Search Results (17)

X-ray ptychography is an ultrahigh resolution imaging technique widely used in synchrotron radiation facilities. Its imaging performance relies on the quality of the acquired signals. However, the X-ray detectors used often suffer from signal loss due to sensor gaps, beamstops, defective pixels, overexposure, or other factors, resulting in degraded image quality. To suppress and compensate for the effects of signal loss, we proposed the known probe approach to partially recover the lost signals and introduced the high probe divergence strategy by investigating the effects of probe divergence on reconstruction quality under signal loss conditions. Both simulation and experiment results show that high probe divergence can effectively suppress the impact of signal loss on reconstruction quality while using a known probe as the initial probe for reconstruction can largely recover missing signals in Fourier space, resulting in a much better image than using a guessed initial probe. These strategies allow for high-quality imaging in the presence of signal loss without secondary data acquisition, significantly improving experimental efficiency and reducing radiation damage compared to previous strategies. Full article

Fourier Ptychography (FP) is a powerful computational imaging technique that enables high-resolution, wide-field imaging by synthesizing apertures and leveraging coherent diffraction. However, the application of FP in long-distance imaging has been limited due to challenges such as noise and optical aberrations. This study introduces deep learning methods following macroscopic FP to further enhance image quality. Specifically, we employ super-resolution convolutional neural networks and very deep super-resolution, incorporating residual learning and residual neural network architectures to optimize network performance. These techniques significantly improve the resolution and clarity of FP images. Experiments with real-world film samples demonstrate the effectiveness of the proposed methods in practical applications. This research highlights the potential of deep learning to advance computational imaging techniques like FP, paving the way for improved long-distance imaging capabilities. Full article

Fourier ptychography (FP) can break through the limitations of existing optical systems with a single aperture and realize large field-of-view (FOV) and high-resolution (HR) imaging simultaneously by aperture synthesis in the frequency domain. The method has potential applications for remote sensing and space-based imaging. However, the aperture stop of the imaging system was generally set to be much smaller than the system with an adjustable diaphragm, so it failed to make full use of the imaging capability of the system. In this paper, a reflective remote FP with full aperture is proposed, and the optical aperture of the camera is set to be the maximum according to the sample-matching condition, which can further improve the imaging resolution by exploring the whole capability of the system. Firstly, the physical model of the remote FP is established using oblique illumination of a convergent spherical wave. Then, the sampling characteristics of the low-resolution (LR) intensity image are analyzed. Assuming diffraction-limited imaging, the size of the aperture of the optical system needs to match the sampling of the detector. An experimental setup with an imaging distance of 2.4 m is built, and a series of LR images is collected by moving the camera for the diffused samples, including the USAF resolution test target and the banknote, where the diameter of the single aperture is set to the maximum to match the size of the CCD pixel under the practical minimum F^# of the camera of 2.8. The high-resolution image is reconstructed by applying the iterative phase retrieval algorithm. The experimental results show that the reconstructed resolution is improved to 2.5×. This verifies that remote FP with full aperture can effectively improve the imaging resolution using only the present single-aperture optical system. Full article

In this study, we proposed a multiplexed color illumination strategy to improve the data acquisition efficiency of Fourier ptychography microscopy (FPM). Instead of sequentially lighting up one single channel LED, our method turns on multiple white light LEDs for each image acquisition via a color camera. Thus, each raw image contains multiplexed spectral information. An FPM prototype was developed, which was equipped with a 4×/0.13 NA objective lens to achieve a spatial resolution equivalent to that of a 20×/0.4 NA objective lens. Both two- and four-LED illumination patterns were designed and applied during the experiments. A USAF 1951 resolution target was first imaged under these illumination conditions, based on which MTF curves were generated to assess the corresponding imaging performance. Next, H&E tissue samples and analyzable metaphase chromosome cells were used to evaluate the clinical utility of our strategy. The results show that the single and multiplexed (two- or four-LED) illumination results achieved comparable imaging performance on all the three channels of the MTF curves. Meanwhile, the reconstructed tissue or cell images successfully retain the definition of cell nuclei and cytoplasm and can better preserve the cell edges as compared to the results from the conventional microscopes. This study initially validates the feasibility of multiplexed color illumination for the future development of high-throughput FPM scanning systems. Full article

Fourier ptychographic microscopy (FPM) is a computational imaging technology that can acquire high-resolution large-area images for applications ranging from biology to microelectronics. In this study, we utilize multifocal plane imaging to enhance the existing FPM technology. Using an RGB light emitting diode (LED) array to illuminate the sample, raw images are captured using a color camera. Then, exploiting the basic optical principle of wavelength-dependent focal length variation, three focal plane images are extracted from the raw image through simple R, G, and B channel separation. Herein, a single aspherical lens with a numerical aperture (NA) of 0.15 was used as the objective lens, and the illumination NA used for FPM image reconstruction was 0.08. Therefore, simultaneous multifocal plane FPM with a synthetic NA of 0.23 was achieved. The multifocal imaging performance of the enhanced FPM system was then evaluated by inspecting a transparent organic light-emitting diode (OLED) sample. The FPM system was able to simultaneously inspect the individual OLED pixels as well as the surface of the encapsulating glass substrate by separating R, G, and B channel images from the raw image, which was taken in one shot. Full article

