This paper presents a dynamic model for full-power converter permanent magnet synchronous wind turbines based on Physics-Informed Neural Networks (PINNs). The model integrates the physical dynamics of the wind turbine directly into the loss function, enabling high-accuracy equivalent modeling with limited data and overcoming the typical “black-box” constraints and large data requirements of traditional data-driven approaches. To enhance the model’s real-time adaptability, we introduce an online update mechanism leveraging Bayesian Neural Networks (BNNs) combined with a clustering-guided strategy. This mechanism estimates uncertainty in the neural network weights in real-time, accurately identifies error sources, and performs local fine-tuning on clustered data. This improves the model’s ability to track real-time errors and addresses the challenge of parameter-specific adjustments. Finally, the data-driven model is integrated into the CloudPSS platform, and its multi-scenario modeling accuracy is validated across various typical cases, demonstrating the robustness of the proposed approach. Full article

Split-shaft wind turbines decouple the turbine’s shaft from the generator’s shaft, enabling several modifications in the drivetrain. One of the significant achievements of a split-shaft drivetrain is the reduction in size of the excitation circuit. The grid-side converter is eliminated, and the rotor-side converter can safely reduce its size to a fraction of a full-size excitation. Therefore, this low-power-rated converter operates at low voltage and handles regular operations well. However, fault conditions may expose weaknesses in the converter and push it to its limits. This paper investigates the effects of the reduced-size rotor-side converter on the voltage ride-through capabilities required from all wind turbines. Four different protection circuits, including the active crowbar, active crowbar along a resistor–inductor circuit (C-RL), series dynamic resistor (SDR), and new-bridge fault current limiter (NBFCL), are employed, and their effects are investigated and compared. Wind turbine controllers are also utilized to reduce the impact of faults on the power electronic converters. One effective method is to store excess energy in the generator’s rotor. The proposed low-voltage ride-through strategies are simulated in MATLAB Simulink (2022b) to validate the results and demonstrate their effectiveness and functionality. Full article

This paper introduces an enhanced bi-directional full-bridge resonant converter designed for Vehicle-to-Grid (V2G) systems. A key innovation lies in the incorporation of an auxiliary LC resonant circuit connected via a tertiary transformer winding. This circuit dynamically modifies the magnetizing inductance based on operating frequency, enabling soft-switching across all primary switches, specifically, Zero-Voltage Switching (ZVS) at turn-on and near Zero-Current Switching (ZCS) at turn-off across the entire load spectrum. Additionally, the converter supports both Constant Current (CC) and Constant Voltage (CV) charging modes at distinct, fixed operating frequencies, thus avoiding wide frequency variations. A 3.3 kW prototype developed for onboard electric vehicle charging applications demonstrates the effectiveness of the proposed topology. Experimental results confirm high efficiency in both charging and discharging operations, achieving up to 98.13% efficiency in charge mode and 98% in discharge mode. Full article

Radar echo extrapolation is a critical forecasting tool in the field of meteorology, playing an especially vital role in nowcasting and weather modification operations. In recent years, spatiotemporal sequence prediction models based on deep learning have garnered significant attention and achieved notable progress in radar echo extrapolation. However, most of these extrapolation network architectures are built upon convolutional neural networks, using radar echo images as input. Typically, radar echo intensity values ranging from −5 to 70 dBZ with a resolution of 5 dBZ are converted into 0–255 grayscale images from pseudo-color representations, which inevitably results in the loss of important echo details. Furthermore, as the extrapolation time increases, the smoothing effect inherent to convolution operations leads to increasingly blurred predictions. To address the algorithmic limitations of deep learning-based echo extrapolation models, this study introduces three major improvements: (1) A Deep Convolutional Generative Adversarial Network (DCGAN) is integrated into the ConvLSTM-based extrapolation model to construct a DCGAN-enhanced architecture, significantly improving the quality of radar echo extrapolation; (2) Considering that the evolution of radar echoes is closely related to the surrounding meteorological environment, the study incorporates specific physical variable products from the initial zero-hour field of RMAPS-NOW (the Rapid-update Multiscale Analysis and Prediction System—NOWcasting subsystem), developed by the Institute of Urban Meteorology, China. These variables are encoded jointly with high-resolution (0.5 dB) radar mosaic data to form multiple radar cells as input. A multi-channel radar echo extrapolation network architecture (MR-DCGAN) is then designed based on the DCGAN framework; (3) Since radar echo decay becomes more prominent over longer extrapolation horizons, this study departs from previous approaches that use a single model to extrapolate 120 min. Instead, it customizes time-specific loss functions for spatiotemporal attenuation correction and independently trains 20 separate models to achieve the full 120 min extrapolation. The dataset consists of radar composite reflectivity mosaics over North China within the range of 116.10–117.50°E and 37.77–38.77°N, collected from June to September during 2018–2022. A total of 39,000 data samples were matched with the initial zero-hour fields from RMAPS-NOW, with 80% (31,200 samples) used for training and 20% (7800 samples) for testing. Based on the ConvLSTM and the proposed MR-DCGAN architecture, 20 extrapolation models were trained using four different input encoding strategies. The models were evaluated using the Critical Success Index (CSI), Probability of Detection (POD), and False Alarm Ratio (FAR). Compared to the baseline ConvLSTM-based extrapolation model without physical variables, the models trained with the MR-DCGAN architecture achieved, on average, 18.59%, 8.76%, and 11.28% higher CSI values, 19.46%, 19.21%, and 19.18% higher POD values, and 19.85%, 11.48%, and 9.88% lower FAR values under the 20 dBZ, 30 dBZ, and 35 dBZ reflectivity thresholds, respectively. Among all tested configurations, the model that incorporated three physical variables—relative humidity (rh), u-wind, and v-wind—demonstrated the best overall performance across various thresholds, with CSI and POD values improving by an average of 16.75% and 24.75%, respectively, and FAR reduced by 15.36%. Moreover, the SSIM of the MR-DCGAN models demonstrates a more gradual decline and maintains higher overall values, indicating superior capability in preserving echo structural features. Meanwhile, the comparative experiments demonstrate that the MR-DCGAN (u, v + rh) model outperforms the MR-ConvLSTM (u, v + rh) model in terms of evaluation metrics. In summary, the model trained with the MR-DCGAN architecture effectively enhances the accuracy of radar echo extrapolation. Full article

