The patch loading resistance of slender steel plate girders is a critical factor in the design of launched steel and composite steel–concrete bridges. Traditional design methods enhance patch loading resistance through various stiffening techniques, with contributions typically estimated via code expressions calibrated on experimental data that do not always reflect the complexities of full-scale bridge applications. Finite Element (FE) modeling offers a more realistic alternative, though its practical application is often hindered by modeling uncertainties and nonlinearities. To bridge this gap, this paper introduces an advanced FE modeling approach. It provides a comprehensive description of an FE model that accurately predicts both the load–displacement behavior and the patch loading resistance. The model is benchmarked against a broad set of experimental tests and systematically investigates the effects of key modeling parameters and their interactions—material stress–strain law, boundary condition representation, stiffness of the load introduction area, initial geometric imperfections, and solving algorithms. Key findings demonstrate that a bilinear elastoplastic material model with hardening is sufficient for estimating ultimate resistance, and kinematic constraints can effectively replace rigid transverse stiffeners. The stiffness of the load application zone significantly influences the response, especially in launched bridge scenarios. Initial imperfections notably affect both stiffness and strength, with standard fabrication tolerances offering suitable input values. The modified Riks algorithm is recommended for its efficiency and stability in nonlinear regimens. The proposed methodology advances the state of practice by providing a simple yet reliable FE modeling approach for predicting patch loading resistance in real-world bridge applications, leading to safer and more reliable structural designs. Full article

An analytical study of the nonlinear response of imperfect stiffened doubly curved shells made of functionally graded material (FGM) is presented. The formulation of the problem is based on the first-order shear deformation shell theory in conjunction with the von Kármán geometrical nonlinear strain–displacement relationships. The nonlinear equations of the motion of stiffened double-curved shells based on the extended Sanders’s theory were derived using Galerkin’s method. The material properties vary in the direction of thickness according to the linear rule of mixture. The effect of both longitudinal and transverse stiffeners was considered using Lekhnitsky’s technique. The fundamental frequencies of the stiffened shell are compared with the FE solutions obtained by using the ABAQUS 6.14 software. A stepwise approximation technique is applied to model the functionally graded shell. The resulting nonlinear ordinary differential equations were solved numerically by using the fourth-order Runge–Kutta method. Closed-form solutions for nonlinear frequency–amplitude responses were obtained using He’s energy method. The effect of power index, functionally graded stiffeners, geometrical parameters, and initial imperfection on the nonlinear response of the stiffened shell are considered and discussed. Full article

Bimetallic-clad pipes demonstrate exceptional advantages in transporting corrosive oil and gas through the combination of the load-carrying capacity of the base material and the anti-corrosive function of the thin layer of corrosion-resistant alloy. This study investigates the mechanical properties of 24-inch X65 + Alloy625 metallurgically clad pipes through experimental tests and finite element analysis. Uniaxial tensile testing with digital image correlation reveals uniform deformation between the base and clad layers until interfacial failure initiates at an average strain threshold of 34.17%. Microstructural characterization shows continuous metallurgical bonding, with the X65 layer exhibiting polygonal ferrite and bainitic phases, contrasting with the austenitic equiaxed grain structure of Alloy625. In terms of numerical modeling, finite element analyses that consider both initial geometric imperfections and manufacturing-induced residual stresses are performed to evaluate the bending response of the clad pipe. The effect of initial ovality and residual stresses on its bending capacity is also studied. Full article

This study experimentally and numerically investigated the overall buckling behavior of steel box column components. Two box section specimens were fabricated for axial compression tests. Prior to the tests, the material properties, initial geometric imperfections and residual stress were measured. In addition, an extended parameter analysis was conducted using a finite element model validated by experimental results to evaluate the impact of geometric defects and residual stresses on the bearing capacity of unstiffened and stiffened box section columns. A novel column curve was proposed based on massive datasets of parametric models. The short and long column specimens exhibited typical strength failure and buckling failure modes, respectively. The initial geometric imperfections and residual stresses slightly reduced the buckling strength from the models, with a maximum reduction in buckling strength owing to initial geometric imperfections of 5.2% and that owing to residual stresses of 6.52%. The unstiffened and stiffened box columns have the same stability coefficient when the slenderness ratio is the same. Additionally, the ultimate load capacity calculation formula for stiffened box columns proposed in this paper averages 2.20% higher than Class C curves in JTG D64-2015, lies between Japanese and U.S. codes, and demonstrates good accuracy. Full article

