In this paper, a high-sensitivity sub-zero temperature sensor based on the Mach–Zehnder interferometer coated with organic silicone film is proposed. The sensor is fabricated by polishing four orthogonal sides in the multimode fiber (MMF) of the single-mode–multimode–single-mode (SMS) structure with a CO₂ laser and then coating the structure with a mixed film of hydroxyl-terminated siloxane and methyl MQ silicone resin to form a sub-zero-sensitive layer. The sub-zero temperature sensitivity of the coated sensors is experimentally compared for samples with different numbers of polished facets. The experimental results show that the sub-zero temperature sensitivity of the sensors with one to four polished facets increased from 0.73 nm/K to 2.15 nm/K in the temperature range of 223 K to 273 K. The fiber sub-zero sensor has the advantages of compact structure, high sensitivity and low cost, which lead to the potential for application in fields such as biomedicine, aerospace and energy. Full article

To resolve the discrepancy between the measured strain and the actual surface strain of wind turbine blades when using rubber-encapsulated fiber Bragg grating (FBG) sensors for strain monitoring, this study establishes a surface-bonded strain transfer model for such sensors. The total strain transfer efficiency of the sensor is decomposed into two components: the strain transfer efficiency from the rubber substrate to the FBG core (encapsulated grating strain transfer efficiency) and that from the wind turbine blade to the rubber substrate (strain transfer efficiency between the rubber substrate and the blade). Based on the theory of mechanics of materials, the strain transfer equation is derived, and the key factors influencing strain transfer efficiency—FBG bonding length and rubber substrate thickness—are analyzed via the control variable method. Three ethylene propylene diene monomer (EPDM)-encapsulated FBG sensors with rubber substrate thicknesses of 3 mm, 4 mm, and 6 mm were fabricated. Tensile strain transfer tests were conducted using fiber-reinforced plastic (FRP) strips to simulate the material properties of wind turbine blades, so as to validate the effectiveness of the proposed model. The experimental results demonstrate that the strain transfer efficiency of the sensor increases with the extension of FBG bonding length and decreases with the increase in rubber substrate thickness, with 4 mm determined as the optimal substrate thickness for EPDM-encapsulated FBG sensors. On the basis of the aforementioned findings, an EPDM-encapsulated FBG strain rosette sensor was developed, which can effectively measure the complex stress of a wind turbine blade model. This study provides a theoretical foundation for the structural design and engineering application of rubber-encapsulated FBG sensors in the strain monitoring of wind turbine blades. Full article

When traditional geogrids are used to mitigate reflective cracks in asphalt pavement, it is difficult to monitor the internal state of the pavement and the strain of the geogrid in real time. This study proposes a sensing geogrid based on warp-knitting technology, where fiber Bragg grating (FBG) sensors are embedded into the geogrid through the weaving process, enabling it to possess both reinforcement and strain-sensing functions. The sensing geogrid was calibrated through laboratory tensile tests, and field monitoring was conducted to obtain optical signal variation data at various stages during asphalt pavement paving, as well as the deformation of the geogrid at different measurement points in each stage. The results indicate that the weaving process did not damage the FBG sensors, and the sensing geogrid exhibited good optical signal performance and normal signal acquisition during the production and transportation stages. The strain of the FBG sensors and the geogrid showed a linear correlation, with a correlation coefficient of 845 με/nm, demonstrating good deformation compatibility between them. Field monitoring confirmed that the sensing geogrid has good construction adaptability and can perceive fluctuations in optical signals and deformation of the geogrid during the construction process. Specifically, significant deformation of the geogrid occurred during the construction of the asphalt-treated base (ATB-25) and bottom layers, accompanied by substantial fluctuations in optical signals due to construction machinery. In contrast, signal fluctuations were smaller during the construction of the middle and surface layers, with the influence depth of construction machinery being approximately 22 cm. Compared to ordinary road sections, the deflection basin curve of the reinforced section was gentler, and the maximum deflection was reduced by approximately 41%. This study confirms the feasibility of the sensing geogrid and provides a valuable reference for its application in road engineering. Full article

