Rock bursts usually happen during the hours or days after tunnel excavation, even in an unsupported opening where no collapses occur. To investigate the mechanism of those delayed failures in brittle rock tunnels, this paper showcases the performed scale-model test based upon the Jinping II headrace tunnelling project. The model test was conducted in a particularly designed loading apparatus; the scale-model is composed of a similar material for the deep brittle rock. The tunnel in the scale-model is excavated by a specially made drilling tool. The failure mode of the deep circle tunnel under isotropic and anisotropic geostress were obtained; the delay failure time was recorded, and the accompanying stresses and strains changing were monitored. Under isotropic geostress the failure shape has a smooth circle boundary, failure process totally costs 56 h. While under anisotropic geostress a dog-eared breakdown was found, the failure process amounted to 72 h. The time-to-failure was evaluated by delay failure theory, and the evaluation equation was implemented into in FEM code. Numerical simulations have been performed to simulate the failure time and failure mode. The numerical results of failure time and failure mode mainly match the scale-model testing results. Full article

Under the “dual-carbon” strategy, accurately quantifying carbon emissions in water conservancy projects is crucial to promoting low-carbon construction. However, existing life cycle assessment (LCA) methods for carbon emissions during the mechanical construction stage often fail to reflect actual processes and are limited by high costs and lengthy data collection, potentially leading to inaccurate estimates. To address these challenges, this paper proposes a carbon emission evaluation method for the mechanical construction stage, based on carbon footprint theory and discrete event simulation (DES). This method quantifies equipment operation time and energy consumption during the drilling and blasting processes, enabling a detailed and dynamic emission analysis. Using the Fumin Pumped Storage Power Station Tunnel Project as a case study, a comparative analysis is conducted to examine the carbon emission characteristics of drilling and blasting operations under different surrounding rock conditions based on DES. The validity of the proposed model is confirmed by comparing its results with monitoring data and LCA results. The results show a clear upward trend in carbon emission intensity as surrounding rock conditions deteriorate, with emission intensity rising from 8405.82 kgCO₂e/m for Class II to 16,189.30 kgCO₂e/m for Class V in the headrace tunnel. The total carbon emissions of the water conveyance tunnels reach 40,019.64 tCO₂e, with an average intensity of 13,565.98 kgCO₂e/m. This study presents a refined and validated framework for assessing the carbon emissions of pumped storage tunnels. It addresses key limitations of traditional LCA methods in the mechanical construction stage and provides a practical tool to support the green transition of hydraulic infrastructure. Full article

The frequent pressure pulsations due to hydraulic transients in hydropower plants induce cyclic loading on the rock mass that may contribute to increased instances of block falls and increased risk of tunnel collapse over the power plant lifetime. This study focuses on understanding the effect of frequent start and stop sequences of hydropower in unlined pressure tunnels. For this purpose, data from a pore water pressure monitoring system is utilized, which was installed at the downstream end of the headrace tunnel at the 50 MW Roskrepp hydropower plant in southern Norway. The objective of this study is to analyze the recorded data and quantify the impact of the hydraulic transient on the surrounding rock mass in the unlined pressure tunnel. The monitoring of pressure data over several years clearly shows that frequent load changes could cause a considerable effect on the rock mass and constituent joint system. A delayed response of the pressure in boreholes in the rock mass compared with inside the tunnel is seen in all start and stop sequences and is considered to be the main reason for instability caused by transients. The response of pore pressure in boreholes is greatly influenced by the characteristics of joints. The results show that the start sequence and shorter shutdown duration exert a greater impact on rock mass as compared to the stop sequence and longer shutdown duration. Therefore, it is recommended to increase the shutdown duration so that the impact can be minimized to increase the tunnel lifetime. This study recommends implementing a more conservative design approach in tunnels with weak rock masses in projects that involve frequent load changes. Full article

