The geoacoustic and physical properties of the bottom, as well as spatial distribution, are crucial factors in analyzing the underwater acoustic field structure and establishing a geoacoustic model. Acoustic inversion has been widely used as an economical and effective method to obtain multi-parameters of the bottom. Compared with traditional inversion methods based on acoustic propagation models, acoustic backscattering models are more suitable for multi-parameter inversion, because they contain more bottom information. In this study, a Bayesian inversion method based on an acoustic backscattering model is proposed to obtain bottom multi-parameters, including geoacoustic parameters (the sound speed and loss parameter), partial physical parameters of the sediment, and statistical parameters of the seafloor roughness and sediment heterogeneity. The bottom was viewed as a kind of fluid medium. A high-frequency backscattering model based on fluid theory was adopted as the forward model to fit the scattering strength between the model prediction and the measured data. The Bayesian inversion method was used to obtain the posterior probability density (PPD) of the inversion parameters. Parameter estimation, uncertainty, and correlation were acquired by calculating the maximum a posterior (MAP), the mean values, the one-dimensional marginal distributions of the PPD, and the covariance matrix. Finally, the high-frequency bottom backscattering strength from the Quinault Range site was employed for inversion tests. The estimated values and uncertainties of various bottom parameters are presented and compared with the directly measured bottom parameters. The comparison results demonstrate that the method proposed herein can be used to estimate the sediment/water sound speed ratio, the sediment/water density ratio, and the spectral exponent of the roughness spectrum effectively and reliably. Full article

This study focuses on the inversion of sub-bottom profile (SBP) data in the northern South China Sea using an empirical relationship derived from sediment acoustic data. The sub-bottom profile is primarily utilized for various marine applications, such as geological mapping and resource exploration. In this research, we present a study conducted in the northern slope canyon of the South China Sea. Firstly, we obtained the seabed reflection coefficient from sub-bottom profiles obtained by the autonomous underwater vehicle (AUV) detection system. Secondly, we utilized the acoustic empirical relationship in the northern South China Sea to establish relationship equations between the seabed reflection coefficient and the porosity, density, and average particle size of the sediment at a main frequency of 4 kHz (the AUV shallow profile main frequency). Then, using these equations, we were able to invert the physical parameters such as porosity, density, and average particle size of the seabed surface sediments. Finally, the inverted results are compared and analyzed by using the sediment samples test data. The overall deviation rate of the inverted physical parameters is within the range of ±10% when compared. The inverted results closely match the measured values, accurately reflecting the dynamic changes in the physical properties of seabed surface sediments. Notably, the average grain size is a direct indicator of the sediment particles size with smaller particles found in deeper water. The variation characteristics of sediment physical parameters align well with the variation of sediment types in the canyon, which is consistent with changes in the water depth, topography, and hydrodynamic conditions of the area. This further demonstrates the reliability of the inversion results. Full article

Low frequency acoustic methods are a common tool for seabed stratigraphy mapping. Due to the efficiency in seabed mapping compared to geotechnical methods, estimating geotechnical sediment properties from acoustic surveying is attractive for many applications. In this study, co-located geotechnical and geoacoustic measurements of different seabed sediment types in shallow water environments (<5 m of water depth) are analyzed. Acoustic impedance estimated from sediment properties based on laboratory testing of physical samples is compared to acoustic impedance deduced from CHIRP sonar measurements using an inversion approach. Portable free fall penetrometer measurements provided in situ sediment strength. The results show that acoustic impedance values deduced from acoustic data through inversion fall within a range of ±25% of acoustic impedance estimated from porosity and bulk density. The acoustic measurements reflect variations in shallow sediment properties such as porosity and bulk density (~10 cm below seabed surface), even for very soft sediments (s_u < 3 kPa) and loose sands (~20% relative density). This is a step towards validating the ability of acoustic methods to capture geotechnical properties in the topmost seabed layers. Full article

