Search Results (32)

The geometric parameters of the Null-Flux coil (NFC) are crucial to the load capacity and economic viability of electrodynamic suspension (EDS) systems. This study investigates the influence of NFC geometry on the electromagnetic force characteristics in EDS systems. Through the electromagnetic modeling of EDS mechanisms, an analytical model for EDS systems is established. Systematic experiments compare electromagnetic forces under varying NFC lengths and gaps, supported by a self-developed stationary EDS dynamic simulation platform. The results demonstrate that the average levitation force is positively correlated with the coil length, and it is larger when the coil length is close to its width. Meanwhile, the NFC length has a significant impact on the lift-to-drag ratio, while the NFC gap has a relatively smaller effect on it. This work provides a complete methodology integrating analytical modeling and experimental validation, offering practical guidelines for NFC design in maglev actuators. The findings advance EDS system optimization through quantifiable geometric criteria, particularly for transportation applications requiring precision electromagnetic force control. Full article

This paper investigates the application of Incremental Nonlinear Dynamic Inversion (INDI) for launch vehicle flight control, addressing the limited exploration of nonlinear control architectures and their potential benefits in the context of the current “New Space” era. In this context, this study aims to bridge the gap between the launcher’s traditional linear control practice and nonlinear methods, focusing on INDI, which offers the potential to enhance limits of performance while reducing mission preparation (“missionisation”) efforts. INDI control commands incremental inputs by exploiting feedback acceleration estimates in a feedback-linearised plant in order to reduce model dependency, making it easier to design and resulting in a robust closed loop as compared to nonlinear dynamic inversion. The objective of this paper is therefore to demonstrate INDI’s implementation in a representative industrial launch ascent scenario, evaluate its strengths and limitations relative to industry standards, and promote its adoption within the launcher Guidance, Navigation, and Control (GNC) community. Comparative simulations with traditional scheduled PD controllers, with and without angular acceleration feedback, are highlighted together with several trade-offs. Furthermore, this paper presents a new and practical INDI stability analysis method as applied in the context of aerospace attitude control, as well as an augmentation of the design with an outer control loop for active load relief. Results indicate that while INDI exhibits increased sensitivity to sensor noise and actuator delays as compared to the linear controllers, its advantages in robustness and performance are significant. Notably, INDI’s ability to handle nonlinearities without extensive tuning and gain-scheduling surpasses the capabilities of the traditional linear control counterparts. These results highlight the potential of INDI as a more robust and efficient alternative to state-of-practice launcher control design methodologies. Full article

While the concept of humanoid robots stems from the goal of replicating human movement, these systems have yet to match the elegance and efficiency of human locomotion. A key reason for this gap is that current humanoid robots differ from humans in their kinematics, dynamics, and actuator properties. This work seeks to close that gap by designing an optimized humanoid robot with characteristics closely resembling those of an average human. For this purpose, we built a detailed framework for the in-depth electromechanical modeling of actuator components. This model was used in the comprehensive optimization of the robot’s actuator system, which was designed as a multi-objective scheme based on the objectives introduced in our previous work. This process helped both in achieving efficient and high-performance actuators and in streamlining the design of the structural parts to have mass and inertia distributions similar to those of humans. The proposed design process was utilized in the design of our humanoid robot, Mithra. Initial test showed that Mithra achieved its design goals in terms of human-like kinematics and dynamics characteristics, together with sufficient actuator strength for tasks such as stair navigation, squatting, and running. Full article

Traditional fracture reduction relies heavily on the surgeon’s experience, which hinders the transmission of skills. This specialization bottleneck, coupled with the high demands on physical strength, significantly limits the efficiency of daily treatments in trauma orthopedics. Currently, most fracture surgery robots focus on open or minimally invasive reduction techniques, which inherently carry the risk of iatrogenic damage due to surgical incisions or bone pin insertions. However, research in closed reduction-oriented robotic systems is remarkably limited. Addressing this gap, our study introduces a novel bone-setting robot for the closed reduction of ankle fractures designed with a redundant parallel platform. The parallel robot’s design incorporates three sliding redundancy actuators that enhance its tilt flexibility while maintaining load performance. Moreover, a singularity-free redundant kinematic solver has been developed, optimizing the robot’s operational efficacy. Building upon the demonstrations from professional closed reduction techniques, we propose the use of a multivariate Student-t process as a multi-output regression model within dynamic movement primitive for accurately learning stable reduction maneuvers. Additionally, we develop an anthropomorphic variable impedance controller based on inverse dynamics. The simulation results demonstrate convincingly that the developed ankle bone-setting robot is proficient in effectively replicating and learning the nuanced closed reduction techniques. Full article

