To address the issue of restricted grout diffusion caused by seepage effects during grouting in sandy soil layers, this study proposes an optimised grouting method for water-based polyurethane-cement composite grout (WPU-CS) under vacuum-pressure synergy. By establishing a porous medium flow model based on the mass conservation equation and linear filtration law, the influence mechanism of cement particle seepage effects was quantitatively characterised. An orthogonal test (L₉(3⁴)) optimised the grout composition, determining the optimal parameter combination as the following: water-to-cement ratio 1.5:1, polyurethane-to-cement ratio 5~10%, magnesium aluminium silicate content 1%, and hydroxypropyl methylcellulose content 0.15%. Vacuum permeation grouting tests demonstrated that compared to pure cement slurry, WPU-CS reduced filter cake thickness by 80%, significantly suppressing the leaching effect (the volume fraction $\delta$ of cement particles exhibited exponential decay with increasing distance $r$ from the grouting end, and the slurry front velocity gradually decreased). Concurrently, the porosity $\varphi$ in the grouted zone showed a gradient distribution (with more pronounced porosity reduction near the grouting end). When vacuum pressure increased from −10 kPa to −30 kPa, slurry diffusion distance rose from 11 cm to 18 cm (63.6% increase). When grouting pressure increased from 20 kPa to 60 kPa, diffusion distance increased from 8 cm to 20 cm (150% increase). The study confirms that synergistic control using WPU-CS with moderate grouting pressure and high vacuum effectively balances seepage suppression and soil stability, providing an innovative solution for efficient sandy soil reinforcement. Full article

As Earth Pressure Balance (EPB) shield machine crossed with steep slopes beneath an existing highway in sandstone–mudstone alternating strata, case studies of changes in vertical displacement, settlement trough evolution, and tunnel stress induced by shield tunnel construction were investigated. The quality of synchronous grouting was evaluated using ground penetrating radar (GPR) technology. The results showed that highway settlement could be categorized into four stages: initial settlement, uplift, secondary settlement, and stabilization. The secondary settlement caused by shield tail detachment was significantly greater than the initial settlement induced by distant shield construction. The settlement trough evolved throughout construction; the maximum settlement point shifted from the tunnel centerline but it consistently remained within 3 m. During the early phase of shield tail detachment, the circumferential stress of shield tunnel changed rapidly. The circumferential stress was primarily compressive, tensile stress was observed at some monitoring points. The tensile stress at the monitoring points gradually transitioned to compressive stress. After the tunnel undercrossed, the circumferential stress gradually stabilized. The GPR detection revealed that in groundwater-rich strata, poor grouting quality areas were prone to appear at the tunnel crown, while grouting quality in other areas performed better. This engineering case can serve as a positive reference for similar EPB shield tunnels passing in close proximity beneath existing highways. Full article

Grout voids in external tendons of post-tensioned bridges are a critical issue, as they may result in the corrosion of the steel strands and significantly reduce tendon strength. Therefore, preventing tendon failure necessitates thorough inspection for these voids during both construction and operation. Terahertz electromagnetic wave testing is an effective method for detecting voids between the protective duct and the grout in external tendons, as terahertz waves can penetrate through the protective duct. This study introduces a D-band electronic frequency-modulated continuous-wave terahertz A-scanner for enhanced real-time inspection. The proposed method offers key advantages such as miniaturization, cost-effectiveness, and robustness, while providing effective detection of voids beneath the duct in external tendons. It is indicated that voids with a thickness of approximately 2.5 mm or greater can be detected using the D-band THz A-scanner. Full article

To address the stability control challenges of narrow coal pillar roadways along goaf-sides affected by thick coal seam secondary mining, this study investigates the 51507 track gateway in Liuyuanzi Coal Mine through theoretical analysis, numerical simulation, and field testing. The research focuses on stress evolution and energy distribution characteristics during secondary mining extraction. Key findings include the following: (1) Under the superimposed influence of goaf-side abutment pressure and secondary mining front abutment pressure, roadway surrounding rock exhibits regional asymmetric characteristics in energy dissipation. (2) Within 10 m ahead of the secondary mining face, the coal pillar experiences intense energy dissipation and plastic zone penetration, leading to bearing structure failure. (3) The energy mechanism reveals that asymmetric dissipative energy distribution drives plastic zone expansion. Accordingly, an integrated control strategy combining differentiated support (bolts/cables + tension-type opposite anchor cables + hydraulic props) with coal pillar grouting modification was developed. Field implementation demonstrated effective control of surrounding rock deformation within 200 mm. This study provides theoretical foundations and technical references for roadway stability control under similar mining conditions. Full article

