This study presents an analytical and numerical framework to describe the debonding behavior of fiber-reinforced cementitious matrix (FRCM)-reinforced flat masonry elements under direct shear tests. A sawtooth shear stress–slip law, initially proposed for Steel Reinforced Grout (SRG) systems by two of the authors, is calibrated for a PBO-FRCM system based on the experimental results available in the literature. These recent experimental outcomes on flat masonry pillars serve to validate the model by capturing essential interface behaviors, including residual strength and pseudo-linear hardening. Furthermore, a finite element (FE) model of the specimens has been developed to simulate the interface response, allowing for a comparison between numerical predictions and experimental results. The sawtooth law is implemented directly in commercial FE software without the need for custom coding. Additionally, a mesh sensitivity analysis was performed to verify numerical stability and identify the optimal discretization parameters for consistent model response. Results show good agreement among experimental observations, the sawtooth analytical model, and FE simulations. The analytical model slightly underestimates the experimental peak load by about 4–6%, while the FE predictions differ from the experimental results by less than 10%, confirming the reliability of the proposed modeling framework. Full article

This study explores the structural safety, mechanical response and optimal construction parameters of the Horizontal Directional Drilling (HDD) technology applied in airport rigid pavements novelly for navigation lighting renovation. This study adopts a combined research method of three-dimensional finite element modeling (FEM) and field tests (full-scale 4C and 4E class airport runway sections). The reliability of the model is verified by the measured data using a Heavy Weight Deflectometer (HWD). The effects of drilling depth, drilling position and typical aircraft loads on the stress and deformation at the bottom of the pavement slab are systematically analyzed. Then, drilling, grouting and non-destructive testing are carried out in the field full-scale test section to investigate the change in pavement bearing capacities. The results show that minimized influence on the mechanical properties of the pavement can be achieved by using 15 cm drilling depths at either slab center or joints. The pavement stiffness slightly decreases by a maximum of 18.9% after drilling. According to the field grouting test, the Impulse Stiffness Modulus (ISM) of most measuring points can be recovered to the original level before drilling. The use of a 10 cm diameter HDD driller meets the structural safety requirements of airport pavements. The HDD technology induces minimized pavement damage and influence on the bearing capacity of the airport runway structure compared with traditional construction technologies, highlighting its advantages in airfield navigation lighting renovations. Full article

In situ tunnel expansion provides a cost-effective and environmentally sustainable alternative to new tunnel construction. However, staged widening disturbs the lining–rock system, triggering complex, non-monotonic stability responses. This study integrates physical model tests and FLAC3D simulations to investigate the mechanical evolution of a limestone tunnel widened by the Center Diaphragm (CD) method. Seven cross-sections (S1–S7) were fabricated and tested under uniaxial compression with digital image correlation. Results show that the peak load decreases from 385.73 kN in the lined baseline (S1) to 184.14 kN at the first unilateral cut (S3), a 49% reduction, but recovers to 262.28 kN at the left-half closure (S4) before dropping to 128.16 kN at the upper-right excavation (S5). The final relined stage (S7) regains 200.69 kN, a 40% improvement over the unlined enlarged state (S6). Numerical analyses confirm this non-monotonic trajectory in terms of the peak plastic-zone fraction. It reaches at 86.32% in S3, decreases to 74.03% in S4, and rises to 76.43% in S5. The fractions further reach 88.51% in S6 and 87.70% in S7, reflecting the enlarged span and redistributed yielding. Targeted bolting at weak stages S3 and S5 reduced plastic-zone fraction by 14.73 and 4.75 percentage points, and reduced crown settlement by 68% and 41%, respectively. These findings challenge the conventional monotonic degradation assumption, identify S3 and S5 as critical weak links, and validate selective reinforcement for enhancing stability during tunnel expansion. Full article