Infrastructure that was constructed during the high economic growth period of Japan is starting to deteriorate; thus, there is a need for the maintenance and management of these structures. The basis of maintenance and management is the inspection process, which involves finding and recording damage. However, in headrace tunnels, the water supply is interrupted during inspection; thus, it is desirable to comprehensively photograph and record the tunnel wall and detect damage using the captured images to significantly reduce the water supply interruption time. Given this background, the aim of this study is to establish an investigation and assessment system for deformation points in the inner walls of headrace tunnels and to perform efficient maintenance and management of the tunnels. First, we develop a mobile headrace photography device that photographs the walls of the headrace tunnel with a charge-coupled device line camera. Next, we develop a method using YOLOv7 for detecting chalk marks at the damage locations made during cleaning of the tunnel walls that were photographed by the imaging system, and these results are used as a basis to develop a system that automatically accumulates and plots damage locations and distributions. For chalking detection using continuous wall surface images, a high accuracy of 99.02% is achieved. Furthermore, the system can evaluate the total number and distribution of deteriorated areas, which can be used to identify the causes of change over time and the occurrence of deterioration phenomena. The developed system can significantly reduce the duration and cost of inspections and surveys, and the results can be used to select priority repair areas and to predict deterioration through data accumulation, contributing to appropriate management of headrace tunnels. Full article

A surge chamber is a common pressure reduction facility in a hydropower plant. Owing to large flow inertia in the upstream headrace tunnel and downstream tailrace tunnel, a hydropower plant with upstream and downstream surge chambers (HPUDSC) was adopted. This paper aimed to investigate the operational stability and nonlinear dynamic behavior of a HPUDSC. Firstly, a nonlinear dynamic model of the HPUDSC system was built. Subsequently, the operational stability and nonlinear dynamic behavior of the HPUDSC system were studied based on Hopf bifurcation theory and numerical simulation. Finally, the influencing factors of stability of the HPUDSC system were investigated. The results indicated the nonlinear HPUDSC system occurred at subcritical Hopf bifurcation, and the stability domain was located above the bifurcation curve, which provided a basis for the tuning of the governor parameters during operation. The dominant factors of stability and dynamic behavior of the HPUDSC system were flow inertia and head loss of the headrace tunnel and the area of the upstream surge chamber. Either increasing the head loss of the headrace tunnel and area of the upstream surge chamber or decreasing the flow inertia of the headrace tunnel could improve the operational stability of the HPUDSC. The proposed conclusions are of crucial engineering value for the stable operation of a HPUDSC. Full article

Choosing reasonable control measures for different intensity rockburst risks not only effectively prevents and mitigates rockburst risks but also reduces time and engineering investment costs. Due to the limitations of the tunnel boring machine’s structure and working conditions, tunnels excavated by TBMs are highly susceptible to rockbursts. What is even worse is that there are very few measures to control the rockburst risk in these tunnels. Implementing reasonable control measures from the limited mitigation measures to control and mitigate rockburst in TBM tunnels is an urgent problem that warrants a solution. In this paper, a large number of on-site rockburst risk control cases and a large amount of MS monitoring data (the total mileage of MS monitoring is approximately 7 km, lasting for 482 days) are used to derive a reasonable scheme to control the rockburst risk of different intensities in twin TBM tunnels. First, the rockburst early warning effect of the two headrace tunnels of the Neelum–Jhelum hydropower station based on microseismic monitoring is analyzed. Second, based on highly accurate rockburst warning results, 94 rockburst risk control cases are applied to analyze the control effect of different control measures at different intensities of rockburst risk. Then, by combining factors such as the time cost and expense cost of different control measures, more reasonable control measures for different intensity rockburst risks are proposed: for slight rockburst risk, normal excavation is preferred; for moderate rockburst risk, horizontal destress boreholes are preferred; and for intense rockburst risk, a combination of measures of shortening daily advance and horizontal destress boreholes is preferred. The research results can provide a reference for other TBM excavation projects to carry out rockburst risk prevention and mitigation. Full article

The demand for energy storage systems is rising together with the proportion of renewable energy sources (RES) in power systems. The highest capacity among the various energy storage systems in power systems is provided by pumped-storage hydropower (PSH). In this paper, the ability of the real-time digital simulator (RTDS), e.g., dSpace–SCALEXIO, to emulate a complex pumped-storage hydropower plant with four units, two common penstocks, a surge tank, and a long headrace tunnel is investigated. The RTDS is the smart brain of an advanced lab setup called power hardware in the loop (PHIL), which is an extremely safe and useful lab system for electrical power system research and testing hardware and methods under various conditions. In this research, the capability of an RTDS to emulate the behavior of a pumped-storage hydropower plant including four Francis pump-turbines, four short penstocks, two common penstocks, a surge tank, and a long headrace tunnel is evaluated. Francis pump-turbines are modelled based on the hill chart-based interpolation and waterways including penstocks and headrace tunnel are modelled based on the polynomial approximation of a hyperbolic function. Finally, the results from the RTDS are presented and discussed. According to the results of the paper, we confirm that the RTDS can accurately emulate the hydraulic, mechanical, and electrical transients of a pumped-storage hydropower plant with a complex configuration. Full article

