Search Results (48)

The colour degradation of murals presents a significant challenge in the conservation of architectural heritage. Previous research has often concentrated on localized pigment changes while paying insufficient attention to the interaction between colour variation and indoor environmental conditions. Although non-destructive analytical techniques are widely used in heritage studies, their integrated application in combination with colourimetry has been limited, particularly in the context of Tibetan Buddhist murals in highland continental climates. This study investigates the murals of Liuli Hall in Meidai Lamasery, Inner Mongolia, as a representative case. We employed a comprehensive methodology that combines non-destructive analytical tools, gas chromatography–mass spectrometry, and quantitative colour analysis to examine pigment composition, binding material, and surface deterioration. Through joint analysis using the CIE Lab and CIE LCh colour space systems, we quantified mural colour changes and explored their correlation with material degradation and environmental exposure. The pigments identified include cinnabar, atacamite, azurite, and chalk, with animal glue and drying oils as binding materials. Colourimetric results revealed pronounced yellowing on the east and west walls, primarily caused by the ageing of organic binders. In contrast, a notable reduction in brightness on the south wall was attributed to dust accumulation. These findings support tailored conservation measures such as regular surface cleaning for the south wall and antioxidant stabilization treatments for the east and west walls. Initial cleaning efforts proved effective. The integrated approach adopted in this study provides a replicable model for mural diagnostics and conservation under complex environmental conditions. Full article

Structural adhesives or fixing glues are typically applied to larger components on printed circuit boards (PCBs) to increase mechanical stability and minimize damage from vibration. Existing work tends to focus on component placement verification and solder joint analysis, etc. However, the detection of structural adhesives remains largely unexplored. This paper proposes a vision-based method for detecting structural adhesive defects on PCBs. The method uses HSV color segmentation to extract PCB regions, followed by Hough-transform-based morphological analysis to identify board features. The perspective transformation then extracts and rectifies the adhesive regions, and constructs an adhesive region template by detecting the standard adhesive area ratio in its corresponding adhesive region. Finally, template matching is used to detect the structural adhesives. The experimental results show that this approach can accurately detect the adhesive state of PCBs and identify the qualified/unqualified locations, providing an effective vision-based detection scheme for PCB manufacturing. The main contributions of this paper are as follows: (1) A vision-based structural adhesive detection method is proposed, and its detailed algorithm is presented. (2) The developed system includes a user-friendly visualization interface, streamlining the inspection workflow. (3) Actual experiments are performed to evaluate this study, and the results validate its effectiveness. Full article

Satellite video geographic alignment can be applied to target detection and tracking, true 3D scene construction, image geometry measurement, etc., which is a necessary preprocessing step for satellite video applications. In this paper, a multi-scale spatiotemporal feature enhancement and recursive motion compensation method for satellite video geographic alignment is proposed. Based on the SuperGlue matching algorithm, the method achieves automatic matching of inter-frame image points by introducing the multi-scale dilated attention (MSDA) to enhance the feature extraction and adopting a joint multi-frame optimization strategy (MFMO), designing a recursive motion compensation model (RMCM) to eliminate the cumulative effect of the orbit error and improve the accuracy of the inter-frame image point matching, and using a rational function model to establish the geometrical mapping between the video and the ground points to realize the georeferencing of satellite video. The geometric mapping between video and ground points is established by using the rational function model to realize the geographic alignment of satellite video. The experimental results show that the method achieves the inter-frame matching accuracy of 0.8 pixel level, and the georeferencing accuracy error is 3 m, which is a significant improvement compared with the traditional single-frame method, and the method in this paper can provide a certain reference for the subsequent related research. Full article

This study employs the finite element method to propose a model-based design strategy for upholstered furniture frames. Three-dimensional discrete models of these frames were created, considering the orthotropic characteristics of pine (Pinus sylvestris L.) and spruce (Picea abies L.) wood, reinforced structurally with glue joints and upholstery staples. The modelling process utilised the CAE system Autodesk Inventor Nastran, applying the finite element method (FEM). Static analyses were performed by simulating standard loading conditions. The calculations incorporated the stiffness coefficients of the frame’s comb joint connections. The findings illustrate the stress distribution, displacements, and equivalent strains within the furniture frame models. The deformation and strength parameters of the frames introduce a novel perspective on designing upholstered furniture structures using the component-based FEM approach. These outcomes are applicable to the development of upholstered furniture designs. Full article