This study addresses the challenges posed by weakly cemented strata in mine tunnels, where surrounding rock softens and deforms upon water exposure, which promotes the development of seepage pathways, and exhibits insufficient stability in bolt (cable) support systems. This study conducts laboratory grouting tests using silica sol on typical weakly cemented sandstone from Xinjiang mining areas. The mineral composition and pore structure were characterized using XRD, SEM, and mercury porosimetry. The injectable mixing ratio parameters for silica sol and the catalyst were determined through viscosity-time evolution tests. Grouting was performed using a custom-built constant-pressure grouting apparatus. After curing, unconfined compressive strength (UCS) and porosity-permeability tests were conducted to evaluate the micro-mechanism of grouting effects on the mechanical and permeability properties of weakly cemented sandstone. The results indicate: (1) The sandstone exhibits a high clay mineral content of 39.8%, dominated by illite. Its pores are primarily small-scale (10–100 nm), accounting for 79.31% of the total pore volume. This scale matches that of silica sol nanoparticles (approximately 9–20 nm), facilitating slurry penetration into micro-pores; (2) microscopic analyses reveal that silica sol effectively reconstructs pore structures through permeation filling and surface coating. Compared to KCl-induced gelation (with approximately 8% gel coverage), NaCl-induced gelation forms a more continuous gel film with more complete pore filling, achieving coverage of around 22%. Furthermore, the larger surface area of the gel aggregates indicates a more thorough filling of micro- and nano-pores, effectively enhancing rock mass compactness. (3) Permeability decreased from 6.91 mD to 3.55 mD, a reduction of 48.6%, while porosity decreased from 16.94% to 13.55%, showing a phased reduction during the grouting process; (4) following pressure grouting stabilization, the uniaxial compressive strength of sandstone increased appropriately by approximately 7–14%, while the elastic modulus rose by about 18–28%. The failure mechanism shifted from shear brittleness to a shear-tension composite state, with enhanced post-peak bearing capacity. These findings provide support for optimizing silica sol grouting parameters in weakly cemented strata tunnels and for the synergistic reinforcement of rock mass permeability and strength. Full article

Frequent large-scale construction projects have rendered subway box structures vulnerable to displacements. This study examined the adequacy of foundation reinforcement for a subway box structure exhibiting displacement behavior. A displacement function was derived from the optical leveling data, and a three-dimensional numerical analysis was performed by applying the computed subgrade elastic modulus as a boundary condition. The analysis produced estimates of uplift and subsidence at the nodes along both the transverse and longitudinal directions of the structure. To determine the required amount of reinforcement (grouting volume), the nodal reinforcement depth obtained from the analysis was applied to a grid-based volumetric calculation method. The nodal intervals were subdivided to the maximum feasible extent, and rectangular grids with sufficient resolution were established to ensure accurate reinforcement-volume calculation. The reinforcement volumes estimated through the numerical analysis were compared with actual field values to assess the adequacy of the foundation reinforcement. Some differences were observed, which were attributed to field constraints that prevented reinforcements at certain required locations. Based on these findings, additional reinforcements can be applied at the analytically identified locations to ensure the structural safety of the subway box structure. Full article

In response to the increasing structural damage, reduced load-bearing capacity, and diminished durability of heavy-haul railway culverts under heavy axle load transportation conditions, this study focuses on the application of assembled corrugated plates to reinforce diseased culverts. Through engineering applications, numerical simulations, and field tests, the research investigates reinforcement techniques, analyzes parameter influences, and evaluates effectiveness. The results demonstrate that the integration of corrugated plates with existing culverts forms a composite structure, enhancing overall stiffness by sharing loads. Under identical conditions of corrugation height, pitch, and grout layer thickness, arc-shaped corrugated plates exhibit smaller mid-span deflections and stresses compared to triangular and rectangular profiles, with arc-shaped plates showing superior reinforcement performance. The sensitivity analysis results indicate that the waveform is the most sensitive parameter affecting the reinforcement performance. With the waveform fixed, the corrugation height has a relatively significant influence on the reinforcement effectiveness, followed by the corrugation pitch, while the influence of the grout layer thickness is negligible. Field trials on 14 diseased culverts with varying spans demonstrate that corrugated plate reinforcement reduces mid-span deflections and steel reinforcement strains by an average reduction exceeding 40%, with deflection reductions slightly outpacing strain reductions. These findings validate the substantial effectiveness of corrugated plate reinforcement in heavy-haul railway culvert rehabilitation. Full article