A grid-connected converter is the interface between renewable energy power generation systems, such as solar power generation, wind power, hydropower, etc., and the power grid, responsible for the stable and efficient transmission of electric energy generated by renewable energy power generation systems to the grid. In order to realize local access for distributed photovoltaic power generation devices and energy storage devices, a composite three-port converter has the advantages of small size, low cost and high power density compared with a combined three-port converter. In view of the current problems of the existing compound three-port (AC/DC/DC) converters, such as DC and AC circulating current in current composite three-port converters and the harmonic control problem, the proposed compound three-port topology consists of a full-bridge inverter with six switching tubes, a zigzag transformer, two sets of filter inductors and two filter capacitors. Among them, the power frequency transformer adopts the zigzag connection method, which can effectively restrain the AC circulation and eliminate the DC magnetic flux of the iron core while introducing the third port. Firstly, the principle of AC/DC and DC/DC power conversion in the composite three-port topology is analyzed, which has higher efficiency than other topologies. Secondly, the topology control strategy is analyzed, and a two-loop hybrid current control method with improved current loop is proposed. When the DC-side voltage fluctuates, the DC offset of the battery can effectively improve the stability of the network side. Through the MATLAB/Simulink simulation experiment platform, the high efficiency of energy conversion and stable grid-connected operation characteristics are verified. Finally, the experiment of integrating into the power grid was carried out. Experiments were used to verify the effectiveness and feasibility of the proposed topology and strategy. The experimental results show that Total Harmonic Distortion (THD) can be controlled below 3%. Full article

Wind turbines’ volume and power generation capacity have increased worldwide. Consequently, their inspection, maintenance, and repair are garnering increasing attention. Structural defects are common in turbine blades, but their detection is difficult due to the relatively large size of the blades. Therefore, engineers often use nondestructive testing. This study employed an unmanned aerial vehicle (UAV) to simultaneously capture visible-light and infrared thermal images of wind power blades. Subsequently, instant neural graphic primitives and neural radiance fields were used to reconstruct the visible-light image in three dimensions (3D) and generate a 3D mesh model. Experiments determined that after converting parts of the orthographic-view images to elevation- and depression-angle images, the success rate of camera attitude calculation increased from 85.6% to 97.4%. For defect measurement, the system first filters out the perspective images that account for 6–12% of the thermal image foreground area, thereby excluding most perspective images that are difficult to analyze. Based on the thermal image data of wind power generation blades, the blade was considered to be in a normal state when the full range, average value, and standard deviation of the relative temperature grayscale value in the foreground area were within their normal ranges. Otherwise, it was classified as abnormal. A heat accumulation percentage map was established from the perspective image of the abnormal state, and defect detection was based on the occurrence of local minima. When a defect was observed in the thermal image, the previously reconstructed 3D image was switched to the corresponding viewing angle to confirm the actual location of the defect on the blade. Thus, the proposed 3D image reconstruction process and thermal image quality analysis method are effective for the long-term monitoring of wind turbine blade quality. Full article