Deflection is a crucial indicator for structural safety assessment and maintenance of engineering structures. Traditional deflection inspection methods are confronted with the difficulty in selecting reference points, and therefore these methods are usually applied in short-term monitoring of structures. In this context, a novel strategy for automatic deflection inspection of beam-like composite structures which overcomes the difficulty in selecting reference points is put forward in this article. First, deflection assessment of composite structures using long-gauge fiber optic sensing was theoretically established. The relationship between vertical displacement and monitored average strain is irrelevant to external loads. The approach is applicable to both linear and nonlinear stages of structures, and deflection distribution along the structures can be estimated. Second, a four-point loading experiment on a wood–concrete composite beam which was installed with long-gauge fiber optic sensors was performed to verify the reliability of the deflection inspection method. Deflection was estimated under three conditions: (1) without considering composite action; (2) considering composite action but neglecting interface slip; and (3) considering both composite action and interface slip. Meanwhile, displacement meters were also installed to verify the calculated results. Experimental results indicate that the presented strategy has high precision. Hence, the presented method serves as an innovative option for assessing composite structures in both the short and long term. Full article

This study presents an experimental and numerical investigation on the impact of embedded fiber optic sensors on the mechanical properties, like tensile, compression, bending and compression-after-impact properties, and sensing performances of intelligent composites. The influence by different volume fractions of embedded fiber optics on the mechanical properties was revealed. Combined with finite element simulations, the effect of embedded sensors on the basic mechanical properties of composite materials was obtained. The sensing performance of the embedded fiber Bragg grating (FBG) sensors was validated through comparison with conventional strain gauges. Full article

This study demonstrates single-channel fiber Bragg grating (FBG) sensing for relative vibration-state monitoring of a motor–support system under angle-dependent boundary conditions. A packaged FBG accelerometer-type sensing unit was mounted on the motor–support structure, and the reflected Bragg wavelength was recorded as a one-dimensional optical vibration response. Because the sensor was installed away from the rotating shaft, the measured wavelength fluctuation was interpreted as a coupled vibration-sensitive response of the motor, fixture, sensor package, bonding condition, and changing boundary state, rather than as a calibrated shaft speed or absolute acceleration signal. Adaptive variational mode decomposition (AVMD) was applied to track the time-varying narrowband spectral-response trajectory of the Bragg-wavelength signal. In parallel, raw wavelength windows were supplied to LSTM, 1D-CNN, and CNN–LSTM autoencoders to evaluate waveform departures from learned nominal fixed-angle behavior. The fixed-angle results showed stable but distinguishable optical vibration responses under different boundary states, whereas the dynamic angle-transition records produced local trajectory changes and alarm-candidate intervals. Baseline and autoencoder comparisons further clarified the trade-off between transition coverage and false-alarm tendency. The RMS threshold baseline was more sensitive to transition-related amplitude changes but produced more false alarms, whereas the CNN–LSTM autoencoder provided the most selective response among the tested autoencoder branches. The results are interpreted as task-specific evidence for relative vibration-state transition monitoring rather than as general motor fault diagnosis. Overall, the framework demonstrates a compact FBG-based route for relative vibration-state transition monitoring when speed references, dense sensor layouts, and labeled fault data are unavailable. Full article

