This manuscript proposes a fast transient simulation method based on PEEC to model overvoltage caused by spark gap and disconnecting switch operations in UHV series compensation (FSC). It proposes a simulation method based on the Partial Element Equivalent Circuit (PEEC) for modeling the fast transient processes associated with the operation of primary equipment in UHV FSC. Initially, a multi-conductor system model for both primary and secondary equipment on the cascade platform is developed. Then, the lumped components′ modeling of primary equipment and secondary equipment is added on the basis of multi-conductor model. Through simulation, the rapid transient overvoltage of primary equipment and the electromagnetic disturbance of the secondary system are analyzed. The simulation results provide insights into the distribution of fast transient overvoltage and the transient electromagnetic disturbance along the bus, from the low-voltage bus to the high-potential platform, under various primary equipment operating conditions. These findings provide a basis for theoretical analysis of the layout of sensor devices on platform and the design of electromagnetic shielding for interference-prone systems on platform. Full article

In complex electromagnetic environments, such as substations, converter stations in power systems, and the compartments of aircraft, trains, and automobiles, electromagnetic immunity testing is crucial. It requires that the electric field sensor has features such as a large dynamic measurement range (amplitude from hundreds of V/m to tens of kV/m), a fast response speed (response time in the order of nanoseconds or sub-nanoseconds), a wide test bandwidth (DC to 1 GHz even above), miniaturization, and robustness to strong electromagnetic interference. This paper introduces a multi-channel, ultra-wideband transient electric field measurement system. The system’s analog bandwidth covers the spectrum from DC and a power frequency of 50 Hz to partial discharge signals, from DC to 1.65 GHz, with a storage depth of 2 GB (expandable). It overcomes issues related to the instability, insufficient bandwidth, and lack of accuracy of optical fibers in analog signal transmission by using front-end digital sampling based on field-programmable gate array (FPGA) technology and transmitting digital signals via optical fibers. This approach is effectively applicable to measurements in strong electromagnetic environments. Additionally, the system can simultaneously access four channels of signals, with synchronization timing reaching 300 picoseconds, can be connected to voltage and current sensors simultaneously, and the front-end sensor can be flexibly replaced. The performance of the system is verified by means of a disconnect switch operation and steady state test in an HVDC converter station. It is effectively applicable in scenarios such as the online monitoring of transient electromagnetic environments in high-voltage power equipment, fault diagnosis, and the precise localization of radiation sources such as partial discharge or intentional electromagnetic interference (IEMI). Full article

Virtual synchronous generator (VSG) control, which can provide inertia output, damp power oscillations, and offer frequency and voltage support to power grids, has become a growing trend in the control field of wind power generation. As a new technology, there are still challenges that VSG control has not solved well, such as transient overvoltage suppression. A kind of transient overvoltage, which often occurs during the commutation failures of HVDC transmission systems, will trigger a mass of wind turbine generators (WTGs) disconnecting from grids. To reduce the grid-disconnection risk of the virtual synchronous generator control-based doubly fed induction generators (VSG-DFIGs), this paper first analyzes the mechanism of the automatic voltage regulation (AVR) control usually employed by VSG-DFIGs, then proposes measures to suppress the transient overvoltage. To solve the problem of the reactive power response lag issued by VSG-DFIGs, which will further aggravate the transient overvoltage in continuous low and high voltage faults, the time constant of the AVR control is switched. To fully exploit the potential of the DFIGs’ reactive power support, the droop coefficient of the AVR control is switched during the abnormal voltage stages. The switched droop coefficient will change the rotor excitation current magnitude, thus adjusting the internal potential of a DFIG, finally better supporting or suppressing the terminal voltage during the low or high voltage periods. Simulation results based on the DIgSILENT/PowerFactory platform demonstrate that the proposed method can effectively suppress the transient overvoltage that occurs in continuous low and high voltage events caused by the commutation failures of HVDC transmission systems, reducing the number of WTGs disconnecting from the grids. Full article

