A platform for converting near-infrared (NIR) laser power modulation into the self-mixing (SM) signal of a quantum cascade laser (QCL) operating at terahertz (THz) frequencies is introduced. This approach is based on laser feedback interferometry (LFI) with a THz QCL using a metal-coated silicon nitride trampoline membrane resonator as both the external QCL laser cavity and the mechanical coupling element of the two-laser hybrid system. We show that the membrane response can be controlled with high precision and stability both in its dynamic (i.e., piezo-electrically actuated) and static state via photothermally induced NIR laser excitation. The responsivity to nanometric external cavity variations and robustness to optical feedback of the QCL LFI apparatus allows a highly sensitive and reliable transfer of the NIR power modulation into the QCL SM voltage, with a bandwidth limited by the thermal response time of the membrane resonator. Interestingly, a dual information conversion is possible thanks to the accurate thermal tuning of the membrane resonance frequency shift and displacement. Overall, the proposed apparatus can be exploited for the precise opto-mechanical control of QCL operation with advanced applications in LFI imaging and spectroscopy and in coherent optical communication. Full article

The application of a high-voltage electric field (HVEF) is crucial for mitigating the growth and reproduction of pathogenic microorganisms on solid surfaces. However, the electric field distribution of HVEF in the undischarged state and bactericidal effect remain largely unexplored. Herein, a unipolar wire–plate HVEF device was developed and its field strength distribution was simulated by COMOSL software (version 6.2). The simulation analysis revealed that the electric field strength and space charge density of HVEF in the undischarged state reached a maximum at the discharge electrode and a minimum at the middle of the two electrode wires. The electric field strength and the inhomogeneity of electric intensity distribution also decreased with the increase in electrode spacing. The sterilization effect of E. coli was positively correlated with voltage and treatment time, but negatively correlated with electrode spacing, which was consistent with the change in the field strength of the simulation results. When the voltage was −12.5 kv and electrode spacing 2.7 cm, the sterilization rate was 98.03% at 60 min. In addition, the increase in treatment temperature and relative humidity also affected the electric field distribution, thereby improving the bactericidal effect. Our results revealed that the electric field distribution was the main factor affecting the sterilization effect of HVEF, which provided theoretical support for the design of HVEF sterilization equipment and the optimization of sterilization performance Full article

Eggs are a highly nutritious food; however, those are also fragile and susceptible to cracks, which can lead to bacterial contamination and economic losses. Traditional methods for detecting cracks, particularly in processed eggs, often fall short due to changes in the eggs’ physical properties during processing. This study was aimed at developing a novel device for detecting egg cracks using electric discharge phenomena. The system was designed to apply a high-voltage electric field to the eggs, where sparks were generated at crack locations due to the differences in electrical conductivity between the insulative eggshell and the more conductive inner membrane exposed by the cracks. The detection apparatus consisted of a custom-built high-voltage power supply, flexible electrode pins, and a rotation mechanism to ensure a complete 360-degree inspection of each egg. Numerical simulations were performed to analyze the distribution of the electric field and charge density, confirming the method’s validity. The results demonstrated that this system could efficiently detect cracks in both raw and processed eggs, overcoming the limitations of existing detection technologies. The proposed method offers high precision, reliability, and the potential for broader application in the inspection of various poultry products, representing a significant advancement in food safety and quality control. Full article

In general, a high voltage (HV) substation can be made up of multiple insulation subsystems: an air insulation subsystem (AIS), gas insulation subsystem (GIS), liquid insulation subsystem (power transformers), and solid insulation subsystem (power cables), all of them with their grounding structures interconnected and linked to the substation earth. Partial discharge (PD) pulses, which are generated in a HV apparatus belonging to a subsystem, travel through the grounding structures of the others. PD analyzers using high-frequency current transformer (HFCT) sensors, which are installed at the connections between the grounding structures, are sensitive to these traveling pulses. In a substation made up of an AIS, several non-critical PD sources can be detected, such as possible corona, air surface, or floating discharges. To perform the correct diagnosis, non-critical PD sources must be separated from critical PD sources related to insulation defects, such as a cavity in a solid dielectric material, mobile particles in SF6, or surface discharges in oil. Powerful diagnostic tools using PD clustering and phase-resolved PD (PRPD) pattern recognition have been developed to check the insulation condition of HV substations. However, a common issue is how to determine the subsystem in which a critical PD source is located when there are several PD sources, and a critical one is near the boundary between two HV subsystems, e.g., a cavity defect located between a cable end and a GIS. The traveling direction of the detected PD is valuable information to determine the subsystem in which the insulation defect is located. However, incorrect diagnostics are usually due to the constraints of PD measuring systems and inadequate PD diagnostic procedures. This paper presents a diagnostic procedure using an appropriate PD analyzer with multiple HFCT sensors to carry out efficient insulation condition diagnoses. This PD procedure has been developed on the basis of laboratory tests, transient signal modeling, and validation tests. The validation tests were carried out in a special test bench developed for the characterization of PD analyzers. To demonstrate the effectiveness of the procedure, a real case is also presented, where satisfactory results are shown. Full article