Under dual challenges of global infrastructure expansion and industrial solid waste management, alkali-activated polymers (AAP), as industrial solid-waste-based low-carbon cementitious materials, exhibit immense potential in grouting engineering applications. This review synthesizes current research progress through three critical dimensions: reaction mechanisms, performance characteristics, and grouting applications (grouting for reinforcement and water-blocking). The reaction mechanism universally comprises three stages: dissolution, depolymerization, and polycondensation. Key performance determinants include precursor composition (e.g., slag, fly ash, metakaolin) and alkaline activator properties (type, modulus, concentration). The multifunctional advantages of AAP are fundamentally governed by their microstructural evolution. Specifically, the rapid formation of highly cross-linked C-(A)-S-H and N-A-S-H gels directly contributes to rapid setting and high early strength development, with high-calcium precursors such as slag exhibiting faster strength gain than low-calcium systems, such as fly ash and metakaolin. Furthermore, the absence of vulnerable calcium hydroxide phases, combined with a densified, low-porosity aluminosilicate network, provides superior thermal stability, corrosion resistance, frost durability, and low permeability. Nevertheless, pronounced autogenous shrinkage and drying shrinkage, driven by mesopore moisture loss and the highly viscoelastic solid skeleton, remain primary constraints for field implementation. In grouting reinforcement, AAP can effectively enhance the strength and structural integrity of weak soils, such as soft clay, loess, and sulfate-rich saline soils. For grouting water-blocking, particularly in sodium-silicate-based binary systems, AAP achieves rapid gelation, superior washout resistance, and high anti-seepage pressure, proving optimal for groundwater inflow control. Future research must prioritize (i) standardized mix design protocols for performance consistency, (ii) advanced shrinkage mitigation strategies, (iii) systematic durability assessment under coupled environmental stressors (e.g., wet–dry cycling, chemical attack, thermal fatigue), and (iv) cross-disciplinary collaboration for industrial-scale validation. Full article

This study addresses the brittleness, poor bonding, and low crack resistance of ordinary Portland cement (OPC) grouting materials by incorporating an ethylene-vinyl acetate (EVA) copolymer. The enhancement mechanisms and engineering applicability of EVA-modified cement grouts were systematically investigated. Using EVA contents from 0% to 20%, macro-scale tests covering fluidity, rheology, bleeding rate, and compressive strength were conducted, along with microstructural analyses (SEM, XRD, FT-IR). Results indicate that with 12% EVA, the 28-day compressive strength reached 21.03 MPa, reflecting a 68% increase over the unmodified grout. Most favorable amount of EVA promoted the formation of C–S–H gel, filled microcracks, and enhanced structural densification, whereas excessive EVA content led to the formation of a polymer film that hindered hydration and reduced strength. Furthermore, EVA effectively improved the rheological behavior of the grout, with the Vipulanandan model demonstrating superior accuracy over the Bingham model in characterizing its non-Newtonian flow. This study systematically established a quantitative–qualitative correlation between EVA content, nonlinear rheological behavior (characterized by advanced models), microstructure evolution (porosity, C–S–H, polymer film) and final macromechanics and durability. Full article

To investigate the effect of different grouting pressures on the reinforcement of fractured sandy mudstone, grouting tests, mechanical experiments, CT scanning, and SEM analysis were conducted on fractured rock samples. Based on CT data, the precise internal structure of the grouted rock samples was obtained. High-fidelity numerical models were constructed in ABAQUS through image processing and mesh mapping techniques and then imported into ANSYS for uniaxial compression simulation. The results showed that under grouting pressures of 1 MPa, 3 MPa, and 5 MPa, the compressive strengths of the samples were 10.08 MPa, 12.39 MPa, and 13.28 MPa, corresponding to increases of 22.9% and 7.2%, respectively. The elastic moduli were 1.16 GPa, 1.52 GPa, and 1.63 GPa, with increases of 31% and 7.2%, respectively. The toughness index and brittleness index exhibited opposite trends: the toughness index increased from 1.6555 to 1.7135 and then to 1.7648 (rises of 3.5% and 2.9%), while the brittleness index decreased from 1.5255 to 1.4020 and then to 1.3075 (reductions of 8.1% and 6.7%). The ductility index rose from 1.8760 to 2.0972 and then to 2.2637 (increases of 11.8% and 7.9%). The failure mode of the grouted rock samples shifted from brittle to ductile behavior, with the most pronounced overall mechanical improvement observed at 3 MPa grouting pressure. SEM analysis indicated that as the grouting pressure increased, the dominant crack type changed from large cracks to micro-cracks. At 3 MPa, the grout fully penetrated micro-pores and enhanced the sample’s integrity, whereas at 5 MPa, excessive grouting pressure induced damage to the rock matrix itself. Fracture simulations further demonstrated that as the grouting pressure increased from 1 MPa to 3 MPa and above, the failure mode shifted from being controlled by pre-existing fractures to a holistic rupture involving both the grout and the rock matrix, leading to significantly improved structural integrity. This study establishes an integrated numerical simulation approach of “CT scanning—in situ modeling—mechanical analysis”, providing a scientific basis for optimizing grouting parameters. Full article

