Search Results (59)

The role of distributed energy resources in distribution networks is evolving to support system operation, facilitated by their participation in local flexibility markets. Future scenarios envision a significant share of low-power resources providing ancillary services to efficiently manage network congestions, offering a competitive alternative to conventional grid reinforcement. Additionally, the interaction between distribution and transmission systems enables the provision of flexibility services at higher voltage levels for various applications. In such cases, the aggregated flexibility of low-power resources is typically represented as a capability envelope at the interface between the distribution and transmission network, constructed by accounting for distribution grid constraints and subsequently communicated to the transmission system operator. This paper revisits this concept and introduces a novel approach for envelope construction. The proposed method is based on a surrogate model composed of a limited set of standard power flow components—loads, generators, and storage units—enhancing the integration of distribution network flexibility into transmission-level optimization frameworks. Notably, this advantage can potentially be achieved without significant modifications to the optimization tools currently available to grid operators. The effectiveness of the approach is demonstrated through a case study in which the adoption of distribution network surrogate models within a coordinated framework between transmission and distribution operators enables the provision of ancillary services for transmission resilience support. This results in improved resilience indicators and lower control action costs compared to conventional shedding schemes. Full article

Phase-shifting transformers (PST) are widely used to control power flows. However, conventional designs can vary only the phase angle, leaving the voltage magnitude unaffected or requiring structurally complex devices. This study proposes a compact PST topology that realizes simultaneous, decoupled control of both voltage magnitude and phase angle through two coordinated sets of windings. Closed-form equations are derived to link the phase-shifting and voltage regulation windings turn ratios to any target magnitude ratio and phase-shift angle, providing a unified design framework that guarantees the full practical operating range. Steady-state tests verify that the device can change the phase or adjust the magnitude independently without cross-coupling. Dynamic tests demonstrate that, when a tap command is issued, the line currents and active power converge to new set-points within a few fundamental periods and with minimal oscillation. Furthermore, the PST’s application to loop closing operations in 220 kV networks is investigated, where simulation results show it can suppress loop closing currents by over 90% under adverse voltage mismatch conditions. These results confirm that the proposed PST offers a fast, economical alternative to Flexible AC Transmission Systems (FACTS) equipment for real-time power flow balancing, renewable integration and inter-area exchange in modern transmission networks. Full article

Driven by the environmental benefits associated with reduced greenhouse gas emissions, oil companies have intensified research efforts into reassessing the strategies used to meet the electrical demands of offshore production platforms. Among the various alternatives available, the deployment of onshore–offshore interconnections via High-Voltage Direct Current (HVDC) transmission systems has emerged as a promising solution, offering both economic and operational advantages. In addition to reliably meeting the electrical demand of offshore facilities, this approach enables enhanced operational flexibility due to the advanced control and regulation capabilities inherent to HVDC converter stations. Based on the use of interconnection through an HVDC link, aiming to evaluate the operation of the electrical system as a whole, this study focuses on evaluating dynamic events using the PSCAD software version 5.0.2 to analyze the direct online starting of a large induction motor and the sudden loss of a local synchronous generating unit. The simulation results are then analyzed to assess the effectiveness of both Grid-Following (GFL) and Grid-Forming (GFM) control strategies for the converters, while the synchronous generators are evaluated under both voltage regulation and constant power factor control operation, with a particular focus on system stability and restoration of normal operating conditions in the sequence of events. Full article

This study evaluates and compares centralized and distributed reactive power compensation strategies using Static Var Compensators (SVCs) to enhance the performance of a high-voltage transmission system in the Caribbean region of Colombia. The methodology comprises four stages: system characterization, assessment of the uncompensated condition under peak demand, definition of four SVC-based scenarios, and steady-state analysis through power flow simulations using DIgSILENT PowerFactory. SVCs were modeled as Thyristor-Controlled Devices (“SVC Type 1”) operating as PV nodes for voltage regulation. The evaluated scenarios include centralized SVCs at the Slack node, node N4, and node N20, as well as a distributed scheme across load nodes N51 to N55. Node selection was guided by power flow analysis, identifying voltage drops below 0.9 pu and overloads above 125%. Technically, the distributed strategy outperformed the centralized alternatives, reducing active power losses by 37.5%, reactive power exchange by 46.1%, and improving node voltages from 0.71 pu to values above 0.92 pu while requiring only 437 MVAr of compensation compared to 600 MVAr in centralized cases. Economically, the distributed configuration achieved the highest annual energy savings (36 GWh), the greatest financial return (USD 5.94 M/year), and the shortest payback period (7.4 years), highlighting its cost-effectiveness. This study’s novelty lies in its system-level comparison of SVC deployment strategies under real operating constraints. The results demonstrate that distributed compensation not only improves technical performance but also provides a financially viable solution for enhancing grid reliability in infrastructure-limited transmission systems. Full article