Hybrid electric vehicles (HEVs) and fuel cell electric vehicles (FCEVs) utilize boost converters to gain a higher voltage than the battery. Interleaved boost converters are suitable for low input voltage, large input current, miniaturization, and high-efficiency applications. This paper proposes a novel linear quadratic integral (LQI) control for the interleaved boost converters. First, the small-signal model of the interleaved-boost converter is derived. In the proposed method, an output voltage and a current signal error between two-phase input currents are selected to control not only the output voltage but also a balance between two-phase input currents. Furthermore, steady-state characteristics in terms of the output voltage and the input current are demonstrated by experiments and simulations using an experimental apparatus with a rated power of 700 W. The validity of the proposed method’s tracking performance and load response is demonstrated by comparing it with that of the conventional PI control. The tracking performance of the LQI control for the 40 V step response has a ten times faster response than that of the PI control. Also, the experimental results demonstrate that the proposed method maintains a constant output voltage for a 300 W load step while the PI control varies by 10 V during 70 ms. Additionally, the proposed method has an excellent disturbance rejection. Full article

Tissue imaging is crucial in oral cancer diagnostics. Imaging techniques such as X-ray imaging, magnetic resonance imaging, optical coherence tomography (OCT) and computed tomography (CT) enable the visualization and analysis of tissues, aiding in the detection and diagnosis of cancers. A significant amount of research has been conducted on designing OCT probes for tissue imaging, but most probes are either heavy, bulky and require external mounting or are lightweight but straight. This study addresses these challenges, resulting in a curved lightweight, low-voltage and compact handheld imaging probe for oral soft tissue examination. To the best of our knowledge, this is the first curved handheld OCT probe with its shape optimized for oral applications. This probe features highly compact all-fiber optics with a diameter of 125 μm and utilizes innovative central deflection magnetic actuation for controlled beam scanning. To ensure vertical stability while scanning oral soft tissues, the fiber was secured through multiple narrow slits at the probe’s distal end. This apparatus was encased in a 3D-printed angular cylinder tube (15 mm outer diameter, 12 mm inner diameter and 160 mm in length, weighing < 20 g). An angle of 115° makes the probe easy to hold and suitable for scanning in space-limited locations. To validate the feasibility of this probe, we conducted assessments on a multi-layered imaging phantom and human tissues, visualizing microstructural features with high contrast. Full article

In the traditional control scheme of a 12/8-pole bearingless switched reluctance motor (BSRM), radial force and torque are usually controlled as a compromise due to the conflict between their effective output areas. Additionally, each phase requires individual power circuits and is excited in turn to produce a continuous levitation force, resulting in high power device requirements and high controller costs. This paper discusses a 12/8-pole single-winding hybrid-rotor bearingless switched reluctance motor (HBSRM) with a hybrid rotor consisting of cylindrical and salient-pole lamination segments. The asymmetric rotor of the HBSRM slightly increases the complexity of its structure and magnetic circuit, but makes it possible to generate the desired radial force at any rotor angular position. A control scheme for the HBSRM is developed to utilize the independent excitation of the four windings in one phase to generate the desired levitation force at any rotor angular position, and it requires only half the number of power circuits used in the conventional control scheme of a 12/8-pole single-winding BSRM. Different from the average torque chosen to be controlled in traditional methods, this scheme directly regulates the instantaneous total torque produced by all excited phases together and presents a current algorithm to optimize the torque contribution of each phase so as to reduce torque pulsation, and the improved performance of this bearingless motor is finally validated by simulation analysis. Full article

Commutation failures in high-voltage direct current (HVDC) transmission systems often occur within inverter stations, posing challenges to the safe and consistent operation of HVDC transmission projects. This paper examines data gathered from a wide-spectrum transient electromagnetic voltage monitoring apparatus. The findings uncover a notable correlation between transient AC bus voltage disturbances, stemming from faults, and the occurrence of commutation failures in HVDC transmission systems. Leveraging this correlation, we propose a commutation failure mitigation strategy for HVDC systems centered around AC bus voltage disturbances within inverter stations. Through fault validation simulations conducted across three HVDC transmission systems, our strategy demonstrates effective suppression of commutation failure incidents within HVDC transmission projects. Full article

