Search Results (24)

Transformer fires within indoor substations constitute severe hydrocarbon fire scenarios characterized by rapid heat release rates and extreme peak temperatures, posing a critical threat to the structural integrity of steel frameworks and power grid stability. To rigorously assess structural safety under such conditions, this study employs a sequential thermal-mechanical coupled numerical methodology combining Computational Fluid Dynamics (CFD) and Finite Element Analysis (FEA). Focusing on a 110 kV indoor substation, the research simulates the transient, non-uniform temperature fields induced by transformer oil combustion and analyzes the thermo-mechanical response of key steel components. Furthermore, the protective efficacy of two non-intumescent coatings (Material A and Material B) with distinct thermal conductivities is systematically evaluated. Computational results elucidate significant thermal stratification, with upper-level structures sustaining exposure to temperatures exceeding 1500 K. Unprotected steel components subjected to direct flame impingement exhibit severe stress concentrations and plastic deformation, reaching their load-bearing limit within 4825 s. The application of fire-retardant coatings markedly enhances fire resistance; a 5 mm layer of Material A (λ = 0.20 W/(m·K)) extends the time to failure to approximately 9390 s. Notably, increasing the thickness of Material A to 20 mm, or alternatively employing a 10 mm layer of Material B (λ = 0.10 W/(m·K)), effectively mitigates thermal stress concentrations. This ensures structural deformation remains within safe limits throughout a 3 h (10,800 s) fire duration. This study provides a theoretical basis and quantitative engineering references for the optimal fire protection design of substation steel structures. Full article

In the split main transformer room of the indoor substation studied in this paper, the heat dissipation area of the transformer main body and part of the convection pipeline accounts for approximately 5.4% of the total heat dissipation area, with the outdoor radiator responsible for releasing most of the heat. Compared with the integrated main transformer room of indoor substations, the split-type design features a smaller building size and lower ventilation energy consumption, thus it is widely applied in urban areas. This study employs computational fluid dynamics (CFD) simulation to investigate the natural ventilation and heat dissipation performance of the main transformer room in a 110 kV indoor substation located in the Shijiazhuang area. A thermal imager is used to capture the surface temperature distribution of the main transformer, and the data is fitted into a polynomial function. During the numerical simulation, the surface temperature of the main transformer is set using a user-defined function (UDF), and the total heat dissipation of each heat-dissipating surface of the transformer is extracted via FLUENT(Ansys 2024 R2) software as the basis for evaluating the ventilation and heat dissipation effectiveness. The effects of different ventilation window sizes on the natural ventilation heat dissipation and air change rate of the indoor substation’s main transformer room under thermal pressure are compared. The feasibility of this numerical simulation method is verified through experimental measurements and theoretical analysis. Full article

This paper addresses the suppression of multi-frequency line spectrum vibrations during the operation of indoor substations through the development of an active vibration isolation scheme based on a piezoelectric stack inertial actuator. Based on the finite element modal analysis, the excitation frequencies that strongly influence structural response were identified, and the excitation points and sensor layout strategies were determined under a collocated control configuration. Subsequently, the actuator’s structural design and system integration were carried out. Experimental results demonstrate vibration amplitude reductions of 18.75 dB at 100 Hz, 46.02 dB at 200 Hz, and 32.04 dB at 300 Hz, respectively, validating the effectiveness of the proposed method in controlling line spectrum vibrations at multiple frequencies. The study shows that the coordinated optimization of modal matching and the dynamic response capability of inertial actuators provides experimental evidence and technical guidelines for active vibration isolation in large plate-shell structures. Full article

Against the backdrop of the global energy crisis and the “dual carbon” goals (carbon peaking and carbon neutrality), the passive energy-saving design of substation buildings in cold regions faces severe challenges. This study systematically conducts a decomposed analysis of the shape coefficient, thermal performance of the building envelope (including external walls, internal walls, roofs, and external windows), and window-to-wall ratio of substation buildings in cold regions, quantifies the degree of influence of each factor, and proposes corresponding energy-saving design strategies. This study took a 110 kV substation in Yuhua District, Shijiazhuang City, Hebei Province, as the research object. A building energy consumption model was established based on DeST (2023) software, and the influence of the building shape coefficient, U-values of the envelope structure (external walls, internal walls, roofs, external windows), and window-to-wall ratio on the building’s cooling and heating loads was analyzed using the numerical simulation and control variable methods. Leveraging a rigorously validated, high-resolution simulation framework, we quantitatively dissect the marginal energy penalties and payoffs of every passive design variable governing fully indoor substations in cold-climate zones. The resultant multidimensional response surfaces are distilled into a deterministic, climate-specific passive energy-saving protocol that secures heating-energy savings of up to 43% without compromising electrical safety or operational accessibility. (1) Reducing the shape coefficient can significantly lower the heat load, and it is recommended to control it at 0.35–0.40; (2) The thermal performance of the envelope structure has a differential effect: the energy-saving effect is optimal when the U-value of external walls is 0.20–0.30 W/(m²·K) and the U-value of roofs is ≤0.25 W/(m²·K). A U-value of 2.4 W/(m²·K) is recommended for external windows, while the internal wall exerts a weak influence; (3) The window-to-wall ratio should be controlled by orientation: east-facing/north-facing ≤ 0.20, south-facing ≤ 0.35, and west-facing ≤ 0.30. Based on the above results, a comprehensive energy-saving strategy of “compact form–high-efficiency envelope–limited window-to-wall ratio” is proposed, which provides theoretical support and technical pathways for the energy-saving design of substation buildings in cold areas. Compared with existing substation buildings, the recommended parameters yield a significant reduction in total life-cycle carbon emissions and hold important practical significance for realizing the “dual carbon” goals (carbon peaking and carbon neutrality) of the power system. Full article

