Search Results (122)

Hierarchical surface structuring is a critical aspect of advanced materials design, impacting fields ranging from optics to biomimetics. Among several laser-based methods for complex structuring of photo-responsive surfaces, the broadband vectorial interferometry proposed here offers unique performances. Such a method leverages a polychromatic laser source, an unconventional choice for holographic encoding, to achieve deterministic multiscale surface structuring through interference light patterning. Azopolymer films are used as photosensitive substrates. By exploring the interaction between optomechanical stress modulations at different spatial periodicities induced within the polymer bulk, we demonstrate the emergence of hierarchical Fourier surfaces composed of multiple deterministic levels. These structures range from sub-micrometer to tens of micrometers scale, exhibiting a high degree of control over their morphology. The experimental findings reveal that the optical encoding scheme significantly influences the resulting topographies. The polarization light patterns lead to more regular and symmetric hierarchical structures compared to those obtained with intensity patterns, underscoring the role of vectorial light properties in controlling surface morphologies. The proposed method is fully scalable, compatible with more complex recording schemes (including multi-beam interference), and it is applicable to a wide range of advanced technological fields. These include optics and photonics (diffractive elements, polarimetric devices), biomimetic surfaces, topographical design, information encoding, and anti-counterfeiting, offering a rapid, reliable, and versatile strategy for high-precision surface structuring at a submicrometric scale. Full article

Shaping or splitting of a Gaussian beam is often desired to optimise laser–material interactions, improving throughput and quality. This can be achieved holographically using liquid crystal-on-silicon spatial light modulators (LC-SLMs). Until recently, maximum exposure has been limited to circa 120 W average power with a Gaussian profile, restricting potential applications due to the non-linear (NL) phase response of the liquid crystal above this threshold. In this study, we present experimental tests of a new SLM device, demonstrating high first-order diffraction efficiency of η = 0.98 ± 0.01 at 300 W average power and a phase range Δφ > 2π at P = 383 W, an exceptional performance. The numerically calculated device temperature response with power closely matches that measured, supporting the higher power-handling capability. Surface modification of mild steel and molybdenum up to P = 350 W exposure is demonstrated when employing a single-mode (SM) fibre laser source. Exposure on mild steel with a vortex beam (m = +6) displays numerous ringed regions with varying micro-structures and clear elemental separation created by the radial heat flow. On molybdenum, with multi-spot Gaussian exposure, both MoO₃ films and recrystallisation rings were observed, exposure-dependent. The step change in device capability will accelerate new applications for this LC-SLM in both subtractive and additive manufacturing. Full article

Holographic optical elements (HOEs) are promising for solar energy collection due to their advantages of lightweight and high efficiency, but the narrow reconstruction of their angular and spectral widths limits their application. This paper proposes a novel holographic lens array solar collector (HLASC), which can collect light from a large angle range with an expanded spectrum. The large acceptance angle is achieved by a holographic lens array with a large relative aperture. To expand the collection spectral width within a large incident angle, the collection spectrum is spatially allocated within a single lens range. The methods of single-wavelength recording and multi-wavelength reconstruction contribute to the flexible design and simple fabrication of the HLASC. The optical experiment demonstrates that the HLASC can collect the entire visible spectrum in a range greater than 54°. We believe that an expanded reconstruction angle and wavelength will promote the widespread application of HOEs in solar energy collection. Full article

Modern SNARKs are constructed using polynomial Interactive Oracle Proofs (IOPs) and polynomial commitments. In this work, we introduce a novel polynomial holographic IOP for the $\mathcal{NP}$-Complete language Rank-1 Constraint System (R1CS), where holographic IOP means that the proof system supports preprocessing. Our construction achieves linear-time proving, logarithmic-time verification, and constant query complexity. For an R1CS instance with size O(N) over a sufficiently large finite field, the prover’s time is O(N), the verifier’s time is O(log N), and the query complexity is O(1). By combining our polynomial holographic IOP with the recent polynomial commitment scheme Orion, we obtain a transparent SNARK for R1CS with remarkable performance: the prover’s time is O(N), the verifier’s time is O(log²N), and the proof size is O(log²N). The core technique in our construction is the classical SumCheck protocol, which enables us to efficiently check whether an n-variate polynomial sums to a specific value on a given domain, such as {0, 1}ⁿ. Additionally, we showcase how to achieve holography from the lookup protocol, which allows us to efficiently verify that all elements in a vector are contained in another vector. We introduce a new polynomial IOP for the lookup relation with a linear-time prover. Full article

