Search Results (77)

This paper presents a novel design for a bionic knee exoskeleton equipped with a variable stiffness actuator based on rope-driven artificial muscles. To meet the varying stiffness requirements of the knee joint across different gait modes, the actuator dynamically switches between multiple rope bundle configurations, thereby enabling effective stiffness modulation. A mathematical model of the knee exoskeleton is developed, and the mechanical properties of the selected flexible aramid fiber ropes under tensile loading are analyzed through both theoretical and experimental approaches. Furthermore, a control framework for the exoskeleton system is proposed. Wearable experiments are conducted to evaluate the effectiveness of the variable stiffness actuation in improving compliance and comfort across various gait patterns. Electromyography (EMG) results further demonstrate that the exoskeleton provides a compensatory effect on the rectus femoris muscle. Full article

The lower-limb assistance exoskeleton is increasingly being utilized in various fields due to its excellent performance in human body assistance. As a crucial component of robots, the joint is expected to be designed with a high-output torque to support hip and knee movement, and lightweight to enhance user experience. Contrasted with the elastic actuation with harmonic drive and other flexible transmission, the non-elastic quasi-direct actuation is more promising to be applied in exoskeleton due to its advanced dynamic performance and lightweight feature. Moreover, robot joints are commonly driven electrically, especially by a permanent magnet synchronous motor which is rapidly developed because of its compact structure and powerful output. Based on different topological structures, numerous research focus on torque density, ripple torque suppression, efficiency improvement, and thermal management to improve motor performance. Furthermore, the elaborated joint with powerful motors should be controlled compliantly to improve flexibility and interaction, and therefore, popular complaint control algorithms like impedance and admittance controls are discussed in this paper. Through the review and analysis of the integrated design from mechanism structure to control algorithm, it is expected to indicate developmental prospects of lower-limb assistance exoskeleton joints with optimized performance. Full article

Background: Self-controlled motor imagery combined with assistive devices is promising for enhancing neurorehabilitation. This study developed a soft, Flexible Exoskeleton (flexEXO) for finger movements and investigated whether self-controlled motor tasks facilitate stronger cortical activation than externally controlled conditions. Methods: Twenty-one healthy participants performed grasping tasks under four conditions: Self-Controlled Motion (SCC), Other-Controlled Motion (OCC), Self-Controlled Imagery Only (SCIOC), and Other-Controlled Imagery Only (OCIOC). EEG data were recorded, focusing on event-related desynchronization (ERD) in the μ and β bands during imagery and motion and event-related synchronization (ERS) in the β band during feedback. Source localization was performed using eLORETA. Results: Higher μERD and βERD were observed during self-controlled tasks, particularly in the primary motor cortex and supplementary motor area. Externally controlled tasks showed enhanced activation in the inferior parietal lobule and secondary somatosensory cortex. βERS did not differ significantly across conditions. Source localization revealed that self-controlled tasks engaged motor planning and error-monitoring regions more robustly. Conclusions: The flexEXO device and the comparison of brain activity under different conditions provide insights into the neural mechanisms of motor control and have implications for neurorehabilitation. Full article

Research on pediatric hand exoskeletons remains limited compared to that on devices for adults. This paper presents the design and experimental validation of a customizable pediatric finger module, part of a hand exoskeleton tailored to individual anatomical features. The module aims to assist finger flexion in children with mild spasticity during activities of daily living. A patient-specific design methodology was applied to the case of a 12-year-old child. The finger module integrates compliant dorsal structures and cable-driven transmission with rigid anchoring elements to balance flexibility and structural stability. Different geometries and thickness values were tested to optimize comfort and quantify mechanical performance. Additive manufacturing was adopted to enable rapid prototyping and easy replacement of parts. Tensile and bending tests were conducted to determine stiffness and cable travel. Results support the feasibility of the proposed finger module, offering empirical data for selection and sizing of the actuation system and paving the way for the advancement of new modular pediatric devices. Full article

This research presents the results of conceptual design and modeling of an exoskeleton. It is intended for ankle joint rehabilitation in patients with musculoskeletal disorders. The exoskeleton design includes three screw actuators that smoothly control motion in the planes of dorsal and plantar flexion, inversion, and eversion. The results of the virtual tests performed on the exoskeleton device demonstrated a high degree of adaptability to varying loads and different phases of motion. Controlled torque fluctuations and linear motion provide the necessary support during different phases of rehabilitation, which has a positive impact on the patient’s recovery rate. The advantages of the design include material availability, ease of use, and flexibility in customization, making it an attractive option for use in both clinical and home settings. The study emphasizes the importance of developing affordable and accurate rehabilitation devices that can adapt to individual patient needs. Full article