Renewable energy sources have a multifaceted impact on power grids, ranging from the reliability and quality of electricity to the selective impact on equipment. While renewables used to be distributed in distribution networks, now their capacity is commensurate with thermal power plants and their impact on the grid should not be underestimated. According to the statistics on the interruption of the bulk electric networks, one of the main reasons for emergency shutdowns of extra high-voltage power lines are single-phase short circuits. The problem of mathematical modeling of the limit modes in terms of static stability is very relevant to the design and operation of electric power systems (EPS). Calculations of limit modes have both an independent value and a component of other electrical engineering tasks related to ensuring the required level of reliability and cost-effectiveness of the operation of the united PS. Despite the great degree of development of issues of planning and control of electric modes, system accidents associated with unacceptable loads of network elements occur in the Ukrainian energy industry. Non-phase modes regularly occur in electric power systems, which can lead to an unacceptable load of intersystem network elements, which imposes significant restrictions on their throughput. Single-phase short circuits are more than 95% of other damage that occurs in the line. The use of single-phase auto reclose on the transmission lines allows disconnecting only the damaged phase for a short period of time and not the entire transmission line. This action preserves the transit of electricity along the line and prevents the violation of the stability of parallel operation. To achieve this, the current-free pause of the single-phase auto reclose should last as short as possible. On the other hand, an important task to be solved when using single-phase auto reclose is to choose the minimum duration of the current-free pause necessary for its success. The problem studied in this paper deals with the safety and correct operation of transmission lines (TS) of the Ukrainian bulk power system in special conditions (not predictable, changing due to frequent attacks). For a quickly changing configuration, the power grid uses switches, and in the case of ultra-high voltage, the TS needs to solve the problem of secondary arc currents and recovering stresses in the place of arc burning after its extinction. One of the methods of reducing secondary arc currents and recovering stresses in the place of arc burning after its extinction is the implementation of single-phase automatic reclosing (SPAR). The main theoretical result of the paper is a proposed mathematical model of a compensated power transmission line based on the use of matrix n-poles, which makes it possible to model in detail stationary power transmission modes, including the SPAR mode. The proposed mathematical model of three-phase power transmission has been created using phase coordinates and can be used for the analysis of complex asymmetric modes. The main practical result of the paper is physically interpreted simplified models of three-phase TS, which can be used for the study of resonant overvoltages and currents of the feeding arc in non-full-phase circuit SPAR. The conclusion that can be drawn from the obtained results points out which line lengths must take into account the influence of longitudinal asymmetry when choosing the inductive resistance, i.e., take into account the dependence of the mode parameters on the location of the damaged phase. The observed results show that the largest values of the multiplicity of overvoltages will take place in phase B. The novelty of the work is the developed technique that makes it possible to determine in advance, depending on the disconnected phase of the line, the values of the primary conductivities of the STC (static thyristor compensators) and the corresponding angles of control of the thyristor switches, which satisfy almost complete compensation of the secondary arc at any point of the line in the specific condition (hard) of the bulk power system operation. Full article

The presence of high short-circuit currents (200–300 kA) in autonomous and generator power systems of low and medium voltage classes, causing a decrease in the switching resource of switching facilities, necessitates the search for ways of limiting the current. The paper proposes a solution to this problem: a semiconductor current-limiting device based on a DC chopper, a DC-to-DC converter. This devices’ features are its low dimensions and losses during typical operation. Semiconductor elements can be arranged quite compactly due to the lack of radiators for cooling, since the cooling process—taking into account the short duration of the current limitation process—is not efficient. The choice of semiconductor devices takes into account the short duration of the current load, as a result of which the temperature of the semiconductor structure does not exceed its permissible value. This paper presents a method for calculating the parameters of semiconductor devices, taking into account the current load as well as adjusting the magnitude of current limitation to a value that can be disconnected by switching devices. The short-term mode of operation of the power semiconductor device with current regulated by the frequency and duty cycle of its operation makes it possible to facilitate the required current limitation in the circuit for the subsequent fault clearance with a typical electrical device. The problem of overcurrent of one of the elements of the limiter is noted, which requires special attention to ensure that the semiconductor device is not overheated. This paper also presents the principle of current limitation, summarizes the results of experimental studies, and analyzes the presented capabilities of a semiconductor current limiter. Full article

Technology in electric vehicles has increased substantially in the past decade. Moreover, it is projected to grow at record highs in the coming years since these vehicles are needed to reduce the contamination related to the transportation sector. One of the essential elements of an electric car is its battery, due to its cost. Batteries comprise parallel and series-connected cell arrangements to meet the power system requirements. Therefore, they require a cell equalizer circuit to preserve their safety and correct operation. These circuits keep a specific variable of all cells, such as the voltage, within a particular range. Within cell equalizers, capacitor-based ones are very common as they have many desirable characteristics of the ideal equalizer. In this work, an equalizer based on the switched-capacitor is proposed. A switch is added to this technology that allows the disconnection of the capacitor from the circuit. In this way, an equalization process can be achieved without excess transfers. Therefore, a more efficient and faster process can be completed. In addition, it allows another equalization variable to be used, such as the state of charge. This paper studies the operation, power design, and controller design of the converter. Moreover, the proposed equalizer was compared to other capacitor-based architectures. Finally, simulation results were presented to validate the theoretical analysis. Full article