Transmission flexibility is a key component of current power systems and demands a reconfiguration of alternatives to expand transmission infrastructure. This paper addresses the use of a Battery Energy Storage System (BESS) as an asset of the transmission system that provides increased transmission capacity. Furthermore, the BESS also supports operational procedures of the transmission system in the course of the re-establishment of normal operation during transients, which helps maintain the power quality requirements. A case study is presented to assess the additional capabilities that an operational 30 MW/60 MWh BESS primarily used to provide congestion relief in the state of São Paulo, Brazil, could provide to the power system. Based on a 5-year horizon transmission and generation expansion plans by local governing bodies, a set of four alternative applications for this BESS was proposed and studied, as follows: (1) increased operational flexibility under contingencies and maintenance, (2) islanded operation for increased reliability, (3) grid support during system restoration, and (4) increased hosting capacity for variable renewables. The results show that the BESS improves performance and power quality indexes while aiding the operation during contingencies. Full article

The thyristor-controlled phase-shift transformer (TCPST) is an effective means of controlling power flow, exhibiting a simple structure and a long operating life. However, conventional TCPSTs are limited in their ability to regulate the phase-shifting angle, necessitating the matching of the step-up/down transformer to control the amplitude of voltages. Therefore, this paper puts forth two distinct structures of TCPSTs, each of which is capable of regulating both the phase-shifting angle and the amplitude of voltages: the two-core step-up/down thyristor-controlled phase-shifting transformer (TCSUD-TCPST) and the single-core step-up/down thyristor-controlled phase-shifting transformer (SCSUD-TCPST). Moreover, a comparison was conducted between the topology structure and the thyristor-controlled strategies of the TCSUD-TCPST and the SCSUD-TCPST. The coupling relationship and the limitations of the phase-shifting angle and the amplitude of voltages are illustrated, indicating that the SCSUD-TCPST appears to be a more suitable option for power transmission. Furthermore, the considerable static and dynamic characteristics of the TCSUD-TCPST and the SCSUD-TCPST were investigated through the PLECS simulation platform, which was also employed to further verify the aforementioned conclusions. Full article

In light of the growing complexity and demand in modern power systems, there is an increasing need for reliable, efficient, and flexible power flow control mechanisms. The Unified Power Flow Controller (UPFC), as a fundamental component of Flexible AC Transmission Systems (FACTSs), has garnered considerable attention due to its exceptional capabilities in regulating power flow and maintaining voltage stability. Nevertheless, the expense associated with high-capacity UPFCs is considerable, thereby rendering their practical implementation challenging. Phase-shifting transformers are less costly but require better power flow characteristics. Therefore, this paper puts forth the proposition of an Advanced Capacity-Expansion-Type Unified Power Flow Controller (ACET-UPFC) based on a single-core phase-shifting transformer (SCPST). This proposed topology is designed to enhance the capacity of the conventional UPFC, while maintaining similar power flow characteristics, and demonstrates strong voltage regulation capabilities, enabling connections across different voltage levels, thereby rendering it more economically feasible for large-scale deployment. This paper presents a detailed analysis of the power flow characteristics of the ACET-UPFC, including a theoretical foundation, mathematical modeling, and an investigation into the impact of various design parameters. Moreover, the ACET-UPFC’s capacity expansion capability and power flow characteristics are also examined. The ACET-UPFC is subjected to further investigation through the use of the PLECS simulation platform, thereby offering a more efficient and cost-effective solution for modern power grids. Full article