The inversion of acoustic field data to estimate geoacoustic parameters has been a prominent research focus in the field of underwater acoustics for several decades. Modal-dispersion curves have been used to inverse seabed sound speed and density profiles, but such techniques do not account for attenuation inversion. In this study, a new approach where modal-dispersion and waveform envelope data are simultaneously inversed under a multi-objective framework is proposed. The inversion is performed using the Multi-Objective Bayesian Optimization (MOBO) method. The posterior probability densities (PPD) of the estimation results are obtained by resampling from the exploited state space using the Gibbs Sampler. In this study, the implemented MOBO approach is compared with individual inversions both from modal-dispersion curves and the waveform data. In addition, the effective use of the Wasserstein metric from optimal transport theory is explored. Then the MOBO performance is tested against two different cost functions based on the L2 norm and the Wasserstein metric, respectively. Numerical experiments are employed to evaluate the effect of different cost functions on inversion performance. It is found that the MOBO approach may have more profound advantages when applied to Wasserstein metrics. Results obtained from our study reveal that the MOBO approach exhibits reduced uncertainty in the inverse results when compared to individual inversion methods, such as modal-dispersion inversion or waveform inversion. However, it is important to note that this enhanced uncertainty reduction comes at the cost of sacrificing accuracy in certain parameters other than the sediment sound speed and attenuation. Full article

The inversion method based on the reflection loss-grazing angle curve is an effective tool to obtain local underwater acoustic parameters. Because geoacoustic parameters vary in sensitivity to grazing angle, it is difficult to get accurate results in geoacoustic parameter inversion based on small-grazing-angle data in shallow water. In addition, the normal-mode model commonly used in geoacoustic parameter inversion fails to meet the needs of accurate local sound field simulation as the influence of the secant integral is ignored. To solve these problems, an acoustic data acquisition scheme was rationally designed based on a sparker source, a fixed vertical array, and ship drifting with the swell, which could balance the trade-off among signal transmission efficiency and signal stability, and the actual local acoustic data at low-to-mid frequencies were acquired at wide grazing angles in the South Yellow Sea area. Furthermore, the bottom reflection coefficients (bottom reflection losses) corresponding to different grazing angles were calculated based on the wavenumber integration method. The local seafloor sediment parameters were then estimated using the genetic algorithm and the bottom reflection loss curve with wide grazing angles, obtaining more accurate local acoustic information. The seafloor acoustic velocity inverted is $c_p=1659 \mathrm{m}/\mathrm{s}$ and the sound attenuation is ${\alpha }_p=0.656 \mathrm{dB}/\mathsf{\lambda }$ in the South Yellow Sea. Relevant experimental results indicate that the method described in this study is feasible for local inversion of geoacoustic parameters for seafloor sediments. Compared with conventional large-scale inversion methods, in areas where there are significant changes in the seabed sediment level, this method can obtain more accurate local acoustic features within small-scale areas. Full article

Geoacoustic inversion is a challenging task in marine research due to the complex environment and acoustic propagation mechanisms. With the rapid development of deep learning, various designs of neural networks have been proposed to solve this issue with satisfactory results. As a data-driven method, deep learning networks aim to approximate the inverse function of acoustic propagation by extracting knowledge from multiple replicas, outperforming conventional inversion methods. However, existing deep learning networks, mainly incorporating stacked convolution and fully connected neural networks, are simple and may neglect some meaningful information. To extend the network backbone for geoacoustic inversion, this paper proposes a transformer-based geoacoustic inversion model with additional frequency and sensor 2-D positional embedding to perceive more information from the acoustic input. The simulation experimental results indicate that our proposed model achieves comparable inversion results with the existing inversion networks, demonstrating its effectiveness in marine research. Full article

A class of problems of wave propagation in waveguides consisting of one or several layers that are characterized by linear variation of the squared refractive index along the normal to the interfaces between them is considered in this paper. In various problems arising in practical applications, it is necessary to efficiently solve the dispersion relations for such waveguides in order to compute horizontal wavenumbers for different frequencies. Such relations are transcendental equations written in terms of Airy functions, and their numerical solutions may require significant computational effort. A procedure that allows one to reduce a dispersion relation to an ordinary differential equation written in terms of elementary functions exclusively is proposed. The proposed technique is illustrated on two cases of waveguides with both compact and non-compact cross-sections. The developed reduction method can be used in applications such as geoacoustic inversion. Full article

