Laminar flow offers significant potential for increasing the energy efficiency of future transport aircraft. At the Cluster of Excellence SE²A—Sustainable and Energy-Efficient Aviation—the laminarization of the wing by means of hybrid laminar flow control (HLFC) is being investigated. The aim is to maintain the boundary layer as laminar for up to 80% of the chord length of the wing. This is achieved by active suction on the leading edge and the rear part of the wing. The suction panels are constructed with a thin micro-perforated skin and a supporting open-cellular core structure. The mechanical requirements for this kind of sandwich structure vary depending on its position of usage. The suction panel on the leading edge must be able to sustain bird strikes, while the suction panel on the rear part must sustain bending loads from the deformation of the wing. The objective of this study was to investigate the energy absorption properties of a triply periodic minimal surface (TPMS) structure that can be used as a bird strike-resistant core in the wing leading edge. To this end, cubic-sheet-based gyroid specimens of different polymeric materials and different geometric dimensions were manufactured using additive manufacturing processes. The specimens were then tested under quasi-static compression and dynamic crushing loading until failure. It was found that the mechanical behavior was dependent on the material, the unit cell size, the relative density, and the loading rate. In general, the weight-specific energy absorption (SEA) at 50% compaction increased with increasing relative density. Polyurethane specimens exhibited an increase in SEA with increasing loading rate, as opposed to the specimens of the other investigated polymers. A smaller unit cell size induced a more consistent energy absorption, due to the higher plateau force. Full article

Hybrid Laminar Flow Control (HLFC) is a promising technology for reducing aircraft drag and, therefore, emissions and fuel consumption. The integration of HLFC systems within the small space of the wing leading edge, together with de-icing and high lift systems, is one of the main challenges of this technology. This challenge can be tackled by using microholes along the outer skin panels to control suction without the need for an internal chamber. However, microperforations modify the mechanical properties of titanium sheets, which bring new challenges in terms of wing manufacturability. These modified properties create uncertainty that must be investigated. The present paper studies the mechanical properties of micro-drilled titanium grade 2 sheets and their modeling using the Finite Element Method (FEM). First, an experimental campaign consisting of tensile and Nakajima tests is conducted. Then, an FEM model is developed to understand the role of the anisotropy in sheet formability. The anisotropy ratios are found by combination of Design of Experiments (DoE) and the Response Surface Method (RSM); these ratios are as follows: 1.050, 1.320, and 0.975 in the directions Y, Z, and XY, respectively. Some mechanical properties are affected by the presence of microholes, especially the elongation and formability that are significantly reduced. The reduction in elongation depends on the orientation: 20% in longitudinal, 17% in diagonal, and 31% in transversal. Full article

Laminar flow offers significant potential for increasing the energy-efficiency of future transport aircraft. The German Cluster of Excellence SE²A is developing a new approach for hybrid laminar flow control. The concept aims to maintain laminar flow up to 80% of the chord length by integrating suction panels at the rear part of the wing, which consist of a thin suction skin and a supporting core structure. This study examines effects of various suction panel configurations on wing mass and load transfer for an all-electric short-range aircraft. Suction panel material, as well as thickness and relative density of the suction panel core are modified in meaningful boundaries. Suction panels made from Ti6Al4V offer the most robust design resulting in a significant increase in wing mass. For the studied configurations, they represent up to 33.8% of the mass of the wingbox. In contrast, panels made from Nylon11CF or PU1000 do not significantly increase the wing mass. However, the use of these materials raises questions about their robustness under operational conditions. The results demonstrate that the choice of material strongly influences the load path within the wing structure. Ti6Al4V suction panels provide sufficient mechanical properties to significantly contribute to load transfer and buckling stiffness. Locally, the share of load transfer attributed to the suction panel exceeds 50%. In contrast, compliant materials such as Nylon11CF or PU1000 are inherently decoupled from load transfer. Unlike the thickness of the suction skin, the relative density of the core structure strongly affects the wrinkling stiffness. However, wrinkling failure did not appear critical for the examined suction panel configurations. In the present study, the mechanical properties of Ti6Al4V cannot fully be exploited. Therefore, compliant suction panels made from Nylon11CF are preferred in order to achieve a lightweight solution, provided that they meet operational requirements. Full article

Surface suction provides an efficient way to delay boundary layer transitions. In order to verify the suction effects and determine the mechanism of suction control in transonic swept wing boundary layers, wind tunnel transition measurements in a hybrid laminar flow control (HLFC) wind tunnel model uses an infrared thermography technique in the Aircraft Research Association (ARA) 2.74 m × 2.44 m low turbulence level transonic wind tunnel. Based on the experimental data of stationary crossflow dominant transitions without and with surface suction in transonic swept wing boundary layers, in this paper, the effects on the receptivity and linear and nonlinear evolution of stationary crossflow vortices have been analyzed with the consideration of curvature. Theoretical analysis agreed with the experimental observations in regard to the transition delay caused by boundary layer suction near the leading-edge region. Full article