To compare the mechanical performance differences between sleeve grouting lap and butt joints, a total of 41 lap joints, including 27 standard lap joints and 14 anti-deflection lap joints, and 20 butt joints were subjected to tensile and high-stress cyclic tensile-compression tests. The results indicate that both types of joints failed by tensile fracture of the rebars in uniaxial tension, with the load-bearing capacity, total elongation at maximum force, and ductility generally meeting the code requirements. In high-stress cyclic tests, the load-bearing capacity of both types of joints increased, while the initial stiffness and ductility decreased. The residual deformation of the anti-deflection lap joints and butt joints generally met the specification requirements. Anti-deflection measures can reduce the residual deformation of lap joints; however, their constraint stiffness is limited, resulting in slightly greater residual deformation of lap joints compared to butt joints. After the completion of the high-stress cyclic tensile–compression tests, the maximum longitudinal strain near the reinforcement side of the sleeve’s middle cross-section in lap joints and the absolute value of the maximum circumferential compressive strain were both less than those in butt joints, indicating that lap joints have lower tensile performance requirements for the sleeve. Based on experimental results, a lap length of 12.5 d is recommended, with an additional 4–6 d allowance to enhance splice reliability under high-stress cyclic loading. Full article

With the increasing density of urban underground space development, the soil disturbance induced by large-section rectangular pipe jacking poses a significant threat to the safety of underlying subway tunnels. Taking the Lihe Road utility tunnel project in Wuhan, which crosses over Metro Line 4, as the engineering background, a three-dimensional finite element (FE) model was established using Midas GTS NX to simulate the entire pipe jacking process. Field monitoring data from caisson excavation, ground improvement, pipe jacking, and backfill grouting were introduced for validation, enabling a systematic investigation of the influence mechanism of pipe jacking on existing tunnels. In the numerical simulation, the modified Mohr–Coulomb constitutive model was adopted for the soil, and a “portal-type” reinforcement system was introduced. The pipe jacking process was simulated equivalently with a 1.2 m advance per cycle. The results indicate that the ground settlement induced by pipe jacking exhibits a stage-wise accumulation pattern and eventually develops into a stable settlement trough. The vertical settlement of the tunnel follows an evolutionary law of “early occurrence in the near field, delayed response in the far field, and final convergence,” with peak settlements of 2.44 mm and 2.53 mm for the left and right lines, respectively. Ground improvement significantly mitigates soil deformation, reducing the maximum surface settlement from 45.5 mm to 11.1 mm, decreasing the tunnel’s peak vertical settlement by 37%, and reducing horizontal displacement by 64%, thereby effectively suppressing lateral soil extrusion. The proposed closed-loop analysis method of “numerical simulation–monitoring validation–measure evaluation” reveals the spatiotemporal evolution law of soil–tunnel interaction during pipe jacking construction and provides valuable reference for risk control in similar engineering projects. Full article

