With the accelerating global transition toward sustainable energy systems, power grids with a high share of renewable energy face increasing challenges due to volatility and uncertainty, necessitating advanced flexibility resource planning and stability optimization strategies. This paper presents a comprehensive distribution network planning framework that coordinates and integrates multiple types of flexibility resources through joint optimization and network reconfiguration to enhance system adaptability and operational resilience. A novel virtual network coupling modeling approach is proposed to address topological constraints during network reconfiguration, ensuring radial operation while allowing rapid topology adjustments to isolate faults and restore power supply. Furthermore, to mitigate the uncertainty and fault risks associated with extreme weather events, a CVaR-based risk quantification framework is incorporated into a bi-level optimization model, effectively balancing investment costs and operational risks under uncertainty. In this model, the upper-level planning stage optimizes the siting and sizing of flexibility resources, while the lower-level operational stage coordinates real-time dispatch strategies through demand response, energy storage operation, and dynamic network reconfiguration. Finally, a hybrid SA-PSO algorithm combined with conic programming is employed to enhance computational efficiency while ensuring high solution quality for practical system scales. Case study analyses demonstrate that, compared to single-resource configurations, the proposed coordinated planning of multiple flexibility resources can significantly reduce the total system cost and markedly improve system resilience under fault conditions. Full article

In the modern era of smart grids, integrating advanced Geographic Information Systems (GISs) with protection coordination functionalities is pivotal for enhancing the reliability and efficiency of distribution networks. This paper presents an implementation of a web-based distribution network GIS platform that seamlessly integrates distribution system feeder GIS monitoring with the system model file layout, fault current analysis, and coordination simulation functions. The system can provide scalable and accessible solutions for power utilities, ensuring that protective devices operate in a coordinated manner to minimize outage impacts and improve service restoration times. The proposed GIS platform has demonstrated significant improvements in fault management and relay coordination through extensive simulation and field testing. This research advances the capabilities of distribution network management and sets a foundation for future enhancements in smart grid technology. Full article

This work proposes an effective control technique for enhancing the stability of Doubly Fed Induction Generator-Based Wind Turbines (DFIG-WTs) connected to the grid during voltage sag and swell events, ensuring the reliable and efficient operation of wind energy systems integrated with the grid. The proposed approach integrates a Dynamic Voltage Restorer (DVR) in series with a Wind Turbine Generator (WTG) output terminal to enhance the Fault Ride-Through (FRT) capability during grid disturbances. To develop a flexible control strategy for both unbalanced and balanced fault conditions, a combination of feedforward and feedback control based on a sliding mode control (SMC) for DVR converters is used. This hybrid strategy allows for precise voltage regulation, enabling the series compensator to inject the required voltage into the grid, thereby ensuring constant generator terminal voltages even during faults. The SMC enhances the system’s robustness by providing fast, reliable regulation of the injected voltage, effectively mitigating the impact of grid disturbances. To further enhance system performance, Model Predictive Control (MPC) is implemented for the Rotor-Side Converter (RSC) within the back-to-back converter (BTBC) configuration. The main advantages of the predictive control method include eliminating the need for linear controllers, coordinate transformations, or modulators for the converter. Additionally, it ensures the stable operation of the generator even under severe operating conditions, enhancing system robustness and dynamic response. To validate the proposed control strategy, a comprehensive simulation is conducted using a 2 MW DFIG-WT connected to a 120 kV grid. The simulation results demonstrate that the proposed control approach successfully limits overcurrent in the RSC, maintains electromagnetic torque and DC-link voltage within their rated values, and dynamically regulates reactive power to mitigate voltage sags and swells. This allows the WTG to continue operating at its nominal capacity, fully complying with the strict requirements of modern grid codes and ensuring reliable grid integration. Full article

Aiming at the transient synchronization instability problem of grid-forming energy storage under a fault in the grid-connected inverter, this paper proposes an adaptive transient synchronization support strategy for grid-forming energy storage facing inverter faults. First, the equal area rule is employed to analyze the transient response mechanism of the grid-forming energy storage grid-connected inverter under faults, revealing the negative coupling relationship between active power output and transient stability, as well as the positive coupling relationship between reactive power output and transient stability. Based on this, through the analysis of the dynamic characteristics of the fault overcurrent, the negative correlation between the fault inrush current and impedance and the positive correlations among the fault steady-state current, active power, and voltage at the point of common coupling are identified. Then, a variable proportional–integral controller is designed to adaptively correct the active power reference value command, and the active power during the fault is gradually restored via the frequency feedback mechanism. Meanwhile, the reactive power reference value is dynamically adjusted according to the voltage at the point of common coupling to effectively support the voltage. Finally, the effectiveness of the proposed strategy is verified in MATLAB/Simulink. Full article