Aimed at solving the problem of insulation failure caused by the local overheating of the oil-immersed converter transformer, this paper investigates the heat transfer characteristics of the 500 kV converter transformer based on the electromagnetic-flow-heat coupling model. Firstly, this paper used the finite element method to calculate the core and winding loss. Then, a two-dimensional fluid-heat coupling model was used to investigate the effects of the inlet flow rate and the radius of the oil pipe on the heat transfer characteristics. The results show that the larger the inlet flow rate, the smaller the specific gravity of high-temperature transformer oil at the upper end of the tank. Increasing the pipe radius can reduce the temperature of the heat dissipation of the transformer in relative equilibrium. Still, the pipe radius is too large to lead to the reflux of the transformer oil in the oil outlet. Increasing the central and sub-winding turn distance, the oil flow diffusion area and flow velocity increase. Thus, the temperature near the winding is reduced by about 9%, and the upper and lower wall temperature is also reduced by about 4%. Based on the analysis of the sensitivity weight indicators of the above indicators, it is found that the oil flow rate has the largest share of influence on the hot spot temperature of the transformer. Finally, the surface temperature of the oil tank when the converter transformer is at full load is measured. In the paper, the heat transfer characteristics of the converter transformer are investigated through simulation and measurement, which can provide a certain reference value for the study of the insulation performance of the converter transformer. Full article

This paper provides guidelines for designing and modeling sensing coils in high-voltage, high-frequency transformers to enable a cost-efficient design of isolated converter topologies. The objective is to design a magnetic structure in which an additional sensing coil, placed on the main transformer, can be used to precisely measure the voltage on the secondary, despite fast changes in the voltage and current. This is usually a challenging task since high-voltage transformers will always require considerable isolation, which will give rise to significant leakage fields, which in turn will distort the measurement, especially at high frequencies. Our main finding is that this problem can be avoided if the sensing winding is carefully routed to maintain a certain ratio between the transformer’s coupling coefficients, which is achieved by placing this winding in an area within the core in which the magnetic field is low. In principle, this leads to a linear relationship between the voltages of the secondary and sensing windings despite non-ideal leakage inductances. The results are demonstrated experimentally using a 10 kW transformer, with 60 kV isolation, demonstrating a coupling coefficient of about 0.99, which reflects an error of less than $1.5\%$ in the sensed secondary voltage. Full article

The polar energy router is a key device in the polar clean energy system which converges the output of wind power, photovoltaic units, energy storage units and hydrogen fuel cells through the power electronic power converter to the DC bus, which requires the use of a variety of specifications of DC/DC converters; as a result, the efficiency of the DC/DC converter is directly connected to the efficiency of the polar energy router. This paper presents an enhanced isolated DC/DC converter with a phase-shifted full-bridge topology designed to meet the high-efficiency conversion requirements of polar energy routers. Although soft switching can be realized naturally in phase-shifted full-bridge topology, it also faces challenges, such as the difficulty of realizing soft switching under light load conditions, large circulation losses, a loss of duty cycle and oscillation in the secondary-side voltage. To solve these problems, an improved scheme of the phase-shifted full-bridge converter with an active clamp circuit is proposed in this paper. The scheme realized zero-voltage switch (ZVS) under light load by utilizing clamp capacitor energy. The on-state loss was reduced by zeroing the primary-side current during the circulating phase. This paper provides a detailed description of the topology, working principle and performance characteristics of the improved scheme, and its feasibility has been verified through experiments. Full article

In a single-switch forward converter, which is a type of single-input multiple-output (SIMO) DC–DC converter, voltage changes are observed at the outputs due to the current passing through the diodes, the difficulty of winding the transformer in full and half windings, differences in resistance in the windings, the presence of leakage inductance and the existence of common inductance between the windings. These voltage changes are undesirable, and cross-regulation techniques have been developed to keep the outputs at the desired value. One of these techniques, the weighted control method, in which voltage information is received from many outputs, is addressed in this article. The reason we apply this technique is to avoid additional components and their control problems. In addition, this technique is simpler and cheaper than other cross-regulation techniques. In this way, we will contribute to the literature on cross-regulation, showing that cross-regulation remains below 3.33% and circuit efficiency reaches 86.83% by using the weighted control method. Full article