The continuously growing penetration of renewable energy sources (RESs) in electrical networks provides increasing challenges and critical situations to be managed by worldwide system operators. Due to their features and variability, non-programmable RES power plants, whose increasing penetration reduces the inertia level of the power system, may determine the instability effects on the grids, especially from the frequency and voltage regulation standpoints. The present study focuses on the support that advanced FACTS (Flexible Alternating Current Transmission System) devices, such as STATCOMs (Static Synchronous Compensators), can provide to the power system operation in terms of system inertia improvement, frequency stability, and voltage stability. In particular, a review of the scientific literature and practice is performed, with the aim of benchmarking the ongoing evolution of these technologies, also comparing them with different options based on synchronous condensers, synchronous condensers integrated with flywheels, and STATCOMs with supercapacitors. The outcome of the analysis consists of an updated evaluation of the state-of-the-art technological development in the field and of a comparison between different FACTSs with the purpose of identifying the most suitable solutions for different practical situations, also taking account of synergies across various options. This study includes an updated overview regarding the status of STATCOM installation in the Italian power grid. Full article

Ensuring the stability of power systems is essential to promote energy sustainability. The integrated operation of these systems is critical in sustaining modern societies and economies, responding to the increasing demand for electricity and curbing environmental consequences. This study focuses on the optimization of energy system stability through the coordination of power system stabilizers (PSSs) and power oscillation dampers (PODs) in a single-machine infinite bus energy grid configuration that has flexible AC alternating current transmission system (FACTS) devices. Intelligent control strategies using PSS and POD techniques are suggested to increase power system stability and generate supplementary control signals for both the generator excitation system and FACTS device switching control. An intelligent optimal modal control framework equipped with deep learning methods is introduced to control the generator excitation system and thyristor-controlled series capacitor (TCSC). By optimally choosing the weighting matrix Q and implementing close-loop pole shifting, an optimal modal control approach is formulated. To harness its adaptive potential in fine-tuning controller parameters, an auxiliary deep learning-based optimization algorithm with actor–critic architecture is implemented. This comprehensive technique provides a promising path to effectively reduce electromechanical oscillations, thereby enhancing voltage regulation and transient stability in power systems. Full article

Modern electrical power networks make extensive use of high voltage direct current transmission systems based on voltage source converters due to their advantages in terms of both cost and flexibility. Moreover, incorporating a direct current link adds more complexity to the optimal power flow computation. This paper presents a new meta-heuristic technique, named self-adaptive bonobo optimizer, which is an improved version of bonobo optimizer. It aims to solve the optimal power flow for alternating current power systems and hybrid systems AC/DC, to find the optimal location of the high voltage direct current line in the network, with a view to minimize the total generation costs and the total active power transmission losses. The self-adaptive bonobo optimizer was tested on the IEEE 30-bus system, and the large-scale Algerian 114-bus electric network. The obtained results were assessed and contrasted with those previously published in the literature in order to demonstrate the effectiveness and potential of the suggested strategy. Full article

Due to the high cost and complex challenges faced by offshore wind power transmission, economic research into offshore wind power transmission can provide a scientific basis for optimal decision-making on offshore wind power projects. Based on the analysis of the topology structure and characteristics of typical wind power transmission schemes, this paper compares the economic benefits of five different transmission schemes with a 3.6 GW sizeable onshore wind farm as the primary case. Research includes traditional high voltage alternating current (HVAC), voltage source converter high voltage direct current transmission (VSC-HVDC), a fractional frequency transmission system (FFTS), and two hybrid DC (MMC-LCC and DR-MMC) transmission scenarios. The entire life cycle cost analysis model (LCCA) is employed to thoroughly assess the cumulative impact of initial investment costs, operational expenses, and eventual scrap costs on top of the overall transmission scheme’s total cost. This comprehensive evaluation ensures a nuanced understanding of the financial implications across the project’s entire lifespan. In this example, HVAC has an economic advantage over VSC-HVDC in the transmission distance range of 78 km, and the financial range of a FFTS is 78–117 km. DR-MMC is better than the flexible DC delivery scheme in terms of transmission capacity, scalability, and offshore working platform construction costs in the DC delivery scheme. Therefore, the hybrid DC delivery scheme of offshore wind power composed of multi-type converters has excellent application prospects. Full article