This paper proposes a novel phase-resolved partial discharge (PRPD) sensor embedded in a MV-class bushing for high-accuracy insulation analysis. The design, fabrication, and evaluation of a PRPD sensor embedded in a MV-class bushing aimed to achieve the detection of partial discharge (PD) pulses that are phase-synchronized with the applied primary HV signal. A prototype PRPD sensor was composed of a flexible printed circuit board (PCB) with dual-sensing electrodes, utilizing a capacitive voltage divider (CVD) for voltage measurement, the D-dot principle for PD detection, and a signal transducer with passive elements. A PD simulator was prepared to emulate typical PD defects, i.e., a metal protrusion. The voltage measurement precision of the prototype PRPD sensor was satisfied with the accuracy class of 0.2 specified in IEC 61869-11, as the maximum corrected voltage error ratios and corrected phase errors in 80%, 100%, and 120% of the rated voltage (13.2 kilovolts (kV)) were less than 0.2% and 10 min, respectively. In addition, the prototype PRPD sensor had good linearity and high sensitivity for PD detection compared with a conventional electrical detection method. According to performance evaluation tests, the prototype PRPD sensor embedded in the MV-class bushing can measure PRPD patterns phase-synchronized with the primary voltage without any additional synchronization equipment or system. Therefore, the prototype PRPD sensor holds potential as a substitute for conventional commercial PD sensors. Consequently, this advancement could lead to the enhancement of power system monitoring and maintenance, contributing to the digitalization and minimization of power apparatus. Full article

Professional divers exposed to pressures greater than 11 ATA (1.1 MPa) may suffer from high-pressure neurological syndrome (HPNS). Divers who use closed-circuit breathing apparatus and patients and medical attendants undergoing hyperbaric oxygen therapy (HBOT) face the risk of CNS hyperbaric oxygen toxicity (HBOTx) at oxygen pressure above 2 ATA (0.2 MPa). Both syndromes are characterized by reversible CNS hyperexcitability, accompanied by cognitive and motor deficits, and N-methyl-D-aspartate receptor (NMDAR) plays a crucial role in provoking them. Various NMDAR subtypes respond differently under hyperbaric conditions. The augmented currents observed only in NMDAR containing GluN2A subunit increase glutamatergic synaptic activity and cause dendritic hyperexcitability and abnormal neuronal activity. Removal of the resting Zn²⁺ voltage-independent inhibition exerted by GluN2A present in the NMDAR is the major candidate for the mechanism underlying the increase in receptor conductance. Therefore, this process should be the main target for future research aiming at developing neuroprotection against HPNS and HBOTx. Full article

An efficient catalyst is key to achieving the synthesis of electrochemical ammonia and improving safety. In this work, using biomass walnut shell as a carbon source and sodium thiosulfate as a sulfur source, sulfur-modified walnut shell-derived carbon material was synthesized via a simple low-temperature impregnation method at room temperature and atmospheric pressure as an effective electrochemical ammonia synthesis catalyst with high thermal stability. Scanning electron microscopy (SEM), transmission electron microscopy (TEM), Raman spectroscopy, X-ray photoelectron spectroscopy (XPS), nitrogen adsorption–desorption apparatus, thermogravimetry (TG), and other characterization methods were applied to analyze the micro-morphology and physicochemical structure of the electrocatalyst. The synthesized ammonia performance of the catalyst was measured using an ultraviolet (UV) spectrophotometer and electrochemical workstation. The catalyst design used the doping of sulfur atoms to create rich catalytic active sites, while the presence of elemental sulfur on the catalyst surface provided hydrophobicity, which was conducive to inhibiting competitive hydrogen evolution reaction (HER) and enhancing the electrocatalytic ammonia synthesis performance of the catalyst. Under normal temperature and pressure conditions, when a voltage of −0.45 V was applied, the ammonia yield in 0.05 M H₂SO₄ electrolyte was 10.39 μg_NH3 mg_cat.⁻¹ h⁻¹. The results showed that the introduction of sulfur effectively improved the electrocatalytic and thermal safety performance of bio-derived carbon materials, and the test presented that the performance of the catalyst was stable and reusable. Full article