Ensuring access to affordable, reliable, sustainable, and modern energy, as declared in the United Nations’ Agenda 2030, requires both the inclusion of new renewable energy sources, and the renovation of existing hydropower infrastructure, since this resource is considered a key strategy to support flexibility in electric grids with high penetrations of variable generation. This paper addresses the design of a self-supporting lining for the renovation of a headrace tunnel, that has been affected by a buckling event, in order to extend the operating life of the Chivor Hydropower Project, located in Colombia. Studies performed by AES Corporation about the buckling events that affected the headrace tunnel and the condition assessment are first described. Then, the design alternatives to renovate this important part of the hydropower plant’s infrastructure are presented in a general way. The detailed design and construction planning for the selected alternative are then illustrated by showing some calculations used in hydropower design. Such a renovation project is one of the first of its class in Colombia and goes from studies of the buckling events to the design of a modern lining that will be constructed while keeping the 1000-MW (6% of Colombia’s demand) hydropower plant in operation conditions, in order to extend its life for 50 more years, which represents an example for managers and practitioners of large-scale hydraulic engineering projects. Full article

The support theory of the excavation disturbance zone (EDZ) cannot provide an accurate physical explanation or theoretical description of the time-dependent properties required for the development of an EDZ. Therefore, the primary factors that cause the formation of an EDZ should be determined to further improve the support theory of the EDZ and grasp the principle underlying the control of the long-term stability of rock masses. Considering the headrace tunnel and nuclear waste repository as the research background, this study aimed to understand the deformation damage evolution process of the surrounding rock after tunnel excavation under different working conditions using the self-developed realistic failure process analysis (RFPA^2D) code. The simulation revealed the following. First, an EDZ is formed, although the deformation damage to the surrounding rock is relatively small under the action of environmental factors. Second, under the action of stress in the abovementioned case, the deformation speed, damage degree, and scope of the surrounding rock significantly increase, accelerating the formation and development of the EDZ. Therefore, the boundary of the EDZ expands significantly. Third, when environmental factors are blocked, the range of the EDZ is small due to the small deformation damage to the surrounding rock. Thus, the main factors responsible for the formation of the EDZ are environmental factors, whereas stress is only an auxiliary factor. A numerical simulation method that considers environmental factors can more accurately reproduce the formation of an EDZ. Therefore, a study of the internal mechanism of the EDZ phenomenon can provide a more in-depth understanding of the essential characteristics of an EDZ at the macro level. Furthermore, it can provide a scientific basis and method for the construction and support designs of underground excavation projects and widen the possibilities for further improving the support theory of the EDZ. Full article

Weak and weathered rocks are well known for their sensitivity to changes in moisture content. Degrading behavior is common in weak rocks with moisture-sensitive mineral components and present numerous stability problems. The slake durability is a measure of the resistance to weakening and disintegration of rock materials which quantitatively distinguishes durable from non-durable rock materials. Several rock material parameters interact on the process of disintegration when exposed to cyclic moisture changes, whereby the content of clay is believed to play a major role. This manuscript evaluates the overall material composition of flysch and serpentinite rocks cored from the wall of the shotcrete-lined headrace tunnel of a hydropower project, including minerals, structure, porosity, the presence of micro-discontinuities, and swelling potential, and links these properties to the slake durability. Further, the different methods used to assess compositional features affecting the durability of weak rocks are evaluated and discussed. The manuscript argues that the mineralogical composition and microstructures present in the intact rock and the content of moisture-sensitive constituents, as swelling clays, control the long-term durability of weak rock material. It is demonstrated that XRD assessments are not sufficient to detect the content of brucite and swelling components, and that methods as thin section and SEM analyses should be carried out in the assessment of weak and weathered rock mass. Full article