An asymptotic analytical method is proposed to study the thermal post-buckling behaviors of fiber-reinforced composite (FRC)-laminated beams with geometric imperfections employing a modified zig-zag beam model. The beam model satisfied the discontinuity of the shear deformation at the interlayer interfaces and the stress boundary conditions on the upper and lower surfaces. Each imperfection was assumed to possess the same shape as the buckling mode, and the in-plane boundary conditions were presumed to be immovable. A two-step perturbation method was used to solve the nonlinear governing equations and obtain the equilibrium path. Subsequently, the initial defect sensitivity of the post-buckling behaviors was analyzed. The existence of the bifurcation-type equilibrium path for perfect beams is discussed in depth. Load–deflection curves for beams with various boundary conditions and ply modes were plotted to illustrate these findings. The effects of the slenderness ratio, elastic modulus ratio, thermal expansion coefficient ratio, ply modes, and supported boundaries on the buckling and post-buckling behaviors were also investigated. The numerical results indicate that the slenderness ratio significantly influences the critical buckling temperature, with thicker beams exhibiting higher buckling resistance. The elastic modulus ratio also plays a crucial role, with higher ratios leading to increased buckling strength. Additionally, the thermal expansion coefficient ratio affects the post-buckling load-bearing capacity, with lower ratios resulting in greater stability. Full article

Concrete-filled steel tube (CFT) columns are widely used as structural systems because of their high load-bearing capacity and material efficiency. However, under fire conditions, elevated temperatures degrade the mechanical properties of both steel and concrete. When combined with initial geometric imperfections, these factors significantly affect the load distribution and the fire resistance of the structure. Understanding how material properties and geometric factors change in CFT columns at elevated temperatures is essential for ensuring safe and efficient design. This study used the ASTM E119-88 fire curve to establish the relationship between the surface temperature of the structure and the fire resistance duration of the CFT column. Heat transfer and mechanical analyses of the structure were conducted using ABAQUS 2024 software. A comparison of simulation and experimental data showed that the numerical model was highly accurate. The study also addressed the effects of initial geometric imperfections, considering amplification factors of L/1000 and L/500, and compared the simulation results with the experimental data. The results demonstrated that initial geometric imperfections significantly influenced the fire resistance of the columns. Additionally, this study examined the material properties under high-temperature conditions as specified in the AISC 360-22 standard. The study compared the simulation results with the Eurocode standards and experimental data. The findings suggested that utilizing the material properties specified in the AISC 360-22 standard resulted in more conservative predictions of fire resistance for CFT columns, compared to the Eurocode standards. Furthermore, Appendix 4 of the AISC 360-22 standard was used to calculate the fire resistance rating of the CFT column. These calculations were compared with the simulation and experimental results to evaluate the reliability of using ABAQUS 2024 simulation software. Full article

This paper studies the thermomechanical low-velocity impact behaviors of geometrically imperfect nanoplatelet-reinforced composite (GRC) beams considering the von Kármán nonlinear geometric relationship. The graphene nanoplatelets (GPLs) are assumed to have a functionally graded (FG) distribution in the matrix beam along its thickness, following the X-pattern. The Halpin–Tsai model and the rule of mixture are employed to predict the effective Young modulus and other material properties. Dividing the impact process into two stages, the corresponding impact forces are calculated using the modified nonlinear Hertz contact law. The nonlinear governing equations are obtained by introducing the von Kármán nonlinear displacement–strain relationship into the first-order shear deformation theory and dispersed via the differential quadrature (DQ) method. Combining the governing equation of the impactor’s motion, they are further parametrically solved by the Newmark-β method associated with the Newton–Raphson iterative process. The influence of different types of geometrical imperfections on the nonlinear thermomechanical low-velocity impact behaviors of GRC beams with varying weight fractions of GPLs, subjected to different initial impact velocities, are studied in detail. Full article

Flexible pipe is one of the most important types of equipment applied in the deep-water development of oil and gas and deep-sea metal mining. The carcass of an unbonded flexible pipe with a typical interlocked structure prevents buckling failure under external hydrostatic pressure. The process and principle of carcass layer deformation are described, and a three-dimensional finite element model with solid-shell elements is developed to simulate the cold forming process of a metal strap subjected to a series of rollers. The deflection and deformation behavior in the bend-rolling and interlocking process are investigated, and the residual stress due to deformation is calculated. Taking the carcass layer of a 4-inch internal diameter flexible pipe as an example, a three-dimensional finite element model of the carcass layer loaded with external hydrostatic pressure is developed. The buckling collapse of the carcass layer is evaluated considering different initial imperfections, including residual stress. The results show that the critical pressure can be 60% less than under ideal conditions when the geometric imperfection, material nonlinearity and residual stress due to deformation are considered, which indicates that the effect of residual stress on buckling collapse cannot be ignored. The numerical model and results provide an efficient method and basis for nonlinear buckling analysis and a collapse-resistant unbonded flexible pipe design for industry. Full article