There is a growing field that is devoted to developing inexpensive microscopes and measurement devices by leveraging low-cost commercial parts that can be controlled using smartphones or embedded devices, such as Arduino and Raspbery Pi. Examples include the use of Blu-ray optical heads like the PHR-803T to perform cytometry, spinning disc microscopy, and lensless holographic microscopy. The modular or disposable nature of these devices means that they can also be used in contaminating and degrading environments, including radioactive environments, where replacement of device elements can be expensive. This paper presents the development and operation of a confocal microscope that uses the PHR-803T optical device in a Blu-ray reader for both imaging and detection of temperature variations with between 1.5 and 15 µm resolution. The benefits of using a PHR-803T confocal system include its relatively inexpensive design and the accessibility of the components that are used in its construction. The design of this scanning confocal thermal microscope (SCoT) was optimized based on cost, modularity, portability, spatial resolution, and ease of manufacturability using common tools (e.g., drill press, 3D printer). This paper demonstrated the ability to resolve microscale features such as synthetic spider silk and measure thermal waves in stainless steel using a system requiring <USD 1000 in material costs. Full article

At present, most near-eye display devices adopt flat substrates, which have problems such as limited field of view (FOV) and bulky shape, while the curved structure is expected to expand the FOV with appropriate volume. In this paper, we propose a curved holographic augmented reality (AR) near-eye display system based on holographic optical element (HOE) with the ability to expand the FOV. The system includes a display source and a HOE with curved substrate. We analyze the system by exploiting the diffraction theory between plane and curved surface, and a layered and weighted FOV optimization method using particle swarm optimization algorithm is proposed to realize the optimization of the phase of freeform HOE. Numerical and experimental results show that the proposed curved holographic near-eye display system can realize cylindrical AR display and expand the FOV of the system. It is expected to be applied to the holographic AR near-eye display in the future. Full article

Due to their ability to reversibly isomerize under the influence of external stimuli, spiropyrans represent the most interesting class of organic photochromic molecules. The photochromic properties of the isomeric forms of spiropyrans differ significantly from each other, which makes it possible to use these photochromes as sensors, optoelectronic and holographic devices, memory elements, etc. Also, an undoubted advantage of spiropyrans compared to other classes of organic photochromes is the relative ease of their preparation and chemical transformation. At the same time, modification of the structure of spiropyrans by introducing various functional groups opens up great synthetic possibilities for obtaining new photochromic molecules with various spectral-kinetic characteristics. In the development of research aimed at expanding the boundaries of the use of spirophotochromic compounds, in order to obtain new light-controlled materials with different characteristics, as well as to study the influence of functional groups in the spirophotochromic molecule on the spectral and photochromic properties, we have synthesized a new spiropyran. In this work, we synthesized a new salt of photochromic spiropyran containing various functional groups (–CHO, –NO₂, –OCH₃, –(CH₂)₅N(CH₃)₂*HBr), capable of reversibly responding to external influences. Photoinduced transformations and the spectral and kinetic characteristics of the synthesized compound were studied. Full article

Phase carries crucial information about the light propagation process, and the visualization and quantitative measurement of phase have important applications, ranging from ultra-precision metrology to biomedical imaging. Traditional phase measurement techniques typically require large and complex optical systems, limiting their applicability in various scenarios. Optical metasurfaces, as flat optical elements, offer a novel approach to phase measurement by manipulating light at the nanoscale through light-matter interactions. Metasurfaces are advantageous due to their lightweight, multifunctional, and easy-to-integrate nature, providing new possibilities for simplifying traditional phase measurement methods. This review categorizes phase measurement techniques into quantitative and non-quantitative methods and reviews the advancements in metasurface-based phase measurement technologies. Detailed discussions are provided on several methods, including vortex phase contrast, holographic interferometry, shearing interferometry, the Transport of Intensity Equation (TIE), and wavefront sensing. The advantages and limitations of metasurfaces in phase measurement are highlighted, and future research directions are explored. Full article

