Compared to the traditional non-load-bearing multi-legged robots, the heavy-duty multi-legged robots typically not only have larger body weight, larger volume, and larger load ratio but also require greater energy dissipation. Traditional path planning often focuses on the problem of finding the shortest path. However, the substantial load capacity and multi-jointed structure of heavy-duty multi-legged robots impose stringent requirements on path smoothness. Consequently, the smoothness requirement makes the traditional A* algorithm unsuitable for applications where low-energy operation is critical. An improved low-energy path planning method based on the A* algorithm is presented for an electrically driven heavy-duty six-legged robot. Then, the environment is discretized by using the grid method to facilitate path searching. To address the path zigzagging problem caused by the traditional A* algorithm, the Bézier curve smoothing technique is adopted. The continuous curvature transitions are employed to significantly improve the smoothness of path. The heuristic function in the A* algorithm is enhanced through a dynamic weight adjustment mechanism. The nonlinear suppression strategy is introduced to prevent data changes and improve the robustness of the algorithm. The effectiveness of the proposed method is verified through the MATLAB simulation platform system. The simulation experiments show that, in various environments with different obstacle densities (0.17–0.37%), compared with the traditional A* algorithm, the method proposed in this paper reduces the average path length by 7.2%, the number of turning points by 25.9%, and the energy consumption by 5.75%. The proposed improved A* algorithm can significantly overcome the problem of insufficient smoothness in traditional A* algorithms and reduce the number of nodes generated by the control data stack, which improves the optimization efficiency during path planning. As a result, the heavy-duty six-legged robots can walk farther and operate for longer periods of time while carrying the limited energy sources. Full article

Heavy-load collaborative robots are increasingly used in fields such as industrial handling and precision assembly. With the increase in the end load of the robotic arm and the acceleration of its movement speed, after the robotic arm completes a preset trajectory, due to factors such as inertia, the flexibility of the robotic arm’s rods and the harmonic reducer materials at the joints, there will still be residual vibration for a period of time after the robotic arm reaches the end point. On the one hand, residual vibration will have an adverse impact on the high-precision and high-performance operations of the robotic arm, affecting the operation accuracy and thus the production quality. On the other hand, many operations need to wait until the robotic arm completely stops before proceeding. In practical applications, the time spent waiting for the robotic arm to stop significantly affects efficiency. Therefore, effectively suppressing residual vibration is crucial to improving the performance of the robotic arm. To solve the problem of end residual vibration in heavy-load six-axis collaborative robots, this paper conducts research on input shaping and the estimation of robot end vibration parameters in arbitrary poses. The innovation is that vibration parameters in arbitrary poses are estimated based on the established vibration parameter model. An input shaper is designed according to the derived design method of the input shaper, achieving a certain suppression effect on the residual vibration of the robot end. When the parameter identification error is small, the optimized vibration suppression effect reaches more than 70%, realizing rapid and robust vibration suppression. This research is of great significance for enhancing the application value of collaborative robots in precision manufacturing and heavy-duty handling. Full article

The demand for large-scale, heavy-duty autonomous pavement-sweeping robots is rising due to urban growth, hygiene needs, and labor shortages. Ensuring their health and safe operation in dynamic outdoor environments is vital, as terrain unevenness and slope gradients can accelerate wear, increase maintenance costs, and pose safety risks. This study introduces an AI-driven condition monitoring (CM) framework designed to detect terrain unevenness and slope gradients in real time, distinguishing between safe and unsafe conditions. As system vibration levels and energy consumption vary with terrain unevenness and slope gradients, vibration and current data are collected for five CM classes identified: safe, moderately safe terrain, moderately safe slope, unsafe terrain, and unsafe slope. A simple-structured one-dimensional convolutional neural network (1D CNN) model is developed for fast and accurate prediction of the safe to unsafe classes for real-time application. An in-house developed large-scale autonomous pavement-sweeping robot, PANTHERA 2.0, is used for data collection and real-time experiments. The training dataset is generated by extracting representative vibration and heterogeneous slope data using three types of interoceptive sensors mounted in different zones of the robot. These sensors complement each other to enable accurate class prediction. The dataset includes angular velocity data from an IMU, vibration acceleration data from three vibration sensors, and current consumption data from three current sensors attached to the key motors. A CM-map framework is developed for real-time monitoring of the robot by fusing the predicted anomalous classes onto a 3D occupancy map of the workspace. The performance of the trained CM framework is evaluated through offline and real-time field trials using statistical measurement metrics, achieving an average class prediction accuracy of 92% and 90.8%, respectively. This demonstrates that the proposed CM framework enables maintenance teams to take timely and appropriate actions, including the adoption of suitable maintenance strategies. Full article