This paper proposes and experimentally demonstrates a fiber ring laser (FRL) salinity sensing system based on a Sagnac loop (SL) formed by a tapered polarization-maintaining fiber (TPMF). The operating principle is that salinity modulates the birefringence of the polarization-maintaining fiber (PMF), causing a shift in the interference wavelength of the SL transmission spectrum, while the FRL narrows the optical spectrum and enhances the signal-to-noise ratio (SNR). In the experiment, the SL consists of a 20-cm-long PMF with a tapered waist diameter of 10.86 μm. Over the salinity range of 0‰ to 30‰, the sensitivity of the laser-based sensing system is 97 pm/‰, which agrees well with the 93 pm/‰ sensitivity obtained using a broadband light source (BBS), and the salinity exhibits a good linear relationship with the wavelength shift, with a coefficient of determination (R²) of 0.997. Meanwhile, the ring laser cavity improves the SNR of the sensing system from 22 dB to approximately 54 dB, and compresses the 3-dB bandwidth from 1.75 nm to 0.06 nm. Further adopting the support vector regression (SVR) algorithm for linear regression modeling of the spectral data, the results show that the mean absolute error (MAE) decreases from 0.50‰ to 0.04‰, the root mean square error (RMSE) decreases from 0.54‰ to 0.11‰, and R² reaches as high as 0.99988. To the best of our knowledge, this is the first work that combines salinity laser sensing with an artificial intelligence algorithm. The proposed sensor leverages the narrow linewidth and high SNR advantages of the FRL together with the high-precision linear fitting capability of the SVR algorithm, achieving significantly improved accuracy for salinity measurement compared to conventional spectral demodulation. Full article

Lithium niobate on insulator (LNOI) has emerged as a promising platform for compact, low-loss phase modulators. The extant LNOI studies evaluate device performance almost exclusively through the Pockels effect, treating piezoelectric–photoelastic strain and thermo-optic drift as decoupled channels. Crucially, both mechanisms directly perturb the phase bias of a fiber-optic gyroscope (FOG), rendering them indispensable in sensing-oriented design. This work establishes a unified multiphysics model of an X-cut TFLN ridge phase modulator that self-consistently couples the electro-optic, piezoelectric–photoelastic, thermo-optic, and pyroelectric channels. The contributions of the four mechanisms are quantitatively decomposed under realistic FOG operating conditions, and the slab thickness, ridge-top width, and electrode gap are systematically optimized to balance modulation efficiency against environmental robustness. The co-optimization of the ridge geometry and electrode gap design maintains the EO overlap factor near 0.55, while reducing the half-wave voltage requirement. This results in a half-wave voltage length of V_πL = 1.65 V·cm at a 4.4 μm electrode gap. The optimized geometry and electrode gap (4.4 μm) are essentially temperature-independent: extracted from the Pockels modulation slope, V_πL remains stable at ≈1.65 V·cm (push–pull single-pass; within ~0.3%) across 25~85 °C. Furthermore, an externally imposed substrate temperature rise of 60 K (the upper end of the 25~85 °C FOG operating range) induces a mode-field-weighted thermal residual corresponding to approximately 27% of the Pockels modulation depth at an applied voltage of 5 V. The present study demonstrates that the DC-coupled operation of TFLN sensor-grade modulators is viable across the full FOG temperature range, without dedicated active temperature stabilization, and the residual thermal-bias offset is absorbed by the FOG’s standard closed-loop servo electronics. The results of the study provide quantitative design guidelines for high-performance, environmentally stable TFLN phase modulators in compact FOG systems. Full article