Residual current devices (RCDs) are devices that can provide very good protection measures against electric shock. Yet, under certain circumstances, they can cause unnecessary and unexpected switching off of power in the protected circuits. The main component that determines the properties of an RCD is the summation current transformer. In recently produced RCDs, whose operation is independent from the installation voltage, the summation transformer, apart from detection of the residual current, has yet another task: it must also provide an appropriate energy value to the electromagnetic release in order to carry out mechanical disconnection of the contacts. In this type of RCD, the core of the summation transformer should be made of magnetic material with very high permeability and appropriate geometric dimensions. Manufacturers of RCDs, in order to reduce production costs and to promote miniaturization of the devices, use cores for summation transformers made of amorphous or nanocrystalline materials quite often. In such RCD designs, the impedance-matching circuit is used in the secondary circuit of the summation transformer to ensure proper sensitivity to the residual current. The paper describes the impact of using additional impedance-matching elements in the secondary circuit on the RCD break time. The paper presents the results of tests and measurements of the RCD break times of various internal structures. Full article

Renewable energy sources have power quality and stability issues despite having vast benefits when integrated with the utility grid. High currents and voltages are introduced during the disconnection or injection from or into the power system. Due to excessive inverter switching frequencies, distorted voltage waveforms and high distortions in the output current may be observed. Hence, advancing intelligent and robust optimization techniques along with advanced controllers is the need of the hour. Therefore, this article presents an improved arithmetic optimization algorithm and an offset hysteresis band current controller. Conventional hysteresis band current controllers (CHCCs) offer substantial advantages such as fast dynamic response, over-current, and robustness in response to impedance variations, but they suffer from variable switching frequency. The offset hysteresis band current controller utilizes the zero-crossing time of the current error for calculating the lower/upper hysteresis bands after the measurement of half of the error current period. The duty cycle and hysteresis bands are considered as design variables and are optimally designed by minimizing the current error and the switching frequency. It is observed that the proposed controller yields a minimum average switching frequency of 2.33 kHz and minimum average switching losses of 9.07 W in comparison to other suggested controllers. Results are validated using MATLAB/Simulink environment followed by real-time simulator OPAL-RT 4510. Full article

A novel modular Transformerless, Self-balanced, Static Synchronous Series Compensator (TSB-SSSC) capable of delivering ultra-high current, with the objective of dynamically balancing the impedance of the transmission power grid, is proposed. Balancing transmission lines is crucial in power optimization and delivery because it increases the power transfer capability without building new power lines. The transformerless SSSC needs to support and control the line current from a few hundred to several thousand amperes. This paper presents how the ultra-high current architecture of the TSB-SSSC is achieved by operating multiple converters with self-balancing capabilities in parallel. The mechanism of self-balancing is based on the intrinsic physics of the capacitor and is enabled by a passive network of capacitor equalizers that keep the capacitor voltage equal during switching disconnection. The second self-balancing system consists of an inductive component that balances possible differences among delay switching caused by the aging of the multiple IGBTs from the different converters that form the SSSC. This work presents the analytical set of equations that describes the system and a complete set of simulations where the effectiveness of self-balancing paralleling topology is shown. Full article

This paper addresses one of the current areas of interest in electrical engineering, which is controlled switching of high voltage circuit breakers. During their operation, the problem of controlled switching of high voltage circuit breakers in commutation regimes was studied. Several types of switching were analyzed, considered representative of the transient regime, depending on the type of load, on the defect that may occur on the power supply lines, as well as depending on the position of this defect (near or far). The study carried out in the paper includes simulations of the controlled connection/disconnection operations in a transient regime, assuming the existence of different kinds of defects. To perform the study and simulations in the transient regime, a model, implemented in Matlab, was used for a time interval located around the origin of the time axis. The study included the dependence of the SF6 circuit breaker switching process on the following parameters: the DC voltage supply, ambient temperature and oil pressure in the circuit breaker actuator. The validity of the theory presented in this paper, in addition to being validated by simulations, is proven by the fact that the protection system currently in use at the power station of an 800 MW power plant, at the 400 kV power line, is based on the principles presented in this paper. The theory presented in the paper has been implemented in industry for nearly two years, and the results confirm that the theory presented in the paper is fully applicable in high voltage power stations. Full article