A polyurethane slurry was developed to simultaneously enhance the strength and permeability of geological formations, differing from the conventional fracture grouting used for soft-soil reinforcement. Injected via splitting grouting, the slurry cures to form high-strength, highly permeable channels that increase reservoir permeability while improving mechanical stability (dual-enhanced stimulation). To quantify its diffusion behavior and guide field application, we built a splitting-grouting model using the finite–discrete element method (FDEM), parameterized with the reservoir properties of coalbed methane (CBM) formations in the Ordos Basin and the slurry’s measured rheology and filtration characteristics. Considering the stratified structures within coal rock formed by geological deposition, this study utilizes Python code interacting with Abaqus to divide the coal seam into coal rock and natural bedding. We analyzed the effects of engineering parameters, geological factors, and bedding characteristics on slurry–vein propagation patterns, the stimulation extent, and fracturing pressure. The findings reveal that increasing the grouting rate from 1.2 to 3.6 m³/min enlarges the stimulated volume and the maximum fracture width and raises the fracturing pressure from 26.28 to 31.44 MPa. A lower slurry viscosity of 100 mPa·s promotes the propagation of slurry veins, making it easier to develop multiple veins. The bedding-to-coal rock strength ratio controls crossing versus layer-parallel growth: at 0.3, veins more readily penetrate bedding planes, whereas at 0.1 they preferentially spread along them. Raising the lateral pressure coefficient from 0.6 to 0.8 increases the likelihood of the slurry expanding along the beddings. Natural bedding structures guide directional flow; a higher bedding density (225 lines per 10,000 m³) yields greater directional deflection and a more intricate fracture network. As the angle of bedding increases from 10° to 60°, the slurry veins are more susceptible to directional changes. Throughout the grouting process, the slurry veins can undergo varying degrees of directional alteration. Under the studied conditions, both fracturing and compaction grouting modes are present, with fracturing grouting dominating in the initial stages, while compaction grouting becomes more prominent later on. These results provide quantitative guidance for designing dual-enhanced stimulation to jointly improve permeability and mechanical stability. Full article

Grout propagation is a critical aspect of fracture grouting. This study investigated grout propagation at fracture intersections under flowing conditions using a simplified two-dimensional (2D) fracture network. Transparent soil technology was employed to simulate the porous filling material within the fractures. The results showed that the penetration velocity of grout decreased significantly after passing through an intersection, and the velocity in the main fracture was consistently higher than that in the branch fractures. In the unfilled fracture network, the diffusion ratio between branch and main fractures ranged from 0.35 to 0.88, whereas after filling, it ranged from 0.71 to 0.86. For each intersection, the ratio of grout length in the downstream branch to that in the main fracture (RDM) was positively correlated with branch width. This trend was especially evident in unfilled fractures, whereas in filled fractures, the increase in RDM was much less pronounced. Regarding the upstream ratio (RUM), it was consistently lower than RDM. RUM increased with branch width in unfilled fractures but decreased in filled fractures. Additionally, higher fluid velocity amplified these anisotropic propagation behaviors. Based on the simplified filled fracture model, it was concluded that porous filling materials reduce permeability differences between fractures with different aperture widths. Furthermore, increased flow rate intensified the anisotropic diffusion of grout. This study provides valuable insight into the mechanism of anisotropic grout propagation and offers guidance for engineering grouting applications. Full article

The layered composite roof of a coal mine roadway exhibits heterogeneity, with pronounced variations in layer thickness and strength. Fully grouted rock bolts installed in such layered roofs usually penetrate two or more strata and bond with them to form an integrated anchorage system. Roof failure typically initiates in the shallow strata and progressively propagates to deeper layers; thus, the mechanical properties of the rock at the free surface critically influence the overall stability of the layered roof and the load-transfer behavior of the bolts. In this study, a layered rock mass model was developed using three-dimensional particle flow code (PFC3D), and a triaxial loading scheme with a single free surface was applied to investigate the effects of free-surface rock properties, support parameters, and confining pressure on the load-bearing performance of the layered rock mass. The main findings are as follows: (1) Without support, the ultimate bearing capacity of a hard-rock-free-surface specimen is about 1.2 times that of a soft-rock-free-surface specimen. Applying support strengths of 0.2 MPa and 0.4 MPa enhanced the bearing capacity by 29–38% and 46–75%, respectively. (2) The evolution of axial stress in the bolts reflects the migration of the load-bearing core of the anchored body. Enhancing support strength improves the stress state of bolts and effectively mitigates the effects of high-stress conditions. (3) Under loading, soft rock layers exhibit greater deformation than hard layers. A hard-rock free surface effectively resists extrusion deformation from deeper soft rocks and provides higher bearing capacity. Shallow free-surface failure is significantly suppressed in anchored bodies, and “compression arch” zones are formed within multiple layers due to bolt support. Full article

