Search Results (18)

In order to provide a theoretical basis for the thermal analysis and management of spacecraft/payload interstellar pointing attitudes, which are used for inter-satellite communication, this paper develops an analytical method for solar heat flux under pointing attitudes. The key to solving solar heat flux is calculating the angle between the sun vector and the normal vector of the object surface. Therefore, a method for calculating the included angle is proposed. Firstly, a coordinate system was constructed based on the pointing attitude. Secondly, the angle between the coordinate axis vector and solar vector variation with a true anomaly was calculated. Finally, the reaching direct solar heat flux was obtained using an analytical method or commercial software. Based on the proposed method, the direct solar heat flux of relay satellites in commonly used lunar orbits, including Halo orbits and highly elliptic orbits, was calculated. Thermal analysis on the payload of interstellar laser communication was also conducted in this paper. The calculated temperatures of each mirror ranged from 16.6 °C to 21.2 °C. The highest temperature of the sensor was 20.9 °C, with a 2.3 °C difference from the in-orbit data. The results indicate that the external heat flux analysis method proposed in this article is realistic and reasonable. Full article

High-speed communication can be achieved using laser inter-satellite links. However, laser terminals are highly sensitive to environmental conditions, which can lead to link disconnections. Therefore, an acquisition method capable of determining pointing errors is essential. In this study, a fast space–time fusion acquisition method was developed. This method establishes the relationship between satellite position, capture time, and azimuth and elevation angles. The performance of the proposed acquisition time optimization method was verified in a practical engineering application. Experimental results show that the pointing error was reduced by five times, the acquisition rate increased by 40%, the acquisition speed improved by 300 times, and multiple interference factors were effectively addressed. Full article

In gravitational wave measurement and inter-satellite laser communication systems, the relative rotation and motion between the transmitter and receiver terminals introduces small angular deviations over a link distance of thousands of kilometers, which need to be measured with high accuracy and sensitivity. The heterodyne coherent angle measurement has a higher measurement accuracy and detection sensitivity compared with the traditional direct detection technique, which performs angle measurement through the phase of a beat frequency signal. In this paper, we propose a four-quadrant heterodyne coherent angle measurement technique with μrad accuracy and nW-level detection sensitivity. A mathematical model of a differential wavefront sensing (DWS) angle solution was formulated, and a Monte Carlo simulation system was built for performance testing. An experimental system was devised to assess the accuracy and sensitivity of the heterodyne coherent measurement method and to compare the performance with that of the direct detection method. The experimental results showed that for azimuth and pitch axes, the accuracy of the heterodyne coherent angle measurement was 2.54 μrad and 2.85 μrad under the same signal power of −16 dBm, which had a 5-fold improvement compared with direct detection. The sensitivity of the heterodyne coherent detection was −50 dBm at the 20 μrad accuracy threshold, which was a 1000-fold improvement compared with direct detection. This research is of great significance for the phase measurement and tracking system in the field of gravitational wave detection and has a guiding role in system design work in the field of inter-satellite laser communication. Full article

The rapid advancement of terahertz (THz) communication systems has positioned this technology as a key enabler for next-generation telecommunication networks, including 6G, secure communications, and hybrid wireless-optical systems. This review comprehensively analyzes THz communication, emphasizing its integration with free-space optical (FSO) systems to overcome conventional bandwidth limitations. While THz-FSO technology promises ultra-high data rates, it is significantly affected by atmospheric absorption, particularly absorption beyond 500 GHz, where the attenuation exceeds 100 dB/km, which severely limits its transmission range. However, the presence of a lower-loss transmission window at 680 GHz provides an opportunity for optimized THz-FSO communication. This paper explores recent developments in high-power THz sources, such as quantum cascade lasers, photonic mixers, and free-electron lasers, which facilitate the attainment of ultra-high data rates. Additionally, adaptive optics, machine learning-based beam alignment, and low-loss materials are examined as potential solutions to mitigating signal degradation due to atmospheric absorption. The integration of THz-FSO systems with optical and radio frequency (RF) technologies is assessed within the framework of software-defined networking (SDN) and multi-band adaptive communication, enhancing their reliability and range. Furthermore, this review discusses emerging applications such as self-driving systems in 6G networks, ultra-low latency communication, holographic telepresence, and inter-satellite links. Future research directions include the use of artificial intelligence for network optimization, creating energy-efficient system designs, and quantum encryption to obtain secure THz communications. Despite the severe constraints imposed by atmospheric attenuation, the technology’s power efficiency, and the materials that are used, THz-FSO technology is promising for the field of ultra-fast and secure next-generation networks. Addressing these limitations through hybrid optical-THz architectures, AI-driven adaptation, and advanced waveguides will be critical for the full realization of THz-FSO communication in modern telecommunication infrastructures. Full article

