Search Results (64)

This paper presents a high-sensitivity and anti-interference optical intensity differential curvature sensor based on seven-core fiber (SCF), and its performance is verified through simulation. The sensor adopts a “single-mode fiber–tapered SCF” structure, using the light intensity ratio between the peripheral core and the central core for curvature demodulation. It enhances the sensitivity while effectively suppressing common-mode interference. The simulation results show that when the cone zone diameter of the tapered SCF is optimized to 30 µm, the mode coupling between the cores is significant, forming a strongly coupled super-mode transmission system. Based on the intensity differential principle, this sensor achieves excellent linear response within the curvature range of 0–10 m⁻¹, with a sensitivity of −0.145/m⁻¹. The sensor has a compact structure and simple fabrication process, providing new ideas and solutions to break through the technical bottlenecks of existing fiber curvature sensors, and has broad application prospects in engineering monitoring fields. Full article

We propose a vector bending sensor based on a tapered few-mode multi-core fiber (FM-MCF). A seven-core six-mode fiber is tapered with an optimized taper ratio, enabling bending sensing through power monitoring. When the tapered FM-MCF bends, coupling occurs between the central core and side cores in the tapered region. By monitoring the power of all cores and employing a power differential method, the bending direction and curvature can be reconstructed. The results show that within a curvature range of 2.5 m⁻¹ to 10 m⁻¹, the sensitivity of the ratio of the side core’s power to the middle core’s power with respect to curvature is not less than 0.14/m⁻¹. A deep fully connected feedforward neural network (DNN) is used to demodulate all power information and predict the bending shape of the optical fiber. The algorithm predicts the bending radius and rotation angle with mean absolute errors less than 0.038 m and 3.087°, respectively. This method is expected to achieve low-cost, high-sensitivity bending measurement applications with vector direction perception, providing an effective solution for scenarios with small curvatures that are challenging to detect using conventional sensing methods. Full article

This paper proposes a long-period grating (LPG) based on double-clad fibers (DCFs) for multi-parameter sensing. The sensor consists of cascaded-input single-mode fibers (SMF), DCF, and output SMF. Multi-parameter detection is realized by utilizing the different sensing characteristics of the resonance peak under different physical parameters. The experiment results show that within the temperature range of 30–100 °C, the maximum sensitivity is 66.37 pm/°C. For the refractive index (RI) measurement, the tested range is 1.3309–1.3888 and the maximum sensitivity is −45.84 nm/RIU. Regarding curvature detection, the tested range is 0.6928–1.6971 m⁻¹ and the maximum sensitivity is −2.022 nm/m⁻¹. In addition, the sensor has a symmetrical structure, so its measurement is not restricted by the incident direction of light, thus having flexibility in practical use. This research not only contributes to the advancement of optical fiber sensor technology but also has significant implications for practical applications in industry, the environment, and healthcare. Full article

Shape-sensing optical fibers have become increasingly important in applications requiring flexible navigation, spatial awareness, and deformation monitoring. Fiber Bragg Grating (FBG) sensors inscribed in multi-core optical fibers have been democratized over the years and nowadays offer a compact and robust platform for shape reconstruction. In this work, we propose a novel, computationally efficient method for determining the 3D tip position of a bent multi-core FBG-based optical fiber using a second-order polynomial approximation of the fiber’s shape. The method begins with a calibration procedure, where polynomial coefficients are fitted for known bend configurations and subsequently modeled as a function of curvature using exponential decay functions. This allows for real-time estimation of the fiber tip position from curvature measurements alone, with no need for iterative numerical solutions or high processing power. The method was validated using miniaturized test structures and achieved sub-millimeter accuracy (<0.1 mm) over a 4.5 mm displacement range. Its simplicity and accuracy make it suitable for embedded or edge-computing applications in confined navigation, structural inspection, and medical robotics. Full article