This paper aims to solve the problems of poor mobility, passability, and stability in heavy-duty vehicles, and proposes an active suspension system control strategy based on position–force feedback optimal control to coordinately enhance vehicle passability and wheel grounding performance. Firstly, a two-degrees-of-freedom one-sixth vehicle active suspension model and a valve-controlled hydraulic actuator system model are constructed, and the advantages of impedance control in robot compliance control are integrated to analyze their applicability in hydraulic active suspension. Next, a position feedback controller and force feedback LQG optimal controller for fuzzy PID control are designed, the fuzzy PID-LQG (FPL) integrated method is applied to the hydraulic active suspension system, and the dynamic load of the wheel is tracked by impedance control to obtain the spring mass displacement correction. Then, a suspension system model under the excitation of a C-class road surface and a 0.11 m raised road surface is constructed, and the dynamic simulation and comparison of active/passive suspension systems are carried out. The results show that, compared with PS and LQR control, the body vertical acceleration, suspension dynamic deflection, and wheel dynamic load root-mean-square value of the proposed FPL integrated control active suspension are reduced, which can effectively reduce the body vibration and wheel dynamic load and meet the design objectives proposed in this paper, effectively improving vehicle ride comfort, handling stability, passability, and wheel grounding performance. Full article

In this paper, the design of a driving mechanism for a heavy-duty collaborative robot (cobot) capable of lifting payloads up to 20 kg is presented. This study focuses on an articulated robot utilizing a water-based Electro-Hydraulic Actuator (EHA). The Denavit–Hartenberg (D–H) representation was employed to relate the rotational angles and the end-effector’s location, facilitating the design of the actuators. The maximum required torques for joints 2 and 3, responsible for lifting for 12 s, were calculated under quasi-static and dynamic loading conditions. The results showed that the maximum required torques were 126.67 Nm and 58.86 Nm for joint 2 and 3, respectively. The maximum torque for joint 2 occurs when the pitch links are fully extended, whereas the maximum torque for joint 3 occurs when the third link is parallel to the ground. The torques, due to the inertia and Coriolis dynamic terms, were also calculated and found to be lower than those required for the gravitational term. Various maneuvering scenarios, along with Ansys Motion simulation, were analyzed for the verification of the results. Based on the calculated maximum torques, the linear actuators of the EHA were designed. The heavy-duty cobot can be built with the developed actuator proposed in this paper. The total weight of the entire frame was measured to be 14.59 kg, resulting in a high Payload/Weight (P/W) ratio of 1.37. In conclusion, the robot was made lighter and can operate more efficiently, particularly for heavy loads up to 20 kg. Full article