Volume-phase holographic gratings are suitable for use in greenhouse gas detection imaging spectrometers, enabling the detection instruments to achieve high spectral resolution, high signal-to-noise ratios, and high operational efficiency. However, when utilized in the infrared wavelength band with high dispersion requirements, gratings struggle to meet the demands for low polarization sensitivity due to changes in diffraction performance caused by phase delays in the incidence of light waves with distinct polarization states, and current methods for designing bulk-phase holographic gratings require a large number of calculations that complicate the balance of diffraction properties. To overcome this problem, a design method for transmissive bulk-phase holographic gratings is proposed in this study. The proposed method combines two diffraction theories (namely, Kogelnik coupled-wave theory and rigorous coupled-wave theory) and establishes a parameter optimization sequence based on the influence of design parameters on diffraction characteristics. Kogelnik coupled-wave theory is employed to establish the initial Bragg angle range, ensuring that the diffraction efficiency and phase delay of the grating thickness curve meet the requirements for incident light waves in various polarization states. Utilizing rigorous coupled-wave theory, we optimize grating settings based on criteria such as a center wavelength diffraction efficiency greater than 95%, polarization sensitivity less than 10%, maximum bandwidth, and spectral diffraction efficiency exceeding 80%. The ideal grating parameters are ultimately determined, and the manufacturing tolerances for various grating parameters are analyzed. The design results show that the grating stripe frequency is 1067 lines per millimeter, and the diffraction efficiencies of TE and TM waves are 96% and 99.89%, respectively. The diffraction efficiency of unpolarized light is more than 88% over the whole spectral range with an average efficiency of 94.49%, an effective bandwidth of 32 nm, and a polarization sensitivity of less than 7%. These characteristics meet the performance requirements for dispersive elements based on greenhouse gas detection, the spectral resolution of the detection instrument is up to 0.1 nm, and the signal-to-noise ratio and working efficiency are improved by increasing the transmittance of the instrument. Full article

Building-integrated photovoltaic (BIPV) glazing systems with intelligent window technologies enhance building energy efficiency by generating electricity and managing daylighting. This study explores advanced BIPV glazing, focusing on building-integrated concentrating photovoltaic (BICPV) systems. BICPV integrates concentrating optics, such as holographic films, luminescent solar concentrators (LSC), Fresnel lenses, and compound parabolic concentrators (CPCs), with photovoltaic cells. Notable results include achieving 17.9% electrical efficiency using cylindrical holographic optical elements and crystalline silicon cells at a 3.5× concentration ratio. Dielectric CPCs showed 97.7% angular acceptance efficiency in simulations and 94.4% experimentally, increasing short-circuit current and maximum power by 87.0% and 96.6%, respectively, across 0° to 85° incidence angles. Thermochromic hydrogels and thermotropic smart glazing systems demonstrated significant HVAC energy savings. Large-area 1 m² PNIPAm-based thermotropic window outperformed conventional double glazing in Singapore. The thermotropic parallel slat transparent insulation material (TT PS-TIM) improved energy efficiency by up to 21.5% compared to double glazing in climates like London and Rome. Emerging dynamic glazing technologies combine BIPV with smart functions, balancing transparency and efficiency. Photothermally controlled methylammonium lead iodide PV windows achieved 68% visible light transmission, 11.3% power conversion efficiency, and quick switching in under 3 min. Polymer-dispersed liquid crystal smart windows provided 41–68% visible transmission with self-powered operation. Full article

Augmented reality (AR) technology has been widely applied across a variety of fields, with head-up displays (HUDs) being one of its prominent uses, offering immersive three-dimensional (3D) experiences and interaction with digital content and the real world. AR-HUDs face challenges such as limited field of view (FOV), small eye-box, bulky form factor, and absence of accommodation cue, often compromising trade-offs between these factors. Recently, optical waveguide based on pupil replication process has attracted increasing attention as an optical element for its compact form factor and exit-pupil expansion. Despite these advantages, current waveguide displays struggle to integrate visual information with real scenes because they do not produce accommodation-capable virtual content. In this paper, we introduce a lensless accommodation-capable holographic system based on a waveguide. Our system aims to expand the eye-box at the optimal viewing distance that provides the maximum FOV. We devised a formalized CGH algorithm based on bold assumption and two constraints and successfully performed numerical observation simulation. In optical experiments, accommodation-capable images with a maximum horizontal FOV of 7.0 degrees were successfully observed within an expanded eye-box of 9.18 mm at an optimal observation distance of 112 mm. Full article