A simplified column-buckling model is developed to understand the buckling mechanism of thin-walled strips restrained by uniform lateral pressure in the milling process. The strip is simplified as two rigid columns connected by a rotation spring, resting on a smooth surface, restrained by a uniform pressure and loaded by an axial force. Two loading cases are considered, i.e., the dead load and the follower load. Analytical solutions for the post-buckling responses of the two cases are derived based on the energy method. The minimum buckling force, Maxwell force and stability conditions for the two cases are established. It is demonstrated that the application of higher uniform pressure increases the minimum buckling force for the column and thus makes the column less likely to buckle. For the same pressure level, the dead load is found to be more effective than the follower load in suppressing the buckling of the system. The effect of initial geometric imperfection is also investigated, and the imperfection amplitude and critical restraining pressure that prevent buckling are found to be linearly related. The analytical results are validated by finite element simulations. This analytical model reveals the buckling mechanism of strips under lateral pressure restraint, which cannot be explained by the conventional bifurcation buckling theory, and provides a theoretical foundation for buckling-prevention strategies during the milling process of thin-walled strips, plates and shells commonly encountered in aerospace or automotive industries. Full article

Shear-keyed inter-modular connections (IMCs) are integral components of high-rise modular steel structures (MSSs), providing robust interconnectivity to support grouped tubular columns across modules, thereby introducing column discontinuities and distinctive structural behavior. This study conducted a comprehensive numerical assessment and theoretical analysis of the axial compression behavior of grouped tubular columns based on a validated finite element model (FEM), which captured the member-to-structural level behavior of steel hollow section (SHS) columns and accommodated geometric imperfections. An FEM was initially developed and validated using 28 axial compression tests documented in the literature, comprising 15 tests on cold-formed and 13 on hot-rolled steel hollow section (SHS) columns. The primary parameters explored in tests included material properties (stainless/carbon), processing methods (cold-formed/hot-rolled), cross-section sizes (D/B), cross-sectional or member slenderness ratios (D/t_c, B/t_c, or L_c/r), and the number of columns (1, 7, and 11). A comprehensive parametric numerical study involving 103 grouped tubular column FEMs then investigated the influence of initial imperfection, shear-key height (L_t), thickness (t_t), steel tube length (D), width (B), thickness (t_c), and height (L_c) alongside the effects of space between tube and key, and the gap between tubes. The results indicated that the load-shortening behavior of the grouped columns consists of linear elastic, inelastic, and recession stages. The failure modes observed primarily displayed an S-shaped pair of inward and outward local buckling on the outer sides and double S-shaped local buckling on the interior sides. The buckling arose near the shear key or at 1/4 or 1/2 of the column height. None of the considered models experienced global buckling. Increasing t_t, L_t, t_c, D, or B enhances strength and stiffness, while L_c or L_c/r linearly affects stiffness and ductility. The columns’ nominal axial strength was reduced because of the shear keys, which decreased compression yielding and caused localized elastic buckling. Subsequently, the theoretical analysis revealed that the design codes do not capture this behavior, and thus, their capacity estimate yields inaccurate findings. This discrepancy renders existing code prediction equations, including those from Indian (IS800), New Zealand (NZS400), European (EC3:1-1), Canadian (CSA S16), American (AISC360-16), and Chinese (GB50017) standards, as well as the model proposed by Li et al., non-conservative. To assure conservative results, the paper recommended modification of existing standards and proposed prediction equations based on a fourth-order differential equation that describes the actual behavior of modular steel columns grouped with shear keys. The proposed design approach accurately predicted the axial compression capacity of modular steel-grouped columns, proving conservative yet effective. This provides valuable data that could transform design and construction techniques for MSSs, extending to various column and IMC forms through adaptable design parameters. This enhancement in structural performance and safety significantly contributes to the advancement of modular construction practices. Full article

The stochastic modeling of geometrically imperfect steel frame structures requires statistical inputs for imperfection parameters, often with specific mutual correlations. The stochastic input values of geometrical imperfections are derived from European Standard EN 1090-2:2018 tolerance criteria. Two advanced stochastic methods, #RSS (random storey sway) and #RSP (random storey position), are developed based on these criteria. This paper presents a verification study, using random sampling simulations, for these two stochastic methods (#RSS and #RSP) to directly model the initial global geometrical imperfections of steel frame structures. The proposed methods have been verified for structures with equidistant storey heights and for those comprising up to 24 storeys, making them applicable to a wide range standard steel frame structures. It has been found that the performance of the #RSS method is satisfactory. An advantage of #RSS is that the random parameters are statistically independent. On the other hand, the #RSP method requires the definition of these mutual correlations in order to satisfy the criterion that 95 percent of random realizations of initial imperfections fall within the tolerance limits of the corresponding European Standard. The #RSP method, however, might have certain advantages for structures with a larger number of storeys (above 24), as closely discussed in this study. Additionally, this study provides useful provisions for the advanced numerical analyses of multi-storey steel frames of various geometries. Full article