Chitin is one of the most abundant biopolymers in nature and is found mainly in the exoskeletons of crustaceans and insects, in the cell walls of fungi, and in some species of mollusks. Chitosan is a derivative of chitin; it is much more accessible and has a broader range of applications, including improving the quality of materials such as films, plastics, and concrete. The rheological properties of chitin and chitosan refer to their behavior against deformation and flow and their ability to resist structural changes under mechanical stress conditions. These properties are fundamental in applications where the aim is to control the texture, viscosity, and handling of these biopolymers. Three types of methods for the extraction of chitin and chitosan can be classified: the first is the chemical method, which presents high yields but uses reagents that generate toxic residues; the second is the biological method, which takes advantage of chemical reactions of microorganisms but in some cases has low yields compared to chemical extraction; and the third is the enzymatic method, which uses reagents with a low production of toxic residues. However, low extraction yields are also reported. One of the primary sources of chitin and chitosan is the residue of shellfish and crustaceans. However, a new source of obtaining these compounds is the black soldier fly, which has the same yields of biopolymers as shellfish. In addition, this is a residue of the black soldier fly larvae culture, where protein, oil, and biofertilizers are generated by the bioconversion of organic waste. This work proposes the black soldier fly as an alternative source for extracting chitin and chitosan, using organic methodologies that do not generate toxic residues and have high yields. Including these biopolymers in concrete elaboration could have positive results in terms of flexibility, compressive strength, and workability. Full article

Electromyography (EMG) signals are fundamental in neurorehabilitation as they provide a non-invasive means of capturing the electrical activity of muscles, enabling precise detection of motor intentions. This capability is essential for controlling assistive devices, such as therapeutic exoskeletons, that aim to restore mobility and improve motor function in patients with neuromuscular impairments. The integration of EMG into neurorehabilitation systems allows for adaptive and patient-specific interventions, addressing the variability in motor recovery needs. However, achieving the high fidelity, low latency, and robustness required for real-time control of these devices remains a significant challenge. This paper introduces a novel multi-channel electromyography (EMG) acquisition system implemented on a System-on-Chip (SoC) architecture for robotic neurorehabilitation. The system employs the Zynq-7000 SoC, which integrates an Advanced RISC Machine (ARM) processor, for high-level control and an FPGA for real-time signal processing. The architecture enables precise synchronization of up to eight EMG channels, leveraging high-speed analog-to-digital conversion and advanced filtering techniques implemented directly at the measurement site. By performing filtering and initial signal processing locally, prior to transmission to other subsystems, the system minimizes noise both through optimized processing and by reducing the distance to the muscle, thereby significantly enhancing the signal-to-noise ratio (SNR). A dedicated communication interface ensures low-latency data transfer to external controllers, crucial for adaptive control loops in exoskeletal applications. Experimental results validate the system’s capability to deliver high signal fidelity and low processing delays, outperforming commercial alternatives in terms of flexibility and scalability. This implementation provides a robust foundation for real-time bio-signal processing, advancing the integration of EMG-based control in neurorehabilitation devices. Full article

This study designs and develops a wearable exoskeleton piano assistance system for individuals recovering from neurological injuries, aiming to help users regain the ability to perform complex tasks such as playing the piano. While soft robotic exoskeletons have proven effective in rehabilitation therapy and daily activity assistance, challenges remain in performing highly dexterous tasks due to structural complexity and insufficient motion accuracy. To address these issues, we developed a modular division method based on multi-domain mapping and a top-down process model. This method integrates the functional domain, structural domain, and user needs domain, and explores the principles and methods for creating functional construction modules, overcoming the limitations of traditional top-down approaches in design flexibility. By closely combining layout constraints with the design model, this method significantly improves the accuracy and efficiency of module configuration, offering a new path for the development of piano practice assistance devices. The results demonstrate that this device innovatively combines piano practice with rehabilitation training and through the introduction of ontological modeling methods, resolves the challenges of multidimensional needs mapping. Based on five user requirements (P), we calculated the corresponding demand weight (K), making the design more aligned with user needs. The device excels in enhancing motion accuracy, interactivity, and comfort, filling the gap in traditional piano assistance devices in terms of multi-functionality and high adaptability, and offering new ideas for the design and promotion of intelligent assistive devices. Simulation analysis, combined with the motion trajectory of the finger’s proximal joint, calculates that 60° is the maximum bending angle for the aforementioned joint. Physical validation confirms the device’s superior performance in terms of reliability and high-precision motion reproduction, meeting the requirements for piano-assisted training. Through multi-domain mapping, the top-down process model, and modular design, this research effectively breaks through the design flexibility and functional adaptability bottleneck of traditional piano assistance devices while integrating neurological rehabilitation with music education, opening up a new application path for intelligent assistive devices in the fields of rehabilitation medicine and arts education, and providing a solution for cross-disciplinary technology fusion and innovative development. Full article