Timber–concrete composites are established structural elements to combine the advantageous properties of both materials by connecting them. In this work, an innovative flexible adhesive connection in different configurations is investigated. Load-bearing capacity, stiffness, and the failure modes were first experimentally investigated by performing push-out tests. Subsequently, a numerical evaluation using ABAQUS 2017/Standard software was carried out in order to develop a three-dimensional numerical model. The Cohesive Zone Model (CZM) is employed to represent the adhesive characteristics at the contact areas between the Cross-Laminated Timber (CLT) and concrete elements. Three different connection configurations were evaluated, each consisting of five push-out specimens. The study investigates the impact of bonding surface area and the alignment of prefabricated glue strips with the load direction on the connection’s longitudinal shear load-bearing capacity, stiffness, and slip modulus. In addition, the impact of cyclic loads and the impact of time on displacements were analyzed. The average load capacity of the full surface connection (type A) is 44.5% and 46.2% higher than the vertical adhesive strips (type B) and the horizontal adhesive strips (type C), respectively. However, the initial stiffness of the tested joints depends on the orientation of the prefabricated adhesive fasteners, being approximately 20% higher when the bonding elements are aligned parallel to the load direction compared to when they are oriented perpendicularly. Full article

Corner joints and edge banding are essential components that significantly impact the strength, durability, and aesthetic appeal of particleboard furniture. This review examines the critical role of edge banding in enhancing the performance of corner joints, which are fundamental to the overall quality of panel furniture. A targeted literature search was conducted across key databases, including the Web of Science Core Collection (WoS CC), Scopus, and Google Scholar, focusing on scientific resources in the technical and biotechnical sciences. The selection of joint types, materials, and construction methods can substantially influence both the structural integrity and visual design of the furniture. Well-designed corner joints improve durability and longevity by ensuring that furniture can withstand various forces and loads without failure or deformation. These joints enhance the aesthetics of furniture by providing seamless and visually appealing connections between different elements. Edge banding is vital for reinforcing corner joint strength, as different materials exhibit varying degrees of resistance to impact, scratches, and abrasion, thereby safeguarding furniture surfaces. Also, edge banding contributes to the furniture’s longevity, ensuring durability during use as well as through disassembly and transport during remodeling or relocation. This review aims to consolidate existing knowledge and establish parameters for future research on the quality and performance of corner joints and edge bands in particleboard furniture. Full article

The strength properties of softwood components with bonded joints reinforced with fasteners were investigated and compared. Initial tests of the strength of the glue joints were carried out, with a change in the type of adhesive used. The application method significantly influenced the shear strength of the joint. With the adhesive and pre-bonding systems used, the shear strength of the adhesive joint of pine wood (Pinus silvestris L.) with PUR and PVAC resin was determined. The industrial results were 31% lower than in the shear test of the wooden joint bonded with PVAC glue. In terms of transverse shear force with staples, the joint has a transverse holding force that is higher than components connected with screws or nails. As the number of glue sticks increased, the shear strength of the pine wood increased. The strengths of the joined components in the glue roller method had an intermediate value. They did not differ significantly between the two-row gluing systems used. An increase in the force required to shear the bonded joint was observed for the different adhesive systems, the fasteners used, and their density. Full article

The present study deals with the parameters for Stainless Steel 304 and Aluminum 5083 optimized with an emphasis on surface roughness, cure time, and their impact on the tensile strength of single-lap shear joints. Utilizing a central composite design, the effects of these factors were examined. Acetone was used to polish the surfaces, and silicon carbide sheets (P30, P36, and P60) were used to abrade them. Utilizing Henkel Loctite HY4090 glue, testing was conducted in accordance with ASTM D1002 guidelines. The variables were optimized with Design-Expert 11. Maximum tensile strengths were obtained with P30 abrasion and a 48-h cure time for SS304 (Ra = 3.2 µm) and Al5083 (Ra = 5 µm), respectively. Full article

This study is aimed at traditional vegetable grafting using a large number of plastic clips, which cannot be recycled in time and cause serious pollution within the planting environment. This paper proposes a new grafting method based on a UV adhesive instead of plastic clips. First of all, a UV adhesive spray grafting device was designed. The structure includes seedling adsorption positioning mechanisms, a butt joint mechanism, a handling mechanism, a spray valve, a UV curing lamp, etc., to facilitate the adhesive spraying. For the rootstock and scion, a horizontal, lateral seedling and negative pressure adsorption and positioning method is adopted, with fluid dynamics simulation of the diameter and quantity of the adsorption holes in the rootstock adsorption mechanism carried out using Fluent 2022 R1 software and completion of the optimization of the parameters of the adsorption and positioning mechanism. The fluid volume method is used to simulate the adsorption and positioning mechanism. For optimization, the volume of fluid method (VOF) and the discrete particle method (DPM) are used in a coupled simulation of the UV adhesive spraying process, and the value range of the spraying influencing factors is determined: the selected glue pressure, atomization pressure, and spraying height for three-factor, three-level orthogonal simulation. A grafting test is also verification, deriving the significance ranking of their impact on the success rate of the grafting: atomization pressure > spraying height > glue pressure. Under the condition of a 0.25 Mpa atomization pressure, a 0.15 Mpa glue supply pressure, and a 10 mm spraying height, the grafting success rate for watermelon was 100%, the effective spraying rate was 83.03%, the healing success rate was 94.5%, and the length of the film was 7.86 mm. The results of the study can provide a research basis for the research and development of new types of spraying and grafting robot technology. Full article