Electrothermal actuators are highly advantageous for microelectromechanical systems (MEMS) due to their capability to generate significant force and large displacements. Despite these benefits, their application in reconfigurable conduction line switches is limited, particularly when employing commercial processes. In DC MEMS switches, electrothermal actuators require electrical insulation between the biasing voltage and the transmission line to prevent interference and maintain the integrity of the switch. This work presents a chevron-type electrothermal actuator utilizing a stack of $\mathrm{S}\mathrm{i}{\mathrm{O}}_2/$ Al thin films on a silicon (Si) structural layer beam to create a DC MEMS switch. The design leverages a thin film Al heater to drive the actuator while the $\mathrm{S}\mathrm{i}{\mathrm{O}}_2$ layer provides electrical insulation, suppressing crosstalk with the Si layer. The electrical contact resistance of a Si-to-Si interface was evaluated by applying a controlled current and measuring the resultant voltage. A low contact resistance of 150 Ω was achieved when an initial contact gap of 2.52 μm was closed using an actuator with an actuation voltage of 1.2 V and a current of 205 mA, with a switching speed of less than 5 ms. Factors such as the contact force, the temperature, and the residual device layer etching angle significantly impact the Si-to-Si contact resistance and the switch’s longevity. The switch withstands a breakdown voltage up to 350 V at its terminal contacts. Thus, it will be robust to self-actuation caused by unwanted voltage contributions, making it suitable for high-voltage and harsh environment applications. Full article

Humans interact with the environment through a variety of senses. Touch in particular contributes to a sense of presence, enhancing perceptual experiences, and establishing causal relations between events. Many human–machine interfaces only allow for one-way communication, which does not do justice to the complexity of the interaction. To address this, we developed a bidirectional human–machine interface featuring a bracelet equipped with linear resonant actuators, controlled via a Robot Operating System (ROS) program, to simulate haptic feedback. Further, the wireless interface includes a motion sensor and a sensor to quantify the tightness of the bracelet. Our functional experiments, which compared stimulation with three and five intensity levels, respectively, were performed by four healthy participants in their twenties and thirties. The participants achieved an average accuracy of 88% estimating three vibration intensity levels. While the estimation accuracy for five intensity levels was only 67%, the results indicated a good performance in perceiving relative vibration changes with an accuracy of 82%. The proposed haptic feedback bracelet will facilitate research investigating the benefits of bidirectional human–machine interfaces and the perception of vibrotactile feedback in general by closing the gap for a versatile device that can provide high-density user feedback in combination with sensors for intent detection. Full article

Currently, the main solution for braking systems for underground electric trackless rubber-tired vehicles (UETRVs) is traditional hydraulic braking systems, which have the disadvantages of hydraulic pressure crawling, the risk of oil leakage and a high maintenance cost. An electro-mechanical-braking (EMB) system, as a type of novel brake-by-wire (BBW) system, can eliminate the above shortcomings and play a significant role in enhancing the intelligence level of the braking system in order to meet the motion control requirements of unmanned UETRVs. Among these requirements, the accurate control of clamping force is a key technology in controlling performance and the practical implementation of EMB systems. In order to achieve an adaptive clamping force control performance of an EMB system, an optimized fuzzy proportional-integral-differential (PID) controller is proposed, where the improved fuzzy algorithm is utilized to adaptively adjust the gain parameters of classic PID. In order to compensate for the deficiency of single-close-loop control and adjusting the brake gap automatically, a cascaded three-closed-loop control architecture with force/position switch technology is established, where a contact point detection method utilizing motor rotor angle displacement is proposed via experiments. The results of the simulation and experiments indicate that the clamping force response of the proposed multi-close-loop Variable Universe Fuzzy–PID (VUF-PID) controller is faster than the multi-closed-loop Fuzzy–PID and cascaded three-close-loop PID controllers. In addition, the chattering of braking force can be suppressed by 17%. This EMB system may rapidly and automatically finish the operation of the overall braking process, including gap elimination, clamping force tracking and gap recovery, which can obviously enhance the precision of the longitudinal motion control of UETRVs. It can thus serve as a BBW actuator of mine autonomous driving electric vehicles, especially in the stage of braking control. Full article