As a new development direction in exoskeleton research, wearable flexible exoskeleton systems are highly favored for their freedom of movement, flexibility, lightweight design, and comfortable wearability. These systems are gradually becoming the preferred choice for rehabilitation therapy, and enhancing physical performance. In this thesis, based on existing research in wearable flexible exoskeletons, we aim to design a lightweight wearable upper limb rehabilitation exoskeleton that meets the needs of stroke patients with a high likelihood of upper limb impairment. The system should provide sufficient flexibility for comfortable and convenient use while minimizing the weight to reduce the user’s burden during wear. Our proposed lightweight wearable flexible exoskeleton assists users in achieving rehabilitation exercises for both the shoulder (external/internal rotation) and forearm (flexion/extension) movements. The system consists of a flexible fabric section connecting the torso–shoulder–upper arm, a flexible fabric section for the forearm, and a back-mounted actuation device. The fabric sections primarily consist of elastic textile materials with a few rigid components. Emphasizing lightweight design, we strive to minimize the exoskeleton’s weight, ensuring optimal user comfort. The actuation device connects to the fabric sections via tensioned wires, driven by a motor to induce arm movement during rehabilitation exercises. To enhance safety and prevent secondary upper limb injuries due to exoskeleton malfunction, we incorporate a physical limiter retricting the exoskeleton’s range of motion. Additionally, we include tension-adjustment mechanisms and cushioning springs to improve the feasibility of this wearable flexible exoskeleton. After completing the structural design, this paper conducted a basic static and kinematic analysis of the exoskeleton system to provide theoretical support. Additionally, the feasibility and effectiveness of the exoskeleton system design were verified through dynamic simulations. Full article

The engineering of actuation systems for active exoskeletons presents a significant challenge due to the stringent demands for mass reduction and compactness, coupled with complex specifications for actuator dynamics and stroke length. This challenge is met with a model-based methodology. Models for human body, exoskeleton and parametric actuation systems are derived and coupled. Beginning with an inverse dynamics human body simulation, loads in human joints are estimated, and the corresponding support torques are derived. Under the assumption of a control law ensuring these support torques, an optimization problem is stated to determine actuation system parameters such as the number of stator coils and number of battery cells. Lastly, results from the optimization are validated using sophisticated models. The methodology is applied to an exemplary exoskeleton and compared to an approach derived from previous studies. Full article

This paper presents a novel approach to enhancing the performance of artificial muscle fibers by incorporating air gaps within the bulk dielectric material. Building on previous models, the COMSOL simulation was developed to investigate the effects of varying the inner ligament width (‘w3’) and air gap width (‘w2’) on force production. Results indicated that an air gap width of 50 µm is optimal, balancing improved force output with manufacturability constraints. A longitudinal array sweep was conducted to determine force density saturation in long fiber arrays, comparing the gap model with a traditional non-gap model. The gap model demonstrated superior performance, achieving higher force densities and better energy efficiency. The inclusion of air gaps reduced overall weight, enhanced flexibility, and improved the force-to-weight ratio, making the design particularly suitable for applications in prosthetics, exoskeletons, and soft robotics. These findings suggest that the air gap design represents a significant advancement in artificial muscle technology, offering a practical and efficient solution for various biomedical and robotic applications. Full article