Solar irradiance is a critical factor influencing the reliability of optical inter-satellite links (O-ISLs). Despite its significance, limited research has focused on addressing this challenge. This work investigates the impact of solar irradiation on the optimal path configuration. A multi-directional field-of-view (FoV) model is used to practically accommodate the solar irradiance imposed on each optical transceiver module in a single satellite. The effectiveness of the optimal path configurations is evaluated through detour mitigation strategies, comparing inter-plane and inter-shell link alternatives in intercontinental scenarios within the northern hemisphere. In the scenarios, it is found that there is a tradeoff between the FoV and the level of the signal-to-noise ratio (SNR) required to overcome the effects of solar irradiance. Also, seasonal alterations in the sun’s incident direction significantly influence the link availability, with unusable link rates nearly doubling in summer compared to spring because of orbital inclinations tending to be aligned more closely with the solar direction toward Earth. The proposed inter-shell-based path optimization reduces the total link distance by up to 2500 km compared to those of the inter-plane configurations, demonstrating superior performance in mitigating impairment due to solar irradiance. Full article

Laser space networks are an important development direction for inter-satellite communication. Detecting the angle of arrival (AOA) of multiple satellites in a wide field of view (FOV) is the key to realize inter-satellite laser communication networking. The traditional AOA detection method based on the lens system has a limited FOV. In this paper, we demonstrate a system that uses a spatially distributed sensor array to detect the AOA in a wide FOV. The basic concept is to detect AOA using the signal strength of each sensor at different spatial angles. An AOA detection model was developed, and the relationship of key structural parameters of the spatially distributed sensor array on the FOV and angular resolution was analyzed. Furthermore, a spatially distributed sensor array prototype consisting of 5 InGaAs PIN photodiodes distributed on a 3D-printed structure with an inclination angle of 30° was developed. In order to improve the angle calculation accuracy, a multi-sensor data fusion algorithm is proposed. The experimental results show that the prototype’s maximum FOV is 110°. The root mean square error (RMSE) for azimuth is 0.6° within a 60° FOV, whereas the RMSE for elevation is 0.67°. The RMSE increases to 1.1° for azimuth and 1.7° for elevation when the FOV expands to 110°. The designed spatially distributed sensor array has the advantages of a wide FOV and low size, weight, and power (SWaP), presenting great potential for multi-satellite laser communication applications. Full article

Space-based gravitational wave detection uses an equilateral triangular satellite constellation with inter-satellite laser heterodyne interferometry to measure displacement variations caused by gravitational waves. Inter-satellite laser communication is critical for data transmission, redundancy and clock synchronization, which suppresses clock noise and enhances detection sensitivity. This integrated approach ensures precise gravitational wave information extraction, supporting the high-accuracy requirements of space-based observatories. This study focuses on the modeling and simulation of inter-satellite laser communication for space-based gravitational wave detection. Based on the data-transmission requirements of such systems, the principles of inter-satellite laser communication are analyzed. The research includes the selection of pseudo-random noise (PRN) codes, the signal scheme design and the development of the mathematical models for signal transmission. A simulation model is subsequently constructed in Simulink to evaluate the system. The simulation results confirm the accuracy of the model’s functionalities, including spreading, phase modulation, noise addition, phase demodulation and despreading. Additionally, the model achieves a data-transmission rate of 62.5 kbps with a bit error rate (BER) better than ${10}^{-6}$ when the modulation index exceeds $3.4\times {10}^{-3}$, meeting the requirements for inter-satellite laser communication in space-based gravitational wave detection. Full article