This study presents a comprehensive analysis of a simplified design methodology for timber–concrete composite roof and floor structures employing metal web beams, also known as posi-joisted beams, easi-joist, or open web joists, validated through both laboratory experiments and finite element (FE) method analyses. The proposed method integrates the transformed section method and the γ-method, as outlined in Annex B of EN1995-1-1 for mechanically jointed beams. The investigation focuses on roof and floor structures featuring posi-joisted beams, oriented strand board (OSB) sheets connected by screws, and a layer of concrete bonded to the OSB sheets using epoxy glue and granite chips. Two groups, each consisting of four specimens, were prepared for the laboratory experiments. Each specimen comprised two posi-joisted beams, 1390 mm long, connected by OSB/3 boards measuring 400 mm in width and 18 mm in thickness. The beams had a cross-sectional depth of 253 mm, corresponding to beams of grade PS10, with top and bottom chords made from solid timber (95 mm × 65 mm). Bracing members with cross-sections of 100 mm × 45 mm were used to join the bottom chords of the beams. A layer of self-levelling mass SakretBAM, 50 mm thick, was bonded to the OSB/3 boards using SicaDur 31 epoxy glue and granite chips (16–32 mm). The specimens underwent three-point bending tests under static loads, and FE modelling, conducted using Ansys R2 2022 software, was employed for both experimental groups. A comparative analysis of results obtained from the simplified design method, FE simulations, and experimental data revealed that the simplified method accurately predicted maximum vertical displacements of the roof fragment, including posi-joisted beams, with precision up to 11.6% and 23.10% in the presence and absence of a concrete layer, respectively. The deviation between normal stresses in the chords of the beams obtained through the simplified method and FE modelling was found to be 7.69%. These findings demonstrate the effectiveness and reliability of the proposed design methodology for timber–concrete composite roofs with posi-joisted beams. Full article

Grouted sleeves (GSs) are a type of precast joint that can effectively connect steel rebars with excellent performance. However, the grouting debonding problem, which can occur due to the leakage of the glue plug, can seriously affect the properties of GSs. In this paper, a guided-wave-based structural health monitoring (SHM) method is used to detect debonding in GSs. The axisymmetric longitudinal mode is selected as the incident wave since it is sensitive to axial damage. Eight piezoelectrics (PZTs) are then symmetrically installed to actuate signals. The proposed samples are GSs with four different debonding sizes. First, the relationship between the arrival time of the first wave packet and the debonding size is explored through theoretical derivation. The arrival time decreases linearly with an increasing debonding size. A similar trend is observed when the relationship is verified via a numerical simulation and experimental results. This method will provide a reference for detecting debonding in similar GS multilayer structures. Full article

Variable-stiffness actuators can flexibly adjust the overall or local stiffness of a structure, thus enabling reconstruction, adaptation, and locking capabilities that can meet a wide range of task requirements. However, the programmable design and manufacture of three-dimensional (3D) variable-stiffness actuators has become a challenge. In this paper, we present a method to develop the 3D structure of variable-stiffness actuators that combines variable-stiffness joints with 3D printing technology. The variable-stiffness joints were obtained by arranging steel needles wrapped with enameled copper wire inside the grooves of a polylactic acid (PLA) structure and bonding the three components with silicone glue. First, a variable-stiffness joint was used as a variable-stiffness node and subjected to 3D printing to realize multiple 3D variable-stiffness designs and manufacture a programmable structure. Then, using the repulsive force between paired magnets, we developed a driving actuator for the 3D variable-stiffness structure, enabling the expansion and deployment functions of the structure. In addition, an electromagnetically driven mechanical gripper was designed based on variable-stiffness joints to effectively decrease the driving energy in applications where objects are held for extended periods using variable-stiffness control. Our study provides practical solutions and guidance for the development of 3D variable-stiffness actuators, contributing to the achievement of more innovative and practical actuators. Full article