This study presents a 3D fracture network modeling approach for designing curtain grouting systems in building foundations, utilizing geological mapping data from the Dongzhuang Project. A one-dimensional Markov chain model is applied to simulate the transitions in fracture density, while fracture orientation and size are characterized using Fisher and statistical distribution models. To enhance the prediction accuracy, a correction method is introduced to refine the transition matrices. The model’s reliability is validated using tunnel wall fracture data and borehole detection, demonstrating strong agreement in both trend and magnitude. In under 100,000 simulations, when the allowable absolute error is set to 1, the optimal accuracy can reach 80%. Reliability analysis confirms the robustness of the approach, with 99.91% of predictions within a ± 2 error margin. The final fracture network model effectively captures spatial heterogeneity and fracture penetration across various foundation layers; the spatial distribution density index of fractures can provide a reference basis for optimizing the layout of impermeable curtains in complex geological conditions. This integrated modeling approach offers a reliable tool for improving grouting strategies in building foundation projects and other civil infrastructure. Full article

To address the challenge of dynamic monitoring during grouting operations in coal mine fault zones under pressurized mining, this study proposes the Borehole–Tunnel Joint Resistivity Method (BTJRM). By integrating three-dimensional (3D) electrode arrays in both tunnels and boreholes with 3D resistivity inversion technology, this approach enables fully automated underground data acquisition and real-time processing, facilitating comprehensive dynamic monitoring of grout propagation. A case study was conducted on a coal mine fault grouting project, where tunnel and borehole survey lines were deployed to construct a 3D cross-monitoring network, overcoming the limitations of traditional 2D data acquisition. Finite volume method and quasi-Gauss–Newton inversion algorithms were employed to analyze dynamic resistivity variations, enhancing spatial resolution for detailed characterization of grout migration. Key findings include: (1) Grout diffusion reduced resistivity by 10%, aligning with electrical response patterns during fracture-filling stages; (2) 3D inversion reveals that grout propagates along the principal stress axis, forming a “Y”-shaped low-resistivity anomaly zone that penetrates the fault structural block and extends into roadway areas. The maximum planar and vertical displacements of grout reach 100 m and 40 m, respectively. Thirty days post-grouting, resistivity recovers by up to 22%, reflecting the electrical signature of grout consolidation; (3) This method enables 3D reconstruction of grout diffusion pathways, extends the time window for early warning of water-conducting channel development, and enhances pre-warning capabilities for grout migration. It provides a robust framework for real-time sealing control of fault strata, offering a novel dynamic monitoring technology for mine water inrush prevention. The technology can provide reliable grouting evaluation for mine disaster control engineering. Full article

As a novel seismic reinforcement measure for earth–rock dams, the PFA-reinforced rockfill materials technology lacks comprehensive investigation into both its reinforcement efficacy and the underlying mechanisms. In this study, we establish a fluid–solid coupling model of PFA-reinforced rockfill materials utilizing the matrix discrete element software MatDEM3.24, developed independently by Nanjing University. The model simulates the dynamic process of polymer grouting within the rockfill body and analyzes the impact of slurry diffusion patterns and various grouting pressures on polymer grouting. Our findings reveal that the diffusion of polymer foam in rockfill occurs in three distinct stages, which are characteristic of penetration grouting. Moreover, we observed that grouting pressure had a significant effect on the diffusion range of the slurry, with greater sensitivity noted in the Z direction. Additionally, we observed a decrease in porosity with increasing grouting pressure, and stress augmentation exhibited an approximately linear relationship with grouting pressure, but the stress augmentation in different directions was different. These research outcomes offer valuable insights into the practical implementation and optimization of PFA-reinforced rockfill materials technology, bearing considerable engineering implications. Full article

Penetration grouting is a significant grouting technique. The pore structure has important impacts on the infiltration mechanism of slurry in porous media. In this study, based on fractal theory, a theoretical penetration grouting model for Bingham fluid is established. An experimental apparatus for simulating the penetration process of Bingham fluid with a constant flow rate is developed. A series of penetration-grouting experiments are conducted to validate the theoretical model established in this study and analyze the impacts of the water–cement ratio and flow rate on the slurry injection pressure. The results show that the theoretical values of the slurry pressure along the penetration direction obtained from the penetration grouting model match the experimental values well. This indicates that the proposed model can better describe the process of slurry infiltration and provide valuable support for related grouting projects. Full article