Coherent free-space optical communication offers significant advantages in terms of communication capacity, making it particularly suitable for high-speed inter-satellite transmission within satellite communication networks. Nonetheless, the presence of Doppler frequency offset (FO) and phase noise (PN) associated with lasers adversely affects the bit error rate (BER) performance of these communication systems. Conventional methods for FO and phase estimation are usually hindered by high computational demands and phase cycle slips, especially in environments characterized by elevated channel noise. To address these challenges, a noise-tolerant method is proposed to facilitate accurate carrier phase recovery (CPR) with reduced complexity. This method merges a second-order feedback loop and a feedforward stage to achieve accurate estimation. The simulation results indicate that the proposed method surpasses traditional methods in terms of noise tolerance and resource efficiency. Particularly, the BER of the proposed method can be decreased to $6.7\times {10}^{-3}$ at a signal-to-noise ratio (SNR) of 4.5 dB, in contrast to a BER of 0.25 for the traditional method. Additionally, the resource consumption of the proposed method can be decreased by 64% under equivalent conditions. Furthermore, the experimental results reveal that the phase estimation error and BER for the proposed method are $2.1\times {10}^{-4}$ and $7.5\times {10}^{-4}$, respectively, when the received power is −41 dBm. These values are significantly lower than those achieved with traditional methods, which obtain errors of $1.85\times {10}^{-3}$ and a BER of 0.48, respectively. Full article

This paper examines the growing adoption of laser communication (lasercom) in space missions and payloads for identifying emerging trends and key technology drivers of future optical communications satellite systems. It also presents a comprehensive overview of commercially available and custom-designed lasercom terminals, outlining their characteristics and specifications to meet the evolving demands of global satellite networks. The analysis explores the technical considerations and challenges associated with integrating lasercom terminals into LEO constellations and the Inter-satellite communications service provision in LEO due to their power, size, and weight constraints. By analyzing advancements in CubeSat lasercom technology designed to cater for the emergence of future mega constellations of interacting small satellites, the paper underscores its promising role in establishing high-performance satellite communication networks for future space exploration and data transmission. In addition, a brief overview of our ALIGN planned mission is provided, which highlights the main key operational features in terms of PAT and link budget analysis. Full article

In the field of inter-satellite laser communication, achieving high-quality communication and compensating for the Doppler frequency shift caused by relative motion necessitate lasers with narrow linewidths, low phase noise, and the ability to achieve mode-hop-free tuning within a specific range. To this end, this paper investigates a novel external cavity diode laser (ECDL) with a frequency-selective F-P etalon structure, leveraging the external cavity F-P etalon structure in conjunction with an auxiliary filter to achieve single longitudinal mode selection. The laser undergoes linewidth testing using a delayed self-heterodyne beating method, followed by the testing of its phase noise and frequency noise characteristics using a noise analyzer, yielding beat spectra and noise power spectral density profiles. Furthermore, the paper introduces an innovative bidirectional temperature-scanning laser method to achieve optimal laser-operating point selection and mode-hop-free tuning. The experimental results showcase that the single longitudinal mode spectral side-mode suppression ratio (SMSR) is around 70 dB, and the output power exceeds 10 mW. Enhancing the precision of the F-P etalon leads to a more pronounced suppression of low-frequency phase noise, reducing the Lorentzian linewidth from the initial 10 kHz level to a remarkable 5 kHz level. The bidirectional temperature-scanning laser method not only allows for the selection of the optimal operating point but also enables mode-hop-free tuning within 160 pm. Full article

The signal-receiving end of acquisition, pointing, and tracking (APT) systems applied to intersatellite laser communication terminals usually uses a fast-steering mirror (FSM) to control the fiber-coupling process, has a complex structural design, and induces large errors in the nonideal coaxial optical path. Herein, we propose a fiber-optic nutator using a piezoelectric ceramic tube (PCT) as the driving unit that allows scanning in the focal plane of the light signal to achieve active fiber coupling in the APT system. Specifically, this article describes the structural design principle of a PCT-based fiber optic nutator, establishes a simulation model of the mechanism, and proves the correctness of the simulation model by measuring the deflection angle of a PCT based on a parallel light collimator. The minimum accuracy of the designed nutator was 0.145 μm, the maximum nutation radius R was 20.09 μm, and the maximum nutation bandwidth was 20 kHz, as determined through simulation. Finally, the design parameters of the nutator were evaluated. The PCT-based fiber optic nutator, which met the design parameters, structurally replaced the fiber optic coupling component FSM and fine tracking camera in conventional APT systems successfully. Therefore, the PCT-based fiber optic nutator allows the active coupling control of signal light to a single-mode fiber (SMF) based on energy feedback on a theoretical basis and promotes the lightweight design of relay optical paths in APT systems. In addition, with future work in optimization of the nutation control algorithm, the scanning range and accuracy of the nutator can be improved. Full article