This paper explores the optimal configuration strategies for building-integrated photovoltaic (BIPV) systems in response to the low-carbon transformation needs of semi-outdoor substations, aiming to reconcile the contradiction between photovoltaic (PV) power generation efficiency and indoor environmental control in industrial buildings. Taking a 220 kV semi-outdoor substation of the China Southern Power Grid as a case study, a building energy consumption–PV power generation coupling model was established using EnergyPlus software. The impacts of three PV wall constructions and different building orientations on a transformer room and an air-conditioned living space were analyzed. The results show the EPS-filled PV structure offers superior passive thermal performance and cooling energy savings, making it more suitable for substation applications with high thermal loads. Building orientation plays a decisive role in the net energy performance, with an east–west alignment significantly enhancing the PV module’s output and energy efficiency due to better solar exposure. Based on current component costs, electricity prices, and subsidies, the BIPV system demonstrates a moderate annual return, though the relatively long payback period presents a challenge for widespread adoption. East–west orientations offer better returns due to their higher solar exposure. It is recommended to adopt east–west layouts in EPS-filled PV construction to optimize both energy performance and economic performance, while further shortening the payback period through technical and policy support. This study provides an optimized design path for industrial BIPV module integration and aids power infrastructure’s low-carbon shift. Full article

This study aims to improve the operational efficiency of district heating (DH) systems by introducing a novel control method based on variable flow rate control, without compromising indoor comfort. The novelty of this work lies in its integrated analysis of flow control and substation configurations in DH networks, linking real-world operational strategies with mathematical modeling to improve energy efficiency and infrastructure costs. Using a case study from Omsk, Russia, where supply temperatures and energy demand profiles are traditionally rigid, the proposed approach utilizes operational data, including outdoor temperature, supply/return temperature, and hourly consumption patterns, to optimize heat delivery. A combination of flow rate adjustments, bypass line implementation, and selective control strategies for transitional seasons (fall and spring) was modeled and analyzed. The methodology integrates heat meter data, indoor temperature tracking, and Supervisory Control and Data Acquisition (SCADA)-like system inputs to dynamically adapt supply temperatures while avoiding overheating and reducing distribution losses. The results show a significant reduction in excess heat supply during warm days, with improvements in heat demand prediction accuracy (17.3% average error) compared to standard models. Notably, the optimized configuration led to a 21% reduction in total greenhouse gas (GHG) emissions (including 6537 tons of CO₂ annually), a 55.3% decrease in annualized operational costs, and a positive net present value (NPV) by year nine, with an internal rate of return (IRR) of 25.4%. Compared to conventional scenarios, the proposed solution offers better economic performance without requiring extensive infrastructure upgrades. These findings demonstrate that flexible, data-driven DH control is a feasible and sustainable alternative for aging networks in cold-climate regions. Full article

This study investigates the seismic performance of the V3.0 220 kV standard-designed substation of the Southern Power Grid, located in a high-intensity seismic zone, with a focus on the application of seismic isolation technology. Seismic isolation and structural analysis were conducted and shaking table tests were performed on both isolated and non-isolated structural models. A total of 40 tests were carried out using three levels of ground motion intensity (i.e., 140 gal, 400 gal, and 800 gal) and in three directions (unidirectional, bidirectional, and triaxial). The dynamic characteristics, seismic response, and isolation effectiveness were evaluated. Results indicate that the test models exhibit strong agreement with theoretical and numerical predictions, with an average frequency deviation of 10.98%. The fundamental period of the isolated structure was extended by a factor of 2.33 compared to the non-isolated configuration. As the peak ground acceleration increased, structural frequency decreased, and the period increased. The isolated structure showed a lower first-period growth rate (4.82%) than the non-isolated structure (15.38%). Even under 800 gal excitations, the isolated structure remained within the elastic range. Seismic isolation significantly reduced structural response, with a control effectiveness exceeding 50%, enabling a one-degree reduction in seismic design intensity. A vulnerability analysis based on 200 simulated earthquake cases revealed that the isolated structure exhibited lower failure probabilities across four performance states. At 600 gal PGA, the failure probability in the LS3 state was reduced by 27.8%. These findings confirm the effectiveness and reliability of seismic isolation design for substations in high seismic intensity regions. Full article