Doubly Fed Induction Generator (DFIG)-based Wind Energy Systems (WESs) have become increasingly prominent in the global energy sector, owing to their superior efficiency and operational flexibility. Nevertheless, DFIGs are notably vulnerable to fluctuations in the grid, which can result in power quality issues—including voltage swells, sags, harmonic distortion, and flicker—while also posing difficulties in complying with Fault Ride-Through (FRT) standards established by grid regulations. To address the previously mentioned challenges, this paper develops an integrated approach utilizing a Dynamic Voltage Restorer (DVR) in conjunction with a Lithium-ion storage system. The DVR is coupled in series with the WES terminal, while the storage system is coupled in parallel with the DC link of the DFIG through a DC/DC converter, enabling rapid voltage compensation and bidirectional energy exchange. Simulation results for a 2 MW WES employing DFIG modeled in MATLAB/Simulink demonstrate the efficacy of the proposed system. The approach maintains terminal voltage stability, reduces Total Harmonic Distortion (THD) to below 0.73% during voltage sags and below 0.42% during swells, and limits DC-link voltage oscillations within permissible limits. The system also successfully mitigates voltage flicker (THD reduced to 0.41%) and harmonics (THD reduced to 0.4%), ensuring compliance with IEEE Standard 519. These results highlight the proposed system’s ability to enhance both PQ and FRT capabilities, ensuring uninterrupted wind power generation under various grid disturbances. Full article

The increasing penetration of renewable energy sources (RESs) has significantly altered the operational characteristics of modern power systems, resulting in reduced system inertia and fault current capacity. These developments introduce new challenges for maintaining frequency and voltage stability, particularly in low-inertia grids that are dominated by inverter-based resources (IBRs). This paper presents a hierarchical control framework that integrates synchronous condensers (SCs) and grid-forming (GFM) inverters through a leader–follower consensus control architecture to address these issues. In this approach, selected GFMs act as leaders to restore nominal voltage and frequency, while follower GFMs and SCs collaboratively share active and reactive power. The primary control employs droop-based regulation, and a distributed secondary layer enables proportional power sharing via peer-to-peer communication. A modified IEEE 14-bus test system is implemented in PSCAD to validate the proposed strategy under scenarios including load disturbances, reactive demand variations, and plug-and-play operations. Compared to conventional droop-based control, the proposed framework reduces frequency nadir by up to 0.3 Hz and voltage deviation by 1.1%, achieving optimised sharing indices. Results demonstrate that consensus-based coordination enhances dynamic stability and power-sharing fairness and supports the flexible integration of heterogeneous assets without requiring centralised control. Full article

The Tankou area is a vital production capacity replacement area in the Jianghan oilfield. The recovery of the amount of erosion in Qianjiang Formation and Jinghezhen Formation is significant for studying this area’s tectonic evolution and geothermal history. The target layer, characterised by well-developed plastic materials, intense tectonic deformation, and insufficient well data, fails to meet the applicability criteria of the conventional denudation estimation methods. This study proposes a novel approach based on the structural strain characteristics. The method estimates the stratigraphic denudation by analysing residual formation features and fault characteristics. First, a stress analysis is performed using the fault characteristics, and the change law for the thickness of the target layer is summarised based on the characteristics of the residual strata to recover the amount of erosion in the profile. Second, a grid of the stratigraphic lines in the profiles of the main line and the tie line is used to complete the recovery of the amount of erosion in the plane through interpolation, and the results of the profile recovery are corrected again. Finally, the evolution results of the geological equilibrium method and the stress–strain analysis are compared to analyse the reasonableness of their differences and verify the accuracy of the erosion recovery results. The area of erosion in each layer increases from bottom to top. The amount of denudation in each layer gradually increases from the denudation area near the southern slope to the surrounding area. It converges to 0 at the boundary of the denudation area. The maximum amount of erosion is distributed in the erosion area close to the side of the residual layer with a low dip angle. The specific denudation results are as follows: Qian1 Member + Jinghezhen Formation has a denudation area of 6.3 km² with a maximum denudation thickness of 551 m; Qian2 Member has a denudation area of 2.6 km² with a maximum denudation thickness of 164 m; Qian3 Member has a denudation area of 2.3 km² with a maximum denudation thickness of 215 m; Upper Qian4 Submember has a denudation area of 1.54 km² with a maximum denudation thickness of 191 m; and Lower Qian4 Submember has a denudation area of 1.2 km² with a maximum denudation thickness of 286 m. This method overcomes the conventional denudation restoration approaches’ reliance on well logging and geochemical parameters. Using only seismic interpretation results, it achieves relatively accurate denudation restoration in the study area, thereby providing reliable data for timely analyses of the tectonic evolution, sedimentary facies, and hydrocarbon distribution patterns. In particular, the fault displacement characteristics can be employed to promptly examine how reasonable the results on the amount of denudation between faults are during the denudation restoration process. Full article