High-resolution infrared remote sensing imaging is critical in planetary exploration, especially under demanding engineering conditions. However, due to diffraction, the spatial resolution of conventional methods is relatively low, and the spatial bandwidth product limits imaging systems’ design. Extensive research has been conducted with the aim of enhancing spatial resolution in remote sensing using a multi-aperture structure, but obtaining high-precision co-phase results using a sub-aperture remains challenging. A new high-resolution imaging method utilizing multi-aperture joint-encoding Fourier ptychography (JEFP) is proposed as a practical means to achieve super-resolution infrared imaging using distributed platforms. We demonstrated that the JEFP approach achieves pixel super-resolution with high efficiency, without requiring subsystems to perform mechanical scanning in space or to have high position accuracy. Our JEFP approach extends the application scope of Fourier ptychographic imaging, especially in distributed platforms for planetary exploration applications. Full article

The Vertical Cavity Surface-Emitting Laser (VCSEL) has led to the rapid development of advanced fields such as communication, optical sensing, smart cars, and more. The accurate testing of VCSEL beam quality is an important prerequisite for its effective application. In this paper, a method for measuring the divergence angle of the VCSEL far field spot based on transmissive Fourier ptychography is proposed. First, a single CCD multi-angle VCSEL far-field spot acquisition system is designed. Second, based on the proposed Fourier ptychographic algorithm with synchronous optimization of embedded optical transfer function, a resolution-enhanced phase image of the spot is reconstructed and the boundary extracted by the Sobel operator of the phase image is defined as the boundary position of the beam waist. In this way, the beam waist radius of the laser beam is calculated. Finally, the divergence angle of the laser beam is measured via the radius of the beam waist. Compared with the traditional Gaussian beam definition method, the method proposed in this paper has higher accuracy in divergence angle measurement. The experimental results show that this method can improve the divergence angle measurement accuracy by up to 9.7%. Full article

Fourier ptychography imaging technology is a method developed in recent years to achieve high-resolution imaging. In the traditional macro Fourier ptychography technology, the scanning method when the camera captures low-resolution images mostly uses the rectangular linear grid format. These acquired images contain a small amount of complementary information, and a large number of low-resolution images are needed to achieve high-resolution imaging. Redundant measurements will extend the sampling and reconstruction time, and require more computing resources. In this paper, we propose to obtain the target image spectral energy distribution by pre-sampling. And according to the energy distribution, we use irregular and non-uniform sampling modes to restore the target image. With the same number of samples and same reconstruction time, higher resolution imaging can be achieved compared with traditional methods. Simulation and experimental studies are carried out in this paper, and the results confirm the effectiveness of the proposed methods. Compared with the traditional sampling mode, the two sampling modes proposed in this paper increase the resolution from 4.49 lp/mm to 5.66 lp/mm and 5.04 lp/mm respectively. Full article

Polyethylene terephthalate (PET) is a thermoplastic polyester with numerous applications in industry. However, it requires surface modification on an industrial scale for printing and coating processes and plasma treatment is one of the most commonly used techniques to increase the hydrophilicity of the PET films. Systematic improvement of the surface modification by adaption of the plasma process can be aided by a comprehensive understanding of the surface morphology and chemistry. However, imaging large surface areas (tens of microns) with a resolution that allows understanding the surface quality and modification is challenging. As a proof-of-principle, plasma-treated PET films were used to demonstrate the capabilities of X-ray ptychography, currently under development at the soft X-ray free-electron laser FLASH at DESY, for imaging macroscopic samples. In combination with scanning electron microscopy (SEM), this new technique was used to study the effects of different plasma treatment processes on PET plastic films. The studies on the surface morphology were complemented by investigations of the surface chemistry using X-ray photoelectron spectroscopy (XPS) and Fourier transform infrared spectroscopy (FT-IR). While both imaging techniques consistently showed an increase in roughness and change in morphology of the PET films after plasma treatment, X-ray ptychography can provide additional information on the three-dimensional morphology of the surface. At the same time, the chemical analysis shows an increase in the oxygen content and polarity of the surface without significant damage to the polymer, which is important for printing and coating processes. Full article