This study investigates improving district heating (DH) systems by analyzing the effects of low-temperature operation on network efficiency, heat losses, and indoor temperature stability. A mathematical model is developed to simulate building heat performance under different supply temperatures, substation connection types, and envelope materials. The methodology involves detailed hourly heat load simulations and optimization techniques to assess the impact of temperature flexibility and heat accumulation within buildings. The results reveal that a 10 °C reduction in supply temperature leads to a heat loss decrease of up to 20%, significantly improving system efficiency. Moreover, buildings with higher thermal inertia and indirect substation connections exhibit better resilience to short-term temperature fluctuations, ensuring more stable indoor conditions. The analysis also demonstrates that optimizing temperature control can reduce operational costs by 19%, primarily by minimizing excessive heat supply and utilizing stored thermal energy effectively. Despite slight temperature fluctuations in extreme conditions, the system maintains indoor comfort levels within acceptable limits. This study concludes that transitioning to a lower-temperature DH system is feasible without compromising reliability, provided heat accumulation effects and supply flexibility are carefully managed. These findings offer a replicable approach for improving DH efficiency in networks with diverse building configurations. Full article

Building-energy consumption constitutes a pivotal component of global energy systems, with the heating and cooling loads during the operational phase being particularly significant. Substation building, as nodes in the transmission and transformation network, deserve attention for their building-operating loads. This study investigates heating and cooling loads during substation operation in severe cold climates. By integrating energy consumption simulations with one-factor-at-a-time and orthogonal multivariate analyses, optimization strategies under key influencing factors are systematically explored. The impact analysis identifies the following order of influence magnitude on substation total loads: indoor equipment heat generation, ventilation rate, roof U-value, exterior wall U-value, and window U-value. The heating- and cooling-load characteristics exhibit distinct patterns depending on indoor equipment heat generation. The total building load can be reduced by 61.23 per cent under multifactor optimal de-sign conditions, highlighting the critical role of systemic design coordination. This study provides a case study reference for energy efficient design of heating and cooling loads in substations, especially where significant changes in equipment heat occur, and highlights the importance of controlling indoor heat sources to achieve optimal energy efficiency. Full article

The new passive phase change thermal storage window integrates advanced energy-saving materials and technologies to provide efficient insulation and mechanical properties. It is suitable for green buildings. Through on-site experiments and simulations in summer, autumn, and winter in Jilin City, the cyclic use function of summer insulation and winter heating has been verified. This article establishes a numerical model and compares it with measured data to verify the accuracy of the model. In order to further verify the practicality of the new window, it was applied and tested at the Yichun substation in the cold winter region. The results showed that the new window can significantly reduce energy consumption while increasing indoor temperature. This article used a refined model established by Green Building Saville and Airpak3.0 software to deeply analyze the energy consumption and temperature field distribution of the window, and verified the reliability of numerical analysis in performance prediction. This study not only proves the effectiveness of the new phase change thermal storage window but also provides a new solution for the energy-saving design of green buildings. Full article

The electricity load increases significantly with the development of the economy, which raises the issue of scarce land resources; therefore, the application of whole-indoor urban substations has become more and more extensive. However, both the closed environment of indoor substations and their unreasonable ventilation systems mean that the heat dissipation of the equipment cannot be discharged in time. In this study, a combination of natural and mechanical ventilation systems is developed to solve the problem of high indoor temperatures, and corresponding studies are conducted via both numerical simulation and experimental research. Firstly, the ventilation and heat dissipation problem of the whole-indoor urban substation was investigated using numerical simulation technology, and then the feasibility of the ventilation system was determined. Secondly, the experimental platform (including the heat dissipation equipment and ventilation system) was set up, the heat dissipation of the reactor room was analyzed, and the system was tested experimentally. Afterward, the noise generated by the experimental platform was measured and predicted. Finally, via the numerical simulation analysis, it was found that the ventilation effect would be improved regardless of the heat dissipation and that reducing the outdoor temperature or increasing the ventilation volume would reduce the indoor temperature, which could be controlled within 40 °C. The results of this study provide a reference basis and technical guidance for the engineering projects of ventilation systems for indoor substations, which can effectively solve the problem of excessive indoor temperature caused by heat dissipation from substation equipment while providing a favorable guarantee for sustainable operation of the substation. Full article