In this research sustainable refrigerants are tested as filler gases in Transparent Thermal Insulation (TTI) for the first time. These are compared with pig fat, a readily available material with good thermal inertia that is proposed as an organic phase change material (PCM). The aim of this paper is to compare the thermal behaviour of a Hybrid Air Conditioning System (HACS) with TTI filled with R134a, R1233zd and a pig-fat-based PCM. Numerical simulations using the OPAQUE 3 program and two online platforms are used to evaluate the possible application of TTI and PCM as passive systems. Additionally, three TTI models are used to simulate the heat transfer processes of TTI, PCM and R134a. The velocity of the flow in the air gap is also analysed numerically in both laminar and turbulent states. For the assessment, infrared thermographic imagery is used to measure the temperatures in the HACS, giving values of 46.17 °C by day and 38.05 °C at night. The results show that the heat loss and heat gain in the combination TTI filled with refrigerants and pig-fat-based PCM are between 2.22 and 1.51 W/m². In addition, the HACS was able to keep a small box warm during the night. The flow in the air gap of the HACS can be controlled by installing Ni-Ti wire actuators with a cooling temperature of 23 °C and a heating temperature of 70 °C. The Ni-Ti wire actuators can open and close the dampers at 23 °C and 51 °C, respectively. By installing a 5-watt solar-power fan, the velocity of the flow in the air gap in the HACS can be increased, thus improving the efficiency of the system. In all the experiments, the pig fat proved to be suitable for use in building applications as a non-flammable organic material. Full article

Pulsatory movements appear in a variety of fascinating applications involving periodic flow propagation and control. Pulsing encourages mixing and, as a result, mass and heat exchange with the boundaries. Pulsing also helps to decrease surface fouling by allowing solid particles to migrate. An exact solution of the Navier–Stokes equations for the transport of an incompressible viscous fluid in a channel with arbitrary pressure distribution is described in this study. The flow is defined by two primary parameters: the pulsation parameter, which is determined by the periodic pressure gradient, and the kinetic Reynolds number, which is determined by the pulsation frequency. The purpose of employing hybrid nanofluid (HNF) is to increase the base fluid’s thermal conductivity. We regard Ag and Au as nanoparticles (NPs) and blood as a base fluid for this phenomenon. Broadening this reveals that the consideration of nanoparticles has impressively extended the warm movement at the parcels of both turbulent and laminar frameworks. Attention is paid to the slope of speed, temperature, and voltage. The geometric model is therefore described using a symmetry technique. We developed the governing equation for this problem’s analytical solutions. The velocity and temperature fields solution is given in the form of the Bessel and modified Bessel functions. Graph results show the mathematical benefits of the current limits: for instance, Hartmann number $M$, solid volume part of nanoparticles $\varphi$, Reynolds number $R{e}_{\beta }$, Prandtl number $Pr$, intermittent slob limit, etc. The strain angles introduced in the stress contrast, frictional force, velocity profile, and temperature profile were obtained, and the characteristics of the vortex were investigated. Resources at various boundaries of the perceptual flow are examined. As with the final essence, the smoothest results are analyzed and recorded. It has also been discovered that the velocity may be regulated by the external magnetic field, which affects the temperature profiles and hence the heat transfer, which can be enhanced or lowered by mastering the magnetic field. Full article

The capabilities of nanofluids in boosting the heat transfer features of thermal, electrical and power electronic devices have widely been explored. The increasing need of different industries for heat exchangers with high efficiency and small dimensions has been considered by various researchers and is one of the focus topics of the present study. In the present study, forced convective heat transfer of an ethylene glycol/magnesium oxide-multiwalled carbon nanotube (EG/MgO-MWCNT) hybrid nanofluid (HNF) as single-phase flow in a heat exchanger (HE) with elliptical corrugated tubes is investigated. Three-dimensional multiphase governing equations are solved numerically using the control volume approach and a validated numerical model in good agreement with the literature. The range of Reynolds numbers (Re) 50 < Re < 1000 corresponds to laminar flow. Optimization is carried out by evaluation of various parameters to reach an optimal case with the maximum Nusselt number (Nu) and minimum pressure drop. The use of hybrid nanofluid results in a greater output temperature, a higher Nusselt number, and a bigger pressure drop, according to the findings. A similar pattern is obtained by increasing the volume fraction of nanoparticles. The results indicate that the power of the pump is increased when EG/MgO-MWCNT HNFs are employed. Furthermore, the thermal entropy generation reduces, and the frictional entropy generation increases with the volume fraction of nanoparticles and Re number. The results show that frictional and thermal entropy generations intersect by increasing the Re number, indicating that frictional entropy generation can overcome other effective parameters. This study concludes that the EG/MgO-MWCNT HNF with a volume fraction (VF) of 0.4% is proposed as the best-case scenario among all those considered. Full article