Although optical fiber-based surface plasmon resonance (SPR) sensors have revolutionized real-time, label-free biosensing, conventional designs suffer from limited multi-analyte detection capabilities. This study utilizes the novel Pi (π)-configured dual SPR optical fiber sensor with two opposing side-polished surfaces, enabling plasmonic excitation for simultaneous multi-analyte detection. The proposed sensor leverages asymmetric metallic thin films such as Ag, Au, Cu, and hybrid configurations (metal + TiO₂) to generate two distinct resonance peaks, significantly enhancing detection versatility. Numerical simulations using the finite element method in COMSOL Multiphysics v6.3 demonstrate that the π-configuration achieves dual resonance dips at 982 nm and 1276 nm for Ag and Ag–TiO₂ films, 1040 nm and 1317 nm for Au and Au–TiO₂ films, and 977 nm and 1249 nm for Cu and Cu–TiO₂ films, respectively, for an analyte refractive index of 1.42. A peak spectral separation >125 nm was achieved for all the sensors for a refractive index range of 1.37–1.42, ensuring that the two dips are resolvable since the change in SPR wavelength is greater than or equal to the full width at half maximum, preserving dual-analyte capability and minimizing potential crosstalk. The results indicate that the π-configured dual SPR sensor utilizing silver and silver–TiO₂ sensing layers had the highest wavelength sensitivity of 12,600 nmRIU⁻¹ and 20,000 nmRIU⁻¹, respectively, slightly outperforming its gold and copper counterpart. The optimized metallic and hybrid nanostructured films ensure dual distinct peaks with high sensitivity, while maximizing refractive index resolution. This work presents the design of a π-configured SPR-based optical fiber sensor utilizing dielectric and multi-metallic thin films, thereby offering a breakthrough in multiplexed biosensing for applications in medical diagnostics, environmental monitoring, and chemical detection. Full article

Accurate pressure measurement under high-temperature conditions is challenging for silica-diaphragm-based fiber-optic Fabry–Perot (F-P) sensors because temperature causes both optical cavity length (OCL) baseline drift and pressure-sensitivity variation. In this work, a structurally simple and readily fabricated silica-diaphragm-based fiber-optic F-P pressure sensor was developed, and a neural-network-assisted compensation strategy was proposed to suppress the residual errors of conventional analytical compensation. A temperature-dependent response model was established to describe OCL drift and sensitivity variation. The OCL was demodulated from reflection spectra using an FFT-assisted dual-peak and MMSE refinement method, and static pressure measurements were performed over 25–400 °C and 0–2.4 MPa. Based on the experimentally verified response characteristics, a fitting-based compensation method considering both OCL drift and sensitivity variation was first implemented. A lightweight neural network was then constructed using the OCL variation, $\Delta \mathrm{O}\mathrm{C}\mathrm{L}$, and ambient temperature as physically meaningful input features. Compared with fixed-sensitivity compensation and drift-and-sensitivity fitting compensation, whose maximum full-scale errors were 7.10% F.S. and 2.74% F.S., respectively, the proposed method reduced the maximum error to 0.90% F.S. with an RMSE of 0.0045 MPa. Additional validation at the independent intermediate temperatures of 150, 250, and 350 °C further confirmed the generalization capability of the proposed NNC model between calibrated temperature gradients, achieving an overall RMSE of 0.0055 MPa and a maximum full-scale error below 0.77% F.S. The proposed approach provides a high-accuracy and practical solution for high-temperature pressure monitoring using simple fabricated silica-diaphragm F-P sensors. Full article

Due to the limited application of sensors in the low-refractive-index range, accurate detection of certain low-refractive-index objects remains challenging. To address this limitation, this study proposes a novel D-shaped photonic crystal fiber (PCF) operating on the surface plasmon resonance (SPR) principle. Distinct from conventional D-type PCF designs, the proposed structure employs an open-loop channel coated with a gold film to enable efficient excitation. Finite element analysis shows that the sensor’s detection range of refractive index is between 1.23 and 1.32. With increasing analyte refractive index, the loss peak exhibits progressive broadening and eventual stabilization. A maximum spectral sensitivity of 18,500 nm/RIU and a resolution of 5.41 × 10⁻⁶ RIU are attained at a refractive index of 1.32. The sensor features a straightforward design and exhibits excellent performance characteristics. Its exceptional sensing capabilities make it highly competitive for use in applications with a low refractive index. At the same time, to optimize the sensing performance, this study investigates how structural parameters affect the resonant spectrum. Full article