This article presents the conceptual design, operation principle, dynamic modeling, and simulation results of a discrete incremental hydraulic positioning system (DIHPS) intended for use in high-precision, heavy-load industrial automation solutions. An original solution for precise incremental step positioning using DIHPS is proposed, comprising an n-step linear double-acting hydraulic actuator (HA) with a double rod, cylinder sleeve with outflow gaps, binary valves (BVs) bleed-off into the tank, and fixed throttle valves (TRVs) at the inlets of the actuator chambers. The discrete incremental shift of the HA is determined by controlling the opening and closing of the individual BVs, and the step shift of the HA piston stops at the opening location of the BV. A dynamic model of incremental step shift for DIHPS is developed, considering the behavior and relationships of its individual elements. A dynamic model of HA with and without a hydropneumatic accumulator (HPA) is presented. HPA has been shown to effectively dampen piston vibrations and pressure peaks at the HA stop position. The design assumptions, dynamic models, and discrete incremental positioning of the DIHPS are verified by simulation tests and assessed with quantitative indicators. Innovative DIHPSs have significant practical potential in the discrete incremental positioning of heavy loads. Full article

We have developed a manufacturing process for micromirrors based on microelectromechanical systems (MEMS) technology. The process involves designing an electrostatic vertically comb-driven actuator and utilizing a self-alignment process to produce a height difference between the movable comb structure and the fixed comb structure of the micromirror. To improve the stability of the micromirror, we propose four instability models in micromirror operation with the quasi-static driving principle and structure of the micromirror considered, which can provide a basic guarantee for the performance of vertical comb actuators. This analysis pinpoints factors leading to instability, including the left and right gap of the movable comb, the torsion beams of the micromirror, and the comb-to-beams distance. Ultimately, the voltages at which device failure occurs can be determined. We successfully fabricated a one-dimensional micromirror featuring a 0.8 mm mirror diameter and a 30 μm device layer thickness. The height difference between the movable and fixed comb structures was 10 μm. The micromirror was able to achieve a static mechanical angle of 2.25° with 60 V@DC. Stable operation was observed at voltages below 60 V, in close agreement with the theoretical calculations and simulations. At the driving voltage of 80 V, we observed the longitudinal displacement movement of the comb fingers. Furthermore, at a voltage of 129 V, comb adhesion occurred, resulting in device failure. This failure voltage corresponds to the lateral torsional failure voltage. Full article

This paper presents a new MEMS varactor that uses repulsive actuation to achieve an ultra-linear capacitance-to-voltage response. The approach proposed involves actuating the moveable electrode away from the fixed electrode, instead of the conventional closing-the-gap direction. This increasing-gap movement reduces the capacitance as the actuation voltage increases. The MEMS variable capacitor is fabricated using PolyMUMPs technology and exhibits an excellent linearity factor of 99.7% in capacitance-to-voltage response, and a capacitance tuning ratio of 11× was achieved. The proposed strategy will enable the development of high-performance MEMS-based tunable devices for various applications. Full article

For signal transmission and sensing in stretchable structures for human motion monitoring or proprioception of soft robots, textiles with electronically conductive yarns are a promising option. Many recent publications employ silver-plated yarns in knits, braids, wovens for strain or pressure sensing purposes as well as heating fabrics or twisted string actuators. Silver-plated yarns are available in a wide range of base materials, yarn counts and twists. These structural properties significantly influence the electrical and electromechanical behavior of such yarns. However, until now little research has been carried out on the yarns themselves. To close this research gap, several variations of a single yarn type are electromechanically characterized. Additionally, tensile tests with synchronous resistance measurements are performed. From these measurements, sensor metrics are derived and calculated to compare the different variants quantitatively. Full article