Geoacoustic inversion is important for seabed geotechnical applications. It can be formulated as a problem that seeks an optimal solution in a high-dimensional parameter space. The conventional inversion approach exploits optimization methods with a pre-defined search strategy whose hyperparameters need to be fine-tuned for a specific scenario. A framework based on the deep-Q network is proposed in this paper and the environment and agent configurations of the framework are specially defined for geoacoustic inversion. Unlike a conventional optimization method with a pre-defined search strategy, the proposed framework determines a flexible strategy by trial and error. The proposed framework is evaluated by two case studies for estimating the shear wave velocity profile. Its performance is compared with three global optimization methods commonly used in underwater geoacoustic inversion. The results demonstrate that the proposed framework performs the inversion more efficiently and accurately. Full article

The geoacoustic parameter acquisition in the deep sea is of great significance to the research of ocean acoustics. This paper found that the interference structure of the shadow zone induced by the reflection of the high-speed sediment layer could be simply described by the grazing angle of the surface-bottom reflection from the theory of ray acoustics, when the source and receiver depth makes the grazing angle of the surface-bottom reflection consistent with that of the bottom-surface reflection. On this basis, a geoacoustic parameter inversion method by spatial position matching of interference fringes in the shadow zone was proposed, and an interference fringe extraction method was designed based on the maximum between-class variance algorithm in this paper. After extracting the results by the stripe coordinates in the simulation environment, the density was obtained by assuming the base sound speed as an empirical value and combining with Hamilton’s empirical formula, and the sediment sound speed and thickness were inverted by the grid search method. Those inversion results were compared with the multi-dimensional inversion results of the genetic algorithm. The simulation results showed that the fringe extraction method proposed in this paper could effectively extract the interference fringes formed by the reflection of the high-speed sediment in the shadow zone, and compared with the multi-dimensional optimization process, the relatively accurate inversion results of the sound speed and thickness of high-speed sediment could be obtained more effectively and quickly by taking the spatial position of the interference fringe as the cost function of the matching parameter combined with the grid search method in this paper. Full article

Seafloor geoacoustic properties are important in determining sound propagation in the marine environment, which broadly affects sub-sea activities. However, geoacoustic investigation of the deep seafloor, which is required by the recent expansion of deep-water operations, is challenging. This paper presents a methodology for estimating the seafloor sound speed, $c_0$, and a sub-bottom velocity gradient, $K$, in a relatively deep-water-compacting (~1000 m) passive-margin setting, based on standard commercial 2D seismic data. Here we study the seafloor of the southeastern Mediterranean margin based on data from three commercial seismic profiles, which were acquired using a 7.2 km-long horizontal receiver array. The estimation applies a geoacoustic inversion of the wide-angle reflections and the travel times of the head waves of bending rays. Under the assumption of a constant positive $K$, the geoacoustic inversion converges to a unique set of parameters that best satisfy the data. The analysis of 24 measurement locations revealed an increase in the average estimates of $c_0$ from 1537 $\pm$ 13 m s⁻¹ to 1613 $\pm$ 12 m s⁻¹ for seafloor depths between ~1150 m and ~1350 m. $K$ ranged between 0.75 and 0.85 m s⁻¹ with an average of 0.80 $\pm$ 0.035 s⁻¹. The parameters were consistent across the different locations and seismic lines and they match the values that were obtained through depth-migration-velocity analysis and empiric relations, thereby validating our estimation methodology. Full article

Recent studies have illustrated that the Multichannel Analysis of Surface Waves (MASW) method is an effective geoacoustic parameter inversion tool. This particular tool employs the dispersion property of broadband Scholte-type surface wave signals, which propagate along the interface between the sea water and seafloor. It is of critical importance to establish the theoretical Scholte wave dispersion curve computation model. In this typical study, the stiffness matrix method is introduced to compute the phase speed of the Scholte wave in a layered ocean environment with an elastic bottom. By computing the phase velocity in environments with a typical complexly varying seabed, it is observed that the coupling phenomenon occurs among Scholte waves corresponding to the fundamental mode and the first higher-order mode for the model with a low shear-velocity layer. Afterwards, few differences are highlighted, which should be taken into consideration while applying the MASW method in the seabed. Finally, based on the ingeniously developed nonlinear Bayesian inversion theory, the seafloor shear wave velocity profile in the southern Yellow Sea of China is inverted by employing multi-order Scholte wave dispersion curves. These inversion results illustrate that the shear wave speed is below 700 m/s in the upper layers of bottom sediments. Due to the alternation of argillaceous layers and sandy layers in the experimental area, there are several low-shear-wave-velocity layers in the inversion profile. Full article