In the introduction, we present an overview of previous research on this subject in order to help the reader review possible technological solutions regarding the joining of construction materials. The original research presented in this article concerns the results of increasing the shear strength of adhesive joints of plastics using various types of surface preparation (laser texturing). Laser texturing consists in developing the surface by applying various geometric patterns of appropriate shapes and depths, as well as its density on the surface. The above parameters are currently selected in an empirical way as research is still being developed as part of a research project. The textures obtained in this way are subjected to microscopic examination. Then, a layer of glue is applied, and the samples prepared in this way, after drying, are subjected to various destructive tests, e.g., tensile, shear, and bending. In this article, we attempted to test the strength of the bonded joint of polyethylene (PE). The impact of a laser beam with ultrashort picosecond pulses was used in the research. Tools in the form of a TRUMPF TruMicro 5325c device integrated with a SCANLAB GALVO scanning head were used. This enabled ablative material removal without the presence of a heat affected zone (HAZ) in the non-laser part. Ultrashort laser pulses remove material without melting the non-exposed area by the laser beam. On the basis of the tests performed (in this article and previous research works of the authors), it was shown that the method increases the shear strength of the glued joints made in the tested construction materials. This is confirmed by laboratory results of tribological tests. The laser treatment parameters used, which are shown in this article, did not lead to the appearance of cracks in the micromachined materials. Research has shown that the connections between elements with a properly selected micropattern are characterized by a several-fold increase in the strength of joints, unlike materials without a micropattern. The presented method may be helpful for use as a technology for joining plastics. Full article

New types of hybrid aluminum joints: Al-acrylonitrile butadiene styrene (ABS) carbon fiber reinforced thermoplastic polymer (CFRTP) designated Al/Ni-CFP/ABS, and Al-18-8 Stainless steel, Al/Ni-CFP/18-8, by Ni-plated carbon fiber plug (Ni-CFP) insert not before seen in the literature have been fabricated. The goal is to take advantage of extremely high ~6 mm CF surface area for high adhesion, to enhance the safety level of aircraft and other parts. This is without fasteners, chemical treatment, or glue. First, the CFP is plated with Ni. Second, the higher melting point half-length is spot welded to the CFP; and third, the remaining half-length is fabricated. The ultimate tensile strength (UTS) of Al/Ni-CFP/ABS was raised 15 times over that of Al/ABS. Normalized ^cUTS according to CFP cross-section by Rule of Mixtures for ^cAl/Ni-CFP/18-8 was raised over that of ^cAl/Ni-CFP/18-8 from 140 to 360 MPa. Resistance energy to tensile deformation, U_T, was raised 12 times from Al/ABS to Al/Ni-CFP/ABS, and 6 times from Al/CFP/18-8 to Al/Ni-CFP/18-8. Spot welding allows rapid melting followed by rapid solidification for amorphous metal structures minimizing grain boundaries. The Ni-coating lowers or counters the effects of brittle Al₄C₃ and Fe_xC formation at the interface and prevents damage by impingement to CFs, allowing joints to take on more of the load. Full article

Various surface modification techniques have been developed to improve synthetic polymer surfaces’ wetting, adhesion, and printing by adding various functional (polar) groups. UV irradiation has been proposed as a suitable procedure to achieve adequate surface modifications of such polymers, which can be of further use to bond many compounds of interest. The activation of the surface, the favourable wetting properties, and the increased micro tensile strength of the substrate after short-term UV irradiation suggest that such pretreatment can also improve the bonding of the wood-glue system. Thus, this study aims to determine the feasibility of UV irradiation for pretreatment of wood surfaces before gluing and to determine the properties of wooden glued joints prepared in this way. UV irradiation was used to modify variously machined pieces of beech wood (Fagus sylvatica L.) before gluing. Six sets of samples were prepared for each machining process. Samples prepared in this manner were exposed to irradiation on a UV line. Each radiation level had a certain number of passes through the UV line, the more passes, the stronger the irradiation. Thus, the radiation levels were as follows: 1, 5, 10, 20, and 50 passes. The dose (energy delivered on the wood surface) in one pass was 2.36 J/cm². A wetting angle test with glue, a compressive shear strength test of lap joints, and designation of main failure patterns were used to evaluate the properties of wooden glued joints. Wetting angle test was performed according to EN 828, while the compressive shear strength test samples were prepared and tested following the ISO 6238 standard. The tests were conducted using a polyvinyl acetate adhesive. The study found that UV irradiation before gluing improved the bonding properties of variously machined wood. Full article