Hydropower is an important source of renewable energy. Due to ageing infrastructure, more and more existing hydropower plants have to be refurbished and modernised. This includes a complete review of the design parameters as well as the change of specific parts. Investments should be targeted to improve the overall performance of hydropower plants and ensure a long lasting life extension. This paper presents the concept of the submerged wall as a local high point in the headrace tunnel, which can—in combination with the intake gates—replace existing penstock shutoff valves. Such a replacement was conducted for the hydropower plant Schneiderau in Austria, which also allowed us to prove the concept based on measurements including a simulated break of the penstock. The presented solution can help to reduce investment costs and also minimise maintenance efforts and therefore is an attractive option for classic penstock shutoff valves for comparable projects. Full article

Pressurized rock traps are constructed in many hydropower plants to stop sand and gravel from being transported through the turbines. Pressurized rock traps are typically located in the downstream end of unlined headrace tunnels, where the tunnel itself may be one of the sediment sources. This state-of-the-art review presents an overview of research on pressurized rock traps from both publicly available sources and unpublished sources. Limited scientific literature exists on rock traps, and most of the existing literature has previously been unavailable for an international audience. Based on this review, it is concluded that pressurized rock traps should be built with the flow area and sediment deposition volume separated by plates or ribs. Without any separation measures, the sediments risk being re-entrained due to turbulence. This review is separated into three sections: (1) sediment problems and sources of sediments, (2) theory for pressurized rock traps, and (3) design of pressurized rock traps. The recommended design for new pressurized rock traps, including a design flow chart, is provided. Finally, a recommended solution for rebuilding existing pressurized rock traps with an open design into a closed design is also presented. Full article

Over the last two decades, the public policies for promoting new renewable energies allowed the growth of such energies around the world. Due to their success, the policies are changing, forcing the producers to adapt their strategy. For instance, in Switzerland, the feed-in tariff system has been modified in 2018 to promote an electricity production from renewable energies that matches the demand. For small hydraulic power plants owners, such a change requires to increase the flexibility of their fleet. The SmallFLEX project, led by HES-SO Valais, aims at demonstrating on the pilot site of Gletsch-Oberwald owned by Forces Motrices Valaisannes SA, the possibilities to increase the flexibility of the power plant and to provide new services. The paper focuses on the methodology followed to warranty the use of the settling basin, the forebay tank, and the third upper part of the headrace tunnel as a new smart storage volume. By combining laboratory tests, numerical simulations, and on-site measurements, the new range of operating conditions has been defined. These data can be used to foresee economic gains. The methodology and the outputs of the project can be useful for performing such a study on other power plants. Full article

During underground construction, the behavior of the ground is influenced by characteristics of the rock mass with situ stresses and ground water, cross section of the excavation area, excavation method, and the rate of excavation. These fundamental features are considered to ensure the support and stability of underground excavations and achieve long-term successful operation. However, the ground composition of the Himalayas hinders tunnel excavation, especially in case of mechanized tunneling; this causes time and cost overruns. This study has reviewed the recently completed Neelum–Jhelum Hydroelectric Project; the project complexities, geological environments involving significant overburden and tectonic stresses, and effects of the excavation method on tunnel stability were analyzed. The major challenges that were encountered during construction are discussed herein along with their countermeasures. An analysis of project-related data reveals that latest techniques and approaches considering rock mechanics were used to complete the project; the existing approaches and methods were accordingly verified and extended. Apart from ground composition, the excavation methods used play an important role in the occurrence of severe rock bursts. Thus, the findings of this study are expected to be helpful for future tunneling projects in the Himalayas. Full article

Rockburst is an unstable failure of a rock mass which is influenced by many factors. During deep excavations, the presence of nearby geological structures such as minor faults, joints, and shear zones increases the likelihood of rockburst occurrence. A shear zone has been observed in the headrace tunnel in the Neelum Jhelum Hydropower Project, Pakistan, which has played an important role in major rockburst events in the project’s history. A rockburst is a seismic event that involves the release of a great amount of energy as the dynamic wave radiated from the seismic source reaches the excavation boundary. In this paper, the FLAC 2D explicit numerical code has been used to simulate the dynamic phenomenon of rockburst near the shear zone in a headrace tunnel. The behavior of the rock mass around the tunnel has been studied under both static and dynamic loading. According to modeling results, rockburst significantly affected the upper left quadrant of the tunnel similar to the actual failure profile with a depth of approximately 5 m. The dynamic impact of rockburst has also affected the loading conditions of the support system in the adjacent tunnel. This study elucidates one of the most important rockburst controlling factors through numerical analysis and recommends yielding support measures that can withstand the dynamic impacts of rockburst in deep, hard rock tunnels. Full article