Aiming at the DC bus voltage instability problem resulting from the stochastic nature of distributed energy output and load fluctuation, an Integral Sliding Mode Linear Active Disturbance Rejection Control (ISMLADRC) combined with Model Predictive Control (MPC) strategy for energy storage bi-directional DC–DC converter is proposed based on the wind–solar-storage DC microgrid system. The proposed method utilizes a dual closed-loop control structure, employing a two-step MPC approach in the inner current loop to enhance the system’s dynamic response performance. Secondly, the integral sliding mode control algorithm is embedded into the Linear Active Disturbance Rejection (LADRC) technique, based on which the outer voltage loop ISMLADRC controller is designed to mitigate the impact of disturbances on the bus voltage effectively, and the system’s anti-disturbance performance and robustness are improved. Considering that the parameters of the ISMLADRC controller are too many to be tuned, and in order to give full play to the performance of the controller, an Improved Dung Beetle Optimization Algorithm (IDBO) is used to tune the parameters. Finally, based on MATLAB 2022b and RT-LAB 2021.3 platforms, the simulation results show that in a variety of operating conditions, the proposed control strategy can flexibly regulate the bidirectional transmission of battery energy, and the bus voltage recovery time is within 0.1 s, and the voltage fluctuation is less than 0.5%. Full article

The LLC resonant converter is widely recognized as an effective solution for achieving high efficiency in high-frequency operations. This is primarily due to its ability to perform zero-voltage switching (ZVS) on primary switches and zero-current switching (ZCS) on secondary rectifier switches. However, implementing the secondary rectifier of an LLC resonant converter often requires the use of jumpers on the PCB to construct circuit topologies such as the center-tap rectifier (CTR), full-bridge rectifier, and voltage-doubler rectifier (VDR). In conventional VDR configurations, the source voltage of the high-side FET fluctuates according to the switching operation of the primary switch. This fluctuation necessitates auxiliary windings or bootstrap circuits to provide a floating voltage source, adding significant complexity to gate drive circuits in high-power-density applications. This complexity poses a major barrier to the practical adoption of VDRs. To address these challenges, this paper proposes a novel rectification circuit based on the VDR topology, specifically designed for LLC resonant converters, offering simplified gate drive circuitry and improved suitability for high-power-density applications. Full article

High-voltage direct current (HVDC) transmission systems are widely used today due to their several advantages over high-voltage alternative current (HVAC) systems. They are primarily utilized in connecting different large grids or smaller independent networks, especially in submarine interconnections. Many studies have been conducted globally on the optimal planning, operation, and control of these power systems. Understanding the transient stability of these systems during significant disturbances is also of great importance. This paper specifically focuses on power systems with HVDC connections and high penetration of renewable energy sources. Analytical models were developed for power system components like HVDC converters, DC lines, and full converter wind generators. A simulation of a test-case power system was conducted, including various significant disturbances such as HVDC line trips, short circuits, power unit failures, and major changes in load. The voltage and frequency stability of the system under specific operational scenarios was also examined. The results obtained indicate technical limitations and operating guidelines to avoid undesirable conditions and system failure. In conclusion, adopting short-term stability tests the optimal operation point of the system, and the limitations in the penetration by RES units can be decided. Full article

This study offers a modular isolated grid-connected DC/DC medium-voltage DC aggregation converter to support offshore full DC wind farms’ need for lightweight and highly efficient power aggregation and transmission. The converter can simultaneously have a smaller transformer size and lower switching frequency during operation through the dual-voltage stabilization three-loop control strategy and phase-shift modulation strategy, which greatly reduces the space occupied by the converter and lowers the switching loss, Additionally, the use of a two-level structure at a lower switching frequency has lower loss, which effectively reduces the cost of the power device compared with the commonly used three-level converter. The input series output series connection between the converter sub-modules effectively lowers the voltage stress on each power switching device and facilitates expansion into a multi-module structure, expanding its application in high-voltage and large-capacity environments. This study analyzes the two working modes of the DC/DC converter and its control approach, in addition to providing a detailed introduction to the application scenarios of this converter. Ultimately, the efficacy and practicability of the suggested topology and control scheme are confirmed by simulations and experiments. Full article

Fault ride-through is a prerequisite for ensuring continuous operation of a variable-speed pumped storage unit with a full-size converter (FSC-VSPU) and providing support for the renewable energy and power grid. This paper proposes low-voltage ride through (LVRT) and high-voltage ride through (HVRT) strategies for FSC-VSPU to address this issue. Firstly, the structure of FSC-VSPU and its control strategy under power generation and pumping conditions are described. Subsequently, the fault characteristics of the FSC-VSPU under different operating conditions are analyzed. More stringent fault ride-through technical requirements than those for wind turbines are proposed. On this basis, the fault ride-through strategies of combining fast power drop, rotor energy storage control, power anti-regulation control, dynamic reactive current control, low power protection, and DC crowbar circuit are proposed. Simulation case studies conducted in PSCAD/EMTDC verify the correctness of the theoretical analysis and the effectiveness of the LVRT and HVRT strategies in this paper. Full article