The upgrade of the A Toroidal LHC ApparatuS (ATLAS) hadronic Tile Calorimeter (TileCal) Low-Voltage Power Supply (LVPS) forms a part of the Phase-II Upgrade preparations undertaken by the ATLAS experiment for the data taking during the High-Luminosity Large Hadron Collider era. This paper serves to provide a detailed overview of the development of a Burn-in test station for an upgraded LVPS component known as a Brick. The production, quality assurance testing, and all associated apparatus are being jointly undertaken by the University of the Witwatersrand (Wits) and the University of Texas at Arlington (UTA). These Bricks are radiation-hard transformer-coupled buck converters that function to step-down bulk 200 VDC power to the 10 VDC required by the on-detector electronics. To ensure the high reliability of the Bricks, once installed within the TileCal, a Burn-in test station has been designed and built. The Burn-in station functions to implement a Burn-in procedure on eight Bricks simultaneously. This procedure subjects the Bricks to sub-optimal operating conditions, which function to accelerate their ageing, as well as to stimulate failure mechanisms. This results in elements of the Brick that would fail prematurely within the TileCal failing within the Burn-in station or experience performance degradation that can be detected by follow-up testing effectively screening out the non-performative sub-population. The Burn-in station is of fully custom design in both its hardware and software. The development of the test station will be explored in detail; the preliminary Burn-in procedure to be employed will be provided; the preliminary and final commissioning of the test station will be presented. The paper will culminate in the presentation and discussion of the Burn-in of a V8.4.2 Brick and the future outlook of the project. Full article

Power transformers are essential for the distribution and transmission of electricity, but they are prone to degradation due to faults early on. Partial Discharge (PD) is the most significant pointer of insulation breakdown in high-voltage apparatus. Dissolved Gas Analysis (DGA) is a commonly used technique for detecting and diagnosing PD. However, DGA data often contain missing values, which can significantly affect the accuracy of PD diagnosis. To mitigate the issues of missing values, this paper proposes using the k-Nearest Neighbors (kNN) technique to impute the missing values in the dataset. Further, it combines kNN with a Support Vector Machine (SVM) to detect the possibility of a PD source in the high-voltage apparatus. The approach was evaluated on a real-world DGA dataset and achieved high classification performance and discriminatory power for distinguishing between PD and non-PD instances. The effectiveness of the missing value imputation technique was evaluated, and the proposed approach demonstrated improved accuracy and precision compared to methods without imputation. The proposed approach offers a current solution for PD analysis in power transformers using DGA data with missing values. Full article

High Temperature Superconducting (HTS) dynamo flux pumps are a promising alternative to metal current leads for energization and the persistent current mode operation of high current DC superconducting magnet systems for applications in rotating machines, such as Magnetic Resonance Imaging (MRI) or fusion systems. The viability of the flux pump concept has been widely proven by laboratory experiments and research is now in progress for the design and optimization of flux pump devices for practical applications. It has been widely established that the dependence of the critical current density (J_c) on the temperature (T), the magnetic field magnitude (B), and the orientation (θ), has a substantial impact on the overall DC voltage obtained at the terminals, as well as on the current limit and the loss of the flux pump. Since HTS tapes produced by different manufacturers, they show different dependencies of J_c with the amplitude and the orientation of the magnetic field. They also give rise to different outputs when employed in flux pumps. In this paper, we evaluate and compare the performance of several commercial HTS tapes used for flux pumping purposes through numerical simulation. We also investigate the dependence of the flux pump ‘s performance on the operating temperatures. A 2D finite element numerical model is first developed and validated against experimental data at 77 K. Afterward, the same HTS dynamo apparatus used for validation is exploited for the comparison. The J_c(B,θ,T) and $n$(B,θ,T) relations, which characterize each different tape in the model, are reconstructed via artificial intelligence techniques based on the open-access database of the Robinson Research Institute. It is shown in the paper that certain tapes are more suitable than others for flux pump applications and that the best overall operating temperature is in the vicinity of 77 K. Full article

A composite current sensor is designed with soft ferrite as the magnetizer in combination with giant magnetostrictive material (GMM) and fiber Bragg grating (FBG). The temperature drift characteristics of the GMM, detecting performances under thermal strain caused by temperature variation in the GMM rod, are investigated by simulating the coupled fields of magnetostriction and thermal expansion with the finite-element multi-physics method to explore the temperature-drift mechanism of the ferrite–GMM current detector. The sensing characteristics of the GMM-FBG current sensor under quasi-static current excitation at various work temperatures are evaluated by simulating thermal stress between the GMM and FBG to analyze the temperature drift mechanism of the Bragg wavelength signal modulated by FBG. Even though temperature elevation suppresses GMM magnetization and thereby reduces the slopes of stress–strain curves, the steering magnetization of magnetic domains in the GMM rod tends to saturation without appreciable thermal inhibition in the high-stress region of large current excitation, while the magnetostrictive strain is still abated by the reduction in magnetic flux density caused by the thermal expansion of GMM rods. The temperature elevation can also produce thermal stress between the GMM and FBG, which will decrease the detection sensitivity and testing range of the GMM-FBG current sensor. The temperature drift characteristics of the GMM-FBG are generalized into a formula by fitting the wavelength shifting as a function of thermal strain, which will significantly facilitate designing the scale calibration for various ambient temperatures. The present researchers provide a theoretical basis and experimental guidance for developing GMM-FBG current sensors with high sensitivity and stability. Full article