An adaptive particle filter method is presented for performing sequential geoacoustic estimation of a shallow water acoustic environment using the explosive sound sources. This approach treats environmental parameters and source–receiver distance as unknown random variables that evolve as the source moves. As a sequential estimation method, this approach reduces the expense of computation than genetic algorithm and yields results with the same accuracy. Comparing with standard Particle filter, proposed method can adjust control parameters to adapt to a rapidly changing environment. This approach is demonstrated on the shallow water sound propagation data which was collected during the ASIAEX 2001 experiment. The results indicate that the geoacoustic parameters are well estimated and source–receiver distance are also well determined. Full article

Geoacoustic inversion is an efficient method to study the physical properties and structure of ocean bottom while sequential geoacoustic inversion is a challenging task due to the complexity and non-linearity of the underwater environment. In this paper, an ensemble Kalman Particle filter is described to address the sequential geoacoustic inversion problem of range-dependent environment in shallow water. This filter combines the advantages of Particle filter and ensemble Kalman filter so its ability of tracking dynamical geoacoustic parameters is improved. The proposed filtering method is demonstrated with simulated data in a changing oceanic environment and outperforms Particle filter and ensemble Kalman filter. This method is also tested in sea-trial data collected from a shallow-water experiment in the East China Sea. The inverted sound speed in sediment is consistent with in situ measurement and the error between transmission loss predicted by inverted parameters, and the experimental transmission loss is small. Full article

Geoacoustic parameter inversion is a crucial issue in underwater acoustic research for shallow sea environments and has increasingly become popular in the recent past. This paper investigates the geoacoustic parameters in a shallow sea environment using a single-receiver geoacoustic inversion method based on Bayesian theory. In this context, the seabed is regarded as an elastic medium, the acoustic pressure at different positions under low-frequency is chosen as the study object, and the theoretical prediction value of the acoustic pressure is described by the Fast Field Method (FFM). The cost function between the measured and modeled acoustic fields is established under the assumption of Gaussian data errors using Bayesian methodology. The Bayesian inversion method enables the inference of the seabed geoacoustic parameters from the experimental data, including the optimal estimates of these parameters, such as density, sound speed and sound speed attenuation, and quantitative uncertainty estimates. The optimization is carried out by simulated annealing (SA), and the Posterior Probability Density (PPD) is given as the inversion result based on the Gibbs Sampler (GS) algorithm. Inversion results of the experimental data are in good agreement with both measured values and estimates from Genetic Algorithm (GA) inversion result in the same environment. Furthermore, the results also indicate that the sound speed and density in the seabed have fewer uncertainties and are more sensitive to acoustic pressure than the sound speed attenuation. The sea noise could increase the variance of PPD, which has less influence on the sensitive parameters. The mean value of PPD could still reflect the true values of geoacoustic parameters in simulation. Full article

The key to model-based Bayesian geoacoustic inversion is to solve the posterior probability distributions (PPDs) of parameters. In order to obtain PPDs more efficiently and accurately, the state-of-the-art Markov chain Monte Carlo (MCMC) method, multiple-try differential evolution adaptive Metropolis_(ZS) (MT-DREAM_(ZS)), is integrated to the inverse problem because of its excellent ability to fully explore the posterior space of parameters. The effective density fluid model (EDFM), which is derived from Biot–Stoll theory to approximate the poroelastic model, and the published field measurements of backscattering strength are adopted to implement the inversion. The results show that part of the parameters can be estimated close to the measured values, and the PPDs obtained by dual-frequency inversion are more concentrated than those of single-frequency inversion because of the use of more measured backscattering strength data. Otherwise, the comparison between the predicted backscattering strength of dual-frequency inversion results and Jackson’s prediction shows that the solutions of the inverse problem are not unique and may have multiple optimal values. Indeed, the difference between the two predictions is essentially the difference in the estimation of the contribution of volume scattering to the total scattering. Nevertheless, both results are reasonable due to the lack of measurement of volume scattering parameters, and the inversion results given by the posterior probabilities based on the limited measurements and the adopted model are still considered to be reliable. Full article