This review presents a comprehensive examination of recent advancements and findings related to return-temperature reduction in District Heating (DH) systems, with a focus on enhancing overall system efficiency at end-user sites. The review categorizes and clarifies various return-temperature reduction techniques, emphasizing aspects such as building energy performance, heat emitters, thermostatic radiator valves, and substation units. One shall note that return temperature is not a parameter that can be directly controlled within a DH system; instead, it is influenced indirectly by adjusting various system parameters throughout the design, commissioning, operation, and control phases. Key insights include the direct impact of heat demand on return temperatures; the pivotal role of indoor heating systems in optimizing thermal energy use in relation to heat demand; the significance of thermostatic radiator valves in regulating heat output and maintaining low return temperatures; the advantages of ventilation radiators and add-on fans in enhancing radiator efficiency; the necessity for effective substation operation to improve system cooling capacity; and the critical role of operational control strategies in achieving optimal system performance. These findings underscore the need for integrated approaches in DH system design and operation to achieve lower return temperatures and improve overall system efficiency. Full article

In this study, the influence of variables defining indoor temperature is studied, focusing on operational data and visual and technical inspections rather than the temperature control setpoints and occupancy schedule. This is incorrect because infiltration and insolation are highly variable. This results in lowering the temperature difference between the supply and return lines, overheating some spaces, lowering the indoor temperature in others, and poor hydronic balancing. The novelty lies in studying the actual operating condition of real district heating (DH) systems. The research hypothesis is that internal heat gains along with the infiltration of and variations in outdoor temperature cause daily changes in indoor temperature. These factors seem to be the primary reasons for the variations in supply and return temperature, if the rate of energy loss is not large in new office buildings constructed according to tightened contemporary energy conservation regulations. The saving effect is achieved by allowing the energy to be dumped into building envelopes; thus, the flow rate or supply temperature are varied in a narrower range. Dumping heat by using the storage capacity of building envelopes is suggested. The corrected design approach minimizes energy consumption and increases annual performance (e.g., by 14.1% here). Advantages are achieved by tuning a controller at a DH substation. Full article

Mechanical defects and partial discharge (PD) defects can appear in the indoor switchgear of substations or distribution stations, making the switchgear a safety hazard. However, traditional acoustic methods detect and identify these two types of defects separately, ignoring the general recognition of audio signals. In addition, the process of using testing equipment is complex and costly, which is not conducive to timely testing and widespread application. To assist technicians in making a quick preliminary diagnosis of defect types for switchgear, improve the efficiency of the subsequent overhaul, and reduce the cost of detection, this paper proposes a general audio recognition method for identifying defects in switchgear using a smartphone. Using this method, we can analyze and identify audio and video files recorded with smartphones and synchronously distinguish background noise, mechanical vibration, and PD audio signals, which have good applicability within a certain range. When testing the feasibility of using smartphones to identify three types of audio signal, through characterizing 12 sets of live audio and video files provided by technicians, it was found that there were similarities and differences in these characteristics, such as the autocorrelation, density, and steepness of the waveforms in the time domain, and the band energy and harmonic components of the frequency spectrum, and new combinations of features were proposed as applicable. To compare the recognition performance for features in the time domain, frequency band energy, Mel-frequency cepstral coefficient (MFCC), and this method, feature vectors were input into a support vector machine (SVM) for a recognition test, and the recognition results showed that the the present method had the highest recognition accuracy. Finally, a set of mechanical defects and PD defects were set up for a switchgear, for practical verification, which proved that this method was general and effective. Full article

Space Heating (SH) substations in District Heating-based (DH) systems are typically dimensioned at the design outdoor temperature without accounting for internal and solar heat gains. In residential buildings, the total required DH power typically also includes the need for Domestic Hot Water (DHW). This practice results in oversized substations and high DH design flow rates, which, due to heat gains and building thermal mass utilization in building operation, rarely, if ever, occur. Modern buildings maintain the desired indoor temperature with lower heating power by controlling the SH supply temperature with an outdoor-air-dependent heating curve and heating water flow with room unit thermostats. Applying a dynamic heating control algorithm can be considered one option to reduce the required DH power and optimize the DH network. Another possibility to decrease the needed power is controlling the DH flow by prioritizing DHW production and limiting the DH flow for SH. This study proposed a novel sizing method for the DH substation that quantifies the effects of dynamic control and flow limiters. Building models with detailed hydronic plants, accounting for internal heat gains, and using conventional and dynamic heating controls were developed in the IDA Indoor Climate and Energy simulation tool. The results show a potential DH side power reduction of up to 25%. Full article