In this work, we propose a hyperbolic metamaterials (HMMs)-based coreless fiber surface plasmon resonance (SPR) sensor. Leveraging the absence of a core in coreless fibers, the evanescent waves at the cladding–external solution interface couple more effectively into the solution, enabling surface plasmon resonance without any additional processing. To enhance sensitivity, we adopted a multimode–coreless–multimode (MCM) structure and grew layered hyperbolic metamaterials as the SPR-excitation-sensitive layer within the coreless region. Through finite element simulations, we optimized HMM parameters and fabricated high-performance HMM-SPR sensors. Test results demonstrate that the fabricated HMM-SPR sensor achieves an optimal refractive index sensitivity of 3703.33 nm/RIU, representing a 49.68% improvement over single-layer gold film SPR sensors. It successfully detects glucose solutions at varying concentrations with a sensitivity of 2671.25 nm/RIU. The high-sensitivity, structurally simple HMM-SPR sensor we proposed demonstrates broad application prospects in biosensing, environmental monitoring, food safety, and other fields. Full article

Accurate state-of-charge (SOC) estimation is essential for the safe and efficient operation of lithium-ion batteries. However, the weak voltage observability of lithium iron phosphate (LFP) batteries within the voltage plateau region limits the accuracy of conventional voltage-based methods. To address this issue, an electro–mechanical information fusion framework for SOC estimation is proposed. Fiber Bragg grating (FBG) sensors were employed to simultaneously measure the surface strain and temperature of prismatic LFP batteries. Experimental results showed that the strain signal exhibited a stronger correlation with SOC than the voltage signal, with an average absolute correlation coefficient of 0.92. A Thevenin equivalent circuit model combined with an adaptive forgetting factor recursive least squares (AFFRLS) algorithm was established for online voltage modeling, while a Mamba-based strain model was developed to capture the nonlinear temporal relationship between multidimensional sensing data and battery strain. The two models were further integrated with adaptive unscented Kalman filters (AUKFs) and fused through a dual-layer adaptive weighting strategy. Experimental results under the five operating conditions considered in this study demonstrated that the proposed method achieved average RMSE and MAE values of 0.98% and 0.80%, respectively, outperforming standalone voltage- and strain-based methods. Full article

We demonstrate a mechanism-oriented Surface-Enhanced Raman Scattering (SERS) platform based on a hybrid structure integrating monolayer molybdenum disulfide (MoS₂) and gold nanospheres (AuNSs) on an optical microfiber (MF). The microfiber serves as a whispering-gallery-mode (WGM) microcavity. Monolayer MoS₂, grown directly on the microfiber surface via chemical vapor deposition (CVD), provides a chemically active interface for molecular adsorption and charge-transfer-related chemical enhancement. Subsequently deposited AuNSs couple with the microfiber-supported WGM, leading to the formation of hybrid photonic–plasmonic modes. This coupling results in a narrowed scattering resonance and a localized electromagnetic hotspot near the AuNS–microfiber interface. The combined contribution of electromagnetic enhancement from the microfiber–AuNS hybrid cavity and chemical enhancement from the MoS₂ layer produces discernible Raman enhancement for Rhodamine 6G (R6G) molecules under proof-of-concept measurement conditions. This work provides a useful platform for studying SERS enhancement mediated by hybrid photonic–plasmonic modes and offers guidance for the future development of optimized fiber-based SERS sensors. Full article

Fiber optic gyroscopes (FOGs) are core sensors in inertial navigation systems, and their miniaturization and integration are currently hot research topics. This work presents an FOG system driven by a silicon photonics integrated circuit (PIC). The PIC, based on a 90 nm silicon-on-insulator (SOI) process, integrates core components such as polarizers, 3 dB couplers, and phase modulators within a compact footprint of 3 × 0.45 mm². These components exhibit excellent performance over a wide spectral range and play a crucial role in high-performance FOG systems. Experimental results show that the proposed FOG system can definitively measure the small angular velocity of the Earth’s rotation (±7.5 °/h). Further Allan variance analysis reveals that the FOG system has an angular random walk (ARW) of 0.00358 °/h^1/2 and a bias instability (BIS) of 0.1185 °/h. These results demonstrate the application potential of silicon photonics-based FOG systems. Full article