The leaf area index (LAI) is a crucial indicator for quantifying forest productivity and community ecological processes. Satellite remote sensing can achieve large-scale LAI monitoring, but it needs to be calibrated and validated according to the in situ measurements on the ground. In this study, we attempted to use different indirect methods to measure LAI in a tropical secondary forest. These methods included the LAI-2200 plant canopy analyzer (LAI-2200), Digital Hemispherical Photography (DHP), Tracing Radiation and Architecture of Canopies (TRAC), and Terrestrial Laser Scanning (TLS) (using single-station and multi-station measurements, respectively). Additionally, we tried to correct the measured LAI by obtaining indicators of woody components and clumping effects. The results showed that the LAI of this forest was large, with estimated values of 5.27 ± 1.16, 3.69 ± 0.74, 5.86 ± 1.09, 4.93 ± 1.33, and 3.87 ± 0.89 for LAI-2200, DHP, TRAC, TLS multi-station, and TLS single-station, respectively. There was a significant correlation between the different methods. LAI-2200 was significantly correlated with all other methods (p < 0.01), with the strongest correlation with DHP (r = 0.684). TRAC was significantly correlated with TLS single-station (p < 0.01, r = 0.283). TLS multi-station was significantly correlated with TLS single-station (p < 0.05, r = 0.266). With the multi-station measurement method, TLS could maximize the compensation for measurement bias due to the shadowing effects. In general, the clumping index of this forest was 0.94 ± 0.05, the woody-to-total area ratio was 3.23 ± 2.22%, and the total correction coefficient was 1.03 ± 0.07. After correction, the LAI estimates for all methods were slightly higher than before, but there was no significant difference among them. Based on the performance assessment of existing ground-based methods, we hope to enhance the inter-calibration between methods to improve their estimation accuracy under complex forest conditions and advance the validation of remote sensing inversion of the LAI. Moreover, this study also provided a practical reference to promote the application of LiDAR technology in tropical forests. Full article

The Japanese National Institute of Information and Communications Technology (NICT) is currently developing a high-performance laser-communication terminal for CubeSats aimed at providing a high-datarate communication solution for LEO satellites requiring transmission of large volumes of data from orbit. A key aspect of the communication system is a high-power optical amplifier capable of providing enough gain to the transmitted signals to be able to close the link on its counterpart’s receiver with the smallest impact in terms of energy and power on the CubeSat’s platform. This manuscript describes the development of a miniaturized 2-W space-grade 2-stage erbium-doped fiber amplifier (EDFA) compatible with the CubeSat form factor, showing the best power-to-size ratio for a space-qualified EDFA to the best of the authors’ knowledge. Performance results under realistic conditions as well as full space qualification and test are presented, proving that this module can support short-duration LEO-ground downlinks as well as long-duration intersatellite links. Full article

With growth in data volume from space missions, interest in laser communications has increased, owing to their importance for high-speed data transfer in the commercial and defense fields, spaceborne remote sensing, and surveillance. Here, we propose a novel system for space-to-space laser communication, a very high-speed inter-satellite link system using an infrared optical terminal and nanosatellite (VISION), which is aimed at establishing and validating miniaturized laser crosslink systems and several space technologies using two 6U nanosatellites in formation flying. An optical link budget analysis is conducted to derive the signal-to-noise ratio requirements and allocate the system budget; the optical link margin should be greater than 10 dB to guarantee communication with practical limitations. The payload is a laser transceiver with a deployable space telescope to enhance the gain of the beam transmission and reception. Nanosatellites, including precise formation flying GNC systems, are designed and analyzed. The attitude control system ensures pointing and tracking errors within tens of arcsec, and they are equipped with a propulsion system that can change the inter-satellite distance rapidly and accurately. This novel concept of laser crosslink systems is expected to make a significant contribution to the future design and construction of high-speed space-to-space networks. Full article

The low earth orbit (LEO) constellation network has become a promising approach to provide global communication services, due to its advantages in wide global coverage, low transmission delay, and convenient networking. However, the instability of the intersatellite laser terminal and the high relative speed between adjacent satellites cause frequent network topology changing problems for data routing. In this paper, a disruption tolerant distributed routing algorithm (DTDR) is proposed, where the satellites calculate the alternate path for transmission when the network topology changes, which improves the performance of packet loss. Specifically, each satellite maintains the intersatellite link (ISL) information within a specified number of hops. When an ISL state changes within the specified number of hops, the corresponding satellite calculates and switches to the detour path. Furthermore, the traffic is balanced through the detour process. Various simulations were constructed and show that the proposed algorithm outperforms the existing algorithm in terms of packet loss ratio and transmission delay. Full article