Microbially induced carbonate precipitation (MICP) technology is employed to reinforce the surface soil of a dam, aiming to prevent erosion caused by water flow and damage to the dam slope. The relationship between penetration depth, calcium carbonate content, and bonding depth was investigated at eight measuring points on the sand slope surface of a mold under different reinforcement durations. It was observed that as grouting reinforcement times increased, there was a gradual increase in calcium carbonate content but a rapid rise in penetration resistance. Moreover, the bonding depth of sand on the bio-reinforced sand slope increased with higher levels of calcium carbonate content. Microbial grouting reinforcement enhanced soil particle bonding force, requiring water flow to overcome this force for activation of sand particles. Consequently, microbial grouting reinforcement significantly improved shear strength and critical starting flow velocity on sand slope surfaces. The experimental results demonstrated that after MICP surface treatment through spraying, a dense and water-stable hard shell layer composed of bonded calcium carbonate and soil particles formed continuously on sample surfaces, effectively enhancing the strength and erosion resistance of sandy soils. These findings provide reliable evidence for silt slope reinforcement and dam erosion prevention. Full article

Tunnel Boring Machines (TBMs) are integral to modern underground engineering construction, offering enhanced safety and efficiency. However, TBMs often face challenges in complex geological conditions, such as composite strata, resulting in reduced advancement speed and increased cutter wear. This study investigates the rock-breaking characteristics of TBM disc cutters in composite strata through numerical simulations using the Particle Flow Code (PFC) 5.0 software. Focusing on the Jinan Metro Line 6, the research analyzes cutter forces, rock crack propagation, and the impact of cutter edge shapes on rock-breaking efficiency. The discrete element method (DEM) is employed to simulate microscopic behaviors of rocks, providing insights into crack formation, expansion, and failure. This study’s findings reveal that cutter design and operational parameters can significantly influence cutter lifespan and efficiency. By modifying cutter spacing and penetration depth, enhancing rock-breaking efficiency, and grouting softer layers, TBMs can maintain effective excavation in composite strata. The study establishes a comprehensive understanding of the interplay between TBM cutters and complex geological conditions, offering actionable strategies to enhance TBM performance and mitigate cutter damage. Full article

The issue of interfacial shear damage has been a significant challenge in the field of geotechnical engineering, particularly in the context of diaphragm walls and surrounding soils. Polymer grouting is a more commonly used repair and reinforcement method but its application to interface repair and reinforcement in the field of geotechnical engineering is still relatively rare. Consequently, this paper presents a new polymer grouting material for use in grouting reinforcement at the interface between concrete and soils. The bonding characteristics and shear damage mode of the interface after grouting were investigated by the direct shear test, and the whole process of interface shear damage was investigated by digital image correlation (DIC) technology. Finally, the reinforcement mechanism was analyzed by microscopic analysis. The results demonstrate that the permeable polymer is capable of effectively filling the pores of soil particles and penetrating into the concrete-soil interface. Through a chemical reaction with water in the soil, the polymer cements the soil particles together, forming chemical adhesion at the interface and thereby achieving the desired reinforcement and repair effect. In the shear process, as the normal stress increased, the horizontal displacement and horizontal compressive strain at the distal end of the loading end decreased, while the maximum vertical displacement and maximum vertical strain of the cured soil also decreased. The results of scanning electron microscopy (SEM) demonstrated that the four groups of test polymers exhibited a reduction in soil porosity of 53.47%, 58.79%, 52.71%, and 54.12%, respectively. Additionally, the form of concrete-soil interfacial bonding was observed in the concrete-cohesive layer-cured soil mode. The findings of this study provide a foundation for further research on diaphragm wall repair and reinforcement. Full article

Epoxy resin, known for its excellent corrosion resistance, water resistance, and high-temperature resistance, is extensively utilized in construction and water-related projects. Within water conservancy projects, natural factors such as water impact and weathering often result in cracks within rock formations. Consequently, the application of epoxy resin materials for repair and reinforcement has emerged as a common solution. This research investigates the impact of five epoxy grouting materials, YDS (100:6.4), RH-1 (6.1:1), PSI (9:1), TK (100:8), and HK-G (5:1), on the repair and reinforcement of faulted rock at the Yebatan Hydropower Station. Penetration experiments were conducted on rock samples, and the strength of the epoxy grout samples was tested under ambient conditions of 20 °C, 15 °C, and 0 °C. The experimental results indicate that all five epoxy grout materials successfully penetrated the faulted rock samples. Among them, the PSI (9:1) epoxy grouting material exhibited the most exceptional reinforcing effect across different temperatures, with grouting samples demonstrating strengths in the range of 20 to 25 MPa. This paper confirms that epoxy resin effectively repairs and reinforces rock structures, thereby enhancing the safety and durability of water conservancy projects. Full article