The growing integration of DG enhances distribution network resilience, but existing centralized fault recovery strategies face critical limitations: excessive computational burdens on DCs and the insufficient utilization of local control capabilities, particularly with large-scale DG deployments. Current studies often fail to balance computational efficiency and dynamic recovery coordination between centralized and decentralized resources. To address the issue, a hierarchical control architecture is proposed that involves collaboration between the DC and LA energy gateways. By dynamically quantifying LA PSC through net power feasibility analysis, the framework optimizes network reconfiguration (DC level) and decentralized DG scheduling (gateway level). Validated on a modified IEEE 45-bus system, the strategy restored 7 MWh (4:00 fault) and 5 MWh (10:00 fault) of load, outperforming static methods by 26.9× in the mid-day case. While effective in urban grids, rural DG-sparse areas require future integration of mobile storage. The work balances centralized coordination and decentralized execution, offering a scalable resilience solution for modern networks. Full article

The occurrence of extreme disasters, such as seismic hazards, can significantly disrupt transportation and distribution networks (DNs), consequently impacting the post-disaster recovery process. Restoring load using distributed generation represents an important approach to improving the resilience of DNs. However, using these resources to provide resilience is not enough to justify having them installed economically. Therefore, this paper proposes a two-stage stochastic mixed-integer programming (SMIP) model for the configuration of stationary energy storage systems (SESSs) and mobile energy storage systems (MESSs) during earthquakes. The proposed model comprehensively considers both normal and disaster operation scenarios of DNs, maximizing the grid’s economic efficiency and security. The first stage is to make decisions about the location and size of energy storage, using a hybrid configuration scheme of second-life batteries (SLBs) for SESSs and fresh batteries for MESSs. In the second stage, the operating costs of DNs are evaluated by minimizing normal operating costs and reducing load loss during seismic events. Additionally, this paper proposes a scenario reduction method based on hierarchical sampling and distance reduction to generate representative fault scenarios under varying earthquake magnitudes. Finally, the progressive hedging algorithm (PHA) is employed to solve the model. The case studies of the IEEE 33-bus and 12-node transportation network are conducted to validate the effectiveness of the proposed method. Full article

The subway power supply system, as a critical component of urban rail transit infrastructure, plays a pivotal role in ensuring operational efficiency and safety. However, current systems remain heavily dependent on manual interventions for fault diagnosis and recovery, limiting their ability to meet the growing demand for automation and efficiency in modern urban environments. While the concept of “self-healing” has been successfully implemented in power grids and distribution networks, adapting these technologies to subway power systems presents distinct challenges. This review introduces an innovative approach by integrating multi-agent systems (MASs) with advanced artificial intelligence (AI) algorithms, focusing on their potential to create fully autonomous self-healing control architectures for subway power networks. The novel contribution of this review lies in its hybrid model, which combines MASs with the IEC 61850 communication standard to develop fault diagnosis, isolation, and recovery mechanisms specifically tailored for subway systems. Unlike traditional methods, which rely on centralized control, the proposed approach leverages distributed decision-making capabilities within MASs, enhancing fault detection accuracy, speed, and system resilience. Through a thorough review of the state of the art in self-healing technologies, this work demonstrates the unique benefits of applying MASs and AI to address the specific challenges of subway power systems, offering significant advancement over existing methodologies in the field. Full article

This paper proposes a grid-forming (GFM) photovoltaic system transient control strategy based on the combination of dynamic virtual impedance and the radial basis function (RBF) algorithm. First, the virtual synchronous generator (VSG) model is analyzed to understand how virtual impedance affects current surges and system stability during faults. By using dynamic virtual impedance throughout the fault, the strategy suppresses current spikes and improves stability. The RBF neural network dynamically adjusts virtual inertia and damping coefficients to optimize transient power-angle characteristics and speed up recovery during fault restoration. Simulation results show that the strategy reduces transient current surges, improves angle recovery, and boosts system stability during voltage sag. This approach offers an effective solution for low-voltage ride-through (LVRT) and transient control in photovoltaic grid-connected systems, ensuring the resilience and stability of renewable energy integration into the grid. Full article