Hybrid laminar flow control or HLFC design is a complex and multi-disciplinary process, which demands a thorough understanding of all aspects from a global systems viewpoint. The objective of the paper is to present a preliminary design of important components of an HLFC system that helps in quick assessment of conceptual system architectures. This is important to evaluate feasibility, system performance, and overall aircraft benefits at early stages of system development. This paper also discusses the various important system requirements and issues concerning the design of active HLFC systems, and the interfaces between various disciplines are presented. It can be emphasized from the study that the future compressor design for the HLFC system should consider the thermal management aspects and additional mass flow requirements from the aerodynamics-structure design optimization and also from water drain system solutions. A method to calculate the accumulated water content inside the plenum chambers is presented, and the effect of a drain hole on the power consumption is studied. A low order thermal management study of the HLFC compressor motor shows a high temperature rise in the windings for very high speed motors for long duration operation and calls for effective cooling solutions. Full article

Numerical simulations are performed to study the outboard airfoil of advanced technology regional aircraft (ATRA) wings with five different variable camber continuous trailing edge flap (VCCTEF) configurations. The computational study aims to improve the aerodynamic efficiency of the airfoil under cruise conditions. The design of outboard airfoil complies with the hybrid laminar flow control design criteria. This work is unique in terms of analysis of the effects of VCCTEF on the ATRA wing’s outboard airfoil during the off-design condition. The Reynolds–Averaged Navier–Stokes equations coupled with the Spalart-Allmaras turbulence model are employed to perform the simulations for the baseline case and VCCTEF configurations. The current computational study is performed at an altitude of 10 km with a cruise Mach number of 0.77 and a Reynolds number of 2.16 × 10⁷. Amongst all five configurations of VCCTEF airfoils studied, a flap having a parabolic profile (VCCTEF 123) configuration shows the maximum airfoil efficiency and resulted in an increase of 6.3% as compared to the baseline airfoil. Full article

A novel numerical model for groundwater flow in karst aquifers is presented. A discrete-continuum (hybrid) approach, in which a three-dimensional matrix flow is coupled with a one-dimensional conduit flow, was used. The laminar flow in the karst matrix is described by a variably saturated flow equation to account for important hydrodynamic effects in both the saturated and unsaturated zones. Turbulent conduit flow for both free surface and pressurized flow conditions was captured via the noninertia wave equation, whereas the coupling of two flow domains was established through an exchange term proportional to head differences. The novel numerical approach based on Fup basis functions and control-volume formulation enabled us to obtain smooth and locally conservative numerical solutions. Due to its similarity to the isogeometric analysis concept (IGA), we labeled it as control-volume isogeometric analysis (CV-IGA). Since realistic verification of the karst flow models is an extremely difficult task, the particular contribution of this work is the construction of a specially designed 3D physical model ( dimensions: 5.66 × 2.95 × 2.00 m) in order to verify the developed numerical model under controlled laboratory conditions. Heterogeneous porous material was used to simulate the karst matrix, and perforated pipes were used as karst conduits. The model was able to capture many flow characteristics, such as the interaction between the matrix and conduit, rainfall infiltration through the unsaturated zone, direct recharge through sinkholes, and both free surface and pressurized flow in conduits. Two different flow experiments are presented, and comparison with numerical results confirmed the validity of the developed karst flow model under complex laboratory conditions. Full article

The Energy System Transition in Aviation research project of the Aeronautics Research Center Niedersachsen (NFL) searches for potentially game-changing technologies to reduce the carbon footprint of aviation by promoting and enabling new propulsion and drag reduction technologies. The greatest potential for aerodynamic drag reduction is seen in laminar flow control by boundary layer suction. While most of the research so far has been on partial laminarization by application of Natural Laminar Flow (NLF) and Hybrid Laminar Flow Control (HLFC) to wings, complete laminarization of wings, tails and fuselages promises much higher gains. The potential drag reduction and suction requirements, including the necessary compressor power, are calculated on component level using a flow solver with viscid/inviscid coupling and a 3D Reynolds-Averaged Navier-Stokes (RANS) solver. The effect on total aircraft drag is estimated for a state-of-the-art mid-range aircraft configuration using preliminary aircraft design methods, showing that total cruise drag can be halved compared to today’s turbulent aircraft. Full article

This paper challenges the production of the protein nanoparticles using the conjugation of Ni²⁺ complexed nitrilotriacetic acid end-functionalized polystyrene (Ni-NTA-PS) and histidine tagged GFP (His-GFP) hybrid. The microfluidic synthesis of the protein nanoparticle with the advantages of a uniform size, a fast reaction, and a precise control of preparation conditions is examined. The self-assembly occurs on the interfacial surface of the multi-laminated laminar flow stably formed in the microchannel. The clogging of the produced protein nanoparticles on the channel surface is solved by adding a retarding inlet channel. The size and shape of the produced protein nanoparticles are measured by the analysis of transmission electron microscopy (TEM) and scanning electron microscope (SEM) images, and the attachment of the protein is visualized with a green fluorescent image. Future research includes the encapsulation of vaccines and the coating of antigens on the protein surface. Full article