Fourier ptychography imaging is a powerful phase retrieval method that can be used to realize super-resolution. In this study, we establish a mathematical model of long-distance camera scanning based on reflective Fourier ptychography imaging. In order to guarantee the effective recovery of a high-resolution image in the experiment, we analyze the influence of laser coherence in different modes and the surface properties of diverse materials for diffused targets. For the analysis, we choose a single-mode fiber laser as the illumination source and metal materials with high diffused reflectivity as the experimental targets to ensure the validity of the experimental results. Based on the above, we emulate camera scanning with a single camera attached to an X-Y translation stage, and an experimental system with a working distance of 3310 mm is used as an example to image a fifty-cent coin. We also perform speckle analysis for rough targets and calculate the average speckle size using a normalized autocorrelation function in different positions. The method of calculating the average speckle size for everyday objects provides the premise for subsequent research on image quality evaluation; meanwhile, the coherence of the light field and the targets with high reflectivity under this experiment provide an application direction for the further development of the technique, such as computer vision, surveillance and remote sensing. Full article

Fourier ptychography (FP) is a powerful phase retrieval method that can be used to reconstruct missing high-frequency details and high-space-bandwidth products in microscopy. In this study, we further advanced the application of FP in microscopic imaging to the field of macroscopic far-field imaging, incorporating camera scanning for spatial resolution improvement. First, on the basis of the Fraunhofer diffraction mechanism and the transmission imaging model, we found the analysis of the associated theoretical fundamentals via simulations and experiments to be crucially relevant to the far-field of FP imaging. Second, we built an experimental device with long-distance imaging and experimentally demonstrated the relationship between the spectrum overlap ratio and the reconstructed high-resolution image. The simulation and experimental results showed that an overlap ratio higher than 50% had a good reconstruction effect. Third, camera scanning was used to obtain low-resolution intensity images in this study, for which the scanning range was wide and spherical wave illumination was satisfied, and therefore different positions corresponded to different aberrations of low-resolution intensity images, and even different positions of the same image had aberration differences, leading to inconsistencies in the aberrations of different images. Therefore, in the reconstruction process, we further overcame the effect of the inconsistency of aberrations of different images using the partition reconstruction method, which involves cutting the image into smaller parts for reconstruction. Finally, with the proposed partition reconstruction algorithm, we were able to resolve 40 μm line width of GBA1 resolution object and obtain a spatial resolution gain of 4× with a working distance of 2 m. Full article

We report on the development and implementation of methodologies dedicated to soft X-ray imaging by coherent scattering in reflection mode. Two complementary approaches are tested, based on Fourier transform holography and on ptychography. A new method for designing holographic masks has been developed. Our results represent a feasibility test and highlight the potential and limitations of imaging in reflection mode. Reflectivity is less efficient than transmission at soft X-ray wavelengths, hampering the acquisition of good quality images. Nonetheless, it has the potential to image a wider set of samples, notably those that are not transparent to soft X-rays. Although the images obtained so far are of modest quality, these results are extremely encouraging for continuing the development of coherent soft X-ray imaging in reflection mode. Full article

In this research, the accuracy of image classification with Fourier Ptychography Microscopy (FPM) has been systematically investigated. Multiple linear regression shows a strong linear relationship between the results of image classification accuracy and image visual appearance quality based on PSNR and SSIM with multiple training datasets including MINST, Fashion MNIST, Cifar, Caltech 101, and customized training datasets. It is, therefore, feasible to predict the image classification accuracy only based on PSNR and SSIM. It is also found that the image classification accuracy of FPM reconstructed with higher resolution images is significantly different from using the lower resolution images under the lower numerical aperture (NA) condition. The difference is yet less pronounced under the higher NA condition. Full article

How to perform imaging beyond the diffraction limit has always been an essential subject for the research of optical systems. One effective way to achieve this purpose is Fourier ptychography, which has been widely used in microscopic imaging. However, microscopic imaging measurement technology cannot be directly extended to imaging macro objects at long distances. In this paper, a reconstruction algorithm is proposed to solve the need for oversampling low-resolution images, and it is successfully applied to macroscopic imaging. Compared with the traditional FP technology, the proposed sub-sampling method can significantly reduce the number of iterations in reconstruction. Experiments prove that the proposed method can reconstruct low-resolution images captured by the camera and achieve high-resolution imaging of long-range macroscopic objects. Full article

Fourier ptychography microscopy (FPM) is a recently emerged computational imaging method, which combines the advantages of synthetic aperture and phase retrieval to achieve super-resolution microscopic imaging. FPM can bypass the diffraction limit of the numerical aperture (NA) system and achieve complex images with wide field of view and high resolution (HR) on the basis of the existing microscopic platform, which has low resolution and wide field of view. Conventional FPM platforms are constructed based on basic microscopic platform and a scientific complementary metal–oxide–semiconductor (sCMOS) camera, which has ultrahigh dynamic range. However, sCMOS, or even the microscopic platform, is too expensive to afford for some researchers. Furthermore, the fixed microscopic platform limits the space for function expansion and system modification. In this work, we present a simply equipped FPM platform based on an industrial camera and telecentric objective, which is much cheaper than sCMOS camera and microscopic platform and has accurate optical calibration. A corresponding algorithm was embedded into a conventional FP framework to overcome the low dynamic range of industrial cameras. Simulation and experimental results showed the feasibility and good performance of the designed FPM platform and algorithms. Full article