With the increasing complexity of the distribution network structure, enhancing the efficiency and reliability during fault restoration has become a focal point. Based on the multi-source information collected by traditional sensors, such as CT and PT, and intelligent sensors, such as D-PMU, and the graph calculation model, the fault recovery problem of a multi-objective distribution network is studied. Firstly, a power flow calculation model and operation constraint adaptable to topology changes are proposed under the graph calculation framework. The minimum spanning tree theory is utilized to define the blackout range and recovery path set. Secondly, the intelligent sensor D-PMU is configured to collect fault information to ensure that at least one of any two connected load vertices is configured with D-PMU. Thirdly, a topological evolution model is established that considers repeated primary and secondary transfer in outage areas while exploring possible recovery strategies deeply. Finally, a distribution network in Shaanxi Province is taken as an example to verify the model. The experiment shows that the strategy in this paper dynamically adjusts the recovery strategy through four means—one transfer, one repeat transfer in the outage area, two transfers, and cutting off part of the outage load—and the overall recovery rate is increased by more than 20%. Full article

The elevated penetration of renewable energy has seen a significant increase in the integration of inverter-based resources (IBRs) into the electricity network. According to various industrial standards on interconnection and interoperability, IBRs should be able to withstand variability in grid conditions. Positive sequence voltage-oriented control (PSVOC) with a feed-forward decoupling approach is often adopted to ensure closed-loop control of inverters. However, the dynamic response of this control scheme deteriorates during fluctuations in the grid voltage due to the sensitivity of proportional–integral controllers, the presence of the direct- and quadrature-axis voltage terms in the cross-coupling, and predefined saturation limits. As such, a twin delayed deep deterministic policy gradient-based voltage-oriented control (TD3VOC) is formulated and trained to provide effective current control of inverter-based resources under various dynamic conditions of the grid through transfer learning. The actor–critic-based reinforcement learning agent is designed and trained using the model-free Markov decision process through interaction with a grid-connected photovoltaic inverter environment developed in MATLAB/Simulink^® 2023b. Using the standard PSVOC method results in inverter input voltage overshoots of up to 2.50 p.u., with post-fault current restoration times of as high as 0.55 s during asymmetrical faults. The designed TD3VOC technique confines the DC link voltage overshoot to 1.05 p.u. and achieves a low current recovery duration of 0.01 s after fault clearance. In the event of a severe symmetric fault, the conventional control method is unable to restore the inverter operation, leading to integral-time absolute errors of 0.60 and 0.32 for the currents of the d and q axes, respectively. The newly proposed agent-based control strategy restricts cumulative errors to 0.03 and 0.09 for the d and q axes, respectively, thus improving inverter regulation. The results indicate the superior performance of the proposed control scheme in maintaining the stability of the inverter DC link bus voltage, reducing post-fault system recovery time, and limiting negative sequence currents during severe asymmetrical and symmetrical grid faults compared with the conventional PSVOC approach. Full article

A rapid dynamic security assessment (DSA) is crucial for online preventive and restoration decision-making. The deep learning-based DSA models have high efficiency and accuracy. However, the complex model structure and high training cost make them hard to update quickly. This paper proposes a dynamic security partition assessment method, aiming to develop accurate and incrementally updated DSA models with simple structures. Firstly, the power grid is self-adaptively partitioned into several local regions based on the mean shift algorithm. The input of the mean shift algorithm is a symmetric electrical distance matrix, and the distance metric is the Chebyshev distance. Secondly, high-level features of operating conditions are extracted based on the stacked denoising autoencoder. The symmetric electrical distance matrix is modified to represent fault locations in local regions. Finally, DSA models are constructed for fault locations in each region based on the radial basis function neural network (RBFNN) and Chebyshev distance. An online incremental updating strategy is designed to enhance the model adaptability. With the simulation software PSS/E 33.4.0, the proposed dynamic security partition assessment method is verified in a simplified provincial system and a large-scale practical system in China. Test results demonstrate that the Chebyshev distance can improve the partition quality of the mean shift algorithm by approximately 50%. The RBFNN-based partition assessment model achieves an accuracy of 98.96%, which is higher than the unified assessment with complex models. The proposed incremental updating strategy achieves an accuracy of over 98% and shortens the updating time to 30 s, which can meet the efficiency of online application. Full article

This paper provides a power-sharing strategy designed for an islanded grid that becomes isolated from the main grid due to faults or natural disasters. The proposed topology is introduced for post-disaster scenarios where the restoration process may be time-consuming (from a few hours to a few months). This system is equipped with a step-by-step power-sharing strategy based on priority, inputs from photovoltaic sources, and a diesel generator to enhance reliability. The DC–AC inverter control and AC–DC–AC control for the diesel generator are presented, which provide flexible real and reactive control. The system is divided into three priority load areas, and power sharing is conducted based on these priorities. The distinctive feature of the proposed strategy lies in its ability to manage power-sharing under different power generation conditions, prioritizing critical loads. The proposed method is implemented using the MATLAB Simulink environment. Simulation studies are performed under different solar irradiances and variations in the diesel generator’s output to validate the performance of the proposed method. The results demonstrate the practicality of the proposed algorithm in harnessing renewable resources and diesel generators and dynamically managing the energy consumption in loads. Full article