Dual–motor drive is commonly used in heavy–duty robotic joint servo systems. However, the backlash inevitably affects joint accuracy. In this article, a variable bias torque control method is proposed for a dual–motor–driven robotic joint. The variable bias torque varies directly according to the motor current, and the conversion method of the bias compensation torque is presented. A simulation model of the dual–motor drive system in MATLAB/Simulink is established based on the dynamic modeling of a dual–motor drive system, and a robotic joint prototype is also established. The variable bias torque control can achieve a reasonable distribution of the output torque for the whole servo cycle and can effectively reduce the energy consumption of the system to maintain static backlash elimination; the dynamic loading of the bias voltage can be achieved through the setting of the conversion function to complete the smooth transition between the two states of backlash elimination control and common drive control; the dynamic loading of the bias torque improves the torque output capability of the dual–motor system. In the experiment, the steady–state error of the servo system is less than 0.05°, and the error is much smaller than the internal backlash angle (about 2°) of the system, which indicates that the internal backlash of the robot joint has been eliminated. The static backlash elimination bias current of the joint is reduced from about 250 mA to about 110 mA, reducing the energy consumption of the servo system effectively. Full article

Heavy-duty legged robots have played an important role in material transportation, planet exploration, and other fields due to their unique advantages in complex and harsh terrain environments. The instability phenomenon of the heavy-duty legged robots often arises during the dynamic interactions between the supporting feet and the intricate terrains, which significantly impact the ability of the heavy-duty legged robots to move rapidly and accomplish tasks. Therefore, it is necessary to assess the mechanical behavior of foot–terrain interactions for the heavy-duty legged robots. In order to achieve the above goal, a systematic literature review methodology is employed to examine recent technical scientific publications, aiming to identify both current and prospective research fields. The characteristics of supporting feet for different heavy-duty legged robots are compared and analyzed. The foot–terrain mechanical models of the heavy-duty legged robots are discussed. The problems that need further research are summarized and presented, which is conducive to further deepening and expanding the research on the mechanical behavior of foot–terrain interactions for heavy-duty legged robots. Full article

Automated charging technologies are becoming increasingly important in the electrification of heavy road freight transport, especially in combination with autonomous driving. This study provides a comprehensive analysis of automated charging technologies for electric heavy-duty vehicles (HDVs). It encompasses the entire spectrum of feasible technologies, including static and dynamic approaches, with each charging technology evaluated for its advantages, potentials, challenges and technology readiness level (TRL). Static conductive charging methods such as charging robots, underbody couplers, or pantographs show good potential, with pantographs being the most mature option. These technologies are progressing towards higher TRLs, with a focus on standardization and adaptability. While static wireless charging is operational for some prototype solutions, it encounters challenges related to implementation and efficiency. Dynamic conductive charging through an overhead contact line or contact rails holds promise for high-traffic HDV routes with the overhead contact line being the most developed option. Dynamic wireless charging, although facing efficiency challenges, offers the potential for seamless integration into roads and minimal wear and tear. Battery swapping is emerging as a practical solution to reduce downtime for charging, with varying levels of readiness across different implementations. To facilitate large-scale deployment, further standardization efforts are required. This study emphasizes the necessity for continued research and development to enhance efficiency, decrease costs and ensure seamless integration into existing infrastructures. Technologies that achieve this best will have the highest potential to significantly contribute to the creation of an efficiently automated and environmentally friendly transport sector. Full article

Legged agricultural transportation robots are efficient tools that can autonomously transport goods over agricultural terrain, and their introduction helps to improve the efficiency and quality of agricultural production. Their effectiveness depends on their adaptability to different environmental conditions, which is especially true for heavy-duty robots that exert ground forces. Therefore, this study proposes a motion-control strategy for a heavy-duty transport hexapod robot. Two critical tasks were accomplished in this paper: (1) estimating the support surface angle based on the robot’s foot position and body posture, and accordingly determining the motion constraint conditions on this support surface and the body posture based on energy optimization; (2) proposing an adaptive fuzzy impedance algorithm for real-time force–position composite control for adjusting foot position, in order to reduce the steady-state force tracking error caused by terrain stiffness, thus ensuring body stability through tracking of variable foot-end forces. An element of hardware in the loop control platform for a 3.55-ton device was designed and compared with the current popular force-control methods under different external contact terrains. The results show that the proposed control method can effectively reduce force errors, establish support forces faster on less-stiff environments, and reduce the torso tilt during phase switching. Full article