Voltage source converters (VSCs) have emerged as the key components in modern power systems, facilitating efficient energy conversion and flexible power flow control. Understanding the fundamental circuit model of VSCs is essential for their accurate modeling and analysis in power system studies. A basic voltage source converter circuit model connected to an LC filter is essential because it lowers the harmonic distortions and enhances the overall power quality of the micro-grid. This guarantees a clean and steady power supply, which is necessary for the integration of multiple renewable energy sources and sensitive loads. A comprehensive methodology for developing a basic circuit model of VSCs, focusing on the key components and principals involved, is presented in this paper. The methodology includes the modeling of space vector pulse-width modulation (SVPWM) as well as the direct quadrature zero synchronous reference frame. Different design controls, including the design of current control loop in the S-domain, the design of the direct current (DC) bus voltage control loop in the S-domain, and the design of the alternating current (AC) voltage control loop in the S-domain, are explored to capture the dynamic behavior and control strategies of VSCs accurately. The proposed methodology provides a systematic framework for modeling VSCs, enabling engineers and researchers to analyze their performance and assess their impact on power system stability and operation. Future studies can be conducted by using case studies and simulation scenarios to show the efficiency and applicability of the developed models in analyzing VSC-based power electronics applications, including high-voltage direct current (HVDC) transmission systems and flexible alternating current transmission systems (FACTS). The significance of this work lies in its potential to advance the understanding and application of VSCs, contributing to more resilient and efficient power systems. By providing a solid foundation for future research and development, this study supports the ongoing integration of renewable energy sources and the advancement of modern electrical infrastructure. Full article

Due to the increasing demand for transport of electrical energy, measures for power flow control, congestion management, and higher utilisation of the existing grid play a decisive role in the transformation of the power system. Hence, enormous efforts must be undertaken using measures of congestion management. Modelling and integration of corresponding measures in optimisation tools to support grid and system operation and therewith reduce the resulting efforts become more important. This is especially true because of the high intermittency and decentralisation of renewable generation leading to increased complexity of the power system, higher loading of assets, and a growing need for control over flexible alternating current transmission systems (FACTS) and high-voltage direct current (HVDC) converters. This work therefore describes the implementation of optimised congestion management in an A Mathematical Programming Language (AMPL)-based nonlinear optimisation problem. AMPL is an effective tool to deal with highly complex problems of optimisation and scheduling. Therefore, the modelling of assets and flexibilities for power flow control in AC/DC systems in combination with an innovative grid operation strategy using predefined curative measures for the optimised use of the existing grid is introduced. The nonlinear mathematical optimisation aims at the optimal cost selection of flexibility measures. The application of the optimisation technique in a combined AC/DC system shows the optimal preventive and curative use of measures in operational congestion management. Simulation results prove that, by using predefined curative measures, the volume of cost-intensive preventive measures can significantly be reduced, especially in association with power flow control. Full article

The interline power flow controller (IPFC) is one of the most versatile integrated flexible alternating current transmission systems (FACTS) controllers and can realize power flow control for multiple transmission lines in modern power systems. However, control characteristics are ignored in conventional IPFC models, in which unreasonable assumptions about injected voltages may lead to security problems in realistic operation. Besides, preventive security constraints considering IPFC control modes are not included in optimal power flow (OPF) control of the system with IPFC, squandering IPFC control potential. To solve these problems, a preventive-security-constrained optimal power flow (PSCOPF) model considering IPFC control modes is proposed in this paper. IPFC control characteristics under different control modes are analyzed and employed as constraints of the optimization model. The iterative updates of converter output voltages for different control modes are derived respectively for power flow calculation, and the power and voltages required in the objective function and constraints of the proposed model can then be obtained. Through optimal selection of IPFC control modes and control parameters, the proposed model can better reconcile the economical and secure operation of the system. Numerical results demonstrate the efficient performance and superiority of the PSCOPF model considering IPFC control modes. Full article

Flexible alternating current transmission systems (FACTSs) have been widely incorporated in electric power systems in order to control system parameters. This paper proposes the modeling of four FACTS devices, using the Branch Flow Model (BF) as an optimization problem to reduce the complexity of the Newton–Raphson (NR) load flow code with FACTS devices. The devices are represented as variable impedances, as a function of a firing angle, and as voltage source converters (VSCs) located on the buses and transmission lines. This proposed model solves the problem associated with the selection of appropriate initial conditions of the parameters of each device that guarantee convergence. The model is validated by evaluating its percentage deviation with respect to the NR method, using the standard test systems, IEEE 5-bus, IEEE 14-bus, IEEE 30-bus, and IEEE 57-bus systems. Full article