Similar to biological muscles in nature, artificial muscles have unique advantages for driving bionic robots. However, there is still a large gap between the performance of existing artificial muscles and biological muscles. Twisted polymer actuators (TPAs) convert rotary motion from torsional to linear motion. TPAs are known for their high energy efficiency and large linear strain and stress outputs. A simple, lightweight, low-cost, self-sensing robot powered using a TPA and cooled using a thermoelectric cooler (TEC) was proposed in this study. Because TPA burns easily at high temperatures, traditional soft robots driven by TPAs have low movement frequencies. In this study, a temperature sensor and TEC were combined to develop a closed-loop temperature control system to ensure that the internal temperature of the robot was 5 °C to cool the TPAs quickly. The robot could move at a frequency of 1 Hz. Moreover, a self-sensing soft robot was proposed based on the TPA contraction length and resistance. When the motion frequency was 0.01 Hz, the TPA had good self-sensing ability and the root-mean-square error of the angle of the soft robot was less than 3.89% of the measurement amplitude. This study not only proposed a new cooling method for improving the motion frequency of soft robots but also verified the autokinetic performance of the TPAs. Full article

To bridge the gap that exists in the key equipment of the new subsea production control system, the all-electric subsea gate valve actuator, and exploit subsea oil and gas resources with high reliability and safety while saving energy, this paper proposes a novel concept prototype of an all-electric subsea gate valve actuator which has the key functions of a redundant drive, failsafe closing, auxiliary override, position indication, and low-power position holding. It satisfied the electrically-driven requirements of the subsea gate valves and achieved Safety Integrity Level 3. The prototype was developed and tested successfully. The all-electric subsea gate valve actuator is suitable for controlling subsea gate valves with various sizes and rated working pressures to minimize the power consumption for the purpose of keeping the valves open and safely closing them in the event of the electrical failure. An override and position-indicating mechanism is equipped for emergency operation and the visual indication of the status of subsea gate valves. Full article

In this research sustainable refrigerants are tested as filler gases in Transparent Thermal Insulation (TTI) for the first time. These are compared with pig fat, a readily available material with good thermal inertia that is proposed as an organic phase change material (PCM). The aim of this paper is to compare the thermal behaviour of a Hybrid Air Conditioning System (HACS) with TTI filled with R134a, R1233zd and a pig-fat-based PCM. Numerical simulations using the OPAQUE 3 program and two online platforms are used to evaluate the possible application of TTI and PCM as passive systems. Additionally, three TTI models are used to simulate the heat transfer processes of TTI, PCM and R134a. The velocity of the flow in the air gap is also analysed numerically in both laminar and turbulent states. For the assessment, infrared thermographic imagery is used to measure the temperatures in the HACS, giving values of 46.17 °C by day and 38.05 °C at night. The results show that the heat loss and heat gain in the combination TTI filled with refrigerants and pig-fat-based PCM are between 2.22 and 1.51 W/m². In addition, the HACS was able to keep a small box warm during the night. The flow in the air gap of the HACS can be controlled by installing Ni-Ti wire actuators with a cooling temperature of 23 °C and a heating temperature of 70 °C. The Ni-Ti wire actuators can open and close the dampers at 23 °C and 51 °C, respectively. By installing a 5-watt solar-power fan, the velocity of the flow in the air gap in the HACS can be increased, thus improving the efficiency of the system. In all the experiments, the pig fat proved to be suitable for use in building applications as a non-flammable organic material. Full article

Having benefited from technological developments, such as surface micromachining, high-aspect-ratio silicon micromachining and ongoing miniaturization in complementary metal–oxide–semiconductor (CMOS) technology, some electrostatic actuators became widely used in large-volume products today. However, due to reliability-related issues and inherent limitations, such as the pull-in instability and extremely small stroke and force, commercial electrostatic actuators are limited to basic implementations and the micro range, and thus cannot be employed in more intricate systems or scaled up to the macro range (mm stroke and N force). To overcome these limitations, cooperative electrostatic actuator systems have been researched by many groups in recent years. After defining the scope and three different levels of cooperation, this review provides an overview of examples of weak, medium and advanced cooperative architectures. As a specific class, hybrid cooperative architectures are presented, in which besides electrostatic actuation, another actuation principle is used. Inchworm motors—belonging to the advanced cooperative architectures—can provide, in principle, the link from the micro to the macro range. As a result of this outstanding potential, they are reviewed and analyzed here in more detail. However, despite promising research concepts and results, commercial applications are still missing. The acceptance of piezoelectric materials in some industrial CMOS facilities might now open the gate towards hybrid cooperative microactuators realized in high volumes in CMOS technology. Full article