An exoskeleton is a wearable device with human–machine interaction characteristics. An ideal exoskeleton should have kinematic and kinetic characteristics similar to those of the wearer. Most traditional exoskeletons are driven by rigid actuators based on joint torque or position control algorithms. In order to achieve better human–robot interaction, flexible actuators have been introduced into exoskeletons. However, exoskeletons with fixed stiffness cannot adapt to changing stiffness requirements during assistance. In order to achieve collaborative control of stiffness and torque, a bionic variable stiffness hip joint exoskeleton (BVS-HJE) is designed in this article. The exoskeleton proposed in this article is inspired by the muscles that come in agonist–antagonist pairs, whose actuators are arranged in an antagonistic form on both sides of the hip joint. Compared with other exoskeletons, it has antagonistic actuators with variable stiffness mechanisms, which allow the stiffness control of the exoskeleton joint independent of force (or position) control. A BVS-HJE model was established to study its variable stiffness and static characteristics. Based on the characteristics of the BVS-HJE, a control strategy is proposed that can achieve independent adjustment of joint torque and joint stiffness. In addition, the variable stiffness mechanism can estimate the output force based on the established mathematical model through an encoder, thus eliminating the additional force sensors in the control process. Finally, the variable stiffness properties of the actuator and the controllability of joint stiffness and joint torque were verified through experiments. Full article

Over the past few years, interest in wearable exoskeleton gloves has grown. These tools can be used to help those who are healthy or to support those who have neurological and musculoskeletal conditions like stroke, spinal cord injury, etc. The hand, which is the human body’s most flexible limb, encounters more difficult problems and recovers considerably more slowly than the lower and upper limbs. In light of these difficulties, a novel therapy called exoskeleton-based rehabilitation has gained increased significance. In this work, we concentrate on creating a wearable exoskeleton glove that is inexpensive to improve the user’s grasping abilities. The tool significantly raises the user’s gripping capacity, which raises their quality of life. The exoskeleton glove is designed to assist human hands with limited mobility during the motion rehabilitation process and to improve the grasping and dexterous manipulation capabilities of the hands of both impaired and able-bodied individuals. The proposed model consists of two types of systems, mainly the tendon driven system and the pneumatic system. The tendon-driven system is the system that helps in the flexion and extension movements of the hand. The efficiency of the exoskeleton glove is evaluated by performing the basic movements of hand like abduction, adduction, flexion, and extension. The developed hybrid exoskeleton glove can efficiently enhance the grasping capabilities of its users, offering, affordable, lightweight and easy-to-operate solutions that can assist in the execution of activities of daily living (ADL). Full article

This paper explores the adaptation of pseudo-rigid-body models (PRBMs) for simulating large geometric nonlinear deflections in passive exoskeletons, expanding upon their traditional application in small compliant systems. Utilizing the AnyBody modeling system, this study employs force-dependent kinematics to reverse the conventional simulation process, enabling the calculation of forces from the deformation of PRBMs. A novel approach, termed “Constraint Force”, is introduced to facilitate this computation. The approach is thoroughly validated through comparative analysis with laboratory trials involving a beam under bending loads. To demonstrate the functionality, the final segment of this study conducts a biomechanical simulation incorporating motion capture data from a lifting test, employing a novel passive exoskeleton equipped with flexible spring elements. The approach is meticulously described to enable easy adaptation, with an example code for practical application. The findings present a user-friendly and visually appealing simulation solution capable of effectively modeling complex mechanical load cases. However, the validation process highlights significant systematic errors in the direction and amplitude of the calculated forces (20% and 35%, respectively, in the worst loading case) compared to the laboratory results. These discrepancies emphasize the inherent accuracy challenges of the “Constraint Force” approach, pointing to areas for ongoing research and enhancement of PRBM methods. Full article

Robots with flexible joints are gaining importance in areas such as collaborative robots (cobots), exoskeletons, and prostheses. They are meant to directly interact with humans, and the emphasis in their construction is not on precision but rather on weight reduction and soft interaction with humans. Well-known rigid robot control strategies are not valid in this area, so new control methods have been proposed to deal with the complexity introduced by elasticity. Some of these methods are seldom used and are unknown to most of the academic community. After selecting the methods, we carried out a comprehensive comparative study of algorithms: simple gravity compensation (Sgc), the singular perturbation method (Spm), the passivity-based approach (Pba), backstepping control design (Bcd), and exact gravity cancellation (Egc). We modeled these algorithms using MATLAB and simulated them for different stiffness levels. Furthermore, their practical implementation was analyzed from the perspective of the magnitudes to be measured and the computational costs of their implementation. In conclusion, the Sgc method is a fast and affordable solution if joint stiffness is relatively high. If good performance is necessary, the Pba is the best option. Full article