Photopolymers, especially acrylate-based ones with low cost and simple preparation, are promising materials for high-efficiency holographic gratings. However, it is still challenging to achieve high-performance gratings, due to the influences of many factors. In this work, we found that the dark reaction plays a critical role. The effect of the dark reaction on the optical properties of holographic gratings was investigated. Experimental results reveal that the diffraction efficiency of the gratings can be improved by a factor of three by involving the dark reaction process, and the highest diffraction efficiency for gratings can reach 97.8% after optimization. Therefore, the dark reaction can greatly enhance the optical performance of acrylate-based holographic gratings and other optical elements, thus holding great potential for many applications. Full article

Holographic lenses (HLs) are part of holographic optical elements (HOE), and are being applied to concentrate solar energy on a focal point or focal line. In this way, the concentrated energy can be converted into electrical or thermal energy by means of a photovoltaic cell or a thermal absorber tube. HLs are able to passively track the apparent motion of the sun with a high acceptance angle, allowing tracking motors to be replaced, thus reducing the cost of support structures. This article focuses on a review of the materials used in the recording of a holographic lens (HL) or multiple HLs in photovoltaic and/or concentrating solar collectors. This review shows that the use of photopolymers for the recording of HLs enables high-performance efficiency in physical systems designed for energy transformation, and presents some important elements to be taken into account for future designs, especially those related to the characteristics of the HL recording materials. Finally, the article outlines future recommendations, emphasizing potential research opportunities and challenges for researchers entering the field of HL-based concentrating solar photovoltaic and/or concentrating solar thermal collectors. Full article

This paper has proposed a full-color holography based on the space division method to provide a new solution for three-dimensional color holographic display. The hologram is divided into three different regions for the R, G, and B trichromatic hologram components, which will be designed separately at the corresponding positions. The projection images at different projection depths are preprocessed to meet dimension matching and position matching conditions. Different color images are reconstructed on a single plane and 19 planes in simulations and experiments, respectively, which verify the feasibility of the method. The designed phase-only holograms were fabricated on the silica substrate to obtain the diffraction optical element (DOE). Expect for one DOE, three lasers, and one CCD, no additional optical components are required to prompt a compact and simple experimental setup, which is expected to be used to realize full-color display. Full article

The paper proposes an equivalent optical scheme of an in-line digital holographic system for particle recording and a mathematical model that establishes a one-to-one correspondence between the dimensional and spatial parameters of a digital holographic image of a particle and the imaged particle itself. The values of the model coefficients used to determine the real size and longitudinal coordinate of a particle according to its holographic image are found by calibration. The model was tested in field and laboratory conditions to calibrate a submersible digital holographic camera designed to study plankton in its habitat. It was shown that four calibration measurements are sufficient enough to determine the model coefficients, and the developed design of the submersible digital holographic camera makes it possible to perform these measurements during the recording of each hologram. In addition, this neither requires data on the refractive index of the medium with particles nor on the parameters of the optical elements of the scheme. The paper presents the results of marine experiments in the Kara Sea and the Laptev Sea, as well as in fresh water in laboratory conditions and in Lake Baikal. The error in measuring the particle size in seawater without the use of the model is 53.8%, while the error in determining their longitudinal coordinates is 79.3%. In fresh water, the same errors were 59% and 54.5%, respectively. The error in determining the position of a particle with the use of the designed mathematical model does not exceed 1.5%, and the error in determining the size is 4.8%. The model is sensitive to changes in the optical properties of the medium, so it is necessary to perform calibration in each water area, and one calibration is quite sufficient within the same water area. At the same time, the developed design of the submersible holographic camera allows, if necessary, calibration at each holographing of the medium volume with particles. Full article