This paper focuses on the analysis of the stability of the GW17 high-voltage disconnecting switch drive system. Firstly, the optimization model of the disconnector is established, and the simulation analysis is carried out by ADAMS (Automatic Dynamic Analysis of Mechanical Systems) and the simulation results are verified by experiments. Afterwards, ADAMS optimization design and particle swarm optimization algorithm (PSO) are used to optimize the drive system of the disconnector, and the results are verified on the experimental platform. After optimization, the space rod is reduced by 15 mm, the minimum corner angle of the lower conductive rod is reduced by 71.0%, the minimum folding arm angle is reduced by 88.7% and the maximum force of the ball pair is reduced by 35.7%, which realizes the lightweight of the rod, reduces the wear of the ball pair, and improves the stability of the equipment operation. Full article

Although various topologies of multi-terminal high voltage direct current (MT-HVdc) transmission systems are available in the literature, most of them are prone to loss of flexibility, reliability, stability, and redundancy in the events of grid contingencies. In this research, two new wind farms and substation ring topology (2WF-SSRT) are designed and proposed to address the aforementioned shortcomings. The objective of this paper is to investigate MT-HVdc grid topologies for integrating large offshore wind farms with an emphasis on power loss in the event of a dc grid fault or mainland alternating current (ac)grid abnormality. Standards and control of voltage source converter (VSC) based MT-HVdc grids are defined and discussed. High voltage dc switch-gear and dc circuit topologies are appraised based on the necessity of dc cables, HVdc circuit breakers, and extra offshore platforms. In this paper, the proposed topology is analyzed and compared with the formers for number and ratings of offshore substations, dc breakers, ultra-fast mechanical actuators, dc circuits, cost, flexibility, utilization, and redundancy of HVdc links. Coordinated operation of various topologies is assessed and compared with respect to the designed control scheme via a developed EMTDC/PSCAD simulation platform considering three fault scenarios: dc fault on transmission link connecting the wind farm to mainland power converters, dc fault within substation ring of VSC-HVdc stations, and ultimate disconnection of grid side VSC station. Results show that 2WF-SSRT is a promising topology for future MT-HVdc grids. Full article

Vertical-cavity surface-emitting lasers (VCSELs) are commonly used in high-speed optical communication and 3D sensing applications. Both of these applications require high switching frequency and a short rise time of the VCSEL current. The parasitic inductance of the wire (connecting the driver with VCSEL) makes it challenging to achieve a short rise time, which often incur increased supply voltage and excessive power consumption. This paper utilizes a momentary boosting in supply voltage to overcome the parasitic inductance of the wire with minimal power overhead. The proposed technique uses a precalculated boosting capacitance to produce negative voltage for common-anode VCSELs. The boosting capacitance provides the required amount of charge during the rising transition and automatically disconnects itself in steady-state. Circuit simulations reveal up to three times shorter rise time at the negligible cost of less than 10% power overhead. Full article

This paper presents an analysis of a new application of different direct matrix converter topologies used as power interfaces in AC, DC, and hybrid microgrids, with model predictive current control. Such a combination of a converter and control strategy leads to a high power quality microgrid voltage, even with a low power quality main grid voltage and even during the connection and disconnection of a variety of loads and generation sources to the microgrids. These robust systems are suitable for applications in which sensitive loads are to be supplied and these loads are connected close to distributed-generation sources with inherent intermittent behavior. The authors also propose the use of new direct matrix converter configurations with a reduced number of switches in order to achieve reduced cost, reduced failure rate, and higher reliability, which are very desirable in microgrids. Finally, the authors also introduce new hybrid direct matrix converter topologies that provide interesting options for the islanded operation of the microgrids with the use of a battery system. In other words, the proposed hybrid direct matrix converters result in flexible hybrid microgrid configurations integrating DC and AC devices with high power quality and high power supply reliability. Full article

Despite the vast benefits of integrating renewable energy sources (RES) with the utility grid, they pose stability and power quality problems when interconnected with the existing power system. This is due to the production of high voltages and current overshoots/undershoots during their injection or disconnection into/from the power system. In addition, the high harmonic distortion in the output voltage and current waveforms may also be observed due to the excessive inverter switching frequencies used for controlling distributed generator’s (DG) power output. Hence, the development of a robust and intelligent controller for the grid-connected microgrid (MG) is the need of the hour. As such, this paper aims to develop a robust and intelligent optimal power flow controller using a grasshopper optimization algorithm (GOA) to optimize the dynamic response and power quality of the grid-connected MG while sharing the desired amount of power with the grid. To validate the effectiveness of proposed GOA-based controller, its performance in achieving the desired power sharing ratio with optimal dynamic response and power quality is compared with that of its precedent particle swarm optimization (PSO)-based controller under MG injection and abrupt load change conditions. The proposed controller provides tremendous system’s dynamic response with minimum current harmonic distortion even at higher DG penetration levels. Full article
