, it is urgent to research and develop millimeter wave holographic imaging technology for human security inspection. In traditional imaging methods, the azimuthal resolution can be improved through various methods of image processing, but the traditional way to improve the range direction resolution is to increase the system bandwidth. However, improvements of the system bandwidth will greatly increase the cost. The bandwidth improvement space is also limited, so it cannot be expanded indefinitely in practical applications. In this study, the interferometric synthetic aperture theory was used to improve the range direction resolution of 3D millimeter wave holographic images without improving the system bandwidth. Phase unwrapping was used to reconstruct the phase information of complex images and restore the continuous phase distribution of the target object so as to achieve improvement of the range direction resolution without increasing the system bandwidth. This work has theoretical guiding significance to improve the range resolution of millimeter wave imaging. Full article

In order to minimize the influence of decorrelation noise on multi-temporal interferometric synthetic aperture radar (MT-InSAR) applications, a series of phase reconstruction methods have been proposed in recent years. Unfortunately, current phase reconstruction methods generally exhibit a low computational efficiency due to their high non-linearity, in particular in the case that the dimension of a SAR stack is high. In this paper, a new approach is proposed to efficiently resolve phase reconstruction problems. This approach is inspired by the theory of probabilistic principle component analysis. A complex valued probability generative model is constructed to portray a phase reconstruction process. Moreover, in order to resolve such a model, a targeted algorithm based on the idea of expectation maximization is designed and implemented. For validation purposes, the proposed approach is compared to the traditional eigenvalue decomposition-based method by using simulated data and 101 real Sentinel-1A SAR images. The experimental results demonstrate that the proposed method can accelerate the phase reconstruction process drastically, in particular when a high-dimensional SAR stack is required to be processed. Full article

The Interferometric Synthetic Aperture Radar (InSAR) technique has been widely used to obtain the ground surface deformation of geohazards (e.g., mining subsidence and landslides). As one of the inherent errors in the interferometric phase, the digital elevation model (DEM) error is usually estimated with the help of an a priori deformation model. However, it is difficult to determine an a priori deformation model that can fit the deformation time series well, leading to possible bias in the estimation of DEM error and the deformation time series. In this paper, we propose a method that can construct an adaptive deformation model, based on a set of predefined functions and the hypothesis testing theory in the framework of the small baseline subset InSAR (SBAS-InSAR) method. Since it is difficult to fit the deformation time series over a long time span by using only one function, the phase time series is first divided into several groups with overlapping regions. In each group, the hypothesis testing theory is employed to adaptively select the optimal deformation model from the predefined functions. The parameters of adaptive deformation models and the DEM error can be modeled with the phase time series and solved by a least square method. Simulations and real data experiments in the Pingchuan mining area, Gaunsu Province, China, demonstrate that, compared to the state-of-the-art deformation modeling strategy (e.g., the linear deformation model and the function group deformation model), the proposed method can significantly improve the accuracy of DEM error estimation and can benefit the estimation of deformation time series. Full article

Multi-temporal interferometric synthetic aperture radar (MT-InSAR) techniques are well recognized as useful tools for detecting and monitoring Earth’s surface temporal changes. In this work, the fundamentals of error noise propagation and perturbation theories are applied to derive the ground displacement products’ theoretical error bounds of the small baseline (SB) differential interferometric synthetic aperture radar algorithms. A general formulation of the least-squares (LS) optimization problem, representing the SB methods implementation’s core, was adopted in this research study. A particular emphasis was placed on the effects of time-uncorrelated phase unwrapping mistakes and time-inconsistent phase disturbances in sets of SB interferograms, leading to artefacts in the attainable InSAR products. Moreover, this study created the theoretical basis for further developments aimed at quantifying the error budget of the time-uncorrelated phase unwrapping mistakes and studying time-inconsistent phase artefacts for the generation of InSAR data products. Some experiments, performed by considering a sequence of synthetic aperture radar (SAR) images collected by the ASAR sensor onboard the ENVISAT satellite, supported the developed theoretical framework. Full article

Seasonal phase disturbances in satellite Interferometric Synthetic Aperture Radar (InSAR) measurements have been reported in other studies to suggest sub-centimetre land surface terrain motion. These have been interpreted in various ways because they correlate with multiple other (sub-)seasonal signatures of, e.g., clay swelling/shrinkage and groundwater level. Recent microwave radar studies mention the occurrence of phase disturbances in different soil types and soil moisture. This study further explored this topic by modeling phase disturbances caused by both soil and vegetation surface characteristics and aimed to interpret what their possible effects on InSAR-interpreted terrain motion is. Our models, based on fundamental microwave reflection and transmission theory, found phase disturbances caused by seasonal variation of soil and vegetation that have the same magnitude as interpreted seasonal land movement in earlier InSAR studies. We showed that small, temporal differences in soil moisture and vegetation can lead to relatively large phase disturbances in InSAR measurements. These disturbances are a result of waves having to comply with boundary conditions at the interface between media with different dielectric properties. The findings of this study explain the seasonal variations found in other InSAR studies and will therefore bring new insights and alternative explanations to help improve interpretation of InSAR-derived seasonal terrain motion. Full article