Shape sensing with optical fiber sensors is an emerging technology with broad applications across various fields. This study evaluates the metrological performance of shape sensing cables in the presence of fiber core failures, a critical issue in scenarios where cable replacement is impractical due to technological and economic constraints. The impact of core failure is quantified by comparing the uncertainty in key parameters, such as curvature and bending angle, between pristine and damaged cables through Monte Carlo simulations. Results indicate that while core failure degrades performance, shape reconstruction remains achievable. However, the reconstruction becomes sensitive to bending direction due to the loss of core symmetry. Additionally, simulations of how measurement noise propagates into uncertainty in the 3D shape reconstruction are carried out. Analysis of specific shapes, including a circle and a right-handed helix, shows that increasing the number of sensing cores significantly mitigates the adverse effects of core failure. The most notable improvement occurs when the number of cores is increased from four to five. These findings show how shape reconstruction is still possible even in the presence of core damage, and how this changes the behavior of the sensing process. Full article

Optical fiber-based acoustic detectors for ultrasound imaging in medical field feature plano-concave Fabry–Perot cavities integrated on fiber tips, realized via dip-coating. This technique imposes constraints on sensor geometry, potentially limiting performance. Lab-on-Fiber technology enables complex three-dimensional structures with precise control over geometric parameters, such as the curvature radius. A careful investigation of the optical and mechanical aspects involved in the sensors’ performances is crucial for determining the design rules of such probes. In this study, we numerically analyzed the impact of curvature on the optical and acoustic properties of a plano-concave cavity using the Finite Element Method. Performance metrics, including sensitivity, bandwidth, and directivity, were compared to planar Fabry–Perot configurations. The results suggest that introducing curvature significantly enhances sensitivity by improving light confinement, especially for cavity thicknesses exceeding half the Rayleigh zone (∼45 μm), reaching an enhancement of 2.5 a L = 60 μm compared to planar designs. The curved structure maintains high spectral quality (FOM) despite 2% fabrication perturbations. A mechanical analysis confirms no disadvantages in acoustic response and bandwidth (∼40 MHz). These findings establish curved plano-concave structures as robust and reliable for high-sensitivity polymeric lab-on-fiber ultrasound detectors, offering improved performance and fabrication tolerance for MHz-scale bandwidth applications. Full article

Damage to buried gas pipelines caused by mining activities has been frequently reported. Based on a case study from the Central China coal mining area, this research employs a scaled model experiment to investigate the movement of overlying strata in a room-and-pillar mining goaf. Distributed optical fiber strain sensors and thin-film pressure sensors were used to simultaneously measure the stress variations in the pipeline and changes in the soil pressure surrounding it. As the mining recovery rate increased from 50% to 86%, the maximum displacement of the overburden sharply escalated from 33.55 mm to 79.19 mm. During surface subsidence, separation between the pipeline and surrounding soil was observed, leading to the formation of a soil-arching effect. The development of the soil-arching effect increased soil pressure on the top of the pipeline, while soil pressure at the bottom of the pipeline increased on the outer side of the subsidence area and decreased on the inner side. Three critical sections of the pipeline were identified, with the maximum stress reaching 1908.41 kPa. After the completion of mining activities, pipeline collapse occurred, leading to a weakening of the soil-arching effect. Consequently, both stress concentration in the pipeline and soil pressure decreased. The probability integral method was corrected by incorporating the fracture angle, which enabled the determination of the location of maximum surface subsidence curvature, found to be close to the three failure sections of the pipeline. Full article

We present a high-sensitivity curvature and strain Mach–Zehnder interferometer (MZI) fiber sensor based on a configuration of no-core fiber (NCF) and four-core fiber (FCF). We used an optical fiber fusion splicer to directly splice a segment of FCF between two segments of NCF, with both the FCF and NCF made of SiO₂, where the FCF exhibits multi-path interference characteristics that allow for higher sensitivity. The NCF, with its self-focusing property, excites higher-order modes, which split and transmit it into the four cores of the FCF. The experimental results show that within a curvature range of 0.0104 m⁻¹–0.1515 m⁻¹, the maximum sensitivity can reach −78.04 dB/m⁻¹ with a high linear value of ~0.99. Additionally, the strain response is also experimentally studied. In the range of 0–600 με, the maximum strain sensitivity is −6.49 pm/με. The sensor demonstrates high curvature and strain sensitivity, indicating its potential applications in sensing measurements. Full article