Aiming at technical challenges such as the insufficient bearing capacity of orifice formation leading to slurry overflow and non-uniform formation reinforcement in soft soil layer grouting engineering, an external cyclic grouting process through the grouting pipe is innovatively proposed. Distinguished from traditional in-hole circulation methods, this process achieves bottom-up cyclic grouting through a slurry return channel outside the grouting hole, which effectively reduces the risk of orifice fracturing and improves grouting uniformity. A grouting pressure loss equation is established to quantitatively analyze the relationships between the allowable grouting pressure and the side wall opening of the grouting pipe, slurry rheological parameters, surface consolidation depth, and surface consolidation strength. It is revealed that slurry with high viscosity and low yield stress is suitable for deep grouting, and a design criterion innovatively proposes that the side wall opening of the grouting hole should dynamically increase with the grouting depth. Based on the strain–pressure curve, a prediction model for the reinforcement radius of compaction grouting is established. Slurry rheological parameters and formation mechanical parameters are obtained through laboratory tests, and field grouting tests are conducted. The reinforcement effect is verified by means of ground-penetrating radar and standard penetration tests. The results show that, compared with traditional grouting processes, this process significantly improves the bearing capacity of the orifice and enhances the uniformity and compactness of formation reinforcement and that the theoretical prediction error of the reinforcement radius is less than 15%. The research results provide the theoretical basis and technical support for soft soil grouting engineering and have important engineering application value. Full article

To investigate the stability of surrounding rock and support structures during tunnel excavation through karst cave groups, this study adopts an integrated methodology of laboratory tests and numerical simulations. The influence of cave groups with different spatial orientations relative to the tunnel (α = 90°, 45°, 0°, −45°, −90°) is systematically evaluated in terms of surrounding rock deformation, plastic zone development, and support structure loading. Results indicate that spatial orientation significantly affects rock mass stability. The cave groups positioned horizontally to the tunnel (α = 0°) induce the most extensive plastic zone penetration, representing the highest risk scenario. For this critical case, a safety distance threshold of L = 1.8D is proposed. When cavities intrude into the tunnel profile, localized deformation effects become pronounced. Remedial grouting with C25 concrete proves effective, reducing crown uplift, crown settlement, and horizontal convergence at the arch waist by 35.43%, 13.17%, and 58.09%, respectively. Under horizontal-side intrusion conditions, initial support stress increases markedly—nearly doubling compared to other orientations—necessitating targeted reinforcement measures. These findings offer practical guidance for the safe design and construction of tunnels in karst regions. Full article

Post-grouting is an active reinforcement technique that can significantly enhance the bearing performance of bored piles. This study conducted field tests on three in situ test piles using tip grouting, side grouting, and combined tip-side grouting. Based on the analysis of static load test data, the improvement effects of different grouting methods on the vertical bearing behavior of the piles were quantified. In situ tests were then performed to elucidate the reinforcement mechanisms of various post-grouting techniques on the pile foundations. Based on the validated finite element model, the study explored the influence of key grouting parameters on the bearing performance of grouted piles. Analysis of the test data shows that all grouting methods improved the vertical bearing capacity of bored piles. The positive effect of tip grouting was more pronounced than that of side grouting. Furthermore, in the clay layer of the soft soil region, side grouting primarily manifested as splitting grouting, while tip grouting formed a hardened grout bulb at the pile tip through cementation and solidification, thereby significantly enhancing the mobilization of the pile tip bearing capacity. Finite element model analysis shows that, in terms of enhancing the bearing capacity of the pile, expanding the grout diffusion range is more effective than increasing the grout material strength. Full article

Blasting-induced vibrations from new tunnel construction pose a significant threat to the structural safety of existing tunnel linings due to dynamic stress concentration. To address this, this study establishes a transient-response analytical model for composite lining tunnels using wave function expansion and a combination of the Duhamel integral and Fourier transform methods. Through a case study of the Hongshan South Road Tunnel, the research systematically quantifies the influence of critical factors such as load rise time, lining thickness, and material stiffness. Numerical results reveal that under blasting P-wave action, the inner vault of the secondary lining exhibits the most significant dynamic stress concentration, identifying it as the primary vulnerable zone. Furthermore, peak dynamic stress and vibration velocity increase sharply as the load rise time decreases, indicating that short-duration, high-intensity impacts present the greatest hazard. To mitigate these effects, the study identifies several optimization strategies: increasing the thickness of the initial support and employing high-modulus materials effectively reduce stress peaks. Specifically, maintaining the elastic modulus ratio of the surrounding rock to the initial support at approximately 2.0 provides an optimal balance for enhancing blast resistance. The findings suggest that tunnel design should prioritize optimizing the stiffness of the initial support and utilizing grouting to reinforce the surrounding rock. This research provides a robust theoretical framework and specific parameter optimization directions for the seismic and blast-resistant design of composite lining tunnels. Full article