Nowadays, 3D laser scanning technology is extensively employed in laboratory investigations of steel structural components, providing accurate geometric dimensions to reduce uncertainties caused by indeterminate geometry in experimental results. It is often used in conjunction with the Finite Element (FE) Method and analytical solutions, which are more accurate deterministic operators in the research on steel structures. However, establishing a common methodological framework for transferring or mapping 3D-scanned information into finite element models for complex steel structures with stability and fatigue risks remains an ongoing task. In light of this, this study has developed a 3D scanning platform capable of obtaining accurate geometric dimensions for various types of steel components. Different coordinate systems and point cloud mapping algorithms have been established for different types of components to construct actual finite element models with initial imperfections. The feasibility of the self-developed 3D scanning platform and finite element modelling has been validated through three experimental cases: weld details, steel girders, and cylindrical shells. The research findings demonstrate that the captured point cloud can be automatically processed and corrected using the developed algorithm. The scanned data can then be input into the numerical model using various mapping algorithms tailored to the specific geometric properties of the specimens. The differences between the experimental test results and the simulated results obtained from the 3D-scanned finite element models remain within a small range. The self-developed 3D scanning platform and finite element modelling technique effectively capture the actual dimensions of different steel components, enabling the prediction of their stability and fatigue risks through numerical simulations. Full article

A new utilization of entropy in the context of buckling is presented. The novel concept of connecting the strain energy and entropy for a pin-ended strut is derived. The entropy of the buckling mode is extracted through a surrogate model by decomposing the strain energy into entropy and virtual temperature. This concept rationalizes the ranking of buckling modes based on their strain energy under the assumption of given entropy. By assigning identical entropy to all buckling modes, they can be ranked according to their deformation energy. Conversely, with identical strain energy assigned to all the modes, ranking according to entropy is possible. Decreasing entropy was found to represent the scaling factors of the buckling modes that coincide with the measurement of the initial out-of-straightness imperfections in IPE160 beams. Applied to steel plane frames, scaled buckling modes can be used to model initial imperfections. It is demonstrated that the entropy (scale factor) for a given energy roughly decreases with the inverse square of the mode index. For practical engineering, this study presents the possibility of using scaled buckling modes of steel plane frames to model initial geometric imperfections. Entropy proves to be a valuable complement to strain energy in structural mechanics. Full article

This paper provides a numerical and experimental analysis of global stability of axially compressed columns made of thin-walled rectangular concrete-filled steel tubes (CFSTs), with the consideration of initial geometric imperfections. The presented work introduces the theory of stability and strength of composite structural members subjected to axial compressive force. Moreover, a numerical calculation method for the determination of column resistance under axial load is presented, taking into account the influence of second-order effects that are considered in the European standard for the design of such members. This paper also presents the method of creating 3D models using the ABAQUS software, numerical analysis, and comparison of the obtained numerical results with experimental tests. In addition to the actual boundary and load conditions, the real properties of the used materials were also taken into account during the creation of 3D models. The actual properties of the used materials were obtained experimentally. Based on the obtained results and their comparison, several new findings and proven facts about the design and assessment of axially compressed columns made of thin-walled rectangular steel tubes filled with concrete are presented in the conclusions of the paper. Full article

The fully transparent cabin used in a manned submersible is typically made of the viscoelastic material polymethyl methacrylate (PMMA). The pressure-bearing capacity of a PMMA-manned cabin was investigated considering the effects of initial geometrical imperfections and large openings. Three types of cabins were studied within the failure mode of nonlinear buckling, including an intact spherical cabin, a spherical cabin with a single opening, and a spherical cabin with double openings. The initial geometrical imperfection ranges from 0.1% to 0.5% of the inner diameter. The ultimate strength decreasing tendency for the different types of cabins with increasing initial imperfection was obtained and the thickness of the hatch cover determined based on the principle of equivalence differed its effects on the strength of the cabin. The influence of the hatch cover stiffness was not linear and indicated the necessity of exploring the coordinated design between the PMMA shell and the metal hatch cover for the transparent cabin. Full article