In this work, we propose a fiber Bragg grating (FBG)-based sensor for curvature measurements. Two gratings are inscribed through the protective coating in a specialty optical fiber using focused femtosecond laser pulses and point-by-point direct writing technology. One grating is inscribed on the central core adjacent to an air channel, while the other is inscribed on the eccentric core. The bending characteristics of the two-core fiber strongly depend on the bending direction due to the asymmetry of the fiber cores. A bending sensitivity of 58 $\mathrm{p}\mathrm{m}/{\mathrm{m}}^{-1}$ is achieved by the FBG in the eccentric fiber core over the curvature range of 0–50 ${\mathrm{m}}^{-1}$. Temperature and humidity cross-sensitivity could be significantly reduced by analyzing the differences in peak shifts between the two gratings. The sensor features a large sensing range and good robustness due to the presence of its protective buffer coating, which makes it a good candidate for curvature sensing in engineering fields. Full article

This article presents a long-period fiber-grating sensor based on a congruent quasi-helical structure (CQH-LPFG) with the two-parameter measurement of both temperature and curvature. The CQH-LPFG sensor was manufactured using a high-frequency CO₂ laser, and an innovative quasi-helical structure was introduced into the two-parameter measurement of the temperature and curvature of the optical fiber sensor with excellent results. The experiment and analysis demonstrate that the curvature sensitivities of the three resonance peaks in the 1440 nm to 1540 nm transmission spectrum were 11.88 nm/m⁻¹, 8.05 nm/m⁻¹, and 11.11 nm/m⁻¹, and the curvature varied ranging from 0.156 m⁻¹ to 0.494 m⁻¹. The three resonance peaks showed temperature responsivities of 29.87 pm/°C, 24.65 pm/°C, and 36.85 pm/°C, respectively, and the linear fit was of excellent quality. In the case of measuring both curvature and temperature changes simultaneously, the resonant peak wavelength of the CQH-LPFG sensor was demodulated through matrix analysis, with dip A and dip C providing superior simultaneous measurements. These features make it a promising candidate for applications such as engineering machinery and the health inspection of buildings. Full article

A vector curvature and temperature sensor based on an in-fiber hybrid microstructure is proposed and experimentally demonstrated. The proposed scheme enables the dimensions of the Fabry–Perot and Mach–Zehnder hybrid interferometer to be adjusted for the formation of the Vernier effect by simply changing the length of a single optical fiber. The sensor is fabricated using a fiber Bragg grating (FBG), multimode fiber (MMF), and a single-hole dual-core fiber (SHDCF). The sensor exhibits different curvature sensitivities in four vertical directions, enabling two-dimensional curvature sensing. The temperature and curvature sensitivities of the sensor were enhanced to 100 pm/°C and −25.55 nm/m⁻¹, respectively, and the temperature crosstalk was minimal at −3.9 × 10⁻³ m⁻¹/°C. This hybrid microstructure sensor technology can be applied to high-sensitivity two-dimensional vector curvature and temperature detection for structural health monitoring of buildings, bridge engineering, and other related fields. Full article

A high-sensitivity curvature sensor with dual-parameter measurement ability based on angularly cascaded long-period fiber grating (AC-LPFG) is proposed and experimentally demonstrated, which consists of two titled LPFGs (TLPFGs) with different tilt angles and the same grating period. AC-LPFG was fabricated by using a deep ultraviolet laser and an amplitude-mask in our laboratory. The experimental results show that simultaneous measurement of curvature and temperature can be achieved by monitoring the wavelengths of two resonant peaks for different TLPFGs. The two peaks show opposite shifts with increasing curvature and has a maximum curvature sensitivity of 16.392 nm/m⁻¹. With the advantages of low cost, high sensitivity, and dual-parameter measurements, our sensor has more potential for engineering applications. Full article