Recent technological progress is opening up practical applications for quadruped robots. In this context, comprehensive performance demands, including speed, payload, robustness, terrain adaptability, endurance, and techno-economics, are increasing. However, design conflicts inevitably exist among these performance indicators, highlighting design challenges, especially for a heavy-duty, electrically actuated quadruped robots, which are strongly constrained by motor torque density and battery energy density. Starting from task-specific holistic system thinking, in this paper, we present a novel task-oriented approach to the design of such kind of robots, incorporating hierarchical optimization and a control-in-the-loop design, while following a structured design path that effectively exploits the strengths of both heuristic and computational designs. Guided by these philosophies, we utilize heuristic design to obtain the approximate initial form of the prototype and propose a key task-oriented actuator joint configuration, utilizing commercially available components. Subsequently, we build a step-wise analytical models considering trajectory optimization and motor heat constraints for optimization of leg length and joint match parameters to achieve a compact performance requirement envelope and minimize redundancy in the construction of task-specific components. Furthermore, we construct a holistic simulation platform with a module control algorithm for typical scenarios to evaluate subsystem results and adjust design parameters iteratively, balancing conflicts and eventually achieving a reliable design specification for detailed subsystem design. Based on these strategies, we develop a heavy-duty electric prototype achieving a maximum speed of 2 m/s in trotting gait with a load weighting over 160 kg and enduring a period of 2 h. The experiment upon the prototype verifies the efficiency of the proposed approach. Full article

This study aims to resolve the problems of low precision, poor flexibility and unstable operation in the control performance of loading robots with long telescopic booms and heavy loads. Firstly, the kinematics and dynamics of long-arm heavy-duty robots are analyzed, and the dynamics model of a long-arm heavy-duty robot is established using the Lagrange method. A new power-hybrid sliding-mode approach law is proposed, and a hybrid force/position control strategy is used to control long-arm heavy-duty robots. The position control of long-arm heavy-duty robots uses a new sliding-mode adaptive control to improve the position accuracy of important joints, and PD control is used to force control the other joints. The two-stage telescopic arm is flexible and the long-arm heavy-load robot is simulated. The simulation results show that the long-arm heavy-load robot obtained using the improved sliding-mode adaptive control algorithm has good track-tracking and jitter-suppression effects. The new power-hybrid sliding-mode controller designed in this paper reduces the jitter amplitude of the end-effector of long-arm heavy-duty robots by 28.75%, 10.92% and 16.22%, respectively, compared with the existing new approach law sliding-mode controller. The simulation results show that the proposed power-hybrid reaching law sliding-mode controller can effectively reduce the amplitude difference of the end-effector. Finally, the force/position control strategy is combined with force-based impedance control, and the design process of impedance controller parameters is introduced, which provides a reference for the trajectory-tracking and vibration-suppression of end-effectors of long-arm heavy-duty robots. Full article

This paper demonstrates the capabilities of three-dimensional (3D) LiDAR scanners in supporting a safe distance maintenance functionality in human–robot collaborative applications. The use of such sensors is severely under-utilised in collaborative work with heavy-duty robots. However, even with a relatively modest proprietary 3D sensor prototype, a respectable level of safety has been achieved, which should encourage the development of such applications in the future. Its associated intelligent control system (ICS) is presented, as well as the sensor’s technical characteristics. It acquires the positions of the robot and the human periodically, predicts their positions in the near future optionally, and adjusts the robot’s speed to keep its distance from the human above the protective separation distance. The main novelty is the possibility to load an instance of the robot programme into the ICS, which then precomputes the future position and pose of the robot. Higher accuracy and safety are provided, in comparison to traditional predictions from known real-time and near-past positions and poses. The use of a 3D LiDAR scanner in a speed and separation monitoring application and, particularly, its specific placing, are also innovative and advantageous. The system was validated by analysing videos taken by the reference validation camera visually, which confirmed its safe operation in reasonably limited ranges of robot and human speeds. Full article