Real-time online identification of spacecraft segment damage is of great significance for realizing spacecraft structural health monitoring and life prediction. In this paper, a damage response characteristic field inversion algorithm based on the differential reconstruction of strain response is proposed to solve the problem of not being able to recognize the small damages of spacecraft structure directly by the strain response alone. Four crack damage location identification methods based on vector norm computation are proposed, which realize online identification and precise location of structural damage events without external excitation by means of spacecraft structural working loads only. A spacecraft segment structural damage monitoring system based on fiber optic grating sensors was constructed, and the average error of damage localization based on the curvature vector 2 norm calculation was 2.58 mm, and the root-mean-square error was 1.98 mm. The results show that the method has superior engineering applicability for on-orbit service environments. Full article

An optical fiber sensor for the simultaneous measurement of microdisplacement and temperature based on balloon-shaped single-mode fibers cascaded with a fiber Bragg grating with two core-offset joints is proposed. The interference between the core mode and cladding mode is caused by the stimulation of the cladding mode by the core-offset joints’ structure. The cladding of the core has a distinct refractive index, which causes optical path differences and interference. The balloon-shaped structure realizes mode selection by bending. As the displacement increases, the radius of the balloon-shaped interferometer changes, resulting in a change in the interference fringes of the interferometer, while the Bragg wavelength of the fiber grating remains unchanged. Temperature changes will cause the interference fringes of the interferometer and the Bragg wavelength of the fiber grating to shift. The proposed optical fiber sensor allows for the simultaneous measurement of microdisplacement and temperature. The results of the experiment indicate that the sensitivity of the interferometer to microdisplacement is 0.306 nm/µm in the sensing range of 0 to 200 μm and that the temperature sensitivity is 0.165 nm/°C, respectively. The proposed curvature sensor has the advantages of a compact structure, extensive spectrum of dynamic measurement, high sensitivity, and simple preparation, and has a wide range of potential applications in the fields of structural safety monitoring, aviation industry, and resource exploration. Full article

This paper presents the development and application of an optical fiber-embedded tendon based on biomimetic multifunctional structures. The tendon was fabricated using a thermocure resin (polyurethane) and the three optical fibers with one fiber Bragg grating (FBG) inscribed in each fiber. The first step in the FBG-integrated artificial tendon analysis is the mechanical properties assessment through stress–strain curves, which indicated the customization of the proposed device, since it is possible to tailor the Young’s modulus and strain limit of the tendon as a function of the integrated optical fibers, where the coated and uncoated fibers lead to differences in both parameters, i.e., strain limits and Young’s modulus. Then, the artificial tendon integrated with FBG sensors undergoes three types of characterization, which assesses the influence of temperature, single-axis strain, and curvature. Results show similarities in the temperature responses in all analyzed FBGs, where the variations are related to the heterogeneity on the polyurethane matrix distribution. In contrast, the FBGs embedded in the tendon presented a reduction in the strain sensitivity when compared with the bare FBGs (i.e., without the integration in the artificial tendon). Such results demonstrated a reduction in the sensitivity as high as 77% when compared with the bare FBGs, which is related to strain field distributions in the FBGs when embedded in the tendon. In addition, the curvature tests indicated variations in both optical power and wavelength shift, where both parameters are used on the angle estimation using the proposed multifunctional artificial tendon. To that extent, root mean squared error of around 3.25° is obtained when both spectral features are considered. Therefore, the proposed approach indicates a suitable method for the development of smart structures in which the multifunctional capability of the device leads to the possibility of using not only as a structural element in tendon-driven actuators and devices, but also as a sensor element for the different structures. Full article