The clearance of a kinematic pair will lead to the contact collision between the joints of the mechanism, which will have a great influence on the dynamic characteristics of a mechanical system with clearance. In order to study the influence of a rotating motion pair with clearance on the dynamic characteristics of a tool changing robot, a contact wear dynamics model of a modular tool changing robot was established based on the three-state model of “free-contact-collision”. Different from analysis of a light linkage structure, this paper takes a solid structure with large mass as the analysis object. Based on the impact contact force model and the improved Coulomb friction model, the effects of clearance size, rotational speed and friction coefficient on the dynamic characteristics of the tool changing robot were analyzed. The Archard wear model was used to predict the wear between the motion pairs with clearance. The analysis results show that, with the increase of clearance size and actuating speed, the fluctuation range of velocity and acceleration increases, and the fluctuation frequency decreases. Under the action of friction, the contact force between components will be reduced due to energy loss so that the kinematic reliability of the mechanism is improved. The wear of the moving pair with clearance is non-uniform. Through the research of this paper, the motion characteristics of the tool-changing robot at low speed and heavy load are clarified. The results show that the established method can realize the dynamic characteristics analysis of low-speed heavy-duty mechanisms with joint gaps, which can be used to guide the design of tool-changing robots, and also has important reference significance for the design of mechanisms containing joint gaps in general. Full article

Mobile robots are no longer used exclusively in research laboratories and indoor controlled environments, but are now also used in dynamic industrial environments, including outdoor sites. Mining is one industry where robots and autonomous vehicles are increasingly used to increase the safety of the workers, as well as to augment the productivity, efficiency, and predictability of the processes. Since autonomous vehicles navigate inside tunnels in underground mines, this kind of navigation has different precision requirements than navigating in an open environment. When driving inside tunnels, it is not relevant to have accurate self-localization, but it is necessary for autonomous vehicles to be able to move safely through the tunnel and to make appropriate decisions at its intersections and access points in the tunnel. To address these needs, a topological navigation system for mining vehicles operating in tunnels is proposed and validated in this paper. This system was specially designed to be used by Load-Haul-Dump (LHD) vehicles, also known as scoop trams, operating in underground mines. In addition, a localization system, specifically designed to be used with the topological navigation system and its associated topological map, is also proposed. The proposed topological navigation and localization systems were validated using a commercial LHD during several months at a copper sub-level stoping mine located in the Coquimbo Region in the northern part of Chile. An important aspect to be addressed when working with heavy-duty machinery, such as LHDs, is the way in which automation systems are developed and tested. For this reason, the development and testing methodology, which includes the use of simulators, scale-models of LHDs, validation, and testing using a commercial LHD in test-fields, and its final validation in a mine, are described. Full article

Extraction of raw materials, especially in extremely harsh underground mine conditions, is irrevocably associated with high risk and probability of accidents. Natural hazards, the use of heavy-duty machines, and other technologies, even if all perfectly organized, may result in an accident. In such critical situations, rescue actions may require advanced technologies as autonomous mobile robot, various sensory system including gas detector, infrared thermography, image acquisition, advanced analytics, etc. In the paper, we describe several scenarios related to rescue action in underground mines with the assumption that searching for sufferers should be done considering potential hazards such as seismic, gas, high temperature, etc. Thus, possibilities of rescue team activities in such areas may be highly risky. This work reports the results of testing of a UGV robotic system in an underground mine developed in the frame of the AMICOS project. The system consists of UGV with a sensory system and image processing module that are based on an adaptation of You Only Look Once (YOLO) and Histogram of Oriented Gradients (HOG) algorithms. The experiment was very successful; human detection efficiency was very promising. Future work will be related to test the AMICOS technology in deep copper ore mines. Full article
